The shortwave time service system is a vital land-based wireless time service solution, serving as a supplement and backup to the global navigation satellite system. It ensures that time users can access reliable timings, especially in extreme situations. However, the current BPM shortwave time service signal in China faces issues such as insufficient anti-interference reception capabilities and poor timing accuracy. This paper capitalizes on the advantages of Chirp signals and explores a new modulation technology for BPM shortwave time signals that is compatible with the existing modulation system. A Dual Chirp Time-Division Combined Modulation (DCTDCM) scheme is proposed for broadcasting two time signals: Coordinated Universal Time (UTC) and Universal Time 1 (UT1). Furthermore, an in-depth study of the receiving method for this scheme is conducted, with detailed design of its parameters. The designed DCTDCM signals offer a spread spectrum gain of 24 dB and a multipath resolution capability of at least 125 μs, significantly enhancing the anti-interference reception and anti-multipath attenuation capabilities of shortwave time signals. As a result, the availability and timing accuracy of shortwave time signals are substantially improved. Finally, extensive comparative experiments on reception performance validate the effectiveness of this approach. Full article

Aluminum thermal welding joints are widely used in the maintenance welding of heavy-haul railways due to their easy handling and high efficiency. However, due to their inherent welding characteristics, welding results in certain differences in the material’s physical properties at the welding zone compared to adjacent base materials, leading to the occurrence of short-wave irregularity under long-term wheel–rail interactive forces. In order to explore the evolution characteristics of weld irregularity, dynamic characteristics, and plastic deformation under long-term wheel–rail impact, a detailed tracking test was conducted on a normal aluminum weld, and the process from being put on the track to being damaged and replaced was evaluated. At the same time, a rigid–flexible coupling model was established for subsequent analysis, and plastic damage was analyzed using the finite element model. The results show that the service life of the weld can be divided into three different stages: the initial stage, the intermediate stage, and the damage stage. In the damage stage, a temporary separation occurred between the wheel and rail, leading to a sudden change in the wheel–rail interaction. The weight of 250 MT at the weld reached the repairment control limit. The concentration effect of equivalent plastic deformation was most serious at 2~5 mm below the rail head. Full article

Near real-time aerosol fields from the Copernicus Atmospheric Monitoring Services (CAMS), operated by the European Centre for Medium-Range Weather Forecasts (ECMWF), are configured for use in the HARMONIE-AROME Numerical Weather Prediction model. Aerosol mass mixing ratios from CAMS are introduced in the model through the first guess and lateral boundary conditions and are advected by the model dynamics. The cloud droplet number concentration is obtained from the aerosol fields and used by the microphysics and radiation schemes in the model. The results show an improvement in radiation, especially during desert dust events (differences of nearly 100 W/m² are obtained). There is also a change in precipitation patterns, with an increase in precipitation, mainly during heavy precipitation events. A reduction in spurious fog is also found. In addition, the use of the CAMS near real-time aerosols results in an improvement in global shortwave radiation forecasts when the clouds are thick due to an improved estimation of the cloud droplet number concentration. Full article

