Molecular Re-Diagnosis with Whole-Exome Sequencing Increases the Diagnostic Yield in Patients with Non-Syndromic Retinitis Pigmentosa
by
, , , and
Anna Wawrocka
1,*,
Magdalena Socha
1,†,
Joanna Walczak-Sztulpa
1,†,
Grzegorz Koczyk
2,
Anna Skorczyk-Werner
1 and
Maciej R. Krawczyński
1,3 1
Department of Medical Genetics, Poznan University of Medical Sciences, 60-806 Poznan, Poland
2
Biometry and Bioinformatics Team, Institute of Plant Genetics, Polish Academy of Sciences, 60-479 Poznan, Poland
3
Centers for Medical Genetics GENESIS, 60-529 Poznan, Poland
*
Author to whom correspondence should be addressed.
†
These authors have contributed equally to this work.
Diagnostics 2023, 13(4), 730; https://doi.org/10.3390/diagnostics13040730
Submission received: 16 January 2023
/
Revised: 8 February 2023
/
Accepted: 13 February 2023
/
Published: 14 February 2023
(This article belongs to the Special Issue New Horizons in Retinal Diseases Diagnostics and Treatment)
Abstract
:Retinitis pigmentosa (RP) is a clinically and genetically heterogeneous group of disorders with progressive loss of photoreceptor and pigment epithelial function. Nineteen unrelated Polish probands clinically diagnosed with nonsyndromic RP were recruited to this study. We used whole-exome sequencing (WES) to identify potential pathogenic gene variants in molecularly undiagnosed RP patients, as a molecular re-diagnosis after having performed targeted NGS in the past. Targeted NGS allowed for identification of the molecular background in only 5 out of 19 patients. Fourteen patients who remained unsolved despite the targeted NGS were subjected to WES. WES revealed potentially causative variants in RP-related genes in another 12 patients. Together, NGS methods revealed the coexistence of causal variants affecting distinct RP genes in 17 out of 19 RP families, with a very high efficiency of 89%. With the improvement of NGS methods, including higher sequencing depth, broader target enrichment, and better bioinformatic analysis capabilities, the ratio of identified causal gene variants has significantly increased. Therefore, it is important to consider repeating high-throughput sequencing analysis in those patients in whom the previously performed NGS did not reveal any pathogenic variants. The study confirmed the efficiency and clinical utility of re-diagnosis with WES in molecularly undiagnosed RP patients.
1. Introduction
Retinitis pigmentosa (RP, MIM: 268,000) is a progressive and degenerative inherited retinal disorder that affects 1 in 4000 people worldwide. RP is classified as nonsyndromic; not affecting other organs or tissues; and syndromic with other neurosensory disorders, developmental abnormalities, and complex clinical phenotypes.
RP is characterized by an initial loss of rod function, resulting in defective dark adaptation and progressive loss of peripheral vision, often progressing into the central retina involving cone photoreceptors and leading to severe visual impairment or blindness. Furthermore, characteristic “bone spicules” pigment depositions in the retina, attenuation of the retinal blood vessels, and optic disc pallor are observed [1,2,3]. Phenotypic variability among individuals sharing the same genetic background is observed. Moreover, RP is a genetically heterogeneous disease and can be inherited in an autosomal dominant, autosomal recessive, or X-linked pattern. Due to genetic, allelic, and phenotypic heterogeneity, the diagnosis of RP patients can be a challenging task. Until now, mutations in at least 75 genes have been linked to nonsyndromic RP (RetNet, https://sph.uth.edu/retnet/; 10 January 2023). Molecular diagnosis is unquestionably crucial for establishing a correct clinical diagnosis in patients presenting with RP, and it is also necessary for estimating the risk of recurrence and providing reliable genetic counseling to families. Finally, it will form the basis for gene-specific therapy in the future.
A significant improvement of diagnostic yields has been gained in recent years with the use of next generation sequencing-based approaches, which are highly efficient for testing causal genetic variants and helpful in elucidating many previously unexplained causes of RP.
In this study, we implemented a WES re-diagnosis in a cohort of Polish patients affected with nonsyndromic RP, in whom a NGS diagnostic panel performed several years ago failed to identify any potentially causative variants.
2. Materials and Methods
2.1. Clinical Examination
Nineteen probands, together with 8 affected siblings with an initial diagnosis of nonsyndromic RP and 14 unaffected family members, were recruited from 19 unrelated Polish families. Within the cohort, 8 cases were familial, and 11 were sporadic. The patients underwent genetic counseling, coupled with a detailed medical history analysis. Ophthalmologic examinations, including measurement of central visual acuity, an eye fundus examination, electroretinography (ERG), and optical coherence tomography (OCT), were performed. All participants or guardians provided written informed consent and the study was approved by the Bioethics Committee at Poznan University of Medical Sciences in compliance with good clinical practice (GCP) and Polish law. All study protocols adhered to the tenets of the Declaration of Helsinki.
