Beneficial Effects of Young Coconut Juice on Increasing Skin Thickness, Enhancing Skin Whitening, and Reducing Skin Wrinkles in Ovariectomized Rats

by
Nisaudah Radenahmad
1,*,†,
Amornpun Sereemaspun
2,†,
Nurdeen Bueraheng
1 and
Albert Manggading Hutapea
3
1
Division of Health and Applied Sciences, Faculty of Science, Prince of Songkla University, Hat Yai, Songkhla 90110, Thailand
2
Nanomedicine Research Unit, Department of Anatomy, Faculty of Medicine, Chulalongkorn University, Bangkok 10330, Thailand
3
Department of Pharmacy, Faculty of Science, Universitas Advent Indonesia, Bandung 40559, Indonesia
*
Author to whom correspondence should be addressed.
†
These authors contributed equally to this work.
Appl. Sci. 2022, 12(3), 1584; https://doi.org/10.3390/app12031584
Submission received: 1 December 2021 / Revised: 21 January 2022 / Accepted: 28 January 2022 / Published: 1 February 2022
Browse Figures
Versions Notes

Abstract

:
It has been previously demonstrated in light microscopic and immunohistochemical studies that ovariectomized rats receiving young coconut juice at 100 mL/kg BW showed much better wound healing and improved skin complexion. Nevertheless, it was found that young coconut juice at 100 mL/kg BW/day caused unfavorable side effects, such as glycogen deposition in the liver. Therefore, in the current study, 3 lower doses (10, 20, and 40 mL/kg BW/day) were optimized, and the ultrastructure was further investigated. Compared to normal rats, all the parameters regarding skin changes, including epidermal and dermal thickness, the number of hair follicles, the diameters of collagen fibrils, perimeters, and nuclei of fibroblast and keratinocyte cells, and ultrastructural changes in keratinocyte and fibroblast cells were significantly reduced in ovariectomized rats. Those parameters in the ovariectomized rats were restored to normal by injecting estradiol benzoate or by feeding young coconut juice to the rats, where the effect was found to be dose-related but not in the case of all the parameters. In most cases, a dose of young coconut juiceof 40 mL/kg BW/day was the optimal dose. The results suggest that young coconut juice may be as effective as estradiol benzoate in reducing skin atrophy/aging, probably as a selective estrogen receptor moderator.

1. Introduction

The skin is the body’s biggest organ. As it gets older, it starts to degenerate. The skin serves a variety of purposes, including protecting the body, regulating temperature, and acting as a sensory organ [1]. Skin aging is characterized by a loss of elasticity, decreased epidermal thickness, and the degeneration of dermal collagen and elastic fibers, resulting in wrinkles and skin dryness [2].
Hormones have an affinity with the skin. Estrogens influenceskin’swater-holding capacity [3], vascularity [4], pigmentation [5], and elasticity [6], among other skin functions. Estrogens influence skin thickness, wrinkles, and hydration, thus helping to prevent skin aging [7]. Estrogens influence the skin and its appendages, such as hair follicles [8]. Ovarian estrogen is a major source of estrogen in women, but it decreases with age, especially following menopause [9]. The skin of menopausal women undergoes degenerative changes. The skin’s thickness declines by 1.13 percent every year after menopause, whereas the collagen content decreases by 2 percent [10]. The skin’s ability to protect itself against oxidative stress is also impaired by estrogen deficiency. Collagen deficit causes the skin to become thin, losing suppleness and demonstrating wrinkles, dryness, and vascularity [2]. Estrogen replacement therapy can improve keratinocyte proliferation, epidermal thickness, skin suppleness, collagen content and quality, and vascularization, and reduce wrinkles, all of which effects can help to reverse these skin changes [8,11,12]. Hormone replacement therapy (HRT) can help protect the skin as one becomes older, especially if one is going through menopause (the period when estrogen levels drop dramatically). Despite this, HRT increases the risk of a variety of cancers, including invasive breast cancer [13] and uterine cancer [14,15], as well as cardiovascular illness, including an increased risk of heart attack, stroke, and blood clots [13]. Phytoestrogens are naturally occurring selective estrogen receptor modulators (SERMs) that can provide a natural estrogen replacement for postmenopausal women.
This research team discovered in 2006 that ovariectomized (ovx) rats given young coconut juice (YCJ) demonstrated considerably improved wound healing (including reduced scarring), brighter skin, and shorter hair than controls [16]. The phytoestrogenic properties of YCJ [17], binding with ERα and ERβ [18] and downregulating the macrophage migratory inhibitory factor (MIF) [19], were later discovered to be responsible for the favorable effects of YCJ on accelerating cutaneous wound healing. At 100 mL/kg BW/day, the YCJ supplement had adverse side effects, such as glycogen accumulation in the liver [18]. As a result, three lower dosages of YCJ (10, 20, and 40 mL/kg body weight, respectively) were used in the current investigation. Using ovariectomized rats as a model for postmenopausal women, the current study aimed to determine the optimal dose of YCJ, with the fewest adverse effects on cutaneous alterations, to alleviate skin problems in aging/menopausal women using light microscopy (LM) and transmission electron microscopy (TEM).

2. Materials and Methods

2.1. YCJ Preparation

YCJ was collected in considerable quantities in the Khlong Hoi Khong region of Hat Yai, Songkhla, Thailand. It was then dried, and the resulting powder was stored at −30 °C until it was needed. The powder was newly reconstituted and prepared for oral consumption daily. Our earlier paper [16] contains a detailed explanation of the YCJ preparation process and administration protocol.

2.2. Animals

Mahidol University’s Salaya campus provided adult female Wistar rats (8 months old and 250–300 g BW). At the Animal House Laboratory, Faculty of Science, Prince of Songkla University, Hat Yai, Songkhla, Thailand, the animals were fed standard food pellets, housed in a room free of any sources of chemical contamination, artificially illuminated (a 12-h dark/light cycle), and exposed to controlled temperatures (25 ± 1 °C) and humidity (50 ± 5%). The Animal Care and Use Committee of Prince of Songkla University and the National Institute of Health (NIH publication 86–23, revised 1985) provided humane treatment for all animals. License number 04/57 was assigned to the protocol.

2.3. Experimental Design

Seventy rats were randomly allocated into seven groups, each containing ten rats. The first group served as a standard control group (NC). The second group is the sham-operated group (SC). The ovariectomized (ovx) rats were the third group (OC). Exogenous estrogen (2.5 g/kg BW) was injected into the fourth group of ovx rats, and the assigned dose of estradiol benzoate was given for three days a week (OE), following the same procedure as in earlier investigations [20]. The ovx rats in the fifth, sixth, and seventh groups were given 10 (OJ10), 20 (OJ20), and 40 (OJ40) mL/kg BW/day of YCJ, respectively. One week following the ovariectomy, the EB and YCJ treatments began.Here, an injection vehicle (reverse osmosis water) was force-fed to SC and OC rats. One week after the ovariectomy, YCJ was treated once a day, every day. The rats were sacrificed after ten weeks of feeding and injection treatments. For the LM and TEM studies, the skin from the dorsal region of each animal was excised, fixed with 10% neutral formalin, and processed with paraffin. The chemiluminescent immunoassay (CIA) technique was used to obtain serum for estradiol assays (ECLIA, Modular E 170C, Estradiol II 03,000,079 122, Roche, Germany).

Ovariectomy Procedure

The lateral side of the rats was cleaned with antiseptic solutions. The animal was anesthetized then placed on the operating table, with the lateral side of the body in an upright position. A single midline incision was made about one fingerbreadth below the costal margin, and the skin was penetrated using small surgical scissors. Blunt forceps were used to free subcutaneous connective tissue from the underlying muscle of each side. The ovary was located by retracting the surrounding fat around the ovary to expose the oviduct. All vessels around the ovary were ligated to avoid bleeding before removing the ovary out of the fat pad. For the sham group, after the operation, the ovaries were put back into the abdominal cavity, then the subcutaneous tissue, muscle layer, and, finally, the skin were sutured.

