OxyR Positively Influences Phaseolotoxin Synthesis and Pyoverdin Production in Pseudomonas savastanoi pv. phaseolicola NPS3121

by
Jackeline Lizzeta Arvizu-Gómez
1,*,
Alejandro Hernández-Morales
2,*,
Rafael Arnulfo Juárez-Navarro
3,
Juan Diego Paredes-Tadeo
3,
Juan Campos-Guillén
4,
Juan Ramiro Pacheco-Aguilar
4,
Abril Bernardette Martínez-Rizo
5 and
Christian González-Reyes
3
1
Secretaría de Investigación y Posgrado, Centro Nayarita de Innovación y Transferencia de Tecnología (CENITT), Universidad Autónoma de Nayarit, Tepic 63000, Mexico
2
Facultad de Estudios Profesionales Zona Huasteca, Universidad Autónoma de San Luis Potosí, San Luis Potosí 79060, Mexico
3
Unidad Académica de Ciencias Químico Biológico y Farmacéuticas, Universidad Autónoma de Nayarit, Tepic 63000, Mexico
4
Facultad de Química, Universidad Autónoma de Querétaro, Santiago de Querétaro 76010, Mexico
5
Unidad Académica de Medicina, Universidad Autónoma de Nayarit, Tepic 63000, Mexico
*
Authors to whom correspondence should be addressed.
Microorganisms 2022, 10(11), 2123; https://doi.org/10.3390/microorganisms10112123
Submission received: 9 July 2022 / Revised: 22 October 2022 / Accepted: 23 October 2022 / Published: 27 October 2022
(This article belongs to the Section Plant Microbe Interactions)
Browse Figures
Versions Notes

Abstract

:
Phaseolotoxin is a major virulence factor of the bean pathogen bacterium P. savastanoi pv. phaseolicola. This toxin plays a key role in the development of the halo blight disease in bean plants. So far, the signal transduction pathways involved in the synthesis of phaseolotoxin have not been elucidated. The influence of regulation mechanisms related to the oxidative stress response, in particular the OxyR protein, it has been suggested to be involved in this process.. In this study we evaluated the role of OxyR in P. savastanoi pv. phaseolicola, mainly compared to the synthesis of phaseolotoxin and the virulence of this phytopathogen. Generation of the oxyR-mutant, pathogenicity and virulence tests, and analyses of gene expression by RT-PCR assays were performed. The results showed that OxyR exerts an effect on the synthesis of phaseolotoxin and positively influences the expression of the Pht and Pbo cluster genes. Likewise, OxyR influences the production of pyoverdine by the control of the expression of the genes encoding the PvdS sigma factor, involved in the synthesis of this pigment. This study is the first report on members of the OxyR regulon of P. savastanoi pv. phaseolicola NPS3121.

1. Introduction

Pseudomonas savastanoi pv. phaseolicola (syn P. syringae pv. phaseolicola; P. amygdali pv. phaseolicola) is the causal agent of the common bean (Phaseolus vulgaris L.) disease known as “halo blight”. It affects leaves and pods, being one of the most destructive diseases of bean cultivation, causing losses of production in the order of 23 to 43%, mainly in temperate or cold areas [1,2]. The disease is characterized by the presence of chlorotic areas around the necrotic site of infection. In cases of severe infection, the plants develop a systemic generalized chlorosis presenting growth deficiencies, with wrinkled and mottled upper leaves [1,3]. Among the virulence factors that P. savastanoi pv. phaseolicola synthesizes for the development of the disease, is the phytotoxin known as phaseolotoxin, which is the main factor responsible for the characteristic chlorotic symptoms of the halo blight [4,5,6]. The phaseolotoxin [Nδ (N’-sulfodiaminophosphinyl)-ornithyl-alanyl-homoarginine] is an extracellular toxin, non-host-specific, which is produced by the bacteria within the site of infection and diffuses into leaf tissues causing chlorophyll synthesis inhibition [5,7,8]. In addition, phaseolotoxin facilitates the systemic invasion of the plant, contributing significantly to the virulence of the pathogen. Phaseolotoxin is then a key element for the development of the disease and an important virulence factor of the bacterium [5,6,9]. The production of phaseolotoxin by P. savastanoi pv. phaseolicola is regulated by the temperature, with optimal production at 18–20 °C, while at 28 °C (the optimal growth temperature for this bacterium) it is not detected [10,11].
Genes required for phaseolotoxin synthesis and, therefore, for the virulence of the bacterium are located within a 30.24 kb horizontally acquired pathogenicity island name “Pht cluster”, where they are organized in five transcriptional units including two monocistronic (argK and phtL) and three polycistronic operons, one comprising of 11 genes from phtA to phtK with an internal promoter driving expression of phtD to phtK and a third large polycistronic operon comprising of 10 genes from phtM to phtV [12,13,14]. Recent studies have identified and characterized a second chromosomal region of P. savastanoi pv. phaseolicola NPS3121 called as “Pbo cluster”, which is also involved in the phaseolotoxin synthesis. The Pbo cluster contains 16 open reading frames arranged in four transcriptional units, including one monocistronic (pboJ) and three polycistronic (pboA-pboI, pboK-pboN, and pboO-pboP) [15]. Analyses of gene expression of the Pht and Pbo clusters have shown thermoregulation of the phaseolotoxin genes, whose expression occurs selectively at low temperatures (18 °C) with high levels of transcripts and increase of the promoter activity of the most of these genes under this condition, with exception of the pboJ gene (Pbo cluster), is constitutively expressed at both 18 °C and 28 °C [12,15].
The mechanisms that control the gene expression of phaseolotoxin in P. savastanoi pv. phaseolicola are just beginning to be elucidated. However, the advances that have been made in this regard have shown that the regulation of the Pht and Pbo clusters is complex and involves many factors, including both specific regulatory proteins encoded within the Pht cluster itself (PhtL, PhtA, PhtABC) [12,16,17,18] and global regulators (IHF, the two-component GacS-GacA system and a putative 14–20 kDa regulator protein) [19,20,21]. Most of these factors appear to mediate the regulation of genes of the Pht and Pbo clusters in response to low temperature.
Transcriptomics analyses, comparing the gene expression profile of the bacterium P. savastanoi pv. phaseolicola NP3121 grown at 18 °C and 28 °C (corresponding to related conditions and not with the phaseolotoxin synthesis, respectively) showed that, at low temperatures (18 °C), the overall expression profile obtained for P. savastanoi is like that reported for Pseudomonas aeruginosa after exposure to the oxidative stress inducing agent-hydrogen peroxide, resulting in an expression pattern of oxidative stress response [22]. Therefore, these analyses suggested that low temperatures (18 °C) induce oxidative stress in the P. savastanoi pv. phaseolicola cells, which in turn, give rise to the gene expression profile obtained, among which are highlighted the expression of the Pht and Pbo cluster phaseolotoxin genes [22]. Recent studies of our work group showed that the gene expression of the Pht cluster is regulated by oxidative stress in a manner dependent of the reactive oxygen species (ROS) present in the cell, thereby demonstrating that the expression of the Pht cluster genes is part of the oxidative stress response in P. savastanoi pv. phaseolicola NPS3121 [23]. Moreover, these results suggest possible regulatory pathways involved in the phaseolotoxin synthesis, where the regulation mechanisms of oxidative stress response could be involved.
The OxyR regulon has been identified and characterized in the E. coli model bacterium as one of the main regulatory pathways for the response to oxidative stress, which responds, in particular, to the existence of hydrogen peroxide (H2O2) in the cells. The regulatory action of OxyR is mediated by the activation of the protein, directly, through the oxidation of the disulphide bonds by H2O2. Once activated, OxyR induces the expression of genes within the OxyR regulon, which mainly protects the cell from H2O2 toxicity [24,25,26]. The OxyR dependent regulation of primary antioxidant genes is conserved in a variety of bacteria. However, recent investigations have revealed differences in the members of the OxyR regulon among bacteria [27,28,29]. Furthermore, it has been demonstrated that there is diversity in the activation mechanisms of OxyR orthologs in other microorganisms [30]. Studies in diverse phytopathogenic bacteria have demonstrated that OxyR participates in the synthesis of some pathogenicity and/ or virulence factors, but this influence is variable or specific for the phytopathogen [31,32,33]. Although OxyR is primarily thought of as a transcriptional activator, in some bacteria it can function as either a repressor or an activator under both oxidizing and reducing conditions [30]. Thus far, the role of the OxyR global regulator in P. savastanoi pv. phaseolicola NPS3121 has not been evaluated and no member of the OxyR regulon in this phytopathogen has been reported. Therefore, this study was undertaken with the objective to evaluate the influence of OxyR in the production of virulence determinants in P. savastanoi pv. phaseolicola NPS3121, mostly focused on the synthesis of phaseolotoxin. The present work demonstrates that the OxyR global regulator positively influences the synthesis and gene expression related to phaseolotoxin, contributing to the knowledge about the regulatory pathways involved in this process. Additionally, based on the results obtained, this work demonstrates that like phaseolotoxin, synthesis of pyoverdine is also a member of the OxyR regulon of P. savastanoi pv. phaseolicola NPS3121.

