Wireless Capsule Endoscopy (WCE) is a minimally invasive technology for imaging the gastrointestinal (GI) tract, particularly the small intestine, where conventional endoscopy faces accessibility limitations. Traditional capsule endoscopes rely on passive motion driven by natural peristalsis, which limits controllability and may increase the risk of capsule retention. To address these challenges, this study presents the design and experimental validation of a compliant active capsule endoscope actuated by four Shape Memory Alloy (SMA) spring actuators. A key feature of the proposed system is a steering mechanism that reuses the same SMA actuators responsible for locomotion, enabling control of the camera orientation without increasing system complexity, size, or weight. The capsule architecture consists of rigid polylactic acid (PLA) links connected through thermoplastic polyurethane (TPU) flexure hinges, fabricated using dual-material 3D printing. Nonlinear finite element analysis (FEA) was employed to optimize the flexure hinge geometry for maximum displacement while maintaining safe stress levels. To validate the concept, a $3.5\times$ scaled prototype was fabricated and integrated with SMA actuators and an Arduino-based control system. The experimental results demonstrate effective locomotion and steering capabilities, achieving a maximum stroke of approximately 5.4 mm and a steering angle of 24° for the $3.5\times$ scaled prototype, corresponding to an estimated stroke of approximately 1.98 mm (Based on the FEA) at the intended clinical scale. Thermal characterization of the SMA actuators was also conducted to identify suitable operating current ranges for future biomedical deployment. The results demonstrate the feasibility of integrating locomotion and steering within a compact compliant capsule architecture, representing a step toward next-generation capsule endoscopy systems with improved navigation and diagnostic capability. Full article

This paper focuses on the modeling and design of an adaptive vortex generator (AVG). The device is actuated through shape memory alloy (SMA) elements. The interest of the research community in these devices is due to their ability to improve the performance of the aircraft, directly altering and controlling the boundary layer. Their action consists of energizing the flow, thereby hindering separation. The peculiarity of the presented AVG architecture lies in its compactness and adaptability, which allows for its activation just for some specific phases that are not adequately covered by the conventional. This system can enable load alleviation in the cruise phase when a gust occurs (spoiler modality) and stall prevention in high-lift conditions (vane modality). These two working capabilities can be obtained by mounting the AVGs at different angles of incidence, with respect to the direction of the flow. The present paper is structured as follows. First, the project of RADAR, hosting the activities, is presented with specific focus on the main objectives and on the strategy of maturation of the technologies. Then, attention is paid to the simulations of the aerodynamic field produced by the AVG. These outcomes have driven the next part of the work, focusing on the identification of the architecture of the AVG. A dedicated finite element modeling approach was implemented to address the design task, even in the presence of SMA non-linear elements. Three main operational phases were simulated: (1) the stretching of the springs up to their connection to the architecture (pre-load phase); (2) the elastic recovery of the springs and the achievement of equilibrium with the hosting structure; and (3) the activation of the springs through heating to deflect the AVG. The simulations proved the capability of the system to produce the required deflection/deployment, even under the most severe load conditions. In particular, the simulations highlighted the capability of the system to produce a deflection of the vortex generator of 83.5 deg under the most severe load conditions, against the required value of 80 deg. This result was obtained by also keeping the structural safety factor at a value of four, in line with the wind tunnel facility requirement. Another key outcome of the dynamic analysis was the absence of coupling with vortex shedding, since the system resonance frequencies (135 and 415 Hz) are well outside the vortex-shedding frequency range (500–1400 Hz). Full article

The development of upper-limb prostheses is often hindered by limited dexterity, a restricted workspace, and bulky designs, primarily due to performance limitations in proximal joints like the shoulder and elbow, which contribute to high user abandonment rates. To overcome these challenges, this paper presents a novel, bioinspired, and integrated prosthetic system as an advancement in bionic technology. The design incorporates a shoulder joint based on an asymmetric 3-RRR spherical parallel mechanism (SPM) with actuators embedded within the moving platform, and an elbow joint actuated by low-voltage Shape Memory Alloy (SMA) springs. The inverse kinematics of the shoulder mechanism was established, revealing the existence of up to eight configurations. We employed Multi-Objective Particle Swarm Optimization (MOPSO) to simultaneously maximize workspace coverage, enhance dexterity, and minimize joint torque. The optimized design achieves remarkable performance: (1) 85% coverage of the natural shoulder’s workspace; (2) a maximum von Mises stress of merely 3.4 MPa under a 40 N load, ensuring structural integrity; and (3) a sub-0.2 s response time for the SMA-driven elbow under low-voltage conditions (6 V) at a motion velocity of 6°/s. Both motion simulation and prototype testing validated smooth and anthropomorphic motion trajectories. This work provides a comprehensive framework for developing lightweight, high-performance prosthetic limbs, establishing a solid foundation for next-generation wearable robotics and bionic devices. Future research will focus on the integration of neural interfaces for intuitive control. Full article

