Effects of Waterlogging, Drought and Their Combination on Yield and Water-Use Efficiency of Five Hungarian Winter Wheat Varieties
Abstract
1. Introduction
2. Materials and Methods
2.1. Experimental Design
2.2. Plant Growth Conditions
2.3. Statistical Processing
3. Results
4. Discussion
5. Conclusions
Author Contributions
Funding
Conflicts of Interest
Appendix A
Parameter | Unit | Values |
---|---|---|
pH | - | 7.8 |
EC | dS·m−1 | 0.71 |
SO42− | mg·L−1 | 44 |
NH4+ | mg·L−1 | 0.30 |
COD | mg·L−1 | 0.24 |
Fe | mg·L−1 | 0.63 |
Appendix B
Assessment of Uncertainty | ||
---|---|---|
Measurement | Accuracy | Possibility of uncertainty |
Relative water content | Apparent dielectric permittivity: ±1 Ea from 1–40 cm, ±15% from 40–80 cmVWC: ±0.03 m3/m3 (±3% VWC) in mineral soils, ±0.01–0.02 m3/m3 (±1–2% VWC) in any porous medium | Small chance of error |
Plant development | Made exactly according to the instructions of Zadoks scale | To minimize errors, this measurement was taken by one person. |
Grain yield, biomass | Readability 0.1 g; accuracy 0.1 g | The measurements of these parameters were highly accurate. |
Number of the grains | Man-made | To minimize the uncertainty, counting was repeated two times by one person. |
Plant height | Made by a gauging-stick | Minor possibility of uncertainty |
Water use | Readability 5 g; accuracy 1 g ≤ x ≥ 5 g | Possibility of uncertainty between 1 and 5 grams |
Temperature of the cambers | For temperature measurements in the greenhouse chamber, sensors with accuracy of 0.1 °C were used. Temperature during the vegetation period was regulated by a standardized climatic program [28]. | The same climatic program was used for the phytotron studies. Minor possibility of uncertainty. |
Relative humidity | For the relative humidity measurements, sensors with accuracy of 1% were used. Temperature during the vegetation period was regulated by a standardized climatic program [28]. | The same climatic program was used for the phytotron studies. Minor possibility of uncertainty. |
Artificial illumination | Wavelength of the applied lamps covered PAR spectrum (380–720 nm). Artificial illumination was started at an intensity of 500 µmol·m−2·s−1 and was increased to 700 µmol·m−2·s−1 until the end of the vegetation. | The same climatic program was used for the phytotron studies. Minor possibility of uncertainty. |
CO2 concentration | CO2 sensor (TIM10) with an accuracy of 3% was installed in the chamber. When the measured value reached 450 ppm, the windows opened automatically. | Very reliable system, minor possibility of uncertainty. |
Adding of water-soluble fertilizer | Done with manual pipette (Pipet-Lite Pipette LTS L-20MLXLS, Mettler Toledo Ltd., Busapest, Hungary) Accuracy: ±0.6%/120 µL; Precision ±0.6%/32 µL | Minor possibility of uncertainty. |
References
- Pask, A.J.D.; Reynolds, M.P. Breeding for yield potential has increased deep soil water extraction capacity in irrigated wheat. Crop Sci. 2013, 53, 2090–2104. [Google Scholar] [CrossRef]
- Semenov, M.A.; Stratonovitch, P. Designing high-yielding wheat ideotypes for a changing climate. Food Energy Secur. 2013, 3, 185–360. [Google Scholar] [CrossRef]
