Materials

Research

2539 KiB

Open AccessFeature PaperArticle

Determination of Specific Heat Capacity on Composite Shape-Stabilized Phase Change Materials and Asphalt Mixtures by Heat Exchange System

by Biao Ma, Xue-yan Zhou, Jiang Liu, Zhanping You, Kun Wei and Xiao-feng Huang

Materials 2016, 9(5), 389; https://doi.org/10.3390/ma9050389 - 19 May 2016

Cited by 54 | Viewed by 9696

Abstract

Previous research has shown that composite shape-stabilized phase change material (CPCM) has a remarkable capacity for thermal storage and stabilization, and it can be directly applied to highway construction without leakage. However, recent studies on temperature changing behaviors of CPCM and asphalt mixture [...] Read more.

Previous research has shown that composite shape-stabilized phase change material (CPCM) has a remarkable capacity for thermal storage and stabilization, and it can be directly applied to highway construction without leakage. However, recent studies on temperature changing behaviors of CPCM and asphalt mixture cannot intuitively reflect the thermoregulation mechanism and efficiency of CPCM on asphalt mixture. The objective of this paper is to determine the specific heat capacity of CPCM and asphalt mixtures mixed with CPCM using the heat exchange system and the data acquisition system. Studies have shown that the temperature-rise curve of 5 °C CPCM has an obvious temperature plateau, while an asphalt mixture mixed with 5 °C CPCM does not; with increasing temperature, the specific heat capacities of both 5 °C CPCM and asphalt mixture first increase and then decrease, while the variation rate of 5 °C CPCM is larger than that of the asphalt mixture, and the maximum specific heat capacity of 5 °C CPCM appears around the initial phase change temperature. It is concluded that the temperature intervals of 5 °C CPCM are −18 °C–7 °C, 7 °C–25 °C and 25 °C–44 °C, respectively, and that of the asphalt mixture are −18 °C~10 °C, −10 °C~5 °C and 5 °C~28 °C. A low dosage of 5 °C CPCM has little influence on the specific heat capacity of asphalt mixture. Finally, the functions of specific heat capacities and temperature for CPCM and asphalt mixture mixed with CPCM were recommended by the sectional regression method. Full article

(This article belongs to the Special Issue Development and Characterisation of Encapsulated PCM: Nano-, Micro-, and Macro-Encapsulation)

► Show Figures

Figure 1

4909 KiB

Open AccessArticle

Macro-Encapsulated PCM Cylinder Module Based on Paraffin and Float Stones

by Kailiang Huang, Dong Liang, Guohui Feng, Mingzhi Jiang, Yuhua Zhu, Xin Liu and Bian Jiang

Materials 2016, 9(5), 361; https://doi.org/10.3390/ma9050361 - 12 May 2016

Cited by 12 | Viewed by 5877

Abstract

Organic phase change material (PCM) with macro-encapsulation is attractive in energy storage applications as it has relatively low cost. This study focuses on using PET plastic pipes to encapsulate paraffin and using low-cost float stones to increase the thermal conductivity of PCM modules [...] Read more.

Organic phase change material (PCM) with macro-encapsulation is attractive in energy storage applications as it has relatively low cost. This study focuses on using PET plastic pipes to encapsulate paraffin and using low-cost float stones to increase the thermal conductivity of PCM modules as they have a special structure of high porosity. Float stones were immersed in the liquid PCM and an ultrasonic welding method used to prevent leakage of the PET plastic pipes. Scanning electron microscopy (SEM) was used to discover the appearance of the composite PCM. The thermal performance of the PCM cylinder module was analyzed through experimental tests of a constant-temperature water bath and numerical simulations. The result indicates that this PCM Ccylinder module is superior in thermal energy storage compared with the reference module even though fewer PCM was contained and the latent heat loss is considerable. The pipe diameter is an important parameter when using this kind of PCM cylinder module in water tanks. Full article

(This article belongs to the Special Issue Development and Characterisation of Encapsulated PCM: Nano-, Micro-, and Macro-Encapsulation)

► Show Figures

Figure 1

7631 KiB

Open AccessArticle

On the Behavior of Different PCMs in a Hot Water Storage Tank against Thermal Demands

by Jacobo Porteiro, José Luis Míguez, Bárbara Crespo, José De Lara and José María Pousada

Materials 2016, 9(3), 213; https://doi.org/10.3390/ma9030213 - 21 Mar 2016

Cited by 18 | Viewed by 6138

Abstract

Advantages, such as thermal storage improvement, are found when using PCMs (Phase Change Materials) in storage tanks. The inclusion of three different types of materials in a 60 l test tank is studied. Two test methodologies were developed, and four tests were performed [...] Read more.

