Batteries, Volume 7, Issue 4 (December 2021) – 25 articles

Cover Story (view full-size image): Short circuits in lithium-ion batteries, caused by the mechanical loading conditions during a car crash, are currently a major topic in electric vehicle safety. The publication shows the creation of a finite element model of a cylindrical lithium-ion battery using state-of-the-art testing and simulation techniques. For the virtual short circuit prediction, a variety of short-circuit criteria based on stresses, strains, and geometric parameters are tested. Finally, it is shown that a combination of two geometric criteria is best suited for virtual short-circuit detection in the presented simulation case. The simulation model is built using a macroscopic approach, shortening simulation time and making it applicable for use in full vehicle simulations. View this paper.
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
21 pages, 4042 KiB
Article
The Battery Life Estimation of a Battery under Different Stress Conditions
by Natascia Andrenacci, Francesco Vellucci and Vincenzo Sglavo
Batteries 2021, 7(4), 88; https://doi.org/10.3390/batteries7040088 - 18 Dec 2021
Cited by 9 | Viewed by 6608
Abstract
The prediction of capacity degradation, and more generally of the behaviors related to battery aging, is useful in the design and use phases of a battery to help improve the efficiency and reliability of energy systems. In this paper, a stochastic model for [...] Read more.
The prediction of capacity degradation, and more generally of the behaviors related to battery aging, is useful in the design and use phases of a battery to help improve the efficiency and reliability of energy systems. In this paper, a stochastic model for the prediction of battery cell degradation is presented. The proposed model takes its cue from an approach based on Markov chains, although it is not comparable to a Markov process, as the transition probabilities vary with the number of cycles that the cell has performed. The proposed model can reproduce the abrupt decrease in the capacity that occurs near the end of life condition (80% of the nominal value of the capacity) for the cells analyzed. Furthermore, we illustrate the ability of this model to predict the capacity trend for a lithium-ion cell with nickel manganese cobalt (NMC) at the cathode and graphite at the anode, subjected to a life cycle in which there are different aging factors, using the results obtained for cells subjected to single aging factors. Full article
(This article belongs to the Special Issue Lithium-Ion Batteries Aging Mechanisms, 2nd Edition)
Show Figures

Figure 1

12 pages, 2032 KiB
Article
Temperature-Induced Precipitation of V2O5 in Vanadium Flow Batteries—Revisited
by Emil Holm Kirk, Filippo Fenini, Sara Noriega Oreiro and Anders Bentien
Batteries 2021, 7(4), 87; https://doi.org/10.3390/batteries7040087 - 17 Dec 2021
Cited by 8 | Viewed by 3981
Abstract
The maximum operation temperature of the vanadium solution in vanadium flow batteries is typically limited to 40 °C to prevent the damaging thermal precipitation of V2O5. Therefore, the operation of batteries at high ambient temperatures is an important aspect [...] Read more.
The maximum operation temperature of the vanadium solution in vanadium flow batteries is typically limited to 40 °C to prevent the damaging thermal precipitation of V2O5. Therefore, the operation of batteries at high ambient temperatures is an important aspect to tackle for stationary storage. In the present work, a comprehensive study of the high temperature stability of redox solutions for vanadium flow batteries was performed. In particular, focus was placed on a comparison between batch and in operando precipitation experiments. It was found that, despite being a widely used method in the literature, caution should be taken when assessing the precipitation through capacity fade due to the large influence of external oxidation and cycling parameters, plausibly leading to an incorrect interpretation of the results. The in operando experiments consistently show a precipitation temperature almost 10–20 °C higher than in the batch tests at a 100% state of charge for the same time lapse. Full article
Show Figures

Figure 1

20 pages, 3172 KiB
Article
Lithium-Ion Battery Thermal Management Systems: A Survey and New CFD Results
by Morena Falcone, Eleonora Palka Bayard De Volo, Ali Hellany, Claudio Rossi and Beatrice Pulvirenti
Batteries 2021, 7(4), 86; https://doi.org/10.3390/batteries7040086 - 14 Dec 2021
Cited by 14 | Viewed by 8629
Abstract
The environment has gained significant importance in recent years, and companies involved in several technology fields are moving in the direction of eco-friendly solutions. One of the most discussed topics in the automotive field is lithium-ion battery packs for electric vehicles and their [...] Read more.
The environment has gained significant importance in recent years, and companies involved in several technology fields are moving in the direction of eco-friendly solutions. One of the most discussed topics in the automotive field is lithium-ion battery packs for electric vehicles and their battery thermal management systems (BTMSs). This work aims to show the most used lithium-ion battery pack cooling methods and technologies with best working temperature ranges together with the best performances. Different cooling methods are presented and discussed, with a focus on the comparison between air-cooling systems and liquid-cooling systems. In this context, a BTMS for cylindrical cells is presented, where the cells are arranged in staggered lines embedded in a solid structure and cooled through forced convection within channels. The thermal behavior of this BTMS is simulated by employing a computational fluid dynamics (CFD) approach. The effect of the geometry of the BTMS on the cell temperature distribution is obtained. It is shown that the use of materials with additives for the solid structure enhances the performance of the system, giving lower temperatures to the cells. The system is tested with air-cooling and water-cooling, showing that the best performances are obtained with water-cooling in terms of cell packing density and lowest cell temperatures. Full article
(This article belongs to the Special Issue Battery Systems and Energy Storage beyond 2020)
Show Figures

