This paper proposes a miniaturized frequency-scanning antenna with high scanning rate. To overcome the OSB (open stopband) of traditional leaky wave antenna, CRLH-TL (Composite Right/Left-Handed-Transmission Line) is adopted. Furthermore, an antenna unit consisting of two symmetrically curved microstrip lines with two short branches is employed, whose second mode exhibits excellent transmission characteristics. The measurements demonstrate that the antenna can achieve scanning from −67.5° to 35.5° in the frequency band range of 5.65–6.5 GHz, with a scanning rate of 7.3. During scanning, the highest gain in the band is 12.3 dBi, the lowest is 10 dBi, and the gain fluctuation is within 2.3 dB, showing good scanning characteristics. Additionally, the length of the proposed antenna is approximately 3.84λ₀ for a central frequency of 5.95 GHz. Full article

In radio frequency identification (RFID), differences in spectrum policies and tag misreading in different countries are the two main issues that limit its application. To solve these problems, this article proposes a composite right/left-handed transmission line (CRLH-TL)-based reconfigurable antenna for ultra-high frequency near-field and far-field RFID reader applications. The CRLH-TL is achieved using a periodically capacitive gap-loaded parallel plate line. By deploying the CRLH-TL operating at zeroth-order resonance, a loop antenna with in-phase radiating current is obtained, which contributes to a strong and uniform H-field and a horizontally polarized omnidirectional radiation pattern. By introducing additional tunable components, frequency and reading range reconfigurabilities are enabled. The frequency tuning range is from 833 MHz to 979 MHz, which covers the worldwide UHF RFID band. Moreover, each operation mode has a narrow frequency band, which means it can operate without violating different countries’ radio frequency policy and reduce the design difficulty of designing multiple versions of a reader. Both the near-field interrogation zone and maximum far-field reading distance of the antenna are adjustable. The near-field interrogation zone is 400 mm × 400 mm × 50 mm and can be further confined. The tuning range for far-field reading distance is from 2.71 m to 0.35 m. Full article

A metamaterial-inspired varactor-tuned antenna with frequency reconfigurability and pattern diversity is designed. Two different versions of a reconfigurable structure are integrated into a single antenna to excite two different orthogonal patterns, which realizes pattern diversity for MIMO applications. The outer annular Composite Right-/Left-Handed Transmission Line (CRLH-TL) works at the 1 mode and provides a broadside pattern, and the inner circular radiator loaded with split ring resonators (SRR) operates at the 0 mode and radiates an omnidirectional pattern, which realizes pattern diversity. By using surface-mounted varactors, the operating frequencies for the two radiation patterns can be tuned over a wide frequency range, from 1.7 GHz to 2.2 GHz, covering the 1.71–2.17 GHz LTE band, and a low mutual coupling between the two radiators is achieved. The antenna has also been prototyped. The measured results are in good agreement with the simulation results, verifying the proposed concept. The dual-mode MIMO system equipped with the proposed antenna elements is discussed within the context of a 3-D channel model, and it shows a superior array compactness and spectral efficiency (SE) performance compared to scenarios with single-mode elements. Full article

This article presents a wide-angle-scanning leaky-wave antenna (LWA) based on a composite right/left-handed (CRLH) transmission line. In contrast to traditional semiconductor elements, thin-film ferroelectric capacitors were implemented in the CRLH unit cells to enable electric beam scanning. The proposed CRLH LWA has a single-layer design without metalized vias and is compatible with PCB and thin-film technologies. To fabricate the CRLH LWA prototype, dielectric material substrates and thin-film ferroelectric capacitors were manufactured, and their characteristics were investigated. Double-sided metalized fluoroplast-4 reinforced with fiberglass with a permittivity of 2.5 was used as a substrate for CRLH LWA prototyping. A solid solution of barium strontium titanate (Ba${}_x$Sr${}_{1-x}$TiO${}_3$) with a composition of $x=0.3$ was used as a ferroelectric material in electrically tunable capacitors. The characteristics of the manufactured ferroelectric thin-film capacitors were measured at a frequency of 1 GHz using the resonance method. The capacitors have a tunability of about two and a quality factor of about 50. The antenna prototype consists of ten units with a total length of 1.25 wavelengths at the operating frequency of close to 2.4 GHz. The experimental results demonstrate that the main beam can be shifted within the range of −40 to 16 degrees and has a gain of up to 3.2 dB. The simple design, low cost, and excellent wide-angle scanning make the proposed CRLH LWA viable in wireless communication systems. Full article

