Outcomes of Atrioseptostomy with Stenting in Patients with Pulmonary Arterial Hypertension from a Large Single-Institution Cohort
Abstract
:1. Introduction
2. Materials and Methods
2.1. Regulatory Aspects
2.2. Patient Population
2.3. Surgical Technique
2.4. Statistical Analysis
3. Results
4. Discussion
5. Conclusions
Author Contributions
Funding
Conflicts of Interest
References
- Galiè, N.; Humbert, M.; Vachiéry, J.-L.; Gibbs, S.; Lang, I.M.; Kaminski, K.A.; Simonneau, G.; Peacock, A.; Noordegraaf, A.V.; Beghetti, M.; et al. 2015 ESC/ERS Guidelines for the diagnosis and treatment of pulmonary hypertension. Eur. Hear. J. 2015, 37, 67–119. [Google Scholar] [CrossRef]
- Nihill, M.R.; O’Laughlin, M.P.; Mullins, C.E. Effects of atrial septostomy in patients with terminal cor pulmonale due to pulmonary vascular disease. Catheter. Cardiovasc. Diagn. 1991, 24, 166–172. [Google Scholar] [CrossRef]
- Kerstein, D.; Levy, P.S.; Hsu, D.; Hordof, A.J.; Gersony, W.M.; Barst, R.J. Blade Balloon Atrial Septostomy in Patients With Severe Primary Pulmonary Hypertension. Circulation 1995, 91, 2028–2035. [Google Scholar] [CrossRef] [PubMed]
- Rich, S.; Dodin, E.; McLaughlin, V.V. Usefulness of Atrial Septostomy as a Treatment for Primary Pulmonary Hypertension and Guidelines for its Application. Am. J. Cardiol. 1997, 80, 369–371. [Google Scholar] [CrossRef]
- Kurzyna, M.; Dąbrowski, M.; Bielecki, D.; Fijałkowska, A.; Pruszczyk, P.; Opolski, G.; Burakowski, J.; Florczyk, M.; Tomkowski, W.Z.; Wawrzyńska, L.; et al. Atrial Septostomy in Treatment of End-Stage Right Heart Failure in Patients With Pulmonary Hypertension. Chest 2007, 131, 977–983. [Google Scholar] [CrossRef] [PubMed]
- Sandoval, J.; Gaspar, J.; Peña, H.; Santos, L.E.; Córdova, J.; Del Valle, K.; Rodriguez, A.; Pulido, T. Effect of atrial septostomy on the survival of patients with severe pulmonary arterial hypertension. Eur. Respir. J. 2011, 38, 1343–1348. [Google Scholar] [CrossRef] [Green Version]
- Chiu, J.S.; Zuckerman, W.A.; Turner, M.E.; Richmond, M.E.; Kerstein, D.; Krishnan, U.; Torres, A.; Vincent, J.A.; Rosenzweig, E.B. Balloon atrial septostomy in pulmonary arterial hypertension: Effect on survival and associated outcomes. J. Hear. Lung Transplant. 2015, 34, 376–380. [Google Scholar] [CrossRef]
- Bauer, A.; Khalil, M.; Schmidt, D.; Bauer, J.; Esmaeili, A.; Apitz, C.; Voelkel, N.F.; Schranz, D. Creation of a restrictive atrial communication in pulmonary arterial hypertension (PAH): Effective palliation of syncope and end-stage heart failure. Pulm. Circ. 2018, 8, 1–9. [Google Scholar] [CrossRef] [Green Version]
- Micheletti, A.; Hislop, A.A.; Lammers, A.; Bonhoeffer, P.; Derrick, G.; Rees, P.; Haworth, S. Role of atrial septostomy in the treatment of children with pulmonary arterial hypertension. Heart 2006, 92, 969–972. [Google Scholar] [CrossRef] [Green Version]