2. Materials and Methods

2.1. Bacterial Strains, Media, and Growth Conditions

The Pseudomonas savastanoi strains: pv. phaseolicola NPS3121 wild type [34], oxyR-mutant, oxyR- complemented mutant (oxyR- C) and P. syringae pv. tomato DC3000 were grown or maintained on King´s B (KB, Sigma–Aldrich®, MO, USA) medium or in M9 minimal medium (Sigma–Aldrich®, MO, USA) at 18 °C or 28 °C. The Escherichia coli strains were routinely grown on Luria–Bertani (LB, Dibico®, EdoMex, Mexico) medium at 37 °C. The E. coli Top 10 strain (Invitrogen, CA, USA) was used in the cloning procedures. The E. coli strain JM103 [35] was used as an indicator strain in the phaseolotoxin assays. When required, the following antibiotics were added for the P. savastanoi strains and E. coli, respectively: ampicillin (Amp) (300 μg mL−1, 100 μg mL−1), kanamycin (Km) (70 μg mL−1, 50 μg mL−1), gentamicin (Gm) 30 μg mL−1, and rifampin (Rf) 50 μg mL−1.

2.2. Molecular Biology Techniques

Genomic DNA of P. savastanoi pv. phaseolicola NPS3121 was isolated as previously described [36]. Routine molecular techniques were performed using standard protocols [37]. Plasmids were purified using the GenEluteTM Plasmid Miniprep Kit (Sigma-Aldrich®, St. Louis, MO, USA). Restriction enzymes were used according to instructions provided by the suppliers. The PCR products were amplified with Taq DNA Polymerase (Thermo Fisher Scientific, Waltham, MA, USA). Primers were designed using the Vector NTI Software (Invitrogen, Carlsbad, CA, USA) based on the reference genome of P. savastanoi pv. phaseolicola 1448A (Gene Bank accession no. CP000058) [38]. The oligonucleotides used in this study are listed in Table 1.

2.3. Construction of the P. savastanoi pv. phaseolicola NPS3121 oxyR- Mutant Strain and oxyR- Complemented Mutant (oxyR- C)

The generation of the oxyR-mutant of P. savastanoi pv. phaseolicola NPS3121 was carried out through the mutational strategy of gene inactivation by the integration of a homologous suicide plasmid, based on the methodology previously described [40]. An internal fragment (493 bp) of the unique homologous gene oxyR (PSPPH_RS00995; old_locus_tag PSPPH_0190; 924 bp) was obtained by PCR using the primers pairs OxyR-FWD:AGCAGGCTCAAGGTATTCGT and OxyR-REV:GAAGCGACCATGTGCCGAAT (Table 1). The PCR amplification was performed at 94 °C for 3 min for 1 cycle; 94 °C for 35 s, 55 °C for 35 s, and 72 °C for 1 min for 35 cycles; and 72 °C for 7 min for 1 cycle. The amplicon was cloned into the vector pCR4-TOPO (Invitrogen, CA, USA) obtaining the recombinant molecule pCR4-TOPO::oxyR disrupted, in which the orientation and validation of the insert was carried out by restriction and sequencing analyses. This recombinant molecule (pCR4-TOPO::oxyR disrupted) was incorporated into the working strain by electroporation using the following parameters: 200 V, 20 Ω y 250 µFD. The obtained transformants were selected in KBRfKmAmp medium. Finally, the cointegration of the suicide plasmid in the target region was confirmed by PCR. The complementation in trans of the oxyR-mutant strain was performed by cloning of the oxyR gene (PSPPH_RS00995) in the pBBR1MCS-5 plasmid [41]. A DNA fragment containing the oxyR open reading frame and 250 bp upstream from the ATG codon was obtained by PCR using the pOxyR250-SmaI-OxyRRev-BamHI oligonucleotides (Table 1). The PCR amplicon was digested by SmaI-BamHI restriction enzymes and ligated into the pBBR1MCS-5 plasmid digested with the same enzymes. The resulting plasmid pBBR1MCS-5::oxyR250 was introduced by electroporation in the P. savastanoi pv. phaseolicola oxyR-mutant strain.

2.4. Bacterial Growth Curves of the P. savastanoi pv. phaseolicola NPS3121 Strains

The growth dynamics of the strains: wt, oxyR-mutant, and oxyR- C (complemented mutant) of P. savastanoi pv. phaseolicola NPS3121, were evaluated in both M9 minimal medium (MM9)(2X) supplemented with 0.4 mM CaCl2, 4 mM MgSO4 and glucose (0.8%) and King´s B (KB) media at 18 °C and 28 °C. The bacterial growth curves in MM9 were carried as follows: pre-inoculums (30 mL) of the wt, oxyR-mutant, and oxyR- C strains, were grown in MM9 at 28 °C for 24–48 h. The cells were inoculated into 100 mL of MM9 at optical density (OD600nm) 0.1. To evaluate the effect of the temperature, the cultures were incubated at 18 °C or 28 °C. On the other hand, the growth conditions in the KB rich medium consisted of: pre-inoculums (30 mL) of the strains wt, oxyR-mutant, and oxyR- C, were grown in KBRf, KBRfKmAmp, and KBRfKmAmpGm broth, respectively, at 28 °C for 24 h. These pre-inoculums were used to inoculate 100 mL of KB broth at optical density (OD600nm) 0.05. The cultures were incubated at 18 °C or 28 °C. Two biological replicates with two technical replicates were evaluated.

2.5. Bacterial Growth Conditions and RNA Isolation

The growth conditions used for the expression analyses corresponded to those previously used in studies of genic expression of virulence (phaseolotoxin) and pathogenicity factors [12,22,23]. Pseudomonas savastanoi pv. phaseolicola NPS3121 strains were grown at 18 °C and 28 °C in M9 minimal medium (MM9) (2X) supplemented with 0.4 mM CaCl2, 4 mM MgSO4 and glucose (0.8%) (Golden-Bell Reactivos®, Jal, Mexico) as the carbon source. The growth conditions were as follows: pre-inoculums (30 mL) of the wt and oxyR-mutant strains of P. savastanoi pv. phaseolicola were grown in M9 minimal medium at 28 °C for 24–48 h. The cells were inoculated into 100 mL of MM9 at optical density (OD600nm) 0.1. The cultures were incubated at 18 °C or 28 °C and grown until they reached the late log phase, growth stage in which the cells were recovered to further RNA extraction. The cells cultures were distributed in 50 mL conical tubes and recovered by centrifugation (GYROZEN® 1580R, Corea) to 4000 rpm for 15 min at 4 °C. Supernatants of each culture were removed to further assays of phaseolotoxin production. For RNA isolation, the cell pellets were subjected to one washing step with sterile deionized water prior to their storage at −80 °C. Total RNA was extracted using the TRIzol Reagent following the manufacturer´s instructions (Invitrogen, CA, USA). The RNA was eluted in 50 μL of diethylpirocarbonate (DEPC)-treated water. Genomic DNA was removed by digestion with DNase I (Invitrogen, USA). The quantity and quality of the RNA was determined using a spectrophotometer (Multiskan-GO, Thermo Fisher Scientific, MA, USA). The integrity of RNA samples was confirmed by analytical agarose gel electrophoresis.

2.6. Analysis of Expression by Reverse Transcriptase (RT)-PCR Assays

The gene expression analyses were performed by the RT-PCR technique using the oligonucleotides pairs listed in Table 1. Analyses were performed with two biological replicates using RNA isolated from a different culture and two technical replicates with the same RNA samples. The SuperScript One-Step RT-PCR kit (Invitrogen, CA, USA) was used according to the manufacturer’s instructions with 200 ng RNA template per reaction. The RT reaction was performed at 50 °C for 30 min, followed by PCR amplification at 94 °C for 2 min for 1 cycle; 94 °C for 35 s, 55–60 °C for 40 s, and 72 °C for 1–2 min for 23–28 cycles; and 72 °C for 7 min for 1 cycle. Controls used for each set of primers were: (i) PCR without the reverse transcription step to verify the absence of DNA; (ii) RT-PCRs without RNA templates to detect any contaminating DNA/RNA; (iii) PCRs using chromosomal DNA as template to ensure primer fidelity. Furthermore, the amplification of a portion of the 16S rRNA operon using suitable primers was used as an internal control of the reaction (23 amplification cycles). Twenty-eight amplification cycles were used in most of the RT-PCR assays. Number cycles in which the differential expression widely reported, for the Pht cluster genes in function of the temperature (28 °C vs. 18 °C) [12,22,23] was observed in these assays.

