Editor’s Choice Articles

The hardware of networked embedded sensor nodes is in continuous evolution, from those 8-bit MCUs-based platforms such as Mica, up to powerful Edge nodes that even include custom hardware devices, such as FPGAs in the Cookies platform. This evolution process comes up with issues related to the deployment of the Internet of Things, particularly in terms of performance and communication bottlenecks. Moreover, the associated integration process from the Edge up to the Cloud layer opens new security concerns that are key to assure the end-to-end trustability and interoperability. This work tackles these questions by proposing a novel embedded Edge platform based on an EFR32 SoC from Silicon Labs with Contiki-NG OS that includes an ARM Cortex M4 MCU and an IEEE 802.15.4 transceiver, used for resource-constrained low-power communication capabilities. This IoT Edge node integrates security by hardware, adding support for confidentiality, integrity and availability, making this Edge node ultra-secure for most of the common attacks in wireless sensor networks. Part of this security relies on an energy-efficient hardware accelerator that handles identity authentication, session key creation and management. Furthermore, the modular hardware platform aims at providing reliability and robustness in low-power distributed sensing application contexts on what is called the Extreme Edge, and for that purpose a lightweight multi-hop routing strategy for supporting dynamic discovery and interaction among participant devices is fully presented. This embedded algorithm has served as the baseline end-to-end communication capability to validate the IoT hardware platform through intensive experimental tests in a real deployment scenario. Full article

The number of forest fires that occurred in recent years in different parts of the world is causing increased concern in the population, as the consequences of these fires expand beyond the destruction of the ecosystem. However, with the proliferation of the Internet of Things (IoT) industry, solutions for early fire detection should be developed. The assessment of the fire risk of an area and the communication of this fact to the population could reduce the number of fires originated by accident or due to the carelessness of the users. This paper presents a low-cost network based on Long Range (LoRa) technology to autonomously evaluate the level of fire risk and the presence of a forest fire in rural areas. The system is comprised of several LoRa nodes with sensors to measure the temperature, relative humidity, wind speed and CO₂ of the environment. The data from the nodes is stored and processed in a The Things Network (TTN) server that sends the data to a website for the graphic visualization of the collected data. The system is tested in a real environment and, the results show that it is possible to cover a circular area of a radius of 4 km with a single gateway. Full article

The significant increase of the Internet of Things (IoT) devices in smart homes and other smart infrastructure, and the recent attacks on these IoT devices, are motivating factors to secure and protect IoT networks. The primary security challenge to develop a methodology to identify a malicious activity correctly and mitigate the impact of such activity promptly. In this paper, we propose a two-level anomalous activity detection model for intrusion detection system in IoT networks. The level-1 model categorizes the network flow as normal flow or abnormal flow, while the level-2 model classifies the category or subcategory of detected malicious activity. When the network flow classified as an anomaly by the level-1 model, then the level-1 model forwards the stream to the level-2 model for further investigation to find the category or subcategory of the detected anomaly. Our proposed model constructed on flow-based features of the IoT network. Flow-based detection methodologies only inspect packet headers to classify the network traffic. Flow-based features extracted from the IoT Botnet dataset and various machine learning algorithms were investigated and tested via different cross-fold validation tests to select the best algorithm. The decision tree classifier yielded the highest predictive results for level-1, and the random forest classifier produced the highest predictive results for level-2. Our proposed model Accuracy, Precision, Recall, and F score for level-1 were measured as 99.99% and 99.90% for level-2. A two-level anomalous activity detection system for IoT networks we proposed will provide a robust framework for the development of malicious activity detection system for IoT networks. It would be of interest to researchers in academia and industry. Full article

Sol-gel-processed Mg-doped SnO₂ thin-film transistors (TFTs) were successfully fabricated. The effect of Mg concentration on the structural, chemical, and optical properties of thin films and the corresponding TFT devices was investigated. The results indicated that an optimal Mg concentration yielded an improved negative bias stability and increased optical band gap, resulting in transparent devices. Furthermore, the optimal device performance was obtained with 0.5 wt% Mg. The fabricated 0.5 wt% Mg-doped SnO₂ TFT was characterized by a field effect mobility, a subthreshold swing, and I_on/I_off ratio of 4.23 cm²/Vs, 1.37 V/decade, and ~1 × 10⁷, respectively. The added Mg suppressed oxygen-vacancy formation, thereby improving the bias stability. This work may pave the way for the development of alkaline-earth-metal-doped SnO₂-based thin-film devices. Full article

The Internet of Things (IoT) has gained significant recognition to become a novel sensing paradigm to interact with the physical world in this Industry 4.0 era. The IoTs are being used in many diverse applications that are part of our life and is growing to become the global digital nervous systems. It is quite evident that in the near future, hundreds of millions of individuals and businesses with billions will have smart-sensors and advanced communication technology, and these things will expand the boundaries of current systems. This will result in a potential change in the way we work, learn, innovate, live and entertain. The heterogeneous smart sensors within the Internet of Things are indispensable parts, which capture the raw data from the physical world by being the first port of contact. Often the sensors within the IoT are deployed or installed in harsh environments. This inevitably means that the sensors are prone to failure, malfunction, rapid attrition, malicious attacks, theft and tampering. All of these conditions cause the sensors within the IoT to produce unusual and erroneous readings, often known as outliers. Much of the current research has been done in developing the sensor outlier and fault detection models exclusively for the Wireless Sensor Networks (WSN), and adequate research has not been done so far in the context of the IoT. Wireless sensor network’s operational framework differ greatly when compared to IoT’s operational framework, using some of the existing models developed for WSN cannot be used on IoT’s for detecting outliers and faults. Sensor faults and outlier detection is very crucial in the IoT to detect the high probability of erroneous reading or data corruption, thereby ensuring the quality of the data collected by sensors. The data collected by sensors are initially pre-processed to be transformed into information and when Artificially Intelligent (AI), Machine Learning (ML) models are further used by the IoT, the information is further processed into applications and processes. Any faulty, erroneous, corrupted sensor readings corrupt the trained models, which thereby produces abnormal processes or outliers that are significantly distinct from the normal behavioural processes of a system. In this paper, we present a comprehensive review of the detecting sensor faults, anomalies, outliers in the Internet of Things and the challenges. A comprehensive guideline to select an adequate outlier detection model for the sensors in the IoT context for various applications is discussed. Full article