2.2. Molecular Analysis
Blood samples from 19 probands and 22 tested family members were obtained for genetic analysis. Genomic DNA was extracted from the peripheral blood lymphocytes using a MagCore® HF16 Automated Nucleic Acid Extractor and Genomic DNA Large Volume Whole Blood Kit (RBC Bioscience Corp., New Taipei City, Taiwan).
2.2.1. Targeted Next-Generation Sequencing
Diagnostic NGS panels associated with autosomal dominant or autosomal recessive retinitis pigmentosa, encompassing 26 and 56 genes (Supplementary Materials) respectively, were first performed in the probands, according to the expected type of inheritance. Targeted NGS of Retinitis Pigmentosa was performed at Asper Biogene (Republic of Estonia). For details see the Supplementary Material. The variant classification was established based on American College of Medical Genetics (ACMG) guidelines [4].
2.2.2. Whole-Exome Sequencing
DNA samples of patients from S6 to S19 were subjected to exome capture and high-throughput sequencing. Target enrichment was performed using a Twist Human Core Exome Kit (Twist Bioscience, San Francisco, CA, USA), and paired-end sequencing (2 × 100 bp) was carried out using Illumina NovaSeq 6000 (Illumina). A variant-discovery pipeline was built on the basis of GATK Best Practices. Variants (hg19 reference) were annotated using ANNOVAR [5] (all non-commercially available component databases as of 16 December 2020), Ensembl/VEP [6] 102.0, CADD [7], and v1.6, Exomiser v12.1.0 [8]. Frequent (AF > 0.001 in the component population bases) and/or benign variants (according to ClinVar; as of 16 December 2020) were discarded at the filtering stage. For phenotypic scoring, Phen2Gene [9] was used to rescore Exomiser results, based on Human Phenotype Ontology term HP:0000510 [10]. CNVs were analyzed manually based on a priority list, according to Phen2Gene scores.
2.2.3. Sanger Sequencing
The candidate variants identified in each patient were validated using PCR and Sanger sequencing. Furthermore, Sanger sequencing of the appropriate gene fragments was performed, in order to carry out segregation analysis and establish the inheritance mode of the altered alleles in selected families, given the availability of the relatives’ DNA samples. PCR reactions and purification of PCR products were carried out following standard protocols.
2.2.4. Quantitative Real-Time Polymerase Chain Reaction (qPCR)
Quantitative real-time polymerase chain reaction (qPCR) was performed to validate the CNVs and to narrow down their genomic coordinates. A previously described protocol was followed [11]. For details see the Supplementary Materials. For primer sequences see Table S1.
2.2.5. Breakpoint Sequencing
A series of qPCR, long-range PCR, and standard PCR amplification coupled with Sanger sequencing were utilized to establish the exact genomic coordinates of the aberrations using primers specific to the DNA fragments overlapping the 5′ and 3′ ends of the CNVs. qPCR was performed as described in the previous paragraph (additionally for details see the Supplementary Materials). The long-range PCR was performed using Ranger Mix (Bioline) following the producer’s protocol. For primer sequences see Table S2.
3. Results
3.1. Clinical Features
In the current study, we present 19 patients diagnosed with nonsyndromic RP. All probands displayed classic RP features, with loss of night vision as the first symptom of the disease, accompanied by a progressing narrowing of the visual field in the following years. The fundus examination showed retinal bone-spicule pigmentation (except for patient S16) and abnormal pallor of the optic disc in all patients. Cataract was observed in patients S3, S6, S7, S11, S12, S15, and S16. The ophthalmological findings of the patients are summarized in Table 1. The clinical features of patient S15 are presented in Figure 1.
3.2. Molecular Results
To search for variants that could be responsible for the patients’ phenotypes, we performed targeted NGS sequencing prior to this study. The NGS panel type was selected based on the expected inheritance mode for each patient individually. In each family, an analysis was performed on the index patient. Previously reported and novel variants identified in RP patients are listed in Table 2. Targeted NGS allowed confirmation of the molecular background of the disease in 5 out of 19 patients. Among them, five novel and two previously reported variants were identified in the following genes: SPATA7, CERKL, PRPF8, and PRPF31 (Table 2).
Fourteen families (from F6 to F19) who remained unsolved despite targeted NGS were subjected to WES. WES revealed potentially causative variants in RP-related genes in 12 out of 14 families, including 8 novel and 10 previously reported variants involving BBS2, USH2A, RPGR, SNRNP200, EYS, RGR, PRPF31, CEP290, NR2E3, and PRPF4 (Table 2). The analysis targeting copy number variants (CNVs) using WES data allowed for the identification of three novel heterozygous CNVs in patients S9, S12, and S15 (Figure S2). We utilized qPCR and Sanger sequencing to narrow down the genomic coordinates of all aforementioned alterations and were able to show the span and orientation of the CNVs detected in probands S5, S9, and S15 (Table 2, Figure S2). In family S9, the identified deletion of 63,759 bp (chr1:216,259,404-216,323,160; hg19) encompassing exons 22–24 of the USH2A gene (Figure S2) was combined with a novel splicing variant c.3316 + 1G > T (Figure S1). The size of the duplication identified in proband S12 was narrowed down using qPCR and its maximal size was 30,101 bp (chr6:65,134,995-65,165,095; hg19) and minimal size was 29,307 bp (chr6:65,135,261-65,164,567; hg19) (Figure S2). Patient S12 carried a heterozygous duplication of exons 27 and 28 and portion of the adjacent introns of the EYS gene, as well as a missense variant c.7654del (p.Val2552Ter) on the other allele (Figure 2 and Figure S1).