2.7. Phaseolotoxin Bioassays

Phaseolotoxin production by the P. savastanoi pv. phaseolicola oxyR-mutant strain was evaluated by the E. coli JM103 strain growth inhibition assay as previously described [42,43], with some modifications. The supernatants of the cell cultures of the oxyR-mutant strain grown at 18 °C and 28 °C in M9 minimal medium were recovered as described above. Aliquots of 100 μL of the supernatants were deposited on sterile 6 mm Whatman paper discs and left until dry to subsequently transfer them onto MM9 agar plates previously seeded with the E. coli JM103 control strain. The plates were incubated at 37 °C for 24 h. In every case, plates containing arginine were used as controls to confirm that growth inhibition was because of phaseolotoxin. Simultaneously, cultures of the P. savastanoi pv. phaseolicola NPS3121 wt strain and oxyR- complemented mutant (oxyR- C) grown at 18 °C and 28 °C in M9 minimal medium were evaluated and used as a control.

2.8. Pathogenicity and Virulence Assays in Bean Pods

Bacteria were tested for pathogenicity and virulence using the modified bean pod assays previously described [44]. Bacterial cells grown in KB medium agar plates supplemented with the corresponding antibiotics, were removed with a sterile toothpick, and inoculated in detached bean pods previously disinfected with NaClO 5%. For each bacterial strain, three pods were inoculated. The inoculated bean pods were placed inside an airtight container into which these were arranged on a surface positioned about 3–4 cm from a base of paper moistened with sterile water to maintain humidity. The containers were maintained at 28 °C or 18 °C for 3–5 days. As controls, inoculations with cells of P. syringae pv. tomato DC3000 were included. Likewise, pods treated only with sterile toothpick without bacteria were included as a control.

2.9. Quantification of Siderophores

The P. savastanoi pv. phaseolicola NPS321 strains: wild type, oxyR-mutant, and oxyR- C, were grown in M9 minimal medium at 28 °C and 18 °C with shaking at 200 rpm. Cell-free supernatants were obtained by centrifugation at 4000 rpm for 15 min at 4 °C and filtered through a syringe filter (0.22 μm). The supernatants were analysed at 400 nm to determine pyoverdine production. The pyoverdine concentration was calculated using the molar absorption coefficient (ε = 20000 M−1 cm−1) [45]. The values were normalized with the biomass of the cultures at 600 nm and expressed in µM of pyoverdine [46]. Three biological replicates were evaluated. Statistical analysis was performed using the statistical software GraphPad Prism Version 5.01. Analysis of variance (ANOVA) was performed with Tukey´s method to compare the means between treatments (p < 0.05).

3. Results

3.1. OxyR Positively Influences on the Growth Rate of P. savastanoi pv. phaseolicola NPS3121

To evaluate the role of OxyR on the physiology of the P. savastanoi pv. phaseolicola bacterium, specifically in relation to the production of virulence determinants, we first constructed the oxyR-mutant in P. savastanoi pv. phaseolicola NPS3121. Obtaining the oxyR-mutant was achieved by the integration of a homologous suicide plasmid in the unique homologous gene oxyR (PSPPH_RS00995; PSPPH_0190). The integration of the suicide plasmid in the interest target was validated by PCR assays [47]. Because the pathogenicity and virulence capacity of various phytopathogenic bacteria is a function of their growth [48,49], we obtained bacterial growth curves of the oxyR- P. savastanoi pv. phaseolicola NPS3121 mutant strain under conditions related or not (18 °C or 28 °C, respectively) to its virulence or pathogenicity [22]. This aimed to evaluate the influence of OxyR in the growth of P. savastanoi pv. phaseolicola. First, the results showed that in both the oxyR-mutant and the wild type (wt) strain, low temperatures (18 °C) decreased the bacterial growth rate in both M9 minimal medium and King´s B media (Figure 1). On the other hand, the analysis of the growth kinetics in MM9 showed that in lacking functional OxyR, the growth rate of P. savastanoi pv. phaseolicola was diminished; this at both 18 °C and 28 °C. At 28 °C, the optimal growth temperature for this bacterium, the growth rate in the oxyR-mutant decreased approximately 1.5-fold relative to the wt strain. While the comparison of the growth rates among the P. savastanoi strains (wtvs. oxyR-) at 18 °C showed a decrease of 3-fold in the oxyR- relative to the wt strain (Figure 1). This behaviour was reproducible in all performed kinetics. Contrary to what was observed in MM9, the bacterial growth curves in the rich KB medium showed that at 28 °C the lack of OxyR did not influence the growth rate; only at 18 °C was there observed a decrease in the growth rate in the oxyR-mutant compared to the wt strain (Figure 1). These results suggest that OxyR is implicated in the bacterial growth process of P. savastanoi pv. phaseolicola NPS3121.
To validate these results, the construction and evaluation of the bacterial growth curves of the oxyR- complemented mutant strain (oxyR- C) was performed. An increase in the bacterial growth rate was observed in the oxyR- C strain compared to the oxyR-mutant strain in most of the evaluated conditions (Figure 1). The introduction in trans of oxyR only partially completed the growth phenotypes. In general, these results demonstrate that OxyR plays an important role in the growth of P. savastanoi pv. phaseolicola NPS3121, positively influencing this process. This positive influence occurs mainly at low temperatures (18 °C) and under minimal media conditions. On the other hand, because previous work has indicated that in the late log growth phase there occurs expression of virulence genes [22,23], these bacterial growth assays allowed us to establish the growth stage for this study, in particular compared to MM9. Additionally, because the expression and activity of OxyR are dependent on the growth stage, being most active in the log phase and less in the stationary phase [50], these growth curves allowed us to obtain the cell cultures under functionality conditions of OxyR.

3.2. The Virulence of P. savastanoi pv. phaseolicola NPS3121 Is Influenced by the OxyR Global Regulator

As above mentioned, in various bacteria, the OxyR protein influences the virulence and/or pathogenicity of these microorganisms; the influence is variable (positive or negative) [27,31]. To evaluate whether OxyR participates in the virulence of P. savastanoi pv. phaseolicola NPS3121, we performed in vitro production tests for phaseolotoxin, an important virulence factor of the bacterium, using the oxyR-mutant and the oxyR- C strains. The results showed the absence of formation of halos of growth inhibition in the oxyR-mutant strain assays at both evaluated temperatures (18 °C and 28 °C), compared with the wt strain, which showed the presence of halos of growth inhibition in assays of cultures grown at 18 °C (Figure 2). These halos are representatives of the capacity for phaseolotoxin production by the bacteria. As was expected, the absence of halos of growth inhibition in assays of supernatants of the wt strain grown at 28 °C was observed, congruent with the existent thermoregulation (18 °C) on the synthesis of phaseolotoxin [10,11]. Furthermore, the phaseolotoxin assays showed that the presence of the oxyR gene in trans in the oxyR-mutant background restores the ability for production of phaseolotoxin in this bacterium at 18 °C (Figure 2).
Additionally, plant inoculation tests were performed by bean pod assays as previously described [44]. The results of the bean pod inoculation tests showed the presence of similar necrotic spots among the strains wt, oxyR-mutant, and oxyR- C, which is characteristic of the infection process, while only the wt and oxyR- C strains were able to produce the characteristic water-soaked lesion related to virulence processes. As the control, we inoculated the P. syringae pv. tomato DC3000 strain, which elicited the expected hypersensitive response (HR), and inoculum without bacteria (negative control), which did not produce any symptoms, ruling out that the necrotic spot observed was caused by the inoculation procedure (Figure 2). All these results demonstrate that OxyR is necessary to the phaseolotoxin synthesis and in the virulence of P. savastanoi pv. phaseolicola NPS3121.