A small zero-order resonant antenna based on the composite right-left-handed (CRLH) principle is designed and fabricated without metallic vias at 30 GHz to have patch-like radiation. The mirror images of two CRLH structures are connected to design the antenna without via holes. The equivalent circuit, parameter extraction, and dispersion diagram are studied to analyze the characteristics of the CRLH antenna. The antenna was fabricated and experimentally verified. The measured realized gain of the antenna is 5.35 dBi at 30 GHz. The designed antenna is free of spurious resonance over a band width of 10 GHz. A passive beamforming array is designed using the proposed CRLH antenna and the Butler matrix. A substrate integrated waveguide is used to implement the Butler matrix. The CRLH antennas are connected to four outputs of a $4\times 4$ Butler matrix. The scanning angles are ${12}^{\circ }$, ${-68}^{\circ }$, ${64}^{\circ }$, and ${-11}^{\circ }$ for excitations from port 1 to port 4 of the $4\times 4$ Butler matrix feeding the CRLH antenna. Full article

In this study, a dual-tuned mode of liquid crystal (LC) material was proposed and adopted on reconfigurable metamaterial antennas to expand the fixed-frequency beam-steering range. The novel dual-tuned mode of the LC is composed of double LC layers combined with composite right/left-handed (CRLH) transmission line theory. Through a multi-separated metal layer, the double LC layers can be loaded with controllable bias voltage independently. Therefore, the LC material exhibits four extreme states, among which the permittivity of LC can be varied linearly. On the strength of the dual-tuned mode of LC, a CRLH unit cell is elaborately designed on three-layer substrates with balanced dispersion values under arbitrary LC state. Then five CRLH unit cells are cascaded to form an electronically controlled beam-steering CRLH metamaterial antenna on a downlink Ku satellite communication band with dual-tuned characteristics. The simulated results demonstrate that the metamaterial antenna features’ continuous electronic beam-steering capacity from broadside to −35° at 14.4 GHz. Furthermore, the beam-steering properties are implemented in a broad frequency band from 13.8 GHz to 17 GHz, with good impedance matching. The proposed dual-tuned mode can make the regulation of LC material more flexible and enlarge the beam-steering range simultaneously. Full article

A linear phased array antenna excited with a novel composite right/left-handed (CRLH) phase shifters structure is proposed. The phase of the conventional CRLH transmission line is controlled with magnetically aligned micron-sized particles embedded inside the unit cell of the CRLH transmission line. The cascading of unit cells produces the desired phase shifts for the main beam scanning of the linear antenna array operating at a 5.5 GHz center frequency for Wi-Fi 6 applications. The proposed phase shifter design has a very low insertion loss (0.5–2 dB), excellent matching characteristics with the antenna array (less than −10 dB) and a small phase error (1–2 degrees). A 1 × 4 linear patch antenna phased array operating at a 5.5 GHz center frequency of the Wi-Fi 6 band is simulated using the Method of Moments (MoM) simulator platform. Then, the array is driven with the proposed novel CRLH phase shifters for the main beam at broadside and the main beam steered at 15- and 30-degree scan angles toward the desired users. For experimental validation, multiple unit cells of the proposed phase shifters are fabricated, and the 1 × 4 patch antenna array is fed with these fabricated unit cells of the phase shifters. The phased array radiation patterns are measured using an in-house fully calibrated anechoic chamber and were compared with simulated phased array patterns. The measured phased array patterns are in good agreement with the simulated patterns. As compared with commercially available phase shifters, the proposed novel CRLH phase shifters do not need external complex biasing circuitry, which is a major advantage in space constraint limitations at the router side of multi-user MIMO-OFDM systems. Full article