- RajeshKumar, R.; Pavithran, S.; Sivakumar, K.; Vettukattil, J.J. Atrial septostomy with a predefined diameter using a novel occlutech atrial flow regulator improves symptoms and cardiac index in patients with severe pulmonary arterial hypertension. Catheter. Cardiovasc. Interv. 2017, 90, 1145–1153. [Google Scholar] [CrossRef]
- Stümper, O.; Gewillig, M.; Vettukattil, J.J.; Budts, W.; Chessa, M.; Chaudhari, M.; Wright, J.G.C. Modified technique of stent fenestration of the atrial septum. Heart 2003, 89, 1227–1230. [Google Scholar] [CrossRef]
- Prieto, L.; Latson, L.A.; Jennings, C. Atrial septostomy using a butterfly stent in a patient with severe pulmonary arterial hypertension. Catheter. Cardiovasc. Interv. 2006, 68, 642–647. [Google Scholar] [CrossRef] [PubMed]
- Troost, E.; Delcroix, M.; Gewillig, M.; Van Deyk, K.; Budts, W. A modified technique of stent fenestration of the interatrial septum improves patients with pulmonary hypertension. Catheter. Cardiovasc. Interv. 2009, 73, 173–179. [Google Scholar] [CrossRef] [PubMed]
- Roy, A.K.; Gaine, S.; Walsh, K.P. Percutaneous Atrial Septostomy with Modified Butterfly Stent and Intracardiac Echocardiographic Guidance in a Patient with Syncope and Refractory Pulmonary Arterial Hypertension. Hear. Lung Circ. 2013, 22, 668–671. [Google Scholar] [CrossRef]
- Kuhn, B.T.; Javed, U.; Armstrong, E.J.; Singh, G.D.; Smith, T.W.; Whitcomb, C.J.; Allen, R.P.; Rogers, J.H. Balloon dilation atrial septostomy for advanced pulmonary hypertension in patients on prostanoid therapy. Catheter. Cardiovasc. Interv. 2014, 85, 1066–1072. [Google Scholar] [CrossRef]
- Velazquez Martín, M.; González-Trevilla, A.A.; Lopez-Guarch, C.J.; Tejada, J.G.; Martin-Asenjo, R.; Subías, P.E. Use of Atrial Septostomy to Treat Severe Pulmonary Arterial Hypertension in Adults. Revista Española de Cardiología Engl. Ed. 2016, 69, 78–81. [Google Scholar] [CrossRef]
- Degano Iglesias, L.A.; Sabaté-Rotés, A.; Blasco, P.B.; Vernetta, A.T.; Galdó, A.M.; Brotons, D.C.A. Atrial Septostomy in Children With Pulmonary Hypertension. Revista Española de Cardiología Engl. Ed. 2019, 72, 688–691. [Google Scholar] [CrossRef]
- Rich, S.; Lam, W. Atrial septostomy as palliative therapy for refractory primary pulmonary hypertension. Am. J. Cardiol. 1983, 51, 1560–1561. [Google Scholar] [CrossRef]
- Austen, W.G.; Morrow, A.G.; Berry, W.B. EXPERIMENTAL STUDIES OF THE SURGICAL TREATMENT OF PRIMARY PULMONARY HYPERTENSION. J. Thorac. Cardiovasc. Surg. 1964, 48, 448–455. [Google Scholar] [CrossRef]
- Hopkins, W.E.; Ochoa, L.L.; Richardson, G.W.; Trulock, E.P. Comparison of the hemodynamics ans survival of adults with severe primary pulmonary hypertension or Eisenmenger syndrome. J. Heart Lung Transplant. 1996, 15, 100–105. [Google Scholar]
- D’Alonzo, G.E.; Barst, R.J.; Ayres, S.M.; Bergofsky, E.H.; Brundage, B.H.; Detre, K.M.; Fishman, A.P.; Goldring, R.M.; Groves, B.M.; Kernis, J.T.; et al. Survival in Patients with Primary Pulmonary Hypertension. Ann. Intern. Med. 1991, 115, 343–349. [Google Scholar] [CrossRef] [PubMed]
