Article

Laboratory Exploration of Several Potential Biocontrol Methods Against the Ambrosia Beetle, Euwallacea interjectus

by
Jialin Liu
1,
Nan Jiang
1,
Haiming Gao
2,
Shengchang Lai
1,
Yang Zhou
1,
Dejun Hao
1 and
Lulu Dai
1,*
1
Co-Innovation Center for Sustainable Forestry in Southern China, College of Forestry, Nanjing Forestry University, Nanjing 210036, China
2
College of Forestry and Horticulture, Xinjiang Agricultural University, Urumqi 830052, China
*
Author to whom correspondence should be addressed.
Insects 2025, 16(1), 56; https://doi.org/10.3390/insects16010056
Submission received: 6 December 2024 / Revised: 28 December 2024 / Accepted: 8 January 2025 / Published: 9 January 2025
(This article belongs to the Section Insect Pest and Vector Management)
Browse Figures
Review Reports Versions Notes

Simple Summary

The ambrosia beetle Euwallacea interjectus, a pest of economic tree species, has caused significant damage to Chinese poplar plantations since 2020, aided by its symbiosis with Fusarium populicola. Current control relies on tree removal and chemicals, with limited biological control options. This study evaluated several potential biocontrol agents, including Beauveria bassiana, Serratia marcescens, and its metabolite prodigiosin, and the ectoparasitic mites Pyemotes moseri and P. zhonghuajia. While these agents showed promise in laboratory tests, further investigation is needed for field application.

Abstract

The ambrosia beetle Euwallacea interjectus Blandford (Coleoptera: Curculionidae: Scolytinae) has recently emerged as a pest in Chinese poplar plantations, causing significant economic losses through damage to host trees in association with its mutualistic fungus Fusarium populicola. This study evaluated the biocontrol potential of Beauveria bassiana strain B-BB-1, Serratia marcescens strain B-SM-1, its metabolite prodigiosin, and two ectoparasitic mites, Pyemotes moseri and Pyemotes zhonghuajia. B. bassiana exhibited significant lethality toward adult female E. interjectus, reduced offspring production, and inhibited F. populicola growth. S. marcescens and prodigiosin had certain lethal effects on larvae and inhibited the growth of F. populicola. Both mites effectively parasitized beetle pupae and larvae, with no significant differences in efficacy between the two species. These agents demonstrate promise for the biological control of E. interjectus, offering insights for managing ambrosia beetle infestations.

1. Introduction

Euwallacea interjectus Blandford (Coleoptera: Curculionidae: Scolytinae) is a fungus-feeding ambrosia beetle that carries mutualistic fungi in specialized mycangia, cultivating them as food within tree xylem [1,2]. These fungi, primarily Fusarium species, are pathogenic to trees, causing wilt diseases and, along with the beetles, obstructing vascular tissues, which gradually kills the host tree [2,3,4]. E. interjectus is found across 14 Chinese provinces and in the United States, Japan, Argentina, Thailand, Malaysia, and Bangladesh [5,6,7,8,9]. It damages economically important trees, such as poplars in water-stressed regions of Argentina and Acer negundo in Florida [6,8]. In Japan, it also vectors Ceratocystis ficicola, a fig wilt pathogen [9]. Recent outbreaks in China’s Shanghai and Jiangsu Provinces have devastated over 1500 hectares of poplar stands, killing tens of thousands of trees and threatening local poplar industries [5,10].
The current integrated management of ambrosia beetles includes cultural, chemical, and biological control, as well as the use of semiochemicals [11]. Biological control primarily employs entomopathogenic fungi, such as Beauveria bassiana and Metarhizium anisopliae, which reduce beetle survival and reproduction in laboratory settings while producing spores to spread infections. Other fungi, such as Isaria fumosorosea and Aspergillus flavus, also show strong pathogenicity [12,13]. Research on entomopathogenic bacteria is limited, but Serratia marcescens has demonstrated insecticidal properties and produces prodigiosin, a compound with potential applications in biological control [14,15]. Antagonistic microorganisms, such as Trichoderma spp. and Bacillus subtilis, are being studied for their ability to control beetles and disrupt their symbiotic relationships, although further research is needed to confirm these effects [16,17].
Additionally, Pyemotes mites (Acariformes: Pyemotidae) are widely distributed ectoparasites, with several species recognized as natural enemies of bark beetles, such as Pyemotes moseri, P. dryas, and P. johnmoseri [18,19,20]. P. zhonghuajia and P. moseri, both of which were discovered in China [19,21], paralyze and kill their hosts by releasing toxins and then feed on the host’s hemolymph [22]. The opisthosoma of female mites gradually enlarges, producing the next generation of mites. Pyemotes mites may also act as vectors for biocontrol fungi, supporting integrated pest management, although their effectiveness against ambrosia beetles requires further investigation [23,24].
To investigate the potential of various biological control agents against the ambrosia beetle E. interjectus and its mutualistic fungus, we assessed the efficacy of B. bassiana strain B-BB-1, S. marcescens strain B-SM-1, the prodigiosin crude extract, and the parasitoids P. zhonghuajia and P. moseri. Our evaluation focused on their toxicity, antagonistic interactions, and biocontrol potential. This research provides insights into the biocontrol effects of these agents on E. interjectus and serves as a reference for their application in managing ambrosia beetles.

2. Materials and Methods

2.1. Beetle, Strain, and Mite Sources

Euwallacea interjectus were collected from poplar trees within Huanghai National Forest Park in Dongtai City, Jiangsu Province, China (120°50′38″ E, 32°52′43″ N). The beetles were reared on an artificial diet at 25 ± 3 °C, and individuals at different life stages were collected. The artificial diet comprised 250–280 g oven-dried Populus sawdust, 10 g each of yeast, casein, and soluble starch, 20 g sucrose, 40 g agar, and 1 L distilled water. The diet preparation and beetle rearing followed Zheng et al. [25].
Fusarium populicola was isolated from the mycangia and the inner walls of the galleries of E. interjectus, which has been identified as a Fusarium mutualist and stored in our laboratory [1]. Beauveria bassiana strain B-BB-1 was isolated from naturally diseased and deceased adult female E. interjectus. Serratia marcescens strain B-SM-1 was isolated from diseased and deceased larvae of E. interjectus. Furthermore, the isolates of these two strains were deposited in the China Center for Type Culture Collection (CCTCC) for further study with CCTCC No. M2023270 (B-BB-1) and M2023245 (B-SM-1).
Pyemotes zhonghuajia and P. moseri were sourced from Beijing ShanFeng Biotechnology Co., Ltd. (Beijing, China) They were propagated in a 28 °C incubator under dark conditions using Tenebrio molitor pupae as hosts and were subsequently used in the experiments.

