This paper presents a method for calculating radial forces in switched reluctance motors (SRMs) under radial and tilted air gap eccentricity states. Firstly, the Fourier series method is used to establish a nonlinear model of a switched reluctance motor, which calculates the air gap length at different positions around the motor circumference and applies the Radial Electromagnetic Force (REF) equation to compute the radial force values at various positions under the air gap eccentricity states. Secondly, the finite element method is employed to analyze the factors influencing radial forces in switched reluctance motors under air gap eccentricity states, considering different winding phases and structural parameters as influencing factors. Finally, a measurement platform for radial forces under multiple types of air gap eccentricity states is established to validate the effectiveness of the analytical results for radial forces under radial and tilted air gap eccentricity states. Full article

In this research project a large linear electromagnetic actuator (LLEA) was designed and manufactured. The electromagnetic performance was published in previous works, but in this paper we focus on the technological challenges related to the manufacturing in particular. This LLEA was based on the magnet-free switched-reluctance principle, having six effective energised stator “teeth” and four passive mover parts (4:6 ratio). Various aspects and challenges encountered during the manufacturing, transport, and assembly are discussed. Thermal expansion of steel contributed to the decision of the modular design, with each module having 1.3 m in length, with a 2 mm longitudinal dilatation gap. The initial prototype was tested with a 10.6 m length, with plans to extend the test track to 60 m, which was fully achievable due to the modular design and required 29 tons of electrical steel to be built. The stator laminations were cut by a bespoke progressive tool with stamping, and other parts by a CO₂ laser. Mounting was based on welding (back of the stator) and clamping plates (through insulated bolts). The linear longitudinal force was on the order of 8 kN, with the main air gap of 7.5–10 mm on either side of the mover. The lateral forces could exceed 40 kN and were supported by appropriate construction steel members bolted to the concrete floor. The overall mechanical tolerances after installation remained below 0.5 mm. The technology used for constructing this prototype demonstrated the cost-effective way for a semi-industrial manufacturing scale. Full article

Due to the high demand for fuel efficiency, electric vehicles have come into the picture, as they only use batteries to power the vehicle. This requires constant charging of the batteries at charging stations, which are costly and impractical to install. But it is possible to install charging stations by making use of photovoltaic (PV) cells and demagnetization currents to self-charge batteries under stand-still conditions. The design of a bidirectional converter with asymmetrical half-bridge converter based on a switched reluctance motor (SRM) drive, using PV for electric vehicles, is implemented in this paper. It consists of developing a control unit (GCU), Li-ion battery pack, and photovoltaic (PV) solar cells that are integrated with a bidirectional converter and asymmetrical half-bridge converter (AHBC) to provide power to the SRM drive. The solar-assisted SRM drive can be operated in either the motoring mode or charging mode. In the motoring-mode GCU, the battery or PV energy can be used in any combination to power the SRM. In the charging-mode PV, the GCU and AC grids are used to charge the battery under stand-still conditions. This work helps in the self-charging of batteries using either the GCU or PV cells, as well as aids in the improvement in the performance characteristics. Also, this work compares the performance metrics for the proposed system and conventional system. The performance of the drive system using PV cells/GCU is evaluated and verified through MatLab/Simulink and experimental results. Full article

This research paper presents a comprehensive comparison between Permanent Magnet Synchronous Motors (PMSMs) and Switched Reluctance Motors (SRMs) in the context of drone applications. The study focuses on motors designed for an output power of 500 watts, with a torque of 0.8 Nm. Simulation results demonstrate that both motor types achieve the specified power rating, exhibiting a torque output of 0.8 Nm. In this comparative analysis, key performance parameters, efficiency, and operational characteristics of PMSM and SRM are systematically evaluated. The study addresses the unique features and challenges associated with each motor type, providing valuable insights for optimizing drone propulsion systems. Additionally, the influence of these motor choices on drone efficiency, weight, and overall performance is discussed. The research contributes to the understanding of motor selection in drone design, offering practical guidance for engineers and researchers involved in unmanned aerial vehicle development. As drone applications continue to diversify, this comparative study aids in making informed decisions regarding motor technologies, balancing power requirements, and maximizing operational efficiency. Full article

This paper presents an experimental acoustic noise characterization of a switched reluctance motor (SRM) designed for a wind turbine pitch angle control application. It details the fixture design for holding and positioning the sound intensity probes, along with the essential hardware setup for conducting acoustic noise experiments. Additionally, the software configuration is described to ensure compliance with specific measurement requirements. To study the effect of speed and load variations on the motor’s acoustic noise characteristics, tests are conducted at various operating points. The tests employ pulse-width modulation (PWM) current control, operating at a switching frequency of 12.5 kHz. Sound pressure and sound intensity are measured across different operating conditions to determine the sound power and psychoacoustic metrics. Furthermore, the effect of different factors on the motor’s sound power level, as well as on psychoacoustic metrics such as sharpness, loudness, and roughness, is analyzed and discussed. Full article