Advantages, such as thermal storage improvement, are found when using PCMs (Phase Change Materials) in storage tanks. The inclusion of three different types of materials in a 60 l test tank is studied. Two test methodologies were developed, and four tests were performed following each methodology. A thermal analysis is performed to check the thermal properties of each PCM. The distributions of the water temperatures inside the test tanks are evaluated by installing four Pt-100 sensors at different heights. A temperature recovery is observed after exposing the test tank to an energy demand. An energetic analysis that takes into account the energy due to the water temperature, the energy due to the PCM and the thermal loss to the ambient environment is also presented. The percentage of each PCM that remains in the liquid state after the energy demand is obtained. Full article

(This article belongs to the Special Issue Development and Characterisation of Encapsulated PCM: Nano-, Micro-, and Macro-Encapsulation)

► Show Figures

Figure 1

6402 KiB

Open AccessArticle

Building Energy Storage Panel Based on Paraffin/Expanded Perlite: Preparation and Thermal Performance Study

by Xiangfei Kong, Yuliang Zhong, Xian Rong, Chunhua Min and Chengying Qi

Materials 2016, 9(2), 70; https://doi.org/10.3390/ma9020070 - 25 Jan 2016

Cited by 55 | Viewed by 7789

Abstract

This study is focused on the preparation and performance of a building energy storage panel (BESP). The BESP was fabricated through a mold pressing method based on phase change material particle (PCMP), which was prepared in two steps: vacuum absorption and surface film [...] Read more.

This study is focused on the preparation and performance of a building energy storage panel (BESP). The BESP was fabricated through a mold pressing method based on phase change material particle (PCMP), which was prepared in two steps: vacuum absorption and surface film coating. Firstly, phase change material (PCM) was incorporated into expanded perlite (EP) through a vacuum absorption method to obtain composite PCM; secondly, the composite PCM was immersed into the mixture of colloidal silica and organic acrylate, and then it was taken out and dried naturally. A series of experiments, including differential scanning calorimeter (DSC), scanning electron microscope (SEM), best matching test, and durability test, have been conducted to characterize and analyze the thermophysical property and reliability of PCMP. Additionally, the thermal performance of BESP was studied through a dynamic thermal property test. The results have showed that: (1) the surface film coating procedure can effectively solve the leakage problem of composite phase change material prepared by vacuum impregnation; (2) the optimum adsorption ratio for paraffin and EP was 52.5:47.5 in mass fraction, and the PCMP has good thermal properties, stability, and durability; and (3) in the process of dynamic thermal performance test, BESP have low temperature variation, significant temperature lagging, and large heat storage ability, which indicated the potential of BESP in the application of building energy efficiency. Full article

(This article belongs to the Special Issue Development and Characterisation of Encapsulated PCM: Nano-, Micro-, and Macro-Encapsulation)

► Show Figures

Figure 1

3827 KiB

Open AccessArticle

Development of Hollow Steel Ball Macro-Encapsulated PCM for Thermal Energy Storage Concrete

by Zhijun Dong, Hongzhi Cui, Waiching Tang, Dazhu Chen and Haibo Wen

Materials 2016, 9(1), 59; https://doi.org/10.3390/ma9010059 - 19 Jan 2016

Cited by 48 | Viewed by 8964

Abstract

The application of thermal energy storage with phase change materials (PCMs) for energy efficiency of buildings grew rapidly in the last few years. In this research, octadecane paraffin was served as a PCM, and a structural concrete with the function of indoor temperature [...] Read more.

