The performance improvement potential with the optimisation of vane geometry and port timing angle in oil-injected Rotary Vane Compressors (RVCs) is not yet fully understood. Commonly, studies have used single-phase CFD models without consideration of lubricating oil. However, the presented analysis uses a more complex oil–gas two-phase CFD model. A fully analytical grid generation method was used for discretisation of the rotor domain, and the numerical method was validated against the experimental results. Coupled with the analysis of the flow field, the effects of five vane parameters and four configurations of port timing angles on the compressor performance were studied. The results show that the baseline case of the RVC achieved the volumetric and adiabatic efficiencies of 95.4% and 62.3%, respectively, while the specific power was 9.47 kW/(m³·min⁻¹), which is consistent with typical industrial RVCs. The RVC as a high-efficiency compressor highly relies on the vane tip clearance size. The baseline parameters of the vane geometry and the port timing angles are relatively reasonable, and further optimisation of vane thickness, vane tip radius, vane eccentric angle, vane tip eccentric angle, intake port closing angle and exhaust port closing angle contributes to 1.7% decrease in the specific power. Overall, the structural parameter optimisation carried out in this paper, combined with the operational parameter optimisation conducted in previous studies, leads to a power reduction of 5.6%. Full article

Innovating seal structures and optimizing size parameters are effective ways to enhance the leakage characteristics of labyrinth seals (LSs). Inspired by the ecological fishways with high flow resistance on dam sides, a novel bio-inspired staggered labyrinth seal is proposed. The leakage characteristics of both the curved-edged bio-inspired labyrinth seal (CELS) and the straight-edged bio-inspired labyrinth seal (SELS) at different tooth-incline angles are studied numerically and experimentally. The influence of key geometrical parameters on the leakage characteristics and flow field parameters of the CELSs are investigated, and the leakage control mechanism of bio-inspired LSs is revealed via analyzing flow field parameter distribution. The results indicate that, compared to conventional double-sided staggered straight-tooth labyrinth seals, the leakage rate reduction in CELSs is up to 30% when the incline angle is equal to 25°, outperforming that of the SELS in leakage control. This improvement is mainly attributed to the flow path bending and jet contraction effects at the tooth-tip entrance, along with the thermodynamic effects of the high-turbulence dissipation zone adjacent to the tooth top. The optimum leakage characteristics can be achieved when seal clearance h < 0.5 mm, aspect ratio δ < 0.6, and tooth thickness t < 1.5 mm. This work provides new insights into the structural design of high-resistance and low-leakage labyrinth seals. Full article

A submersible sewage pump is designed for conveying solid–liquid two-phase media containing sewage, waste, and fiber components, through its small and compact design and its excellent anti-winding and anti-clogging capabilities. In this paper, the computational fluid dynamics–discrete element method (CFD-DEM) coupling model is used to study the influence of different conveying conditions and particle parameters on the wear of the flow components in a submersible sewage pump. At the same time, the energy balance equation is used to explore the influence mechanism of different tip clearance sizes on the internal flow pattern, wear, and energy conversion mechanism of the pump. This study demonstrates that increasing the particle volume fraction decreases the inlet particle velocity and intensifies wear in critical areas. When enlarging the tip clearance thickness from 0.4 mm to 1.0 mm, the leakage vortex formation at the inlet is enhanced, leading to increased wear rates in terms of the blade and volute. Consequently, the total energy loss and turbulent kinetic energy generation increased by 3.57% and 2.25%, respectively, while the local loss coefficient in regard to the impeller channel cross-section increased significantly. The findings in this study offer essential knowledge for enhancing the performance and ensuring the stable operation of pumps under solid–liquid two-phase flow conditions. Full article