2.2. Bioassays of B. bassiana and S. marcescens

Since the larvae of E. interjectus remain hidden deep within the tunnels before pupation, the spores of B. bassiana sprayed on the surface are unlikely to reach the tunnels. Therefore, the application of B. bassiana is timed to target the short flight period following the emergence of female adults. The main objective is to investigate whether the infected female adults can die before producing offspring. As a result, the test of B. bassiana was conducted only on female adults.
Similarly, regarding S. marcescens, unlike the surface-penetrating infection mechanism of fungi, insect pathogenic bacteria typically infect insects through ingestion via the digestive tract. In actual rearing conditions, most infected individuals are larvae and pupae. For the flying female adults, no significant effects of S. marcescens infection were observed. Therefore, the test for S. marcescens was conducted only on larvae.

2.2.1. Bioassay of B. bassiana Strain B-BB-1

  • Petri dish experiments: B. bassiana conidia were suspended in sterile water with 0.1% Tween 80 to prepare concentrations of 105, 106, 107, and 108 viable spores/mL. The steps for the production of B. bassiana conidia are shown in the Supplementary Material Supporting text. Female E. interjectus adults were immersed in these suspensions or the control solution (Tween 80 alone) for 30 s, dried, and transferred to Petri dishes lined with moist sterile filter paper (10 beetles per dish, 6 replicates per concentration). The dishes were incubated at 25–28 °C, and survival was monitored daily. Dead beetles were incubated separately to confirm fungal infection. Mortality was corrected using Abbott’s formula [26].
  • Artificial diet experiments: Treated beetles (106 to 108 viable spores/mL or control) were individually placed in 50 mL tubes containing 20 mL of artificial diet (30 replicates/treatment). The reason for treating the beetles with spores instead of the diet is that the high temperature during diet preparation could inactivate the spores. Additionally, the artificial diet is compacted in the tube with a paraffin-sealed surface, making it difficult for spores to penetrate and evenly distribute throughout the diet. After 20 days at 28 °C, the diet was dissected to evaluate parent beetle survival and offspring production. This approach was used as a preliminary model for Populus wood segments, as the artificial diet is easier to dissect for initial assessment.
  • Poplar log experiments: Poplar logs were inoculated with female E. interjectus treated with spore powder or spore suspension, along with untreated controls (details in the Supplementary Material). Each log was inoculated with at least 30 beetles, with a minimum of 10 beetles per treatment, and the experiment was replicated across three logs (Figures S1a,b and S2). Every 2 days, the expelled sawdust was collected, dried, and weighed to assess beetle activity and survival. After 10 days, the logs were dissected to determine beetle survival rates and offspring production.

2.2.2. Bioassay of S. marcescens Strain B-SM-1

PDA plates colonized by F. populicola were sprayed with five tenfold dilutions of S. marcescens broth or sterile water (control). Second- and third-instar E. interjectus larvae (10 per plate, 3 replicates per treatment) were introduced to the plates and incubated at 25–28 °C. Larval survival was recorded daily, and dead larvae were removed. Details are provided in the Supplementary Materials.

2.3. In Vitro Antagonism of F. populicola by B. bassiana and S. marcescens

The antagonistic effects of B. bassiana and S. marcescens on F. populicola were assessed using dual-culture assays on PDA plates. For B. bassiana, the mycelial plugs of each fungus were coinoculated or used individually as controls, and colony growth and inhibition zones were measured. For S. marcescens, bacterial streaks were paired with F. populicola plugs on PDA plates with similar controls and measurements [16]. The plates were incubated at 28 °C in darkness, and the growth inhibition percentages were calculated [27]. The detailed procedures are provided in the Supplementary Materials.

2.4. Toxicity and Antifungal Effects of Prodigiosin Crude Extract (PCE)

To evaluate the toxicity of PCE to E. interjectus, PDA plates colonized by F. populicola were treated with PCE solution at different concentrations (100%, 10%, 1%, and 0.1%) or sterile water as a control. Ten larvae were introduced per plate, with three replicates per treatment. Larval survival was recorded daily.
For antifungal effects, PDA plates containing 0.1%, 0.2%, and 1% PCE were prepared, with untreated plates serving as controls. F. populicola plugs were inoculated at the center, and colony diameters were periodically measured to assess inhibition. Details are provided in the Supplementary Materials.

2.5. Preference, Life Cycle, and Parasitism of Pyemotes Species on E. interjectus

For host preference, E. interjectus adults, pupae, and larvae were exposed to Pyemotes species in sealed 6 cm Petri dishes, and mortality, mite attachment, and opisthosoma condition were recorded daily.
To study the mites’ life cycle, parasitized pupae were placed on filter paper discs in sticky traps, ensuring that all offspring mites were captured. After incubation, offspring were counted using microscopy and ImageJ software (ver. 1.51j8).
For parasitism, E. interjectus larvae on F. populicola-colonized plates were exposed to Pyemotes species, and larval survival, mite attachment, and opisthosoma development were monitored daily. Details are provided in the Supplementary Materials.

2.6. Statistical Analysis

For bioassays assessing the effects of B. bassiana, S. marcescens, and PCE on E. interjectus on Petri dishes and mutualistic fungus plates, survival curves were analyzed using the Kaplan–Meier method with log-rank tests and Bonferroni-corrected pairwise comparisons (p < 0.05). In assays involving B. bassiana on artificial diets and in poplar logs, survival rates and offspring production under different treatments were compared using chi-square tests and Bonferroni adjustments.
Data not meeting normality or homogeneity of variance assumptions, including offspring production in artificial diets, the dry weight of expelled sawdust from logs, and the relative quantity of Pyemotes species on E. interjectus developmental stages, were analyzed using the Kruskal–Wallis test, followed by Dunn–Bonferroni pairwise comparisons. For the antagonistic effects of B. bassiana and S. marcescens against F. populicola, the antifungal efficacy of PCE, and differences in the results between the two Pyemotes species, independent-sample t-tests were applied, as these data were normally distributed.
All the data, except for the log-rank test, which was completed with Origin 2022 (OriginLab Corporation, Northampton, MA, USA), were analyzed using SPSS 26 (IBM Corporation, Armonk, NY, USA). The figures were plotted with Origin 2022 (OriginLab Corporation, Northampton, MA, USA).