A conformal cylindrical phased array antenna excited with composite right/left-handed (CRLH) phase shifters is proposed. The phase tuning of the CRLH phase shifter is achieved by embedding novel magneto-static field-responsive micron-sized particles in its structure. It is shown that through the tiny magnet activation of these novel magneto-static particles at appropriate locations along the length of CRLH stub and inter-digital fingers, variable phase shifts are obtained. The proposed particle-based CRLH phase shifter operates in C-band (5–6) GHz with a low insertion loss and phase error. The 1 × 4 cylindrical phased array is excited with the four unit cells of the proposed particle-embedded CRLH transmission line phase shifters to scan the main beam at desired scan angles. A prototype of a 1 × 4 cylindrical phased array excited with the particle-based CRLH phase shifters was fabricated, and the results show that the simulated results are in close agreement with the measured results. The conformal cylindrical array with the proposed particle-based CRLH phase shifters has great potential for use in printed and flexible electronics design where commercially available phase shifters have a definite drawback. Full article

A novel design of a reconfigurable MIMO antenna array of a 3D geometry-based solar cell integration that is operating at sub-6 GHz for self-power applications in a 5G modern wireless communication network. The proposed antenna array provides three main frequency bands around 3.6 GHz, 3.9 GHz, and 4.9 GHz, with excellent matching impedance of S₁₁ ≤ −10 dB. The proposed MIMO array is constructed from four antenna elements arranged on a cubical structure to provide a low mutual coupling, below −20 dB, over all frequency bands of interest. Each antenna element is excited with a coplanar waveguide (CPW). The proposed radiation patterns are controlled with two optical switches of Light Dependent Resistors (LDRs). The proposed antenna array is fabricated and tested experimentally in terms of S-parameters, gain and radiation patterns. The maximum gain is found to be 3.6 dBi, 6.9 dBi, and 3.5 dBi at 3.6 GHz, 3.9 GHz, and 4.9 GHz, respectively. It is realized that the proposed array realizes a significant beam forming by splitting the antenna beam and changing the main lobe direction at 3.9 GHz after changing LDR switching statuses. Such an antenna array is found to be very applicable for femtocell wireless communication networks in the 5G systems. Full article

In this paper, a miniaturized very-high frequency (VHF) band antenna using both top and bottom meander lines is proposed. To design a compact size antenna in the VHF band, a Composite Right/Left-Handed (CRLH) transmission line is applied to antenna structure; additionally, both top and bottom meander lines were used to achieve a greater inductance. The CRLH transmission line unit cell operates at 88 MHz, and the fabricated antenna is designed by arranging 7-unit cells. The overall size of the proposed antenna is 0.087λ × 0.02λ × 0.0003λ at the lowest operating frequency, and the antenna operates at 84 MHz. The VSWR 3.5:1 reference operating bandwidth of the antenna is 2%. The received power of the proposed CRLH antenna was measured to verify the antenna performance. Full article

This research article describes a technique for realizing wideband dual notched functionality in an ultra-wideband (UWB) antenna array based on metamaterial and electromagnetic bandgap (EBG) techniques. For comparison purposes, a reference antenna array was initially designed comprising hexagonal patches that are interconnected to each other. The array was fabricated on standard FR-4 substrate with thickness of 0.8 mm. The reference antenna exhibited an average gain of 1.5 dBi across 5.25–10.1 GHz. To improve the array’s impedance bandwidth for application in UWB systems metamaterial (MTM) characteristics were applied it. This involved embedding hexagonal slots in patch and shorting the patch to the ground-plane with metallic via. This essentially transformed the antenna to a composite right/left-handed structure that behaved like series left-handed capacitance and shunt left-handed inductance. The proposed MTM antenna array now operated over a much wider frequency range (2–12 GHz) with average gain of 5 dBi. Notched band functionality was incorporated in the proposed array to eliminate unwanted interference signals from other wireless communications systems that coexist inside the UWB spectrum. This was achieved by introducing electromagnetic bandgap in the array by etching circular slots on the ground-plane that are aligned underneath each patch and interconnecting microstrip-line in the array. The proposed techniques had no effect on the dimensions of the antenna array (20 mm × 20 mm × 0.87 mm). The results presented confirm dual-band rejection at the wireless local area network (WLAN) band (5.15–5.825 GHz) and X-band satellite downlink communication band (7.10–7.76 GHz). Compared to other dual notched band designs previously published the footprint of the proposed technique is smaller and its rejection notches completely cover the bandwidth of interfering signals. Full article