The application of thermal energy storage with phase change materials (PCMs) for energy efficiency of buildings grew rapidly in the last few years. In this research, octadecane paraffin was served as a PCM, and a structural concrete with the function of indoor temperature control was developed by using a macro-encapsulated PCM hollow steel ball (HSB). The macro-encapsulated PCM-HSB was prepared by incorporation of octadecane into HSBs through vacuum impregnation. Test results showed that the maximum percentage of octadecane carried by HSBs was 80.3% by mass. The macro-encapsulated PCM-HSB has a latent heat storage capacity as high as 200.5 J/g. The compressive strength of concrete with macro-encapsulated PCM-HSB at 28 days ranged from 22 to 40 MPa. The indoor thermal performance test revealed that concrete with macro-encapsulated octadecane-HSB was capable of reducing the peak indoor air temperature and the fluctuation of indoor temperature. It can be very effective in transferring the heating and cooling loads away from the peak demand times. Full article

(This article belongs to the Special Issue Development and Characterisation of Encapsulated PCM: Nano-, Micro-, and Macro-Encapsulation)

► Show Figures

Figure 1

2523 KiB

Open AccessArticle

Preparation and Characterization of Inorganic PCM Microcapsules by Fluidized Bed Method

by Svetlana Ushak, M. Judith Cruz, Luisa F. Cabeza and Mario Grágeda

Materials 2016, 9(1), 24; https://doi.org/10.3390/ma9010024 - 4 Jan 2016

Cited by 39 | Viewed by 10650

Abstract

The literature shows that inorganic phase change materials (PCM) have been very seldom microencapsulated, so this study aims to contribute to filling this research gap. Bischofite, a by-product from the non-metallic industry identified as having good potential to be used as inorganic PCM, [...] Read more.

The literature shows that inorganic phase change materials (PCM) have been very seldom microencapsulated, so this study aims to contribute to filling this research gap. Bischofite, a by-product from the non-metallic industry identified as having good potential to be used as inorganic PCM, was microencapsulated by means of a fluidized bed method with acrylic as polymer and chloroform as solvent, after compatibility studies of both several solvents and several polymers. The formation of bischofite and pure MgCl₂·6H₂O microcapsules was investigated and analyzed. Results showed an efficiency in microencapsulation of 95% could be achieved when using 2 min of fluidization time and 2 kg/h of atomization flow. The final microcapsules had excellent melting temperatures and enthalpy compared to the original PCM, 104.6 °C and 95 J/g for bischofite, and 95.3 and 118.3 for MgCl₂·6H₂O. Full article

(This article belongs to the Special Issue Development and Characterisation of Encapsulated PCM: Nano-, Micro-, and Macro-Encapsulation)

► Show Figures

Figure 1

2310 KiB

Open AccessFeature PaperArticle

Preparation and Characterization of Microencapsulated Phase Change Materials for Use in Building Applications

by Jessica Giro-Paloma, Refat Al-Shannaq, Ana Inés Fernández and Mohammed M. Farid

Materials 2016, 9(1), 11; https://doi.org/10.3390/ma9010011 - 26 Dec 2015

Cited by 43 | Viewed by 7659

Abstract

A method for preparing and characterizing microencapsulated phase change materials (MPCM) was developed. A comparison with a commercial MPCM is also presented. Both MPCM contained paraffin wax as PCM with acrylic shell. The melting temperature of the PCM was around 21 °C, suitable [...] Read more.

A method for preparing and characterizing microencapsulated phase change materials (MPCM) was developed. A comparison with a commercial MPCM is also presented. Both MPCM contained paraffin wax as PCM with acrylic shell. The melting temperature of the PCM was around 21 °C, suitable for building applications. The M-2 (our laboratory made sample) and Micronal^® DS 5008 X (BASF) samples were characterized using SEM, DSC, nano-indentation technique, and Gas Chromatography/Mass spectrometry (GC-MS). Both samples presented a 6 μm average size and a spherical shape. Thermal energy storage (TES) capacities were 111.73 J·g⁻¹ and 99.3 J·g⁻¹ for M-2 and Micronal^® DS 5008 X, respectively. Mechanical characterization of the samples was performed by nano-indentation technique in order to determine the elastic modulus (E), load at maximum displacement (P_m), and displacement at maximum load (h_m), concluding that M-2 presented slightly better mechanical properties. Finally, an important parameter for considering use in buildings is the release of volatile organic compounds (VOC’s). This characteristic was studied at 65 °C by CG-MS. Both samples showed VOC’s emission after 10 min of heating, however peaks intensity of VOC’s generated from M-2 microcapsules showed a lower concentration than Micronal^® DS 5008 X. Full article