3. Results

3.1. Lethal Effect of B. bassiana and S. marcescens to E. interjectus

3.1.1. Lethal Effect of B. bassiana to E. interjectus

The results of the Petri dish experiment indicated that the survival curves of E. interjectus differed markedly following exposure to different concentrations of B. bassiana spore suspensions (Figure 1a). Statistical significance among the groups was confirmed by the log-rank test (χ2 = 131.45, df = 4, p < 0.001). The pairwise comparison results revealed that, except for the 105 spores/mL treatment, which did not differ significantly from the control (χ2 = 0.28, df = 1, p > 0.05), all the other treatments presented significant differences from the control. Overall, mortality increased with increasing spore concentration. However, no significant difference was observed between the 107 and 108 spores/mL treatments (χ2 = 6.40, df = 1, p > 0.05), indicating that concentrations above 107 spores/mL were sufficient to achieve effective results.
After 20 days, dissection of the artificial diets revealed that female survival in the 106 spores/mL treatment group was 36.67 ± 8.80% (n = 30), which was significantly lower than that in the control group (83.33 ± 6.80%; n = 30). The 107 and 108 spores/mL treatments resulted in complete mortality (Table 1). These results corroborate the findings from the Petri dish experiments. Although the 107 spores/mL treatment was lethal, 23.33 ± 7.72% (n = 30) of the females still produced offspring, with some exceeding 30. Conversely, the 108 spores/mL treatment limited reproduction, with only 3.33 ± 3.28% (n = 30) producing fewer than 10 offspring, indicating superior efficacy (Table 1, Figure 1b).
Dry weight measurements of the sawdust expelled by the beetles revealed that most beetles in the control group remained active, with only a brief plateau period between 4 and 6 days, and continued to expel sawdust throughout the experiment. In contrast, the beetles in the two treatment groups experienced negligible sawdust expulsion after the fourth day, suggesting that they were either nearly dead or had died by this time (Figure 1c). This finding matched the timing of mass mortality observed in the Petri dish experiments. To confirm the survival status of the beetles, the logs infested for 10 days were split open, revealing a survival rate of 71.08 ± 7.77% (n = 39) for the control group females, whereas no females survived in the two treatment groups, indicating a significant lethal effect of the B. bassiana treatment (chi-square test, p < 0.001). Among the treated beetles, 44.18 ± 11.78% (n = 42) and 75.08 ± 6.45% (n = 44) emerged and died at the bottoms of the collection tubes (spore suspension and powder, respectively), with others found blocking gallery entrances (Figure S1c,d).

3.1.2. Lethal Effect of S. marcescens to E. interjectus

Using the plate spreading method, the highest treatment concentration was determined to be approximately 1.6 × 109 cfu/mL. The survival curves of E. interjectus larvae treated with varying concentrations substantially overlapped, with no distinct mortality peaks (Figure 2a). Log-rank tests revealed statistically significant differences between groups (χ2 = 25.45, df = 5, p < 0.001). The pairwise comparison results indicated that there were no significant differences among all the treatments (p > 0.05), and even the second-highest concentration treatment (1.6 × 108 cfu/mL) resulted in no significant difference compared with the control (χ2 = 8.00, df = 1, p > 0.05). S. marcescens showed a generally moderate and inconsistent lethal effect but caused larval mortality (Figure 2b), with some larvae ingesting sufficient bacteria to result in death only after pupation (Figure 2c).

3.2. The Antagonistic Effects of B. bassiana and S. marcescens on F. populicola

3.2.1. B. bassiana Versus F. populicola

A continuous recording of the radius of each colony revealed that from day 7 onward, the growth of F. populicola on competition plates was significantly inhibited (t = 5.515, df = 10, p < 0.001), with a growth inhibition percentage of 11.06%. This inhibition occurred before the mycelia of the two fungi were in contact. In contrast, B. bassiana showed no significant inhibition until day 10, at which point a more pronounced inhibitory effect was observed (t = 2.391, df = 10, p = 0.038), with a growth inhibition percentage of 17.90%. By this time, the percentage of growth inhibition for F. populicola had reached 34.95%. The width of the inhibition zone between the two mycelia was 8.00 ± 0.34 mm (n = 6), which was often accompanied by dark pigmentation along the edge of the F. populicola colony (Figure 3b).

3.2.2. S. marcescens Versus F. populicola

Commencing on the third day, the colony radius of F. populicola on the competition plates was significantly different from that of the control group (t = 11.578, df = 9, p < 0.001), with a growth inhibition percentage of 22.10%. Mycelial growth continued to be significantly inhibited but never ceased, maintaining a stable inhibition percentage and making contact with S. marcescens colonies on the fifth day (Figure 4b). No formation of inhibition zones between the two species was noted, nor was any pigmentation detected. F. populicola was able to grow through the S. marcescens colony, whereas the latter permeated the interstices of the former’s mycelium.

3.3. Toxicity and Antifungal Effects of PCE

Larvae reared on F. populicola plates treated with varying concentrations of PCE presented distinct survival curves (Figure 5a). The results of the Kaplan–Meier log-rank test indicated significant differences between groups (χ2 = 190.58, df = 4, p < 0.001). The larvae in the 100% PCE treatment group reached a corrected mortality rate of 86.11 ± 8.18% (n = 36) within 24 h, with complete mortality observed by 48 h, demonstrating the highly toxic effects of high concentrations of PCE on the larvae. In contrast, the 10% PCE treatment group had a corrected mortality rate of only 2.53 ± 6.16% (n = 36) after 24 h, increasing to 36.11 ± 14.87% after 48 h.
The measurement of colony diameter revealed that F. populicola in the three treatment groups was continuously suppressed throughout the experimental period. The presence of PCE had a pronounced inhibitory effect on the growth of F. populicola, with increased efficacy observed at higher concentrations. Even the treatment group with a mere 0.1% PCE concentration demonstrated a significant inhibition percentage of 21.40% on day 5, with the colony diameter substantially reduced compared with that of the control (t = 24.872, df = 17, p < 0.001). In contrast, the 1% PCE treatment group achieved an inhibition percentage of 52.23% at this time, which was also significantly lower than that of the control (t = 4.671, df = 12.236, p < 0.001) (Figure 5b).

3.4. Preferences of the Two Pyemotes Species at Different Stages of E. interjectus Development

Due to the uncontrollable release of mites, there were apparent differences in total mite counts across groups, so relative distributions were utilized in lieu of absolute numbers for comparative purposes. The patterns of the relative distributions of P. moseri and P. zhonghuajia across different developmental stages of E. interjectus exhibited broadly similar trends (Figure 6). After 24 h, the predominant distribution of mites was observed on the larvae and pupae, with a slightly lower number on the larvae than on the pupae. Starting on the second day, some larval carcasses began to show signs of dehydration and shrinkage or infection, and the mites on their surfaces started to disperse. Overall, compared with larvae and adults, beetle pupae have advantages such as reduced water loss, being cleaner and less prone to microbial contamination, lack of a hard exoskeleton, a larger surface area, and higher nutrient content, making them easier to parasitize. Consequently, the two Pyemotes species showed a preference for pupae, where their opisthosomata developed best and in the greatest numbers (Table 2).