The video created by a surveillance cameras plays a crucial role in crime prevention and examinations in smart cities. The closed-circuit television camera (CCTV) is essential for a range of public uses in a smart city; combined with Internet of Things (IoT) technologies they can turn into smart sensors that help to ensure safety and security. However, the authenticity of the camera itself raises issues of building up integrity and suitability of data. In this paper, we present a blockchain-based system to guarantee the trustworthiness of the stored recordings, allowing authorities to validate whether or not a video has been altered. It helps to discriminate fake videos from original ones and to make sure that surveillance cameras are authentic. Since the distributed ledger of the blockchain records the metadata of the CCTV video as well, it is obstructing the chance of forgery of the data. This immutable ledger diminishes the risk of copyright encroachment for law enforcement agencies and clients users by securing possession and identity. Full article

The study of public opinion can provide us with valuable information. The analysis of sentiment on social networks, such as Twitter or Facebook, has become a powerful means of learning about the users’ opinions and has a wide range of applications. However, the efficiency and accuracy of sentiment analysis is being hindered by the challenges encountered in natural language processing (NLP). In recent years, it has been demonstrated that deep learning models are a promising solution to the challenges of NLP. This paper reviews the latest studies that have employed deep learning to solve sentiment analysis problems, such as sentiment polarity. Models using term frequency-inverse document frequency (TF-IDF) and word embedding have been applied to a series of datasets. Finally, a comparative study has been conducted on the experimental results obtained for the different models and input features. Full article

Ιn this review article, a comprehensive study is provided regarding the latest achievements in simulation techniques and platforms for fifth generation (5G) wireless cellular networks. In this context, the calculation of a set of diverse performance metrics, such as achievable throughput in uplink and downlink, the mean Bit Error Rate, the number of active users, outage probability, the handover rate, delay, latency, etc., can be a computationally demanding task due to the various parameters that should be incorporated in system and link level simulations. For example, potential solutions for 5G interfaces include, among others, millimeter Wave (mmWave) transmission, massive multiple input multiple output (MIMO) architectures and non-orthogonal multiple access (NOMA). Therefore, a more accurate and realistic representation of channel coefficients and overall interference is required compared to other cellular interfaces. In addition, the increased number of highly directional beams will unavoidably lead to increased signaling burden and handovers. Moreover, until a full transition to 5G networks takes place, coexistence with currently deployed fourth generation (4G) networks will be a challenging issue for radio network planning. Finally, the potential exploitation of 5G infrastructures in future electrical smart grids in order to support high bandwidth and zero latency applications (e.g., semi or full autonomous driving) dictates the need for the development of simulation environments able to incorporate the various and diverse aspects of 5G wireless cellular networks. Full article

WebRTC is a set of standard technologies that allows exchanging video and audio in real time on the Web. As with other media-related applications, the user-perceived audiovisual quality can be estimated using Quality of Experience (QoE) measurements. This paper analyses the behavior of different objective Full-Reference (FR) models for video and audio in WebRTC applications. FR models calculate the video and audio quality by comparing some original media reference with the degraded signal. To compute these models, we have created an open-source benchmark in which different types of reference media inputs are sent browser to browser while simulating different kinds of network conditions in terms of packet loss and jitter. Our benchmark provides recording capabilities of the impairment WebRTC streams. Then, we use different existing FR metrics for video (VMAF, VIFp, SSIM, MS-SSIM, PSNR, PSNR-HVS, and PSNR-HVS-M) and audio (PESQ, ViSQOL, and POLQA) recordings together with their references. Moreover, we use the same recordings to carry out a subjective analysis in which real users rate the video and audio quality using a Mean Opinion Score (MOS). Finally, we calculate the correlations between the objective and subjective results to find the objective models that better correspond with the subjective outcome, which is considered the ground truth QoE. We find that some of the studied objective models, such as VMAF, VIFp, and POLQA, show a strong correlation with the subjective results in packet loss scenarios. Full article

Routing or forwarding information, such as the location of incidents and victims in a disaster, is significantly important for quick and accurate incident response. However, forwarding such information in disaster areas has been a challenging task for the Wireless Sensor Network as existing networks are affected (destroyed or overused) the disaster. Opportunistic information forwarding can play a vital role in such circumstances. Existing opportunistic routing protocols require huge message transmissions for cluster restoration, which is not energy efficient and results in packet loss. Hence, this paper introduces an energy efficient and reliable opportunistic density cluster-based routing protocol that opportunistically transmits data using a density-clustering protocol for emergency and disaster situations. Simulation results show that the proposed protocol outperforms some existing and well-known routing protocols in terms of network energy consumption, throughput and successful data transmissions. Full article

Vehicle detection is essential for driverless systems. However, the current single sensor detection mode is no longer sufficient in complex and changing traffic environments. Therefore, this paper combines camera and light detection and ranging (LiDAR) to build a vehicle-detection framework that has the characteristics of multi adaptability, high real-time capacity, and robustness. First, a multi-adaptive high-precision depth-completion method was proposed to convert the 2D LiDAR sparse depth map into a dense depth map, so that the two sensors are aligned with each other at the data level. Then, the You Only Look Once Version 3 (YOLOv3) real-time object detection model was used to detect the color image and the dense depth map. Finally, a decision-level fusion method based on bounding box fusion and improved Dempster–Shafer (D–S) evidence theory was proposed to merge the two results of the previous step and obtain the final vehicle position and distance information, which not only improves the detection accuracy but also improves the robustness of the whole framework. We evaluated our method using the KITTI dataset and the Waymo Open Dataset, and the results show the effectiveness of the proposed depth completion method and multi-sensor fusion strategy. Full article

In this study, the thermal behavior of a 1S18P battery pack is examined based on the power demand during train propulsion between two stations. The proposed thermal prediction model is classified into Joules heating with equivalent resistance, reversible heat, and heat dissipation. The equivalent resistances are determined by 5% of the state of charge intervals using the hybrid pulse power characterization test. The power demand profile during train propulsion between two stations is provided by the Korea Railroad Research Institute. An experiment is conducted to examine the 1S18P battery pack thermal behavior during the propulsion between two stations. A comparison of the simulation and experiment results validated the proposed thermal model. Full article