3.3. OxyR Positively Influences the Expression of Genes Involved in the Phaseolotoxin Synthesis

Once it was demonstrated that OxyR influences the synthesis of phaseolotoxin by in vitro phaseolotoxin assays, we decided to evaluate whether this influence is related to processes of regulation and/or expression of phaseolotoxin genes. Currently, the Pht and Pbo cluster genomic regions have been identified as involved in the synthesis of phaseolotoxin in P. savastanoi pv. phaseolicola [12,15]. The RT-PCR assays were performed to analyse the expression pattern of genes of the Pht and Pbo clusters in the oxyR-mutant background grown at both 28 °C and 18 °C. As a control, the wt strain cultures grown in similar conditions were assayed, simultaneously. Five genes (argK, phtA, desI, phtL, and amtA), representatives of the five transcriptional units that make up the Pht cluster, were selected and evaluated in these assays. An expression pattern dependent on low temperatures (18 °C) of the Pht cluster genes was observed in the wt background, as expected, while for that in the oxyR-mutant, no transcripts signal was observed at both 28 °C and 18 °C for all the genes evaluated (Figure 3). These results showed that OxyR positively influences the expression of the Pht cluster genes, particularly at 18 °C.
Regarding the Pbo cluster genes, RT-PCR analyses were performed by evaluating the expression of four genes (pboO, pboL, pboA, and pboJ) representative of the four transcriptional units that make up this region. These assays showed the expression pattern expected for the Pbo cluster genes in the wt background, with higher transcript levels at 18 °C compared to 28 °C, with the exception of the pboJ gene, which is similar at both temperatures. The assays in the oxyR-mutant background showed the absence of transcripts signals in all the evaluated genes at both temperatures (Figure 3). These results suggest that the OxyR protein participates in the regulation of the expression at low temperatures (thermoregulation) of the phaseolotoxin genes.

3.4. In P. savastanoi pv. phaseolicola NPS3121, the Pyoverdine Synthesis Is Also a Member of the OxyR Regulon

A phenotypic feature of the cultures of the oxyR-mutant strain, observed during the analyses of bacterial characterization (e.g., bacterial growth curves and virulence assays) mentioned above, is the absence of pyoverdine production, a pigment distinctive of the fluorescent Pseudomonas group. Pyoverdine, major yellow-green Fe(III) chelating siderophore, has been reported as an important virulence factor of various species of Pseudomonas; even its function in the pathogenesis in some biological models of infection has been demonstrated [51,52]. To evaluate the pyoverdine levels present in the oxyR-mutant cultures, we carried out quantitative analysis of this siderophore at 28 °C and 18 °C. The results showed lower amounts of pyoverdine in the oxyR-mutant compared to the wt strain (p < 0.05) at both temperatures tested (28 °C and 18 °C). At 28 °C, the amount of pyoverdine in the culture supernatants of the wt strain was higher (21.42 ± 0.65) compared to the oxyR-mutant (1.49 ± 0.06). Likewise, higher pyoverdine levels in supernatants of the wt strain grown at 18 °C (17.17 ± 0.52) were observed compared to the oxyR-mutant (2.26 ± 0.78). No significant difference was observed between the cell culture supernatants grown at 28 °C and 18 °C for the oxyR-mutant (Figure 4). These findings were confirmed by observing the cell-free supernatants under exposure to UV-light (Figure 3). Additionally, the analysis of the supernatants of the oxyR- C strain showed a significant restoration of the pyoverdine levels at both temperatures compared to the oxyR-mutant (Figure 4). Thus, the results demonstrate that the synthesis of pyoverdine is a function of the OxyR protein.
To assess whether the low levels of pyoverdine observed in the oxyR-mutant strain are because of changes in the expression of the genes regulating the pyoverdine-synthesis, RT-PCR assays were performed evaluating the expression of the pvdS regulator gene. The PvdS alternative sigma factor protein plays an important role in the expression of all the genes of pyoverdine synthesis [53]. The results showed the absence of transcripts signals in the oxyR-mutant background at both temperatures evaluated compared to the wt strain (Figure 3). These results demonstrate that OxyR positively influences the expression of pyoverdine genes in P. savastanoi pv. phaseolicola NPS3121.
Additionally, RT-PCR assays were performed evaluating the expression of the sodB gene encoding for the dismutase superoxide antioxidant enzyme. Like those obtained for the rest of the evaluated genes, the expression of the sodB gene was inhibited in the oxyR-mutant at both temperatures (28 °C and 18 °C) (Figure 3). These results demonstrate that the loss-function OxyR in the mutant strain influences the oxidative stress response.