A novel liquid chromatography-tandem mass spectrometry (LC-MS/MS) method has been developed and validated for the simultaneous determination of tipiracil (TIP), trifluridine (FTD), and their metabolites, 5-trifluoromethyluracil (FTY) and 5-carboxy-2′-deoxyuridine (5CDU), in rat plasma. This method is highly sensitive, specific, and fast. Paracetamol (PAR) is used as an internal standard (IS). Using acetonitrile-induced protein precipitation, the analytes were extracted from a plasma sample and separated on a Waters BEH C18 (1.7 μm particle size, 50 mm × 2.1 mm ID) column protected by a security guard cartridge (C18, 4 × 2.0 mm). The isocratic mobile phase was made up of methanol and water containing 0.1% formic acid (80:20, v/v) at a flow rate of 0.5 mL/min for 4 min. The quantification was performed using a positive electrospray ionization (ESI) interface and a multiple-reaction monitoring (MRM) mode. The MRM transitions employed were m/z 242.96 → 182.88 for TIP, 296.96 → 116.86 for FTD, 180.98 → 139.85 for FTY, 272.96 → 156.86 for 5CDU, and 151.97 → 92.68 for IS. The validated method complied with the guidelines set by the US-FDA over on a linear concentration range of 5–4000 ng/mL for FTD, FTY, and 5CDU, and 5–1000 ng/mL for TIP. The coefficient of determination (r2) was equal to or greater than 0.997. The corresponding lower limits of detection (LLOD) were 1.5 ng/mL for FTD, FTY, and 5CDU and 1.0 ng/mL for TIP. The recoveries of all analytes from rat plasma ranged from 88.67% to 112.18%, and the mean relative standard deviation (RSD) of accuracy and precision result was less than or equal to 6.84%. FTD, FTY, 5CDU, and TIP demonstrated adequate stability throughout the various circumstances examined. Additionally, no matrix effects were identified for any of the analytes. The assay was effectively utilized to conduct a pharmacokinetic study in rats following the oral administration of FTD and TIP at a dosage of 5.6 mg/kg, with a ratio of 1:0.5 for FTD and TIP, respectively. This indicates that the suggested approach is suitable for future clinical research. The pharmacokinetic parameters C_max (maximum concentration), T_max (time to reach maximum concentration), t1/2 (half-life), AUC_0-24 (area under the concentration–time curve from 0 to 24 h), AUC total (total area under the concentration–time curve), Ke (elimination rate constant), Vd (volume of distribution), and CL (clearance) of all analytes were assessed. The assay developed exhibits significant advancements compared to earlier bioanalytical methods documented in the literature. These improvements include high sensitivity, specificity, and efficacy in high throughput analysis of complex matrices. Additionally, the assay offers a shorter run time and smaller sample volume (50 μL). Full article

A spiral axial-flow blade pump (SABP) is an indispensable device in the closed gathering and transporting technology of oil and natural gas exploitation; it can not only transport a gas–liquid mixture with a high gas content, but also transport a gas–liquid–solid mixture containing a small amount of sand. However, due to the large vortices that often appear in the flow channel of the SABP, cavitation is induced extremely easily. This paper presents a numeric calculation of the cavitation performance of an SABP to reveal the law governing the impact of cavitation on its internal flow. The impact of tip clearance with different sizes on the dynamic and static head of the SABP was analyzed, and the change rules of the absolute velocity, relative velocity, and dynamic and static head were revealed under different cavitation stages, too. Full article

Gas–liquid multiphase pumps are critical transportation devices in the petroleum and chemical engineering industries, and improving their conveyance efficiency is crucial. This study investigates the influence of blade tip clearance variations on the flow characteristics within a multiphase pump. Numerical simulations were conducted using Eulerian two-phase and SST k-ω turbulence models with four distinct tip clearance sizes (0 mm, 0.3 mm, 0.6 mm, and 0.9 mm). The performance curve, tip leakage flow (TLF), and internal gas distribution were subjected to analysis. The results indicate that the TLF is linearly related to the clearance size and traverses multiple flow passages, resulting in energy losses and a reduced pump head coefficient. Larger tip clearances (0.6 mm and 0.9 mm) exhibited a more uniform flow pattern, contrasting the irregularities seen with a 0.3 mm clearance. Compared to no tip clearance (0 mm), gas holdup within the impeller passages decreased by 18.39%, 39.62%, and 58.53% for clearances of 0.3 mm, 0.6 mm, and 0.9 mm, respectively, leading to decreased overall system efficiency. This study highlights the connection between tip clearance size and flow dynamics in multiphase pumps, offering insights for optimal tip clearance selection during multiphase pump design. Full article

In the current study, full-stage unsteady simulations were performed to investigate rotating instability inception mechanisms in a particularly large tip clearance centrifugal compressor with a vaneless diffuser and a volute. Four operating points along a speed line were analysed to understand the influence of the mass flow reduction on flow structures. Close to the peak efficiency, an unsteady interaction between the tip clearance vortices and splitter blades was observed. Considering other studies, the influence of the tip gap size was analysed. Then, a large-scale vortex shedding from the leading edges of the main blades was detected when the stage operated near the maximum pressure ratio. It was demonstrated that shed vortices were caused by the combination of the radial gradient of the tangential velocity under the tip vortex and the reverse backflow near the casing. Previous studies on axial compressors refer to these vortical structures as backflow vortices. These vortices cause a significant increase in the incidence angle in the tip region. Full article