2.4. Specimen Preparation for TEM

Tissue samples from the rats’ dorsal skin were fixed for 24 h at 4 °C in 4% paraformaldehyde (primary fixation), then in 1% OsO4 for 1 h, washed with phosphate buffer solution, then blocked with 2% uranyl acetate for 1 h. The specimens were dehydrated using increasing quantities of ethanol, before being embedded in Embed-812 (Epon-812 Substitute, Cat # 14900). To assess the tissue area, semi-thin slices were cut at 400 mm and stained with 0.5% toluidine blue. Before being examined with a transmission electron microscope, ultrathin sections were cut at 90 mm and stained with 5% uranyl acetate and lead citrate (JEOL JEM-2010, Tokyo, Japan).

2.5. Microscopic Analysis by Quantitative Histomorphometry

2.5.1. Light Microscopy: Hematoxylin and Eosin (H&E) Staining

Hematoxylin and EosinStaining

Briefly, the sections were deparaffinized using xylene. Then, the sections were hydrated using grading alcohol, then washed withtap water. Primary staining of the nuclei was conducted with Mayer’s hematoxylin and rewashed with tap water. Eosin was used to counterstain these sections, and they were dehydrated with grading alcohol, cleared with xylene, and finally cover-slipped with permount.

Measurement of Epidermal and Dermal Thickness; the Number of Hair Follicles

Two impartial observers counted the parameters being studied. At 400× magnification, an eyepiece micrometer was mounted on a light microscope, and a count was taken. The average was calculated by adding the readings from both observers. The distancebetween the stratum granulosum and the stratum basale was used to determine epidermal thickness. Dermal thickness was determined by measuring the distance between the stratum basale and the upper section of the hypodermis. The distance between the dermis’ bottom line and the muscular adipose was used to calculate hypodermal thickness.
Each thickness measurement is based on an average of 25 measurements. Hair follicles with a diameter of more than 20 µm were detected in ten regions of the dermis, averaged, and compared between groups. Image analysis software was used to analyze and quantify all parameters (Olympus Cellsens version 1.6, Tokyo, Japan). The results were represented as numbers per µm2, and the seven groups were compared using the mean ± SEM.

2.5.2. Transmission Electron Microscopy (TEM)

-
For the measurement of collagen fibril diameters, for 1 grid, collagen fibrils were photographed at 20,000× magnification in 2 planes: long- and cross-sections. For a long section, 2 photos were taken, and 20 collagen fibrils per photo were measured and averaged. For a cross-section, 60 collagen fibrils were measured and averaged. Therefore, for one grid, a total of 100 fibrils were counted, and the results were averaged [21]. A statistical comparison of the seven groups was made using each group’s mean ± SEM data.
In measuring cellular changes, ten cells from one grid were randomly studied at 4000× magnification, using the criteria employed by Hussein et al. [22].
-
Measurement of the nucleus and cell perimeter
The ultrastructure (TEM) photos of each rat’s ten largest keratinocytes and fibroblasts (3 rats per group) were chosen. They were then transferred to the microscope program, and the nucleus and cell perimeters were drawn and measured. Two impartial observers counted the parameters, and the average values of the observation results were determined. Readings from both the observers were added, and an average was determined. Image analysis software (Olympus BX50 light microscope and Olympus DP73 camera with cellSens software) was used to analyze and quantify all parameters (v1.16, Olympus Corporation). The results were reported as nucleus/cell perimeters per µm, and the seven groups were compared using mean ± SEM.

2.6. Statistical Analysis

The Shapiro–Wilk test was performed to test for a normal distribution. Altman’s nomogram was used for the calculations of sample size. Statistical analysis was performed using a one-way ANOVA, followed by an LSD using the statistical program SPSS version 16.0 (SPSS, Inc., Chicago, IL, USA). A random selection of microscopic fields was achieved using a computer-generated list of random numbers (Excel version 5.0). Results are expressed as mean ± SEM. p < 0.05 was considered a significant result.

3. Results

3.1. LM (Hematoxylin and Eosin Staining): Epidermis and Dermis

The epidermis and dermis of skin changes stained with Hematoxylin and Eosin staining are demonstrated in Figure 1. Following ovariectomy (OC group), the skin of the ovx rats showed typical atrophy. The degree ofkeratinizationand thickness of the epidermis showed a reduction.
The epidermal thickness became thinner in comparison with the control groups; thekeratinocyte cellnumber and the vascularity werelow;the number of glands was reduced; the collagen bundles’ morphology and distribution changed. EB injections (OE group) or YCJ injections (OJ group) reduced the histological changes in the skin caused by the ovariectomy (OC group). In fact, the epidermal, as well as dermal, keratinization and thickness in ovx-treated rats were virtually unchanged compared to control animals (SC and OE groups). When ovx rats were given EB (OE group) or YCJ treatments, their epidermal and dermal thicknesses increased (OJ groups). Skin thickness was enhanced with YCJ treatments (OJ10, OJ20, and OJ40 groups), but not in a dose-dependent way. The OJ10 group had the highest epidermal thickness (Figure 2A), while the OJ40 group had the highest dermal thickness (Figure 2B). Furthermore, the morphology and distribution of the collagen bundle of the YCJ treatment groups were equivalent to that of the control group (NC, SC, and OE groups). When the number of hair follicles and the diameter of collagen fibrils were measured, the OJ40 groups had the highest scores (Figure 2C–E).

3.2. Transmission Electron Microscopy (TEM): Keratinocytes

Figure 3 shows a transmission electron micrograph (TEM) of rat epidermis keratinocytes. According to the TEM analysis, the epidermal keratinocytes in the sham (SC), ovx+EB(OE), and ovx+YCJ (OJ) groups were tightly connected through desmosomes. The size of the keratinocyte cells in the OC group declined after ovariectomy (OC group). When the ovx rats were fed either EB (OE group) or YCJ (YCJ group), cell and nucleus size increased (OJ groups). The desmosomes in the ovx epidermiswere significantly less and were smaller than those in the control groups (SC and OE) and the OJ group. When compared to the OC group, the OJ group had more desmosomes and narrow intercellular gaps.The OJ group’s keratinocytes had the most cytoplasmic processes, and their numbers also increased. The above observations were confirmed when the statistical analysis was undertaken (Figure 4A,B). Surprisingly, when three doses of YCJ treatments were compared among each group, no significant differences in nuclei and keratinocyte cell perimeters were found (Figure 4A,B).

3.3. Transmission Electron Microscopy (TEM): Fibroblasts

The electron micrograph (TEM) of fibroblasts in the dermis was demonstrated in Figure 5. TEM examination demonstrated that the dermal fibroblasts of the normal control (SC, OE) groups were composed of large nuclei that contained more euchromatin than heterochromatin, and cytoplasmic processes were elongated without any dilation of the organelles, particularly the RER. Furthermore, there were numerous collagen fibers packed as large bundles surrounding the fibroblast cells. Following ovariectomy (OC group), the fibroblast cells in the OC group shrank in size;dilation of the rough endoplasmic reticulum (RER) in the cytoplasm was observed; cytoplasmic processes were smaller, and their numbers were also reduced. The reported dilation of the RER, as it appeared in the ovx group, is one of the indicators of cell degeneration. Cell size and nuclei size were increased when the ovx rats were treated with EB (OE group)or YCJ feeding (OJ groups). In the OJ groups, the nuclei were larger and the cytoplasmic processes were branching and elongated, compared with the OC group. In addition, the extracellular matrix had more numerous collagen fibers in the OJ groups, compared with the OC group. These observations were confirmed when statistical analysis of the collagen fibril numbers was performed (Figure 2D,E). The changes mentioned above were dose-related, with the OJ40 group representing the best dose for both in terms of the nucleus and the fibroblast cell perimeters (Figure 4C,D).

3.4. Transmission Electron Microscopy (TEM): Dermo-Epidermal Junction

The dermo-epidermal junction between the epidermis and dermis is shown in Figure 6. Basal borders at the dermo-epidermal junction of keratinocytes connected with the basement membrane via numerous hemidesmosomes. The basal borders of the cells were irregular, with protruding dermal papillary interdigitated with epidermal ridges. Following ovariectomy (the OC group), that junction was reduced compared to the control (NC, SC, and OE) and OJ groups. The collagen fibers in the papillary and reticular layers of the OC group were much smaller, shorter, and more loosely packed compared with the control (NC, SC, and OE) and OJ groups. In addition, the gap between the papillary and reticular layer of the OC group was wider, resulting in a wide space between those two layers. By contrast, the papillary layer and the reticular layers of the dermis for the control (NC, SC, and OE) and OJ groups contained numerous collagen fibers, packed tightly.

