Due to its simple structure and lack of moving parts, the supersonic air ejector has been widely applied in the fields of machinery, aerospace, and energy-saving. The performance of the ejector is influenced by the flow channel structure and the velocity of the jet, thus the confined jet is an important limiting factor for the performance of the supersonic air ejector. In order to investigate the effect of the confined jet on the performance of the ejector, an air ejector with a rectangular section was designed. The effects of the section width (
Wc) on the entrainment ratio, velocity distribution, turbulent kinetic energy distribution, Mach number distribution, and vorticity distribution of the rectangular section air ejector were studied numerically. The numerical results indicated that the entrainment ratio of the rectangular section air ejector increased from 0.34 to 0.65 and the increment of the
ER was 91.2% when the section width increased from 1 mm to 10 mm. As
Wc increased, the region of the turbulent kinetic energy gradually expanded. The energy exchange between the primary fluid and the secondary fluid was mainly in the form of turbulent diffusion in the mixing chamber. In addition to
Wc limiting the fluid flow in the rectangular section air ejector, the structure size of the rectangular section air ejector in the XOY plane also had a limiting effect on the internal fluid flow. In the rectangular section air ejector, the streamwise vortices played an important role in the mixing process. The increase of
Wc would increase the distribution of the streamwise vortices in the constant-area section. Meanwhile, the distribution of the spanwise vortices would gradually decrease.