Deletions of exons 5, 6, and partly 7 in the PRPF31 gene, 1543 bp in size, were identified in familial case S15 (Figure 2) (chr19:54,625,718-54,627,260, with a ATTATCATT insertion at the breakpoint; hg19) (Figure S2). Unfortunately, the patient’s family members did not consent to participate in genetic testing. We were not successful in identifying the molecular basis of the disease in patients S10 and S16. Due to the consanguinity of the parents of patient S10, we assumed autosomal recessive inheritance of the variant but did not identify a potentially pathogenic variant in the RP genes. Based on the analysis of the pedigree of family F16, an autosomal dominant mode of inheritance of the disease was expected; however, the WES analysis failed to uncover a dominant causal variant. The only identified variant was a heterozygous deletion in the RP1L1 gene, responsible for the autosomal recessive form of the disease, which was not compatible with the history of RP in this family (Figure 2).
None of the novel variants were present in the gnomAD SVs (v2.1) (Genome Aggregation Database) and the NHLBI Exome Variant Server (EVS), and therefore, based on the ACMG guidelines, they were assessed as pathogenic or likely pathogenic variants. With the use of the two NGS diagnostic methods applied, it was possible to identify the potentially causative gene variants in 17 out of 19 patients included in this study. We identified 25 causal gene variants, of which 13 were novel. The segregation of the variants identified in familial cases is presented in Figure 2.
4. Discussion
In recent years, an increasing number of genetic determinants of retinitis pigmentosa has necessitated a drive towards the use of next-generation sequencing [12,13]. While common variants in 75 well-characterized genes have provided an explanation in some nonsyndromic cases, phenotypic variability, the overlap with other retinal disorders, and uncommon causal variants require following up with whole-exome/genome sequencing. In this context, decreasing costs and the improved quality of results, together with increasing coverage of problematic regions of the human genome facilitate a more thorough analysis [2]. For complex phenotypes with multiple underlying causes, such as RP, successful identification of causative structural variations and regulatory changes requires prioritization of clinically relevant variants coupled with phenotype ontology [13].
In this report, next generation sequencing methods revealed the coexistence of causal variants affecting distinct RP genes in 17 out of 19 RP families. Previously, using targeted NGS analysis, we had detected variants associated with the disease in only five patients from this group, whereas with the use of WES, we established the molecular background of the disease in another 12 RP patients. In the group presented, it was possible to determine the genetic basis of the disease with very high efficiency, which reached 89%. The overall diagnostic yield of 89% was distinctively higher than that presented in previous studies, where the estimated detection rate ranged from 50 to 70% [14,15,16,17]. The choice of the NGS panel in the past was carried out based on the type of inheritance of the disease expected. However, this approach may be ineffective in sporadic cases of RP, which was noticeable in the presented cohort. One issue was a different type of inheritance being identified after WES than the one suggested by the previously selected NGS panel. This instance was observed in sporadic patients S6, S7, S11, S13, S14, and the familial case S8. Furthermore, in patients S9 and S12, heterozygous variants in recessive genes were identified in the NGS panel, while the second causal variant for each patient was only found by WES. CNVs were the second alterations in both patients (Table 2). It is worth mentioning that, due to a lower coverage of targeted regions and restricted bioinformatic capabilities, the NGS panel analysis performed several years ago did not routinely include a pipeline for detection of CNVs. Patients S15 and S17 harbored mutations in genes that were not captured by gene panels and for the aforementioned reasons were only detected by means of WES.
In the presented RP cohort, in nine patients, the disease is inherited in autosomal recessive mode and in eight patients in autosomal dominant mode, while in two patients it was X chromosome-linked. The expression of RP inherited in an autosomal dominant mode is the least severe, associated with a delayed onset of symptoms and slower progression of the disease, which is in line with observations in our group of patients. The clinical features are relatively more severe in patients with X-linked variants compared to patients with other types of inheritance [18]. Affected males usually experience an early onset of symptoms and present with rapid progression, while female carriers can show great phenotypic variability, from asymptomatic to significant visual and retinal impairment, and present the first symptoms much later [19]. family F8, although the first symptoms in the affected patient S8 appeared relatively late (at 15 years of age) compared to other patients with X-linked RP, currently he presents with severely decreased visual acuity and an extremely restricted visual field (Table 2). The female carrier from the same family (I.2) experienced decreased visual acuity at the age of 30, and from the age of 60 progressive narrowing of the visual field and night blindness have also been observed. The three remaining carriers in the family (III.2, III.3, and III.4) have shown no symptoms of RP to date (Figure 2). As reported in the literature, disease expression in female carriers can be correlated with X chromosome methylation status. Even though numerous studies did not show a strong correlation between X-inactivation (XCI) and the carriers’ phenotype, retinal XCI ratios may not be accurately reflected in the most commonly tested blood DNA [20]. Variable expression of the disease in female carriers with skewed X-inactivation and overexpression of the mutant gene in the retina remains a feasible explanation.
