Appl. Mech., Volume 2, Issue 2 (June 2021) – 11 articles

The tensile fracture mechanics and thermo-mechanical properties of mixtures composed of two kinds of epoxy resins of different chemical structures and functional groups were studied. The base resin was a bi-functional epoxy resin based on diglycidyl ether of bisphenol-A (DGEBA) and the other resins were (a) distilled triglycidylether of meta-amino phenol (b) 1, 6–naphthalene di epoxy and (c) fluorene di epoxy. This research shows that a small number of multifunctional epoxy systems, both di- and tri-functional, can significantly increase tensile strength (14%) over neat DGEBA while having no negative impact on other mechanical properties including glass transition temperature and elastic modulus. In fact, when compared to unmodified DGEBA, the tri-functional epoxy shows a slight increase (5%) in glass transition temperature at 10 wt.% concentration. The enhanced crosslinking of DGEBA (90 wt.%)/distilled triglycidylether of meta-amino phenol (10 wt.%) blends may be the possible reason for the improved glass transition. Finally, the influence of strain rate, temperature and moisture were investigated for both the neat DGEBA and the best performing modified system. The neat DGEBA was steadily outperformed by its modified counterpart in every condition. Full article

The Euler–Bernoulli theory of beams is usually presented in two forms: (i) in the linear case of a small slope using Cartesian coordinates along and normal to the straight undeflected position; and (ii) in the non-linear case of a large slope using curvilinear coordinates along the deflected position, namely, the arc length and angle of inclination. The present paper starts with the exact equation in a third form, that is, (iii) using Cartesian coordinates along and normal to the undeflected position like (i), but allowing exactly the non-linear effects of a large slope like (ii). This third form of the equation of the elastica shows that the exact non-linear shape is a superposition of linear harmonics; thus, the non-linear effects of a large slope are equivalent to the generation of harmonics of a linear solution for a small slope. In conclusion, it is shown that: (i) the critical buckling load is the same in the linear and non-linear cases because it is determined by the fundamental mode; (ii) the buckled shape of the elastica is different in the linear and non-linear cases because non-linearity adds harmonics to the fundamental mode. The non-linear shape of the elastica, for cases when powers of the slope cannot be neglected, is illustrated for the first four buckling modes of cantilever, pinned, and clamped beams with different lengths and amplitudes. Full article

Research in the field of underwater (UW) robotic applications is rapidly developing. The emergence of coupling the newest technologies on submersibles, different types of telecommunication devices, sensors, and soft robots is transforming the rigid approach to robotic design by providing solutions that bridge the gap between accuracy and adaptability in an environment where there is so much fluctuation in object targeting and environmental conditions. In this paper, we represent a review of the history, development, recent research endeavors, and projected outlook for the area of soft robotics technology pertaining to its use with tactile sensing in the UW environment. Full article

This paper investigates the macroscopic anisotropic behavior of periodic cellular solids with rigid-jointed microscopic truss-like architecture. A theoretical matrix-based procedure is presented to calculate the homogenized stiffness and strength properties of the material which is validated experimentally. The procedure consists of four main steps, namely, (i) using classical structural analysis to determine the stiffness properties of a lattice unit cell, (ii) employing the Bloch’s theorem to generate the irreducible representation of the infinite lattice, (iii) resorting to the Cauchy–Born Hypothesis to express the microscopic nodal forces and deformations in terms of a homogeneous macroscopic strain field applied to the lattice, and (iv) employing the Hill–Mandel homogenization principle to obtain the macro-stiffness properties of the lattice topologies. The presented model is used to investigate the anisotropic mechanical behavior of 13 2D periodic cellular solids. The results are documented in three set of charts that show (i) the change of the Young and Shear moduli of the material with respect to their relative density; (ii) the contribution of the bending stiffness of microscopic cell elements to the homogenized macroscopic stiffness of the material; and (iii) polar diagrams of the change of the elastic moduli of the cellular solid in response to direction of macroscopic loading. The three set of charts can be used for design purposes in assemblies involving the honeycomb structures as it may help in selecting the best lattice topology for a given functional stiffness and strength requirement. The theoretical model was experimentally validated by means of tensile tests performed in additively manufactured Lattice Material (LM) specimens, achieving good agreement between the results. It was observed that the model of rigid-joined LM (RJLM) predicts the homogenized mechanical properties of the LM with higher accuracy compared to those predicted by pin-jointed models. Full article