Graphical abstract

15 pages, 1708 KiB
Article
Impedance Based Temperature Estimation of Lithium Ion Cells Using Artificial Neural Networks
by Marco Ströbel, Julia Pross-Brakhage, Mike Kopp and Kai Peter Birke
Batteries 2021, 7(4), 85; https://doi.org/10.3390/batteries7040085 - 12 Dec 2021
Cited by 18 | Viewed by 5493
Abstract
Tracking the cell temperature is critical for battery safety and cell durability. It is not feasible to equip every cell with a temperature sensor in large battery systems such as those in electric vehicles. Apart from this, temperature sensors are usually mounted on [...] Read more.
Tracking the cell temperature is critical for battery safety and cell durability. It is not feasible to equip every cell with a temperature sensor in large battery systems such as those in electric vehicles. Apart from this, temperature sensors are usually mounted on the cell surface and do not detect the core temperature, which can mean detecting an offset due to the temperature gradient. Many sensorless methods require great computational effort for solving partial differential equations or require error-prone parameterization. This paper presents a sensorless temperature estimation method for lithium ion cells using data from electrochemical impedance spectroscopy in combination with artificial neural networks (ANNs). By training an ANN with data of 28 cells and estimating the cell temperatures of eight more cells of the same cell type, the neural network (a simple feed forward ANN with only one hidden layer) was able to achieve an estimation accuracy of ΔT= 1 K (10 C <T< 60 C) with low computational effort. The temperature estimations were investigated for different cell types at various states of charge (SoCs) with different superimposed direct currents. Our method is easy to use and can be completely automated, since there is no significant offset in monitoring temperature. In addition, the prospect of using the above mentioned approach to estimate additional battery states such as SoC and state of health (SoH) is discussed. Full article
(This article belongs to the Special Issue Battery Systems and Energy Storage beyond 2020)
Show Figures

Figure 1

16 pages, 3270 KiB
Review
Recent Development of Nickel-Rich and Cobalt-Free Cathode Materials for Lithium-Ion Batteries
by Lukman Noerochim, Suwarno Suwarno, Nurul Hayati Idris and Hermawan K. Dipojono
Batteries 2021, 7(4), 84; https://doi.org/10.3390/batteries7040084 - 10 Dec 2021
Cited by 33 | Viewed by 9396
Abstract
The exponential growth in the production of electric vehicles requires an increasing supply of low-cost, high-performance lithium-ion batteries. The increased production of lithium-ion batteries raises concerns over the availability of raw materials, especially cobalt for batteries with nickel-rich cathodes, in which these constraints [...] Read more.
The exponential growth in the production of electric vehicles requires an increasing supply of low-cost, high-performance lithium-ion batteries. The increased production of lithium-ion batteries raises concerns over the availability of raw materials, especially cobalt for batteries with nickel-rich cathodes, in which these constraints can impact the high price of cobalt. The reliance on cobalt in these cathodes is worrisome because it is a high-cost, rare material, with an unstable supply chain. This review describes the need and feasibility of developing cobalt-free high-nickel cathode materials for lithium-ion batteries. The new type of cathode material, LiNi1−x−yMnxAlyO2 promises a completely cobalt-free composition with almost the same electrochemical performance as that of the conventional high-nickel cathode. Therefore, this new type of cathode needs further research for its commercial applications. Full article
Show Figures

Figure 1

16 pages, 4568 KiB
Article
Copper Chloro-Complexes Concentrated Solutions: An Electrochemical Study
by Giampaolo Lacarbonara, Luigi Faggiano, Stefania Porcu, Pier Carlo Ricci, Stefania Rapino, Declan P. Casey, James F. Rohan and Catia Arbizzani
Batteries 2021, 7(4), 83; https://doi.org/10.3390/batteries7040083 - 3 Dec 2021
Cited by 6 | Viewed by 3754
Abstract
Basic studies on concentrated solutions are becoming more and more important due to the practical industrial and geological applications. The use in redox flow batteries is one of the most important applications of these solutions. Specifically, in this paper we investigated high-concentrated copper [...] Read more.
Basic studies on concentrated solutions are becoming more and more important due to the practical industrial and geological applications. The use in redox flow batteries is one of the most important applications of these solutions. Specifically, in this paper we investigated high-concentrated copper chloro-complexes solutions with different additives. The concentration of ligands and additives affects the physicochemical and electrochemical properties of 2 M solutions of Cu(I) and Cu(II). Solutions with calcium chloride and HCl as Cl source were investigated with Cu:Cl ratios of 1:5 and 1:7, the 1:5 Cu:Cl ratio being the best performing. The substitution of calcium chloride with ammonium chloride increased the conductivity. However, while the effect on the positive electrode process was not very evident, the reversibility of the copper deposition–stripping process was greatly improved. Orthophosphoric acid could be a viable additive to decrease the complexation of calcium with chloride anions and to improve the stability of Cu(II) chloro-complexes. Absorption spectroscopy demonstrated that phosphate ions do not coordinate copper(II) but lead to a shift in the distribution of copper chloro-complexes toward more coordinated species. Electrochemically, the increased availability of chloride anions in solution stabilized the Cu(II)-rich solution and led to increased reversibility of the Cu(II)/Cu(I) redox process. Full article
Show Figures