Furthermore, in this study, we reported a case of pseudodominantly inherited autosomal recessive RP in the family F18 with co-segregating deleterious variants in the NR2E3 gene. Based on the family F18 pedigree, RP was inherited in an apparent autosomal dominant pattern (Figure 2). Targeted NGS revealed the known pathogenic homozygous variant c.481delA (p.Thr161HisfsTer18) in one patient from this family (III.3), suggesting the diagnosis of an autosomal recessive form of the disease, which was in contradiction with the observed pedigree. Segregation analysis of the variant in the family confirmed the presence of the homozygous variant in an affected brother (III.2) and indicated the clinically healthy carriers (I.2, II.4, III.1) (Figure 2). Interestingly, we also identified the same but heterozygous alteration in the patient’s affected father (II.3). Therefore, to search for another causative variant in patient S18, WES was conducted. This revealed another c.951delC (p.Thr318fs) alteration and validated the presence of the c.481delA (p.Thr161HisfsTer18) mutation in the NR2E3 gene in a compound heterozygous state (Figure S1). This finding confirmed the pseudodominant inheritance of RP in family F18. Pseudodominant inheritance of autosomal recessive diseases occurs when an affected individual (homozygous or compound heterozygous) has an unaffected partner, who is a carrier for a pathogenic variant in the same gene, and their offspring is affected by the same autosomal recessive disorder as manifested in the parent. Pseudodominant inheritance has already been documented in retinal disorders, including congenital stationary night blindness (CSNB) with alterations in the GRM6 gene [21], in patients with RP related to IMPG2 variants, or in cone-rod dystrophy and Stargardt disease with ABCA4 pathogenic variants [22,23]. Nevertheless, to our knowledge this is the first report of NR2E3 pseudodominant inheritance in retinitis pigmentosa. This finding reminds us of the importance of considering the possibility of pseudodominance in apparently autosomal dominant pedigrees of RP. It also indicates the crucial role of molecular analysis, which in some cases is the only means of correctly classifying the mode of inheritance as pseudodominant.
A heterozygous deletion encompassing the entire sequence of the PRPF31 gene was detected by targeted NGS and confirmed by qPCR in patient S5. Breakpoint analysis determined the size of the deletion as 33,998 bp (chr19:54,602,534-54,636,531; hg19). In addition to the PRPF31 gene, the detected deletion encompasses three upstream coding genes: TFPT, NDUFA3, and a portion of OSCAR. The presence of the deletion was also confirmed in the patient’s affected father using qPCR (Figure 2 and Figure S2). PRPF31 mutations are the second most common genetic cause of adRP in most populations [24]. Deletions encompassing the entire PRPF31 and upstream genes have previously been reported in RP patients [25,26,27].
In this study, we did not find disease-causing alterations in two patients (S10, S16). Possible reasons for this could be that the variants are in the noncoding regions of corresponding genes that cannot be captured by WES analysis or that they are difficult-to-identify gross deletions, insertions, or complex rearrangements. Whole-genome sequencing may be a comprehensive alternative method that could resolve these problems.
The considerable advancements in high-throughput sequencing observed in recent years have made molecular diagnosis possible for those patients in whom prior testing failed to identify the genetic basis of disease. Therefore, it is important for previously undiagnosed patients to undergo a high-throughput sequencing again. Due to the higher sequencing depth and broader target enrichment than in the NGS panels, when coupled with suitable bioinformatic analysis, WES can be sufficient to accurately identify disease-causing variants in most RP patients. In conclusion, our study confirmed the efficiency and clinical utility of re-diagnosis with whole-exome sequencing in molecularly undiagnosed patients with RP. It also showed that WES is suitable and efficient for the molecular screening of RP patients. Performing WES enabled us to establish a final diagnosis in most RP patients presented in this study and made it feasible to assess the patients’ prognosis.
Supplementary Materials
The following supporting information can be downloaded at: https://www.mdpi.com/article/10.3390/diagnostics13040730/s1, Table S1, Oligonucleotide primers used to perform copy number analysis; Table S2, qPCR, long-range and sequencing oligonucleotide primers used to establish breakpoints of the CNVs; Figure S1, Sequencing results of the variants identified in RP patients and the segregation analysis in familial RP cases; Figure S2, qPCR validation and breakpoint sequencing of the CNVs qPCR results in families F5, F9, and F15; Autosomal Dominant Retinitis Pigmentosa NGS panel; Autosomal Recessive Retinitis Pigmentosa, NGS panel; Methods.
