Comparison of Conventional Imaging and 18F-Fluorodeoxyglucose Positron Emission Tomography/Computed Tomography in the Diagnostic Accuracy of Staging in Patients with Intrahepatic Cholangiocarcinoma
by
, ,
Eiko Nishioka
1,
Masakatsu Tsurusaki
2,*,
Ryohei Kozuki
2,
Sung-Woon Im
2,
Atsushi Kono
1,
Kazuhiro Kitajima
3,
Takamichi Murakami
1 and
Kazunari Ishii
2 1
Department of Radiology, Kobe University Graduate School of Medicine, Kobe 650-0017, Hyogo, Japan
2
Department of Radiology, Kindai University Faculty of Medicine, Osaka-Sayama 589-8511, Osaka, Japan
3
Department of Radiology, Hyogo Medical University Faculty of Medicine, Nishinomiya 663-8501, Hyogo, Japan
*
Author to whom correspondence should be addressed.
Diagnostics 2022, 12(11), 2889; https://doi.org/10.3390/diagnostics12112889
Submission received: 29 September 2022
/
Revised: 14 November 2022
/
Accepted: 17 November 2022
/
Published: 21 November 2022
(This article belongs to the Special Issue The Role of Imaging in Liver Surgery)
Abstract
:We aimed to examine the accuracy of tumor staging of intrahepatic cholangiocarcinoma (ICC) by using 18F-fluorodeoxyglucose positron emission tomography/computed tomography (18F-FDG PET-CT). From January 2001 to December 2021, 202 patients underwent PET-CT, CT, and MRI for the initial staging of ICC in two institutions. Among them, 102 patients had undergone surgical treatment. Ninety patients who had a histopathological diagnosis of ICC were retrospectively reviewed. The sensitivity and specificity of 18F-FDG PET-CT, CT, and magnetic resonance imaging (MRI) in detecting tumors, satellite focus, vascular invasion, and lymph node metastases were analyzed. Ninety patients with histologically diagnosed ICC were included. PET-CT demonstrated no statistically significant advantage over CT and MR in the diagnosis of multiple tumors and macrovascular invasion, and bile duct invasion. The overall sensitivity, specificity, positive predictive value (PPV), negative predictive value (NPV), and accuracy of PET-CT in lymph node metastases were 84%, 86%, 91%, 84%, and 86%, respectively. PET-CT revealed a significantly higher accuracy compared to CT or MRI (86%, 67%, and 76%, p < 0.01, respectively) in the diagnosis of regional lymph node metastases. The accuracy of tumor staging by PET-CT was higher than that by CT/MRI (PET-CT vs. CT vs. MRI: 68/90 vs. 47/90 vs. 51/90, p < 0.05). 18F-FDG PET-CT had sensitivity and specificity values for diagnosing satellite focus and vascular and bile duct invasion similar to those of CT or MRI; however, PET-CT showed higher accuracy in diagnosing regional lymph node metastases. 18F-FDG PET-CT exhibited higher tumor staging accuracy than that of CT/MRI. Thus, 18FDG PET-CT may support tumor staging in ICC.
1. Introduction
Intrahepatic cholangiocarcinoma (ICC) is the second most common primary hepatic malignancy after hepatocellular carcinoma (HCC). Epidemiological studies show that ICC is rare in most western countries. However, the incidence is exceptionally high in Asian countries, such as China, Korea, Japan, and Thailand. The northeastern region of Thailand has the highest incidence worldwide (85 per 100,000 population/year) [1]. Notably, ICC shares some common risk factors with HCC, such as hepatitis B or C viral infection, cirrhosis, diabetes, and alcohol abuse [2]. The early diagnosis of ICC is difficult, as the disease is typically asymptomatic. The tumor, nodes, and metastases (TNM) system by the International Union Against Cancer (UICC)/American Joint Committee on Cancer (AJCC) is widely used for ICC staging. However, until the sixth edition of this staging system, the staging of HCC and ICC was identical, with the distinction between these two only being introduced in the seventh edition and updated in the current eighth edition. [3]. Computed tomography/magnetic resonance imaging (CT/MRI) is routinely used in the diagnosis and staging of ICC. However, the associated diagnostic accuracy, sensitivity, specificity, and TNM staging are considered suboptimal for ICC management [4,5].
Positron emission tomography (PET) using 18F-fluorodeoxyglucose (18F-FDG) is an imaging modality that measures the glucose metabolism rate in tumor cells and thus provides biochemical information about tumors, which is not provided by other imaging modalities. Increased uptake of 18F-FDG represents an enhanced glucose metabolism in cancer cells, which makes it a marker of tumor viability. Expectedly, 18F-FDG PET-CT is increasingly used in the diagnosis, prognosis, staging, and treatment monitoring of many tumor types [6,7,8,9,10,11]. To our knowledge, there has been only one meta-analysis, and few studies have evaluated the diagnostic efficacy of 18F-FDG PET/CT for patients with ICC [12,13,14,15,16,17], which is not currently included in the routine clinical management of ICC [1,18,19]. There was no study that evaluated the correlation among associated diagnostic accuracy, sensitivity, specificity, and the eighth edition of TNM staging for ICC.
Our preliminary findings suggest that this modality may help identify lymph nodes and distant metastases in patients with ICC. Therefore, a cohort study of patients with ICC was conducted to compare the efficacy of 18F-FDG PET-CT with that of CT/MRI in tumor staging.