Power electronic converters are used to transform one form of energy to another. They are classified into four types depending upon the nature of the input and output voltages. The inverter is one among those types; it converts direct electrical current into alternating electrical current at desired frequency. Conventional types of inverters are capable of producing voltage at the output terminal that can only switch between two levels. The range of output voltage generated at the output is low when they are used for high power applications. To improve the voltage profile and efficiency of the overall system, multilevel inverters (MLIs) are introduced. In multilevel inverters the voltage at the output terminal is generated from several DC voltage levels fed at its input. The generated output is more appropriate to a sine wave and the dv/dt rating is also less leading to the reduction in EMI. Though they possess many advantages compared to the conventional inverters, the structural complexity and triggering techniques involved in designing multilevel inverters are high. Many studies are being carried out in defining new topologies of MLI with reduced switch as well as with the implementation of different PWM techniques. This paper will provide an extensive review on variety of MLI configurations based on the parameters such as the number of switches, switching techniques, symmetric, asymmetric, hybrid topologies, configurations based on applications, THD and power quality. Full article

In this work, we explore the use of the resistive random access memory (RRAM) device as a synapse for mimicking the trained weights linking neurons in a deep learning neural network (DNN) (AlexNet). The RRAM devices were fabricated in-house and subjected to 1000 bipolar read-write cycles to measure the resistances recorded for Logic-0 and Logic-1 (we demonstrate the feasibility of achieving eight discrete resistance states in the same device depending on the RESET stop voltage). DNN simulations have been performed to compare the relative error between the output of AlexNet Layer 1 (Convolution) implemented with the standard backpropagation (BP) algorithm trained weights versus the weights that are encoded using the measured resistance distributions from RRAM. The IMAGENET dataset is used for classification purpose here. We focus only on the Layer 1 weights in the AlexNet framework with 11 × 11 × 96 filters values coded into a binary floating point and substituted with the RRAM resistance values corresponding to Logic-0 and Logic-1. The impact of variability in the resistance states of RRAM for the low and high resistance states on the accuracy of image classification is studied by formulating a look-up table (LUT) for the RRAM (from measured I-V data) and comparing the convolution computation output of AlexNet Layer 1 with the standard outputs from the BP-based pre-trained weights. This is one of the first studies dedicated to exploring the impact of RRAM device resistance variability on the prediction accuracy of a convolutional neural network (CNN) on an AlexNet platform through a framework that requires limited actual device switching test data. Full article

We need open platforms driven by specialists, in which queries can be created and collected for long periods and the diagnosis made based on a rigorous clinical follow-up. In this work, we developed a multi-language robot interface helping to evaluate the mental health of seniors by interacting through questions. Through the voice interface, the specialist can propose questions, as well as receive users’ answers, in text form. The robot can automatically interact with the user using the appropriate language. It can process the answers and under the guidance of a specialist, questions and answers can be oriented towards the desired therapy direction. The prototype was implemented on an embedded device meant for edge computing, thus it was able to filter environmental noise and can be placed anywhere at home. The proposed platform allows the integration of well-known open source and commercial data flow processing frameworks. The experience is now available for specialists to create queries and answers through a Web-based interface. Full article

Due to the exponential increase in the human population of this bio-sphere, energy resources are becoming scarce. Because of the traditional methods, most of the generated energy is wasted every year in the distribution network and demand side. Therefore, researchers all over the world have taken a keen interest in this issue and finally introduced the concept of the smart grid. Smart grid is an ultimate solution to all of the energy related problems of today’s modern world. In this paper, we have proposed a meta-heuristic optimization technique called the dragonfly algorithm (DA). The proposed algorithm is to a real-world problem of single and multiple smart homes. In our system model, two classes of appliances are considered; Shiftable appliances and Non-shiftable appliances. Shiftable appliances play a significant role in demand side load management because they can be scheduled according to real time pricing (RTP) signal from utility, while non-shiftable appliances are not much important in load management, as these appliances are fixed and cannot be scheduled according to RTP. On behalf of our simulation results, it can be concluded that our proposed algorithm DA has achieved minimum electricity cost with a tolerable waiting time. There is a trade-off between electricity cost and waiting time because, with a decrease in electricity cost, waiting time increases and vice versa. This trade-off is also obtained by our proposed algorithm DA. The stability of the grid is also maintained by our proposed algorithm DA because stability of the grid depends on peak-to-average ratio (PAR), while PAR is reduced by DA in comparison with an unscheduled case. Full article

Wearable electronics are produced by depositing thin electroconductive layers with low resistance on flexible substrates. In the process of producing such metallic films, as well as during their usage, structural defects may appear which affect their electrical properties. In this paper, we present analytical and numerical models for understanding phenomena related to the electrical conductivity of thin electroconductive layers. The algorithm in the numerical model is based on the boundary integral equation method. The formulas enable calculation of the potential distribution and electric field strength of the analyzed structures, and describe the impact of cracks on their electrical resistance. The validity of the proposed models was verified by experimental results. Full article

A transformer-less Buck-Boost direct current–direct current (DC–DC) converter in use for the fast charge of electric vehicles, based on powerful high-voltage isolated gate bipolar transistor (IGBT) modules is analyzed, designed and experimentally verified. The main advantages of this topology are: simple structure on the converter’s power stage; a wide range of the output voltage, capable of supporting contemporary vehicles’ on-board battery packs; efficiency; and power density accepted to be high enough for such a class of hard-switched converters. A precise estimation of the loss, dissipated in the converter’s basic modes of operation Buck, Boost, and Buck-Boost is presented. The analysis shows an approach of loss minimization, based on switching frequency reduction during the Buck-Boost operation mode. Such a technique guarantees stable thermal characteristics during the entire operation, i.e., battery charge cycle. As the Buck-Boost mode takes place when Buck and Boost modes cannot support the output voltage, operating as a combination of them, it can be considered as critically dependent on the characteristics of the semiconductors. With this, the necessary duty cycle and voltage range, determined with respect to the input-output voltages and power losses, require an additional study to be conducted. Additionally, the tolerance of the applied switching frequencies for the most versatile silicon-based powerful IGBT modules is analyzed and experimentally verified. Finally, several important characteristics, such as transients during switch-on and switch-off, IGBTs’ voltage tails, critical duty cycles, etc., are depicted experimentally with oscillograms, obtained by an experimental model. Full article