3.5. Transmission Electron Microscopy (TEM): Collagen Fibrils

Figure 7 depicts the electron micrograph (TEM) of rat skin, showing an overview of the collagen fibers. Compared with the control (SC, OE) groups, the number of collagen bundles of the OC group was considerably smaller, and the spaces between bundles were wider following ovariectomy (OC group). The number of collagen bundles and their sizes were increased when the ovx rats were treated with EB (OE group) or YCJ feeding (OJ groups). Therefore, the space between the bundles of the OJ groups became narrower when compared with the SC, OE, and OC groups, as confirmed by the cross- and long sections (Figure 8 and Figure 9, respectively). Those observations were confirmed when the collagen fibrils’ diameters in the thick sections of the dermis (Figure 2D) and the thin sections (Figure 2E) were measured. The changes mentioned above were dose-related, with the OJ40 group presenting the best results, even though there was no significant difference among all three YCJ treatments (Figure 2D,E).

3.6. Ultrastructural Changes of Keratinocyte and Fibroblast Cell Scores

The ultrastructural changes of the keratinocyte and fibroblast cells were scored using the criteria shown in Table 1.When compared with the normal baseline (NC) group, after ten weeks of treatment, it was found that both the keratinocyte and fibroblast cell scores of the SC group were significantly reduced. The scores of the OC group were significantly lower, following ovariectomy. The scores were significantly increased when the ovx rats were treated with EB (OE group) or YCJ feeding (OJ groups), except in the case of the OE group of keratinocytes. For fibroblast cells, among three doses of YCJ treatment, the scores were not significantly different. In contrast with keratinocyte cells, ovx rats treated with YCJ 40 mL/kg BW (OJ40) presented the highest score compared to the three doses of YCJ treatment (Figure 10).

3.7. Gross Evaluation of Wound Healing

Among all six groups, the best accelerated wound healing and hair growth performance occurred in the OJ40 group. The hair was much softer and brighter in the OJ40 group, compared with the control and the OJ10 and OJ20 groups (Figure 11A,B). This beneficial effect of accelerating wound healing of YCJ confirmed our previous results and was persistent throughout every single experiment we conducted [18,19,23].

4. Discussion

Skin aging and poor wound healing [24] are more common in menopausal women due to decreased estrogen production, which can impair the structure and function of the skin. HRT can help to counteract these side effects. However, the treatmentmay not be suitable for all menopausal women [13].
YCJ has been utilized in several medicinal applications but not for wound healing or for enhancing skin appearance. We were the first to report in 2006 that ovx rats given YCJ had significantly enhanced wound healing, including less scarring, brighter skin, and smoother hair, when compared to controls. However, these findings were based on a four-week period of gross morphological examination at the time. Later, we discovered that YCJ enhanced wound healing by downregulating the macrophage migration inhibitory factor (MIF) and via Erβ, rather than ERα [18]. To investigate these findings further, we conducted the current study, which examined changes in the skin, including its underlying structures, at a microscopic level (both LM and TEM) after rats were given YCJ over ten weeks, a longer time period than the original study. This was performed to simulate postmenopausal women’s prolonged consumption in an ovariectomized rat.
Even though the particular active components or phenolic groups of YCJ have yet to be determined, flavonoids make up most phytoestrogens with wound-healing activities [25]. As a result, we believe the positive effects of YCJ are attributable to its flavonoid properties. YCJ contains 58 percent beta-sitosterol, as well as additional sterols such as stigmasterol, stigmastatrienol, spinasterol, and fucosterol, as reported in previous studies [17]. According to Moghadasian et al. [26], beta-sitosterol may act as a sex steroid precursor since its structure is similar to animal cholesterol. Furthermore, the methanol extract of coconuts displayed an estrogenic effect in rats, due to its high concentration of beta-sitosterol, stigmasterol, and other flavonoids [27].
According to earlier studies [28,29,30], coconut extract is abundant in phytohormones like abscisic acid (ABA), auxin, gibberellins (GAs), and other cytokinins. In human fibroblast cells, trans-zeatin, one of the most significant cytokines contained in coconuts, has been demonstrated to have anti-aging characteristics [31]. According to this study, the rapid effect of YCJ on wound healing is mainly due to its strong estrogenic action, which increases the manufacture of endogenous estrogens.
Under LM and TEM examination, the current study discovered that YCJ increased skin thickness while preserving fibroblast and keratinocyte cell shape and increasing collagen fibril quantities. These findings are consistent with Uyar’s [32] study of the effects of soybean (Glycine max) extracts on the collagen layer and estrogen receptors in female rats’ skin. They discovered that soy isoflavones have positive effects on the skin through mechanisms such as lipid oxidation prevention, fibroblast proliferation stimulation, collagen degradation reduction, and the inhibition of 5-reductase [32].
Experiments with a cohort of postmenopausal women treated with isoflavone-rich soy extract for six months resulted in considerable increases in epithelial thickness, the number of elastic and collagen fibers, and the number of blood vessels [33]. The skin of ovariectomized rats administered red clover isoflavones appeared to be well-organized, with a normal epidermis of uniform thickness and regular keratinization and vascularity, collagen, and elastic fibers [34]. The amount of collagen in the red clover-isoflavones-treated group increased significantly compared to the control group [34].
The epidermis, dermis, and subcutaneous tissue comprise the three layers of skin. Keratinocytes make up most of the epidermis. Through estrogen receptors, phytoestrogens have an anti-aging impact on the skin [35]. In recent work, we discovered that YCJ consumption had a considerable effect on ERβ detection [18] and that Erβ stimulation leads to increased keratinocyte proliferation and migration [36]. Polito et al. found that treating ovx rats with genistein aglycone, a soy-derived isoflavone, enhanced collagen thickness via TGF-β1-producing cell types [37]. TGF-β1, a growth factor that promotes fibroblast proliferation and extracellular matrix (ECM) secretion, influences angiogenesis and epithelialization is the primary mechanism by which topical estrogen increases ECM secretion [38]. Our discovery of YCJ’s high binding to ERβ suggests that oxidative stress pathways may be involved in YCJ’s skin aging prevention activity in ovx rats. Many people believe that phytoestrogens can protect the skin from oxidative stress by binding to ERβ and activating ERE, to cause the dissociation of Nrf2 and Keap1. Nrf2 enters the nucleus and activates ARE, which increases the transcription of antioxidant enzymes [39]. This increases mitochondrial membrane potential and stimulates NO release in physiological circumstances. H2O2 induces a decrease in mitochondrial membrane potential, as well as an increase in NO production, which phytoestrogens can help to avoid. This helps to protect the skin from oxidative damage [40].
The outcome of hair follicle density in the dermis in this investigation reflects the findings of our prior study, in which we treated ovx rats with YCJ 100 mL/kg BW [18]. The current findings show that the number of hair follicles and their width in the dermis of the ovx+YCJ (OJ) group were higher and larger than the normal controls (NC, SC, OE) and the ovx (OC) groups utilizing lower dosages of YCJ of 10, 20, and 40 mL/kg BW. The number of hair follicles in the OJ groups grows in a dose-dependent manner, with the OJ40 (ovx+YCJ 40 mL/kg BW) group having the largest number and the ovx(OC) group having the lowest number. Lower dosages of YCJ (10, 20, and 30 mg/kg) were used in the current study.Hair follicles are important in skin biology for more than just their ability to produce hair. Since hair follicles are self-renewing and contain supplies of multipotent stem cells that may regenerate the epidermis, they are assumed to play a role in wound healing [41,42] and epidermal growth. Furthermore, positive correlations between the perimeters of the fibroblast, keratinocyte cells, collagen fibril diameters, and serum E2 levels reported in the current study confirmed the effects of YCJ on skin and skin appendages. This suggests that some of the active ingredients in YCJ influence the growth and proliferation of fibroblasts, keratinocyte cells, and collagen fibrils.
The skin epidermis is a stratified squamous epithelium made up of four unique cell types, the most common of which are keratinocytes. The papillary layer is made up of loose connective tissue (fibroblasts, collagen fibers, and thin elastic fibers), and the reticular layer is made up of thick bundles of collagen fibers and coarse elastic fibers that create the skin dermis. Collagen is a fundamental part of the skin dermis, offering significant support for skin resistance, and is produced by fibroblasts. In the current study, statistical analysis revealed that estrogen and YCJ impacted both keratinocyte and fibroblast cells, resulting in increased collagen fibril formation and extracellular matrix content, as well as decreased intercellular space.
Collagen fibril diameters from both thick and thin sections of ovx rats receiving YCJ treatments in the current study were thicker than those of the control groups and the ovx group (Figure 8D,E), showing that both estrogen and YCJ are likely to influence collagen fibril diameters in ovx rats. Many studies have found that estrogen therapy improves collagen content and skin thickness [43,44,45,46,47]. Previous research involving a variety of phytoestrogens has backed up the current findings. For example, in human keratinocyte culture, Miyakazi et al. found that genistein and daidzein promote hyaluronic acid synthesis [48]. In a European trial of 234 postmenopausal women, isoflavone (Novadiol®) cream improved skin dryness and wrinkles after 12 weeks of treatment [49].
Raloxifene stimulates collagen production in human skin fibroblasts more efficiently than estradiol [50]. So far, phytoestrogens have been found to increase skin collagen thickness by:(1) inducing subcutaneous VEGF expression and increasing TGF-β in the skin [37,51]; (2) reducing collagen degradation by increasing TIMP protein levels to inhibit MMPs [52,53]; and (3) inhibiting FLT3 kinase activity and reducing Ras/mitogen-activated protein kinase/extracellular signal-regulated kinase and Akt/p70 ribosomal kinase pathways, to inhibit AP-1 activity and reduce gene transcription of MMP-1 [54]. Additional molecular pathways need to be elucidated.
A single layer of columnar or high cuboidal keratinocytes rests on abasement membrane in the epidermis’ stratum basale. The basal domain of basal cells is anchored to the basement membrane by hemidesmosomes and associated intermediate filaments [42]. In the current study, the dermo-epidermal junctions of rats treated with YCJ (OJ groups) were not different from the NC and SC groups. The irregularities of the basal borders of the ovx(OC) and ovx+EB (OE)groups were markedly reduced compared with the control (NC, SC, and OJ) groups. This novel phenomenon indicates the obvious influences of YCJ on the protein component alteration of the hemidesmosomes of the stratum basale cell layer. Previously, it was found that phytoestrogens increase the production of hyaluronic acid [55] and extracellular matrix proteins [35], which gives rise to the hypothesis that it might help provide hemidesmosome structures in ovx rats treated with YCJ. However, the underlying molecular mechanisms need to be explored further in the future.
Both EB and YCJ considerably enhanced the thickness of the skin, both the epidermis and dermis, and the collagen content, as measured by collagen fibril diameters, and raised the number of hair follicle densities in ovx rats, according to the findings. These protective effects were validated histologically by LM and TEM levels, indicating that YCJ can prevent skin aging even in the absence of estrogen.
The skin is an estrogen-responsive tissue with specific receptors that respond to estrogen. While HRT has long been recommended to treat undesirable menopausal symptoms, as well as to prevent postmenopausal osteoporosis and other risk factors like heart attack and stroke, many studies have linked HRT to an increased risk of cardiovascular complications, venous thromboembolism, coronary artery disease [56], and many types of cancer [57,58,59]. As a result, the risks and benefits of systemic HRT have been thoroughly examined. Thus, HRT is not suggested for the treatment of skin aging, and topical estrogen cannot be used until clinical research has been completed to determine the minimum levels of estrogen compounds that have the best local effects without creating systemic hormonal side effects.
The question as to whether estrogen substitutes like phytoestrogens and SERMs are effective estrogens for mitigating skin aging in postmenopausal women has to be explored further. We examined a range of research on the effects of a YCJ oral intake on the expression of ERα and ERβ in injured and normal skin [16,18,19], with the goal of determining if it has phytoestrogenic qualities and can operate as a SERM. Our findings show that YCJ, a non-steroidal plant with estrogen-like biological activity, appears to be a promising alternative to conventional hormone replacement therapy for skin aging without affecting liver or kidney function (please see Payanglee et al. for details on lipid, liver, and renal parameters [60]).
In summary, we have already shown that YCJ has a definite positive effect on cutaneous wound healing and skin appearance. These could be modified to have both therapeutic and cosmetic benefits, such as accelerating wound healing and reducing scars [18] from surgery, especially those associated with plastic surgery where scars must be greatly reduced, treating chronic ulcers, skin whitening, wrinkle reduction, preventing or reducing freckles, skin and hair diseases caused by estrogen deficiency, and repairing burns. The molecular processes involved, as well as the mechanisms through which YCJ and related substances regulate skin function and slow skin aging, are unknown at this time. More research will be required in the future to elucidate the issue.