2. Materials and Methods
2.1. Patients
Patients who were diagnosed with ICC using CT/MRI at the Kindai University Hospital and Hyogo Medical University Hospital between January 2001 and December 2021 were retrospectively reviewed. These patients were routinely investigated with conventional radiological imaging modalities, such as chest radiography/CT and abdominal CT/MRI, to assess the tumor stage. Simultaneously, 18F-FDG PET-CT was performed for these patients. All imaging examinations were performed 4 weeks before treatment. The patient’s demographic and clinical characteristics data were collected, and the TNM stage was assessed using the eighth edition of the AJCC/Union for International Cancer Control (UICC) staging system [3]. The study was conducted in accordance with the Declaration of Helsinki. Approval was granted by the local ethics committee (25-117). The requirement for informed consent was waived.
2.2. Conventional Radiological Imaging
Contrast-enhanced abdominal CT (Aquilion Multi 64, Toshiba Medical Systems, Otawara, Japan, and Discovery CT 750HD, GE Medical Systems, Milwaukee, WI, USA) and MRI at a 3T scanner (Intera Acheiva 3T, Philips Healthcare, Best, The Netherlands) or 1.5T scanner (1.5T Signa HDxt, GE Healthcare, Milwaukee, WI, USA) were used to evaluate the primary tumors and to detect any intraabdominal metastases. Chest radiography and whole-body bone scintigraphy were used to identify distant metastases. After the injection of intravenous contrast (150 mL at 3 mL/s), CT and MRI scans of the abdomen were obtained with 5 mm collimation and a table speed of 5 mm/s. The images were reconstructed with 5 mm thickness. The CT and MRI scans were interpreted by radiologists with over 10 years of experience. A diagnosis of ICC was defined as an irregular mass with markedly low attenuation, peripheral rim enhancement followed by the progressive and concentric filling with contrast, and the focal dilatation of the intrahepatic ducts around the tumor. Enlarged lymph nodes were identified on CT/MRI and were measured along their short axes. Lymph node metastasis was defined as a short axis of ≥10 mm or when it increased by ≥20% on sequential CT/MRI scans within an interval of four weeks [20].
2.3. PET
The 18F-FDG PET-CT images were obtained using a PET/CT scanner (Discovery PET/CT 710; GE Healthcare Life Sciences, Amersham Place, Little Chalfont, Buckinghamshire, England). The patients fasted for at least four hours before the intravenous administration of 3.0 MBq/kg of 18F-FDG (80.7–307.5 MBq). The blood sugar level was checked before administration, and none of the patients had a glucose level greater than 115 mg/dL. The patients underwent full-body scans. Imaging began approximately 60 min after an intravenous administration of 18F-FDG using the 3D time-of-flight mode (3D TOF), and the helical CT data acquired with free breathing were used for attenuation correction. The CT scanning parameters were 120 kV, an automated tube current with a noise index of 23 for helical CT, 0.5 s/rotation, a pitch factor of 1.375, a detector configuration of 16 × 1.25 mm, a slice thickness of 3.75 mm, a slice interval of 3.27 mm, and a display field-of-view (DFOV) of 500 mm. All PET images were reconstructed using a block sequential regularized expectation maximization algorithm. We adopted a β value of 800. The PET imaging properties were as follows: a slice thickness and interval of 3.27 mm and a matrix size of 192 × 192, and a DFOV of 500 mm. Accurate patient positioning between the transmission and emission scanning was performed via laser marking. Both attenuation-corrected and non-attenuation-corrected images were interpreted visually. The attenuation-corrected images were then analyzed semi-quantitatively using standard uptake values (SUV). Regions of interest were drawn over the area of maximum activity in a lesion. The SUV was calculated as follows: SUV = tissue concentration/(injected dose × body weight). A primary tumor was defined when a focal lesion with an increase in the 18F-FDG uptake was detected relative to the values observed in the surrounding normal tissue. A lymph node was defined as positive when SUVmax was ≥2.5 [20].
2.4. Statistical Analysis
Categorical variables were presented as numbers (percentages) and compared using the χ2 test. Continuous variables were checked for normality, and continuous variables were presented as the mean ± standard deviation (SD) and compared using the t-test. The McNemar test was used to compare the diagnostic performance between PET/CT and conventional imaging methods. These analyses were performed using SPSS Statistics version 17.0 (SPSS; IBM, Tokyo, Japan). p-values < 0.05 were considered statistically significant.
3. Results
From January 2001 to December 2021, 255 consecutive patients were clinically diagnosed with ICC. Among them, 202 patients underwent PET-CT, CT, and MRI during their preoperative diagnosis session, including 102 patients who had undergone surgical treatment. Among the 102 patients who had a histopathological diagnosis, 90 had ICC and were included in this study (Table 1). The tumor size, tumor number, macroscopic vascular invasion, cancer embolus in the bile duct, lymph node metastases, nerve invasion, and peripheral tissue invasion were evaluated by histopathological examinations (Supplementary Figure S1).
Eleven patients were diagnosed histopathologically with HCC and one with an isolated necrotic nodule. Among 90 patients with ICC, 85 underwent hepatectomy plus lymphadenectomy, and five underwent exploratory laparotomy only because of the intraoperative detection of abdominal metastases (peritoneal dissemination). Moreover, 105 cases (including five exploratory laparotomy cases) were considered unresectable preoperatively due to multiple tumors in the future remnant liver (n = 10), peritoneal dissemination (n = 5), distant lymph node metastasis (n = 48), and distant organ metastases (n = 42). Among the 90 patients that underwent surgery, 35 patients had multiple tumors, 5 had vascular invasion, 6 had bile duct invasion, and 25 had regional lymph node metastases (Table 1).