Author Contributions
Conceptualization, A.W.; methodology, J.W.-S. and G.K.; validation, M.S., J.W.-S. and A.S.-W.; formal analysis, G.K.; investigation, A.W., M.S. and J.W.-S.; resources, A.W. and A.S.-W.; writing—original draft preparation, A.W.; writing—review and editing, M.S. and M.R.K.; visualization, A.W.; supervision, M.R.K.; project administration, A.W.; funding acquisition, A.W. All authors have read and agreed to the published version of the manuscript.
Funding
This research was funded by a grant from the National Science Center Poland nr 2019/03/X/NZ2/00547 to AW.
Institutional Review Board Statement
The study was conducted according to the guidelines of the Declaration of Helsinki and approved by the Bioethics Committee at Poznan University of Medical Sciences (nr 1038/19, 7 November 2019).
Informed Consent Statement
Informed consent was obtained from all subjects involved in the study.
Data Availability Statement
The data used in this study are available from the corresponding author upon request.
Conflicts of Interest
The authors declare no conflict of interest.
References
- Hartong, D.T.; Berson, E.L.; Dryja, T.P. Retinitis pigmentosa. Lancet 2006, 368, 1795–1809. [Google Scholar] [CrossRef] [PubMed]
- Verbakel, S.K.; van Huet, R.A.C.; Boon, C.J.F.; den Hollander, A.I.; Collin, R.W.J.; Klaver, C.C.W.; Hoyng, C.B.; Roepman, R.; Klevering, B.J. Non-syndromic retinitis pigmentosa. Prog. Retin. Eye Res. 2018, 66, 157–186. [Google Scholar] [CrossRef] [PubMed]
- Hubshman, M.W.; Broekman, S.; Van Wijk, E.; Cremers, F.; Abu-Diab, A.; Khateb, S.; Tzur, S.; Lagovsky, I.; Smirin-Yosef, P.; Sharon, D.; et al. Whole-exome sequencing reveals POC5 as a novel gene associated with autosomal recessive retinitis pigmentosa. Hum. Mol. Genet. 2018, 27, 614–624. [Google Scholar] [CrossRef] [PubMed]
- Richards, S.; Aziz, N.; Bale, S.; Bick, D.; Das, S.; Gastier-Foster, J.; Grody, W.W.; Hegde, M.; Lyon, E.; Spector, E.; et al. Standards and guidelines for the interpretation of sequence variants: A joint consensus recommendation of the American College of Medical Genetics and Genomics and the Association for Molecular Pathology. Genet. Med. 2015, 17, 405–424. [Google Scholar] [CrossRef] [PubMed]
- Yang, H.; Wang, K. Genomic variant annotation and prioritization with ANNOVAR and wANNOVAR. Nat. Protoc. 2015, 10, 1556–1566. [Google Scholar] [CrossRef]
- McLaren, W.; Gil, L.; Hunt, S.E.; Riat, H.S.; Ritchie, G.R.S.; Thormann, A.; Flicek, P.; Cunningham, F. The Ensembl Variant Effect Predictor. Genome Biol. 2016, 17, 122. [Google Scholar] [CrossRef]
- Rentzsch, P.; Schubach, M.; Shendure, J.; Kircher, M. CADD-Splice-improving genome-wide variant effect prediction using deep learning-derived splice scores. Genome Med. 2021, 13, 31. [Google Scholar] [CrossRef]
- Smedley, D.; Jacobsen, J.O.B.; Jäger, M.; Köhler, S.; Holtgrewe, M.; Schubach, M.; Siragusa, E.; Zemojtel, T.; Buske, O.J.; Washington, N.L.; et al. Next-generation diagnostics and disease-gene discovery with the Exomiser. Nat. Protoc. 2015, 10, 2004–2015. [Google Scholar] [CrossRef]
- Zhao, M.; Havrilla, J.M.; Fang, L.; Chen, Y.; Peng, J.; Liu, C.; Wu, C.; Sarmady, M.; Botas, P.; Isla, J.; et al. Phen2Gene: Rapid phenotype-driven gene prioritization for rare diseases. NAR Genom. Bioinform. 2020, 2, lqaa032. [Google Scholar] [CrossRef]
- Köhler, S.; Gargano, M.; Matentzoglu, N.; Carmody, L.C.; Lewis-Smith, D.; Vasilevsky, N.A.; Danis, D.; Balagura, G.; Baynam, G.; Brower, A.M.; et al. The Human Phenotype Ontology in 2021. Nucleic Acids Res. 2021, 49, D1207–D1217. [Google Scholar] [CrossRef]
- Sowińska-Seidler, A.; Piwecka, M.; Olech, E.; Socha, M.; Latos-Bielenska, A.; Jamsheer, A. Hyperosmia, ectrodactyly, mild intellectual disability, and other defects in a male patient with an X-linked partial microduplication and overexpression of the KAL1 gene. J. Appl. Genet. 2015, 56, 177–184. [Google Scholar] [CrossRef] [PubMed]
- Dias, M.F.; Joo, K.; Kemp, J.A.; Fialho, S.; Cunha, A.D.S.; Woo, S.J.; Kwon, Y.J. Molecular genetics and emerging therapies for retinitis pigmentosa: Basic research and clinical perspectives. Prog. Retin. Eye Res. 2018, 63, 107–131. [Google Scholar] [CrossRef]
