The efficient detection of tire sidewall defects is crucial for ensuring safety and quality control in manufacturing. Traditional inspection is slow and inconsistent, while automated methods fail to address the complexity and coexistence of multiple tire sidewall defects. To alleviate those shortcomings, this study develops a curvature-based three-dimensional (3D) defect detection system that leverages the inherent rotational symmetry of tire sidewalls, allowing for more accuracy and efficiency in detecting intricate tire sidewall defects. Firstly, a defect detection system is developed that collects the three-dimensional data of tires, enabling precise quality assessments and facilitating accurate defect identification. Secondly, a dataset encompassing various types of intricate tire sidewall defects is constructed. This study leverages normal vectors and surface variation features to conduct an in-depth analysis of the complex three-dimensional shapes of tire sidewalls, while incorporating optimized curvature calculations that significantly enhance detection accuracy and algorithm efficiency. Moreover, the approach enables the simultaneous detection of intricate defect types, such as scratches, transportation damage, and cuts, thereby improving the comprehensiveness and accuracy of the detection process. The experimental results demonstrate that the system achieves a detection accuracy of 95.3%, providing crucial technical support for tire quality control. Full article

Automatic detection of tire defects has become an important issue for tire production companies since these defects cause road accidents and loss of human lives. Defects in the inner structure of the tire cannot be detected with the naked eye; thus, a radiographic image of the tire is gathered using X-ray cameras. This image is then examined by a quality control operator, and a decision is made on whether it is a defective tire or not. Among all defect types, the foreign object type is the most common and may occur anywhere in the tire. This study proposes an explainable deep learning model based on Xception and Grad-CAM approaches. This model was fine-tuned and trained on a novel real tire dataset consisting of 2303 defective tires and 49,198 non-defective. The defective tire class was augmented using a custom augmentation technique to solve the imbalance problem of the dataset. Experimental results show that the proposed model detects foreign objects with an accuracy of 99.19%, recall of 98.75%, precision of 99.34%, and f-score of 99.05%. This study provided a clear advantage over similar literature studies. Full article

The condition of a railway vehicle’s wheels is an essential factor for safe operation. However, the current inspection of railway vehicle wheels is limited to periodic major and minor maintenance, where physical anomalies such as vibrations and noise are visually checked by maintenance personnel and addressed after detection. As a result, there is a need for predictive technology concerning wheel conditions to prevent railway vehicle damage and potential accidents due to wheel defects. Insufficient predictive technology for railway vehicle’s wheel conditions forms the background for this study. In this research, a real-time tire wear classification system for light-rail rubber tires was proposed to reduce operational costs, enhance safety, and prevent service delays. To perform real-time condition classification of rubber tires, operational data from railway vehicles, including temperature, pressure, and acceleration, were collected. These data were processed and analyzed to generate training data. A 1D–CNN model was employed to classify tire conditions, and it demonstrated exceptionally high performance with a 99.4% accuracy rate. Full article

Tire defect detection, as an important application of automatic inspection techniques in the industrial field, remains a challenging task because of the diversity and complexity of defect types. Existing research mainly relies on X-ray images for the inspection of defects with clear characteristics. However, in actual production lines, the major threat to tire products comes from defects of low visual quality and ambiguous shape structures. Among them, bubbles, composing a major type of bulge-like defects, commonly exist yet are intrinsically difficult to detect in the manufacturing process. In this paper, we focused on the detection of more challenging defect types with low visibility on tire products. Unlike existing approaches, our method used laser scanning technology to establish a new three-dimensional (3D) dataset containing tire surface scans, which leads to a new detection framework for tire defects based on 3D point cloud analysis. Our method combined a novel 3D rendering strategy with the learning capacity of two-dimensional (2D) detection models. First, we extracted accurate depth distribution from raw point cloud data and converted it into a rendered 2D feature map to capture pixel-wise information about local surface orientation. Then, we applied a transformer-based detection pipeline to the rendered 2D images. Our method marks the first work on tire defect detection using 3D data and can effectively detect challenging defect types in X-ray-based methods. Extensive experimental results demonstrate that our method outperforms state-of-the-art approaches on 3D datasets in terms of detecting tire bubble defects according to six evaluation metrics. Specifically, our method achieved 35.6, 40.9, and 69.1 mAP on three proposed datasets, outperforming others based on bounding boxes or query vectors. Full article