Figure 1

24 pages, 2785 KiB
Review
A Perspective on Li/S Battery Design: Modeling and Development Approaches
by Chase McCreary, Yuhui An, Sun Ung Kim and Yoon Hwa
Batteries 2021, 7(4), 82; https://doi.org/10.3390/batteries7040082 - 2 Dec 2021
Cited by 10 | Viewed by 5474
Abstract
Lithium/sulfur (Li/S) cells that offer an ultrahigh theoretical specific energy of 2600 Wh/kg are considered one of the most promising next-generation rechargeable battery systems for the electrification of transportation. However, the commercialization of Li/S cells remains challenging, despite the recent advancements in materials [...] Read more.
Lithium/sulfur (Li/S) cells that offer an ultrahigh theoretical specific energy of 2600 Wh/kg are considered one of the most promising next-generation rechargeable battery systems for the electrification of transportation. However, the commercialization of Li/S cells remains challenging, despite the recent advancements in materials development for sulfur electrodes and electrolytes, due to several critical issues such as the insufficient obtainable specific energy and relatively poor cyclability. This review aims to introduce electrode manufacturing and modeling methodologies and the current issues to be overcome. The obtainable specific energy values of Li/S pouch cells are calculated with respect to various parameters (e.g., sulfur mass loading, sulfur content, sulfur utilization, electrolyte-volume-to-sulfur-weight ratio, and electrode porosity) to demonstrate the design requirements for achieving a high specific energy of >300 Wh/kg. Finally, the prospects for rational modeling and manufacturing strategies are discussed, to establish a new design standard for Li/S batteries. Full article
(This article belongs to the Special Issue Rechargeable Lithium-Sulfur Battery: Present and Future)
Show Figures

Figure 1

12 pages, 3638 KiB
Article
Effects of State-of-Charge and Penetration Location on Variations in Temperature and Terminal Voltage of a Lithium-Ion Battery Cell during Penetration Tests
by Yiqun Liu, Yitian Li, Y. Gene Liao and Ming-Chia Lai
Batteries 2021, 7(4), 81; https://doi.org/10.3390/batteries7040081 - 1 Dec 2021
Cited by 9 | Viewed by 5028
Abstract
The nail penetration test has been widely adopted as a battery safety test for reproducing internal short-circuits. In this paper, the effects of cell initial State-of-Charge (SOC) and penetration location on variations in cell temperature and terminal voltage during penetration tests are investigated. [...] Read more.
The nail penetration test has been widely adopted as a battery safety test for reproducing internal short-circuits. In this paper, the effects of cell initial State-of-Charge (SOC) and penetration location on variations in cell temperature and terminal voltage during penetration tests are investigated. Three different initial SOCs (10%, 50%, and 90%) and three different penetration locations (one is at the center of the cell, the other two are close to the edge of the cell) are used in the tests. Once the steel cone starts to penetrate the cell, the cell terminal voltage starts to drop due to the internal short-circuit. The penetration tests with higher initial cell SOCs have larger cell surface temperature increases during the tests. Also, the penetration location always has the highest temperature increment during all penetration tests, which means the heat source is always at the penetration location. The absolute temperature increment at the penetration location is always higher when the penetration is close to the edge of the cell, compared to when the penetration is at the center of the cell. The heat generated at the edges of the cell is more difficult to dissipate. Additionally, a battery cell internal short-circuit model with different penetration locations is built in ANSYS Fluent, based on the specifications and experimental data of the tested battery cells. The model is validated with an acceptable discrepancy range by using the experimental data. Simulated data shows that the temperature gradually reduces from penetration locations to their surroundings. The gradients of the temperature distributions are much larger closer to the penetration locations. Overall, this paper provides detailed information on the temperature and terminal voltage variations of a lithium-ion polymer battery cell with large capacity and high power under penetration tests. The presented information can be used for assessing the safety of the onboard battery pack of electric vehicles. Full article
Show Figures

Figure 1

22 pages, 5188 KiB
Review
The Emerging Electric Vehicle and Battery Industry in Indonesia: Actions around the Nickel Ore Export Ban and a SWOT Analysis
by Andante Hadi Pandyaswargo, Alan Dwi Wibowo, Meilinda Fitriani Nur Maghfiroh, Arlavinda Rezqita and Hiroshi Onoda
Batteries 2021, 7(4), 80; https://doi.org/10.3390/batteries7040080 - 24 Nov 2021
Cited by 32 | Viewed by 20970
Abstract
As the automotive industry shifts from internal combustion engine (ICE) vehicles to electric vehicles (EVs), many countries are setting new strategies in their transportation sector. The Li-ion battery is currently the most common battery used in EVs due to its high energy density, [...] Read more.
As the automotive industry shifts from internal combustion engine (ICE) vehicles to electric vehicles (EVs), many countries are setting new strategies in their transportation sector. The Li-ion battery is currently the most common battery used in EVs due to its high energy density, durability, safety, and cost competitiveness. Nickel is predicted to be an essential component for the lithium nickel cobalt manganese oxide (NMC) as a cathode material of choice for EV applications. Indonesia, one of the world’s largest nickel ore suppliers, put an export ban on nickel ore effective from 2020. The bold movement was intended to initiate the domestic EV industry and encourage investors abroad to drive their manufacturing activities into the country. On the other hand, the global Li-ion battery manufacturers who imported nickel from Indonesia had to restrategize their businesses. This review discussed the chronological events leading to the ban and after the ban from the media, government regulations, and literature reviews. The authors of this study also conducted interviews and attended seminars with the national experts and key players in the battery and EV industry to gain their most pertinent insights. The SWOT analysis of the reviewed materials indicated that while the Indonesian battery industry is still new, it needs to diversify its research and development activities and collaborate internationally to optimize the utilization of its resources and meet the purchasing power of the domestic EV market. Finally, this study summarized six key factors to support Indonesia’s ambition to be a new regional hub for EVs. These factors are: (1) pricing, (2) technology, (3) policy, (4) investment, (5) infrastructure, and (6) compliance with sustainability standards. Full article
(This article belongs to the Special Issue Batteries: Feature Papers 2021)
Show Figures