3.5. Life Cycles of the Two Pyemotes Species in the Parasitization of E. interjectus

Continuous observation and photographic documentation revealed that the life cycles of the two Pyemotes species were largely consistent (Figure 7). After 1 day, the pupae were densely covered with mites, at which time the majority of the mites’ opisthosomata had not yet initiated development. By the second day, the opisthosomata of most mites had begun to develop and expand. On the third day, the opisthosomata had attained their final size. Between days 6 and 7, mature male offspring began emerging and remained around the mother’s genital opening. After the seventh day, the female offspring began to appear, mating with the males before disseminating to seek new hosts. The mother’s opisthosoma started to cave in and rupture, with the dissemination process capable of lasting for more than a week. By counting the disseminated offspring mites, no significant differences were noted between the two Pyemotes species with respect to the number of opisthosomata formed on individual female pupae of E. interjectus, the number of offspring produced, or the average number of offspring per opisthosoma (Table 3).

3.6. Parasitism of Two Pyemotes Species on E. interjectus

Both P. moseri and P. zhonghuajia successfully located and parasitized E. interjectus larvae on mutualistic fungus plates, with 90 ± 5.00% (n = 40) and 90 ± 3.53% (n = 40) of the larvae infested within one day, resulting in 100% mortality, even if there was only one mite on their surface. However, by day three, larval carcasses were fully colonized by bacteria or fungi, leading to mite death and incomplete opisthosomata development, preventing either species from completing their life cycle (Figure S3).

4. Discussion

As one of the most widely used entomopathogenic fungi, Beauveria bassiana has been reported to effectively kill numerous species of beetles in Scolytinae, such as Dendroctonus ponderosae, Dendroctonus rufipennis, Xylosandrus germanus, Xyleborus affinis, and Xylosandrus crassiusculus. It has been shown to effectively kill these beetles and potentially inhibit the growth of mutualistic fungi within beetle tunnels, thereby slowing the population growth of these ambrosia beetles [28,29,30]. In this study, B. bassiana demonstrated a significant lethal effect on female adults of Euwallacea interjectus. These findings suggest the potential of B. bassiana as a biocontrol agent against E. interjectus, which aligns with previous reports on other beetle species [31,32]. Additionally, confrontation assays on plates revealed that B. bassiana could inhibit the growth of F. populicola, which is consistent with the findings of Prabhukarthikeyan et al. [33], potentially disrupting the mutualistic relationship between beetles and their fungi, thereby affecting offspring development [16].
Serratia marcescens is a common bacterium with known pathogenicity against insects such as Phyllophaga blanchardi and Curculio dieckmanni [15,34]. However, reports linking S. marcescens to Scolytinae beetles are limited and involve species such as Hylurgus ligniperda, Dendroctonus frontalis, and Platypus quercivorus [35,36,37]. In this study, S. marcescens had weak and inconsistent lethal effects on E. interjectus larvae, likely due to its low virulence. Several factors may also have contributed to these variations. First, uneven colonization of the mutualistic fungus on the plates or larval feeding behavior could lead to areas with thinner hyphae. Due to the rapid growth of S. marcescens, droplets of bacterial colonies may form in these areas, which larvae can pick up, disrupting the intended concentration gradient and causing significant variation between replicates. Additionally, the relatively short larval stage may have led to some larvae pupating during the experiment, which could affect feeding behavior and result in variability in bacterial intake. Moreover, observed cannibalism among larvae, where weaker or dead larvae are consumed, may facilitate the spread of S. marcescens between individuals.
Despite some studies indicating that S. marcescens can inhibit Fusarium species by producing chitinase, which degrades fungal cell walls [38], our plate confrontation assays revealed no inhibition zones between S. marcescens and F. populicola, with F. populicola even growing through bacterial colonies. This could be due to the use of a PDA medium, which favors fungal growth. Alternatively, the inhibitory capacity of S. marcescens against F. populicola might be inherently weak, with the reduced diameter of F. populicola potentially attributable to nutrient competition on the plate.
As a key metabolite of S. marcescens, prodigiosin has been reported to have insecticidal and antifungal activities, such as reducing the survival and pupation rates of Aedes aegypti and inhibiting oviposition and egg hatching in Diaphorina citri [39,40]. It also inhibits several plant pathogenic fungi, such as Colletotrichum spp., Pythium myriotylum, and Rhizoctonia solani [41,42,43]. Despite the limited purity of the prodigiosin extracted in our experiments due to constraints in preparation techniques, the crude extract showed significant toxicity to E. interjectus larvae and strong inhibition of F. populicola, highlighting its potential in biological control.
Although these entomopathogenic microorganisms have shown promising results under laboratory conditions, replicating such success in the field remains challenging due to various environmental factors and the beetles’ specific lifestyle. Effective application requires careful selection of weather conditions and the use of protective agents, such as humic acid, sesame oil, or colza oil, to shield B. bassiana from UV damage and prolong its efficacy [44,45]. Furthermore, accurate monitoring of beetle populations is essential for optimizing application timing. Additionally, while S. marcescens is moderately effective, its opportunistic pathogenicity poses potential risks to human health, making it a less ideal control option. Prodigiosin, although promising as a biopesticide, faces limitations because of its high production cost and the logistical challenges associated with delivering treatments into beetle galleries. Further research and optimization are needed to achieve field applicability.
Several Pyemotes mites have been recognized as natural enemies of bark beetles. For example, P. moseri, P. dryas, and P. johnmoseri have been reported to attack Cryphalus spp., Pityophthorus annectans, and Hypoborus ficus, respectively [18,19,20]. In this study, P. moseri and P. zhonghuajia were shown to be able to locate and kill E. interjectus. Moreover, Pyemotes mites can locate pests in tunnels effectively. For example, P. moseri controls Anoplophora glabripennis by entering larval tunnels [23], and P. zhonghuajia targets Phthorimaea operculella within potatoes [46]. However, E. interjectus differs from these cases. Although the mites can locate and parasitize larvae and pupae in underexposed conditions, they struggle to penetrate the narrow and sealed galleries of E. interjectus and exhibit poor parasitism of adult female beetles. Confined gallery spaces, mutualistic fungi, and challenges in dispersal may limit their efficacy. Furthermore, the specificity of Pyemotes mites for E. interjectus remains uncertain, raising concerns about host switching and potential risks to humans, as some species can cause dermatitis. These factors warrant careful evaluation before large-scale mite release.
The biological control of ambrosia beetles remains a global challenge. Although this study suggests several potential control measures for E. interjectus, the unique survival strategy of the beetle, which involves sealing gallery entrances with expelled sawdust, complicates this issue. This behavior not only blocks contamination by extraneous pathogens but also prevents the entry of natural enemies, increasing the difficulty of control efforts and raising the bar for existing biological control methods. To meet this challenge, researchers and forestry managers must continually innovate and seek new strategies and methods to overcome this natural barrier.