An experimental and numerical investigation of the flow near a blunt body has been conducted in this study. Most experimental methods of flow studies use flow visualization and probes introduction into the flow field. The main goal of this research was the development of a new methodology to analyze flows, and to measure flow characteristics without taking into account the distorting effects of measuring probes. A series of experiments were performed on a ground surveillance radar in the Price-Païdoussis subsonic wind tunnel. Forces and moments were measured as functions of wind speeds and angular positions by the use of a six-component aerodynamic scale. A Computational Fluid Dynamics three-dimensional model was employed to analyze the wake region of the ground surveillance radar. A turbulence reduction system was proposed and analyzed in this research. The use of the proposed turbulence reduction system was found to be an effective way to reduce turbulent flow intensity by 50%, drag coefficients by 9.6%, and delay the flow transition point by 7.6 times. Full article

Over time, the fabrication of lattice, porous structures has always been a controversial field for researchers and practitioners. Such structures could be fabricated in a stochastic way, thus, with limited control over the actual porosity percentage. The emerging technology of 3D printing, offered an automated process that did not require the presence of molds and operated on a layer-by-layer deposition basis, provided the ability to fabricate almost any shape through a variety of materials and methods under the umbrella of the ASTM terminology “additive manufacturing”. In the field of biomedical engineering, the technology was embraced and adopted for relevant applications, offering an elevated degree of design freedom. Applications range in the cases where custom-shaped, patient-specific items have to be produced. Scaffold structures were already a field under research when 3D printing was introduced. These structures had to act as biocompatible, bioresorbable and biodegradable substrates, where the human cells could attach and proliferate. In this way, tissue could be regenerated inside the human body. One of the most important criteria for such a structure to fulfil is the case-specific internal geometry design with a controlled porosity percentage. 3D printing technology offered the ability to tune the internal porosity percentage with great accuracy, along with the ability to fabricate any internal design pattern. In this article, lattice scaffold structures for tissue regeneration are overviewed, and their evolution upon the introduction of 3D printing technology and its employment in their fabrication is described. Full article

In the present work, an investigation on the surface topography and geometry variation of bagasse fibers was correlated with their mechanical properties via image analysis. The fibers were tested under a universal tensile testing machine and the diameter of the fibers was calculated using images obtained in a digital microscope. Furthermore, surface characterization and quantification were also performed using images obtained via SEM. The results showed that the surface roughness of alkali-treated bagasse fiber increased compared to that of the untreated one. Moreover, it was observed that the diameter variation of bagasse fiber along its length and among different fibers is not only variable but also unpredictable. The tensile test results revealed that bagasse fibers showed lower stress at a rupture with considerable scatter. It can be inferred that the synergistic effect of thick bagasse fiber, bagasse fiber diameter variations along its length and among fibers, and the fiber fracture mechanism establishes a local condition for fracture and resulted in such variations in tensile properties. Finally, the results clearly showed that the two-parameter Weibull fit the experimental data fairly well ($R^2=0.97$). The Weibull modulus $\left(m\right)$ was found to be 1.7, indicating that the strength distribution is high. Full article

