Integrated Waveguide-Based Photonic Devices

A special issue of Photonics (ISSN 2304-6732).

Deadline for manuscript submissions: 31 December 2024 | Viewed by 12641

Special Issue Editors

Dr. Qiancheng Zhao

E-Mail Website
Guest Editor
School of Microelectronics, Southern University of Science and Technology, Shenzhen, China
Interests: low-loss planar lightwave technology; nonlinear integrated photonic devices; micro-/nano-fabrication
Special Issues, Collections and Topics in MDPI journals
Dr. Li Shen

E-Mail Website
Guest Editor
Wuhan National Laboratory for Optoelectronics, Huazhong University of Science and Technology, Wuhan, China
Interests: mid-infrared photonics; silicon photonics; semiconductor fibers
Special Issues, Collections and Topics in MDPI journals

Special Issue Information

Dear Colleagues,

Planar lightwave circuits have materialized into one of the leading platforms for information acquisition, processing, and transmission with unparalleled advantages of high bandwidth, small footprint, and mass volume scalability. Integrated optical waveguides, enabled by index contrast between the core and cladding materials, confine and guide light at the micro- and nano-scale. Their versatile structures and functions have energized a variety of photonic devices and architectures such as light sources, modulators, amplifiers, detectors, resonators, optical I/O, which are enabling factors for the on-chip implementation of optical communications, metrology, quantum computing, health monitoring, and so on. Great achievements in integrated waveguides have been made in both academia and industry where new material, design methodology, architecture, and manufacture standards constantly emerge. Waveguide-based devices also have extended into cutting-edge territories including quantum technology, artificial intelligence, virtual reality, 6G and millimeter-wave communications, etc. As long as there is a need for higher bandwidth, smaller footprint, low-energy consumption, stronger light-matter interaction, and large scalability, the research into integrated waveguide-based photonic devices will continue to thrive.

This Special Issue focuses on the state-of-the-art achievements in integrated waveguide-based photonic devices, with a broader aim to present novel material, design methodology, and fabrication techniques as well as cutting-edge applications. We welcome work in any form, including reviews, articles, letters, and viewpoints. Topics of interest include (but are not limited to):

  • Low-loss waveguides and high-Q resonators;
  • Passive wavelength/mode/power-controlling devices;
  • Waveguide-grating couplers and optical I/Os;
  • Waveguide-based modulators and detectors;
  • On-chip light sources;
  • Optoelectronic hybrid and heterogeneous integration;
  • Novel waveguide materials and platforms;
  • Optical phased arrays and chip-based LiDAR;
  • Integrated photonic neural network and parallel computing;
  • Integrated quantum photonic devices;
  • Integrated mid-infrared photonic devices;
  • Optofluidic devices and lab-on-chip systems.

Dr. Qiancheng Zhao
Dr. Li Shen
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Photonics is an international peer-reviewed open access monthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2400 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • integrated photonics
  • photonic integrated devices
  • planar lightwave circuits
  • ultra-low-loss waveguides
  • microresonators
  • silicon photonics
  • silicon nitride integrated photonics
  • lithium niobate integrated photonics
  • nonlinear integrated photonics
  • mid-infrared integrated photonics

Benefits of Publishing in a Special Issue

  • Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
  • Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
  • Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
  • External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
  • e-Book format: Special Issues with more than 10 articles can be published as dedicated e-books, ensuring wide and rapid dissemination.

Further information on MDPI's Special Issue polices can be found here.

Published Papers (8 papers)