In an axial-flow turbine of a jet engine used for aircraft propulsion, the passage vortex (PV) and tip leakage vortex (TLV) generated inside the blade passage deteriorate the aerodynamic performance. In this study, a dielectric barrier discharge plasma actuator (PA) was installed in the upstream endwall of the turbine cascade to suppress the PV. The effects of the presence or absence of tip clearance and the change in the size of the tip clearance on the vortex structure at the exit of the turbine cascade were observed by recording the flow velocity distributions using particle image velocimetry. In the absence of tip clearance, only the PV existed and was completely suppressed by the PA. By contrast, in the presence of tip clearance, a TLV occurred in addition to the PV. When the input voltage to the PA was varied with various tip clearance sizes, the change in the flow fields where the PV and TLV interfered was clarified. With tip clearance, the PV was suppressed as the input voltage increased; however, the TLV increased considerably. At each tip clearance size, changes in the center positions of the PV and TLV were observed at varying input voltages of the PA. With increasing input voltages of the PA, the center position of the PV moved to the pressure surface side of the tip of the adjacent blade, and the center position of the TLV moved toward the middle of the flow passage. With a larger tip clearance, the amount of movement at the center positions of both the PV and TLV increased. Full article

The shaft tubular pump device is widely used in various water diversion projects because of its ultra-low head and large flow characteristics. Due to the tip clearance between the blade and the shroud, it is easy to cause hydraulic mechanical performance changes, induced vibration, and noise, which seriously affects the safe and stable operation of the pump. Steady and unsteady three-dimensional flow field numerical simulations of a shaft tubular pump device were carried out using computational fluid dynamics to investigate the impeller flow properties of the device under various flow conditions, including the tip clearance leakage flow (TCLF) and change rule of pressure pulsation. The TCLF, vortex morphology evolution, and pressure pulsation properties of the impeller tip clearance were analyzed. The results show that with an increase in the flow rate, the influence of the tip clearance size on the tip clearance flow decreases, the TCLF decreases, and the axial velocity of the water flow at the tip clearance increases. When the flow rate increases, the swirling strength of the tip leakage vortex decreases, and the distance between the tip leakage vortex and the suction surface of the blade increases. With the increase in flow rate, the pressure pulsation amplitude at the tip clearance increases first and then decreases. The focus of this study is to analyze the variation of tip clearance flow field and pressure pulsation under multiple working conditions, aiming to provide some help for improving the performance of the pump device and ensuring its safe operation. Full article

Experimental and numerical studies of a linear high-loaded turbine cascade with a dual−cavity tip structure are presented in this paper. The experimental conditions contained an increase in the outlet Mach number from 0.42 to 0.92, a change in the incidence angle from −15° to 15° and an increase in the relative clearance size from 0.36% to 1.4%. The ability of the dual−cavity tip to control leakage losses and vortices is assessed using the total pressure coefficient and the Q-criterion. This research indicates that the leakage vortex interacts strongly with the passage vortex, and the change in working conditions affects the balance between the two vortices and thus the flow field structure. The experimental and numerical results prove that the dual−cavity tip can reduce losses in all operating conditions, with the best control effect reduced by 0.025 in a large clearance size condition. In addition, the leakage control effect of the blade tip structure is more influenced by the incoming flow angle and clearance size than the Mach number. Full article

The occurrence of a tip leakage vortex (TLV) is a special phenomenon of ducted propellers, which has a significant influence on the propeller’s hydrodynamic performance and efficiency. The inception, evolution, and instability of the TLV under different tip clearance sizes have a direct impact on the cavitation and acoustic characteristics. A simulation was set up to calculate the open-water performance of a standard ducted propeller. The open-water characteristics (OWCs) were compared with the experimental data to verify the feasibility of the method. Furthermore, to capture the influence of tip clearance size on the vortex structure evolution and wake dynamics, the improved delayed detached eddy simulation (IDDES) method was adopted to simulate four groups of ducted propellers with different tip clearances. The results showed that with the increase in the gap-to-span ratio (GSR), K_TD and η₀ gradually decreased, while K_Q and K_TB increased, but a peak point existed. Moreover, the TLV became thicker, indicating damage to the energy recycling process. The fast Fourier transform (FFT) of several wake points showed pressure pulsations of the wake ranging from the blade-passing frequency to the shaft frequency, and the evolution process accelerated with the increase in the GSR. The power spectral density (PSD) analysis showed that the energy of the wake enhanced with the increase in the GSR. In particular, the vortex interactions could cause pulses in low-GSR conditions, which could intensify the excitation force of the propeller and also have a certain impact on the noise level. Full article

