Mechanism of Casing String Curvature Due to Displacement of Surface Strata
Abstract
:1. Introduction
2. Materials and Methods
2.1. Output Data and Problem Statement
2.2. Boundary Value Problem of String Bend
3. Results and Analysis
4. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
References