- Wollenweber, B.; Porter, J.R.; Schellber, J. Lack of interaction between extreme high-temperature events at vegetative and reproductive growth stages in wheat. J. Agron. Crop Sci. 2003, 189, 142–150. [Google Scholar] [CrossRef]
- Liu, C.; Allan, R.P. Observed and simulated precipitation responses in wet and dry regions 1850–2100. Environ. Res. Lett. 2013, 8, 034002. [Google Scholar] [CrossRef]
- Daryanto, S.; Wang, L.; Jacinthe, P.A. Global synthesis of drought effects on cereal, legume, tuber and root crops production: A review. Agric. Water Manag. 2016, 179, 18–33. [Google Scholar] [CrossRef]
- Fahad, S.; Bajwa, A.A.; Nazir, U.; Anjum, S.A.; Farooq, A.; Zohaib, A.; Sadia, S.; Nasim, W.; Adkins, S.; Saud, S.; et al. Crop Production under Drought and Heat Stress: Plant Responses and Management Options. Front. Plant Sci. 2017, 8, 1147. [Google Scholar] [CrossRef]
- Zhang, J.; Zhang, S.; Cheng, M.; Jiang, H.; Zhang, X.; Peng, C.; Lu, X.; Zhang, M.; Jin, J. Effect on drought on agronomic traits of rice and wheat: A meta-analysis. Int. J. Environ. Res. Public Health 2018, 15, 839. [Google Scholar] [CrossRef]
- Barnabás, B.; Jäger, K.; Fehér, A. The effect of drought and heat stress on the reproductive process of cereals. Plant Cell Environ. 2008, 31, 11–38. [Google Scholar]
- Bartholy, J.; Pongrátz, R. Regional analysis of extreme temperature and precipitation indices for the Carpathian Basin from 1946 to 2001. Glob. Planet. Chang. 2007, 57, 83–95. [Google Scholar] [CrossRef]
- Jabran, K.; Ullah, E.; Hussain, M.; Farooq, M.; Zaman, U.; Yaseen, M.; Chauhan, B.S. Mulching improves water productivity, yield and quality of fine rice under water-saving rice production systems. J. Agron. Crop Sci. 2015, 201, 389–400. [Google Scholar] [CrossRef]
- Powell, N.; Ji, X.; Ravash, R.; Edlington, J.; Dolferus, R. Yield stability for cereals in a changing climate. Funct. Plant Biol. 2012, 39, 539–552. [Google Scholar] [CrossRef]
- Ding, J.; Huang, Z.; Zhu, M.; Li, C.; Zhu, X.; Guo, W. Does cyclic water stress damage wheat yield more than single stress? PLoS ONE 2018, 13, e0195535. [Google Scholar] [CrossRef] [PubMed]
- Farooq, M.; Hussain, M.; Siddique, KH. Drought stress in wheat during flowering and grain-filling periods. Crit. Rev. Plant. Sci. 2014, 33, 331–349. [Google Scholar] [CrossRef]
- Setter, T.L.; Waters, I. Review of prospects for germplasm improvement for waterlogging tolerance in wheat, barley and oats. Plant Soil 2003, 253, 1–34. [Google Scholar] [CrossRef]
- Ercoli, L.; Lulli, L.; Mariotti, M.; Masoni, A.; Arduini, I. Post-anthesis dry matter and nitrogen dynamics in durum wheat as affected by nitrogen supply and soil water availability. Eur. J. Agron. 2008, 28, 138–147. [Google Scholar] [CrossRef]
- Liu, E.K.; Mei, X.R.; Yan, C.R.; Gong, D.Z.; Zhang, Y.Q. Effects of water stress on photosynthetic characteristics, dry matter translocation and WUE in two winter wheat genotypes. Agric. Water Manag. 2016, 167, 75–85. [Google Scholar] [CrossRef]
- Setter, T.L. Farming System for Waterlogging Prone Sandplain Soils of the South Coast; Final Report of GRDC Project No DAW292; Department of Agriculture: Kensington, Australia, 2000.