Graphical abstract

26 pages, 21772 KiB
Article
Virtual Detection of Mechanically Induced Short Circuits in a Cylindrical Lithium-Ion Battery Cell Based on Finite Element Simulation
by Klemens Jantscher, Christoph Breitfuß, Martin Miklau, Khaled Ismail and Peter Dobusch
Batteries 2021, 7(4), 79; https://doi.org/10.3390/batteries7040079 - 17 Nov 2021
Cited by 4 | Viewed by 5452
Abstract
Lithium-ion batteries (LIBs) are commonly used in today’s electric vehicles. Studying their behaviour under mechanical loading, including short circuits, is vital for vehicle safety. This paper covers three major topics, (1) a general literature review for the state-of-the-art of LIBs, (2) physical cell [...] Read more.
Lithium-ion batteries (LIBs) are commonly used in today’s electric vehicles. Studying their behaviour under mechanical loading, including short circuits, is vital for vehicle safety. This paper covers three major topics, (1) a general literature review for the state-of-the-art of LIBs, (2) physical cell tests for model validation are performed, wherein the occurrence of short circuits is detected and (3) creating a finite element model (FEM) of an 18650 cylindrical LIB using the most recent testing and simulation techniques. A variety of short-circuit criteria based on stresses, strains and geometric parameters have been implemented in the simulation and compared to the test results. It will be demonstrated that a combination of two geometric criteria, in the radial and axial directions of the cell, is best suited for virtual short-circuit detection in the simulation. Finally, the short-circuit criteria are implemented in a post-processing tool that allows fast short-circuit analysis of cells of different loadings. In the future, this method of short-circuit detection will be used to analyse an assembly of several battery cells such as, for instance, an automotive or maritime battery pack. Furthermore, the developed method enables mechanical integration with respect to crash safety in vehicles. Full article
Show Figures

Figure 1

21 pages, 13403 KiB
Article
Implementation of Battery Digital Twin: Approach, Functionalities and Benefits
by Soumya Singh, Max Weeber and Kai Peter Birke
Batteries 2021, 7(4), 78; https://doi.org/10.3390/batteries7040078 - 16 Nov 2021
Cited by 39 | Viewed by 10621
Abstract
The concept of Digital Twin (DT) is widely explored in literature for different application fields because it promises to reduce design time, enable design and operation optimization, improve after-sales services and reduce overall expenses. While the perceived benefits strongly encourage the use of [...] Read more.
The concept of Digital Twin (DT) is widely explored in literature for different application fields because it promises to reduce design time, enable design and operation optimization, improve after-sales services and reduce overall expenses. While the perceived benefits strongly encourage the use of DT, in the battery industry a consistent implementation approach and quantitative assessment of adapting a battery DT is missing. This paper is a part of an ongoing study that investigates the DT functionalities and quantifies the DT-attributes across the life cycles phases of a battery system. The critical question is whether battery DT is a practical and realistic solution to meeting the growing challenges of the battery industry, such as degradation evaluation, usage optimization, manufacturing inconsistencies or second-life application possibility. Within the scope of this paper, a consistent approach of DT implementation for battery cells is presented, and the main functions of the approach are tested on a Doyle-Fuller-Newman model. In essence, a battery DT can offer improved representation, performance estimation, and behavioral predictions based on real-world data along with the integration of battery life cycle attributes. Hence, this paper identifies the efforts for implementing a battery DT and provides the quantification attribute for future academic or industrial research. Full article
(This article belongs to the Special Issue Battery Systems and Energy Storage beyond 2020)
Show Figures

Figure 1

15 pages, 3486 KiB
Article
Preparation of Composite Electrodes for All-Solid-State Batteries Based on Sulfide Electrolytes: An Electrochemical Point of View
by Sara Giraldo, Koki Nakagawa, Ferley A. Vásquez, Yuta Fujii, Yongming Wang, Akira Miura, Jorge A. Calderón, Nataly C. Rosero-Navarro and Kiyoharu Tadanaga
Batteries 2021, 7(4), 77; https://doi.org/10.3390/batteries7040077 - 11 Nov 2021
Cited by 10 | Viewed by 7308
Abstract
All-solid-state batteries (ASSBs) are a promising response to the need for safety and high energy density of large-scale energy storage systems in challenging applications such as electric vehicles and grid integration. ASSBs based on sulfide solid electrolytes (SEs) have attracted much attention because [...] Read more.
All-solid-state batteries (ASSBs) are a promising response to the need for safety and high energy density of large-scale energy storage systems in challenging applications such as electric vehicles and grid integration. ASSBs based on sulfide solid electrolytes (SEs) have attracted much attention because of their high ionic conductivity and wide electrochemical windows of the sulfide SEs. Here, we study the electrochemical performance of ASSBs using composite electrodes prepared via two processes (simple mixture and solution processes) and varying the ionic conductor additive (80Li2S∙20P2S5 and argyrodite-type Li6PS5Cl). The composite electrodes consist of lithium-silicate-coated LiNi1/3Mn1/3Co1/3O2 (NMC), a sulfide SE, and carbon additives. The charge-transfer resistance at the interface of the solid electrolyte and NMC is the main parameter related to the ASSB’s status. This value decreases when the composite electrodes are prepared via a solution process. The lithium silicate coating and the use of a high-Li-ion additive conductor are also important to reduce the interfacial resistance and achieve high initial capacities (140 mAh g−1). Full article
(This article belongs to the Special Issue Ionic Transportation Bases in All-Solid-State Batteries)
Show Figures