- Nootens, M.X.; Berarducci, L.A.; Kaufmann, E.; Devries, S.; Rich, S. The Prevalence and Significance of a Patent Foramen Ovale in Pulmonary Hypertension. Chest 1993, 104, 1673–1675. [Google Scholar] [CrossRef] [PubMed]
- Reichenberger, F.; Pepke-Zaba, J.; McNeil, K.; Parameshwar, J.; Shapiro, L.M. Atrial septostomy in the treatment of severe pulmonary arterial hypertension. Thorax 2003, 58, 797–800. [Google Scholar] [CrossRef] [PubMed] [Green Version]
- Lammers, A.E.; Derrick, G.; Haworth, S.G.; Bonhoeffer, P.; Yates, R.S. Efficacy and long-term patency of fenestrated amplatzer devices in children. Catheter. Cardiovasc. Interv. 2007, 70, 578–584. [Google Scholar] [CrossRef] [PubMed]
- Sandoval, J.; Gaspar, J.; Pulido, T.; Bautista, E.; Martínez-Guerra, M.L.; Zeballos, M.; Palomar, A.; Gómez, A. Graded balloon dilation atrial septostomy in severe primary pulmonary hypertension. J. Am. Coll. Cardiol. 1998, 32, 297–304. [Google Scholar] [CrossRef]
Authors | Number of Cases | Age at Intervention (Years) | Type of Stents | Perioperative/30-Day Mortality (%) | Duration of Follow-Up, Outcome, Surgical Procedures, Stent Patency |
---|---|---|---|---|---|
Stümper, O. et al. 2003 [11] | 6 | 7.5–72 | Standard stent (Johnson & Johnston P308 or P188, or Jomed 17-mm), diabolo-shaped configuration | No | Median—1.05 (max—2.1) years. One death. One heart-lung transplantation. All stents were patent. |
Prieto, L.R. et al. 2006 [12] | 1 | 32 | Palmaz-Schatz 18-mm stent (Johnson & Johnson), butterfly-shaped configuration | No | 4 months. Lung transplantation. Stent was patent. |
Troost, E. et al. 2009 [13] | 15 | 48.2 ± 20.5 | Palmaz Genesis 1910 stent (Cordis Corporation), diabolo-shaped configuration | 1 (6.5%)/2 (13%) | Medium—0.7 (max—5.9) years. Six deaths. Four lung transplantations with 2 deathsAll stents were patent. |
Roy, A.K. et al. 2013 [14] | 1 | 68 | Palmaz Genesis 10 × 29 mm peripheral stent (Cordis Corporation), butterfly-shaped configuration | No | 1 year. Stent was patent. |
Kuhn, B.T. et al. 2015 [15] | 6 | Not reported specifically for patients with PAH | 7 × 18 mm peripheral stent | No | Not reported specifically for patients with PAH. All stents were patent. |
Velazquez Martín, M et al. 2016 [16] | 1 | 64 | Palmaz Genesis 19-mm stent (Johnson & Johnson), diabolo-shaped configuration | No | 44 months. Stent was patent. |
Degano Iglesias, L.A. et al. 2019 [17] | 9 | 0.38–11.8 | Palmaz Genesis 10 × 19 mm stent, diabolo-shaped configuration | No | Median—25.85 months (including 2 patients with non-stenting techniques). Two deaths. Three lung transplantations. Stent patency is not described. |
Before AS | After AS | p Before/After AS Group 1 | p Before/After AS Group 2 | |||||
---|---|---|---|---|---|---|---|---|