Multiple tumors were diagnosed by CT, MRI, and PET-CT scans with corresponding accuracy rates of 80%, 79%, and 72%, respectively. The diagnosis of vascular invasion in patients by CT, MRI, and PET-CT had accuracy rates of 88%, 92%, and 94%, respectively. Bile duct invasion was diagnosed by CT, MRI, and PET-CT and had corresponding accuracy rates of 93%, 96%, and 94%, respectively. Twenty-five patients had histologically confirmed metastases in the regional lymph nodes. Regional lymph node metastases detected by CT had a sensitivity of 40%, MRI had a sensitivity of 56%, and PET-CT had a sensitivity of 84%. These results are shown in detail in Table 2.
The corresponding specificity rates were 80%, 83%, and 86%, respectively. PET-CT showed higher accuracy (86%) than those of CT (67%) and MRI (76%) at diagnosing lymph node metastasis in patients with ICC (p < 0.01). Among the 34 patients with lymph nodes > 1 cm, 23 (68%) patients had lymph node metastases. Among the 23 patients with lymph nodes of ≤1 cm, 2 (8.7%) were positive for metastases. There was a positive association between the lymph node metastases status and lymph node size (p < 0.01).
The TNM staging of each patient was assessed using PET-CT or conventional radiological imaging, including abdominal CT or MRI, chest radiography, and whole-body bone scintigraphy (CT/MRI) evaluations (Table 3). Among them, 33/30/19 patients were down-staged, and 10/9/3 were up-staged by CT/MRI/PET-CT when compared with pathological examination. The accuracy of tumor staging by PET-CT was higher than that by CT/MRI (PET-CT vs. CT vs. MRI: 68/90 vs. 47/90 vs. 51/90, p = 0.003) (Table 4). PET-CT had no impact on patient management in 76% of cases.
4. Discussion
The 18F-FDG PET scan is a radiological technique that combines anatomic and functional imaging. It is increasingly used in the management of different tumors [21,22,23,24,25,26]. Most studies find it valuable in diagnosing and staging tumors when compared with traditional imaging techniques such as CT and MRI. There were a few studies presenting the advantages and disadvantages of 18F-FDG PET-CT with a particular focus on ICC. It has also been reported as useful in malignant biliary cancer, including ICC, as it outperformed CT and MRI at detecting lymph node metastases [13,14,20]. Two meta-analyses compared the diagnostic value of 18F-FDG PET/CT versus MRI for the staging of both extrahepatic and intrahepatic cholangiocarcinoma (ECC/ICC) [27,28]. This meta-analysis indicated that both MRI and 18F-FDG PET/CT could provide reasonable diagnostic accuracy for primary tumors of ECC/ICC. According to our study, 18F-FDG PET/CT positive findings can diagnose lymph node metastases, while negative findings may not exclude the metastases. As for MRI, it can neither rule in nor rule out the disease. Therefore, 18F-FDG PET/CT may be a better choice for diagnosing lymph node metastasis of ECC/ICC. We summarized the past studies of the diagnostic value of 18F-FDG PET/CT for the staging of ECC/ICC Table 5 [12,14,16,17,29,30,31,32,33,34,35,36,37,38]. However, no past meta-analysis and few studies have evaluated the diagnostic performance of 18F-FDG PET/CT in patients with a focused-on ICC. Most studies have reported that the sensitivity, specificity, and accuracy values of 18F-FDG PET for detecting lymph node metastases were significantly higher than those of CT/MRI imaging. Compared to CT/MRI, 18F-FDG PET imaging assessments, the uptake of 18F-FDG reduces the risk of misdiagnosis, which is associated with CT/MRI and evaluations by relatively inexperienced radiologists. However, 18F-FDG PET has limitations in detecting small lesions with low tumor metabolism. The present study found that 18F-FDG PET was not superior at diagnosing satellite lesions (Figure 1) and vascular and bile duct invasion (Figure 2).
Conventional imaging techniques, such as CT and MRI, can help diagnose lymph node metastases when the lymph node size is ≥1 cm. In this study, the relationship between lymph node size and lymph node metastasis was positive. However, among patients with lymph nodes > 1 cm, 38 cases (61.3%) were positive for metastases. Among patients with lymph nodes ≤ 1 cm, 2 (7.1%) cases were diagnosed with metastasis. Thus, a lymph node size > 1 cm is not an accurate indicator of metastasis risk. Using a high SUV, 18F-FDG PET showed high sensitivity, specificity, and accuracy in detecting lymph node metastasis. Most previous studies on 18F-FDG PET for malignant tumors highlighted the modality’s capacity to detect distant metastatic lesions and tumor recurrence. These findings were validated in this study.
As a whole-body imaging technique, 18F-FDG PET is more powerful than conventional imaging techniques, such as abdominal CT/MRI. PET-CT imaging, had higher accuracy in tumor staging than CT/MRI in patients who received treatment that was different from what was originally planned. This study showed that 18F-FDG PET may help assess lymph node metastases. Moreover, this modality might be used as a complementary examination in patients with ICC alongside CT/MRI.
This study had the following major limitations. First, 105 patients, with the exception of five exploratory laparotomy cases with abdominal metastases, did not receive surgery, lacked histological staging findings, and were thus not eligible for tumor staging. In five cases, peritoneal dissemination could not be diagnosed by PET-CT, and exploratory laparotomy was performed. Therefore, the diagnostic performance of PET-CT for peritoneal dissemination seems to be limited. Second, this was not a randomized controlled study and might have been affected by selection bias. Thus, a well-designed randomized controlled trial is required to validate our findings.