4. Discussion

A key element in the development of the halo blight disease by P. savastanoi pv. phaseolicola is the effective synthesis of diverse virulence factors, among which phaseolotoxin has been highlighted. Despite its importance, knowledge about the regulatory mechanisms or signal transduction pathways related to the synthesis of this compound is very scarce. Therefore, it is necessary to do more research on this topic to better understand the molecular basis involved in this process. Previous works suggested that the OxyR protein is a member of the signal transduction pathway involved in the thermoregulation of phaseolotoxin, without this being verified yet. In this work, we initiated a study on the role of OxyR in P. savastanoi pv. phaseolicola by focusing on the control of phaseolotoxin production and the virulence of the bacterium. This study demonstrates that OxyR positively influences the expression of genes controlling phaseolotoxin synthesis and pyoverdine production, both important virulence determinants. Additionally, the effect of OxyR on the growth rate of P. savastanoi pv. phaseolicola was also reported.
The bacterial growth curves of the wt and oxyR-mutant strains of P. savastanoi pv. phaseolicola NPS3121 showed that OxyR plays an important role in the optimal growth of the bacterium, mainly at low temperatures (18 °C) and in minimal media conditions. The analysis of the bacterial growth curves in MM9, at 28 °C and 18 °C, showing a clear diminishment in the growth rate in the oxyR-mutant compared to the wt strain at both temperatures, while for those in the rich KB medium, the lack of OxyR only influenced the growth rate of P. savastanoi pv. phaseolicola NPS3121 at low temperatures (18 °C). The diminished bacterial growth rate was partially restored with the presence of the oxyR gene in trans (oxyR-C). No significant change was observed among the wt and oxyR-mutants in KB medium at 28 °C. The influence of the OxyR global regulator on the growth of some bacterial pathogens had been previously reported. A positive influence of OxyR in the growth of Vibrio parahaemolyticus, determined by analysis of an oxyR-mutant strain, has been demonstrated [54]. Likewise, in Shewanella oneidensis, the oxyR mutation was implicated in the cell’s deprived ability to proliferate [55]. Conversely, the null influence of OxyR on the growth of P. syringae pv. tomato DC3000 has been also demonstrated. The growth curve assays carried out for the wt and oxyR-mutants of P. syringae pv. tomato DC3000 in King´s B (KB) media showed that there was no significant difference between the bacterial growth among them [31]. These results are like those obtained in this study where the wt and oxyR-mutants of P. savastanoi pv. phaseolicola NPS3121 grown in KB medium, showed similar growth dynamics at 28 °C. Some studies have demonstrated the influence of growth media composition and/or culture conditions on OxyR in bacterial growth [31,54]. Mostly, under conditions of rich media and/or shaken cultures, no change in the growth among the wt and oxyR-mutant strains has been observed in some pathogenic bacteria [31,54]. Based on this latter, the differences observed in this work in the growth rates of the wt and oxyR-mutant strains of P. savastanoi pv. phaseolicola NPS3121 grown in MM9 compared to those grown in rich KB medium could be due to the differences of composition of these media. Additionally, the analysis of the bacterial growth curves showed a negative effect of the low temperatures (18 °C) on the growth rate of both evaluated strains (wt and oxyR-mutants). This effect of low temperatures had already been previously observed in several P. syringae strains and in P. savastanoi pv. phaseolicola NPS3121 [22,56]. However, the fact that the lack of OxyR resulted in implications in the growth rate mainly at 18 °C in a manner independent of the media composition used, suggests an important role of the OxyR protein in the physiology of the bacterium under low temperature conditions. Additional work is necessary to evaluate the way in which OxyR is involved in the growth of P. savastanoi pv. phaseolicola NPS3121, particularly at low temperatures.
The analyses concerning the influence of OxyR on the virulence and pathogenicity of the bacterium P. savastanoi pv. phaseolicola NPS3121 performed by bean pod assays, demonstrated that OxyR has a critical role in the virulence of the bacteria, but no roles in the pathogenicity processes. The in vitro phaseolotoxin assays confirmed these findings. The absence of the formation of halos of growth inhibition observed in the oxyR-mutant assays compared to the wt strain, and the restoration of these halos of growth inhibition in the oxyR- C strain, clearly demonstrate the implication of the oxyR gene in the ability of cells to produce phaseolotoxin, a major virulence factor of P. savastanoi pv. phaseolicola NPS3121. Similar findings have been previously reported in studies of various phytopathogenic bacteria. The positive influence of OxyR on the virulence of P. syringae pv. tomato DC3000 in Tomato and Arabidopsis plants has been demonstrated [31]. Likewise, OxyR is required for the virulence of the Pantoea stewartii and Ralstonia solanacearum bacteria [32,33]. The way in which OxyR is involved in the production of phaseolotoxin was determined by RT-PCR assays to evaluate the expression pattern of the genes of the Pht and Pbo clusters. The absence of transcript signals for the genes of both the Pht and Pbo clusters observed in the oxyR-mutant background, grown at 28 °C and 18 °C, demonstrate that the influence of OxyR on phaseolotoxin production is through the control or regulation of the expression of genes related to the synthesis of this compound. These results suggest that the OxyR protein acts as an activator to the expression of the phaseolotoxin genes. However, more experimental work is necessary to corroborate this. Although OxyR is primarily thought of as a transcriptional activator, it can function as either a repressor or activator under both oxidizing and reducing conditions [30,57]. On the other hand, despite that the expression of the pboJ gene in the wt strain was constitutive at both 28 °C and 18 °C, unlike the low-temperature-dependent expression of the remaining genes in the Pbo cluster and the Pht cluster genes, the pboJ expression was also decreased in the oxyR-mutant at both evaluated temperatures. These results demonstrate that OxyR influences the expression of the phaseolotoxin genes in a manner independent of the temperature. Furthermore, these results demonstrate that synthesis of phaseolotoxin and the genes of the Pht and Pbo clusters are members of the OxyR regulon in P. savastanoi pv. phaseolicola NPS3121.
The positive influence of OxyR on the expression of genes related to the virulence factors production has been documented in P. syringae pv. tomato DC3000, where OxyR promotes the expression of the algD gene involved in the exopolysaccharide alginate synthesis [31]. Similarly, OxyR positively influences the expression of various genes related to virulence in P. aeruginosa PAO1 [29]. On the other hand, and contrary to what was observed in this study, it has been reported that during infection of P. syringae pv. tomato DC3000, whose oxyR-mutant is compromised in its virulence to Arabidopsis and tomato plants, there is no direct implication of OxyR on the expression of genes related to the production of coronatine (corR), the main phytotoxin produced by this pathovar [31]. This agrees with what has been reported in that the targets of the OxyR protein are different, or particular, among bacteria [30].
A distinctive feature of the cultures of the oxyR-mutant of P. savastanoi pv. phaseolicola NPS3121 was the absence of the yellow-green pigment characteristic of the fluorescent Pseudomonas group, which is related to the pyoverdine siderophore production. The confirmation that OxyR influences the production of pyoverdine was performed by quantitative analysis of this siderophore. These analyses showed the presence of low levels of pyoverdine in assays with the oxyR-mutant strain compared to the wt strain. Pyoverdine levels in the oxyR-mutant were significantly restored by the presence in trans of the oxyR gene (oxyR- C strain). Through RT-PCR assays, we demonstrated that these low levels of pyoverdine are because of the decrease in the expression of the gene encoding to PvdS obtained in the oxyR-mutant strain at both evaluated temperatures. The PvdS sigma factor activates the transcription of pyoverdine biosynthethic genes [51]. Furthermore, the influence of PvdS in the expression of genes that encode virulence factors has been documented [51,53]. These results demonstrate that OxyR positively influences the pyoverdine synthesis by the positive regulation of the pvdS gene in P. savastanoi pv. phaseolicola NPS3121. The regulation of the pvdS gene by the OxyR protein had been previously reported in P. aeruginosa PAO1 [29]. On the other hand, the results of these analyses further demonstrate that pyoverdine synthesis and genes related to this process are also members of the OxyR regulon in P. savastanoi pv. phaseolicola NPS3121.
The pyoverdine siderophore has also been reported to be an important virulence factor in some pathovars of P. syringae, implicated in the phytotoxins synthesis, extracellular polysaccharide, and the quorum sensing mechanism [58]. Therefore, the reduced virulence observed on the bean pod inoculation tests with the oxyR-mutant of P. savastanoi pv. phaseolicola NPS3121 could also be considered related to the low levels of pyoverdine present in this strain and not just with the inhibition of the phaseolotoxin synthesis. However, previous work in P. syringae pv. tomato DC3000 and P. syringae pv. phaseolicola 1448A have demonstrated that pyoverdine does not have a determinative role in the pathogenesis or virulence of these bacteria in their host plants [59].
The OxyR regulon has been widely studied in the E. coli and in P. aeruginosa bacteria. Although there are significant differences, the OxyR regulons of these and other microorganisms tend to include similar classes of genes as those involved in the defence to oxidative stress and iron homeostasis [29,30,60]. In particular, in P. aeruginosa PAO1, the OxyR regulon also includes genes involved in quorum-sensing, protein synthesis, oxidative phosphorylation, secretion and virulence factors encoding genes [29]. Thus far, the OxyR regulon of the P. syringae bacteria, including pv. phaseolicola has been poorly studied. Recent studies on P. syringae pv. tomato DC3000 have identified genes encoding thrioredoxins, thioredoxin reductase, and catalases, as being influenced by the OxyR protein. Likewise, genes involved in the alginate biosynthesis were identified as members of this regulon. The partial or indirect influence of OxyR on the expression of regulators of the T3SS and coronatine synthesis also was demonstrated [31]. Our study is the first report on members of the OxyR regulon in the P. savastanoi pv. phaseolicola NPS3121 bacterium.

5. Conclusions

In this study, we report that OxyR positively influences the synthesis of phaseolotoxin by regulation of the expression of genes of the Pht and Pbo clusters leading to a non-toxigenic phenotype of P. savastanoi pv. phaseolicola NPS3121. Likewise, the implication of OxyR in the synthesis of pyoverdine and oxidative stress is demonstrated in this study.

Author Contributions

Conceptualization, J.L.A.-G. and A.H.-M.; methodology, J.L.A.-G., R.A.J.-N., J.D.P.-T. and A.H.-M.; formal analysis, J.L.A.-G. and A.H.-M.; investigation, J.L.A.-G., R.A.J.-N., J.D.P.-T. and A.H.-M.; writing—original draft preparation, J.L.A.-G., A.H.-M., J.C.-G.; J.R.P.-A., A.B.M.-R. and C.G.-R.; writing—review and editing, J.L.A.-G., A.H.-M., J.C.-G. and J.R.P.-A.; supervision, project administration, funding acquisition, J.L.A.-G. All authors have read and agreed to the published version of the manuscript.

Funding

This research was funded by grants from Fondo Frontera de la Ciencia CONACYT, FORDECYT-PRONACES/137707/2020, (CF 2019-137707) to Arvizu-Gómez Jackeline Lizzeta (Universidad Autónoma de Nayarit).