Group 1 (n = 55) | Group 2 (n = 13) | P | Group 1 (n = 55) | Group 2 (n = 10) | P | |||
Age (years) | 20 (12–34) | 32 (13–37) | 0.198 | N/A | N/A | N/A | N/A | N/A |
Time from PAH diagnosis and AS (months) | 10 (5–16) | 7 (5–18) | 0.708 | N/A | N/A | N/A | N/A | N/A |
WHO functional class | 3 (3–3) | 4 (4–4) | <0.001 | 2 (2–3) | 3 (3–3) | 0.005 | <0.001 | 0.005 |
Syncope | 42 (76%) | 9 (69%) | 0.690 | 0 (0%) | 0 (0%) | 1.0 | <0.001 | <0.001 |
SaO2 at rest (%) | 97 (95–98) | 95 (94–97) | 0.059 | 91 (89–93) | 89 (88–90) | 0.010 | <0.001 | 0.024 |
6MWD (m) | 397 (334–432) | 198 (134–284) | <0.001 | 423 (388–469) | 299 (240–357) | <0.001 | <0.001 | 0.015 |
SaO2 after 6MWD test (%) | 96 (93–97) | 92 (90–93) | 0.003 | 83 (81–87) | 82 (79–82) | 0.036 | <0.001 | 0.010 |
BNP (pg/mL) | 203 (98–400) | 854 (399–1246) | 0.002 | 86 (48–134) | 217 (97–389) | 0.023 | <0.001 | 0.007 |
Echocardiography | ||||||||
RV systolic pressure (mm Hg) | 100 (90–120) | 110 (100–120) | 0.399 | 100 (90–120) | 100 (84–110) | 0.389 | 0.250 | 0.192 |
Tricuspid regurgitation | 2 (1.5–3) | 3 (2.5–3) | 0.042 | 2 (1.5–2) | 2 (1.5–2.5) | 0.512 | <0.001 | 0.027 |
Cardiac Catheterization or Intraoperative Measurement | ||||||||
RA pressure (mm Hg) | 14 (11–16) | 16 (15–19) | 0.003 | 11 (10–14) * | 14 (13–16) * | 0.008 | <0.001 | 0.002 |
LA pressure (mm Hg) | 6 (5–8) | 9 (8–11) | 0.008 | 8 (7–9) * | 11.5 (10.5–13) * | 0.001 | <0.001 | 0.002 |
Mean PA pressure (mm Hg) | 64 (54–81) | 62 (58–73) | 0.668 | 71 (61–87) * | 73 (61–83) * | 0.812 | 0.001 | 0.173 |
Mean PA pressure/Mean arterial pressure | 0.81 (0.66–1.05) | 0.78 (0.60–0.91) | 0.522 | 0.90 (0.70–1.09) * | 0.98 (0.73–1.11) * | 0.557 | 0.035 | 0.066 |
Patient Number/Time after Atrial Septostomy | Cause of Lethal Outcome |
---|---|
Group 1 (“intermediate risk”) | |
1. One year | Progressive PAH |
2. One year | Pulmonary hypertensive crisis after appendectomy |
3. One year and 8 months | Pulmonary hypertensive crisis after teeth extraction |
4. Three years and 2 months | Progressive PAH |
5. Four years and 1 months | Progressive PAH |
6. Five years | Pulmonary hypertensive crisis after cardiac catheterization |
7. Five years and 1 month | Progressive PAH |
8. Five years and 10 months | Progressive PAH |
9. Six years and 8 months | Progressive PAH |
10. Six years and 8 months | Progressive PAH |
Group 2 (“high risk”) | |
1. Second day | Repeated pulmonary hypertensive crisis |
2. Tenth day | Repeated pulmonary hypertensive crisis |
3. Twelfth day | Repeated pulmonary hypertensive crisis |
4. One year and 7 months | Progressive PAH |
5. One year and 11 months | Progressive PAH |
6. Two years and 4 months | Progressive PAH |
© 2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access article distributed under the terms and conditions of the Creative Commons Attribution (CC BY) license (http://creativecommons.org/licenses/by/4.0/).