Supervised semantic segmentation algorithms have been a hot area of exploration recently, but now the attention is being drawn towards completely unsupervised semantic segmentation. In an unsupervised framework, neither the targets nor the ground truth labels are provided to the network. That being said, the network is unaware about any class instance or object present in the given data sample. So, we propose a convolutional neural network (CNN) based architecture for unsupervised segmentation. We used the squeeze and excitation network, due to its peculiar ability to capture the features’ interdependencies, which increases the network’s sensitivity to more salient features. We iteratively enable our CNN architecture to learn the target generated by a graph-based segmentation method, while simultaneously preventing our network from falling into the pit of over-segmentation. Along with this CNN architecture, image enhancement and refinement techniques are exploited to improve the segmentation results. Our proposed algorithm produces improved segmented regions that meet the human level segmentation results. In addition, we evaluate our approach using different metrics to show the quantitative outperformance. Full article

The paper presents the Embodied Agent-based Robot control system modelling Language (EARL). EARL follows a Model-Driven Software Development approach (MDSD), which facilitates robot control system development. It is based on a mathematical method of robot controller specification, employing the concept of an Embodied Agent, and a graphical modelling language: System Modelling Language (SysML). It combines the ease of use of SysML with the precision of mathematical specification of certain aspects of the designed system. It makes the whole system specification effective, from the point of view of the time needed to create it, conciseness of the specification and the possibility of its analysis. By using EARL it is possible to specify systems both with fixed and variable structure. This was achieved by introducing a generalised system model and presenting particular structures of the system in terms of modelling block configurations adapted by using instances. FABRIC framework was created to support the implementation of EARL-based controllers. EARL is compatible with component based robotic middlewares (e.g., ROS and Orocos). Full article

This paper describes a low-cost flight control system of a small aileron-less hand-launched solar-powered unmanned aerial vehicle (UAV). In order to improve the accuracy of the whole system model and quantify the influence of each subsystem, detailed modeling of UAV energy and a control system including a solar model, engine, energy storage, sensors, state estimation, control law, and actuator module are established in accordance with the experiment and component principles. A whole system numerical simulation combined with the 6 degree-of-freedom (DOF) simulation model is constructed based on the typical mission route, and the parameter precision sequence and energy balance are obtained. Then, a hardware-in-the-loop (HIL) experiment scheme based on the Stewart platform (SP) is proposed, and three modes of acceleration, angular velocity, and attitude are designed to verify the control system through the inner and boundary states of the flight envelope. The whole system scheme is verified by flight tests at different altitudes, and the aerodynamic force coefficient and sensor error are corrected by flight data. With the increase of altitude, the cruise power increases from 47 W to 78 W, the trajectory tracking precision increases from 23 m to 44 m, the sensor measurement noise increases, and the bias decreases. Full article

This paper presents the sensorless control algorithm for a permanent magnet synchronous motor (PMSM) drive system with the estimator and the intelligent controller. The estimator is constructed on the novel sliding mode observer (SMO) in combination with a phase-locked loop (PLL) to estimate the position and speed of the rotor. The intelligent controller is a radial basis function neural network (RBFNN)-based self-tuning PID (Proportional-Integral-Derivative) controller, applied to the velocity control loop of the PMSM drive control system to adapt strongly to dynamic characteristics during the operation with an external load. The I-f startup strategy is adopted to accelerate the motor from standstill, then switches to the sensorless mode smoothly. The control algorithm program is based on MATLAB and can be executed in simulations and experiments. The control system performance is verified on an experimental platform with various speeds and the dynamic load, in which the specified I-f startup mode and sensorless mode, inspected by tracking response and speed regulation. The simulation and experimental results demonstrate that the proposed method has worked successfully. The motor control system has smooth switching, good tracking response, and robustness against disturbance. Full article

Design and control of a lower-limb exoskeleton rehabilitation of the elderly are the main challenge for health care in the past decades. In order to satisfy the requirements of the elderly or disabled users, this paper presents a novel design and adaptive fuzzy control of lower-limb empowered rehabilitation, namely MOVING UP. Different from other rehabilitation devices, this article considers active rehabilitation training devices. Firstly, a novel product design method based on user experience is proposed for the lower-limb elderly exoskeleton rehabilitation. At the same time, in order to achieve a stable operation control for the assistant rehabilitation system, an adaptive fuzzy control scheme is discussed. Finally, the feasibility of the design and control method is validated with a detailed simulation study and the human-interaction test. With the booming demand in the global market for the assistive lower-limb exoskeleton, the methodology developed in this paper will bring more research and manufacturing interests. Full article

Neural-network computing has revolutionized the field of machine learning. The systolic-array architecture is a widely used architecture for neural-network computing acceleration that was adopted by Google in its Tensor Processing Unit (TPU). To ensure the correct operation of the neural network, the reliability of the systolic-array architecture should be guaranteed. This paper proposes an efficient systolic-array redundancy architecture that is based on systolic-array partitioning and rearranging connections of the systolic-array elements. The proposed architecture allows both offline and online repair with an extended redundancy architecture and programmable fuses and can ensure reliability even in an online situation, for which the previous fault-tolerant schemes have not been considered. Full article

In order to solve the imminent problem in that the traditional protection strategy cannot meet time requirements, together with the fact that the rotational inertia of a DC microgrid is small and short-circuit fault develops rapidly, a bidirectional short-circuit current blocker (BSCCB) based on solid-state circuit breaker for a DC microgrid is proposed. Firstly, the bidirectional current blocking circuit structure is proposed based on the analysis of key components. Then, a top-level differential protection strategy is developed based on the aforementioned proposal. Finally, the performance of the blocking circuit is simulated and verified by experiments. The results show that the proposed method can block short-circuit current within 4 ms, and the response speed of the protection strategy is very fast compared with previous approaches. BSCCB also has reclosing, bidirectional blocking and energy releasing functions. The current blocker proposed in this paper can be reused multiple times and has a promising future in low-voltage DC microgrid application. Full article

This study presents a new path planning method based on Fuzzy Analytic Hierarchy Process (FAHP) for a mobile robot to be effectively operated through a multi-objective decision making problem. Unlike typical AHP, the proposed FAHP has a difference in using triangulation fuzzy number based extent analysis to derive weight vectors among the considerations. FAHP framework for finding the optimal position in this study is defined with the highest level (goal), middle level (objectives), and the lowest level (alternatives). It analytically selects an optimal position as a sub-goal among points on the sensing boundary of the mobile robot considering the three objectives: the travel distance to the target, robot’s rotation, and safety against collision between obstacles. Alternative solutions are evaluated by quantifying the relative importance for the objectives. Comparative results obtained from the artificial potential field, AHP, and FAHP simulations show that FAHP is much preferable for mobile robot’s path planning than typical AHP. Full article