5. Conclusions

In this study, we assessed the effects of Beauveria bassiana strain B-BB-1, Serratia marcescens strain S-SM-1, crude extract of prodigiosin from S. marcescens, Pyemotes zhonghuajia, and Pyemotes moseri on Euwallacea interjectus and its mutualistic fungus Fusarium populicola. B. bassiana significantly increased mortality in female E. interjectus adults and inhibited F. populicola growth. S. marcescens was lethal to E. interjectus larvae but with inconsistent efficacy, and it showed weak inhibition of F. populicola. Prodigiosin extract exhibited high toxicity to E. interjectus larvae and significantly inhibited F. populicola. Both P. zhonghuajia and P. moseri attacked E. interjectus, preferentially targeting pupae, and exhibited locating and killing capabilities against the beetle larvae on mutualistic fungus plates. These agents show promise for biocontrol, but challenges remain in delivering them into beetle galleries within trees, necessitating further research.

Supplementary Materials

The following supporting information can be downloaded at: https://www.mdpi.com/article/10.3390/insects16010056/s1, Figure S1: Operations of poplar log experiments and observations of dead beetles; Figure S2: Diagram of the experimental setup for poplar log experiments; Figure S3: Microbial colonization on E. interjectus larva.

Author Contributions

Conceptualization and methodology, J.L., H.G. and L.D.; formal analysis, data curation, visualization, and writing—original draft preparation, J.L., S.L., Y.Z. and D.H.; investigation, J.L. and N.J.; resources, D.H. and L.D.; writing—review and editing, S.L., Y.Z., D.H. and L.D.; supervision, H.G., S.L., Y.Z. and L.D.; project administration, S.L., Y.Z. and L.D.; funding acquisition, H.G. and L.D. All authors have read and agreed to the published version of the manuscript.

Funding

This work was supported by the Forestry Science, Technology Innovation, and Promotion Projects of Jiangsu (LYKJ-Dongtai (2021) no. 1), Xinjiang Forestry Development Subsidy Funds (Forestry and Grass Science and Technology (XJLYKJ-2023-08).

Data Availability Statement

The data presented in this study are available upon request from the corresponding author.

Acknowledgments

The authors would like to say thanks to the staff of Dafeng Forestry Centre for their support.

Conflicts of Interest

The authors declare no conflicts of interest.