5. Conclusions

The results of the current study indicated that: (1) EB injections at 2.5 µg/kg BW/day for 3 days per week was enough to restore aging skin back to its normal condition; (2) the effects of YCJ were similar to those of EB treatment in all parameters, with some parameters where YCJ was even better than EB; (3) at the various doses tested, YCJ treatment restored aging skin back to its normal condition with the optimal dose of 40 mL/kg BW/day (OJ40 group) with specificparameters, e.g., hair follicle numbers higher than all the normal control (NC, SC, and OE) groups;(4) the most accelerated wound healing and hair growth for YCJ occurred in the OJ40 group. These findings indicate that feeding YCJ could account, at least in part, for the protective role of estrogen replacement in preventing or reducing skin aging/damage in female rats: by increasing epidermal and dermal thickness; improving ultrastructural changes for keratinocytes and fibroblasts; increasing the number and size of collagen fibrils, and hence reducing wrinkles in ovx rats and enhancing skin complexion.

Author Contributions

Conceptualization, N.R.; methodology, N.R.; software, N.B.; validation, N.R. and N.B.; formal analysis, N.B.; investigation, N.B.; resources, N.R.; data curation, N.R.; writing—original draft preparation, N.R.; writing—review and editing, A.S. and A.M.H.; visualization, N.R.; supervision, N.R.; project administration, N.R.; funding acquisition, N.R. All authors have read and agreed to the published version of the manuscript.

Funding

This study was supported by the government budget of Prince of Songkla University, grant no. SCI580566S.

Institutional Review Board Statement

All animals received humane care in compliance with the Animal Care and Use Committee of Prince of Songkla University guidelines and the National Institutes of Health (NIH publication 86-23 revised 1985. The protocol was approved under license number 04/57).

Informed Consent Statement

This study did not involved with humans.

Data Availability Statement

The data used to support the findings of this study are included withing the article.