Acknowledgments

We are grateful to PTI Israel Mora Ávalos for the technical support performed.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Department of Crop Science. Bacterial Diseases of Beans; Report on Plant Disease; Department of Crop Science: Urbana, IL, USA, 2000. [Google Scholar]
  2. Schwartz, H.F. Halo blight. In Bean Production Problems in the Tropics, 2nd ed.; Schwartz, H.F., Pastor-Corrales., M., Eds.; CIAT: Cali, Colombia, 1989; pp. 285–293. ISBN 958-9183-04-2. [Google Scholar]
  3. Agrios, G.E. Plant Pathology, 5th ed.; Academic Press: Burlington, MA, USA, 2005. [Google Scholar]
  4. Bender, C.L.; Alarcón-Chaidez, F.; Gross, D.C. Pseudomonas syringae Phytotoxins: Mode of Action, Regulation, and Biosynthesis by Peptide and Polyketide Synthetases. Microbiol. Mol. Biol. Rev. 1999, 63, 266–292. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  5. Mitchell, R.E. Isolation and Structure of a Chlorosis-Inducing Toxin of Pseudomonas phaseolicola. Phytochemistry 1976, 15, 1941–1947. [Google Scholar] [CrossRef]
  6. Mitchell, R.E.; Bieleski, R.L. Involvement of Phaseolotoxin in Halo Blight of Beans. Plant Physiol. 1977, 60, 723–729. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  7. Ferguson, A.R.; Johnston, J.S. Phaseolotoxin: Chlorosis, Ornithine Accumulation and Inhibition of Ornithine Carbamoyltransferase in Different Plants. Physiol. Plant Pathol. 1980, 16, 269–275. [Google Scholar] [CrossRef]
  8. Smith, A.G.; Rubery, P.H. Investigation of the Mechanism of Action of a Chlorosis-Inducing Toxin Produced by Pseudomonas phaseolicola. Plant Physiol. 1982, 70, 932–938. [Google Scholar] [CrossRef] [Green Version]
  9. Mitchell, R.E. Bean Halo-Blight Toxin. Nature 1976, 260, 75–76. [Google Scholar] [CrossRef]
  10. Goss, R.W. The relation of temperature to common and halo blight of beans. Phytopathology 1970, 30, 258–264. [Google Scholar]
  11. Nüske, J.; Fritsche, W. Phaseolotoxin Production By Pseudomonas syringae pv. phaseolicola: The Influence of Temperature. J. Basic Microbiol. 1989, 29, 441–447. [Google Scholar] [CrossRef]
  12. Aguilera, S.; López-López, K.; Nieto, Y.; Garciduenas-Pina, R.; Hernández-Guzmán, G.; Hernández-Flores, J.L.; Murillo, J.; Alvarez-Morales, A. Functional Characterization of the Gene Cluster from Pseudomonas syringae pv. Phaseolicola NPS3121 Involved in Synthesis of Phaseolotoxin. J. Bacteriol. 2007, 189, 2834–2843. [Google Scholar] [CrossRef] [Green Version]
  13. Genka, H.; Baba, T.; Tsuda, M.; Kanaya, S.; Mori, H.; Yoshida, T.; Noguchi, M.T.; Tsuchiya, K.; Sawada, H. Comparative Analysis of ArgK-Tox Clusters and Their Flanking Regions in Phaseolotoxin-Producing Pseudomonas syringae Pathovars. J. Mol. Evol. 2006, 63, 401–414. [Google Scholar] [CrossRef]
  14. Sawada, H.; Kanaya, S.; Tsuda, M.; Suzuki, F.; Azegami, K.; Saitou, N. A Phylogenomic Study of the OCTase Genes in Pseudomonas syringae Pathovars: The Horizontal Transfer of the ArgKTox Cluster and the Evolutionary History of OCTase Genes on Their Genomes. J. Mol. Evol. 2002, 54, 437–457. [Google Scholar] [CrossRef] [PubMed]
  15. Guardado-Valdivia, L.; Chacón-López, A.; Murillo, J.; Poveda, J.; Hernández-Flores, J.L.; Xoca-Orozco, L.; Aguilera, S. The Pbo Cluster from Pseudomonas syringae pv. Phaseolicola NPS3121 Is Thermoregulated and Required for Phaseolotoxin Biosynthesis. Toxins 2021, 13, 628. [Google Scholar] [CrossRef] [PubMed]
  16. Aguilera, S.; De la Torre-Zavala, S.; Hernández-Flores, J.L.; Murillo, J.; Bravo, J.; Alvarez-Morales, A. Expression of the Gene for Resistance to Phaseolotoxin (ArgK) Depends on the Activity of Genes PhtABC in Pseudomonas syringae pv. Phaseolicola. PLoS ONE 2012, 7, e46815. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  17. Aguilera, S.; Alvarez-Morales, A.; Murillo, J.; Hernández-Flores, J.L.; Bravo, J.; De la Torre-Zavala, S. Temperature-Mediated Biosynthesis of the Phytotoxin Phaseolotoxin by Pseudomonas syringae pv. Phaseolicola Depends on the Autoregulated Expression of the PhtABC Genes. PLoS ONE 2017, 12, e0178441. [Google Scholar] [CrossRef] [Green Version]
  18. González-Villanueva, L.; Arvizu-Gómez, J.L.; Hernández-Morales, A.; Aguilera-Aguirre, S.; Álvarez-Morales, A. The PhtL Protein of Pseudomonas syringae pv. Phaseolicola NPS3121 Affects the Expression of Both Phaseolotoxin Cluster (Pht) and Non-Pht Encoded Genes. Microbiol. Res. 2014, 169, 221–231. [Google Scholar] [CrossRef]
  19. Arvizu-Gómez, J.L.; Hernández-Morales, A.; Pastor-Palacios, G.; Brieba, L.G.; Álvarez-Morales, A. Integration Host Factor (IHF) Binds to the Promoter Region of the PhtD Operon Involved in Phaseolotoxin Synthesis in P. Syringae pv. Phaseolicola NPS3121. BMC Microbiol. 2011, 11, 11–90. [Google Scholar] [CrossRef] [Green Version]
  20. De la Torre-Zavala, S.; Aguilera, S.; Ibarra-Laclette, E.; Hernandez-Flores, J.L.; Hernández-Morales, A.; Murillo, J.; Álvarez-Morales, A. Gene Expression of Pht Cluster Genes and a Putative Non-Ribosomal Peptide Synthetase Required for Phaseolotoxin Production Is Regulated by GacS/GacA in Pseudomonas syringae pv. Phaseolicola. Res. Microbiol. 2011, 162, 488–498. [Google Scholar] [CrossRef]
  21. Álvarez-Morales, A.; Hernández-Morales, A.; Arvizu-Gómez, J.L. A 14–20 KDa Protein Binds to the Upstream Region of the PhtM Operon Involved in the Synthesis of Phaseolotoxin in Pseudomonas syringae pv. Phaseolicola NPS3121. Rev. Argent. De Microbiol. 2018, 50, 115–125. [Google Scholar] [CrossRef]
  22. Arvizu-Gómez, J.L.; Hernández-Morales, A.; Aguilar, J.R.P.; Álvarez-Morales, A. Transcriptional Profile of P. Syringae pv. Phaseolicola NPS3121 at Low Temperature: Physiology of Phytopathogenic Bacteria. BMC Microbiol. 2013, 13, 81. [Google Scholar] [CrossRef] [Green Version]
  23. Hernández-Morales, A.; Rojas-Morales, J.A.; Reynoso-López, M.; Martínez-Rizo, A.B.; Velázquez-Fernández, J.B.; Arvizu-Gómez, J.L. Oxidative Stress Regulates the Expression of the Pht Cluster Genes Involved in Phaseolotoxin Synthesis in Pseudomonas syringae pv. Phaseolicola NPS3121. J. Gen. Plant Pathol. 2018, 84, 137–141. [Google Scholar] [CrossRef]
  24. Chiang, S.M.; Schellhorn, H.E. Regulators of Oxidative Stress Response Genes in Escherichia coli and Their Functional Conservation in Bacteria. Arch. Biochem. Biophys. 2012, 525, 161–169. [Google Scholar] [CrossRef] [PubMed]
  25. Demple, B. Regulation of Bacterial Oxidative Stress Genes. Annu. Rev. Genet. 1991, 25, 315–337. [Google Scholar] [CrossRef] [PubMed]
  26. Imlay, J.A. Cellular Defenses against Superoxide and Hydrogen Peroxide. Annu. Rev. Biochem. 2008, 77, 755–776. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  27. Teramoto, H.; Inui, M.; Yukawa, H. OxyR Acts as a Transcriptional Repressor of Hydrogen Peroxide-Inducible Antioxidant Genes in Corynebacterium glutamicum R. FEBS J. 2013, 280, 3298–3312. [Google Scholar] [CrossRef]
  28. Harrison, A.; Ray, W.C.; Baker, B.D.; Armbruster, D.W.; Bakaletz, L.O.; Munson, R.S. The OxyR Regulon in Nontypeable Haemophilus influenzae. J. Bacteriol. 2007, 189, 1004–1012. [Google Scholar] [CrossRef] [Green Version]
  29. Wei, Q.; Le Minh, P.N.; Dötsch, A.; Hildebrand, F.; Panmanee, W.; Elfarash, A.; Schulz, S.; Plaisance, S.; Charlier, D.; Hassett, D.; et al. Global Regulation of Gene Expression by OxyR in an Important Human Opportunistic Pathogen. Nucleic Acids Res. 2012, 40, 4320–4333. [Google Scholar] [CrossRef]
  30. Dubbs, J.M.; Mongkolsuk, S. Peroxide-Sensing Transcriptional Regulators in Bacteria. J. Bacteriol. 2012, 194, 5495–5503. [Google Scholar] [CrossRef] [Green Version]
  31. Ishiga, Y.; Ichinose, Y. Pseudomonas syringae pv. tomato OxyR Is Required for Virulence in Tomato and Arabidopsis. Mol. Plant-Microbe Interact. 2016, 29, 119–131. [Google Scholar] [CrossRef] [Green Version]
  32. Burbank, L.; Roper, M.C. OxyR and SoxR Modulate the Inducible Oxidative Stress Response and Are Implicated during Different Stages of Infection for the Bacterial Phytopathogen Pantoea Stewartii Subsp. Stewartii. Mol. Plant-Microbe Interact. 2014, 27, 479–490. [Google Scholar] [CrossRef] [Green Version]
  33. Flores-Cruz, Z.; Allen, C. Necessity of OxyR for the Hydrogen Peroxide Stress Response and Full Virulence in Ralstonia solanacearum. Appl. Environ. Microbiol. 2011, 77, 6426–6432. [Google Scholar] [CrossRef] [Green Version]
  34. Peet, R.C.; Lindgren, P.B.; Willis, D.K.; Panopoulos, N.J. Identification and Cloning of Genes Involved in Phaseolotoxin Production by Pseudomonas syringae pv. “Phaseolicola”. J. Bacteriol. 1986, 166, 1096–1105. [Google Scholar] [CrossRef] [PubMed]
  35. Yanisch-Perron, C.; Vieira, J.; Messing, J. Improved M13 Phage Cloning Vectors and Host Strains: Nucleotide Sequences of the M13mpl8 and PUC19 Vectors. Gene 1985, 33, 103–119. [Google Scholar] [CrossRef]
  36. Chen, W.; Kuo, T. A Simple and Rapid Method for the Preparation of Gram-Negative Bacterial Genomic DNA. Nucleic Acids Res. 1993, 21, 2260. [Google Scholar] [CrossRef] [PubMed]
  37. Sambrook, J.; Fritsch, E.F.; Maniatis, T. This Is a Free Sample of Content from Molecular Cloning: A Laboratory Manual, 2nd ed.; Cold Spring Harbor: New York, NY, USA, 1989. [Google Scholar]
  38. Joardar, V.; Lindeberg, M.; Jackson, R.W.; Selengut, J.; Dodson, R.; Brinkac, L.M.; Daugherty, S.C.; DeBoy, R.; Durkin, A.S.; Giglio, M.G.; et al. Whole-Genome Sequence Analysis of Pseudomonas syringae pv. Phaseolicola 1448A Reveals Divergence among Pathovars in Genes Involved in Virulence and Transposition. J. Bacteriol. 2005, 187, 6488–6498. [Google Scholar] [CrossRef] [Green Version]
  39. Lane, D.J. 16S/23S rRNA sequencing. In Nucleic Acid Techniques in Bacterial Systematics; Stackebrandt, E., Goodfellow, M., Eds.; John Wiley & Sons, Inc.: New York, NY, USA, 1991; pp. 115–176. [Google Scholar]
  40. Windgassen, M.; Urban, A.; Jaeger, K.J. Rapid Gene Inactivation in Pseudomonas aeruginosa. FEMS Microbiol. Lett. 2000, 193, 201–205. [Google Scholar] [CrossRef]
  41. Kovach, M.E.; Elzer, P.H.; Hill, D.S.; Robertson, G.T.; Farris, M.A.; Roop, R.M., II; Peterson, K.M. Four new derivatives of the broad-host-range cloning vector pBBR1MCS, carrying different antibiotic-resistance cassettes. Gene 1995, 166, 175–176. [Google Scholar] [CrossRef]
