Search Results (65)

In practical applications, high-temperature superconducting (HTS) cables or magnets may carry AC with DC bias, such as in superferric magnets, which can increase the AC loss of the cables or magnets. When the DC bias current is high, the resulting high loss can lead to a significant temperature rise in the cable or magnet and may even cause quench. Furthermore, different waveforms of the alternating current also result in different losses and temperature rises. Therefore, it is essential to investigate the AC loss of the cable under different current waveforms and DC bias levels using an electromagnetic–thermal coupling method. In this paper, an electromagnetic–thermal coupling model is used to investigate the AC loss and temperature rise characteristics of four stacked REBCO tapes under four typical current waveforms and various DC bias levels. The actual multilayer structure of REBCO tapes is considered in the numerical simulation, which facilitates the analysis of current distribution among different layers and its contribution to the total loss of the stacked cable. The results show that under zero DC bias or a small DC bias (0.1I_dc), the square-wave current yields the largest AC loss, while the triangular-wave current results in the smallest AC loss. The losses generated by the sawtooth and sinusoidal currents are comparable and intermediate between those of the two aforementioned waveforms. When the DC bias current is moderate (0.5I_dc) and the amplitude of the alternating current is greater than 0.5I_cable, the loss of the cable increases rapidly. The loss generated by the square-wave current is the largest, followed by the sinusoidal current, while the sawtooth and triangular currents produce the smallest losses. When the DC bias current is high (0.9I_dc), even a small amplitude alternating current results in high AC loss in the cable. Full article

Fusion energy represents humanity’s most promising solution for achieving limitless, carbon-free power. The superconducting Tokamak has emerged as the primary pathway to realize this goal. China’s systematic multi-phase strategy, progressing from the Experimental Advanced Superconducting Tokamak (EAST) to the International Thermonuclear Experimental Reactor (ITER) partnership, and now advancing the China Fusion Engineering Demonstration Reactor (CFEDR), has catalyzed transformative innovations in fusion magnet technology, including the development of high-current-density Cable-in-Conduit Conductors (CICC) using both low-temperature superconductors (LTSs) and high temperature superconductors (HTSs), radiation-resistant ultra-low-resistance joints enabling efficient power transfer, multi-sensor quench detection systems with millisecond-level response for magnet integrity preservation, and cryogenic thermal management via multi-stage heat interception zones. This accumulated expertise in superconducting magnet technologies will accelerate the commercialization of fusion energy. Full article

High-temperature superconducting (HTS) conductor on round core (CORC) cables possess the combined features of high current-carrying capacity, strong mechanical properties, and excellent isotropic flexibility. The current relative research on the electromagnetic properties of straight CORC cables has been exceedingly mature. In high-field magnets, CORC cables are typically bent into coils to meet the compactness requirement. Evaluating the bending characteristics of CORC cables, particularly their post-bending electromagnetic properties, holds great scientific significance. In this paper, CORC cables with different sizes of central formers were fabricated to explore the impacts of the bending process and strain on their transport AC loss characteristics. A mapping method was proposed to couple mechanical and electromagnetic models. Results show that the cable sample with a 4 mm outer diameter of the central former exhibits a superior bending characteristic. The bending process on the transport AC loss of CORC cable lies in the redistribution of the magnetic field, while strain mainly affects AC loss by leading to local critical current (Ic) degradation. CORC cables with small bending diameters require electromagnetic–mechanical-coupling simulation to predict their electromagnetic characteristics accurately. Conclusions drawn from this paper will provide invaluable guidance for the fabrication of bent CORC cables. Full article

To achieve global carbon-neutrality goals, magnetic levitation (maglev) technologies offer a promising pathway toward sustainable, energy-efficient transportation systems. In this study, a comprehensive methodology was developed to analyse and optimise the levitation performance of high-temperature superconducting (HTS) maglev systems. Several permanent magnet guideway (PMG) configurations were compared, and an optimised PMG Halbach array design was identified that enhances flux concentration and significantly improves levitation performance. To accurately model the electromagnetic interaction between the HTS bulk and the external magnetic field, finite element models based on the H-formulation were established in both two dimensions (2D) and three dimensions (3D). An HTS maglev demonstrator was built using YBCO bulks, and an experimental platform was constructed to measure levitation force. While the 2D model offers fast computation, it shows deviations from the measurements due to geometric simplifications, whereas the 3D model predicts levitation forces for the cylindrical bulk with much higher accuracy, with errors remaining below 10%. The strong agreement between experimental measurements and the 3D simulation across the entire force–height cycle confirms that the proposed model reliably reproduces the electromagnetic coupling and resulting levitation forces in HTS maglev systems. The paper provides a practical and systematic reference for the optimal design and experimental validation of HTS bulk-based maglev systems. Full article