- Ali, M.; Jense, C.R.; Mogensen, V.O.; Andersen, M.N.; Henson, I.E. Root signalling and osmotic adjustments during intermittent soil drying sustain grain yield of field-grown wheat. Field Crop Res. 1999, 62, 35–52. [Google Scholar] [CrossRef]
- Semenov, M.A.; Stratonovitch, P.; Alghabari, F.; Gooding, M.J. Adapting wheat in Europe for climate change. J. Cereal Sci. 2014, 59, 245–256. [Google Scholar] [CrossRef]
- Dickin, E.; Bennett, S.; Wright, D. Growth and yield responses of UK wheat cultivars to winter waterlogging. J. Agric. Sci. 2009, 174, 127–140. [Google Scholar] [CrossRef]
- Haque, E.; Oyanagi, A.; Kawaguchi, K. Aerenchyma formation in the seminal roots of Japanese wheat cultivars in relation to growth under waterlogged conditions. Plant Prod. Sci. 2012, 15, 163–173. [Google Scholar] [CrossRef]
- Yang, J.; Zahng, J.; Huang, Z.; Zhu, Q.; Wang, L. Remobilization of carbon reserves is improved by controlled soil-drying during grain filling of wheat. Crop Sci. 2000, 40, 1645–1655. [Google Scholar] [CrossRef]
- Wu, J.; Li, J.-C.; Wei, F.-Z.; Wang, C.-Y.; Zhang, Y.; Sun, G. Effects of nitrogen spraying on the post-anthesis stage of winter wheat under waterlogging stress. Acta Physiol. Plant. 2014, 36, 207–2016. [Google Scholar] [CrossRef]
- Zhang, X.; Wang, Y.; Sun, H.; Chen, S.; Shao, L. Optimizing the yield of winter wheat by regulating water consumption during vegetative and reproductive stages under limited water supply. Irrig. Sci. 2013, 31, 1103–1112. [Google Scholar] [CrossRef]
- Morell, F.J.; Lampurlanés, J.; Álvaro-Fuente, J.; Cantero-Martínez, C. Yield and water use efficiency of barley in a semiarid Mediterranean agroecosystem: Long-term effects of tillage and N fertilization. Soil Tillage Res. 2011, 117, 76–84. [Google Scholar] [CrossRef]
- Oweis, T.; Zhang, H.; Pala, M. Water use efficiency of rained and irrigated bread wheat in a Mediterranean environment. Agron. J. 2000, 92, 231–238. [Google Scholar] [CrossRef]
- Zadoks, J.C.; Chang, T.T.; Konzak, C.F. A decimal code for the growth stages of cereals. Weed Res. 1974, 14, 415–421. [Google Scholar] [CrossRef]
- Varga, B.; Vida, G.; Varga-László, E.; Bencze, S.; Veisz, O. Effect of simulating drought in various phenophases on the water use efficiency of winter wheat. J. Agron. Crop Sci. 2015, 201, 1–9. [Google Scholar] [CrossRef]
- Varga, B.; Varga-László, E.; Bencze, S.; Balla, K.; Veisz, O. Water use of winter cereals under well-watered and drought-stressed conditions. Plant Soil Environ. 2013, 59, 150–155. [Google Scholar] [CrossRef]
- Tischner, T.; Kőszegi, B.; Veisz, O. Climatic programmes used on Martonvásár phytotron most effectly in recent years. Acta. Agric. Hung. 1997, 45, 85–104. [Google Scholar]
- Akhtar, J.; Gorham, J.; Qureshi, R.H. Combined effect of salinity and hypoxia in wheat (Triticum aestivum L.) and wheat-Thinopyrum amphiloids. Plant Soil 1994, 166, 47–54. [Google Scholar] [CrossRef]
- Akhtar, I.; Nazir, N. Effect and waterlogging and drought stress in plants. Int. J. Water Res. Environ. Eng. 2013, 2, 34–40. [Google Scholar]