This study presents a small-scale hip exoskeleton incorporating bi-directional artificial muscles constructed with springs of Shape Memory Alloy (SMA). The prototype can effectively support hip motion in both extension and flexion, spanning an angular range of $-{20}^{°}$ to ${200}^{°}$. Experiments for thermo-mechanical characterization were executed to assess the performance of the SMA muscles throughout the entire motion range. The outcomes not only confirmed the suitability of the SMA muscles for the designed exoskeleton but also provided valuable insights into their behavior and capabilities. System identification experiments were carried out to establish an accurate transfer function, guiding the tuning of Proportional-Integral-Derivative (PID) controllers for enhanced motion-control effectiveness. The safety of the SMA system was addressed with a focus on preventing overheating. Challenges in accurately measuring the temperature of a thin spring were overcome by utilizing two thermocouples for each SMA springs group. Additionally, conventional SMA temperature measurement methods, such as infrared and resistance-based techniques, are limited by high cost, nonlinearity, and small range. This study presents a model-based temperature estimation algorithm that integrates a heat transfer model, electrical input data, and thermocouple data to enable accurate and real-time SMA temperature estimation without additional sensors, offering a cost-effective and reliable alternative. To evaluate the small hip prototype and its controller capabilities, control experiments were executed for both stepping and sinusoidal trajectories. The exoskeleton successfully tracked the desired trajectories, showing its precision. Moreover, system performance under adaptive control was further investigated, revealing an RMSE of $0.{94}^{°}$ in sinusoidal trajectory experiments, indicating reliable disturbance rejection in the angle measurements. Full article

Wall plate rupture in liquid storage structures (LSSs) induced by earthquakes is a prevalent issue. To mitigate the impacts of seismic hazards on plate–shell composite concrete liquid storage structures (CLSSs), in this study, we propose an investigation into X-type mild steel–Shape Memory Alloy (SMA) seismic mitigation control for plate–shell composite CLSSs with sand-layer seismic isolation. Via finite element parametric analysis, this study examines the effects of two key parameters—the sand-layer friction coefficient and the spring-damping ratio of X-type mild steel–SMA seismic mitigation elements—on the dynamic response of CLSSs. The results indicate the following: under unidirectional seismic excitation, the proposed mitigation method achieves a favorable control effect on the maximum principal stress of the structure; under bidirectional seismic excitation, the optimal control effect on the maximum principal stress is achieved when the spring-damping ratio of the mitigation elements is 0.3 and the friction coefficient of the seismic isolation sand layer is 0.4. Additionally, under both unidirectional and bidirectional seismic excitation, this method exhibits a noticeable control effect on the peak liquid sloshing height. Full article

This study presents a phenomenological model for predicting the thermomechanical behaviour of spring-type actuators made of shape memory alloys (SMAs). The model incorporates the kinetics of martensite–austenite phase transitions as a function of temperature and applied stress. The primary innovation is the inclusion of a scalar internal variable that represents the evolution of the phase transformation within a phenomenological macroscopic model. This approach enables the deformation–force–temperature behaviour of SMA-based spring elements under cyclic loading to be accurately described. A set of constitutive equations was derived to describe reversible and residual strains, along with transformation start and finish conditions. Model parameters were calibrated using experimental data from VSP-1 and TN-1K SMA springs that were subjected to thermal cycling. The validation results show a high correlation between the theoretical predictions and the experimental data, with deviation margins of less than 6.5%. The model was then applied to designing and analysing thermosensitive actuator mechanisms for temperature control systems. This yielded accurate deformation–force characteristics, demonstrating low inertia and high repeatability. This approach enables the efficient prediction and improvement of the performance of SMA-based spring elements in actuators, making it relevant for adaptive systems in marine and aerospace applications. Full article