The smart environmental management system proposed in this work offers a new approach to environmental monitoring by utilizing data from IoT stations and MODIS satellite imagery. The system is designed to be deployed in vast regions, such as the Mekong Delta, with low building and operating costs, making it a cost-effective solution for environmental monitoring. The system leverages telemetry data collected by IoT stations in combination with MODIS MOD09GA, MOD11A1, and MCD19A2 daily image products to develop computational models that calculate the values land surface temperature (LST), 2.5 and 10 (µm) particulate matter mass concentrations (PM2.5 and PM10) in areas without IoT stations. The MOD09GA product provides land surface spectral reflectance from visible to shortwave infrared wavelengths to determine land cover types. The MOD11A1 product provides thermal infrared emission from the land surface to compute LST. The MCD19A2 product provides aerosol optical depth values to detect the presence of atmospheric aerosols, e.g., PM2.5 and PM10. The collected data, including remote sensing images and telemetry sensor data, are preprocessed to eliminate redundancy and stored in cloud storage services for further processing. This allows for automatic retrieval and computation of the data by the smart data processing engine, which is designed to process various data types including images and videos from cameras and drones. The calculated values are then made available through a graphic user interface (GUI) that can be accessed through both desktop and mobile devices. The GUI provides real-time visualization of the monitoring values, as well as alerts to administrators based on predetermined rules and values of the data. This allows administrators to easily monitor the system, configure the system by setting alerting rules or calibrating the ground stations, and take appropriate action in response to alerts. Experimental results from the implementation of the system in Dong Thap Province in the Mekong Delta show that the linear regression models for PM2.5 and PM10 estimations from MCD19A2 AOD values have correlation coefficients of 0.81 and 0.68, and RMSEs of 4.11 and 5.74 µg/m${}^3$, respectively. Computed LST values from MOD09GA and MOD11A1 reflectance and emission data have a correlation coefficient of 0.82 with ground measurements of air temperature. These errors are comparable to other models reported in similar regions in the literature, demonstrating the effectiveness and accuracy of the proposed system. Full article

SAET (Shoreline Analysis and Extraction Tool) is a novel open-source tool to enable the completely automatic detection of shoreline position changes using the optical imagery acquired by the Sentinel-2 and Landsat 8 and 9 satellites. SAET has been developed within the ECFAS (European Coastal Flood Awareness System) project, which is intended to be the first European service for coastal flood forecasting, management, and recovery analysis. The tool is developed to characterise the shoreline response associated with punctual events such as coastal storms as well as any other phenomenon. For a given beach segment, SAET facilitates the selection of the satellite images closest in time to the analysed events that offer an adequate cloud coverage level for analysing the shoreline change. Subsequently, the tool automatically downloads the images from their official repositories, pre-processes them and extracts the shoreline position with sub-pixel accuracy. In order to do so, an initial approximate definition of the shoreline is carried out at the pixel level using a water index thresholding, followed by an accurate extraction operating on the shortwave infrared bands to produce a sub-pixel line in vector formats (points and lines). The tool offers different settings to be adapted to the different coastal environments and beach typologies. Its main advantages refer to its autonomy, its efficiency in extracting complete satellite scenes, its flexibility in adapting to different environments and conditions, and its high subpixel accuracy. This work presents an accuracy assessment on a long Mediterranean sandy beach of SDSs extracted from L8 and S2 imagery against coincident alongshore reference lines, showing an accuracy of about 3 m RMSE. At the same time, the work shows an example of the usage of SAET for characterising the response to Storm Gloria (January 2020) on the beaches of Valencia (E Spain). SAET provides an efficient and completely automatic workflow that leads to accurate SDSs while only relying on publicly available information. The tool appears to be a useful extraction tool for beach monitoring, both for public administrations and individual users. Full article

The organic coating of bridge steel girders is subjected to physical scratches, corrosion, and aging in natural weathering. The breakdown of the coating may cause serviceability and safety problems if left unnoticed. Conventional coating inspection is time-consuming and lacks information about the coating’s chemical integrity. A hyperspectral imaging method is proposed to detect the condition of steel coatings based on coating-responsive features in reflectance spectra. A field test was conducted on the real-world bridge, which shows obvious signs of degradation. The hyperspectral signature enables an assessment of the coating’s health and defect severity. The results indicated that the coating scratch can be effectively located in the domain of a hyperspectral image and the scratch depth can be determined by mapping a scratch depth indicator (SDI = R532 nm/R641 nm). Rust sources and products in steel girders can be identified by the unique spectral signatures in the VNIR range, and the rust stains (and thus stain areas) scattered on the coating can be pinpointed at pixel level by the chloride rust (CR) indicators >1.11 (CR = R733 nm/R841 nm). The chemical integrity of a topcoat is demonstrated by the short-wave infrared spectroscopy and the topcoat degradation can be evaluated by the decreased absorption at 8000 cm⁻¹ and 5850 cm⁻¹. Hyperspectral imaging enables faster and more reliable coating condition detection by the spectral features and provides an alternative for multi-object coating detection. Full article

