The increasing demand for critical minerals is forcing the mineral exploration industry to search for deposits beneath deeper cover and over larger areas. MobileMT, an airborne passive, broadband, total-field AFMAG-class system, couples three-component measurements of airborne magnetic field variations with a remote electric-field base station to image electrical resistivity from the surface to depths of >1–2 km. We present a workflow that integrates MobileMT data with the parallelized, adaptive finite-element 2.5D open-source inversion code MARE2DEM, accompanied by automated mesh generation procedures, to create a rapid and scalable workflow for deep ore exploration. Using this software on two field trials, we demonstrate that (i) high-frequency (>4 kHz) data are essential for recovering not only shallow geology but also, when combined with low frequencies, for refining deep structures and targets and that (ii) base station effects modify the shape of the apparent conductivity curve but have negligible impact on the inverted sections. The proposed workflow is a reliable and effective approach for identifying mineralization-related features and refining geologic models based on data from extensive airborne geophysical surveys. Full article

This study proposes a novel drone-based semi-airborne total-field magnetometric resistivity (SA-TFMMR) system for high-resolution detection of conductive fracture zones in geologically hazardous terrains. The system integrates a high-power, low-frequency grounded-wire transmitter with a drone-mounted total-field magnetometer, achieving high survey efficiency and extensive data coverage in mountainous areas. We develop a 3D inversion framework incorporating terrain-adaptive depth weighting, which successfully images a dipping water-saturated fracture zone model beneath a reservoir overburden at a tunnel water gushing accident site. Sensitivity analyses of SA-TFMMR reveal that the effectiveness of detection is controlled by the source-target coupling and the orientation of the target body with respect to the geomagnetic field. Optimal current injection along target strike directions amplifies magnetic anomalies, and orthogonal multi-source configurations can enhance imaging resolution. This UAV-geophysical integration provides a paradigm for pre-disaster monitoring of water-related geohazards. Full article

The characterization of dimensional stone deposits is essential for quarry assessment and design. However, uncertainties in mapping and designing pose significant challenges. To address this issue, an innovative approach is initiated to develop a virtual reality model by integrating unmanned aerial vehicle (UAV) photogrammetry for surface modeling and Electric Resistivity Tomography (ERT) for subsurface deposit imaging. This strategy offers a cost-effective, time-efficient, and safer alternative to traditional surveying methods for challenging mountainous terrain. UAV methodology involved data collection using a DJI Mavic 2 Pro (20 MP camera) with 4 K resolution images captured at 221 m altitude and 80 min flight duration. Images were taken with 75% frontal and 70% side overlaps. The Structure from Motion (SfM) processing chain generated high-resolution outputs, including point clouds, Digital Elevation Models (DEMs), Digital Surface Models (DSMs), and orthophotos. To ensure accuracy, five ground control points (GCPs) were established by a Real-Time Kinematic Global Navigation Satellite System (RTK GNSS). An ERT method known as vertical electric sounding (VES) revealed subsurface anomalies like solid rock mass, fractured zones and areas of iron leaching within marble deposits. Three Schlumberger (VES-1, 2, 3) and two parallel Wenner (VES-4, 5) arrays to a depth of 60 m were employed. The resistivity signature acquired by PASI RM1 was analyzed using 1D inversion technique software (ZondP1D). The integrated outputs of photogrammetry and subsurface imaging were used to design an optimized quarry with bench heights of 30 feet and widths of 50 feet, utilizing open-source 3D software (Blender, BIM, and InfraWorks). This integrated approach provides a comprehensive understanding of deposit surface and subsurface characteristics, facilitating optimized and sustainable quarry design and extraction. This research demonstrates the value of an innovative approach in synergistic integration of UAV photogrammetry and ERT, which are often used separately, for enhanced characterization, decision-making and promoting sustainable practices in dimensional stone deposits. Full article