- Pozo, M.G.-D.; Fernández-Suárez, E.; Martín-Sánchez, M.; Bravo-Gil, N.; Méndez-Vidal, C.; la Rúa, E.R.-D.; Borrego, S.; Antiñolo, G. Unmasking Retinitis Pigmentosa complex cases by a whole genome sequencing algorithm based on open-access tools: Hidden recessive inheritance and potential oligogenic variants. J. Transl. Med. 2020, 18, 73. [Google Scholar] [CrossRef] [PubMed]
- Huang, X.-F.; Huang, F.; Wu, K.-C.; Wu, J.; Chen, J.; Pang, C.-P.; Lu, F.; Qu, J.; Jin, Z.-B. Genotype-phenotype correlation and mutation spectrum in a large cohort of patients with inherited retinal dystrophy revealed by next-generation sequencing. Genet. Med. Off. J. Am. Coll. Med. Genet. 2015, 17, 271–278. [Google Scholar] [CrossRef]
- Carss, K.J.; Arno, G.; Erwood, M.; Stephens, J.; Sanchis-Juan, A.; Hull, S.; Megy, K.; Grozeva, D.; Dewhurst, E.; Malka, S.; et al. Comprehensive Rare Variant Analysis via Whole-Genome Sequencing to Determine the Molecular Pathology of Inherited Retinal Disease. Am. J. Hum. Genet. 2017, 100, 75–90. [Google Scholar] [CrossRef] [PubMed]
- Birtel, J.; Gliem, M.; Mangold, E.; Müller, P.L.; Holz, F.G.; Neuhaus, C.; Lenzner, S.; Zahnleiter, D.; Betz, C.; Eisenberger, T.; et al. Next-generation sequencing identifies unexpected genotype-phenotype correlations in patients with retinitis pigmentosa. PLoS ONE 2018, 13, e0207958. [Google Scholar] [CrossRef]
- Kim, Y.-J.; Kim, Y.-N.; Yoon, Y.-H.; Seo, E.-J.; Seo, G.-H.; Keum, C.; Lee, B.-H.; Lee, J.-Y. Diverse Genetic Landscape of Suspected Retinitis Pigmentosa in a Large Korean Cohort. Genes 2021, 12, 675. [Google Scholar] [CrossRef]
- Tsang, S.H.; Sharma, T. X-linked Retinitis Pigmentosa. Adv. Exp. Med. Biol. 2018, 1085, 31–35. [Google Scholar] [CrossRef]
- Comander, J.; Weigel-DiFranco, C.; Sandberg, M.A.; Berson, E.L. Visual Function in Carriers of X-Linked Retinitis Pigmentosa. Ophthalmology 2015, 122, 1899–1906. [Google Scholar] [CrossRef]
- Fahim, A.T.; Daiger, S.P. The Role of X-Chromosome Inactivation in Retinal Development and Disease. Adv. Exp. Med. Biol. 2016, 854, 325–331. [Google Scholar] [CrossRef]
- Liu, H.; Huang, J.; Xiao, H.; Zhang, M.; Shi, F.; Jiang, Y.; Du, H.; He, Q.; Wang, Z. Pseudodominant inheritance of autosomal recessive congenital stationary night blindness in one family with three co-segregating deleterious GRM6 variants identified by next-generation sequencing. Mol. Genet. Genom. Med. 2019, 7, e952. [Google Scholar] [CrossRef] [PubMed]
- Lee, W.; Xie, Y.; Zernant, J.; Yuan, B.; Bearelly, S.; Tsang, S.H.; Lupski, J.R.; Allikmets, R. Complex inheritance of ABCA4 disease: Four mutations in a family with multiple macular phenotypes. Hum. Genet. 2016, 135, 9–19. [Google Scholar] [CrossRef] [PubMed]
- Huckfeldt, R.M.; East, J.S.; Stone, E.M.; Sohn, E.H. Phenotypic Variation in a Family With Pseudodominant Stargardt Disease. JAMA Ophthalmol. 2016, 134, 580–583. [Google Scholar] [CrossRef]
- Martin-Merida, I.; Aguilera-Garcia, D.; Fernandez-San Jose, P.; Blanco-Kelly, F.; Zurita, O.; Almoguera, B.; Garcia-Sandoval, B.; Avila-Fernandez, A.; Arteche, A.; Minguez, P.; et al. Toward the Mutational Landscape of Autosomal Dominant Retinitis Pigmentosa: A Comprehensive Analysis of 258 Spanish Families. Investig. Ophthalmol. Vis. Sci. 2018, 59, 2345–2354. [Google Scholar] [CrossRef] [PubMed]
- Abu-Safieh, L.; Vithana, E.N.; Mantel, I.; Holder, G.E.; Pelosini, L.; Bird, A.C.; Bhattacharya, S.S. A large deletion in the adRP gene PRPF31: Evidence that haploinsufficiency is the cause of disease. Mol. Vis. 2006, 12, 384–388. [Google Scholar]
- Rose, A.M.; Mukhopadhyay, R.; Webster, A.R.; Bhattacharya, S.S.; Waseem, N.H. A 112 kb deletion in chromosome 19q13.42 leads to retinitis pigmentosa. Investig. Ophthalmol. Vis. Sci. 2011, 52, 6597–6603. [Google Scholar] [CrossRef]
- Kohn, L.M.; Bowne, S.J.; Sullivan, L.S.; Daiger, S.P.; I Burstedt, M.S.; Kadzhaev, K.; Sandgren, O.; Golovleva, I. Breakpoint characterization of a novel approximately 59 kb genomic deletion on 19q13.42 in autosomal-dominant retinitis pigmentosa with incomplete penetrance. Eur. J. Hum. Genet. 2009, 17, 651–655. [Google Scholar] [CrossRef]
Figure 1.