This study presents a novel, bioinspired perching mechanism designed to enhance the landing and takeoff capabilities of flapping wing micro aerial vehicles (FWMAVs). Drawing inspiration from the human hand, the lightweight gripper integrates a compliant claw structure actuated by shape memory alloys (SMAs) that mimic muscle movement. These SMA springs act as compact, lightweight substitutes for traditional actuators like motors or solenoids. The mechanism operates via short electrical impulses that trigger both opening and closing motions. A detailed design process was undertaken to optimize phalange lengths for cylindrical grasping and to select appropriate SMAs for reliable performance. Weighing only 50 g, the gripper leverages the high power-to-weight ratio and flexibility of SMAs, with the springs directly embedded within the phalanges to reduce size and mass while preserving high-force output. Experimental results demonstrate fast actuation and a grasping force of approximately 16 N, enabling the gripper to hold objects of varying shapes and sizes and perform perching, grasping, and carrying tasks. Compared to existing solutions, this mechanism offers a simpler, highly integrated structure with enhanced miniaturization and adaptability, making it especially suitable for low-payload MAV platforms like FWMAVs. Full article

Most trunk-like robots are designed with distributed actuators to mimic the envelope-grasping behavior of elephant trunks in nature, leading to a complex actuation system. In this paper, a modular underactuated elephant trunk-imitating robot based on the combined drive of the cable and shape memory alloy (SMA) springs is designed. Unlike the traditional underactuated structure that can only passively adapt to the envelope of the object contour, the proposed elephant trunk robot can control the cable tension and the equivalent stiffness of the SMA springs to achieve active control of the envelope morphology for different target objects. The overall structure of the elephant trunk robot is designed and the principle of deformation envelope is elucidated. Based on the static model of the robot under load, the mapping relationship between the tension force and the tension angle between modules is derived. The positive kinematic model of the elephant trunk robot is established based on the Debavit–Hartenberg (D–H) method, the spatial position of the elephant trunk robot is obtained, and the Monte Carlo method is used to derive the robot’s working space. The active bending envelope grasping performance is further verified by building the prototype to perform grasping experiments on objects of various shapes. Full article

The idle air control actuator is an important device in automotive engine management systems to reduce fuel consumption by controlling the engine’s idling operation. This research proposes an innovative idle air control (IAC) actuator for vehicle applications utilizing shape memory alloy (SMA) technology. The proposed actuator leverages the unique properties of SMAs, such as the ability to undergo large deformations upon thermal activation, to achieve precise and rapid controls in the air intake of automotive engines during idle conditions. The actuator structure mechanism consists of an SMA spring and an antagonistic spring made from steel. The design process utilizes both numerical and analytical approaches. The SMA spring is electrically supplied to activate the opening process of the actuator, and its closing state does not need electricity. However, the PID controller is used to control the applied current, which reduces the time taken by the actuator to achieve the actuation strokes. It shows good operability within multiple numbers of operation cycles. Additionally, the performance of the designed actuator is evaluated through mathematical algorithms by integrating it into the engine’s air intake system during idle operating conditions. The results demonstrate the effectiveness of the SMA-based actuator in achieving rapid control of the air intake through bypass, thereby improving engine idle conditions. Full article

Every year, almost 4 million patients received medical care for knee osteoarthritis. Osteoarthritis involves progressive deterioration or degenerative changes in the cartilage, leading to inflammation and pain as the bones and ligaments are affected. To enhance treatment and surgical outcomes, various studies analyzing the biomechanics of the human skeletal system by fabricating simulated bones, particularly those reflecting the characteristics of patients with knee osteoarthritis, are underway. In this study, we fabricated replicated bones that mirror the bone characteristics of patients with knee osteoarthritis and developed a skeletal model that mimics the actual movement of the knee. To create patient-specific replicated bones, models were extracted from computerized tomography (CT) scans of knee osteoarthritis patients. Utilizing 3D printing technology, we replicated the femur and tibia, which bear the weight of the body and support movement, and manufactured cartilage capable of absorbing and dispersing the impact of knee joint loads using flexible polymers. Furthermore, to implement knee movement in the skeletal model, we developed artificial muscles based on shape memory alloys (SMAs) and used them to mimic the rolling, sliding, and spinning motions of knee flexion. The knee movement was investigated by changing the SMA spring’s position, the number of coils, and the applied voltage. Additionally, we developed a knee-joint-mimicking system to analyze the movement of the femur. The proposed artificial-skeletal-model-based knee-joint-mimicking system appears to be applicable for analyzing skeletal models of knee patients and developing surgical simulation equipment for artificial joint replacement surgery. Full article