Figure 1

18 pages, 3352 KiB
Article
A Method for Monitoring State-of-Charge of Lithium-Ion Cells Using Multi-Sine Signal Excitation
by Jonghyeon Kim and Julia Kowal
Batteries 2021, 7(4), 76; https://doi.org/10.3390/batteries7040076 - 9 Nov 2021
Cited by 13 | Viewed by 5128
Abstract
In this paper, a method for monitoring SoC of a lithium-ion battery cell through continuous impedance measurement during cell operation is introduced. A multi-sine signal is applied to the cell operating current, and the cell SoH and SoC can be simultaneously monitored via [...] Read more.
In this paper, a method for monitoring SoC of a lithium-ion battery cell through continuous impedance measurement during cell operation is introduced. A multi-sine signal is applied to the cell operating current, and the cell SoH and SoC can be simultaneously monitored via impedance at each frequency. Unlike existing studies in which cell impedance measurement is performed ex situ through EIS equipment, cell state estimation is performed in situ. The measured impedance takes into account cell temperature and cell SoH, enabling accurate SoC estimation. The measurement system configured for the experiment and considerations for the selection of measurement parameters are described, and the accuracy of cell SoC estimation is presented. Full article
(This article belongs to the Special Issue Battery Systems and Energy Storage beyond 2020)
Show Figures

Figure 1

20 pages, 5748 KiB
Review
Perovskite Solid-State Electrolytes for Lithium Metal Batteries
by Shuo Yan, Chae-Ho Yim, Vladimir Pankov, Mackenzie Bauer, Elena Baranova, Arnaud Weck, Ali Merati and Yaser Abu-Lebdeh
Batteries 2021, 7(4), 75; https://doi.org/10.3390/batteries7040075 - 7 Nov 2021
Cited by 30 | Viewed by 12232
Abstract
Solid-state lithium metal batteries (LMBs) have become increasingly important in recent years due to their potential to offer higher energy density and enhanced safety compared to conventional liquid electrolyte-based lithium-ion batteries (LIBs). However, they require highly functional solid-state electrolytes (SSEs) and, therefore, many [...] Read more.
Solid-state lithium metal batteries (LMBs) have become increasingly important in recent years due to their potential to offer higher energy density and enhanced safety compared to conventional liquid electrolyte-based lithium-ion batteries (LIBs). However, they require highly functional solid-state electrolytes (SSEs) and, therefore, many inorganic materials such as oxides of perovskite La2/3−xLi3xTiO3 (LLTO) and garnets La3Li7Zr2O12 (LLZO), sulfides Li10GeP2S12 (LGPS), and phosphates Li1+xAlxTi2−x(PO4)3x (LATP) are under investigation. Among these oxide materials, LLTO exhibits superior safety, wider electrochemical window (8 V vs. Li/Li+), and higher bulk conductivity values reaching in excess of 10−3 S cm−1 at ambient temperature, which is close to organic liquid-state electrolytes presently used in LIBs. However, recent studies focus primarily on composite or hybrid electrolytes that mix LLTO with organic polymeric materials. There are scarce studies of pure (100%) LLTO electrolytes in solid-state LMBs and there is a need to shed more light on this type of electrolyte and its potential for LMBs. Therefore, in our review, we first elaborated on the structure/property relationship between compositions of perovskites and their ionic conductivities. We then summarized current issues and some successful attempts for the fabrication of pure LLTO electrolytes. Their electrochemical and battery performances were also presented. We focused on tape casting as an effective method to prepare pure LLTO thin films that are compatible and can be easily integrated into existing roll-to-roll battery manufacturing processes. This review intends to shed some light on the design and manufacturing of LLTO for all-ceramic electrolytes towards safer and higher power density solid-state LMBs. Full article
(This article belongs to the Special Issue Solid State Batteries)
Show Figures

Figure 1

24 pages, 1944 KiB
Article
Optimization of Disassembly Strategies for Electric Vehicle Batteries
by Sabri Baazouzi, Felix Paul Rist, Max Weeber and Kai Peter Birke
Batteries 2021, 7(4), 74; https://doi.org/10.3390/batteries7040074 - 7 Nov 2021
Cited by 27 | Viewed by 9442
Abstract
Various studies show that electrification, integrated into a circular economy, is crucial to reach sustainable mobility solutions. In this context, the circular use of electric vehicle batteries (EVBs) is particularly relevant because of the resource intensity during manufacturing. After reaching the end-of-life phase, [...] Read more.
Various studies show that electrification, integrated into a circular economy, is crucial to reach sustainable mobility solutions. In this context, the circular use of electric vehicle batteries (EVBs) is particularly relevant because of the resource intensity during manufacturing. After reaching the end-of-life phase, EVBs can be subjected to various circular economy strategies, all of which require the previous disassembly. Today, disassembly is carried out manually and represents a bottleneck process. At the same time, extremely high return volumes have been forecast for the next few years, and manual disassembly is associated with safety risks. That is why automated disassembly is identified as being a key enabler of highly efficient circularity. However, several challenges need to be addressed to ensure secure, economic, and ecological disassembly processes. One of these is ensuring that optimal disassembly strategies are determined, considering the uncertainties during disassembly. This paper introduces our design for an adaptive disassembly planner with an integrated disassembly strategy optimizer. Furthermore, we present our optimization method for obtaining optimal disassembly strategies as a combination of three decisions: (1) the optimal disassembly sequence, (2) the optimal disassembly depth, and (3) the optimal circular economy strategy at the component level. Finally, we apply the proposed method to derive optimal disassembly strategies for one selected battery system for two condition scenarios. The results show that the optimization of disassembly strategies must also be used as a tool in the design phase of battery systems to boost the disassembly automation and thus contribute to achieving profitable circular economy solutions for EVBs. Full article
(This article belongs to the Special Issue Battery Systems and Energy Storage beyond 2020)
Show Figures