Wireless Body Area Network (WBAN) has attracted more and more attention in many sectors of society. As a critical component in these systems, wearable antennas suffer from several serious challenges, e.g., electromagnetic coupling between the human body and the antennas, different physical deformations, and widely varying operating environments, and thus, advanced design methods and techniques are urgently needed to alleviate these limitations. Recent developments have focused on the application of metamaterials in wearable antennas, which is a prospective area and has unique advantages. This article will review the key progress in metamaterial-based antennas for WBAN applications, including wearable antennas involved with composite right/left-handed transmission lines (CRLH TLs), wearable antennas based on metasurfaces, and reconfigurable wearable antennas based on tunable metamaterials. These structures have resulted in improved performance of wearable antennas with minimal effects on the human body, which consequently will result in more reliable wearable communication. In addition, various design methodologies of meta-wearable antennas are summarized, and the applications of wearable antennas by these methods are discussed. Full article

In this paper, we propose an electrically small antenna consisting of a composite right/left-handed (CRLH) transmission line (TL) and a non-Foster matching circuit. An interdigital capacitor (IDC) and spiral inductor are used to fabricate the very high frequency (VHF) band antenna based on CRLH TL. The size of the proposed antenna is as small as 0.025 × 0.014 × 0.0008 λ at 145.5 MHz using the zeroth-order resonant generated by the CRLH TL. The antenna operation bandwidth is extended by the non-Foster circuit (NFC) consisting of a pair of transistors in a cross-coupled manner. An antenna prototype is fabricated and the input impedance, the received power, and gain of the proposed antenna are measured. The results show that the broadband characteristic is maintained while the form factor is extremely small compared to the wavelength. The average received power enhancement and increased bandwidth of antenna are 17.3 dB and 335.5 MHz (from 249.2–268.2 to 145.5–500 MHz), respectively. The calculated gain of the proposed antenna with the non-Foster is about −45 dBi at 155 MHz. The proposed antenna can be considered as a potential candidate of a low-profile antenna for military ground communications at the VHF band. Full article

In this paper, a new design method is proposed for a planar and compact dual-band dipole antenna. The dipole antenna has arms as a hybrid CRLH (Composite right- and left-handed) transmission-line comprising distributed and lumped elements for the dual-band function. The two arms are fed by the outputs of a compact and printed CRLH dual-band balun which consists of a CRLH hybrid coupler and an additional CRLH phase-shifter. Its operational frequencies are 2.4 and 5.2 GHz as popular mobile applications. Verifying the method, the circuit approach, EM (Electromagnetics) simulation and measurement are conducted and their results turn out to agree well with each other. Additionally, the CRLH property is shown with the dispersion diagram and the effective size-reduction is mentioned. Full article

This paper presents a frequency-independent, wide-angle scanning leaky-wave antenna (LWA), based on the composite right/left-handed transmission line (CRLH TL). The proposed LWA consists of a coplanar waveguide-grounded (CPWG) structure loaded by varactors. Loaded varactors are used to control the phase constant of the fundamental mode of the LWA by adjusting the applied DC voltage. The LWA has an excellent wide-angle scanning capability, a simple structure, and low cost. Results show that the main beam of an LWA with 20unit cells can scan from −66° to 62° at the operation frequency of3.0 GHz, with a peak gain of 9.9 dBi, and a gain fluctuation of less than 4.9 dB. The operation bandwidth and radiation efficiency are about 13% and over 50%, respectively. A 10-unit cascaded LWA prototype was designed, fabricated, and measured to verify the design concept. Full article