Acknowledgments

We appreciate SakonSuwaluckfrom Faculty of Medicine, Prince of Songkla University, and ChutchawanMuenpo from the Faculty of Science, Prince of Songkla University, for technical assistance and kind suggestion.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Nagula, R.L.; Wairkar, S. Recent advances in topical delivery of flavonoids: A review. J. Control. Release Off. J. Control. Release Soc. 2019, 296, 190–201. [Google Scholar] [CrossRef] [PubMed]
  2. Thornton, M.J. Estrogens and aging skin. Derm. Endocrinol. 2013, 5, 264–270. [Google Scholar] [CrossRef] [PubMed]
  3. Piérard, G.E.; Letawe, C.; Dowlati, A.; Piérard-Franchimont, C. Effect of hormone replacement therapy for menopause on the mechanical properties of skin. J. Am. Geriatr. Soc. 1995, 43, 662–665. [Google Scholar] [CrossRef] [PubMed]
  4. Snell, R.S.; Turner, R. Skin pigmentation in relation to the menstrual cycle. J. Investig. Dermatol. 1966, 47, 147–155. [Google Scholar] [CrossRef] [Green Version]
  5. Harvell, J.; Husson-Saeed, I.; Maibach, H.I. Changes in transepidermal water loss and cutaneous blood flow during the menstrual cycle. Contact Dermat. 1992, 27, 294–301. [Google Scholar] [CrossRef]
  6. Pierard-Franchimont, C.; Letawe, C.; Goffin, V.; Pierard, G. Skin water-holding capacity and transdermal estrogen therapy for menopause: A pilot study. Maturitas 1995, 22, 151–154. [Google Scholar] [CrossRef]
  7. Hall, G.K.; Phillips, T.J. Skin and hormone therapy. Clin. Obstet. Gynecol. 2004, 47, 437–449. [Google Scholar] [CrossRef]
  8. Thornton, M. Oestrogen functions in skin and skin appendages. Expert Opin. Ther. Targets 2005, 9, 617–629. [Google Scholar] [CrossRef]
  9. Lephart, E.D. A review of the role of estrogen in dermal aging and facial attractiveness in women. J. Cosmet. Dermatol. 2018, 17, 282–288. [Google Scholar] [CrossRef]
  10. Brincat, M.; Kabalan, S.; Studd, J.W.; Moniz, C.F.; de Trafford, J.; Montgomery, J. A study of the decrease of skin collagen content, skin thickness, and bone mass in the postmenopausal woman. Obstet. Gynecol. 1987, 70, 840–845. [Google Scholar]
  11. Thornton, M. The biological actions of estrogens on skin. Exp. Dermatol. 2002, 11, 487–502. [Google Scholar] [CrossRef] [Green Version]
  12. Stevenson, S.; Thornton, J. Effect of estrogens on skin aging and the potential role of SERMs. Clin. Interv. Aging 2007, 2, 283. [Google Scholar]
  13. Brower, V. A second chance for hormone replacement therapy? EMBO Rep. 2003, 4, 1112–1115. [Google Scholar] [CrossRef] [Green Version]
  14. Beauregard, S.; Gilchrest, B.A. A survey of skin problems and skincare regimens in the elderly. Arch. Dermatol. 1987, 123, 1638–1643. [Google Scholar] [CrossRef]
  15. Rossouw, J.E.; Anderson, G.L.; Prentice, R.L.; LaCroix, A.Z.; Kooperberg, C.; Stefanick, M.L.; Jackson, R.D.; Beresford, S.A.; Howard, B.V.; Johnson, K.C. Risks and benefits of estrogen plus progestin in healthy postmenopausal women: Principal results From the Women’s Health Initiative randomized controlled trial. Jama 2002, 288, 321–333. [Google Scholar]
  16. Radenahmad, N.; Vongvatcharanon, U.; Withyachumnarnkul, B.; Connor, R. Serum levels of 17β-estradiol in ovariectomized rats fed young-coconut-juice and its effect on wound healing. Songklanakarin J. Sci. Technol. 2006, 28, 897–910. [Google Scholar]
  17. Rattanaburee, P.; Amnuaikit, T.; Radenahmad, N.; Puripattanavong, J. Phytochemical Study and its Quantity and Quality of Fresh and Freeze-Dried Young Coconut Juice (Cocos Nucifera L.). In Advanced Materials Research; Trans Tech Publications Ltd.: Freienbach, Switzerland, 2014; pp. 490–493. [Google Scholar] [CrossRef]
  18. Radenahmad, N.; Saleh, F.; Sayoh, I.; Sawangjaroen, K.; Subhadhirasakul, P.; Boonyoung, P.; Rundorn, W.; Mitranun, W. Young coconut juice can accelerate the healing process of cutaneous wounds. BMC Complement. Altern. Med. 2012, 12, 252. [Google Scholar] [CrossRef] [Green Version]
  19. Radenahmad, N.; Suwansa-ard, S.; Sayoh, I. Young coconut juice accelerates cutaneous wound healing by downregulating macrophage migration inhibitory factor (MIF) in ovariectomized rats: Preliminary novel findings. Songklanakarin J. Sci. Technol. 2015, 37, 417–423. [Google Scholar]
  20. Radenahmad, N.; Saleh, F.; Sawangjaroen, K.; Rundorn, W.; Withyachumnarnkul, B.; Connor, J.R. Young coconut juice significantly reduces histopathological changes in the brain that is induced by hormonal imbalance: A possible implication to postmenopausal women. Histol. Histopathol. Cell. Mol. Bio 2009, 24, 667–674. [Google Scholar]
  21. Tzaphlidou, M. Influence of low doses of gamma-irradiation on mouse skin collagen fibrils. Int. J. Radiat. Biol. 1997, 71, 109–115. [Google Scholar] [CrossRef]
  22. Hussein, M.R.; Abu-Dief, E.E.; Abd El-Raheem, M.H.; Abd-Elrahman, A. Ultrastructural evaluation of the radioprotective effects of melatonin against X-ray-induced skin damage in Albino rats. Int. J. Exp. Pathol. 2005, 86, 45–55. [Google Scholar] [CrossRef] [PubMed]
  23. Radenahmad, N.; Boonyoung, P.; Kamkaew, K.; Chanchula, K.; Kirirat, P. Effects of young coconut juice on the numbers of argyrophil endocrine cells in the gastrointestinal tract of male rats: Novel preliminary findings. Songklanakarin J. Sci. Technol. 2014, 36, 599–606. [Google Scholar]
  24. Calleja-Agius, J.; Muscat-Baron, Y.; Brincat, M.P. Skin ageing. Menopause Int. 2007, 13, 60–64. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  25. Hansteen, B.H. The biochemistry and medical significance of the flavonoids. Pharmacol. Ther. 2002, 96, 67–202. [Google Scholar] [CrossRef]
  26. Moghadasian, M.H. Pharmacological properties of plant sterols in vivo and in vitro observations. Life Sci. 2000, 67, 605–615. [Google Scholar] [CrossRef]
  27. Salah, A.M.; Gathumbi, J.; Vierling, W.; Wagner, H. Estrogenic and cholinergic properties of the methanol extract of RuelliapraetermissaSceinf. ex. Lindau (Acanthaceae) in female rats. Phytomed. Int. J. Phytother. PhytoPharm. 2002, 9, 52–55. [Google Scholar] [CrossRef]
  28. Kobayashi, H.; Morisaki, N.; Tago, Y.; Hashimoto, Y.; Iwasaki, S.; Kawachi, E.; Nagata, R.; Shudo, K. Structural identification of a major cytokinin in coconut milk as 14-O-(3-O-[beta-D-galactopyranosyl-(1-->2)-alpha-D-galactopyranosyl- (1-->3)-alpha-L-arabinofuranosyl]-4-O-(alpha-L-arabinofuranosyl)- beta-d-galactopyranosyl)-trans-zeatin riboside. Chem. Pharm. Bull. 1997, 45, 260–264. [Google Scholar] [CrossRef] [Green Version]
  29. Ge, L.; Tan, S.; Yong, J.W.; Tan, S.N. CE for cytokinin analyses: A review. Electrophoresis 2006, 27, 4779–4791. [Google Scholar] [CrossRef]
  30. Wu, Y.; Hu, B. Simultaneous determination of several phytohormones in natural coconut juice by hollow fiber-based liquid-liquid-liquid microextraction-high performance liquid chromatography. J. Chromatogr. A 2009, 1216, 7657–7663. [Google Scholar] [CrossRef]
  31. Rattan, S.I.; Sodagam, L. Gerontomodulatory and youth-preserving effects of zeatin on human skin fibroblasts undergoing aging in vitro. Rejuvenation Res. 2005, 8, 46–57. [Google Scholar] [CrossRef] [Green Version]
  32. Uyar, B.; Sivrikoz, O.N.; Ozdemir, U.; Dasbasi, T.; Sacar, H. Histological investigation of the effect of soybean (Glycine max) extracts on the collagen layer and estrogen receptors in the skin of female rats. Clinics 2014, 69, 854–861. [Google Scholar] [CrossRef]
  33. Accorsi-Neto, A.; Haidar, M.; Simões, R.; Simões, M.; Soares, J., Jr.; Baracat, E. Effects of isoflavones on the skin of postmenopausal women: A pilot study. Clinics 2009, 64, 505–510. [Google Scholar] [CrossRef] [Green Version]
  34. Circosta, C.; De Pasquale, R.; Palumbo, D.R.; Samperi, S.; Occhiuto, F. Effects of isoflavones from red clover (Trifolium pretense) on skin changes induced by ovariectomy in rats. Phytother. Res. PTR 2006, 20, 1096–1099. [Google Scholar] [CrossRef]
  35. Gopaul, R.; Knaggs, H.E.; Lephart, E.D. Biochemical investigation and gene analysis of equol: A plant and soy-derived isoflavonoid with anti-aging and antioxidant properties with potential human skin applications. BioFactors 2012, 38, 44–52. [Google Scholar] [CrossRef]
  36. Merlo, S.; Frasca, G.; Canonico, P.L.; Sortino, M.A. Differential involvement of estrogen receptor alpha and estrogen receptor beta in the healing promoting effect of estrogen in human keratinocytes. J. Endocrinol. 2009, 200, 189–197. [Google Scholar] [CrossRef] [Green Version]
  37. Polito, F.; Marini, H.; Bitto, A.; Irrera, N.; Vaccaro, M.; Adamo, E.B.; Micali, A.; Squadrito, F.; Minutoli, L.; Altavilla, D. Genisteinaglycone, a soy-derived isoflavone, improves skin changes induced by ovariectomy in rats. Br. J. Pharmacol. 2012, 165, 994–1005. [Google Scholar] [CrossRef] [Green Version]
  38. Son, E.D.; Lee, J.Y.; Lee, S.; Kim, M.S.; Lee, B.G.; Chang, I.S.; Chung, J.H. Topical application of 17β-estradiol increases extracellular matrix protein synthesis by stimulating TGF-β signaling in aged human skin in vivo. J. Investig. Dermatol. 2005, 124, 1149–1161. [Google Scholar] [CrossRef] [Green Version]
  39. Kim, M.-S.; Hong, C.Y.; Lee, S.H. The phytoestrogenic effect of daidzein in human dermal fibroblasts. J. Soc. Cosmet. Sci. Korea 2014, 40, 279–287. [Google Scholar]
  40. Savoia, P.; Raina, G.; Camillo, L.; Farruggio, S.; Mary, D.; Veronese, F.; Graziella, F.; Zavattaro, E.; Tiberio, R.; Grossini, E. Anti-oxidative effects of 17 β-estradiol and genistein in human skin fibroblasts and keratinocytes. J. Dermatol. Sci. 2018, 92, 62–77. [Google Scholar] [CrossRef] [Green Version]
  41. Millar, S.E. Molecular mechanisms regulating hair follicle development. J. Investig. Dermatol 2002, 118, 216–225. [Google Scholar] [CrossRef]
  42. Kierszenbaum, A.L.; Tres, L. Histology and Cell Biology: An Introduction to Pathology E-book; Elsevier Health Sciences: Philadelphia, PA, USA, 2015. [Google Scholar]
