In the early stage, many studies have been carried out on the working characteristics of the hydraulic support and coal gangue recognition. Zhang et al. [
8] studied the bearing characteristics of the hydraulic support by carrying out internal and external loading tests under different heel block contact conditions. Wang et al. [
9] completed the stress and stability analysis of the prop by applying the load to the prop of the hydraulic support. Wang et al. [
10] theoretically studied the coupling relationship of strength, stiffness and stability between the hydraulic support and surrounding rock. Ma et al. [
11] studied the displacement and stress distribution of hydraulic support by stress testing and finite element analysis. Sun et al. [
12] investigated load-bearing characters of hydraulic-powered roof support with dual telescopic legs. Xie et al. [
13] studied the load-bearing characteristics of the top beam in a full range by constructing the spatial mechanical model of the top beam separation body of the four-column support. Wang et al. [
14] established the plane mechanics model of four-column supporting shield support to study its adaptation. Ren et al. [
15] designed the 1:2 reduced-scale hydraulic support to carry out the dynamic impact test and to study the response characteristics of hydraulic support under dynamic impact load. Gao et al. [
16] added a step load to simulate the impact of the roof on the hydraulic support, so as to simulate and study the force transfer characteristics of the hydraulic support under the impact of roof pressure or coal lost gangue. Zhai et al. [
17] used Amesim to establish the impact model of the column hydraulic system of the hydraulic support composed of the force principal model, safety valve model and weight model, then studied the impact response characteristics of the column hydraulic system. Luo et al. [
18] studied the relationship between the impact force and the response speed of the hydraulic system by building the simulation model of the column hydraulic system of the hydraulic support. According to the existing research findings, one of the existing problems in the current study is that the interaction between coal gangue or the surrounding rock and the hydraulic support, or the working characteristics of the hydraulic support under dynamic load, are mainly studied by applying an equal load. The load is obtained through estimation, but the contact course between coal gangue or the surrounding rock and the support is ignored. The research scheme has a large error. The second problem existing in the current study is that there are few related researches on the interaction differences between coal gangue and the support. According to the Flores contact theory and the flexible energy absorption characteristics of the metal plate, Yang et al. [
19,
20] constructed the impact contact dynamics theoretical model between the single particle and the metal plate, the influence of impact velocity, recovery coefficient, material parameters, structure size, impact position and supporting spring stiffness on the dynamic contact response of the system was studied. However, the structural system is simple, and the study is not involved in the interaction between coal gangue and the multi-body combination hydraulic device such as the hydraulic support. Wan et al. [
21,
22] and Yang et al. [
23] took the dynamic impact contact behavior of coal gangue and the tail beam as the research object, constructed the rigid–flexible coupling contact dynamic model of coal gangue impacting the tail beam structure and the dynamic contact finite element simulation model between the coal gangue particle and the tail beam under different constraints, respectively. The influence of impact angle, impact height, impact position, particle radius and particle material on dynamic contact response of the tail beam is studied. However, only the contact between the particle and the tail beam or equivalent structure of the tail beam is constructed, and the influence of the top beam, shield beam, front and rear connecting rod of the hydraulic support on the contact behaviors is not considered. Zeng et al. [
24] established the numerical simulation model of the hydraulic support, considering the whole structure of the hydraulic support, but when studying the response of the hinge point under the condition of the single coal gangue particle impacting the hydraulic support, the contact behavior between the particles and the hydraulic support is imposed by the calculated contact force. At present, the contact response and response difference when the single coal gangue particle impact the different parts of the hydraulic support have not been studied in a reliable way. The third problem existing in current research is that some existing research carries out research on the hydraulic support by replacing the hydraulic cylinder with the equivalent spring damping module, but the spring stiffness model is not accurate. For example, Liang et al. [
25,
26] and Wan et al. [
27] establish the equivalent stiffness model of the hydraulic cylinder just with the consideration of the hydraulic oil compressibility, Liu et al. [
28] and Yang et al. [