Clinical features of patient S15 with RP. Fundus photography of the right eye (A) and left eye (B), showing typical features of RP including optic disc pallor, attenuated retinal vessels, and mid-peripheral bone-spicule pigmentation (indicated by an arrow) (C). (D,E) Optical coherence tomography (OCT) showed thinning of the retina and loss of photoreceptors out of the fovea. In the RE visible single cystic changes in the foveola and fine epiretinal membrane in the temporal part of the macula. (F,G) Full-field electroretinogram (ERG) demonstrated residual rod and cone response amplitude. (H) Concentric narrowing (to approx. 10°) of the visual field of both eyes.
Figure 1.
Clinical features of patient S15 with RP. Fundus photography of the right eye (A) and left eye (B), showing typical features of RP including optic disc pallor, attenuated retinal vessels, and mid-peripheral bone-spicule pigmentation (indicated by an arrow) (C). (D,E) Optical coherence tomography (OCT) showed thinning of the retina and loss of photoreceptors out of the fovea. In the RE visible single cystic changes in the foveola and fine epiretinal membrane in the temporal part of the macula. (F,G) Full-field electroretinogram (ERG) demonstrated residual rod and cone response amplitude. (H) Concentric narrowing (to approx. 10°) of the visual field of both eyes.
Figure 2.
Pedigrees and segregation of the variants associated with the disease identified in familial RP cases. Genotypes are provided for all subjects available for molecular analysis. Identified pathogenic variants are placed below the pedigree. Wild-type variants are indicated with +, while disease-causing variants are indicated with V1 and V2.
Figure 2.
Pedigrees and segregation of the variants associated with the disease identified in familial RP cases. Genotypes are provided for all subjects available for molecular analysis. Identified pathogenic variants are placed below the pedigree. Wild-type variants are indicated with +, while disease-causing variants are indicated with V1 and V2.
Table 1.
Clinical symptoms of patients with RP.
| Patient ID/Family | Age Ranges/ Gender | Family History | Night Blindness/Age | Anterior Segment | Optic Nerve Pallor | Arteriolar Attenuation | Macula | Peripheral Retina | BCVA RE/LE | VF Restriction | ERG Results |
|---|---|---|---|---|---|---|---|---|---|---|---|
| S1/F1 | 20s/M | + | +/ND | − | + | + | without reflex | bone-spicule | 0.2/0.1 | ND | extinguished |
| S2/F2 | 30s/M | − | +/16 | − | + | + | without reflex, bull’s eye maculopathy | bone-spicule, “salt and pepper” | 0.7/0.8 | restricted | extinguished |
| S3/F3 | 40s/F | − | +/7 | cataract | + | + | normal | bone-spicule | 0.9/0.9 | 5–10° | extinguished |
| S4/F4 | 40s/F | + | +/childhood | − | + | + | without reflex, mild dystrophic changes | bone-spicule | 1.0/1.0 | 3–5° | ND |
| S5/F5 | 10s/F | + | +/12 | − | + | + | without reflex | bone-spicule | ND | 30° | scotopic extinguished |
| S6/F6 | 40s/M | − | +/20 | cataract | + | + | without reflex | bone-spicule | 0.5/0.5 | restricted | extinguished |
| S7/F7 | 60s/F | − | +/childhood | cataract | + | + | normal | bone-spicule | 1.0/0.6 | <10° | ND |
| S8/F8 | 40s/M | + | +/15 | − | + | + | hyperpigmentation | bone-spicule | 0.2/0.1 | <10° | scotopic extinguished, fotopic <10% |
| S9/F9 | 30s/F | − | +/21 | − | + | + | without reflex | bone-spicule | ND | 10° | extinguished |
| S10/F10 | 30s/M | − | +/- | − | + | + | normal | bone-spicule | 1.0/1.0 | 15° | residual |
| S11/F11 | 50s/M | − | +/30 | cataract | + | + | Hyperpigmentation, ERM | bone-spicule | 0.15/0.1 | 10° | diminished |
| S12/F12 | 40s/F | + | +/15 | cataract | + | + | without reflex | bone-spicule | 0.1/0.1 | <10° | residual |
| S13/F13 | 40s/M | − | +/40 | − | + | − | CME | hyperpigmentation | 1.0/1.0 | 10° | residual |
| S14/F14 | 30s/M | − | +/childhood | − | + | + | macular degeneration, CME | bone-spicule | 0.6/0.8 | 10–15° | residual |
| S15/F15 | 30s/F | + | +/6 | cataract | + | + | without reflex | bone-spicule | 0.2/0.2 | 10° | residual |
| S16/F16 | 10s/F | + | +/childhood | cataract | + | + | normal | no changes | 1.0/1.0 | 30° | ND |
| S17/F17 | 20s/M | − | +/7 | − | + | + | without reflex | bone-spicule | 0.2/0.2 | 10° | residual |
| S18/F18 | 40s/M | + | +/early childhood | − | + | + | normal | bone-spicule | 1.0/1.0 | restricted | residual |
| S19/F19 | 30s/F | − | +/20 | − | + | + | without reflex | bone-spicule | 0.9/0.7 | <10° | diminished |
BCVA—best-corrected visual acuity. RE—right eye. LE—left eye. M—male. F—female. VF—visual field. ND—no data.