Surface albedo, as an important parameter for land surface geo-biophysical and geo-biochemical processes, has been widely used in the research communities involved in surface energy balance, weather forecasting, atmospheric circulation, and land surface process models. In recent years, operational products using satellite-based surface albedo have, from time to time, been rapidly developed, contributing significantly to the estimation of energy balance at regional or global scales. The increasing number of research topics on dynamic monitoring at a decades-long scale requires a combination of albedo products generated from various sensors or programs, while the quantitative assessment of agreement or divergence among different surface albedo products still needs further understanding. In this paper, we investigated the consistency of three classical operational surface albedo products that have been frequently used by researchers globally via the official issued datasets-MODIS, GLASS (Global LAnd Surface Satellite), and CGLS (Copernicus Global Land Service). The cross-comparison was performed on all the identical dates available during 2000–2017 to represent four season-phases. We investigated the pixel-based validity of each product, consistency of global annual mean, spatial distribution and different temporal dynamics among the discussed products in white-sky (WSA) and black-sky (BSA) albedo at visible (VIS), near-infrared (NIR), and shortwave (SW) regimes. Further, varying features along with the change of seasons was also examined. In addition, the variation in accuracy of shortwave albedo magnitude was explored using ground measurements collected by the Baseline Surface Radiation Network (BSRN) and the Surface Radiation Budget Network (SUFRAD). Results show that: (1) All three products can provide valid long-term albedo for dominant land surface, while GLASS can provide additional estimation over sea surfaces, with the highest percentage of valid land surface pixels, at up to 93% in 24 October. The invalid pixels mainly existed in the 50°N–60°N latitude belt in December for GLASS, Central Africa in April and August for MODIS, and northern high latitudes for CGLS. (2) The global mean albedo of CGLS at the investigated bands has significantly higher values than those of MODIS and GLASS, with a relative difference of ~20% among the three products. The global mean albedo of MODIS and GLASS show a generally increasing trend from April to December, with an abrupt rise at NIR and SW of CGLS in June of 2014. Compared with SW and VIS bands, the linear temporal trend of the NIR global albedo mean in three products continues to increase, but the slope of CGLS is 10–100 times greater than that of the other two products. (3) The differences in albedo, which are higher in April, October, and December than in August, exhibit a small variation over the main global land surface regions, except for Central Eurasia, North Africa, and middle North America. The magnitude of global absolute difference among the three products usually varies within 0.02–0.06, but with the largest value occasionally exceeding 0.1. The relative difference is mainly within 10–20%, and can deviate more than 40% away from the baseline. In addition, CGLS has a greater opportunity to achieve the largest difference compared with MODIS and GLASS. (4) The comparison with ground measurements indicates that MODIS generally performs better than GLASS and CGLS at the sites discussed. This study demonstrates that apparent differences exist among the three investigated albedo products due to the ingested source data, algorithm, atmosphere correction etc., and also points at caution regarding data fusion when multiple albedo products were organized to serve the following applications. Full article

The proliferation of photovoltaic (PV) power generation in power distribution grids induces increasing safety and service quality concerns for grid operators. The inherent variability, essentially due to meteorological conditions, of PV power generation affects the power grid reliability. In order to develop efficient monitoring and control schemes for distribution grids, reliable forecasting of the solar resource at several time horizons that are related to regulation, scheduling, dispatching, and unit commitment, is necessary. PV power generation forecasting can result from forecasting global horizontal irradiance (GHI), which is the total amount of shortwave radiation received from above by a surface horizontal to the ground. A comparative study of machine learning methods is given in this paper, with a focus on the most widely used: Gaussian process regression (GPR), support vector regression (SVR), and artificial neural networks (ANN). Two years of GHI data with a time step of 10 $\min$ are used to train the models and forecast GHI at varying time horizons, ranging from 10 $\min$ to 4 $\mathrm{h}$. Persistence on the clear-sky index, also known as scaled persistence model, is included in this paper as a reference model. Three criteria are used for in-depth performance estimation: normalized root mean square error (nRMSE), dynamic mean absolute error (DMAE) and coverage width-based criterion (CWC). Results confirm that machine learning-based methods outperform the scaled persistence model. The best-performing machine learning-based methods included in this comparative study are the long short-term memory (LSTM) neural network and the GPR model using a rational quadratic kernel with automatic relevance determination. Full article