The article presents a PSpice software-based numerical model of a superconducting transformer with HTS 2G SCS and SF windings for the analysis of electrical circuits, developed using PSpice version 24.1 (Cadence, 2024),which allows for the determination of equivalent parameters and properties of such a transformer in the steady state and in emergency states. The model has user-defined ABM (Analogue Behavioural Modelling) computational blocks and avails itself of the level 2 Jiles-Atherton magnetic hysteresis model and Rhyner’s power law describing the E-J relationship of the HTS superconducting tape. This model was experimentally verified by measurements of a real 10 kVA HTS transformer. On this basis, an extensive numerical model of a superconducting transformer with a more complicated winding structure and a higher power of 21 MVA was developed. For such a transformer, power losses were analysed and the time courses of resistance, current and temperature of superconducting windings made of HTS 2G tapes of the SCS type with a copper stabiliser and SF without a stabiliser were examined during emergency states, such as connecting the transformer to the network and operational short circuit. A discussion was carried out on the effectiveness of using both types of HTS tapes to limit the current in emergency situations posing a risk of loss of superconductivity and destruction of superconducting windings. Full article

High-temperature superconductor (HTS) magnet systems, especially those designed for fusion reactors, require effective and reliable monitoring to avoid damaging anomalies. In tokamaks, some of the magnetic coils are time-dependent, which causes strain and large inductive voltages within the magnet, rendering detection of incipient quench challenging. Ionizing radiation can also create material defects and lead to non-uniform degradation of conductors. The resulting decrease in critical current uniformity across the magnet, along with manufacturing defects, such as failure of structural materials or cooling systems, can all potentially initiate a quench. HTS magnets have a lower normal zone propagation velocity than low-temperature superconductors, and this causes normal zones to be localized, increasing the risk of permanent damage. Fiber optic sensors have several qualities that are essential in fusion systems. Unlike traditional voltage-based sensors, fiber optic cables are immune to the large electromagnetic fields present. This study presents and validates a fiber optic interrogation technique for monitoring magnetic confinement fusion and other high-temperature superconducting magnet systems. Coherent-phase optical time domain reflectometry (OTDR) allows for the high sampling rates (tens of kHz) necessary to quickly detect and mitigate quench events over the long distances required to monitor fusion magnet systems. This technique was demonstrated to successfully detect localized thermal transients at cryogenic temperatures as low as 6 K. These outcomes were also demonstrated using fibers embedded in HTS magnet coils at 77 K, verifying the potential for this interrogation technique’s use for failure detection in HTS coils. Full article

Advanced energy storage solutions are required to mitigate grid destabilization caused by high-penetration renewable energy integration. Superconducting Magnetic Energy Storage (SMES) offers ultrafast response (<1 ms), high efficiency (>95%), and almost unlimited cycling life. However, its commercialization is hindered by the complex modeling of critical current with anisotropic behaviors and the computational inefficiency of high-dimensional optimization for megajoule (MJ)-class magnets. This paper proposes an integrated design framework synergizing a two-dimensional axisymmetric magnetic field model based on Conway’s current-sheet theory, a critical current anisotropy characterization model, and an adaptive genetic algorithm (AGA). A superconducting magnet optimization model incorporating co-calculation of electromagnetic parameters is established. A dual-module chromosome encoding strategy (discrete gap index + nonlinear increment) and parallel acceleration techniques were developed. This approach achieved efficient optimization of MJ-class magnets. For a single solenoid, the critical current increased by 22.6% (915 A) and energy storage capacity grew by 41.8% (1.12 MJ). A 20-unit array optimized by coordinated gap adjustment achieved a matched inductance/current of 0.15 H/827 A (20 MJ), which can enhance transient stability control capability in smart grids. The proposed method provides a computationally efficient design paradigm and user-friendly teaching software tool for high-current SMES magnets, supporting the development of large-scale High-Temperature Superconducting (HTS) magnets, promoting the deployment of large-scale HTS magnets in smart grids and high-field applications. Full article