Diabetic Retinopathy is a major cause of vision loss and blindness affecting millions of people across the globe. Although there are established screening methods - fluorescein angiography and optical coherence tomography for detection of the disease but in majority of the cases, the patients remain ignorant and fail to undertake such tests at an appropriate time. The early detection of the disease plays an extremely important role in preventing vision loss which is the consequence of diabetes mellitus remaining untreated among patients for a prolonged time period. Various machine learning and deep learning approaches have been implemented on diabetic retinopathy dataset for classification and prediction of the disease but majority of them have neglected the aspect of data pre-processing and dimensionality reduction, leading to biased results. The dataset used in the present study is a diabetes retinopathy dataset collected from the UCI machine learning repository. At its inceptions, the raw dataset is normalized using the Standardscalar technique and then Principal Component Analysis (PCA) is used to extract the most significant features in the dataset. Further, Firefly algorithm is implemented for dimensionality reduction. This reduced dataset is fed into a Deep Neural Network Model for classification. The results generated from the model is evaluated against the prevalent machine learning models and the results justify the superiority of the proposed model in terms of Accuracy, Precision, Recall, Sensitivity and Specificity. Full article

Discrete time dynamical chaotic systems obey a set of recurrence equations involving one or more variables. Many chaotic maps have been proposed. None that simultaneously provides two sine–cosine outputs has stationary mean and standard deviation, or is quite robust with respect to the data format used in the hardware implementation. Here, we propose a chaotic oscillator based on a complex phasor whose angular argument evolves according to a geometric progression that is independent of the instantaneous amplitude. In order to maintain the oscillations, the phasor magnitude is normalized at each iteration using an approximation factor. The statistical characteristics of this oscillator are stationary in the short term, and do not depend on the initial conditions. The mean and standard deviation of the two orthogonal sequences quickly approach 0 and $1/\sqrt{2}$ , respectively. The resulting distribution is similar to that of a digital sine with a constant angular step. We also present an FPGA architecture and its implementation results. This oscillator can be used in modulation schemes, such as the chaotic shift keying one or for data and image encryption. Finally, we show an original application that exploits the orthogonality of the two chaotic signals for the simultaneous encryption of two digital images. Full article

In this study, a new coplanar waveguide (CPW)-fed diversity antenna design is introduced for multiple-input–multiple-output (MIMO) smartphone applications. The diversity antenna is composed of a double-fed CPW-fed antenna with a pair of modified T-ring radiators. The antenna is designed to cover the frequency spectrum of commercial sub-6 GHz 5G communication (3.4–3.8 and 3.8–4.2 GHz). It also provides high isolation, better than −16 dB, without an additional decoupling structure. It offers good potential to be deployed in future smartphones. Therefore, the characteristics and performance of an 8-port 5G smartphone antenna were investigated using four pairs of the proposed diversity antennas. Due to the compact size and also the placement of the elements, the presented CPW-fed smartphone antenna array design occupies a very small part of the smartphone board. Its operation band spans from 3.4 to 4.4 GHz. The simulated results agree well with measured results, and the performance of the smartphone antenna design in the presence of a user is given in this paper as well. The proposed MIMO design provides not only sufficient radiation coverage supporting different sides of the mainboard but also polarization diversity. Full article

A theoretical study of the electromagnetic propagation in a complex medium suspended multilayer coplanar waveguide (CPW) is presented. The study is based on the generalized exponential matrix technique (GEMT) combined with Galerkin’s spectral method of moments applied to a CPW printed on a bianisotropic medium. The analytical formulation is based on a Full-GEMT, a method that avoids usual procedures of heavy and tedious mathematical expressions in the development of calculations and uses matrix-based mathematical expressions instead. These particularities are exploited to develop a mathematical model for the characterization of wave propagation in a three-layer shielded suspended CPW structure. This study is based on the development of mathematical formulations in full compact matrix-based expressions resulting in Green’s functions in a matrix form. The implemented method incorporates a new accelerating procedure developed in the GEMT which provides an initial value used to speed up searching for the exact solution in the principal computation code. This helped us to obtain accurate solutions with tolerable computing time. Good agreements have been achieved with the literature in terms of accuracy and rapid convergence. The results for different cases of bianisotropy have been investigated, and particularly, the effect on the dispersion characteristics is presented and compared with the isotropic case. Full article

In this paper, an efficient technique of computation of method of moments (MM) matrix entries for multilayer periodic structures with NURBS surface and Bézier patches modelling is proposed. An approximation in terms of constant pulses of generalized rooftop basis functions (BFs) defined on Bézier patches is proposed. This approximation leads discrete convolutions instead of usual continuous convolution between Green’s functions and BFs obtained by the direct mixed potential integral equation (MPIE) approach. An equivalent periodic problem (EPP) which contains the original problem is proposed to transform the discrete convolutions in discrete cyclic convolutions. The resultant discrete cyclic convolutions are computed by efficiently using the Fast Fourier Transform (FFT) procedure. The performance of the proposed method and direct computation of the MM entries are compared for phases of reflection coefficient. The proposed method is between 9 and 50 times faster than the direct computation for phase errors less than 1 deg. The proposed method exhibits a behaviour of CPU time consumption of O(N_bLog10N_b) as the number N_b of BFs increases. This behaviour provides significant CPU time savings with respect to the expected behaviour of O(N_b²) provided by the direct computation of the MM matrix entries. Full article

Extended range electric vehicles (EREVs) operate both as an electric vehicle (EV) and as a hybrid electric vehicle (HEV). As a hybrid, the on-board range extender (REx) system provides additional energy to increase the feasible driving range. In this paper, we evaluate an experimental research EREV based on the 2016 Chevrolet Camaro platform for optimal energy management control. We use model-in-loop and software-in-loop environments to validate the data-driven power loss model of the research vehicle. A discussion on the limitations of conventional energy management control algorithms is presented. We then propose our algorithm derived from adaptive real-time dynamic programming (ARTDP) with a distance constraint for energy consumption optimization. To achieve a near real-time functionality, the algorithm recomputes optimal parameters by monitoring the energy storage system’s (ESS) state of charge deviations from the previously computed optimal trajectory. The proposed algorithm is adaptable to variability resulting from driving behavior or system limitations while maintaining the target driving range. The net energy consumption evaluation shows a maximum improvement of 9.8% over the conventional charge depleting/charge sustaining (CD/CS) algorithm used in EREVs. Thus, our proposed algorithm shows adaptability and fault tolerance while being close to the global optimal solution. Full article