The tire industry plays a key role in ensuring safe and efficient transportation. With 1.1 billion vehicles worldwide relying on tires for optimum performance, tire quality control is of paramount importance. In recent years, the integration of artificial intelligence (AI) has revolutionized various industries, and the tire industry is no exception. In this article, we take a look at the current state of quality control in the tire industry and the transformative impact of AI on this crucial process. Automatic detection of tire defects remains an important and challenging scientific and technical problem in industrial tire quality control. The integration of artificial intelligence into tire quality control has the potential to transform the tire industry, leading to safer, more reliable, and more sustainable tires. Thanks to continuous progress and a proactive approach to challenges, the tire industry is prepared for a future in which artificial intelligence will play a key role in delivering high-quality tires to consumers around the world. Full article

Tire defects are crucial for safe driving. Specialized experts or expensive tools such as stereo depth cameras and depth gages are usually used to investigate these defects. In image processing, feature extraction, reduction, and classification are presented as three challenging and symmetric ways to affect the performance of machine learning models. This paper proposes a hybrid system for cracked tire detection based on the adaptive selection of correlation features and deep belief neural networks. The proposed system has three steps: feature extraction, selection, and classification. First, the oriented gradient histogram extracts features from the tire images. Second, the proposed adaptive correlation feature selection selects important features with a threshold value adapted to the nature of the images. The last step of the system is to predict the image category based on the deep belief neural networks technique. The proposed model is tested and evaluated using real images of cracked and normal tires. The experimental results show that the proposed solution performs better than the current studies in effectively classifying tire defect images. The proposed hybrid cracked tire detection system based on adaptive correlation feature selection and Deep Belief Neural Networks’ performance provided better classification accuracy (88.90%) than that of Belief Neural Networks (81.6%) and Convolution Neural Networks (85.59%). Full article

Digital shearography is a technique that has recently been applied to material inspections that cannot be performed by the naked eyes, including the detection of air bubble defects in tires. Although digital shearography detects bubbles that are not visible to the naked eyes, the process of determining tire defects still relies on field operators, with inconsistent results depending on the experiences of the field operator personnel. New or different types of bubble defects that AI models have not previously recognized are often missed, resulting in an inadequate quality detection model. In this paper, we propose a bubble defect detection method based on an incremental YOLO architecture. The data for this research was provided by the largest tire manufacturer in Taiwan. In our research, we classify the defects into six distinct categories, pre-process the images to allow better detections of less-noticeable defects, increase the amount of training data used, and generate an initial training model with the YOLO framework. We also propose an incremental YOLO method using small-model training for previously unobserved defects to improve the model detection rate. We have observed detection accuracy and sensitivity of 98% and 90% in the experimental results, respectively. The methods proposed in this paper can assist tire manufacturers in achieving semi-automatic quality inspections and labor cost reductions. Full article

With the development of neural networks, object detection based on deep learning is developing rapidly, and its applications are gradually increasing. In the tire industry, detecting speckle interference bubble defects of tire crown has difficulties such as low image contrast, small object scale, and large internal differences of defects, which affect the detection precision. To solve these problems, we propose a new feature pyramid network based on Faster RCNN-FPN. It can fuse features across levels and directions to improve small object detection and localization, and increase object detection precision. The method has proven its effectiveness through cross-validation experiments. On a tire crown bubble defect dataset, the mAP [0.5:0.95] increased by 2.08% and the AP0.5 increased by 2.4% over the original network. The results show that the improved network significantly improves detecting tire crown bubble defects. Full article