The integral equation formulation of Maxwell’s equations proposed by Brandt provides an alternative to the H and T-A formulations for modelling high-temperature superconducting (HTS) tapes. A modified version of Brandt’s method in the literature models ferromagnetic domains near the tapes by considering the ferromagnetic domains as equivalent surface current. This paper extends this method by including the effect of external magnetic field acting on the ferromagnetic and HTS domains. The proposed method is used on a benchmark problem, which considers an HTS tape with a ferromagnetic substrate under an external time-varying magnetic field. The results agree closely (error in average ac loss less than 3%) with the widely-used T-A formulation implemented in COMSOL down to 2 mT. In addition, the proposed method is also applied to HTS tapes carrying transport ac current in a slot of a machine’s stator iron core, and HTS tapes in a stator iron slot in a machine under working conditions. It is found that ac loss calculated by the proposed method increases as the discretization size of the ferromagnetic material’s boundary decreases, and overshoots the value calculated by the T-A formulation in COMSOL when using very fine discretization. Full article

In this study, real-scale high-temperature superconducting (HTS) field coils for a 10 MW class rotating machine were designed, fabricated, and experimentally evaluated. The aim was to propose a cost-effective winding strategy by combining two types of HTS wires with different angular dependencies of critical current. The 3D FEM simulations were performed to determine the coil layout by considering the magnetic field magnitude and incidence angle. Based on this design, two HTS field coils were fabricated, one wound with two different types of wire and the other with a single wire type. For application to an actual HTS generator, the coil was equipped with an iron core to evaluate its influence on critical current and magnetic field distribution. Experimental results at 77 K showed that the coil combined with two types of HTS wire achieved 112 A without the core and 105 A with the core, while the single-wire coil reached 101 A and 93 A, respectively. The measured results showed good agreement with the simulations, with deviations within 3.7% for the combined-wire coil and 1.9% for the coil equipped with the iron core. These findings indicate that the proposed winding method can maintain high performance while lowering material cost, providing useful guidelines for the design of large-scale HTS rotating machines. Full article

The no-insulation (NI) technique improves the stability and defect-tolerance of high-temperature superconducting (HTS) coils by enabling current redistribution, thereby reducing the risk of quenching. NI–HTS coils are widely applied in DC systems such as high-field magnets and superconducting field coils for electric machines. However, the presence of turn-to-turn contact resistance makes current distribution uneven, rendering traditional simulation methods unsuitable. To address this, a finite element method (FEM) based on the T–A formulation is proposed. This model solves coupled equations for the magnetic vector potential (A) and current vector potential (T), incorporating turn-to-turn contact resistance and anisotropic conductivity. The thin-strip approximation simplifies second-generation HTS materials as one-dimensional conductors, and a homogenization technique further reduces computational time by averaging the properties between turns, although it may limit the resolution of localized inter-turn effects. To verify the model’s accuracy, simulation results are compared against the H formulation, distributed circuit network (DCN) model, and experimental data. The proposed T–A model accurately reproduces key transient characteristics, including magnetic field evolution and radial current distribution, in both circular and racetrack NI coils. These results confirm the model’s potential as an efficient and reliable tool for transient electromagnetic analysis of NI–HTS coils. Full article

In this study, particle-in-cell (PIC) simulation was used to validate a conceptual design for a quasi-spherical, net power, hydrogen-plus-boron-11-fueled fusion reactor incorporating high-temperature superconducting (HTS) magnets. By burning a fully thermalized plasma, our proposed MET6 reactor uses the principles of the 1980 magneto-electrostatic trap design of Yushmanov to improve the classic Polywell design. Because the input power consumed by the reactor will barely balance the waste bremsstrahlung radiation, future research must focus on reducing the bremsstrahlung losses to reach practical net power levels. The first step to reducing bremsstrahlung, explored in this paper, is to tune the reactor parameters to reduce the energies of trapped electrons. We assume the quality factor Q can be approximated as the ratio of fusion power output divided by bremsstrahlung power loss. Thus, assuming the particles’ power loss is negligible compared to bremsstrahlung power loss, the resulting quality factor is estimated to be Q ≈ 1.3. Full article