Table 2.
Pathogenic DNA variants identified in RP patients.
| Patient/Family | Mode of Inheritance | Gene | Transcript | Variant Classification | Pathogenicity Prediction in Protein Level | ACMG Classification | Molecular Method of Searching the Variants | |||
|---|---|---|---|---|---|---|---|---|---|---|
| Nucleotide | Protein | SIFT | PolyPhen-2 | CADD | ||||||
| S1/F1 | AR | SPATA7 | NM_018418.5 | c.19G>T c.889_890del | p.Val7Phe p.Asp297PhefsX10 | D - | PD - | - - | Pathogenic Pathogenic | NGS panel |
| S2/F2 | AR | CERKL | NM_201548.5 | c.397_401del c.1222G>T | p.Leu133GlufsX5 p.Gly408X | - - | - - | - - | Pathogenic Likely pathogenic | NGS panel |
| S3/F3 | AD | PRPF8 | NM_006445.4 | c.6974_6985del | p.Val2325_Ala2328del | - | - | - | Likely pathogenic | NGS panel |
| S4/F4 | AD | PRPF31 | NM_015629.4 | c.1040delT | p.Leu347ArgfsX16 | - | - | - | Pathogenic | NGS panel |
| S5/F5 | AD | PRPF31 | NM_015629.4 | heterozygous deletion chr19:54,606,405-54,637,153 | - | - | - | - | NGS panel | |
| S6/F6 | AR | BBS2 | NM_031885.4 | c.815G>A c.653G>A | p.Arg272Gln p.Gly218Asp | D D | PD PD | D LD | Pathogenic Pathogenic | WES |
| S7/F7 | AR | USH2A | NM_206933.3 | c.14926G>A c.292A>C | p.Gly4976Ser p.Thr98Pro | D B | PD PD | LD - | Pathogenic Pathogenic | WES |
| S8/F8 | X-linked | RPGR | NM_001034853.2 | c.2340_2341del | p.Arg780SerfsTer54 | - | - | LD | Pathogenic | WES |
| S9/F9 | AR | USH2A | NM_206933.3 | c.3316+1G>T heterozygous deletion c.(4627+1_4628-1)_(4978+1_4979-1)del | - - | - - | - - | - - | Pathogenic - | WES |
| S11/F11 | AD | SNRNP200 | NM_014014.5 | c.1671+19C>A | - | - | - | - | - | WES |
| S12/F12 | AR | EYS | NM_001292009.1 | c.7654del heterozygous duplication c.(2732+1_2733-1)_(6078+1_6079-1)dup | p.Val2552Ter - | - - | - - | D - | Pathogenic - | WES |
| S13/F13 | AD | RGR | NM_002921 | c.806A>G | p.Tyr269Cys | D | PD | LD | Pathogenic | WES |
| S14/F14 | X-linked | RPGR | NM_001034853.2 | c.1070G>A | p.Gly357Asp | LD | PD | LD | Likely pathogenic | WES |
| S15/F15 | AD | PRPF31 | NM_015629.4 | heterozygous deletion c.(420+1_421-1)_(697+1_698-1)del | - | - | - | - | - | WES |
| S17/F17 | AR | CEP290 | NM_025114.4 | c.1984C>T c.223A>G | p.Gln662X p.Lys75Glu | - B | - LD | D D | Pathogenic Uncertain significance | WES |
| S18/F18 | AR | NR2E3 | NM_014249.4 | c.481delA c.951delC | p.Thr161HisfsTer18 p.Thr318fs | - - | - - | - - | Pathogenic Pathogenic | WES |
| S19/F19 | AD | PRPF4 | NM_004697.4 | c.1331C>T | p.Thr444Ile | D | D | LD | Benign | WES |
WES—whole-exome sequencing, D—damaging, PD—probably damaging, LD—likely damaging, B—benign. American College of Medical Genetics (ACMG) classification was obtained through the Varsome online available tool. Human Genome Variation Society (HGVS) nomenclature have been used. New variants identified in this study are in bold.