5. Conclusions
When compared with CT or MRI, 18F-FDG PET-CT had similar sensitivity and specificity values for diagnosing satellite focus and vascular and bile duct invasion; however, PET-CT exhibited higher accuracy in diagnosing regional lymph node metastases. The accuracy of tumor staging by 18F-FDG PET-CT was higher than that by CT/MRI. Thus, 18FDG PET-CT may support tumor staging in ICC.
Supplementary Materials
The following supporting information can be downloaded at: https://www.mdpi.com/article/10.3390/diagnostics12112889/s1, Figure S1: Flow chart of patient selection.
Author Contributions
Conceptualization: M.T.; methodology: M.T.; formal analysis: E.N.; image analysis: E.N. and M.T.; data curation: E.N., M.T., R.K., S.-W.I., A.K. and K.K.; writing—original draft preparation: E.N.; writing—review and editing: E.N. and M.T.; supervision: T.M. and K.I. All authors have read and agreed to the published version of the manuscript.
Funding
This research received no external funding.
Institutional Review Board Statement
The study was conducted according to the guidelines of the Declaration of Helsinki and approved by the Institutional Review Board of the Kindai University Faculty of Medicine (Registration number: 25-117, 10 October 2013).
Informed Consent Statement
The requirement for informed consent was waived because of the retrospective nature of the study.
Data Availability Statement
The data presented in this study are available on request from the corresponding author. The data are not publicly available owing to privacy.
Conflicts of Interest
The authors declare no conflict of interest.
References
- Bridgewater, J.; Galle, P.R.; Khan, S.A.; Llovet, J.M.; Park, J.-W.; Patel, T.; Pawlik, T.M.; Gores, G.J. Guidelines for the diagnosis and management of intrahepatic cholangiocarcinoma. J. Hepatol. 2014, 60, 1268–1289. [Google Scholar] [CrossRef] [PubMed] [Green Version]
- Cardinale, V.; Semeraro, R.; Torrice, A.; Gatto, M.; Napoli, C.; Bragazzi, M.C.; Gentile, R.; Alvaro, D. Intra-hepatic and extra-hepatic cholangiocarcinoma: New insight into epidemiology and risk factors. World J. Gastrointest. Oncol. 2010, 2, 407–416. [Google Scholar] [CrossRef] [PubMed]
- Frederick LG, M.D.; Page, D.L.; Fleming, I.D.; Fritz, A.G.; Balch, C.M.; Haller, D.G.; Morrow, M. (Eds.) AJCC Cancer Staging Manual, 8th ed; Springer: New York, NY, USA, 2017. [Google Scholar]
- Ringe, K.I.; Wacker, F. Radiological diagnosis in cholangiocarcinoma: Application of computed tomography, magnetic resonance imaging, and positron emission tomography. Best Pract. Res. Clin. Gastroenterol. 2015, 29, 253–265. [Google Scholar] [CrossRef] [PubMed]
- Fábrega-Foster, K.; Ghasabeh, M.A.; Pawlik, T.M.; Kamel, I.R. Multimodality imaging of intrahepatic cholangiocarcinoma. Hepatobiliary Surg. Nutr. 2017, 6, 67–78. [Google Scholar] [CrossRef] [Green Version]
- Machtay, M.; Duan, F.; Siegel, B.A.; Snyder, B.S.; Gorelick, J.J.; Reddin, J.S.; Munden, R.; Johnson, D.W.; Wilf, L.H.; DeNittis, A.; et al. Prediction of survival by [18F]fluorodeoxyglucose positron emission tomography in patients with locally advanced non-small-cell lung cancer undergoing definitive chemoradiation therapy: Results of the ACRIN 6668/RTOG 0235 trial. J Clin. Oncol. 2013, 31, 3823–3830. [Google Scholar] [CrossRef] [Green Version]
- Martelli, M.; Ceriani, L.; Zucca, E.; Zinzani, P.L.; Ferreri, A.J.; Vitolo, U.; Stelitano, C.; Brusamolino, E.; Cabras, M.G.; Rigacci, L.; et al. [18F]Fluorodeoxyglucose positron emission tomography predicts survival after chemoimmunotherapy for primary mediastinal large B-cell lymphoma: Results of the international extranodal lymphoma study group IELSG-26 study. J. Clin. Oncol. 2014, 32, 1769–1775. [Google Scholar] [CrossRef] [Green Version]
- Mertens, L.S.; Mir, M.C.; Scott, A.M.; Lee, S.T.; Fioole-Bruining, A.; Vegt, E.; Vogel, W.V.; Manecksha, R.; Bolton, D.; Davis, I.D.; et al. 18F-fluorodeoxyglucose–Positron emission tomography/computed tomography aids staging and predicts mortality in patients with muscle-invasive bladder cancer. Urology 2014, 83, 393–399. [Google Scholar] [CrossRef]
- Spaccarelli, N.; Gharavi, M.; Saboury, B.; Cheng, G.; Rook, A.H.; Alavi, A. Role of (18)F-fluorodeoxyglucose positron emission tomography imaging in the management of primary cutaneous lymphomas. Hell. J. Nucl. Med. 2014, 17, 78–84. [Google Scholar] [CrossRef]