Models of subsurface structures are important for successful deposit exploration, but are challenged by the need to integrate data from different geophysical methods. In the present study, we evaluated a method of joint inversion in which audio-magneto telluric (AMT) and dual frequency induced polarization (DFIP) data sets are inverted simultaneously to produce a consistent 2D resistivity model to show a clear image of subsurface structures. To achieve the objectives, we conducted AMT and DFIP surveys along the same survey line within the Dongjun lead–zinc deposit in inner Mongolia by measuring 31 AMT survey sites with a station spacing of 40 m on a 1440 m survey track and operated in fifty-three frequencies in the range of 1–10,400 Hz to record the resistivity distribution of subsurface to depths exceeding 800 m. The same survey setup up was applied to the DFIP method using a pole–dipole array configuration and operating frequencies of 4 Hz and 4/13 Hz. The two-dimensional (2D) model obtained from AMT data revealed distinct low-resistivity anomalies in the middle of the 2D inversion model. In contrast, the DFIP inversion model showed a high resistive body in the same region with relatively high percent frequency effect (PFE) indicating high chargeability. In response to the discrepancies observed in the separate 2D inversion models, we implemented a joint inversion for both the AMT and DFIP data sets. The joint inversion resistivity model shows surficial conducting bodies and a high conductive body along the profile with relatively high PFE, indicating high chargeability. The final joint inversion resistivity model clearly images the large silica alteration zone and the Pb-Zn mineralization. This study demonstrates the feasibility of a joint inversion methodology and highlights the value of integrating geophysical methods through joint inversion for enhanced characterization and exploration of lead–zinc ores. Full article

The 3D resistivity imaging surveying is adept at identifying structural details at various subsurface depths, and it can acquire valuable underground information even in complex geological environments. This technique has been widely applied in fields such as geological exploration, hydrogeology, and environmental monitoring. Currently, the 3D electrical resistivity surveys in the field are primarily deployed using regular grid and equidistant electrode layouts. However, when the survey area is influenced by obstacles or when the target being investigated is particularly complex, this may hinder the deployment of the electrode array in accordance with a rectangular grid. In some instances, it may even be impossible to position the electrodes directly above the target of investigation. The only viable option is thus to place electrodes around obstacles or special targets. In view of this, this paper studied unconventional electrode arrays and inversion imaging techniques of 3D electrical resistivity surveying in confined areas. It presents the design of three electrode arrays: “□”-shaped, “U”-shaped, and “L”-shaped. Furthermore, the study explores 3D resistivity finite element numerical simulation and inversion imaging techniques based on continuous electrical media. Finally, model experiments were conducted to verify the feasibility of these three special electrode arrays. We have applied the “□”-shaped electrode array to investigate the foundation structure of an ancient pagoda in Zhejiang Province, achieving promising results. This study provides valuable reference for the research and application of special observation in 3D electrical resistivity exploration. Full article

The growing expansion of the economy and population has resulted in an increased inclination towards the utilization of groundwater resources. Conducting a geophysical survey is a widely employed method for subsurface mapping and the detection of groundwater. A geophysical study was conducted in Nanshan township, Huarong County, located in the Hunan province of the South-Central region of China. The investigation involved the utilization of a 2D electrical resistivity imaging technique employing forward and inverse pole–dipole electrode arrays. A total of six survey lines were established, each with an electrode distance from the nearest measuring point exceeding 800 m. The maximum current electrode separation was utilized in this setup. The spacing between the electrical resistivity sounding points was established at regular intervals. The findings from the exploration indicate the existence of multiple faults within the surveyed region. The study additionally identified two regions of structural failure, which occurred due to the convergence of faults oriented in different directions. This convergence led to the fracturing of rocks, an increase in water content, and a decrease in resistivity. The findings from the exploration were utilized in the formulation of five verification target boreholes. The results of this study offer significant insights that can inform future investigations into groundwater exploration endeavors within the region. Full article