  43. Castelo-Branco, C.; Duran, M.; González-Merlo, J. Skin collagen changes related to age and hormone replacement therapy. Maturitas 1992, 15, 113–119. [Google Scholar] [CrossRef]
  44. Maheux, R.; Naud, F.; Rioux, M.; Grenier, R.; Lemay, A.; Guy, J.; Langevin, M. A randomized, double-blind, placebo-controlled study on the effect of conjugated estrogens on skin thickness. Am. J. Obstet. Gynecol. 1994, 170, 642–649. [Google Scholar] [CrossRef]
  45. Varela, E.; Rantala, I.; Oikarinen, A.; Risteli, J.; Reunala, T.; Oksanen, H.; Punnonen, R. The effect of topical oestradiol on skin collagen of postmenopausal women. BJOG Int. J. Obstet. Gynaecol. 1995, 102, 985–989. [Google Scholar] [CrossRef] [PubMed]
  46. Callens, A.; Vaillant, L.; Lecomte, P.; Berson, M.; Gall, Y.; Lorette, G. Does hormonal skin aging exist? A study of the influence of different hormone therapy regimens on the skin of postmenopausal women using non-invasive measurement techniques. Dermatology 1996, 193, 289–294. [Google Scholar] [CrossRef] [PubMed]
  47. Sauerbronn, A.; Fonseca, A.; Bagnoli, V.; Saldiva, P.; Pinotti, J. The effects of systemic hormonal replacement therapy on the skin of postmenopausal women. Int. J. Obstet. Gynaecol 2000, 68, 35–41. [Google Scholar] [CrossRef]
  48. Miyazaki, K.; Hanamizu, T.; Iizuka, R.; Chiba, K. Genistein and daidzein stimulate hyaluronic acid production in transformed human keratinocyte culture and hairless mouse skin. Skin Pharmacol. Appl. Skin Physiol. 2002, 15, 175–183. [Google Scholar] [CrossRef] [PubMed]
  49. Bayerl, C.; Keil, D. Isoflavonoide in der Behandlung der Hautalterungpostmenopausaler Frauen. Aktuelle Dermatologie 2002, 28, S14–S18. [Google Scholar]
  50. Surazynski, A.; Jarzabek, K.; Kaczynski, J.; Laudanski, P.; Palka, J.; Wilczynski, S. Differential effects of estradiol and raloxifene on collagen biosynthesis in cultured human skin fibroblasts. Int. J. Mol. Med. 2003, 12, 803–809. [Google Scholar] [CrossRef]
  51. Rona, C.; Vailati, F.; Berardesca, E. The cosmetic treatment of wrinkles. J. Cosmet. Dermatol. 2004, 3, 26–34. [Google Scholar] [CrossRef]
  52. Giardina, S.; Michelotti, A.; Zavattini, G.; Finzi, S.; Ghisalberti, C.; Marzatico, F. Efficacy study in vitro: Assessment of the properties of resveratrol and resveratrol + N-acetyl-cysteine on proliferation and inhibition of collagen activity. Minerva Ginecol. 2010, 62, 195–201. [Google Scholar]
  53. Lephart, E.D. Resveratrol, 4′ Acetoxy Resveratrol, R-equol, Racemic Equol or S-equol as Cosmeceuticals to Improve Dermal Health. Int. J. Mol. Sci. 2017, 18, 1193. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  54. Park, G.; Baek, S.; Kim, J.E.; Lim, T.G.; Lee, C.C.; Yang, H.; Kang, Y.G.; Park, J.S.; Augustin, M.; Mrozek, M.; et al. Flt3 is a target of coumestrol in protecting against UVB-induced skin photoaging. Biochem. Pharmacol. 2015, 98, 473–483. [Google Scholar] [CrossRef] [PubMed]
  55. Patriarca, M.T.; Barbosa de Moraes, A.R.; Nader, H.B.; Petri, V.; Martins, J.R.; Gomes, R.C.; Soares, J.M., Jr. Hyaluronic acid concentration in postmenopausal facial skin after topical estradiol and genistein treatment: A double-blind, randomized clinical trial of efficacy. Menopause 2013, 20, 336–341. [Google Scholar] [CrossRef] [PubMed]
  56. Lephart, E.D.; Naftolin, F. Menopause and the Skin: Old Favorites and New Innovations in Cosmeceuticals for Estrogen-Deficient Skin. Dermatol. Ther. 2021, 11, 53–69. [Google Scholar] [CrossRef]
  57. Verdier-Sévrain, S. Effect of estrogens on skin aging and the potential role of selective estrogen receptor modulators. Climacteric 2007, 10, 289–297. [Google Scholar] [CrossRef]
  58. Desmawati, D.; Sulastri, D. Phytoestrogens and Their Health Effect. Open Access Maced. J. Med. Sci. 2019, 7, 495–499. [Google Scholar] [CrossRef] [Green Version]
  59. Liu, T.; Li, N.; Yan, Y.Q.; Liu, Y.; Xiong, K.; Liu, Y.; Xia, Q.M.; Zhang, H.; Liu, Z.D. Recent advances in the anti-aging effects of phytoestrogens on collagen, water content, and oxidative stress. Phytother. Res. PTR 2020, 34, 435–447. [Google Scholar] [CrossRef]
  60. Payanglee, K.; Chonpathompikunlert, P.; Panityakul, T.; Radenahmad, N. Beneficial effects of young coconut juice on preserving neuronal cell density, lipid, renal and liver profiles in ovariectomized rats. A preliminary study. Songklanakarin J. Sci. Technol. 2017, 39, 237–243. [Google Scholar]
Applsci 12 01584 g001 550
Figure 1. Upper row. A comparison of rat skin epidermal thicknesses for the 7 groups examined (Hematoxylin and Eosin staining, 40×). The epidermal thickness of the OC group was the thinnest, while that of the OJ10 group was the thickest among 3 doses of YCJ treatment. Yellow arrows indicate the epidermal layers. Bar = 50 µm. Lower row: A comparison of rat skin dermal thickness for the 7 groups examined (H&E, 10×). Dermal thickness for the OC group was the thinnest. Among 3 doses of YCJ treatment, the OJ40 group was the thickest. The number of hair follicles in the dermis of the OJ40 group was the most abundant. Yellow arrows indicate the dermal layers. Bar = 200 µm. NC = the baseline normal control group; SC = sham-operated group; OC = ovariectomized (ovx) group; OE = ovxrats receiving estradiol benzoate 2.5 µg/kg BW/day; OJ10 = ovx rats receiving YCJ at 10 mL/kg BW/day; OJ40 = ovx rats receiving YCJ at 40 mL/kg BW/day.
Figure 1. Upper row. A comparison of rat skin epidermal thicknesses for the 7 groups examined (Hematoxylin and Eosin staining, 40×). The epidermal thickness of the OC group was the thinnest, while that of the OJ10 group was the thickest among 3 doses of YCJ treatment. Yellow arrows indicate the epidermal layers. Bar = 50 µm. Lower row: A comparison of rat skin dermal thickness for the 7 groups examined (H&E, 10×). Dermal thickness for the OC group was the thinnest. Among 3 doses of YCJ treatment, the OJ40 group was the thickest. The number of hair follicles in the dermis of the OJ40 group was the most abundant. Yellow arrows indicate the dermal layers. Bar = 200 µm. NC = the baseline normal control group; SC = sham-operated group; OC = ovariectomized (ovx) group; OE = ovxrats receiving estradiol benzoate 2.5 µg/kg BW/day; OJ10 = ovx rats receiving YCJ at 10 mL/kg BW/day; OJ40 = ovx rats receiving YCJ at 40 mL/kg BW/day.
Applsci 12 01584 g001
Applsci 12 01584 g002 550
Figure 2. Skin parameters: Epidermal thickness (A), dermal thickness (B), numbers of hair follicles (C), collagen fibril diameter from thick sections (D), collagen fibril diameter from thin sections (E). Significant differences at p < 0.05 were shown by the different letters indicated above the columns. NC = the normal control group as the baseline; SC = sham-operated group; OC = ovariectomized (ovx) group; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovxrats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day.
Figure 2. Skin parameters: Epidermal thickness (A), dermal thickness (B), numbers of hair follicles (C), collagen fibril diameter from thick sections (D), collagen fibril diameter from thin sections (E). Significant differences at p < 0.05 were shown by the different letters indicated above the columns. NC = the normal control group as the baseline; SC = sham-operated group; OC = ovariectomized (ovx) group; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovxrats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day.
Applsci 12 01584 g002
Applsci 12 01584 g003 550
Figure 3. Electron micrograph (TEM) of the keratinocytes of rat skin epidermis (4000×). Note how the keratinocyte cells in the OC group have shrunk in size. The OJ groups had bigger nucleic and cytoplasmic processes than the OC group. More desmosomes and narrower intercellular spaces occurred in the OJ groups than in the OC group. Far fewer desmosomes and obvious intercellular spaces were observed in the OC group. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. The yellow arrows indicate desmosomes, and yellow chevronsindicate the intracellular spaces. Bar = 2 µm.
Figure 3. Electron micrograph (TEM) of the keratinocytes of rat skin epidermis (4000×). Note how the keratinocyte cells in the OC group have shrunk in size. The OJ groups had bigger nucleic and cytoplasmic processes than the OC group. More desmosomes and narrower intercellular spaces occurred in the OJ groups than in the OC group. Far fewer desmosomes and obvious intercellular spaces were observed in the OC group. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. The yellow arrows indicate desmosomes, and yellow chevronsindicate the intracellular spaces. Bar = 2 µm.
Applsci 12 01584 g003
Applsci 12 01584 g004 550
Figure 4. Cell perimeters: nucleus perimeter of keratinocyte cells (A); cell perimeter of keratinocyte cells (B); nucleus perimeter of fibroblast cells (C); cell perimeter of fibroblast cells (D). Columns with different superscript letters are significantly different at p < 0.05. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day.
Figure 4. Cell perimeters: nucleus perimeter of keratinocyte cells (A); cell perimeter of keratinocyte cells (B); nucleus perimeter of fibroblast cells (C); cell perimeter of fibroblast cells (D). Columns with different superscript letters are significantly different at p < 0.05. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day.
Applsci 12 01584 g004
Applsci 12 01584 g005 550
Figure 5. Electron micrograph (TEM) of rat skin fibroblast cells of the dermis(4000×).In the OC group, the fibroblast cell size was the smallest, and the dilation of RER (chevrons) in the cytoplasm was obviously present. The nuclei were larger in the OJ groups, and cytoplasmic processes were branching and elongating. In addition, in the OJ group, the extracellular matrix had more numerous collagen fibers than the OC group. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. The yellow arrows indicate collagen fibers, and yellow chevrons indicate the dilation of the rough endoplasmic reticulum (RER). Bar = 2 µm.