References

  1. Lai, S.; Zhao, C.; Li, Y.; Zhou, Y.; Zhong, L.; Qiu, C.; Wang, H.; Pan, Y.; Dai, L.; Hao, D. Three novel Fusarium mutualists of ambrosia beetle Euwallacea interjectus in China. Mycol. Prog. 2022, 21, 70. [Google Scholar] [CrossRef]
  2. Hulcr, J.; Black, A.; Prior, K.; Chen, C.Y.; Li, H.F. Studies of ambrosia beetles (Coleoptera: Curculionidae) in their native ranges help predict invasion impact. Fla. Entomol. 2017, 100, 257–261. [Google Scholar] [CrossRef]
  3. Paap, T.; De Beer, Z.W.; Migliorini, D.; Nel, W.J.; Wingfield, M.J. The polyphagous shot hole borer (PSHB) and its fungal symbiont Fusarium euwallaceae: A new invasion in South Africa. Australas. Plant Pathol. 2018, 47, 231–237. [Google Scholar] [CrossRef]
  4. Mendel, Z.; Protasov, A.; Sharon, M.; Zveibil, A.; Yehuda, S.B.; O’Donnell, K.; Rabaglia, R.; Wysoki, M.; Freeman, S. Asian ambrosia beetle Euwallacea fornicatus and its novel symbiotic fungus Fusarium sp. pose a serious threat to the Israeli avocado industry. Phytoparasitica 2012, 40, 235–238. [Google Scholar] [CrossRef]
  5. Wang, L.; Chen, F.; Qiu, C.; Tang, J.; Ding, X.; Ren, J. Identification and risk analyses of Euwallacea interjectus. J. Nanjing For. Univ. 2021, 45, 201. [Google Scholar] [CrossRef]
  6. Landi, L.; Braccini, C.L.; Knížek, M.; Pereyra, V.A.; Marvaldi, A.E. A newly detected exotic ambrosia beetle in Argentina: Euwallacea interjectus (Coleoptera: Curculionidae: Scolytinae). Fla. Entomol. 2019, 102, 240–242. [Google Scholar] [CrossRef]
  7. Lv, J.; Lai, S.; Tian, S.; Zhou, Q.; Xiao, L.; He, P.; Wang, J. Taxonomic studies on the Xyleborini beetles from Jiangxi Province. J. Environ. Entomol. 2018, 40, 840–852, (In Chinese with English Abstract). [Google Scholar]
  8. Cognato, A.I.; Hoebeke, E.R.; Kajimura, H.; Smith, S.M. History of the exotic ambrosia beetles Euwallacea interjectus and Euwallacea validus (Coleoptera: Curculionidae: Xyleborini) in the United States. J. Econ. Entomol. 2015, 108, 1129–1135. [Google Scholar] [CrossRef] [PubMed]
  9. Kajii, C.; Morita, T.; Jikumaru, S.; Kajimura, H.; Yamaoka, Y.; Kuroda, K. Xylem dysfunction in ficus carica infected with wilt fungus Ceratocystis ficicola and the role of the vector beetle Euwallacea interjectus. IAWA J. 2013, 34, 301–312. [Google Scholar] [CrossRef]
  10. Wang, Z.; Li, Y.; Ernstsons, A.S.; Sun, R.; Hulcr, J.; Gao, L. The infestation and habitat of the ambrosia beetle Euwallacea interjectus (Coleoptera: Curculionidae: Scolytinae) in the riparian zone of Shanghai, China. Agric. For. Entomol. 2021, 23, 104–109. [Google Scholar] [CrossRef]
  11. Gugliuzzo, A.; Biedermann, P.H.; Carrillo, D.; Castrillo, L.A.; Egonyu, J.P.; Gallego, D.; Haddi, K.; Hulcr, J.; Jactel, H.E.; Kajimura, H.; et al. Recent advances toward the sustainable management of invasive Xylosandrus ambrosia beetles. J. Pest Sci. 2021, 94, 615–637. [Google Scholar] [CrossRef]
  12. Mukasa, Y.; Kyamanywa, S.; Sserumaga, J.P.; Otim, M.; Tumuhaise, V.; Erbaugh, M.; Egonyu, J.P. An atoxigenic L-strain of Aspergillus flavus (Eurotiales: Trichocomaceae) is pathogenic to the coffee twig borer, Xylosandrus compactus (Coleoptera: Curculionidea: Scolytinae). Environ. Microbiol. Rep. 2019, 11, 508–517. [Google Scholar] [CrossRef]
  13. Kushiyev, R.; Tuncer, C.; Erper, I.; Ozdemir, I.O.; Saruhan, I. Efficacy of native entomopathogenic fungus, Isaria fumosorosea, against bark and ambrosia beetles, Anisandrus dispar Fabricius and Xylosandrus germanus Blandford (Coleoptera: Curculionidae: Scolytinae). Egypt. J. Biol. Pest Control 2018, 28, 1–6. [Google Scholar] [CrossRef]
  14. Sundararajan, P.; Rajaselvi, D.D.; Vivekananthan, S.; Ramasamy, S.P. In-silico method for elucidation of prodigiosin as PARP-1 inhibitor a prime target of Triple-negative breast cancer. Bioorg. Chem. 2023, 138, 106618. [Google Scholar] [CrossRef]
  15. Pineda-Castellanos, M.L.; Rodríguez-Segura, Z.; Villalobos, F.J.; Hernández, L.; Lina, L.; Nuñez-Valdez, M.E. Pathogenicity of isolates of Serratia marcescens towards larvae of the scarab Phyllophaga blanchardi (Coleoptera). Pathogens 2015, 4, 210–228. [Google Scholar] [CrossRef] [PubMed]
  16. Gugliuzzo, A.; Aiello, D.; Biondi, A.; Giurdanella, G.; Siscaro, G.; Zappal, A.L.; Vitale, A.; Garzia, G.T.; Polizzi, G. Microbial mutualism suppression by Trichoderma and Bacillus species for controlling the invasive ambrosia beetle Xylosandrus compactus. Biol. Control 2022, 170, 104929. [Google Scholar] [CrossRef]
  17. Jones, M.E.; Paine, T.D. Potential pesticides for control of a recently introduced ambrosia beetle (Euwallacea sp.) in southern California. J. Pest Sci. 2018, 91, 237–246. [Google Scholar] [CrossRef]
  18. Akşit, T.; Cakmak, I.; Moser, J. Attack by Pyemotes johnmoseri (Acari: Pyemotidae) on Hypoborus ficus (Coleoptera: Scolytidae) in fig trees in Turkey. Exp. Appl. Acarol. 2007, 41, 251–254. [Google Scholar] [CrossRef] [PubMed]
  19. Yu, L.; Liang, L. A new species of Pyemotes (Acari: Pyemotidae) parasitic on bark beetles (Coleoptera: Scolytidae) from Hebei, China. Syst. Appl. Acarol. 1996, 1, 167–171. [Google Scholar] [CrossRef]
  20. Moser, J.C.; Kiełczewski, B.; Wiśniewski, J.; Bałazy, S. Evaluating Pyemotes dryas (Vitzthum 1923) (Acari: Pyemotidae) as a parasite of the southern pine beetle. Int. J. Acarol. 1978, 4, 67–70. [Google Scholar] [CrossRef]
  21. Yu, L.; Zhang, Z.; He, L. Two new species of Pyemotes closely related to P. tritici (Acari: Pyemotidae). Zootaxa 2010, 2723, 1–40. [Google Scholar] [CrossRef]
  22. Weiser, J.; Sláma, K. Effects of the toxin of Pyemotes (Acarina: Pyemotidae) on the insect prey, with special reference to respiration. Ann. Entomol. Soc. Am. 1964, 57, 479–482. [Google Scholar] [CrossRef]
  23. Tang, H.; Zheng, J.; Wang, D. An effective method for biological control of Anoplophora glabripennis (Coleoptera: Cerambycidae) by using a vector mite, Pyemotes moseri (Acarina: Pyemotidae), carrying insecticidal fungi. Sci. Silvae Sin. 2022, 58, 157–164, (In Chinese with English Abstract). [Google Scholar]
  24. Liu, X.; Nie, Z.; Chi, D.; He, L. Toxicity and killing effect of Beauveria bassiana and Pyemotes zhonghuajia on Dioryctria abietella and related enzyme activities. J. Northeast For. Univ. 2023, 51, 139–146. [Google Scholar] [CrossRef]
  25. Zheng, L.; Lai, S.; Zhou, Y.; Jiang, N.; Hao, D.; Dai, L. Biology of Euwallacea interjectus, an emerging poplar pest, reared on an ambrosia beetle artificial diet and medium of fungal symbiont. Bull. Entomol. Res. 2024, 114, 405–415. [Google Scholar] [CrossRef] [PubMed]
  26. Abbott, W.S. A method of computing the effectiveness of an insecticide. J. Econ. Entomol. 1925, 18, 265–267. [Google Scholar] [CrossRef]
  27. Panebianco, S.; Vitale, A.; Polizzi, G.; Scala, F.; Cirvilleri, G. Enhanced control of postharvest citrus fruit decay by means of the combined use of compatible biocontrol agents. Biol. Control 2015, 84, 19–27. [Google Scholar] [CrossRef]
  28. Fernandez, K.X.; Pokorny, S.; Ishangulyeva, G.; Ullah, A.; Todorova, S.I.; Erbilgin, N.; Carroll, A.L.; Vederas, J.C. Beauveria bassiana exhibits strong virulence against Dendroctonus ponderosae in greenhouse and field experiments. Appl. Microbiol. Biotechnol. 2023, 107, 3341–3352. [Google Scholar] [CrossRef] [PubMed]
  29. Castrejón-Antonio, J.E.; Tamez-Guerra, P.; Montesinos-Matías, R.; Ek-Ramos, M.J.; Garza-López, P.M.; Arredondo-Bernal, H.C. Selection of Beauveria bassiana (Hypocreales: Cordycipitaceae) strains to control Xyleborus affinis (Curculionidae: Scolytinae) females. PeerJ 2020, 8, e9472. [Google Scholar] [CrossRef]
  30. Castrillo, L.A.; Griggs, M.H.; Ranger, C.M.; Reding, M.E.; Vandenberg, J.D. Virulence of commercial strains of Beauveria bassiana and Metarhizium brunneum (Ascomycota: Hypocreales) against adult Xylosandrus germanus (Coleoptera: Curculionidae) and impact on brood. Biol. Control 2011, 58, 121–126. [Google Scholar] [CrossRef]
  31. Castrejón-Antonio, J.E.; Tamez-Guerra, P.; García-Ortiz, N.; Muñiz-Paredes, F.; Sánchez-Rangel, J.C.; Montesinos-Matías, R. Biocontrol of Xyleborus affinis (Curculionidae: Scolitinae) females and progeny by Beauveria bassiana (Hypocreales: Cordycipitaceae) in a sawdust artificial diet model. Insects 2023, 14, 477. [Google Scholar] [CrossRef] [PubMed]
  32. Castrillo, L.A.; Griggs, M.H.; Vandenberg, J.D. Granulate ambrosia beetle, Xylosandrus crassiusculus (Coleoptera: Curculionidae), survival and brood production following exposure to entomopathogenic and mycoparasitic fungi. Biol. Control 2013, 67, 220–226. [Google Scholar] [CrossRef]
  33. Prabhukarthikeyan, R.; Saravanakumar, D.; Raguchander, T. Combination of endophytic Bacillus and Beauveria for the management of Fusarium wilt and fruit borer in tomato. Pest Manag. Sci. 2014, 70, 1742–1750. [Google Scholar] [CrossRef] [PubMed]
  34. Zhang, P.; Zhao, Q.; Ma, X.; Ma, L. Pathogenicity of Serratia marcescens to hazelnut weevil (Curculio dieckmanni). J. For. Res. 2021, 32, 409–417. [Google Scholar] [CrossRef]
  35. Wang, M.; Chen, H.; Xie, D.; Xiang, J.; Yu, J.; Chi, D. Composition and structure of culturable bacterial community in the intestinal of Hylurgus ligniperda Fabricius. J. Northeast For. Univ. 2024, 52, 109–114. [Google Scholar] [CrossRef]
  36. Qi, H.; Wang, J.; Endoh, R.; Takeuchi, Y.; Tarno, H.; Futai, K. Pathogenicity of microorganisms isolated from the oak platypodid, Platypus quercivorus (Murayama) (Coleoptera: Platypodidae). Appl. Entomol. Zool. 2011, 46, 201–210. [Google Scholar] [CrossRef]
  37. Moore, G.E. Pathogenicity of ten strains of bacteria to larvae of the southern pine beetle. J. Invertebr. Pathol. 1972, 20, 41–45. [Google Scholar] [CrossRef]
  38. Guo, Z.; Zhang, X.; Wu, J.; Yu, J.; Xu, M.; Chen, D.; Zhang, Z.; Li, X.; Chi, Y.; Wan, S. In vitro inhibitory effect of the bacterium Serratia marcescens on Fusarium proliferatum growth and fumonisins production. Biol. Control 2020, 143, 104188. [Google Scholar] [CrossRef]
  39. Suryawanshi, R.K.; Patil, C.D.; Borase, H.P.; Narkhede, C.P.; Salunke, B.K.; Patil, S.V. Mosquito larvicidal and pupaecidal potential of prodigiosin from Serratia marcescens and understanding its mechanism of action. Pestic. Biochem. Physiol. 2015, 123, 49–55. [Google Scholar] [CrossRef] [PubMed]