- Na, F.; Wang, J.; Li, C.; Deng, L.; Xue, J.; Lu, Y. Primary tumor standardized uptake value measured on F18-fluorodeoxyglucose positron emission tomography is of prediction value for survival and local control in non–small-cell lung cancer receiving radiotherapy: Meta-analysis. J. Thorac. Oncol. 2014, 9, 834–842. [Google Scholar] [CrossRef] [Green Version]
- Mghanga, F.P.; Lan, X.; Bakari, K.H.; Li, C.; Zhang, Y. Fluorine-18 fluorodeoxyglucose positron emission tomography-computed tomography in monitoring the response of breast cancer to neoadjuvant chemotherapy: A meta-analysis. Clin. Breast Cancer 2013, 13, 271–279. [Google Scholar] [CrossRef]
- Kim, J.Y.; Kim, M.-H.; Lee, T.Y.; Hwang, C.Y.; Kim, J.S.; Yun, S.-C.; Lee, S.S.; Seo, D.W.; Lee, S.K. Clinical role of 18F-FDG PET-CT in suspected and potentially operable cholangiocarcinoma: A prospective study compared with conventional imaging. Am. J. Gastroenterol. 2008, 103, 1145–1151. [Google Scholar] [CrossRef] [PubMed]
- Lee, S.W.; Kim, H.J.; Park, J.H.; Park, D.I.; Cho, Y.K.; Sohn, C.I.; Jeon, W.K.; Kim, B.I. Clinical usefulness of 18F-FDG PET-CT for patients with gallbladder cancer and cholangiocarcinoma. J. Gastroenterol. 2010, 45, 560–566. [Google Scholar] [CrossRef] [PubMed]
- Seo, S.; Hatano, E.; Higashi, T.; Nakajima, A.; Nakamoto, Y.; Tada, M.; Tamaki, N.; Iwaisako, K.; Mori, A.; Doi, R.; et al. Fluorine-18 fluorodeoxyglucose positron emission tomography predicts lymph node metastasis, P-glycoprotein expression, and recurrence after resection in mass-forming intrahepatic cholangiocarcinoma. Surgery 2008, 143, 769–777. [Google Scholar] [CrossRef] [PubMed]
- Moon, C.M.; Bang, S.; Chung, J.B. The role of 18F-fluorodeoxyglucose positron emission tomography in the diagnosis, staging, and follow-up of cholangiocarcinoma. Surg. Oncol. 2011, 20, e10–e17. [Google Scholar] [CrossRef] [PubMed]
- Jiang, L.; Tan, H.; Panje, C.M.; Yu, H.; Xiu, Y.; Shi, H. Role of 18F-FDG PET/CT Imaging in Intrahepatic Cholangiocarcinoma. Clin. Nucl. Med. 2016, 41, 1–7. [Google Scholar] [CrossRef] [PubMed]
- Lee, Y.; Yoo, I.R.; Boo, S.H.; Kim, H.; Park, H.L.; Hyun, O.J. The role of F-18 FDG PET/CT in intrahepatic cholangiocarcinoma. Nucl. Med. Mol. Imaging 2017, 51, 69–78. [Google Scholar] [CrossRef] [Green Version]
- Benson, A.B., 3rd; D’Angelica, M.I.; Abbott, D.E.; Abrams, T.A.; Alberts, S.R.; Anaya, D.A.; Are, C.; Brown, D.B.; Chang, D.T.; Covey, A.M.; et al. NCCN guidelines insights: Hepatobiliary cancers, Version 1.2017. J. Natl. Compr. Cancer Netw. JNCCN 2017, 15, 563–573. [Google Scholar] [CrossRef]
- Kubo, S.; Shinkawa, H.; Asaoka, Y.; Ioka, T.; Igaki, H.; Izumi, N.; Itoi, T.; Unno, M.; Ohtsuka, M.; Okusaka, T.; et al. Liver cancer study group of Japan clinical practice guidelines for intrahepatic cholangiocarcinoma. Liver Cancer 2022, 11, 290–314. [Google Scholar] [CrossRef]
- Park, T.G.; Yu, Y.-D.; Park, B.J.; Cheon, G.J.; Oh, S.Y.; Kim, D.-S.; Choe, J.-G. Implication of lymph node metastasis detected on 18F-FDG PET/CT for surgical planning in patients with peripheral intrahepatic cholangiocarcinoma. Clin. Nucl. Med. 2014, 39, 1–7. [Google Scholar] [CrossRef]
- Spolverato, G.; Bagante, F.; Weiss, M.; Alexandrescu, S.; Marques, H.P.; Aldrighetti, L.; Maithel, S.K.; Pulitano, C.; Bauer, T.W.; Shen, F.; et al. Comparative performances of the 7th and the 8th editions of the American joint committee on cancer staging systems for intrahepatic cholangiocarcinoma. J. Surg. Oncol. 2017, 115, 696–703. [Google Scholar] [CrossRef]
- Wang, Y.; Li, J.; Xia, Y.; Gong, R.; Wang, K.; Yan, Z.; Wan, X.; Liu, G.; Wu, D.; Shi, L.; et al. Prognostic nomogram for intrahepatic cholangiocarcinoma after partial hepatectomy. J. Clin. Oncol. 2013, 31, 1188–1195. [Google Scholar] [CrossRef] [PubMed]
- Al-Ibraheem, A.; Buck, A.K.; Benz, M.R.; Rudert, M.; Beer, A.J.; Mansour, A.; Pomykala, K.L.; Haller, B.; Juenger, H.; Scheidhauer, K.; et al. 18F-Fluorodeoxyglucose positron emission tomography/computed tomography for the detection of recurrent bone and soft tissue sarcoma. Cancer 2012, 119, 1227–1234. [Google Scholar] [CrossRef] [PubMed]