29] only consider the elasticity of the hydraulic oil and the cylinder body to establish elastic equivalent stiffness model of the hydraulic cylinder. In fact, the elasticity of the piston rod and other structures will also affect the equivalent stiffness of the hydraulic cylinder. The fourth problem existing in current research is that although there are many related studies in the field of coal gangue recognition, the selection of effective coal gangue recognition parameters and the research of selection basis are rarely involved. Dou et al. [
30] identified coal and gangue with four kinds of working space by image analysis and Relief-SVM. Lai et al. [
31] applied the multispectral technology and two-dimensional autoencoder in their research on coal gangue recognition. Liu et al. [
32] carried on the Hilbert spectrum analysis to the vibration signal of the tail beam so as to study the coal gangue interface identification technology. Song et al. [
33] collected the vibration signal and the sound signal, and then proposed an effective minimum enclosing ball (MEB) algorithm plus the support vector machine (SVM) to coal gangue rapid detection in top coal caving. Pu et al. [
34] conducted coal gangue image identification by the convolutional neural network and transfer learning. Hou et al. [
35] established coal gangue classification system based on the difference between surface texture and gray scale characteristics, and identified coal gangue by image feature extraction and artificial neural network. Zhang et al. [
36] analyzed the distribution characteristics of natural gamma rays in roof coal and rock, established the relationship between radiation intensity and coal gangue content, and identified mixed coal and gangue by radiation signal detection. Alfarzaeai et al. [
37] studied coal gangue identification by convolutional neural networks and thermal images. Zhang et al. [
38] used infrared imager with low emissivity to improve the coal gangue recognition accuracy based on liquid intervention. Yang et al. [
39] used vibration, sound, pressure and other signals to classify and identify the mixing ratio of coal and gangue mixture. Yan et al. [
40] used multi-spectral imaging technology and YOLOv5.1 target detection method to conduct the intelligent recognition and classification of coal and gangue. Yuan et al. [
41] used six different classification methods to classify and identify coal and gangue by constructing the sample library of top coal caving sound signals. Wang et al. [
42] constructed the lightweight accurate and fast recognition model of gangue rate, developed the intelligent image acquisition system and enhanced dust removal algorithm, and realized the image identification of coal gangue in the process of coal discharging. These studies directly applied the above methods in coal gangue recognition, but did not clarify the root causes or gist of recognition parameters or method selection, and did not analyze and discuss coal gangue identifiability at the theoretical level.
In top coal caving, the large number of coal gangue particles and the distribution characteristics of drawing space lead to the contact between coal gangue and various parts of the hydraulic support. Contact behavior between coal gangue particles and the hydraulic support involves the evolution of contact state and the real-time transmission of force. Overall, due to the lack of research method that can accurately describe the whole contact process between particles and hydraulic support, the precise contact characteristics and contact difference characteristics between coal gangue and the hydraulic support are not completely clear, in particular, the contact characteristics and contact difference between coal gangue and the different parts of the hydraulic support have not been studied. As a result, the selection of coal gangue recognition media lacks the theoretical basis in the research of coal gangue recognition technology. In view of the existing problems and deficiencies in the present studies and in order to further clarify the contact response characteristics and the contact response differences law between coal gangue and the hydraulic support, this paper proposed the idea of quantitative research, and the impact contact behavior between single particle coal gangue and the hydraulic support are taken as the research target. A rigid–flexible coupling impact contact simulation model between coal gangue and the hydraulic support is proposed to study the system dynamic response. For this purpose, an accurate model of the hydraulic cylinder liquid stiffness (equivalent spring stiffness) series by five different parts stiffness is firstly established. The rigid–flexible coupling impact contact simulation model between the coal gangue particle and the hydraulic support is established by combining the mesh model of the particle and the main force transmission components of the hydraulic support as well as the multi-body rigid dynamics simulation model of the hydraulic support. On the basis of determining the contact parameters and impact modes, the contact dynamics simulation analysis will be carried out when coal gangue impacts the different components of the hydraulic support with the same height and when the same size coal/gangue impacts the same position of the hydraulic support, respectively. Impact contact response characteristics when coal gangue impacts the different parts of the hydraulic support will be studied. Through comparative analysis, the difference rule of system impact contact responses caused by the difference in the impacted component and the particle material property will be determined, so as to explore the theoretical basis for the selection of coal gangue recognition media.