Figure 5. Electron micrograph (TEM) of rat skin fibroblast cells of the dermis(4000×).In the OC group, the fibroblast cell size was the smallest, and the dilation of RER (chevrons) in the cytoplasm was obviously present. The nuclei were larger in the OJ groups, and cytoplasmic processes were branching and elongating. In addition, in the OJ group, the extracellular matrix had more numerous collagen fibers than the OC group. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. The yellow arrows indicate collagen fibers, and yellow chevrons indicate the dilation of the rough endoplasmic reticulum (RER). Bar = 2 µm.
Applsci 12 01584 g005
Applsci 12 01584 g006 550
Figure 6. Electron micrograph (TEM)of the dermo-epidermal junction of rat skin epidermis (2000×). The junctions of rats treated with YCJ (OJ groups) were not different from the NC and SC groups. In contrast, the dermo-epidermal junctions of the OC and OE groups had markedly reduced irregularities of the basal borders compared to those of the NC, SC, and OJ groups. The papillary layer of the dermis had far fewer collagen fibers and was loosely packed. In the OC and OE groups, the spaces between papillary and reticular layers were wider compared with the NC, SC, and OJ groups. In addition, the collagen fibers of the reticular layer of the OC and OE groups were packed into much smaller bundles compared with the other groups. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. B = basementmembrane, C = collagen fibers, D = dermis (yellow line), E = epidermis (white line), H = hemidesmosome. Bar = 2 µm.
Figure 6. Electron micrograph (TEM)of the dermo-epidermal junction of rat skin epidermis (2000×). The junctions of rats treated with YCJ (OJ groups) were not different from the NC and SC groups. In contrast, the dermo-epidermal junctions of the OC and OE groups had markedly reduced irregularities of the basal borders compared to those of the NC, SC, and OJ groups. The papillary layer of the dermis had far fewer collagen fibers and was loosely packed. In the OC and OE groups, the spaces between papillary and reticular layers were wider compared with the NC, SC, and OJ groups. In addition, the collagen fibers of the reticular layer of the OC and OE groups were packed into much smaller bundles compared with the other groups. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. B = basementmembrane, C = collagen fibers, D = dermis (yellow line), E = epidermis (white line), H = hemidesmosome. Bar = 2 µm.
Applsci 12 01584 g006
Applsci 12 01584 g007 550
Figure 7. Electron micrograph (TEM) of rat skin showing an overview of collagen fibers (2000×). The collagen fibers of the control (NC and SC) groups are arranged in parallel lines. Compared with the control groups, the collagen bundles of the OC group were much smaller. In contrast, collagen fibers combined in the YCJ (OJ) groups into large bundles, particularly that of the OJ40 group. Therefore, in the OJ groups, the space between the bundles (yellow arrows) became narrower when compared with the SC, OC, and OE groups. Yellow arrows indicate spaces between the collagen bundles. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day.Bar = 5 µm.
Figure 7. Electron micrograph (TEM) of rat skin showing an overview of collagen fibers (2000×). The collagen fibers of the control (NC and SC) groups are arranged in parallel lines. Compared with the control groups, the collagen bundles of the OC group were much smaller. In contrast, collagen fibers combined in the YCJ (OJ) groups into large bundles, particularly that of the OJ40 group. Therefore, in the OJ groups, the space between the bundles (yellow arrows) became narrower when compared with the SC, OC, and OE groups. Yellow arrows indicate spaces between the collagen bundles. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day.Bar = 5 µm.
Applsci 12 01584 g007
Applsci 12 01584 g008 550
Figure 8. Electron micrograph (TEM) of rat skin collagen fibrils of the dermis (cross-sections; 20,000×). The cross-sections show the ultrastructure of the collagen fibrils. The collagen diameters of the OC group were the smallest, and those of the OJ40 group were the largest. Furthermore, in the OC group, intercellular spaces between collagen fibrils were wider than in the controls (SC and OE groups) and in all three OJ groups (OJ10, OJ20, and OJ40 groups). NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. Bar = 500 µm.
Figure 8. Electron micrograph (TEM) of rat skin collagen fibrils of the dermis (cross-sections; 20,000×). The cross-sections show the ultrastructure of the collagen fibrils. The collagen diameters of the OC group were the smallest, and those of the OJ40 group were the largest. Furthermore, in the OC group, intercellular spaces between collagen fibrils were wider than in the controls (SC and OE groups) and in all three OJ groups (OJ10, OJ20, and OJ40 groups). NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. Bar = 500 µm.
Applsci 12 01584 g008
Applsci 12 01584 g009 550
Figure 9. Electron micrograph (TEM) of rat skin collagen fibrils of the dermis (long sections; 20,000×). The characteristic alignment of the collagen fibrils is a parallel packing in all groups except that of the OJ group. Collagen fibril size in the OJ groups was larger than that of the OC group. In addition, the spaces between collagen fibrils of the OC group were wider compared with the other groups. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. Bar = 500 µm.
Figure 9. Electron micrograph (TEM) of rat skin collagen fibrils of the dermis (long sections; 20,000×). The characteristic alignment of the collagen fibrils is a parallel packing in all groups except that of the OJ group. Collagen fibril size in the OJ groups was larger than that of the OC group. In addition, the spaces between collagen fibrils of the OC group were wider compared with the other groups. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. Bar = 500 µm.
Applsci 12 01584 g009
Applsci 12 01584 g010 550
Figure 10. Ultrastructural changes of keratinocyte and fibroblast cell scores.Using the criteria as shown in Table 1, ultrastructural changes of keratinocyte and fibroblast cells were scored and statistically compared. All different superscripts indicate statistical significance at p < 0.05 level. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. Bar = 500 µm.
Figure 10. Ultrastructural changes of keratinocyte and fibroblast cell scores.Using the criteria as shown in Table 1, ultrastructural changes of keratinocyte and fibroblast cells were scored and statistically compared. All different superscripts indicate statistical significance at p < 0.05 level. NC = normal control (baseline) rats; SC = sham-operated rats; OC = ovariectomized (ovx) rats; OE = ovx rats given estradiol benzoate (EB) 2.5 µg/kg BW/day; OJ10 = ovx rats given YCJ at 10 mL/kg BW/day; OJ20 = ovx rats given YCJ at 20 mL/kg BW/day; OJ40 = ovx rats given YCJ at 40 mL/kg BW/day. Bar = 500 µm.
Applsci 12 01584 g010
Applsci 12 01584 g011 550
Figure 11. (A) Gross morphology of wound healing for the sham-control group (SC), ovariectomized group (OC), and ovariectomized rats injected with estradiol benzoate(EB) 2.5 µg/kg BW/day group (OE), compared with that of YCJ (B) feeding groups (OJ): ovariectomized rats fed with YCJ 10 mL/kg BW/day (OJ10), ovariectomized rats fed with YCJ 20 mL/kg BW/day (OJ20), ovariectomized rats fed with YCJ 40 mL/kg BW/day (OJ40).The most accelerated wound healing and hair growth occurred in the OJ40 group.The number subscript indicates the following: 0 = 1 day after ovariectomy, 1 = 1 week after ovariectomy, 2 = 2 weeks after ovariectomy, 3 = 3 weeks after ovariectomy.
Figure 11. (A) Gross morphology of wound healing for the sham-control group (SC), ovariectomized group (OC), and ovariectomized rats injected with estradiol benzoate(EB) 2.5 µg/kg BW/day group (OE), compared with that of YCJ (B) feeding groups (OJ): ovariectomized rats fed with YCJ 10 mL/kg BW/day (OJ10), ovariectomized rats fed with YCJ 20 mL/kg BW/day (OJ20), ovariectomized rats fed with YCJ 40 mL/kg BW/day (OJ40).The most accelerated wound healing and hair growth occurred in the OJ40 group.The number subscript indicates the following: 0 = 1 day after ovariectomy, 1 = 1 week after ovariectomy, 2 = 2 weeks after ovariectomy, 3 = 3 weeks after ovariectomy.
Applsci 12 01584 g011
Table
Table 1. Criteria for measurement of keratinocyte and fibroblast cell changes.
Table 1. Criteria for measurement of keratinocyte and fibroblast cell changes.
CellsComplementsDegenerated Cell Features
(0 Point)		Normal Cell Features
(1 Point)
KeratinocytesIntercellular spaceWidening of intercellular space Non-widening of intercellular space
DesmosomeLoss of desmosomesMany desmosomes
Cell sizeReduced cytoplasmic area Normal
cytoplasmic area
Dermoepidermal junctionFlat dermo-epidermal junction The junction increased the number of footlike processes
FibroblastsNucleus-Irregular shape
-Heterochromatin
(Condensation of the nuclear chromatin)		-Spindle shape
-Increased euchromatin
Organelles-Dilated of RER cisternae
-Ballooning of Golgi saccules
-Swollen mitochondria		-Normal RER
-Non-ballooning of Golgi saccules
-Non-swollen mitochondria
Cytoplasm-Reduced cytoplasmic area
-Few branches		-Normal size of cytoplasm
-Branched and elongated
Collagen fibrilsFew collagen fibrils around the fibroblastsNumerous collagen fibrils around the fibroblasts
Publisher’s Note: MDPI stays neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Share and Cite

