Hyperspectral drill-core scanning adds value to exploration campaigns by providing continuous, high-resolution mineralogical data over the length of entire boreholes. However, multivariate mineralogical data must be transformed into lithological domains such that it is compatible with interpolation techniques and be usable for geomodeling. Manual interpretation of multivariate drill-core data is a challenging, time-consuming and subjective task, and automated or semi-automated approaches are needed. However, naive machine-learning techniques that ignore the distinct spatial structure and multi-scale nature of geological systems tend to produce geologically unreasonable results. Automated geological logging and multi-scale hierarchical domaining of drill-cores has been previously addressed in several studies by means of scalograms from a wavelet transform and tessellation, albeit exploiting only univariate information. The methodology involves the extraction of the local first principal component at a neighborhood of each observation, and the segmentation of the resulting series of scores with a continuous wavelet transform for boundary detection. In this way, the correlation pattern between the variables is incorporated into the segmentation. The scalogram accurately locates the geological boundaries at depth and yields hierarchical geological domains with mineralogical composition characteristics. The performance of this approach is demonstrated on a synthetic as well as a real multivariate dataset. The real dataset consists of mineral abundances derived from drill-core hyperspectral imaging data acquired in Elvira, a shale-hosted volcanogenic massive sulfide deposit located in the Iberian Pyrite Belt, where 7000 m of drill-core were acquired along 80 boreholes. The extracted domains are sensible from a geological point of view and spatially coherent across the boreholes in cross-sections. The results at relevant scales were qualitatively validated by comparing against the lithological log. This method is fast, is appropriate for multivariate geological data along boreholes, and provides a choice of scales for hierarchical geological domains along boreholes with mineralogical composition characteristics that can be modeled in 3D. Our approach provides an automatic way to transform hyperspectral image-derived mineral maps into vertically coherent geological units that are appropriate inputs for 3D geological modeling workflows. Moreover, the method improves the boundary detection and geological domaining by making use of multivariate information. Full article

This paper demonstrates a novel approach that uses wavelet tessellation in rapid analysis of raw geochemical data produced by laser-induced breakdown spectroscopy (LIBS) to produce pseudologs that are representative of stratigraphy. Single-line LIBS spectral data for seven major rock-forming elements (Al, Ca, Fe, Mg, Si, Na and K) were collected from a synthetic 22-sample rock-block comprising two distinct lithological groups based on mineralogy, chemistry and texture: plutonic rocks and marble. Seven sublithologies are identified within the rock-block from traditional laboratory whole-rock geochemical analysis: marble, Mg-marble, granite, quartz monzonite, foidolite, granodiorite and gabbroic diorite. Two-domain clustering (k = 2) on raw spectral LIBS data combined with wavelet tessellation was applied to generate a simplified lithological stratigraphy of marble and plutonic rocks and generate a pseudolog identical to the rock-block stratigraphy. A pseudolog generated from seven-domain clustering (k = 7) and wavelet tessellation successfully discriminated most sublithologies within the rock-block slabs, especially marble slabs. Small-scale units were identified within the more mineralogically and geochemically complex plutonic slabs. The spatial resolution of the LIBS analysis, with a measurement spacing of ~0.35 mm, allowed for assessment of individual mineral compositions and rock textures, and small-scale units within the plutonic rocks can be correlated to specific coarse-grained minerals or mineralogical associations. The application of the wavelet tessellation method to raw LIBS geochemical data offers the possibility of rapid and objective lithogeochemical analysis and interpretations which can predate further analysis (quantitative) and supplement geological logging. Full article