Radio-frequency switches manufactured by microelectromechanical systems technology are now widely used in aerospace systems and other mobile installations for various purposes. In these operating conditions, these devices are often exposed to intense mechanical environmental influences that have a strong impact on their operation. These negative effects can lead to unwanted short-circuit or open-circuit in the radio-frequency transmission line or to irreversible damage to structural elements. Such a violation in the operation of radio-frequency microelectromechanical switches leads to errors and improper functioning of the electronic equipment in which they are integrated. Thus, this review is devoted to the analysis of the origin of these negative intense mechanical effects of the environment, their classification, and analysis, as well as a review of methods to reduce or prevent their negative impact on the design of radio-frequency microelectromechanical switches. Full article

In this paper, a stub-loaded square ring resonator (SLSRR) is analyzed and applied to design a very simple and compact wideband bandpass filter structure. Resonant modes dependent on the structure parameters of the SLSRR are analyzed first, and then the first two modes are used to achieve a required passband. The input and output terminals are supplied with high impedance and strong coupling to provide sufficient coupling energy. Two wideband filter examples are designed, manufactured, and measured using the SLSRRs. The first filter is a wideband filter with a wide upper stopband, and the second filter is a dual wideband filter with a notched stopband between two passbands. The two filter examples are designed, fabricated, and measured to verify the design concept and present the advantages of easy design and a simple and compact structure. Full article

Cyberttacks are becoming increasingly sophisticated, necessitating the efficient intrusion detection mechanisms to monitor computer resources and generate reports on anomalous or suspicious activities. Many Intrusion Detection Systems (IDSs) use a single classifier for identifying intrusions. Single classifier IDSs are unable to achieve high accuracy and low false alarm rates due to polymorphic, metamorphic, and zero-day behaviors of malware. In this paper, a Hybrid IDS (HIDS) is proposed by combining the C5 decision tree classifier and One Class Support Vector Machine (OC-SVM). HIDS combines the strengths of SIDS) and Anomaly-based Intrusion Detection System (AIDS). The SIDS was developed based on the C5.0 Decision tree classifier and AIDS was developed based on the one-class Support Vector Machine (SVM). This framework aims to identify both the well-known intrusions and zero-day attacks with high detection accuracy and low false-alarm rates. The proposed HIDS is evaluated using the benchmark datasets, namely, Network Security Laboratory-Knowledge Discovery in Databases (NSL-KDD) and Australian Defence Force Academy (ADFA) datasets. Studies show that the performance of HIDS is enhanced, compared to SIDS and AIDS in terms of detection rate and low false-alarm rates. Full article

In this paper a GaN-on-Si MMIC Low-Noise Amplifier (LNA) working in the Ka-band is shown. The chosen technology for the design is a 100 nm gate length HEMT provided by OMMIC foundry. Both small-signal and noise models had been previously extracted by the means of an extensive measurement campaign, and were then employed in the design of the presented LNA. The amplifier presents an average noise figure of 2.4 dB, a 30 dB average gain value, and input/output matching higher than 10 dB in the whole 34–37.5 Ghz design band, while non-linear measurements testify a minimum output 1 dB compression point of 23 dBm in the specific 35–36.5 GHz target band. This shows the suitability of the chosen technology for low-noise applications. Full article

The application of a large number of Internet of Things (IoT) devices makes our life more convenient and industries more efficient. However, it also makes cyber-attacks much easier to occur because so many IoT devices are deployed and most of them do not have enough resources (i.e., computation and storage capacity) to carry out ordinary intrusion detection systems (IDSs). In this study, a lightweight machine learning-based IDS using a new feature selection algorithm is designed and implemented on Raspberry Pi, and its performance is verified using a public dataset collected from an IoT environment. To make the system lightweight, we propose a new algorithm for feature selection, called the correlated-set thresholding on gain-ratio (CST-GR) algorithm, to select really necessary features. Because the feature selection is conducted on three specific kinds of cyber-attacks, the number of selected features can be significantly reduced, which makes the classifiers very small and fast. Thus, our detection system is lightweight enough to be implemented and carried out in a Raspberry Pi system. More importantly, as the really necessary features corresponding to each kind of attack are exploited, good detection performance can be expected. The performance of our proposal is examined in detail with different machine learning algorithms, in order to learn which of them is the best option for our system. The experiment results indicate that the new feature selection algorithm can select only very few features for each kind of attack. Thus, the detection system is lightweight enough to be implemented in the Raspberry Pi environment with almost no sacrifice on detection performance. Full article

The electrocardiogram (ECG) is a widely used, noninvasive test for analyzing arrhythmia. However, the ECG signal is prone to contamination by different kinds of noise. Such noise may cause deformation on the ECG heartbeat waveform, leading to cardiologists’ mislabeling or misinterpreting heartbeats due to varying types of artifacts and interference. To address this problem, some previous studies propose a computerized technique based on machine learning (ML) to distinguish between normal and abnormal heartbeats. Unfortunately, ML works on a handcrafted, feature-based approach and lacks feature representation. To overcome such drawbacks, deep learning (DL) is proposed in the pre-training and fine-tuning phases to produce an automated feature representation for multi-class classification of arrhythmia conditions. In the pre-training phase, stacked denoising autoencoders (DAEs) and autoencoders (AEs) are used for feature learning; in the fine-tuning phase, deep neural networks (DNNs) are implemented as a classifier. To the best of our knowledge, this research is the first to implement stacked autoencoders by using DAEs and AEs for feature learning in DL. Physionet’s well-known MIT-BIH Arrhythmia Database, as well as the MIT-BIH Noise Stress Test Database (NSTDB). Only four records are used from the NSTDB dataset: 118 24 dB, 118 −6 dB, 119 24 dB, and 119 −6 dB, with two levels of signal-to-noise ratio (SNRs) at 24 dB and −6 dB. In the validation process, six models are compared to select the best DL model. For all fine-tuned hyperparameters, the best model of ECG heartbeat classification achieves an accuracy, sensitivity, specificity, precision, and F1-score of 99.34%, 93.83%, 99.57%, 89.81%, and 91.44%, respectively. As the results demonstrate, the proposed DL model can extract high-level features not only from the training data but also from unseen data. Such a model has good application prospects in clinical practice. Full article