A novel approach for a blending between nowcasting and numerical weather prediction (NWP) for the surface incoming shortwave radiation (SIS) for a forecast horizon of 1–5 h is presented in this study. The blending is performed with a software tool called ANAKLIM++ (Adjustment of Assimilation Software for the Reanalysis of Climate Data) which was originally designed for the efficient assimilation of two-dimensional data sets using a variational approach. A nowcasting for SIS was already presented and validated in earlier publications as seamless solar radiation forecast (SESORA). For our blending, two NWP models, namely the ICON (Icosahedral Non-hydrostatic model) from the German weather Service (DWD) and the IFS (Integrated Forecasting System) from the European Centre for Medium-Range Weather Forecasts (ECMWF), were used. The weights for the input data for ANAKLIM++ vary for every single forecast time and pixel, depending on the error growth of the nowcasting. The results look promising, since the root mean square error (RMSE) and mean absolute error (MAE) of the blending are smaller than the error measures of the nowcasting or NWP models, respectively. Full article

Many wetlands are characterized by a vegetation cover of variable height and density over time. Tracking spatio-temporal changes in inundation patterns of these wetlands remains a challenge for remote sensing. Water In Wetlands (WIW) was predicted using a dichotomous partitioning of reflectance values encoded based on ground-truth (n = 4038) and optical-space derived (n = 7016) data covering all land cover types (n = 17) found in the Rhône delta, southern France. The models were developed with spectral data from Sentinel 2, Landsat 7, and Landsat 8 sensors, hence providing a monitoring tool that covers a 35-year period (same sensor for Landsat 5 and 7). A single model combining the near infrared (NIR ≤ 0.1558 to 0.1804, depending on sensors) and short-wave infrared (SWIR2 ≤ 0.0871 to 0.1131) wavelengths was identified by three independent analyses, each one using a different satellite. Overall accuracy of water maps ranged from 89% to 94% for the training samples and from 90% to 94% for the validation samples, encompassing standard water indices that systematically underestimate flooding duration under vegetation cover. Sentinel 2 provided the highest performance with a kappa coefficient of 0.82 for both samples. Such tool will be most useful for monitoring the water dynamics of seasonal wetlands, which are particularly sensitive to climate change while providing multiple services to humankind. Considering the high temporal resolution of Sentinel 2 (every 5 days), cumulative water maps built with the WIW logical rule could further be used for mapping a wide range of wetlands which are either periodically or permanently flooded. Full article