Figure 1

14 pages, 4087 KiB
Article
Understanding Solid Electrolyte Interphase Nucleation and Growth on Lithium Metal Surfaces
by Stefany Angarita-Gomez and Perla B. Balbuena
Batteries 2021, 7(4), 73; https://doi.org/10.3390/batteries7040073 - 2 Nov 2021
Cited by 3 | Viewed by 4279
Abstract
Experiments and theory are needed to decode the exact structure and distribution of components of a passivation layer formed at the anode surface of Li metal batteries, known as the Solid Electrolyte Interphase (SEI). Due to the inherent dynamic behavior as well as [...] Read more.
Experiments and theory are needed to decode the exact structure and distribution of components of a passivation layer formed at the anode surface of Li metal batteries, known as the Solid Electrolyte Interphase (SEI). Due to the inherent dynamic behavior as well as the lithium reactivity, the SEI structure and its growth mechanisms are still unclear. This study uses molecular simulation and computational chemistry tools to investigate the initial nucleation and growth dynamics of LiOH and Li2O that provide us with thermodynamics and structural information about the nucleating clusters of each species. Following the most favorable pathways for the addition of each of the components to a given nascent SEI cluster reveals their preferential nucleation mechanisms and illustrates different degrees of crystallinity and electron density distribution that are useful to understand ionic transport through SEI blocks. Full article
(This article belongs to the Special Issue Rechargeable Lithium-Sulfur Battery: Present and Future)
Show Figures

Figure 1

10 pages, 2111 KiB
Article
Investigation of a Novel Ecofriendly Electrolyte-Solvent for Lithium-Ion Batteries with Increased Thermal Stability
by Marco Ströbel, Larissa Kiefer and Kai Peter Birke
Batteries 2021, 7(4), 72; https://doi.org/10.3390/batteries7040072 - 28 Oct 2021
Cited by 2 | Viewed by 3394
Abstract
This study presents tributyl acetylcitrate (TBAC) as a novel ecofriendly high flash point and high boiling point solvent for electrolytes in lithium-ion batteries. The flash point (TFP=217C) and the boiling point (TBP=331 [...] Read more.
This study presents tributyl acetylcitrate (TBAC) as a novel ecofriendly high flash point and high boiling point solvent for electrolytes in lithium-ion batteries. The flash point (TFP=217C) and the boiling point (TBP=331C) of TBAC are approximately 200 K greater than that of conventional linear carbonate components, such as ethyl methyl carbonate (EMC) or diethyl carbonate (DEC). The melting point (TMP=80C) is more than 100 K lower than that of ethylene carbonate (EC). Furthermore, TBAC is known as an ecofriendly solvent from other industrial sectors. A life cycle test of a graphite/NCM cell with 1 M lithium hexafluorophosphate (LiPF6) in TBAC:EC:EMC:DEC (60:15:5:20 wt) achieved a coulombic efficiency of above 99% and the remaining capacity resulted in 90 percent after 100 cycles (C/4) of testing. As a result, TBAC is considered a viable option for improving the thermal stability of lithium-ion batteries. Full article
(This article belongs to the Special Issue Battery Systems and Energy Storage beyond 2020)
Show Figures

Graphical abstract

11 pages, 8890 KiB
Article
Evaluation of Computational Chemistry Methods for Predicting Redox Potentials of Quinone-Based Cathodes for Li-Ion Batteries
by Xuan Zhou, Abhishek Khetan and Süleyman Er
Batteries 2021, 7(4), 71; https://doi.org/10.3390/batteries7040071 - 28 Oct 2021
Cited by 9 | Viewed by 5050
Abstract
High-throughput computational screening (HTCS) is an effective tool to accelerate the discovery of active materials for Li-ion batteries. For the evaluation of organic cathode materials, the effectiveness of HTCS depends on the accuracy of the employed chemical descriptors and their computing cost. This [...] Read more.
High-throughput computational screening (HTCS) is an effective tool to accelerate the discovery of active materials for Li-ion batteries. For the evaluation of organic cathode materials, the effectiveness of HTCS depends on the accuracy of the employed chemical descriptors and their computing cost. This work was focused on evaluating the performance of computational chemistry methods, including semi-empirical quantum mechanics (SEQM), density-functional tight-binding (DFTB), and density functional theory (DFT), for the prediction of the redox potentials of quinone-based cathode materials for Li-ion batteries. In addition, we evaluated the accuracy of three energy-related descriptors: (1) the redox reaction energy, (2) the lowest unoccupied molecular orbital (LUMO) energy of reactant molecules, and (3) the highest occupied molecular orbital (HOMO) energy of lithiated product molecules. Among them, the LUMO energy of the reactant compounds, regardless of the level of theory used for its calculation, showed the best performance as a descriptor for the prediction of experimental redox potentials. This finding contrasts with our earlier results on the calculation of quinone redox potentials in aqueous media for redox flow batteries, for which the redox reaction energy was the best descriptor. Furthermore, the combination of geometry optimization using low-level methods (e.g., SEQM or DFTB) followed by energy calculation with DFT yielded accuracy as good as the full optimization of geometry using the DFT calculations. Thus, the proposed calculation scheme is useful for both the optimum use of computational resources and the systematic generation of robust calculation data on quinone-based cathode compounds for the training of data-driven material discovery models. Full article
(This article belongs to the Special Issue Development and Characterization of Lithium Battery Materials)
Show Figures