  40. Hu, W.; Zheng, R.; Liao, Y.; Kuang, F.; Yang, Z.; Chen, T.; Zhang, N. Evaluating the biological potential of prodigiosin from Serratia marcescens KH-001 against Asian citrus psyllid. J. Econ. Entomol. 2021, 114, 1219–1225. [Google Scholar] [CrossRef] [PubMed]
  41. Alijani, Z.; Amini, J.; Ashengroph, M.; Bahramnejad, B. Antifungal activity of Serratia rubidaea Mar61-01 purified prodigiosin against Colletotrichum nymphaeae, the causal agent of strawberry anthracnose. J. Plant Growth Regul. 2022, 41, 585–595. [Google Scholar] [CrossRef]
  42. Jimtha, C.J.; Jishma, P.; Sreelekha, S.; Chithra, S.; Radhakrishnan, E.K. Antifungal properties of prodigiosin producing rhizospheric Serratia sp. Rhizosphere 2017, 3, 105–108. [Google Scholar] [CrossRef]
  43. Gutiérrez-Román, M.I.; Holguín-Meléndez, F.; Bello-Mendoza, R.; Guillén-Navarro, K.; Dunn, M.F.; Huerta-Palacios, G. Production of prodigiosin and chitinases by tropical Serratia marcescens strains with potential to control plant pathogens. World J. Microbiol. Biotechnol. 2012, 28, 145–153. [Google Scholar] [CrossRef] [PubMed]
  44. Mann, A.J.; Davis, T.S. Entomopathogenic fungi to control bark beetles: A review of ecological recommendations. Pest Manag. Sci. 2021, 77, 3841–3846. [Google Scholar] [CrossRef] [PubMed]
  45. Kaiser, D.; Bacher, S.; Mène Saffrané, L.; Grabenweger, G. Efficiency of natural substances to protect Beauveria bassiana conidia from UV radiation. Pest Manag. Sci. 2019, 75, 556–563. [Google Scholar] [CrossRef]
  46. Liu, J.; He, X.; Ye, S.; Zhou, J.; Han, P.; Gao, Y.; Yang, M. Pest management of postharvest potatoes: Lethal, sublethal and transgenerational effects of the ectoparasitic mite Pyemotes zhonghuajia on the potato worm Phthorimaea operculella. Pest Manag. Sci. 2023, 79, 5250–5259. [Google Scholar] [CrossRef] [PubMed]
Insects 16 00056 g001
Figure 1. Effects of B. bassiana treatments on E. interjectus survival, reproduction, and sawdust expulsion. (a) Survival curves for female adults of E. interjectus treated with different concentrations of spore suspensions of B. bassiana in Petri dishes. Curves followed by different letters were significantly different (log-rank test, p < 0.05). (b) Offspring production of female E. interjectus adults treated with different concentrations of B. bassiana spore suspensions and control in artificial diet after 20 days (Dunn–Bonferroni test; significant differences are shown by asterisks: * p < 0.05, *** p < 0.001). (c) Cumulative weight of expelled sawdust in poplar log experiment under three treatment methods. “CT” represents “control treatment,” “PT” represents “spore powder treatment”, and “ST” represents “spore suspension treatment” (Dunn–Bonferroni test; significant differences are shown by asterisks: ns = not significant results, * p < 0.05, ** p < 0.01, *** p < 0.001).
Figure 1. Effects of B. bassiana treatments on E. interjectus survival, reproduction, and sawdust expulsion. (a) Survival curves for female adults of E. interjectus treated with different concentrations of spore suspensions of B. bassiana in Petri dishes. Curves followed by different letters were significantly different (log-rank test, p < 0.05). (b) Offspring production of female E. interjectus adults treated with different concentrations of B. bassiana spore suspensions and control in artificial diet after 20 days (Dunn–Bonferroni test; significant differences are shown by asterisks: * p < 0.05, *** p < 0.001). (c) Cumulative weight of expelled sawdust in poplar log experiment under three treatment methods. “CT” represents “control treatment,” “PT” represents “spore powder treatment”, and “ST” represents “spore suspension treatment” (Dunn–Bonferroni test; significant differences are shown by asterisks: ns = not significant results, * p < 0.05, ** p < 0.01, *** p < 0.001).
Insects 16 00056 g001
Insects 16 00056 g002
Figure 2. Effects of S. marcescens on E. interjectus survival. (a) Survival curves for larvae of E. interjectus on the mutualistic fungi plates treated with different concentrations of S. marcescens. Curves followed by different letters were significantly different (log-rank test, p < 0.05). (b) Dead larva of E. interjectus infected by S. marcescens. (c) Dead pupa of E. interjectus infected by S. marcescens.
Figure 2. Effects of S. marcescens on E. interjectus survival. (a) Survival curves for larvae of E. interjectus on the mutualistic fungi plates treated with different concentrations of S. marcescens. Curves followed by different letters were significantly different (log-rank test, p < 0.05). (b) Dead larva of E. interjectus infected by S. marcescens. (c) Dead pupa of E. interjectus infected by S. marcescens.
Insects 16 00056 g002
Insects 16 00056 g003
Figure 3. Examples of in vitro interactions between F. populicola and B. bassiana. (a) F. populicola control plates. (b) Inhibition zones formed between F. populicola (inoculated on the right of the plate) and B. bassiana (inoculated on the left of the plate). (c) B. bassiana control plates.
Figure 3. Examples of in vitro interactions between F. populicola and B. bassiana. (a) F. populicola control plates. (b) Inhibition zones formed between F. populicola (inoculated on the right of the plate) and B. bassiana (inoculated on the left of the plate). (c) B. bassiana control plates.
Insects 16 00056 g003
Insects 16 00056 g004
Figure 4. Examples of in vitro interactions between F. populicola and S. marcescens. (a) F. populicola control plates. (b) Competition plates between F. populicola (inoculated on the top of the plate) and S. marcescens (inoculated on the bottom of the plate).
Figure 4. Examples of in vitro interactions between F. populicola and S. marcescens. (a) F. populicola control plates. (b) Competition plates between F. populicola (inoculated on the top of the plate) and S. marcescens (inoculated on the bottom of the plate).
Insects 16 00056 g004
Insects 16 00056 g005
Figure 5. Effects of PCE concentrations on E. interjectus survival and F. populicola growth. (a) Survival curves for larvae of E. interjectus on the mutualistic fungi plates treated with different concentrations of the PCE. Curves followed by different letters were significantly different (log-rank test, p < 0.05). (b) Colony growth of F. populicola cultures on PDA plates containing different concentrations of PCE after 5 days. From top to bottom: control, 0.1% PCE treatment, 0.2% PCE treatment, 1% PCE treatment.
Figure 5. Effects of PCE concentrations on E. interjectus survival and F. populicola growth. (a) Survival curves for larvae of E. interjectus on the mutualistic fungi plates treated with different concentrations of the PCE. Curves followed by different letters were significantly different (log-rank test, p < 0.05). (b) Colony growth of F. populicola cultures on PDA plates containing different concentrations of PCE after 5 days. From top to bottom: control, 0.1% PCE treatment, 0.2% PCE treatment, 1% PCE treatment.
Insects 16 00056 g005
Insects 16 00056 g006
Figure 6. Relative distribution changes in two Pyemotes species on different stages of E. interjectus. On the first day, the total number of mites on the surface of the beetles was counted. From the second day onward, the number of mites with developing opisthosoma on the beetle surface was recorded.
Figure 6. Relative distribution changes in two Pyemotes species on different stages of E. interjectus. On the first day, the total number of mites on the surface of the beetles was counted. From the second day onward, the number of mites with developing opisthosoma on the beetle surface was recorded.
Insects 16 00056 g006
Insects 16 00056 g007
Figure 7. Life cycle of two Pyemotes species on the female pupae of the E. interjectus.
Figure 7. Life cycle of two Pyemotes species on the female pupae of the E. interjectus.
Insects 16 00056 g007
Table 1. Survival and offspring production of female E. interjectus adults treated with B. bassiana.
Table 1. Survival and offspring production of female E. interjectus adults treated with B. bassiana.
TreatmentSurvival
(Mean ± SE%)		Offspring Production
(Mean ± SE%)
1080.00 ± 0.00 c3.33 ± 3.28 d
1070.00 ± 0.00 c23.33 ± 7.72 bc
10636.67 ± 8.80 b43.33 ± 9.05 b
Control83.33 ± 6.80 a70.00 ± 8.37 a
The data were collected on day 20 from the artificial diet. Values not followed by the same letter in a column are significantly different (chi-square test with Bonferroni correction, p < 0.05).
Table 2. Relative distribution of opisthosoma on E. interjectus infested by two Pyemotes species.
Table 2. Relative distribution of opisthosoma on E. interjectus infested by two Pyemotes species.
TreatmentThe Relative Quantity of the Opisthosoma
(Mean ± SE%)
AdultsPupaeLarvae
P. moseri1.45 ± 0.71 b74.84 ± 7.46 a23.71 ± 7.85 abH = 10.898, df = 2, p = 0.004
P. zhonghuajia2.77 ± 1.17 b78.05 ± 5.35 a19.17 ± 5.58 abH = 10.674, df = 2, p = 0.005
t = −0.866, df = 8, p = 0.412t = −0.313, df = 8, p = 0.762t = 0.421, df = 8, p = 0.685
The data were collected on day 5. Independent-sample t-tests were used to compare the two Pyemotes species within each column. Kruskal–Wallis tests followed by Dunn–Bonferroni pairwise comparisons were used to compare the three developmental stages within each row, with different letters indicating significant differences in the results of pairwise comparisons (p > 0.05).
Table 3. Metrics of single female pupae of E. interjectus parasitized by two Pyemotes species.
Table 3. Metrics of single female pupae of E. interjectus parasitized by two Pyemotes species.
TreatmentNumber of Opisthosomata
(Mean ± SE)		Total Number of Offspring
(Mean ± SE)		Number of Offspring per Opisthosoma
(Mean ± SE)
P. moseri50.10 ± 2.23549.10 ± 76.8910.96 ± 1.58
P. zhonghuajia52.70 ± 3.57707.00 ± 97.6013.42 ± 2.68
t = −0.585, df = 18, p = 0.566t = −1.206, df = 18, p = 0.244t = −1.094, df = 18, p = 0.288
Independent-sample t-tests were used to compare the two Pyemotes species within each column.
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.