This paper proposes an A-shape hybrid levitation system combining high-temperature superconducting (HTS) maglev and permanent magnet levitation (PML) technologies to address the lateral instability of the PML system. By tilting the PM arrays and HTS bulks on both sides at a specific angle, the system’s cross-section forms an “A” shape. This configuration offers dual advantages: the A-shape PML significantly mitigates unstable lateral deflection forces while preserving levitation capacity, whereas the A-shape HTS maglev enhances guidance force. Through systematic analysis, the effects of the tilt angle and the magnetization direction of the PM arrays on levitation performance are investigated and optimized. The simulation results demonstrate that, at the lateral movement of 5 mm, for the PML system, a tilt angle of 45° reduces lateral deflection force by 94.4%, and synergistic optimization of the tilt angle of 40° and magnetization direction of 38° achieves an 84.6% reduction. The HTS maglev system enhances guidance force, with a 45.3% improvement at a 60° tilt angle and a 30° magnetization direction. This study presents a promising solution for developing a stable, high-load-capacity hybrid levitation system. Full article

The active and passive components of transformer electrical equipment have reached their limits regarding modernization and optimization, leading to the implementation of innovative approaches. This is particularly relevant for mobile and autonomous energy complexes due to the introduction of increased frequency, which can be advantageous, especially in geoengineering, where the energy efficiency of electrical equipment is crucial. The new design of transformer equipment utilizing cryogenic technologies incorporates high-temperature superconducting (HTS) windings, a dielectric filler made of liquid nitrogen, and a three-dimensional magnetic system based on amorphous alloys. The finite element method showed that the skin effect does not impact HTS windings compared to conventional designs when the frequency increases. The analysis and synthesis of the parameters of the magnetic system made from amorphous iron and HTS windings in an HTS transformer with a dielectric medium of liquid nitrogen at a temperature of 77 K were performed, significantly reducing the mass and size characteristics of the HTS transformer compared to traditional counterparts while eliminating environmental and fire hazards. Based on these studies, an experimental prototype of an industrial HTS transformer with a capacity of 25 kVA was designed and manufactured. Full article

This work presents a comparison of different commercial tapes belonging to the second-generation High-Temperature Superconductors (2G HTS) produced by SuNAM Co., Ltd., SuperOx, and Shanghai Superconductors Technology Co., Ltd. (SST) companies. The aim is to investigate pinning mechanisms responsible for best performances, looking at the anisotropy of the irreversibility field and of the flux pinning energy. The irreversibility line states the upper limit of current-carrying capacity, whereas the flux pinning energy explores the ability of material defects to act as weak collectively or strong single vortex pinning centers. All investigated samples have artificial pinning centers (APCs) included in the superconducting matrix: BHO-doped EuBCO for SST, ${\mathrm{Y}}_2{\mathrm{O}}_3$ in YBCO for SuperOx, and ${\mathrm{Gd}}_2{\mathrm{O}}_3$ particles trapped in GdBCO for SuNAM. Resistive transition curves were measured in high magnetic fields up to 16 T for magnetic field orientations parallel and perpendicular to the tape surface. We found that the anistropy of SST tape shows an overall independence both on temperature and magnetic field, while the other two samples show a more complex behavior. This leads to the conclusion that properly engineered APC optimization in coated conductors can further reduce anisotropy of superconducting properties. Full article

Bulk high-temperature superconductors (HTSs) such as REBa₂Cu₃O_7−x (REBCO, RE = Y, Gd) are commonly used in rotationally symmetric superconducting magnetic bearings. However, such bulks have several disadvantages such as brittleness, limited availability and high costs due to the time-consuming and energy-intensive fabrication process. Alternatively, tape stacks of HTS-coated conductors might be used for these devices promising an improved bearing efficiency due to a simplification of manufacturing processes for the required shapes, higher mechanical strength, improved thermal performance, higher availability and therefore potentially reduced costs. Hence, tape stacks with a base area of (12 × 12) mm² and a height of up to 12 mm were prepared and compared to commercial bulks of the same size. The trapped field measurements at 77 K showed slightly higher values for the tape stacks if compared to bulks with the same size. Afterwards, the maximum levitation forces in zero field (ZFC) and field cooling (FC) modes were measured while approaching a permanent magnet, which allows the stiffness in the vertical and lateral directions to be determined. Similar levitation forces were measured in the vertical direction for bulk samples and tape stacks in ZFC and FC modes, whereas the lateral forces were almost zero for stacks with the REBCO films parallel to the magnet. A 90° rotation of the tape stacks with respect to the magnet results in the opposite behavior, i.e., a high lateral but negligible vertical stiffness. This anisotropy originates from the arrangement of decoupled superconducting layers in the tape stacks. Therefore, a combination of stacks with vertical and lateral alignment is required for stable levitation in a bearing. Full article
