Light- and Neutron-Optical Properties of Holographic Transmission Gratings from Polymer-Ionic Liquid Composites with Submicron Grating Spacing
Abstract
:1. Introduction
2. Materials and Methods
2.1. Materials’ and Sample Preparation
2.2. Sample Characterization
3. Results
3.1. Light Diffraction Experiments
3.2. Neutron Diffraction Experiments
4. Discussion
5. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
Abbreviations
BMIMBF | 1-butyl-3-methylimidazolium tetrafluoroborate |
PEGDMA | poly-(ethylene glycol)-dimethacrylate |
PVAC | polyvinyl acetate |
Appendix A
References