Share and Cite

MDPI and ACS Style

Liu, J.; Jiang, N.; Gao, H.; Lai, S.; Zhou, Y.; Hao, D.; Dai, L. Laboratory Exploration of Several Potential Biocontrol Methods Against the Ambrosia Beetle, Euwallacea interjectus. Insects 2025, 16, 56. https://doi.org/10.3390/insects16010056

AMA Style

Liu J, Jiang N, Gao H, Lai S, Zhou Y, Hao D, Dai L. Laboratory Exploration of Several Potential Biocontrol Methods Against the Ambrosia Beetle, Euwallacea interjectus. Insects. 2025; 16(1):56. https://doi.org/10.3390/insects16010056

Chicago/Turabian Style

Liu, Jialin, Nan Jiang, Haiming Gao, Shengchang Lai, Yang Zhou, Dejun Hao, and Lulu Dai. 2025. "Laboratory Exploration of Several Potential Biocontrol Methods Against the Ambrosia Beetle, Euwallacea interjectus" Insects 16, no. 1: 56. https://doi.org/10.3390/insects16010056

APA Style

Liu, J., Jiang, N., Gao, H., Lai, S., Zhou, Y., Hao, D., & Dai, L. (2025). Laboratory Exploration of Several Potential Biocontrol Methods Against the Ambrosia Beetle, Euwallacea interjectus. Insects, 16(1), 56. https://doi.org/10.3390/insects16010056

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