The Deterministic and Synchronous Multichannel Extension (DSME) of the IEEE 802.15.4 standard was designed to fulfill the requirements of commercial and industrial applications. DSME overcomes the IEEE 802.15.4 limitation on the maximum number of Guaranteed Time Slots (GTS) in a superframe and it also exploits channel diversity to increase the communication reliability. However, DSME suffers from scalability problems, as its multi-superframe structure does not efficiently handle GTS in networks with a high number of nodes and periodic flows. This paper proposes the enhanceD DSME (D-DSME), which consists of two extensions that improve the DSME scalability and reliability exploiting a GTS within the multi-superframe to accommodate multiple flows or multiple retransmissions of the same flow. The paper describes the proposed extensions and the performance results of both OMNeT simulations and experiments with real devices implementing the D-DSME. Full article

We have investigated the effect of electron effective mass (m_e*) and tail acceptor-like edge traps density (N_TA) on the electrical characteristics of amorphous-InGaZnO (a-IGZO) thin-film transistors (TFTs) through numerical simulation. To examine the credibility of our simulation, we found that by adjusting m_e* to 0.34 of the free electron mass (m_o), we can preferentially derive the experimentally obtained electrical properties of conventional a-IGZO TFTs through our simulation. Our initial simulation considered the effect of m_e* on the electrical characteristics independent of N_TA. We varied the m_e* value while not changing the other variables related to traps density not dependent on it. As m_e* was incremented to 0.44 m_o, the field-effect mobility (µ_fe) and the on-state current (I_on) decreased due to the higher sub-gap scattering based on electron capture behavior. However, the threshold voltage (V_th) was not significantly changed due to fixed effective acceptor-like traps (N_TA). In reality, since the magnitude of N_TA was affected by the magnitude of m_e*, we controlled m_e* together with N_TA value as a secondary simulation. As the magnitude of both m_e* and N_TA increased, µ_fe and Ion deceased showing the same phenomena as the first simulation. The magnitude of V_th was higher when compared to the first simulation due to the lower conductivity in the channel. In this regard, our simulation methods showed that controlling m_e* and N_TA simultaneously would be expected to predict and optimize the electrical characteristics of a-IGZO TFTs more precisely. Full article

Electrocardiogram (ECG) signal evaluation is routinely used in clinics as a significant diagnostic method for detecting arrhythmia. However, it is very labor intensive to externally evaluate ECG signals, due to their small amplitude. Using automated detection and classification methods in the clinic can assist doctors in making accurate and expeditious diagnoses of diseases. In this study, we developed a classification method for arrhythmia based on the combination of a convolutional neural network and long short-term memory, which was then used to diagnose eight ECG signals, including a normal sinus rhythm. The ECG data of the experiment were derived from the MIT-BIH arrhythmia database. The experimental method mainly consisted of two parts. The input data of the model were two-dimensional grayscale images converted from one-dimensional signals, and detection and classification of the input data was carried out using the combined model. The advantage of this method is that it does not require performing feature extraction or noise filtering on the ECG signal. The experimental results showed that the implemented method demonstrated high classification performance in terms of accuracy, specificity, and sensitivity equal to 99.01%, 99.57%, and 97.67%, respectively. Our proposed model can assist doctors in accurately detecting arrhythmia during routine ECG screening. Full article

The future of traffic management will be based on “connected” and “autonomous” vehicles. With connected vehicles it is possible to gather real-time information. The main potential application of this information is in real-time adaptive traffic signal control. Despite the feasibility of using Floating Car Data (FCD), for signal control, there have been practically no real experiments with all “connected” vehicles to regulate traffic signals in real-time. Most of the research in this field has been carried out with simulations. The purpose of this study is to present a dedicated system that was implemented in the first experiment of an FCD-based adaptive traffic signal. For the first time in the history of traffic management, a traffic signal has been regulated in real time with real “connected” vehicles. This paper describes the entire path of software and system development that has allowed us to make the steps from just simulation test to a real on-field implementation. Results of the experiments carried out with the presented system prove the feasibility of FCD adaptive traffic signals with commonly-used technologies and also establishes a test-bed that may help others to develop better regulation algorithms for these kinds of new “connected” intersections. Full article

Vehicle mobilities for passengers in a city’s downtown area or in the countryside are significant points to characterize their functions and outputs. We focus on commercial sightseeing vehicles in a Japanese city where many tourists enjoy sightseeing. Such mobilities and their visualizations make tourist activities smoother and richer. We design and install a low-power, wide-area positioning system on a rickshaw, which is a human-pulled, two- or three-wheeled cart, and monitor its mobility in Hikone City. All the spatial locations, which are recorded in a time sequence on a cloud server, are currently available as open data on the internet. We analyze such sequential data using graph topology, which reflects the information of corresponding geographical maps, and reproduce it in cyberspace using an agent-based model with similar probabilities to the accumulated rickshaw records from one spatial node to another. Although the numerical results of the agent traced in a simulated city are partially consistent with the rickshaw’s record, we identify some significant differences. We conclude that the rickshaw’s mobility observed at the actual sightseeing sites is partially in the random motion; some cases are strongly biased by memory routes. Such non-randomness in the rickshaw’s mobility indicates the existence of specific features in tourism sources that are identified for each sightseeing activity and affected by local sightseeing resources. Full article

The earliest and simplest impedance compensation technique used in inductive wireless power transfer (WPT) design is the series-series (SS) compensation circuit, which uses capacitors in series with both primary and secondary coils of an air-gapped transformer. Despite of its simplicity at the resonant condition, this configuration exhibits a major sensitivity to variations of the load attached to the secondary, especially when higher coupling coefficients are used in the design. In the extreme situation that the secondary coil is left at open circuit, the current at the primary coil may increase above the safety limits for either the power converter driving the primary coil or the components in the primary circuit, including the coil itself. An approach often used to minimize this problem is detuning, but this also reduces the electrical efficiency of the power transfer. In low power, fixed-distance stationary WPT, a fair trade-off between efficiency and safety must be verified. This paper aims to consolidate a simple design procedure for such a SS-compensation, exemplifying its use in the prototype of a WPT system for automotive light detection and ranging (LiDAR) equipment. The guidelines herein provided should equally apply to other low power applications. Full article

