Analog mixed-signal (AMS) verification is one of the essential tasks in the development process of modern systems-on-chip (SoC). Most parts of the AMS verification flow are already automated, except for stimuli generation, which has been performed manually. It is thus challenging and time-consuming. Hence, automation is a necessity. To generate stimuli, subcircuits or subblocks of a given analog circuit module should be identified/classified. However, there currently needs to be a reliable industrial tool that can automatically identify/classify analog sub-circuits (eventually in the frame of a circuit design process) or automatically classify a given analog circuit at hand. Besides verification, several other processes would profit enormously from the availability of a robust and reliable automated classification model for analog circuit modules (which may belong to different levels). This paper presents how to use a Graph Convolutional Network (GCN) model and proposes a novel data augmentation strategy to automatically classify analog circuits of a given level. Eventually, it can be upscaled or integrated within a more complex functional module (for a structure recognition of complex analog circuits), targeting the identification of subcircuits within a more complex analog circuit module. An integrated novel data augmentation technique is particularly crucial due to the harsh reality of the availability of generally only a relatively limited dataset of analog circuits’ schematics (i.e., sample architectures) in practical settings. Through a comprehensive ontology, we first introduce a graph representation framework of the circuits’ schematics, which consists of converting the circuit’s related netlists into graphs. Then, we use a robust classifier consisting of a GCN processor to determine the label corresponding to the given input analog circuit’s schematics. Furthermore, the classification performance is improved and robust by involving a novel data augmentation technique. The classification accuracy was enhanced from 48.2% to 76.6% using feature matrix augmentation, and from 72% to 92% using Dataset Augmentation by Flipping. A 100% accuracy was achieved after applying either multi-Stage augmentation or Hyperphysical Augmentation. Overall, extensive tests of the concept were developed to demonstrate high accuracy for the analog circuit’s classification endeavor. This is solid support for a future up-scaling towards an automated analog circuits’ structure detection, which is one of the prerequisites not only for the stimuli generation in the frame of analog mixed-signal verification but also for other critical endeavors related to the engineering of AMS circuits. Full article

This paper presents a method to monitor the thermal peaks that are major concerns when designing Integrated Circuits (ICs) in various advanced technologies. The method aims at detecting the thermal peak in Systems on Chip (SoC) using arrays of oscillators distributed over the area of the chip. Measured frequencies are mapped to local temperatures that are used to produce a chip thermal mapping. Then, an indication of the local temperature of a single heat source is obtained in real-time using the Gradient Direction Sensor (GDS) technique. The proposed technique does not require external sensors, and it provides a real-time monitoring of thermal peaks. This work is performed with Field-Programmable Gate Array (FPGA), which acts as a System-on-Chip, and the detected heat source is validated with a thermal camera. A maximum error of 0.3 °C is reported between thermal camera and FPGA measurements. Full article

In this study, different eddy-current based probe designs (absolute and commercial reflection) are used to detect artificial defects with different sizes and at different depths in parts composed of stainless-steel (316) and titanium (TI-64) made by Laser Additive Manufacturing (LAM). The measured defect signal value using the probes is in the range of (20–200) millivolts. Both probes can detect subsurface defects on stainless-steel samples with average surface roughness of 11.6 µm and titanium samples with average surface roughness of 8.7 µm. It is found the signal reading can be improved by adding a coating layer made of thin paper to the bottom of the probes. The layer will decrease the surface roughness effect and smooth out the detected defect signal from any ripples. The smallest subsurface artificial defect size detected by both probes is an artificially made notch with 0.07 mm width and 25 mm length. In addition, both probes detected subsurface artificial blind holes in the range of 0.17 mm–0.3 mm radius. Results show that the absolute probe is more suitable to detect cracks and incomplete fusion holes, whereas the reflection probe is more suitable to detect small diameter blind holes. The setup can be used for defect detection during the additive manufacturing process once the melt pool is solidified. Full article

Brain-computer interfaces (BCI) can detect specific EEG patterns and translate them into control signals for external devices by providing people suffering from severe motor disabilities with an alternative/additional channel to communicate and interact with the outer world. Many EEG-based BCIs rely on the P300 event-related potentials, mainly because they require training times for the user relatively short and provide higher selection speed. This paper proposes a P300-based portable embedded BCI system realized through an embedded hardware platform based on FPGA (field-programmable gate array), ensuring flexibility, reliability, and high-performance features. The system acquires EEG data during user visual stimulation and processes them in a real-time way to correctly detect and recognize the EEG features. The BCI system is designed to allow to user to perform communication and domotic controls. Full article

Photoplethysmography is an extensively-used, portable, and noninvasive technique for measuring vital parameters such as heart rate, respiration rate, and blood pressure. The deployment of this technology in veterinary medicine has been hindered by the challenges in effective transmission of light presented by the thick layer of skin and fur of the animal. We propose an injectable capsule system to circumvent these limitations by accessing the subcutaneous tissue to enable reliable signal acquisition even with lower light brightness. In addition to the reduction of power usage, the injection of the capsule offers a less invasive alternative to surgical implantation. Our current prototype combines two application-specific integrated circuits (ASICs) with a microcontroller and interfaces with a commercial light emitting diode (LED) and photodetector pair. These ASICs implement a signal-conditioning analog front end circuit and a frequency-shift keying (FSK) transmitter respectively. The small footprint of the ASICs is the key in the integration of the complete system inside a 40-mm long glass tube with an inner diameter of 4 mm, which enables its injection using a custom syringe similar to the ones used with microchip implants for animal identification. The recorded data is transferred wirelessly to a computer for post-processing by means of the integrated FSK transmitter and a software-defined radio. Our optimized LED duty cycle of 0.4% at a sampling rate of 200 Hz minimizes the contribution of the LED driver (only 0.8 mW including the front-end circuitry) to the total power consumption of the system. This will allow longer recording periods between the charging cycles of the batteries, which is critical given the very limited space inside the capsule. In this work, we demonstrate the wireless operation of the injectable system with a human subject holding the sensor between the fingers and the in vivo functionality of the subcutaneous sensing on a pilot study performed on anesthetized rat subjects. Full article