Graphical abstract

24 pages, 9128 KiB
Article
Comprehensive Insights into the Porosity of Lithium-Ion Battery Electrodes: A Comparative Study on Positive Electrodes Based on LiNi0.6Mn0.2Co0.2O2 (NMC622)
by Thomas Beuse, Mathias Fingerle, Christian Wagner, Martin Winter and Markus Börner
Batteries 2021, 7(4), 70; https://doi.org/10.3390/batteries7040070 - 26 Oct 2021
Cited by 22 | Viewed by 15415
Abstract
Porosity is frequently specified as only a value to describe the microstructure of a battery electrode. However, porosity is a key parameter for the battery electrode performance and mechanical properties such as adhesion and structural electrode integrity during charge/discharge cycling. This study illustrates [...] Read more.
Porosity is frequently specified as only a value to describe the microstructure of a battery electrode. However, porosity is a key parameter for the battery electrode performance and mechanical properties such as adhesion and structural electrode integrity during charge/discharge cycling. This study illustrates the importance of using more than one method to describe the electrode microstructure of LiNi0.6Mn0.2Co0.2O2 (NMC622)-based positive electrodes. A correlative approach, from simple thickness measurements to tomography and segmentation, allowed deciphering the true porous electrode structure and to comprehend the advantages and inaccuracies of each of the analytical techniques. Herein, positive electrodes were calendered from a porosity of 44–18% to cover a wide range of electrode microstructures in state-of-the-art lithium-ion batteries. Especially highly densified electrodes cannot simply be described by a close packing of active and inactive material components, since a considerable amount of active material particles crack due to the intense calendering process. Therefore, a digital 3D model was created based on tomography data and simulation of the inactive material, which allowed the investigation of the complete pore network. For lithium-ion batteries, the results of the mercury intrusion experiments in combination with gas physisorption/pycnometry experiments provide comprehensive insight into the microstructure of positive electrodes. Full article
Show Figures

Figure 1

19 pages, 3898 KiB
Article
High-Performance Amorphous Carbon Coated LiNi0.6Mn0.2Co0.2O2 Cathode Material with Improved Capacity Retention for Lithium-Ion Batteries
by Anish Raj Kathribail, Arlavinda Rezqita, Daniel Lager, Raad Hamid, Yuri Surace, Maitane Berecibar, Joeri Van Mierlo, Annick Hubin, Marcus Jahn and Jürgen Kahr
Batteries 2021, 7(4), 69; https://doi.org/10.3390/batteries7040069 - 26 Oct 2021
Cited by 9 | Viewed by 4709
Abstract
Coating conducting polymers onto active cathode materials has been proven to mitigate issues at high current densities stemming from the limited conducting abilities of the metal-oxides. In the present study, a carbon coating was applied onto nickel-rich NMC622 via polymerisation of furfuryl alcohol, [...] Read more.
Coating conducting polymers onto active cathode materials has been proven to mitigate issues at high current densities stemming from the limited conducting abilities of the metal-oxides. In the present study, a carbon coating was applied onto nickel-rich NMC622 via polymerisation of furfuryl alcohol, followed by calcination, for the first time. The formation of a uniform amorphous carbon layer was observed with scanning- and transmission-electron microscopy (SEM and TEM) and X-ray photoelectron spectroscopy (XPS). The stability of the coated active material was confirmed and the electrochemical behaviour as well as the cycling stability was evaluated. The impact of the heat treatment on the electrochemical performance was studied systematically and was shown to improve cycling and high current performance alike. In-depth investigations of polymer coated samples show that the improved performance can be correlated with the calcination temperatures. In particular, a heat treatment at 400 °C leads to enhanced reversibility and capacity retention even after 400 cycles. At 10C, the discharge capacity for carbon coated NMC increases by nearly 50% compared to uncoated samples. This study clearly shows for the first time the synergetic effects of a furfuryl polymer coating and subsequent calcination leading to improved electrochemical performance of nickel-rich NMC622. Full article
Show Figures

Graphical abstract

18 pages, 1817 KiB
Article
Thermal Runaway Modelling of Li-Ion Cells at Various States of Ageing with a Semi-Empirical Model Based on a Kinetic Equation
by Mathilde Grandjacques, Pierre Kuntz, Philippe Azaïs, Sylvie Genies and Olivier Raccurt
Batteries 2021, 7(4), 68; https://doi.org/10.3390/batteries7040068 - 18 Oct 2021
Cited by 6 | Viewed by 3658
Abstract
The thermal runaway model used is a semi-empirical model based on a kinetic equation, parametrised by three parameters (m,n,p). It is believed that this kinetic equation can describe any reaction. The choice of parameters is often [...] Read more.
The thermal runaway model used is a semi-empirical model based on a kinetic equation, parametrised by three parameters (m,n,p). It is believed that this kinetic equation can describe any reaction. The choice of parameters is often made without justifications. We assumed it necessary to develop a method to select the parameters. The method proposed is based on data coming from an accelerating rate calorimeter (ARC) test. The method has been applied on data obtained for cells aged on different conditions. Thanks to a post-mortem analysis and simulations carried out using the parameters obtained, we have shown that the ageing mechanisms have a major impact on the parameters. Full article
(This article belongs to the Special Issue Battery Systems and Energy Storage beyond 2020)
Show Figures

Figure 1

15 pages, 1447 KiB
Article
Influence of Temperature and Electrolyte Composition on the Performance of Lithium Metal Anodes
by Sanaz Momeni Boroujeni, Alexander Fill, Alexander Ridder and Kai Peter Birke
Batteries 2021, 7(4), 67; https://doi.org/10.3390/batteries7040067 - 14 Oct 2021
Cited by 5 | Viewed by 4204
Abstract
Lithium metal anodes have again attracted widespread attention due to the continuously growing demand of cells with higher energy density. However, the lithium deposition mechanism and the affecting process of influencing factors, such as temperature, cycling current density, and electrolyte composition are not [...] Read more.
Lithium metal anodes have again attracted widespread attention due to the continuously growing demand of cells with higher energy density. However, the lithium deposition mechanism and the affecting process of influencing factors, such as temperature, cycling current density, and electrolyte composition are not fully understood and require further investigation. In this article, the behavior of lithium metal anode at different temperatures (25, 40, and 60 C), lithium salts, electrolyte concentrations (1 and 2 M), and the applied cell current (equivalent to 0.5 C, 1 C, and 2 C). is investigated. Two different salts were evaluated: lithium bis(fluorosulfonyl)imide (LiFSI) and lithium bis(trifluoromethanesul-fonyl)imide (LiTFSI). The cells at a medium temperature (40 C) show the highest Coulombic efficiency (CE). However, shorter cycle life is observed compared to the experiments at room temperature (25 C). Regardless of electrolyte type and C-rate, the higher temperature of 60 C provides the worst Coulombic efficiency and cycle life among those at the examined temperatures. A higher C-rate has a positive effect on the stability over the cycle life of the lithium cells. The best performance in terms of long cycle life and relatively good Coulombic efficiency is achieved by fast charging the cell with high concentration LiFSI in 1,2-dimethoxyethane (DME) electrolyte at a temperature of 25 C. The cell has an average Coulombic efficiency of 0.987 over 223 cycles. In addition to galvanostatic experiments, Electrochemical Impedance Spectroscopy (EIS) measurements were performed to study the evolution of the interface under different conditions during cycling. Full article
(This article belongs to the Special Issue Battery Systems and Energy Storage beyond 2020)
Show Figures