Hub motor-driven vehicles (HMDVs) suffer from poor handling and stability due to an increased unsprung mass and unbalanced radial electromagnetic forces. Although traditional ground-hook control reduces the dynamic tire load, it severely worsens the body acceleration. This paper presents a generalized ground-hook control strategy based on impedance transfer functions to address the parameter redundancy in structural methods. A quarter-vehicle model with a switched reluctance motor wheel hub drive was used to study different orders of generalized ground-hook impedance transfer function control strategies for dynamic inertial suspension. An enhanced fish swarm parameter optimization method identified the optimal solutions for different structural orders. Analyses showed that the third-order control strategy optimized the body acceleration by 2%, reduced the dynamic tire load by 8%, and decreased the suspension working space by 22%. This strategy also substantially lowered the power spectral density for the body acceleration and dynamic tire load in the low-frequency band of 1.2 Hz. Additionally, it balanced computational complexity and performance, having slightly higher complexity than lower-order methods but much less than higher-order structures, meeting real-time constraints. To address time-domain deviations from generalized ground-hook control in semi-active systems, a dynamic compensation strategy was proposed: eight topological structures were created by modifying the spring–damper structure. A deviation correction mechanism was devised based on the frequency-domain coupling characteristics between the wheel speed and suspension relative velocity. For ride comfort and road-friendliness, a dual-frequency control criterion was introduced: in the low-frequency range, energy transfer suppression and phase synchronization locking were realized by constraining the ground-hook damping coefficient or inertance coefficient, while in the high-frequency range, the inertia-dominant characteristic was enhanced, and dynamic phase adaptation was permitted to mitigate road excitations. The results show that only the T0 and T5 structures met dynamic constraints across the frequency spectrum. Time-domain simulations showed that the deviation between the T5 structure and the third-order generalized ground-hook impedance model was relatively small, outperforming traditional and T0 structures, validating the model’s superior adaptability in high-order semi-active suspension. Full article

This paper introduces an effective method to improve the performance of a proton exchange membrane fuel cell (PEMFC) system powering a switched reluctance motor (SRM). Problems arise in this system due to the inherent torque and current ripples of the SRM, which result from its saliency and nonlinear magnetic characteristics. Another cause for these ripples is the unsmoothed DC voltage applied to the SRM caused by the switching operations of the DC-DC converter. These ripples are reflected in the PEMFC, leading to more losses and a reduced lifespan. Key parameters that can help mitigate torque and current ripples include the appropriate turn-on and turn-off angles of the SRM phases, as well as the DC-link voltage controller gains. This paper investigates three objectives to compare their effects on the PEMFC system: the SRM torque ripple factor, the DC-link voltage ripple factor, and the PEMFC current ripple factor. These objectives are optimized individually using the single-objective particle swarm and stochastic fractal search algorithms. Additionally, the multi-objective Lichtenberg and multi-objective Dragonfly algorithms are applied to optimize the three objectives concurrently. The optimal decision parameters are obtained from the Pareto front solution using the technique of the order of preference by similarity to the ideal solution method. The final results demonstrate that significant enhancement in the PEMFC current ripples and DC-link voltage ripples can be achieved by appropriately selecting the decision parameters using any proposed objective. Full article

An improved super-twisting sliding mode and linear active disturbance rejection control strategy is proposed to improve the dynamic response performance and immunity performance in switched reluctance motor speed control systems. Firstly, the linear extended state observer in linear active disturbance rejection control is improved by using the super-twisting sliding mode (STSM) control algorithm in order to improve the performance of the observer and thus enhance the controller’s immunity to disturbances. Secondly, the STSM control algorithm is used to replace the original linear state error feedback control law to improve the dynamic response performance of the controller, and the sigmoid function is used to replace the sign function in the STSM algorithm to further weaken the inherent chattering of the sliding mode and improve the stability of the system. Finally, the proposed control strategy is verified using the MATLAB/Simulink simulation platform. The simulation results show that the proposed control strategy has a better dynamic response and disturbance immunity performance. Full article

Switched reluctance motor drives are becoming attractive for electric vehicle propulsion systems due to their simple and cheap construction. However, their operation is degraded by torque ripples due to the salient nature of the stator and rotor poles. There are several methods of mitigating torque ripples in switched reluctance motors (SRMs). Apart from changing the geometrical design of the motor, the less costly technique involves the development of an adaptive switching strategy. By selecting suitable turn-on and turn-off angles, torque ripples in SRMs can be significantly reduced. This work combines the benefits of Harris Hawks Optimization (HHO) and Radial Basis Functions (RBFs) to search and estimate optimal switching angles. An objective function is developed under constraints and the HHO is utilized to perform search stages for optimal switching angles that guarantee minimal torque ripples at every speed and current operating point. In this work, instead of storing the ${\theta }_{on}, {\theta }_{off}$ values in a look-up table, the values are passed on to an RBF model to learn the nonlinear relationship between the columns of data from the HHO and hence transform them into high-dimensional outputs. The values are used to train an enhanced neural network (NN) in an adaptive switching strategy to address the nonlinear magnetic characteristics of the SRM. The proposed method is implemented on a current chopping control-based SRM 8/6, 600 V model. Percentage torque ripples are used as the key performance index of the proposed method. A fuzzy logic switching angle compensation strategy is implemented in numerical simulations to validate the performance of the HHO-RBF method. Full article