(This article belongs to the Special Issue Development and Characterisation of Encapsulated PCM: Nano-, Micro-, and Macro-Encapsulation)

► Show Figures

Figure 1

2644 KiB

Open AccessArticle

Preparation, Mechanical and Thermal Properties of Cement Board with Expanded Perlite Based Composite Phase Change Material for Improving Buildings Thermal Behavior

by Rongda Ye, Xiaoming Fang, Zhengguo Zhang and Xuenong Gao

Materials 2015, 8(11), 7702-7713; https://doi.org/10.3390/ma8115408 - 13 Nov 2015

Cited by 34 | Viewed by 6756

Abstract

Here we demonstrate the mechanical properties, thermal conductivity, and thermal energy storage performance of construction elements made of cement and form-stable PCM-Rubitherm® RT 28 HC (RT28)/expanded perlite (EP) composite phase change materials (PCMs). The composite PCMs were prepared by adsorbing RT28 into the [...] Read more.

Here we demonstrate the mechanical properties, thermal conductivity, and thermal energy storage performance of construction elements made of cement and form-stable PCM-Rubitherm® RT 28 HC (RT28)/expanded perlite (EP) composite phase change materials (PCMs). The composite PCMs were prepared by adsorbing RT28 into the pores of EP, in which the mass fraction of RT28 should be limited to be no more than 40 wt %. The adsorbed RT28 is observed to be uniformly confined into the pores of EP. The phase change temperatures of the RT28/EP composite PCMs are very close to that of the pure RT28. The apparent density and compression strength of the composite cubes increase linearly with the mass fraction of RT28. Compared with the thermal conductivity of the boards composed of cement and EP, the thermal conductivities of the composite boards containing RT28 increase by 15%–35% with the mass fraction increasing of RT28. The cubic test rooms that consist of six boards were built to evaluate the thermal energy storage performance, it is found that the maximum temperature different between the outside surface of the top board with the indoor temperature using the composite boards is 13.3 °C higher than that of the boards containing no RT28. The thermal mass increase of the built environment due to the application of composite boards can contribute to improving the indoor thermal comfort and reducing the energy consumption in the buildings. Full article

(This article belongs to the Special Issue Development and Characterisation of Encapsulated PCM: Nano-, Micro-, and Macro-Encapsulation)

► Show Figures

Figure 1

1540 KiB

Open AccessArticle

Study of Fresh and Hardening Process Properties of Gypsum with Three Different PCM Inclusion Methods

by Susana Serrano, Camila Barreneche, Antonia Navarro, Laia Haurie, A. Inés Fernandez and Luisa F. Cabeza

Materials 2015, 8(10), 6589-6596; https://doi.org/10.3390/ma8105324 - 24 Sep 2015

Cited by 6 | Viewed by 5258

Abstract

Gypsum has two important states (fresh and hardened states), and the addition of phase change materials (PCM) can vary the properties of the material. Many authors have extensively studied properties in the hardened state; however, the variation of fresh state properties due to [...] Read more.

Gypsum has two important states (fresh and hardened states), and the addition of phase change materials (PCM) can vary the properties of the material. Many authors have extensively studied properties in the hardened state; however, the variation of fresh state properties due to the addition of Micronal® DS 5001 X PCM into gypsum has been the object of few investigations. Properties in fresh state define the workability, setting time, adherence and shrinkage, and, therefore the possibility of implementing the material in building walls. The aim of the study is to analyze, compare and evaluate the variability of fresh state properties after the inclusion of 10% PCM. PCM are added into a common gypsum matrix by three different methods: adding microencapsulated PCM, making a suspension of PCM/water, and incorporating PCM through a vacuum impregnation method. Results demonstrate that the inclusion of PCM change completely the water required by the gypsum to achieve good workability, especially the formulation containing Micronal® DS 5001 X: the water required is higher, the retraction is lower (50% less) due to the organic nature of the PCM with high elasticity and, the adherence is reduced (up to 45%) due to the difference between the porosity of the different surfaces as well as the surface tension difference. Full article

(This article belongs to the Special Issue Development and Characterisation of Encapsulated PCM: Nano-, Micro-, and Macro-Encapsulation)

► Show Figures

Figure 1