- Bartoletti, R.; Meliani, E.; Bongini, A.; Magno, C.; Cai, T. Fluorodeoxyglucose positron emission tomography may aid the diagnosis of aggressive primary prostate cancer: A case series study. Oncol. Lett. 2014, 7, 381–386. [Google Scholar] [CrossRef] [Green Version]
- Casulo, C.; Schöder, H.; Feeney, J.; Lim, R.; Maragulia, J.; Zelenetz, A.D.; Horwitz, S. 18F-fluorodeoxyglucose positron emission tomography in the staging and prognosis of T cell lymphoma. Leuk. Lymphoma 2013, 54, 2163–2167. [Google Scholar] [CrossRef] [Green Version]
- Chakraborty, D.; Mittal, B.R.; Kashyap, R.; Mete, U.K.; Narang, V.; Das, A.; Bhattacharya, A.; Khandelwal, N.; Mandal, A.K. Role of fluorodeoxyglucose positron emission tomography/computed tomography in diagnostic evaluation of carcinoma urinary bladder: Comparison with computed tomography. World J. Nucl. Med. 2014, 13, 34–39. [Google Scholar] [CrossRef] [PubMed]
- Huang, X.; Yang, J.; Li, J.; Xiong, Y. Comparison of magnetic resonance imaging and 18-fludeoxyglucose positron emission tomography/computed tomography in the diagnostic accuracy of staging in patients with cholangiocarcinoma: A meta-analysis. Medicine 2020, 99, e20932. [Google Scholar] [CrossRef]
- Hu, J.-H.; Tang, J.-H.; Lin, C.-H.; Chu, Y.-Y.; Liu, N.-J. Preoperative staging of cholangiocarcinoma and biliary carcinoma using 18F-fluorodeoxyglucose positron emission tomography: A meta-analysis. J. Investig. Med. 2018, 66, 52–61. [Google Scholar] [CrossRef]
- Ruys, A.T.; Bennink, R.J.; van Westreenen, H.L.; Engelbrecht, M.R.; Busch, O.R.; Gouma, D.J.; van Gulik, T.M. FDG-positron emission tomography/computed tomography and standardized uptake value in the primary diagnosis and staging of hilar cholangiocarcinoma. HPB 2011, 13, 256–262. [Google Scholar] [CrossRef] [Green Version]
- Petrowsky, H.; Wildbrett, P.; Husarik, D.B.; Hany, T.F.; Tam, S.; Jochum, W.; Clavien, P.-A. Impact of integrated positron emission tomography and computed tomography on staging and management of gallbladder cancer and cholangiocarcinoma. J. Hepatol. 2006, 45, 43–50. [Google Scholar] [CrossRef]
- Ma, K.W.; Cheung, T.T.; She, W.H.; Chok, K.S.H.; Chan, A.C.Y.; Dai, W.C.; Chiu, K.W.H.; Lo, C.M. Diagnostic and prognostic role of 18-FDG PET/CT in the management of resectable biliary tract cancer. World J. Surg. 2018, 42, 823–834. [Google Scholar] [CrossRef]
- Li, X.; Zhang, Y.; Zhang, Y. 18F-FDG PET/CT may be a suitable method for preoperative diagnosis and evaluation of Chinese older patients with hilar cholangiocarcinoma. BMC Geriatr. 2018, 18, 150. [Google Scholar] [CrossRef] [PubMed] [Green Version]
- Li, J.; Kuehl, H.; Grabellus, F.; Müller, S.P.; Radunz, S.; Antoch, G.; Nadalin, S.; Broelsch, C.E.; Gerken, G.; Paul, A.; et al. Preoperative assessment of hilar cholangiocarcinoma by dual-modality PET/CT. J. Surg. Oncol. 2008, 98, 438–443. [Google Scholar] [CrossRef] [PubMed]
- Kluge, R.; Schmidt, F.; Caca, K.; Barthel, H.; Hesse, S.; Georgi, P.; Seese, A.; Huster, D.; Berr, F. Positron emission tomography with [18F]fluoro-2-deoxy-D-glucose for diagnosis and staging of bile duct cancer. Hepatology 2001, 33, 1029–1035. [Google Scholar] [CrossRef] [PubMed]
- Kim, Y.J.; Yun, M.; Lee, W.J.; Kim, K.S.; Lee, J.D. Usefulness of 18F-FDG PET in intrahepatic cholangiocarcinoma. Eur. J. Nucl. Med. Mol. Imaging 2003, 30, 1467–1472. [Google Scholar] [CrossRef] [PubMed]
- Kato, T.; Tsukamoto, E.; Kuge, Y.; Katoh, C.; Nambu, T.; Nobuta, A.; Kondo, S.; Asaka, M.; Tamaki, N. Clinical role of 18F-FDG PET for initial staging of patients with extrahepatic bile duct cancer. Eur. J. Nucl. Med. Mol. Imaging 2002, 29, 1047–1054. [Google Scholar] [CrossRef] [PubMed]
- Choi, E.K.; Yoo, I.R.; Kim, S.H.; Choi, W.H.; Choi, W.H.; Na, S.J.; Park, S.Y. The clinical value of dual-time point 18F-FDG PET/CT for differentiating extrahepatic cholangiocarcinoma from benign disease. Clin. Nucl. Med. 2013, 38, e106–e111. [Google Scholar] [CrossRef]
- Adachi, T.; Eguchi, S.; Beppu, T.; Ueno, S.; Shiraishi, M.; Okuda, K.; Yamashita, Y.-I.; Kondo, K.; Nanashima, A.; Ohta, M.; et al. Prognostic impact of preoperative lymph node enlargement in intrahepatic cholangiocarcinoma: A multi-institutional study by the kyushu study group of liver surgery. Ann. Surg. Oncol. 2015, 22, 2269–2278. [Google Scholar] [CrossRef]
Figure 1.