In this paper, the effects of electromagnetic interference (EMI) coupled to a radio-frequency (RF) communication channel by resonant mechanisms are investigated and described in the framework of Shannon information theory in terms of an equivalent channel capacity loss so that to analyze and compare the effects of non-modulated and random Spread Spectrum (SS) modulated EMI. The analysis reveals a higher EMI-induced capacity loss for SS-modulated compared to non modulated EMI under practical values of the quality factor Q, while a modest improvement in the worst case capacity loss is observed only for impractical values of Q. Simulations on a 4-quadrature amplitude modulation (4-QAM) digital link featuring Turbo coding under EMI resonant coupling reveal that SS-modulated EMI gives rise to higher bit error rate (BER) at lower EMI power compared non-modulated EMI in the presence of resonant coupling for practical values of Q, thus suggesting a worse interfering potential of SS-modulated EMI. Full article

We present a 4-port Multiple-Input-Multiple-Output (MIMO) antenna array operating in the mm-wave band for 5G applications. An identical two-element array excited by the feed network based on a T-junction power combiner/divider is introduced in the reported paper. The array elements are rectangular-shaped slotted patch antennas, while the ground plane is made defected with rectangular, circular, and a zigzag-shaped slotted structure to enhance the radiation characteristics of the antenna. To validate the performance, the MIMO structure is fabricated and measured. The simulated and measured results are in good coherence. The proposed structure can operate in a 25.5–29.6 GHz frequency band supporting the impending mm-wave 5G applications. Moreover, the peak gain attained for the operating frequency band is 8.3 dBi. Additionally, to obtain high isolation between antenna elements, the polarization diversity is employed between the adjacent radiators, resulting in a low Envelope Correlation Coefficient (ECC). Other MIMO performance metrics such as the Channel Capacity Loss (CCL), Mean Effective Gain (MEG), and Diversity gain (DG) of the proposed structure are analyzed, and the results indicate the suitability of the design as a potential contender for imminent mm-wave 5G MIMO applications. Full article

In this paper, the effect of common-mode voltage generated in the three-level quasi-switched boost T-type inverter is minimized by applying the proposed space-vector modulation technique, which uses only medium vectors and zero vector to synthesize the reference vector. The switching sequence is selected smoothly for inserting the shoot-through state for the inverter branch. The shoot-through vector is added within the zero vector in order to not affect the active vectors as well as the output voltage. In addition, the shoot-through control signal of active switches of the impedance network is generated to ensure that its phase is shifted 90 degrees compared to shoot through the signal of the inverter leg, which provides an improvement in reducing the inductor current ripple and enhancing the voltage gain. The effectiveness of the proposed method is verified through simulation and experimental results. In addition, the superiority of the proposed scheme is demonstrated by comparing it to the conventional pulse-width modulation technique. Full article

Classical direct torque control (DTC) is considered one of the simplest and fastest control algorithms in motor drives. However, it produces high torque and flux ripples due to the implementation of the three-level hysteresis torque regulator (HTR). Although, increasing the level of HTR and utilizing multilevel inverters has a great contribution in torque and flux ripples reduction, stator flux magnitude of induction motor (IM) droops at every switching sector transition, particularly at low-speed operation. This problem occurs due to the utilization of a zero voltage vector, where the domination of stator resistance is very high. A simple flux regulation strategy (SFRS) is applied for low-speed operation for DTC of IM. The proposed DTC-SFRS modifies the output status of the five-level HTR depending on the flux error, torque error, and stator flux position. This method regulates the stator flux for both forward and reverse rotational directions of IM with retaining the basic structure of classical DTC. By using the proposed algorithm, the stator flux is regulated, hence pure sinusoidal current waveform is achieved, which results in lower total harmonics distortion (THD). The effectiveness of the proposed DTC-SFRS is verified through simulation and experimental results. Full article

In this paper, we report on an in-house developed electronic nose (E-nose) for use with breath analysis. The unit consists of an array of 10 micro-electro-mechanical systems (MEMS) metal oxide (MOX) gas sensors produced by seven manufacturers. Breath sampling of end-tidal breath is achieved using a heated sample tube, capable of monitoring sampling-related parameters, such as carbon dioxide (CO₂), humidity, and temperature. A simple mobile app was developed to receive real-time data from the device, using Wi-Fi communication. The system has been tested using chemical standards and exhaled breath samples from healthy volunteers, before and after taking a peppermint capsule. Results from chemical testing indicate that we can separate chemical standards (acetone, isopropanol and 1-propanol) and different concentrations of isobutylene. The analysis of exhaled breath samples demonstrate that we can distinguish between pre- and post-consumption of peppermint capsules; area under the curve (AUC): 0.81, sensitivity: 0.83 (0.59–0.96), specificity: 0.72 (0.47–0.90), p-value: <0.001. The functionality of the developed device has been demonstrated with the testing of chemical standards and a simplified breath study using peppermint capsules. It is our intention to deploy this system in a UK hospital in an upcoming breath research study. Full article

Multimodal biometrics technology has recently gained interest due to its capacity to overcome certain inherent limitations of the single biometric modalities and to improve the overall recognition rate. A common biometric recognition system consists of sensing, feature extraction, and matching modules. The robustness of the system depends much more on the reliability to extract relevant information from the single biometric traits. This paper proposes a new feature extraction technique for a multimodal biometric system using face–iris traits. The iris feature extraction is carried out using an efficient multi-resolution 2D Log-Gabor filter to capture textural information in different scales and orientations. On the other hand, the facial features are computed using the powerful method of singular spectrum analysis (SSA) in conjunction with the wavelet transform. SSA aims at expanding signals or images into interpretable and physically meaningful components. In this study, SSA is applied and combined with the normal inverse Gaussian (NIG) statistical features derived from wavelet transform. The fusion process of relevant features from the two modalities are combined at a hybrid fusion level. The evaluation process is performed on a chimeric database and consists of Olivetti research laboratory (ORL) and face recognition technology (FERET) for face and Chinese academy of science institute of automation (CASIA) v3.0 iris image database (CASIA V3) interval for iris. Experimental results show the robustness. Full article