The newly constructed Bois d’Arc Lake Reservoir in Fannin County, Texas, USA, inevitably flooded a large ground surface area (67.34 km²) when the reservoir began impounding water in April 2021. Inside this (now) flooded area, land-based archaeological data recovery investigations discovered and documented several archaeological sites, now registered in the state of Texas; though, only two neighboring sites, namely, 41FN178 and 41FN244, are examined here. The first phase of archaeological testing at these sites included shovel testing, test unit excavations, and geoarchaeological trenching that yielded archaeological artifacts suggesting that Middle Caddo Indian peoples (AD 1200–1400) might have occupied this landscape. As the sites were recognized before the reservoir’s impoundment phase, this merited a non-invasive, non-destructive, high-resolution near-surface geophysical study to map strategic areas within sites 41FN178 and 41FN244 that might yield potential shallow targets of archaeological context. The adopted geophysical survey comprised 3D direct current electrical resistivity imaging (ERI) and land horizontal magnetic gradiometry (HMG), each mapping a total surface area of 2133 and 15,640 m², respectively. The combination of 3D ERI and land HMG surveys was instrumental in rapidly mapping the horizontal and vertical extent of shallowly buried anomalies within a large area prior to the completion of the dam and the beginning of water impoundment. Based on the geophysical insights, the outline of several Caddo houses with functional internal and external features (e.g., burnt cooking surfaces, storage pits, refuse pits, fired soil, ditches, a dump site, and a compound fence) are thought to exist within the uppermost 2 m of the Quaternary stratigraphy at both sites. At site 41FN244, 3D ERI found numerous resistive anomalies surrounding a conductive anomaly, collectively interpreted as a group of post-holes surrounding the remains of a Caddo house’s inner clay floor. It also found a cluster of several resistive anomalies interpreted as midden or middens. The HMG survey carried across areas from which archaeological test units also yielded positive findings, at sites 41FN178 and 41FN244, identified numerous scattered monopolar and dipolar anomalies interpreted as post-molds of Caddo houses, compound enclosures or fences, and adjacent middens. Archaeological excavations guided by the geophysical results yielded significant cultural material and post-mold features at site 244, which validate the geophysical interpretation in a preliminary context. Additionally, several dispersed magnetic anomalies are thought to be shallowly buried hearths, burn cooking surfaces, storage pits, and ditches. The mapped magnetic anomalies agree with the location and distribution of previously found archaeological artifacts and the extent of resistive and conductive resistivity anomalies. Follow-up archaeological excavations of these geophysical anomalies have preliminarily confirmed interpretations. Full article

Identifying the movement of the branches of the hidden Thakhek fault in Thailand is challenging due to the absence of evident landforms indicating an active fault. In this study, we analyzed a digital elevation model (DEM) to identify potential landforms. A 2D Electrical Resistivity Tomography (ERT) survey was conducted to locate the hidden Thakhek fault. The results reveal vivid images of resistivity contrast, interpreted as two reverse faults, with mudstone exhibiting low resistivity in the middle, flanked by thick sediment layers with higher resistivity. Three trenches were excavated perpendicular to the two interpreted reverse faults. The displacement of reverse faulting appears to have shifted mudstone over Quaternary sediments, with vertical offsets revealed in trenches NWY-1, NWY-2, and NWY-3. This movement could be identified as a positive flower structure. Additionally, lakes are identified as a negative flower structure along the traces. These features result from strike-slip strains under a locally appropriate compressional and extensional environment in a shearing strike-slip fault. Full article

Mining activities often leave behind a legacy of environmental challenges, with aging tailings ponds representing a significant concern due to their potential for leachate formation and subsequent contaminant release. Thus, this study employs Electrical Resistivity Tomography (ERT) to investigate the intricate pathways of leachate within an aging mining tailings pond, addressing the pressing environmental and human health concerns associated with potential contaminant release. Ten 2D ERT profiles were acquired at the El Mochito mine waste site, covering an area of approximately half a square kilometer. These profiles, ranging in length from 104 to 363 m, provided insights into subsurface conditions down to a maximum depth of 60 m. The subsurface mapping of the ERT data showed three different geoelectric layers. The uppermost layer, with a thickness of approximately 2.5 m and resistivity values ranging from 60 to 100 Ohm.m, was identified as a dry tailing/soil zone. Beneath it, the second layer exhibited moderately resistive values (30–60 Ohm.m) with varying thicknesses of 10–20 m, signifying a percolation/leaching zone (semi-saturated zone). The third layer, characterized by substantially low resistivity (1–30 Ohm.m), indicated saturation and the presence of conductive materials, strongly suggesting active leaching. Based on these findings, this study recommends further investigation through geochemical analysis of subsurface samples and more advanced geophysical imaging techniques to validate the distribution of anomalous zones and delineate remediation pathways. This study lays the foundation for future comprehensive research that will integrate geophysical surveys with geochemical analysis and establish 4D modeling techniques to monitor pollutant penetration over time, with a particular focus on mine waste tailings mapping. Plus, this study contributes valuable insights into the characterization of leachate pathways within mining tailings ponds, offering a foundation for informed environmental management and remediation strategies. Full article