Figure 1

9 pages, 1336 KiB
Article
Attention-Based Long Short-Term Memory Recurrent Neural Network for Capacity Degradation of Lithium-Ion Batteries
by Tadele Mamo and Fu-Kwun Wang
Batteries 2021, 7(4), 66; https://doi.org/10.3390/batteries7040066 - 13 Oct 2021
Cited by 8 | Viewed by 3327
Abstract
Monitoring cycle life can provide a prediction of the remaining battery life. To improve the prediction accuracy of lithium-ion battery capacity degradation, we propose a hybrid long short-term memory recurrent neural network model with an attention mechanism. The hyper-parameters of the proposed model [...] Read more.
Monitoring cycle life can provide a prediction of the remaining battery life. To improve the prediction accuracy of lithium-ion battery capacity degradation, we propose a hybrid long short-term memory recurrent neural network model with an attention mechanism. The hyper-parameters of the proposed model are also optimized by a differential evolution algorithm. Using public battery datasets, the proposed model is compared to some published models, and it gives better prediction performance in terms of mean absolute percentage error and root mean square error. In addition, the proposed model can achieve higher prediction accuracy of battery end of life. Full article
(This article belongs to the Special Issue Circular Battery Technologies)
Show Figures

Figure 1

13 pages, 5456 KiB
Article
Effect of the Etching Profile of a Si Substrate on the Capacitive Characteristics of Three-Dimensional Solid-State Lithium-Ion Batteries
by Sergei Kurbatov, Alexander Mironenko, Victor Naumov, Alexander Skundin and Alexander Rudy
Batteries 2021, 7(4), 65; https://doi.org/10.3390/batteries7040065 - 28 Sep 2021
Viewed by 3074
Abstract
Along with the soaring demands for all-solid-state thin-film lithium-ion batteries, the problem of their energy density rise becomes very acute. The solution to this problem can be found in development of 3D batteries. The present work deals with the development of a technology [...] Read more.
Along with the soaring demands for all-solid-state thin-film lithium-ion batteries, the problem of their energy density rise becomes very acute. The solution to this problem can be found in development of 3D batteries. The present work deals with the development of a technology for a 3D solid-state lithium-ion battery (3D SSLIB) manufacturing by plasma-chemical etching and magnetron sputtering technique. The results on testing of experimental samples of 3D SSLIB are presented. It was found that submicron-scale steps appearing on the surface of a 3D structure formed on Si substrate by the Bosch process radically change the crystal structure of the upper functional layers. Such changes can lead to disruption of the layers’ continuity, especially that of the down conductors. It is shown that surface polishing by liquid etching of the SiO2 layer and silicon reoxidation leads to surface smoothing, the replacement of the dendrite structure of functional layers by a block structure, and a significant improvement in the capacitive characteristics of the battery. Full article
(This article belongs to the Special Issue Solid State Batteries)
Show Figures

Figure 1

12 pages, 2247 KiB
Article
High-Potential Test for Quality Control of Separator Defects in Battery Cell Production
by Louisa Hoffmann, Manuel Kasper, Maik Kahn, Georg Gramse, Gabriela Ventura Silva, Christoph Herrmann, Michael Kurrat and Ferry Kienberger
Batteries 2021, 7(4), 64; https://doi.org/10.3390/batteries7040064 - 24 Sep 2021
Cited by 14 | Viewed by 12169
Abstract
Lithium-ion batteries are a key technology for electromobility; thus, quality control in cell production is a central aspect for the success of electric vehicles. The detection of defects and poor insulation behavior of the separator is essential for high-quality batteries. Optical quality control [...] Read more.
Lithium-ion batteries are a key technology for electromobility; thus, quality control in cell production is a central aspect for the success of electric vehicles. The detection of defects and poor insulation behavior of the separator is essential for high-quality batteries. Optical quality control methods in cell production are unable to detect small but still relevant defects in the separator layer, e.g., pinholes or particle contaminations. This gap can be closed by executing high-potential testing to analyze the insulation performance of the electrically insulating separator layer in a pouch cell. Here, we present an experimental study to identify different separator defects on dry cell stacks on the basis of electric voltage stress and mechanical pressure. In addition, finite element modeling (FEM) is used to generate physical insights into the partial discharge by examining the defect structures and the corresponding electric fields, including topographical electrode roughness, impurity particles, and voids in the separator. The test results show that hard discharges are associated with significant separator defects. Based on the study, a voltage of 350 to 450 V and a pressure of 0.3 to 0.6 N/mm2 are identified as optimum ranges for the test methodology, resulting in failure detection rates of up to 85%. Full article
Show Figures

Figure 1

Previous Issue
Next Issue
Back to TopTop