MDPI and ACS Style

Radenahmad, N.; Sereemaspun, A.; Bueraheng, N.; Hutapea, A.M. Beneficial Effects of Young Coconut Juice on Increasing Skin Thickness, Enhancing Skin Whitening, and Reducing Skin Wrinkles in Ovariectomized Rats. Appl. Sci. 2022, 12, 1584. https://doi.org/10.3390/app12031584

AMA Style

Radenahmad N, Sereemaspun A, Bueraheng N, Hutapea AM. Beneficial Effects of Young Coconut Juice on Increasing Skin Thickness, Enhancing Skin Whitening, and Reducing Skin Wrinkles in Ovariectomized Rats. Applied Sciences. 2022; 12(3):1584. https://doi.org/10.3390/app12031584

Chicago/Turabian Style

Radenahmad, Nisaudah, Amornpun Sereemaspun, Nurdeen Bueraheng, and Albert Manggading Hutapea. 2022. "Beneficial Effects of Young Coconut Juice on Increasing Skin Thickness, Enhancing Skin Whitening, and Reducing Skin Wrinkles in Ovariectomized Rats" Applied Sciences 12, no. 3: 1584. https://doi.org/10.3390/app12031584

APA Style

Radenahmad, N., Sereemaspun, A., Bueraheng, N., & Hutapea, A. M. (2022). Beneficial Effects of Young Coconut Juice on Increasing Skin Thickness, Enhancing Skin Whitening, and Reducing Skin Wrinkles in Ovariectomized Rats. Applied Sciences, 12(3), 1584. https://doi.org/10.3390/app12031584

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