This paper illustrates an experimental activity for the closed-loop position control of an actuator made using shape memory alloy (SMA) wire. A solution with the self-sensing effect was implemented to miniaturize the systems, i.e., without external sensors. A proportional control algorithm was initially used, demonstrating the idea’s feasibility; the wire can behave simultaneously as an actuator and sensor. An experimental investigation was subsequently conducted for the optimization of the developed actuator. As for the material, a Flexinol wire, Ni-Ti alloy, with a diameter of 0.150 mm and a length of 200 mm, was used. Preliminarily, characterization of the SMA wire at constant and variable loads was carried out; the characteristics detected were elongation vs. electric current and elongation vs. electrical resistance. The control system is PC based with a data acquisition card (DAQ). A drive board was designed and built to read the wire’s electrical resistance and power it by pulse width modulation (PWM). A notable result is that the actuator works with good precision and in dynamic conditions, even when it is called to support a load up to 65% different from that for which the electrical resistance–length correlation has previously been experimentally obtained, on which the control is based. This opens up the possibility of using the actuator in a counteracting configuration with a spring, which makes hardware implementation and control management simple. Full article

This study presents the design and evaluation of a prototype snake-like robot that possesses an actuation system based on shape memory alloys (SMAs). The device is constructed based on a modular structure of links connected by two degrees of freedom links utilizing Cardan joints, where each degree of freedom is actuated by an agonist–antagonist mechanism using the SMA spring-shaped actuators to generate motion, which can be easily replaced once they reach a degradation point. The methodology for programming the spring shape into the SMA material is described in this work, as well as the instrumentation required for the monitoring and control of the actuators. A simplified design is presented to describe the way in which the motion is performed and the technical difficulties faced in manufacturing. Based on this information, the way in which the design is adapted to generate a feasible robotic system is described, and a mathematical model for the robot is developed to implement an independent joint controller. The feasibility of the implementation of the SMA actuators regarding the motion of the links is verified for the case of a joint, and the change in the shape of the snake robot is verified through the implementation of a set of tracking references based on a central pattern generator. The generated tracking results confirm the feasibility of the proposed mechanism in terms of performing snake gaits, as well as highlighting some of the drawbacks that should be considered in further studies. Full article

Shape Memory Alloys (SMAs) are a class of metallic alloys that have the ability to return to their original shape after being deformed. NiTi (nickel–titanium) alloy a type of shape memory alloy that possesses unique properties such as remembering its shape, biocompatibility, and super-elasticity. These SMAs have the ability to deform when heated and regain their original shape when allowed to cool. The disadvantage of a fuse is that it can only be used once. By replacing a wire that melts with a NiTi shape memory alloy, we can turn it into a switch that opens when an excessive current (which leads to an increase in temperature of the wire) is applied. Magnets keep the circuit closed. When the wire heats up, the spring-shaped coil shrinks, which opens the circuit. The circuit can then be closed manually once the problems are rectified. Full article

Due to their weight, the seismic response control of buildings needs a large-scale damper. To reduce the consumption of shape memory alloys (SMAs), this study proposed a dual self-centering pattern accomplished by the coil springs and SMA, which could drive the energy dissipation device to recenter. Combined with the friction energy dissipation device (FD), the dual self-centering friction damper (D-SCFD) was designed, and the motivation and parameters were described. The mechanical properties of D-SCFD, including the simplified D-SCFD mechanical model, theoretical index calculations of recentering, and energy dissipation performance, were then investigated. The seismic response mitigation of the steel frame adopting the D-SCFDs under consecutive strong earthquakes was finally analyzed. The results showed that a decrease in the consumption of SMA by the dual self-centering pattern was feasible, especially in the case of low demand for the recentering performance. Reducing the D-SCFD’s recentering performance hardly affected the steel frame’s residual inter-story drift ratios when the residual deformation rate was less than 50%, which can help strengthen the controls on the steel frame’s peak seismic responses. It is recommended to utilize the D-SCFD with not too high a recentering performance to mitigate the seismic response of the structure. Full article

Shape memory alloys (SMAs) have become the most common choice for the development of mini- and micro-type soft bio-inspired robots due to their high power-to-weight ratio, ability to be installed and operated in limited space, silent and vibration-free operation, biocompatibility, and corrosion resistance properties. Moreover, SMA spring-type actuators are used for developing different continuum robots, exhibiting high degrees of freedom and flexibility. Spring- or any elastic-material-based antagonistic or biasing force is mostly preferred among all other biasing techniques to generate periodic oscillation of SMA actuator-based robotic body parts. In this model-based study, SMA-based spring-type actuators were used to develop a carangiform-type robotic fishtail. Fin size optimization for the maximization of forward thrust was performed for the developed system by varying different parameters, such as caudal fin size, current through actuators, pulse-width modulation signal (PWM), and operating depth. A caudal fin with a mixed fin pattern between the Lunate and Fork “Lunafork” and a fin area of approximately 5000 mm² was found to be the most effective for the developed system. The maximum forward thrust developed by this fin was recorded as 40 gmf at an operation depth of 12.5 cm in a body of still water. Full article