The pressure pulsation characteristics of the blade’s surface have an impact on the lifespan of the multiphase pump impeller. To explore the influence of the gap matching relation on the pressure pulsation characteristics at blade’s surface of the pump, the axial clearance coefficient (ACC) between the impeller and diffuser and the relative tip clearance of the impeller were defined. By combining of numerical simulation and experiment, the pressure pulsation characteristics at blade’s surface of the single pressurization unit of the pump were studied under different gap matching relations. The results show that the size of tip leakage flow and the strength of rotor-stator interaction caused by different relative tip clearances have a decisive influence on the pressure pulsation characteristics in the impeller. With the increase of tip clearance, the internal flow field distribution law was greatly changed, which had a great impact on the pressure pulsation peak-to-peak value and dominant frequency amplitude of the suction surface. In addition, the pressure pulsation characteristics of the diffuser were mainly affected by the strength of rotor-stator interaction. When the strength of rotor-stator interaction weakened, the amplitude of the dominant frequency pulsation was decreased by degrees. As the ACC increased, the variation of the pressure pulsation peak-to-peak value and the dominant frequency amplitude coefficient were gradually slowed down in the diffuser, and the dominant frequency amplitude of the monitoring points were most sensitive to change in the ACC. The research results can provide a theoretical reference for the optimal design of the multiphase pump blades. Full article

A high-speed centrifugal pump with a fully sealed structure has the advantages of a small size, no external leakage, and being pollution-free. The inner leakage passage of a pump with a fully sealed structure includes the tip clearance and the hub clearance. The hub clearance, the lubrication passage of the bearing, and the clearance between the stator and the rotor of the built-in motor constitute the internal flow channel. As a consequence of hub leakage, the complexity of the flow field increases and performance of the pump is affected. However, hub leakage also lubricates the bearing and cools the motor by flowing through the internal flow channel. To obtain the actual flow field distribution and external characteristics of the pump, a coupling calculation based on a conventional CFX simulation and MATLAB was carried out. The results show that hub leakage promotes an increase in tip leakage and changes the distribution of the main flow field. Moreover, hub leakage also significantly affects the efficiency of the pump. Compared with hub leakage, the internal flow has a greater impact on the performance of the pump. The numerical simulation results of the internal flow model are similar to the experimental results, with the maximum absolute error of the head at 0.3 m and the maximum absolute error of the efficiency at 1.7%, indicating that the internal flow model is effective at predicting the performance of the high-speed centrifugal pump with a fully sealed structure. Full article

Numerical simulations have been performed to study the effect of the circumferential single-grooved casing treatment (CT) at multiple locations on the tip-flow stability and the corresponding control mechanism at three tip-clearance-size (TCS) schemes in a transonic axial flow compressor rotor. The results show that the CT is more efficient when its groove is located from 10% to 40% tip axial chord, and G2 (located at near 20% tip axial chord) is the best CT scheme in terms of stall-margin improvement for the three TCS schemes. For effective CTs, the tip-leakage-flow (TLF) intensity, entropy generation and tip-flow blockage are reduced, which makes the interface between TLF and mainstream move downstream. A quantitative analysis of the relative inlet flow angle indicates that the reduction of flow incidence angle is not necessary to improve the flow stability for this transonic rotor. The control mechanism may be different for different TCS schemes due to the distinction of the stall inception process. For a better application of CT, the blade tip profile should be further modified by using an optimization method to adjust the shock position and strength during the design of a more efficient CT. Full article

To study the effect of tip clearance on unsteady flow in a tubular turbine, a full-channel numerical calculation was carried out based on the SST k–ω turbulence model using a power-plant prototype as the research object. Tip leakage flow characteristics of three clearance δ schemes were compared. The results show that the clearance value is directly proportional to the axial velocity, momentum, and flow sum of the leakage flow but inversely proportional to turbulent kinetic energy. At approximately 35–50% of the flow direction, velocity and turbulent kinetic energy of the leakage flow show the trough and peak variation law, respectively. The leakage vortex includes a primary tip leakage vortex (PTLV) and a secondary tip leakage vortex (STLV). Increasing clearance increases the vortex strength of both parts, as the STLV vortex core overlaps Core A of PTLV, and Core B of PTLV becomes the main part of the tip leakage vortex. A “right angle effect” causes flow separation on the pressure side of the tip, and a local low-pressure area subsequently generates a separation vortex. Increasing the gap strengthens the separation vortex, intensifying the flow instability. Tip clearance should therefore be maximally reduced in tubular turbines, barring other considerations. Full article