Surface albedo is of crucial interest in land–climate interaction studies, since it is a key parameter that affects the Earth’s radiation budget. The temporal and spatial variation of surface albedo can be retrieved from conventional satellite observations after a series of processes, including atmospheric correction to surface spectral bi-directional reflectance factor (BRF), bi-directional reflectance distribution function (BRDF) modelling using these BRFs, and, where required, narrow-to-broadband albedo conversions. This processing chain introduces errors that can be accumulated and then affect the accuracy of the retrieved albedo products. In this study, the albedo products derived from the multi-angle imaging spectroradiometer (MISR), moderate resolution imaging spectroradiometer (MODIS) and the Copernicus Global Land Service (CGLS), based on the VEGETATION and now the PROBA-V sensors, are compared with albedometer and upscaled in situ measurements from 19 tower sites from the FLUXNET network, surface radiation budget network (SURFRAD) and Baseline Surface Radiation Network (BSRN) networks. The MISR sensor onboard the Terra satellite has 9 cameras at different view angles, which allows a near-simultaneous retrieval of surface albedo. Using a 16-day retrieval algorithm, the MODIS generates the daily albedo products (MCD43A) at a 500-m resolution. The CGLS albedo products are derived from the VEGETATION and PROBA-V, and updated every 10 days using a weighted 30-day window. We describe a newly developed method to derive the two types of albedo, which are directional hemispherical reflectance (DHR) and bi-hemispherical reflectance (BHR), directly from three tower-measured variables of shortwave radiation: downwelling, upwelling and diffuse shortwave radiation. In the validation process, the MISR, MODIS and CGLS-derived albedos (DHR and BHR) are first compared with tower measured albedos, using pixel-to-point analysis, between 2012 to 2016. The tower measured point albedos are then upscaled to coarse-resolution albedos, based on atmospherically corrected BRFs from high-resolution Earth observation (HR-EO) data, alongside MODIS BRDF climatology from a larger area. Then a pixel-to-pixel comparison is performed between DHR and BHR retrieved from coarse-resolution satellite observations and DHR and BHR upscaled from accurate tower measurements. The experimental results are presented on exploring the parameter space associated with land cover type, heterogeneous vs. homogeneous and instantaneous vs. time composite retrievals of surface albedo. Full article

Satellite data offer the opportunity for monitoring the temporal flooding dynamics of seasonal wetlands, a parameter that is essential for the ecosystem services these areas provide. This study introduces an unsupervised approach to estimate the extent of flooded areas in a satellite image relying on the physics of light interaction with water, vegetation and their combination. The approach detects automatically thresholds on the Short-Wave Infrared (SWIR) band and on a Modified-Normalized Difference Vegetation Index (MNDVI), derived from radiometrically-corrected Sentinel-2 data. Then, it combines them in a meaningful way based on a knowledge base coming out of an iterative trial and error process. Classes of interest concern water and non-water areas. The water class is comprised of the open-water and water-vegetation subclasses. In parallel, a supervised approach is implemented mainly for performance comparison reasons. The latter approach performs a random forest classification on a set of bands and indices extracted from Sentinel-2 data. The approaches are able to discriminate the water class in different types of wetlands (marshland, rice-paddies and temporary ponds) existing in the Doñana Biosphere Reserve study area, located in southwest Spain. Both unsupervised and supervised approaches are examined against validation data derived from Landsat satellite inundation time series maps, generated by the local administration and offered as an online service since 1983. Accuracy assessment metrics show that both approaches have similarly high classification performance (e.g., the combined kappa coefficient of the unsupervised and the supervised approach is 0.8827 and 0.9477, and the combined overall accuracy is 97.71% and 98.95, respectively). The unsupervised approach can be used by non-trained personnel with a potential for transferability to sites of, at least, similar characteristics. Full article

The Landsat-8 satellite of the Landsat Data Continuity Mission was launched by the National Aeronautics and Space Administration (NASA) in April 2013. Just weeks after it entered active service, its sensors observed activity at Paluweh Volcano, Indonesia. Given that the image acquired was in the daytime, its shortwave infrared observations were contaminated with reflected solar radiation; however, those of the satellite’s Thermal Infrared Sensor (TIRS) show thermal emission from the volcano’s summit and flanks. These emissions detected in sensor’s band 10 (10.60–11.19 µm) have here been quantified in terms of radiant power, to confirm reports of the actual volcanic processes operating at the time of image acquisition, and to form an initial assessment of the TIRS in its volcanic observation capabilities. Data from band 11 have been neglected as its data have been shown to be unreliable at the time of writing. At the instant of image acquisition, the thermal emission of the volcano was found to be 345 MW. This value is shown to be on the same order of magnitude as similarly timed NASA Earth Observing System (EOS) Moderate Resolution Imaging Spectroradiometer thermal observations. Given its unique characteristics, the TIRS shows much potential for providing useful, detailed and accurate volcanic observations in the future. Full article