MRI (a,b) showed a satellite nodule (white arrow) separated from the main tumor, which was confirmed by histopathology ((f); black arrow) but was not detected on CT (c) or PET-CT (d,e). (a) T2-weighted MR image, (b) Diffusion-weighted MR image (b factor = 800), (c) Contrast-enhanced CT, (d) PET-CT, (e) PET-CT showing main tumor, (f) Gross specimen.
Figure 1.
MRI (a,b) showed a satellite nodule (white arrow) separated from the main tumor, which was confirmed by histopathology ((f); black arrow) but was not detected on CT (c) or PET-CT (d,e). (a) T2-weighted MR image, (b) Diffusion-weighted MR image (b factor = 800), (c) Contrast-enhanced CT, (d) PET-CT, (e) PET-CT showing main tumor, (f) Gross specimen.
Figure 2.
Contrast-enhanced CT showed bile duct ((b); arrow) and vascular emboli ((c); arrow), which were not detected on MRI (a) or PET-CT (d,e). (a) T2-weighted MR image, (b) Axial section of contrast-enhanced CT, (c) Coronal section of contrast-enhanced CT (d,e) PET-CT, (f) Gross specimen (vascular emboli; arrow).
Figure 2.
Contrast-enhanced CT showed bile duct ((b); arrow) and vascular emboli ((c); arrow), which were not detected on MRI (a) or PET-CT (d,e). (a) T2-weighted MR image, (b) Axial section of contrast-enhanced CT, (c) Coronal section of contrast-enhanced CT (d,e) PET-CT, (f) Gross specimen (vascular emboli; arrow).
Table 1.
Clinical and histopathologic characteristics of patients undergoing surgery (n = 90).
| Parameter | Case or Mean ± SD |
|---|---|
| Age (year) | 64.2 (±10.6) |
| Sex (male/female) | 57/33 |
| Hepatitis (B/C) | 8/10 |
| CA199 (>39/≤39 U/mL) | 59/31 |
| CEA (>10/≤10 μg/L) | 16/74 |
| AFP (>20/≤20 μg/L) | 6/84 |
| Tumor location (left lobe/right lobe) | 51/49 |
| SUVmax of tumor | 8.3 (3.5–14.7) |
| SUVmax of lymph node (>2.5/≤2.5) | 32/58 |
| Tumor size (>5/≤5 cm) | 50/40 |
| Tumor number (single/multiple) | 55/35 |
| Macroscopic vascular invasion (yes/no) | 5/85 |
| Cancer embolus in bile duct (yes/no) | 6/84 |
| Lymph node metastases (yes/no) | 25/65 |
| Nerve invasion (yes/no) | 8/82 |
| Peripheral tissue invasion (yes/no) | 6/84 |
CA19-9—carbohydrate antigen 19-9; CEA—carcino-embryonic antigen; AFP—alpha fetoprotein; SUVmax—maximum of standardized uptake value.
Table 2.
Diagnosis of multiple tumors, macrovascular invasion, bile duct invasion, regional lymph node metastases, and distant metastases by imaging modality.
Table 2.
Diagnosis of multiple tumors, macrovascular invasion, bile duct invasion, regional lymph node metastases, and distant metastases by imaging modality.
| CT | MRI | PET-CT | CT vs. MRI vs. PET-CT | CT vs. PET-CT | MRI vs. PET-CT | |
|---|---|---|---|---|---|---|
| Diagnosis of multiple tumors | ||||||
| Sensitivity | 17/35 (49%) | 18/35 (51%) | 10/35 (29%) | N.S. | N.S. | N.S. |
| Specificity | 55/55 (100%) | 53/55 (97%) | 55/55 (100%) | N.S. | N.S. | N.S. |
| PPV | 17/17 (100%) | 18/20 (92%) | 10/10 (100%) | N.S. | N.S. | N.S. |
| NPV | 55/73 (75%) | 53/70 (76%) | 55/77 (71%) | N.S. | N.S. | N.S. |
| Accuracy | 72/90 (80%) | 71/90 (79%) | 65/90 (72%) | N.S. | N.S. | N.S. |
| Diagnosis of macrovascular invasion | ||||||
| Sensitivity | 3/5 (60%) | 3/5 (60%) | 2/5 (40%) | N.S. | N.S. | N.S. |
| Specificity | 76/85 (89%) | 80/85 (94%) | 83/85 (98%) | N.S. | N.S. | N.S. |
| PPV | 3/12 (25%) | 3/8 (38%) | 2/4 (50%) | N.S. | N.S. | N.S. |
| NPV | 76/78 (97%) | 80/82 (98%) | 83/86 (97%) | N.S. | N.S. | N.S. |
| Accuracy | 79/90 (88%) | 83/90 (92%) | 85/90 (94%) | N.S. | N.S. | N.S. |
| Diagnosis of bile duct invasion | ||||||
| Sensitivity | 1/6 (17%) | 3/6 (50%) | 1/6 (17%) | N.S. | N.S. | N.S. |
| Specificity | 83/84 (99%) | 83/84 (99%) | 84/84 (100%) | N.S. | N.S. | N.S. |
| PPV | 1/4 (25%) | 3/6 (50%) | 1/1 (100%) | N.S. | N.S. | N.S. |
| NPV | 83/84 (99%) | 83/84 (99%) | 84/89 (94%) | N.S. | N.S. | N.S. |
| Accuracy | 84/90 (93%) | 86/90 (96%) | 85/90 (94%) | N.S. | N.S. | N.S. |
| Diagnosis of regional lymph node metastases | ||||||
| Sensitivity | 10/25 (40%) | 14/25 (56%) | 21/25 (84%) | 0.02 | <0.01 | <0.01 |
| Specificity | 50/65 (80%) | 54/65 (83%) | 56/65 (86%) | N.S. | N.S. | N.S. |
| PPV | 10/16 (63%) | 14/19 (74%) | 21/23 (91%) | 0.04 | 0.02 | N.S. |
| NPV | 50/74 (68%) | 54/71 (76%) | 56/67 (84%) | <0.01 | <0.01 | 0.02 |
| Accuracy | 60/90 (67%) | 68/90 (76%) | 77/90 (86%) | <0.01 | <0.01 | 0.01 |
N.S. = no significant.