In order to eliminate driving dangers caused by tire surface bubbles, the detection method of bubble defects on tire surfaces based on line lasers and machine vision is studied. Since it is difficult to recognize tire surfaces directly through images, line laser scanning is used to obtain tire images. The filtering method and morphology method are combined to preprocess these images. The gray centroid method is adopted to extract the center of the laser stripe, and then the algorithm to determine the positions of bubble defects on tire surfaces is proposed. According to the geometric characteristics of tire bubbles, the coordinates of starting points, ending points, and rough positions of vertices are determined. Then, the ordinates of the laser center with sub-pixel accuracy near bubble vertices are discretely magnified. The mask made of Gaussian function is convoluted with the magnified region, and the maximum value is obtained. Furthermore, the position of bubble vertices can be accurately extracted. The denoising effects of different methods for images are compared through experiments, and different positions of bubbles are detected. Experimental results show that the detection accuracy of this method is up to 93%, which is much higher than other methods. Experiments verify that the proposed method is effective for detecting tire surface bubbles. Full article

The article discusses the possibility of object detector usage in field of automated visual inspection for objects with specific parameters, specifically various types of defects occurring on the surface of a car tire. Due to the insufficient amount of input data, as well as the need to speed up the development process, the Transfer Learning principle was applied in a designed system. In this approach, the already pre-trained convolutional neural network AlexNet was used, subsequently modified in its last three layers, and again trained on a smaller sample of our own data. The detector used in the designed camera inspection system with the above architecture allowed us to achieve the accuracy and versatility needed to detect elements (defects) whose shape, dimensions and location change with each occurrence. The design of a test facility with the application of a 12-megapixel monochrome camera over the rotational table is briefly described, whose task is to ensure optimal conditions during the scanning process. The evaluation of the proposed control system with the quantification of the recognition capabilities in the individual defects is described at the end of the study. The implementation and verification of such an approach together with the proposed methodology of the visual inspection process of car tires to obtain better classification results for six different defect classes can be considered as the main novel feature of the presented research. Subsequent testing of the designed system on a selected batch of sample images (containing all six types of possible defect) proved the functionality of the entire system while the highest values of successful defect detection certainty were achieved from 85.15% to 99.34%. Full article

This paper introduces and implements an efficient training method for deep learning–based anomaly area detection in the depth image of a tire. A depth image of 16 bit integer size is used in various fields, such as manufacturing, industry, and medicine. In addition, the advent of the 4th Industrial Revolution and the development of deep learning require deep learning–based problem solving in various fields. Accordingly, various research efforts use deep learning technology to detect errors, such as product defects and diseases, in depth images. However, a depth image expressed in grayscale has limited information, compared with a three-channel image with potential colors, shapes, and brightness. In addition, in the case of tires, despite the same defect, they often have different sizes and shapes, making it difficult to train deep learning. Therefore, in this paper, the four-step process of (1) image input, (2) highlight image generation, (3) image stacking, and (4) image training is applied to a deep learning segmentation model that can detect atypical defect data. Defect detection aims to detect vent spews that occur during tire manufacturing. We compare the training results of applying the process proposed in this paper and the general training result for experiment and evaluation. For evaluation, we use intersection of union (IoU), which compares the pixel area where the actual error is located in the depth image and the pixel area of the error inferred by the deep learning network. The results of the experiment confirmed that the proposed methodology improved the mean IoU by more than 7% and the IoU for the vent spew error by more than 10%, compared to the general method. In addition, the time it takes for the mean IoU to remain stable at 60% is reduced by 80%. The experiments and results prove that the methodology proposed in this paper can train efficiently without losing the information of the original depth data. Full article