  42. Staskawicz, B.J.; Panopoulos, N.J. A rapid and sensitive assay for phaseolotoxin. Phytopathology 1979, 69, 663–666. [Google Scholar] [CrossRef]
  43. Hernández-Guzmán, G.; Alvarez-Morales, A. Isolation and Characterization of the Gene Coding for the Amidinotransferase Involved in the Biosynthesis of Phaseolotoxin in Pseudomonas syringae pv. phaseolicola. Mol. Plant-Microbe Interact. 2001, 14, 545–554. [Google Scholar] [CrossRef] [Green Version]
  44. Cheng, G.Y.; Legard, D.E.; Hunter, J.E.; Burr, T.J. Modified Bean Pod Assay to Detect Strains of Pseudomonas syringae pv. syringae that Cause Bacterial Brown Spot of Snap Bean. Plant Dis. 1989, 73, 419–423. [Google Scholar] [CrossRef]
  45. Meyer, J.M.; Abdallah, M.A. The Fluorescent pigment of Pseudomonas fluorescens: Biosynthesis, purifications and Physicochemical properties. J. Gen. Microbiol. 1978, 107, 319–328. [Google Scholar] [CrossRef] [Green Version]
  46. Michel-Briand, Y.; Baysse, C. The pyocins of Pseudomonas aeruginosa. Biochimie 2002, 84, 499–510. [Google Scholar] [CrossRef] [PubMed]
  47. Arvizu-Gómez, J.L. Image that Demonstrates the Integration of the Suicide Plasmid pCR4-TOPO::oxyR Disrupted in the Interest Chromosomal Region oxyR in the P. savastanoi pv. phaseolicola NPS3121 Validated by PCR Assays; Secretaría de Investigación y Posgrado, Centro Nayarita de Innovación y Transferencia de Tecnología, Universidad Autónoma de Nayarit: Tepic, Mexico, Material Not Intented for Publicaction.
  48. O’Malley, M.R.; Anderson, J.C. Regulation of the Pseudomonas syringae Type III Secretion System by Host Environment Signals. Microorganisms 2021, 9, 1227. [Google Scholar] [CrossRef]
  49. Ott, C.M.; Day, D.F.; Koenig, D.W.; Pierson, D.L. The release of alginate lyase from growing Pseudomonas syringae pathovar phaseolicola. Curr. Microbiol. 2001, 42, 78–81. [Google Scholar] [CrossRef] [PubMed]
  50. González-Flecha, B.; Demple, B. Transcriptional regulation of the Escherichia coli oxyR gene as a function of cell growth. J. Bacteriol. 1997, 179, 6181–6186. [Google Scholar] [CrossRef] [Green Version]
  51. Schalk, I.J.; Rigouin, C.; Godet, J. An Overview of Siderophore Biosynthesis among Fluorescent Pseudomonads and New Insights into Their Complex Cellular Organization. Environ. Microbiol. 2020, 22, 1447–1466. [Google Scholar] [CrossRef]
  52. Kang, D.; Revtovich, A.V.; Chen, Q.; Shah, K.N.; Cannon, C.L.; Kirienko, N.V. Pyoverdine-Dependent Virulence of Pseudomonas aeruginosa Isolates From Cystic Fibrosis Patients. Front. Microbiol. 2019, 10, 2048. [Google Scholar] [CrossRef] [Green Version]
  53. Wilson, M.J.; McMorran, B.J.; Lamont, I.L. Analysis of Promoters Recognized by PvdS, an Extracytoplasmic-Function Sigma Factor Protein from Pseudomonas Aeruginosa. J. Bacteriol. 2001, 183, 2151–2155. [Google Scholar] [CrossRef] [Green Version]
  54. Chung, C.-H.; Fen, S.; Yu, S.-C.; Wong, H. Influence of OxyR on Growth, Biofilm Formation, and Mobility of Vibrio parahaemolyticus. Appl. Environ. Microbiol. 2016, 82, 788–796. [Google Scholar] [CrossRef] [Green Version]
  55. Wan, F.; Yin, J.; Sun, W.; Gao, H. Oxidized OxyR Up-Regulates AhpCF Expression to Suppress Plating Defects of OxyR- and Catalase-Deficient Strains. Front. Microbiol. 2019, 10, 439. [Google Scholar] [CrossRef] [Green Version]
  56. Young, J.M.; Luketina, R.C.; Marshall, A.M. The Effects on Temperature on Growth in Vitro of Pseudomonas syringae and Xanthomonas pruni. J. Appl. Bacteriol. 1977, 42, 345–354. [Google Scholar] [CrossRef]
  57. Ieva, R.; Roncarati, D.; Metruccio, M.M.E.; Seib, K.L.; Scarlato, V.; Delany, I. OxyR Tightly Regulates Catalase Expression in Neisseria Meningitidis through Both Repression and Activation Mechanisms. Mol. Microbiol. 2008, 70, 1152–1165. [Google Scholar] [CrossRef]
  58. Taguchi, F.; Suzuki, T.; Inagaki, Y.; Toyoda, K.; Shiraishi, T.; Ichinose, Y. The siderophore pyoverdine of Pseudomonas syringae pv. tabaci 6605 is an intrinsic virulence factor in host tobacco infection. J. Bacteriol. 2010, 92, 117–126. [Google Scholar] [CrossRef] [Green Version]
  59. Owen, J.G.; Ackerley, D.F. Characterization of pyoverdine and achromobactin in Pseudomonas syringae pv. phaseolicola 1448a. BMC Microbiol. 2011, 11, 218. [Google Scholar] [CrossRef] [Green Version]
  60. Storz, G.; Tartaglia, L.A.; Ames, B.N. The OxyR Regulon. Antonie Van Leeuwenhoek 1990, 58, 157–161. [Google Scholar] [CrossRef]
Microorganisms 10 02123 g001 550
Figure 1. Growth curves of the wt, oxyR-mutant, and oxyR- C (complemented mutant) strains of P. savastanoi pv. phaseolicola NPS3121. (a) Bacterial growth curves at 28 °C in MM9. (b) Bacterial growth curves at 18 °C in MM9. (c) Bacterial growth curves at 28 °C in KB medium. (d) Bacterial growth curves at 18 °C in KB medium.
Figure 1. Growth curves of the wt, oxyR-mutant, and oxyR- C (complemented mutant) strains of P. savastanoi pv. phaseolicola NPS3121. (a) Bacterial growth curves at 28 °C in MM9. (b) Bacterial growth curves at 18 °C in MM9. (c) Bacterial growth curves at 28 °C in KB medium. (d) Bacterial growth curves at 18 °C in KB medium.
Microorganisms 10 02123 g001
Microorganisms 10 02123 g002 550
Figure 2. Phaseolotoxin synthesis test and bean pod pathogenicity assays. Left panel shows the phaseolotoxin production assays in vitro. Right panel shows the bean pod assays. (a) P. savastanoi pv. phaseolicola wt strain. (b) oxyR-mutant strain. (c) oxyR- complemented mutant strain [oxyR- C]. (d) P. syringae pv. tomato DC3000 strain.
Figure 2. Phaseolotoxin synthesis test and bean pod pathogenicity assays. Left panel shows the phaseolotoxin production assays in vitro. Right panel shows the bean pod assays. (a) P. savastanoi pv. phaseolicola wt strain. (b) oxyR-mutant strain. (c) oxyR- complemented mutant strain [oxyR- C]. (d) P. syringae pv. tomato DC3000 strain.
Microorganisms 10 02123 g002
Microorganisms 10 02123 g003 550
Figure 3. Expression analysis by RT-PCR assays and pyoverdine production. The figure depicts the effects that the OxyR protein exerts on the expression of the studied genes and on the pyoverdine synthesis. In the figure is included a graphic representation of the Pht and Pbo clusters and sodB, pvdS genes. The housekeeping 16S rDNA gene (16S) was also evaluated and used as an internal control. Each arrow represents an individual gene, with the direction of the arrow indicating the direction of transcription. Gray arrows indicate the genes evaluated by RT-PCR analyses, which are shown under each gene evaluated by a band amplified (black) or absent in wild type and oxyR-mutant al 28 °C (indicated by red triangle) and 18 °C (indicated by blue triangle). Twenty-eight amplification cycles were used in most of the RT-PCR assays. The 16SrRNA was evaluated using 23 cycles of amplification. Representative image showing the production of fluorescent siderophore pyoverdine assessed under UV light is also included.
Figure 3. Expression analysis by RT-PCR assays and pyoverdine production. The figure depicts the effects that the OxyR protein exerts on the expression of the studied genes and on the pyoverdine synthesis. In the figure is included a graphic representation of the Pht and Pbo clusters and sodB, pvdS genes. The housekeeping 16S rDNA gene (16S) was also evaluated and used as an internal control. Each arrow represents an individual gene, with the direction of the arrow indicating the direction of transcription. Gray arrows indicate the genes evaluated by RT-PCR analyses, which are shown under each gene evaluated by a band amplified (black) or absent in wild type and oxyR-mutant al 28 °C (indicated by red triangle) and 18 °C (indicated by blue triangle). Twenty-eight amplification cycles were used in most of the RT-PCR assays. The 16SrRNA was evaluated using 23 cycles of amplification. Representative image showing the production of fluorescent siderophore pyoverdine assessed under UV light is also included.
Microorganisms 10 02123 g003
Microorganisms 10 02123 g004 550
Figure 4. Pyoverdine production by the P. savastanoi pv. phaseolicola NPS3121 strains. (a) Pyoverdine levels in the cell free supernatants of the wt, oxyR-mutant, and oxyR- C strains, grown at 28 °C. (b) Pyoverdine levels in the cell free supernatants of the wt, oxyR-mutant, and oxyR- C strains, grown at 18 °C. Bars represent the means ± SD (n = 3). Different letters represent means that are statistically different (p < 0.05).
Figure 4. Pyoverdine production by the P. savastanoi pv. phaseolicola NPS3121 strains. (a) Pyoverdine levels in the cell free supernatants of the wt, oxyR-mutant, and oxyR- C strains, grown at 28 °C. (b) Pyoverdine levels in the cell free supernatants of the wt, oxyR-mutant, and oxyR- C strains, grown at 18 °C. Bars represent the means ± SD (n = 3). Different letters represent means that are statistically different (p < 0.05).
Microorganisms 10 02123 g004
Table
Table 1. The PCR primers used in this study.
Table 1. The PCR primers used in this study.
Gene/PrimersSequence (5´-3´)Reference
Pht Cluster
argK
L10001CTTTGATGGTATGCATGCGGTT[12]
L10002GGAAGAACTGGCCAAACATTCG
phtA
phtA fwATACTTTCCCTGTTTCCGGA[23]
phtA rvTAAACAGTGGTCAGCTTGTC
desI
P16881TCAACAACATCCACGGGCAT[12]
G720GATATCGCAGCAACACCCATAAAAC
phtL
phtL fwCTGGATGCATCTGTCGGAAT[23]
phtL rvGCCAGCAATGCATCGCTATG
amtA
BRL519TTCATTCAAACCTCGCCCGTGTG[12]
BRL520TGAAAGGAGCCGCCGAAACTATTG
Pbo Cluster
pboO
S126dGCCGTTGTGATAGCCGACAGTGA[15]
S127cAACGCCAGCGCTTCATCCTTGT
pboL
S136dCCACGCTGGACAACATGGTGATC[15]
S137cCATACTTTCTGGCCGCTACCCATTC
pboA
S134dGCAAATTGCCAGTTGCGTTGCC[15]
S135cCCTTTCGGTGTACCGGTAGAACCAG
pboJ
S132dTCTGTTCTGCAGCCTCAACGTGG[15]
S133cTGAGCTGGACAAATTCAATGGAGTGA
Pyoverdine
pvdS
L100277-1909DGACTCACCATTACTCCAGGC[22]
L100278-1909RAGACGGTACATCTCGAACGC
Control
16S ribosomal
27f-1775AGAGTTTGATCMTGGCTCAG[39]
1492R-1776TACGGYTACCTTGTTACGACTT
Construction of oxyR-mutant
OxyR-FWDAGCAGGCTCAAGGTATTCGTThis study
OxyR-REVGAAGCGACCATGTGCCGAATThis study
Construction of oxyR- complemented mutant (oxyR- C)
pOxyR250-SmaICCCGGGACTCGATTGCCAACAGTTCAGGThis study
OxyRRev-BamHIGGATCCCTAACTTGCGACTGTTTTCGGAThis study
Publisher’s Note: MDPI stays neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Share and Cite