Table 3.
Tumor stage assessed by CT, MRI, and PET-CT.
| Stage | CT | MRI | PET-CT | Pathological Examination |
|---|---|---|---|---|
| I | 75 | 70 | 77 | 56 |
| II | 5 | 4 | 2 | 7 |
| III A | 0 | 2 | 0 | 2 |
| III B | 10 | 14 | 21 | 25 |
| IV | 0 | 0 | 0 | 0 |
Table 4.
Changed tumor staging assessed by CT, MRI, and PET-CT, respectively.
| Up Stage | Down Stage | Unchanged | The Accuracy | |
|---|---|---|---|---|
| CT | 10 | 33 | 47 | 47/90 (52%) * |
| MRI | 9 | 30 | 51 | 51/90 (57%) ** |
| PET-CT | 3 | 19 | 68 | 68/90 (76%) *** |
* p (CT vs. PET-CT) = 0.001, ** p (MRI vs. PET-CT) = 0.007, *** p (CT vs. MRI vs. PET-CT) = 0.003.
Table 5.
The principal characteristics and diagnostic performances on PET-CT of past studies.
| Study | Year | Country | Location | No. of Patients | Female/Male | Median Age | Study Design | Examination | Reference Standard | Primary Tumors (T) | Lymph Node Metastases (N) | Distant Metastases (M) | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Sens. | Spec. | Sens. | Spec. | Acc. | Sens. | Spec. | Acc. | ||||||||||
| present study | 2022 | Japan | intrahepatic | 90 | 33/57 | 64 | R | CI vs. PET/CT | HP | 29.0% | 100.0% | 84.0% | 86.0% | 86.0% | NA | NA | NA |
| Li | 2018 | China | hilar | 53 | 17/36 | 68 | R | PET/CT | HP | 100.0% | NA | 67.9% | 88.0% | 77.4% | 47.1% | 97.2% | 81.1% |
| Ma | 2018 | China | All | 66 | 28/38 | 66.0 | R | PET/CT | HP | NA | NA | 81.8% | NA | NA | NA | NA | NA |
| Lee | 2017 | Korea | intrahepatic | 76 | 19/57 | 68 | R | CI vs. PET/CT | HP | NA | NA | 74.5% | 90.0% | 76.9% | NA (higher than CI) | ||
| Jiang | 2016 | China | intrahepatic | 65 | NA | 69.2 | NA | MRI vs. PET/CT | HP | NA | NA | 70.0% | 91.7% | 81.8% | NA | NA | NA |
| Adachi | 2015 | Japan | intrahepatic | 47 | NA | 71 | R | PET/CT | HP | NA | NA | 31.2% | 96.1% | NA | NA | NA | NA |
| Choi | 2013 | Korea | extrahepatic | 34 | NA | NA | R | PET/CT | HP | 88.2% | 100.0% | 89.7% | NA | NA | NA | NA | NA |
| Ruys | 2011 | Netherlands | hilar | 30 | 16/14 | 62 | R | PET/CT | HP | 88.0% | NA | 67.0% | 68.0% | NA | 33.0% | 96.0% | NA |
| Seo | 2008 | Japan | intrahepatic | 35 | NA | NA | R | CI vs. PET/CT | HP | NA | NA | 43.0% | 100.0% | 86.0% | NA | NA | NA |
| Kim | 2008 | Korea | All | 123 | 43/80 | 60 | P | CI vs. PET/CT | HP | 84.0% | 79.3% | 32.0% | NA | 75.9% | 58.0% | NA | 88.3% |
| Li | 2008 | Germany | hilar | 17 | 6/11 | 62 | R | PET/CT | HP | 58.8% | NA | 41.7% | 80.0% | NA | 55.6% | 87.5% | NA |
| Petrowsky | 2006 | Switzerland | All | 61 | NA | NA | P | CT vs. PET/CT | HP | 55.0% | NA | 12.0% | NA | NA | 100.0% | NA | NA |
| Kim | 2003 | Korea | intrahepatic | 21 | 10/11 | 57 | R | CI vs. PET/CT | HP | NA | NA | NA (higher than CI) | NA (higher than CI) | ||||
| Kato | 2002 | Japan | extrahepatic | 30 | 9/21 | 68 | NA | CT vs. PET/CT | HP | NA | NA | 38.0% | 100.0% | 73.0% | NA | NA | NA |
| Kluge | 2001 | Germany | All | 46 | 21/25 | 63 | R | CI vs. PET/CT | HP | 92.3% | 92.9% | 13.0% | NA | NA | 70.0% | NA | NA |
HP = histopathology, NA = not available, No. = number, P = prospective, R = retrospective, All = intrahepatic, hilar, gallbladder and common bile duct, CI = conventional imaging, Sens. = sensitivity, Spec. = specificity, Acc. = accuracy.