At present, inspection systems process visual data captured by cameras, with deep learning approaches applied to detect defects. Defect detection results usually have an accuracy higher than 94%. Real-life applications, however, are not very common. In this paper, we describe the development of a tire inspection system for the tire industry. We provide methods for processing tire sidewall data obtained from a camera and a laser sensor. The captured data comprise visual and geometric data characterizing the tire surface, providing a real representation of the captured tire sidewall. We use an unfolding process, that is, a polar transform, to further process the camera-obtained data. The principles and automation of the designed polar transform, based on polynomial regression (i.e., supervised learning), are presented. Based on the data from the laser sensor, the detection of abnormalities is performed using an unsupervised clustering method, followed by the classification of defects using the VGG-16 neural network. The inspection system aims to detect trained and untrained abnormalities, namely defects, as opposed to using only supervised learning methods. Full article

Automatic defect detection of tire has become an essential issue in the tire industry. However, it is challenging to inspect the inner structure of tire by surface detection. Therefore, an X-ray image sensor is used for tire defect inspection. At present, detection of defective tires is inefficient because tire factories commonly conduct detection by manually checking X-ray images. With the development of deep learning, supervised learning has been introduced to replace human resources. However, in actual industrial scenes, defective samples are rare in comparison to defect-free samples. The quantity of defective samples is insufficient for supervised models to extract features and identify nonconforming products from qualified ones. To address these problems, we propose an unsupervised approach, using no labeled defect samples for training. Moreover, we introduce an augmented reconstruction method and a self-supervised training strategy. The approach is based on the idea of reconstruction. In the training phase, only defect-free samples are used for training the model and updating memory items in the memory module, so the reproduced images in the test phase are bound to resemble defect-free images. The reconstruction residual is utilized to detect defects. The introduction of self-supervised training strategy further strengthens the reconstruction residual to improve detection performance. The proposed method is experimentally proved to be effective. The Area Under Curve (AUC) on a tire X-ray dataset reaches 0.873, so the proposed method is promising for application. Full article

The present paper discusses a comparative application of image processing techniques, i.e., Discrete Fourier Transform, K-Means clustering and Artificial Neural Network, for the detection of defects in the industrial context of assembled tires. The used Artificial Neural Network technique is based on Long Short-Term Memory and Fully Connected neural networks. The investigations focus on the monitoring and quality control of defects, which may appear on the external surface of tires after being assembled. Those defects are caused from tires which are not properly assembled to their respective metallic wheel rim, generating deformations and scrapes which are not desired. The proposed image processing techniques are applied on raw high-resolution images, which are acquired by in-line imaging and optical instruments. All the described techniques, i.e., Discrete Fourier Transform, K-Means clustering and Long Short-Term Memory, were able to determine defected and acceptable external tire surfaces. The proposed research is taken in the context of an industrial project which focuses on the development of automated quality control and monitoring methodologies, within the field of Industry 4.0 facilities. The image processing techniques are thus meant to be adopted into production processes, giving a strong support to the in-line quality control phase. Full article

In recent times, the application of enabling technologies such as digital shearography combined with deep learning approaches in the smart quality assessment of tires, which leads to intelligent tire manufacturing practices with automated defects detection. Digital shearography is a prominent approach that can be employed for identifying the defects in tires, usually not visible to human eyes. In this research, the bubble defects in tire shearography images are detected using a unique ensemble hybrid amalgamation of the convolutional neural networks/ConvNets with high-performance Faster Region-based convolutional neural networks. It can be noticed that the routine of region-proposal generation along with object detection is accomplished using the ConvNets. Primarily, the sliding window based ConvNets are utilized in the proposed model for dividing the input shearography images into regions, in order to identify the bubble defects. Subsequently, this is followed by implementing the Faster Region-based ConvNets for identifying the bubble defects in the tire shearography images and further, it also helps to minimize the false-positive ratio (sometimes referred to as the false alarm ratio). Moreover, it is evident from the experimental results that the proposed hybrid model offers a cent percent detection of bubble defects in the tire shearography images. Also, it can be witnessed that the false-positive ratio gets minimized to 18 percent. Full article