Human gait is very individual and it may serve as biometric to identify people in camera recordings. Comparable results can be achieved while using the acoustic signature of human footstep sounds. This acoustic solution offers the opportunity of less installation space and the use of cost-efficient microphones when compared to visual system. In this paper, a method for person identification based on footstep sounds is proposed. First, step sounds are isolated from microphone recordings and separated into 500 ms samples. The samples are transformed with a sliding window into mel-frequency cepstral coefficients (MFCC). The result is represented as an image that serves as input to a convolutional neural network (CNN). The dataset for training and validating the CNN is recorded with five subjects in the acoustic lab of DLR. These experiments identify a total number of 1125 steps. The validation of the CNN reveals a minimum $F_1$-score of 0.94 for all five classes and an accuracy of 0.98. The Grad-CAM method is applied to visualize the background of its decision in order to verify the functionality of the proposed CNN. Subsequently, two challenges for practical implementations, noise and different footwear, are discussed using experimental data. Full article

Natural fiber composites are widely used in a several industrial applications due to their outstanding biodegradability and recyclability. Thermal compression molding is a rapid and easy method to fabricate composite sheets. To better understand the manufacturing process and evaluate the mechanical properties of hemp woven fabrics reinforced thermoplastic composite at elevated temperatures, a detailed investigation is required. In this study, composite sheets were initially fabricated using hemp fiber fabrics (taffeta and serge 2×1) and polypropylene sheets by the thermal compression molding process. Mechanical tests (uniaxial, shear, and biaxial) were carried out at temperatures ranging from 20 to 160 ${}^{\circ }$C in order to estimate the mechanical properties of composite sheets. Non-linear behavior was observed during the loading due to the unbalanced weaving pattern of hemp fabric. The biaxial behavior of the composite was estimated using a theoretical method for fabric strength prediction taking into account the interaction effect between the yarns. The experimental results demonstrate that, at high temperature, the polymer softens and the fiber reinforcements dismantle which resulting in a decrease in the mechanical properties of the composite. Two analytical models (Ha & Springer and thermal expansion coefficient) were also proposed to estimate the thermo-mechanical properties of natural fiber composites subjected to various temperatures. Full article

In this paper, transverse vibration analysis of rotating micro-beam is investigated based on the modified couple stress theory. The simply-supported micro-beam is modeled utilizing Euler-Bernoulli and Timoshenko beam theories. The system is rotating around a fixed axis perpendicular to the axial direction of the beam. For the first time, displacement filed is introduced as a coupled field to the translational field. In other words, the mentioned rotational displacement field is expressed as a proportional function of translational displacement field using first (axial), second (lateral), and third (angular or rotational) velocity factors. Utilizing Hamilton’s approach as a variational method, dynamic-vibration equations of motion of the proposed model are derived. Galerkin’s method is adopted to solve the equation corresponding to the Euler–Bernoulli and Timoshenko beams. For the case considering shear deformation effects, Navier method is chosen. For evaluation of current results and models, they are compared with those available at the benchmark. In this paper; effects of slenderness ratio, axial, lateral, and angular velocity factors, and rotations of the beam on the frequency are reported. Based on the results presented, mentioned factors should be counted in the analysis and design of such rotating micro-systems. Full article

Strain-based design (SBD) plays an important role in pipeline design and assessment of pipelines subjected to geo-hazards. Under such hazards, a pipe can be subjected to substantial plastic strains, leading to tensile failure at locations of girth weld flaws. For SBD, the finite element method (FEM) can be a reliable tool to calculate the tensile strain capacity (TSC) for better design in pipelines. This study aims to investigate the ductile fracture properties for specific vintage pipeline steel (API 5L grade of X52) using the extended finite element method (XFEM). Eight full-scale tests were simulated using the commercial finite element analysis software ABAQUS Version 6.17. Maximum principal strain is used to assess the damage initiation using the cohesive zone model (CZM) when the crack evolution is evaluated by fracture energy release. A proper set of damage parameters for the X52 materials was calibrated based on the ability of the model to reproduce the experimental results. These experimental results included the tensile strain, applied load, endplate rotation, and crack mouth opening displacement (CMOD). This study describes a methodology for validation of the XFEM and the proper damage parameters required to model crack initiation and propagation in X52 grades of pipeline. Full article