In open pit mining areas, knowledge of geotechnical conditions (e.g., overburden thickness, background slope, and fault locations) ensures geotechnical safety during exploitation as well as reclamation planning. The Greek Public Power Corporation initiated a research program after stability issues emerged on the southern side of the Mavropigi open pit mine in NW Macedonia. Geotechnical wells revealed steeply dipping bedrock and thin tectonic contact, indicating the need for the detailed imaging of the subsurface for future stability measures. For this purpose, a geophysical investigation aimed to extract information mostly for the dip of the interface between schist bedrock and overlaying Neogene sediments and/or limestones. Based on the high contrast of electrical properties between schists and limestones, as well as the differences in acoustic impedance and formation thickness, the seismic reflection and electrical resistivity tomography (ERT) methods were selected. The suitability of the seismic reflection for its application in this area was checked by generating synthetic seismic data, which resulted from the simulation of seismic wave propagation for geological models of the area. The acquisition parameters were determined after the noise test. Field seismic data processing produced a depth-migrated section, which revealed the existence of a fault. The use of dipole–dipole and gradient arrays, in 2D and 3D electrical resistivity measurements, ensured both the lateral and vertical mapping of schist bedrock and detected limestone bodies within the overburden. Also, the tectonic contact zone between limestone and schist formations was properly imaged. The comparison between geoelectrical and seismic sections indicated that the seismic reflection method provided a more accurate estimate of fault inclination. Finally, the geophysical survey enriched the geotechnical models necessary for sustainable mining (e.g., rational exploitation, the optimization of productivity, and zero accidents) including the planning of future reclamation. Full article

The accurate characterization and mapping of low-grade ore deposits necessitate the utilization of a robust exploration technique. Induced polarization (IP) tomography is a powerful geophysical method for mineral exploration. An integrated survey using electrical resistivity tomography (ERT) and IP was employed in this study to characterize and map (Zn-Pb-Ag) ore deposits in NE New Brunswick, Canada. The survey encompassed twelve parallel lines across the study area. The 2D and 3D inversion of the results provided a detailed image of the resistivity and chargeability ranges of subsurface formations. The boundaries of sulfide mineralization were determined based on resistivity values of (700–2000 Ohm.m) and chargeability values of (3.5 mV/V) and were found to be located at an approximate depth of 80–150 m from the surface. The findings were validated through a comparison with data from borehole logs and mineralogy data analysis. The size and shape of sulfide deposits were successfully characterized and mapped in the study area using this cost-effective mapping approach. Full article

To better understand the geothermal system of the Gonghe Basin, we deployed 471 magnetotelluric survey points with an average distance of 2~3 km, covering the eastern and southern areas of the Basin. We used ModEM inversion software to carry out 3D inversion of 431 survey points and established a 3D-electrical model at a depth of 50 km in the area. The resistivity model shows that the low resistivity in the shallow part of the basin is related to the Cenozoic loose sedimentary cover, while the resistivity values of the mountains around the basin and the magmatic rock uplift zone are higher. The electrical model also shows that the high-conductivity layer is widely distributed in the middle and lower crust (15~35 km) of the basin, and direction of the high-conductivity layer is consistent with that of NW–SE fault in the basin. These high-conductivity layers may be the principal reason for the high heat flow values in the Gonghe Basin. Our resistivity model also shows that there is an obvious discontinuity between high- and low-resistivity blocks at different depths in the middle and upper crust. These discontinuities are consistent with the faults observed on the surface, which are related to the strong topographic relief. Our electrical model shows that these faults in the middle and upper crust are connected with the high-conductivity layer as the channel of heat transfer to the shallow part. Finally, the heat energy is enriched in the Triassic granite to form dry hot rock (HDR). The 3D-magnetotelluric imaging results depict the 3D-distribution characteristics of the geothermal system in the eastern and southern parts of the Gonghe Basin. Full article