This study presents a method to reduce the chattering phenomenon and the reaching time of sliding mode speed control for switched reluctance motors (SRMs). In order to simultaneously reduce the chattering phenomenon and reaching time, we propose a hybrid reaching law (HRL) for sliding mode controller (SMC). Furthermore, to address the absence of a position sensor, a sliding mode observer (SMO) is integrated into the proposed HRL-based SMC, enabling accurate estimation of rotor angle and angular speed. Comprehensive simulation results are conducted to verify the effectiveness of the proposed method in terms of the reduced chattering phenomenon and reaching time. Full article

This paper presents an experimental characterization of acoustic noise and sound quality in a 12/8 Switched Reluctance Motor (SRM) using hysteresis and Pulse Width Modulation (PWM) current control techniques. To overcome the limitations of traditional sound power measurements and enhance the accuracy of acoustic noise evaluation, a setup is applied for calculating sound power based on sound intensity measurements. The study provides a detailed description of the intensity probe-holding fixture, the hardware configuration for acoustic noise experiments, and the software setup tailored to specific measurement requirements. The acoustic noise characteristics of the motor are assessed at various operating points using two distinct current control methods: hysteresis current control with a variable switching frequency of up to 20 kHz and PWM current control with a fixed switching frequency of 12.5 kHz. Measurements of sound pressure and sound intensity enable the calculation of sound power and sound quality metrics under different operating conditions. Furthermore, the study investigates the influence of various factors on the motor’s sound power levels and sound quality. The findings provide valuable insights into the contributions of these factors to acoustic noise characteristics and offer a foundation for improving the motor’s acoustic behavior during the design and control stages. Full article

Switched reluctance motors (SRMs) offer several advantages, including a magnet- and winding-free rotor, high mechanical strength, and exceptional output efficiency. However, the doubly salient pole structure and high-frequency switching power supply result in significant torque ripple and electromagnetic noise, which limit the application in the field of new energy vehicles. To address these issues, this paper proposes a direct instantaneous torque control (DITC) strategy based on an optimal switching angle torque sharing function (TSF). Firstly, an improved cosine TSF is designed to reasonably distribute the total reference torque among the phases, stabilizing the synthesized torque of SRM during the commutation interval. Subsequently, an improved artificial bee colony (ABC) algorithm is used to obtain the optimal switching angle data at various speeds, integrating these data into the torque distribution module to derive the optimal switching angle model. Finally, the effectiveness of the proposed control strategy is validated through simulations of an 8/6-pole SRM. Simulation results demonstrate that the proposed control strategy effectively suppresses torque ripple during commutation and reduces the peak current at the beginning of phase commutation. Full article

This paper discusses a numerical model for determining the radial electromagnetic force of switched reluctance motors under air gap eccentricity (vertical and tilt eccentricities). The authors compare experimental and simulation results to demonstrate that the proposed model can accurately simulate the behavior of radial forces in switched reluctance motors under various types of air gap eccentricity. Moreover, the paper attempts to establish a dynamic model of the SRM and nalyze the performance of the radial electromagnetic force under air gap eccentricity in typical scenarios. Full article

This paper presents a solution to reduce source current ripple in the electrical power supplying a switched reluctance motor (SRM) drive. Source current ripple negatively affects the power source by introducing a variable frequency component and increasing losses in the power source. Reducing the source current ripple is important, especially in battery electric vehicles (BEVs). The solution proposed in this paper for reducing source current ripple is to use a classic DC/DC boost converter connected in series with the SRM power supply system. The key to reducing source current ripple is the DC/DC converter control method proposed and described in this article. This method involves controlling the DC/DC converter synchronized with the speed of the SRM motor DC/DC. To verify the correct operation of the proposed solution, simulation and laboratory tests of an SRM drive were performed, the results of which are shown in this paper. Full article

Achieving increased fault tolerance in an electric motor requires decisions to be made about the type and specifications of the motor machine and its appropriate design. Depending on the type of motor, there are generally three ways to achieve an increased resistance of the drive system to tolerate resulting faults. The simplest way is to select the right motor and design it appropriately. Switched reluctance motors (SRMs) have a high tolerance for internal faults (in the motor windings). Failure tolerance can be improved by using parallel paths. The SRM 24/16 solution has been proposed, which allows for operation with four parallel paths. In this paper, a mathematical model designed to analyse the problem under consideration is provided. Based on numerical calculations, the influence of typical faults (open and partial short circuit in one of the paths) on the electromagnetic torque generated as well as its ripple and (source and phase) currents were determined. The higher harmonics of the source current (diagnostic signal) were determined. Laboratory tests were performed to verify the various configurations for the symmetric and emergency operating states. The feasibility of SRM correct operation monitoring was determined from an FFT analysis of the source current. Full article