MDPI and ACS Style

Arvizu-Gómez, J.L.; Hernández-Morales, A.; Juárez-Navarro, R.A.; Paredes-Tadeo, J.D.; Campos-Guillén, J.; Pacheco-Aguilar, J.R.; Martínez-Rizo, A.B.; González-Reyes, C. OxyR Positively Influences Phaseolotoxin Synthesis and Pyoverdin Production in Pseudomonas savastanoi pv. phaseolicola NPS3121. Microorganisms 2022, 10, 2123. https://doi.org/10.3390/microorganisms10112123

AMA Style

Arvizu-Gómez JL, Hernández-Morales A, Juárez-Navarro RA, Paredes-Tadeo JD, Campos-Guillén J, Pacheco-Aguilar JR, Martínez-Rizo AB, González-Reyes C. OxyR Positively Influences Phaseolotoxin Synthesis and Pyoverdin Production in Pseudomonas savastanoi pv. phaseolicola NPS3121. Microorganisms. 2022; 10(11):2123. https://doi.org/10.3390/microorganisms10112123

Chicago/Turabian Style

Arvizu-Gómez, Jackeline Lizzeta, Alejandro Hernández-Morales, Rafael Arnulfo Juárez-Navarro, Juan Diego Paredes-Tadeo, Juan Campos-Guillén, Juan Ramiro Pacheco-Aguilar, Abril Bernardette Martínez-Rizo, and Christian González-Reyes. 2022. "OxyR Positively Influences Phaseolotoxin Synthesis and Pyoverdin Production in Pseudomonas savastanoi pv. phaseolicola NPS3121" Microorganisms 10, no. 11: 2123. https://doi.org/10.3390/microorganisms10112123

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