Continuous monitoring of the varying topographical characteristics of shorelines is important for effective coastal management. Closed-circuit television (CCTV) cameras are installed to accumulate photographic data on coastal topographical changes. The overall change in the coastal waters can be intuitively understood from the images. However, the amount of three-dimensional (3D) changes that can be grasped is limited. To address this, studies have employed aerial photogrammetry, which is the use of unmanned aerial vehicles (UAVs) to capture aerial pictures, construct 3D models of target areas, and perform analysis through scale-invariant feature transform and structure from motion technologies. Although highly efficient, this technique requires several ground-control points (GCPs), which could corrupt the overall imagery. This study designs real-time kinematics—global navigation satellite system (RTK–GNSS) UAV, which requires few GCPs. To evaluate the positional accuracy of the captured UAV orthographic images and digital surface models (DSMs) used for precise coastal terrain measurements, a virtual reference service survey was performed to determine the vertical errors. The R-squared was 0.985, which is close to 1.0. Short-term and one-year topographic changes before and after a storm were investigated using time-series UAV image data after a coastal maintenance project. Analysis of the coefficient of variation in the beach volume for one year revealed that submerged breakwater reduced erosion during high wave resistance. The submerged breakwater located in the center exhibited variability similar to the opening. Hence, this method is more suitable for periodically monitoring coastal areas. Full article

The northern scenic area of Changbai Mountain is a high-incidence area of debris flow disasters, which seriously threaten the safety of tourist’s lives and property. Monitoring debris flow and providing early warning is critical for timely avoidance. Monitoring the change of debris flow source is an effective way to predict debris flow, and the change of source can be reflected in the settlement deformation of the study area. The offset tracking technique (OT) is insensitive to the coherence of SAR images and can resist the decoherence of D-InSAR and SBSA-InSAR to a certain extent. It is a technical means for monitoring large gradient deformation. It has been widely used in the field of seismic activity, glaciers and landslides in recent years, but few scholars have applied this technique in the field of debris flow. In this paper, we use OT techniques in combination with field surveys, Google imagery and Sentinel-1 data to monitor surface deformation in the northern scenic area of Changbai Mountain in 2017 and use D-InSAR techniques to compare and complement the OT monitoring results. The results of this study show that for monitoring surface deformation in the study area after a mudslide, it is better to use both methods to determine the surface deformation in the study area rather than one, and that both methods have their own advantages and disadvantages and yet can complement each other. Finally, we have predicted the development trend of mudflows in the study area by combining the calculated single mudflow solids washout, which will help to improve the long-term monitoring and warning capability of mudflows in the study area. The study also enriches the application of offset-tracking technology and D-InSAR in the field of geohazard monitoring and provides new ideas and methods for the study of mudflow material source changes. Full article

The surface-to-borehole transient electromagnetic (SBTEM) method can provide images at higher resolution for deep earth because its receivers are close to targets. However, as usually the boreholes distribute sparsely, the limited EM data can result in an “equivalent trap” in SBTEM inversions, i.e., the data are well-fitted, but the model is not properly recovered. To overcome this non-unique problem, we propose a dual-mesh three-dimensional (3D) SBTEM inversion scheme. We first use a coarse mesh to obtain a rough resistivity distribution near the borehole, and then we map the coarse mesh attribute into a fine one and capture details from the fine mesh inversion. We test our method on both synthetic data and survey data acquired in Daye, Hubei Province, China. Numerical experiments show that our dual-mesh inversion strategy can better recover the location and resistivity of targets. Full article