- de San Celedonio, R.; Abeledo, L.G.; Miralles, D.J. Identifying the critical period for waterlogging on yield and its components in wheat and barley. Plant Soil 2014, 378, 265–277. [Google Scholar] [CrossRef]
- González, J.A.; Gallardo, M.; Hilal, M.B.; Rosa, M.D.; Prado, F.E. Physiological responses of quinoa (Chenopodium quinoa Willd.) to drought and waterlogging stresses: Dry matter partitioning. Bot. Stud. 2009, 50, 35–42. [Google Scholar]
- Wollmer, A.C.; Pitann, B.; Mühling, K.H. Nutrient deficiencies do not contribute to yield loss after waterlogging events in winter wheat (Triticum aestivum). Ann. Appl. Biol. 2018, 173, 141–153. [Google Scholar] [CrossRef]
- Ghobadi, M.E.; Ghobadi, M.; Zebarjadi, A. Effect of waterlogging at different growth stages on some morphological traits of wheat varieties. Int. J. Biometeorol. 2017, 61, 635–645. [Google Scholar] [CrossRef]
- Parent, C.; Berger, A.; Folzer, H.; Dat, J.; Crevecoeur, M.; Badot, P.-M.; Capelli, N. A novel nonsymbiotic hemoglobin form oak: Cellular and tissue specificity of gene expression. New Phytol. 2008, 177, 142–154. [Google Scholar]
- Angus, J.F.; van Herwaarden, A.F. Increasing water use and water use efficiency in dryland wheat. Agron. J. 2001, 93, 290–298. [Google Scholar] [CrossRef]
- Kang, S.; Zhang, L.; Liang, Y.; Hu, X.; Cai, H.; Gu, B. Effects of limited irrigation on yield and water use efficiency of winter wheat in the Loess Plateau of China. Agric. Water Manag. 2002, 55, 203–216. [Google Scholar] [CrossRef]
- Qiu, G.Y.; Wang, L.; He, X.; Zhang, X.; Chen, S.; Chen, J.; Yang, Y. Water use efficiency and evapotranspiration of winter wheat and its response to irrigation regime in the north China plain. Agric. For. Meteorol. 2008, 148, 1848–1859. [Google Scholar] [CrossRef]
- Sun, H.-Y.; Liu, C.-M.; Zhang, X.-Y.; Shen, Y.-J.; Zhang, Y.-O. Effects of irrigation on water balance, yield and WUE of winter wheat on the North China Plain. Agric. Water Manag. 2006, 85, 211–218. [Google Scholar] [CrossRef]
- Lin, Y.; Zeng, Z.; Ren, C.; Hu, Y. Water use efficiency and physiological responses of oat under alternate partial root-zone irrigation in the semiarid areas of Northeast China. Procedia Eng. 2012, 28, 33–42. [Google Scholar]
Biomass Value (g) | Treatments | HSD 5% | |||
---|---|---|---|---|---|
C | WL | WL + D | |||
Genotypes | BKT | 80.92 Aa | 58.66 Ab | 48.54 Ab | 26.02 |
TOB | 41.72 Ca | 28.11 Cb | 22.52 Bb | 15.52 | |
MAM | 56.24 BCa | 47.54 ABa | 31.90 Bb | 19.38 | |
KAR | 63.22 Ba | 48.16 Ab | 32.61 Bc | 24.05 | |
PAL | 41.30 Ca | 33.63 BCab | 25.55 Bb | 12.38 | |
HSD 5% | 16.74 | 12.44 | 10.20 |
Thousand Kernel Weight (g) | Treatments | HSD 5% | |||
---|---|---|---|---|---|
C | WL | WL + D | |||
Genotypes | BKT | 38.72 ABa | 41.13 ABa | 39.39 Aa | 1.95 |
TOB | 38.62 ABa | 37.30 BCa | 26.09 Ab | 10.81 | |
MAM | 45.68 Aa | 44.77 Aa | 41.21 Aa | 3.71 | |
KAR | 38.04 Ba | 36.77 BCa | 36.77 Aa | 2.65 | |
PAL | 34.19 Ba | 31.48 Ca | 27.48 Aa | 5.298 | |
HSD 5% | 4.21 | 5.06 | 7.51 |
