In light of the global energy shortage, the development of renewable energy has become increasingly vital. With China’s commitment to achieving “carbon peak and carbon neutrality,” photovoltaic power generation has emerged as a focal point in new energy development. However, DC arc faults in photovoltaic systems pose significant safety hazards, potentially leading to electrical fires. While new detection technologies for DC arc faults in photovoltaic power generation systems have advanced rapidly, the diversity of international standards—such as UL 1699 B, GB/T 39750, IEC 63027, and CGC/GF 175—limits both the construction of experimental platforms and the universality of detection technologies. Current research often relies on a single standard to establish experimental platforms, resulting in detection methods with limited applicability and an inability to validate technological effectiveness fully. To address this issue, this paper conducts an in-depth study of four international and national standards (IEC 63027; UL 1699 B, GB/T 39750, and CGC/GF 175), focusing on the discrepancies in decoupling methods, impedance parameter settings, and experimental circuit topologies, including series and parallel arc scenarios. Through comprehensive comparative analysis of multiple standards, this study integrates major international and domestic specifications to develop a multi-standard compatible experimental platform. The platform is designed to accommodate diverse topologies and parameter requirements, enabling efficient collection of arc test data and performance evaluation of arc fault detection devices. It also provides a standardized foundation for the performance testing and classification of DC arc circuit breakers in photovoltaic power generation systems. Through a comprehensive multi-standard comparative analysis, we systematically analyze the technical differences in photovoltaic DC arc detection. We construct a multi-standard compatible experimental platform by integrating mainstream international and domestic standards. This platform is designed to accommodate various topological structures and parameter requirements, facilitating the collection of arcing experimental data and assessment of the performance of arc fault detection devices. The findings from this research provide both theoretical and experimental foundations for developing unified technical guidelines for photovoltaic DC arc protection. This will aid in standardizing the development of detection devices and enhancing the electrical safety of photovoltaic systems. Ultimately, this work is significant for promoting the safe utilization of new energy within the framework of the dual carbon goals. Moving forward, it is crucial to enhance the generalization abilities of detection algorithms further and foster the integration of standards and industrial applications. Full article

A diode-based rectifier (DR) is an attractive transmission technology for offshore wind farms, which reduces the volume of large bulk platforms. A novel parallel–series DC wind farm based on a distributed DR is proposed, which meets the requirements of high voltage and high power with an isolation capability from other units. The coupling mechanism between a modular multilevel converter (MMC) and a DR has been built, and the coordinate control strategy for the whole system has been proposed based on the MMC triple control targets with intermediate variables. Under the proposed control strategy, the system automatically operates at maximum power point tracking (MPPT). The feasibility of topology and the effectiveness of the control strategy are verified under start-up, power fluctuation, onshore alternating current (AC) fault, and direct current (DC) fault based on the power systems computer-aided design (PSCAD)/electromagnetic transients including direct current (EMTDC) simulation. Full article

This paper analyzes one of the most important power capture challenges of the DC series–parallel collection system, called the power curtailment losses. The wind speed difference between the series-connected turbines causes over- and under-voltage conditions in the output voltage of the MVDC (medium-voltage DC) converters of the wind turbine. The power curtailment losses caused by the upper-voltage tolerance levels of the MVDC converters of the wind turbines are analyzed considering a redundancy-based upper-voltage limiting condition. This analysis emphasizes the importance of choosing suitable voltage tolerance levels for the MVDC converters of wind turbines based on the wind farm configuration. The annual energy curtailment losses are quantified and evaluated by a comparative case study performed on a DC series–parallel-connected wind farm rated at 200 MW with the redundancy-based upper-voltage limiting condition. Full article

Photovoltaic (PV) power plant collection and connection to a high voltage direct current (HVDC) grid has many advantages. Compared with the traditional AC collection and grid-connection scheme, it can reduce the power conversion links and improve the system efficiency. As one of the most important devices in the application of a PV HVDC collection and grid-connection system, a high voltage, large capacity, high step-up ratio DC/DC converter is the critical technology. A DC/DC converter scheme based on a boost full bridge isolated power module cascaded in input parallel output series (IPOS) structure is proposed to meet the technical requirements of PV power conversion with high voltage, large capacity, and high step-up ratio. The operation mode of the power module is analyzed, the soft switching method is proposed, and the constraint to realize the soft switching of the power module is deduced. Aiming to resolve the problem of multi-module voltage and current equalization in a cascaded DC/DC converter, a distributed module equalization control strategy is proposed to realize the reliable operation of a power module and converter. A 5 kV/80 kW standard power module is developed, the DC/DC converter experimental platform is built, and the proposed system scheme and control strategy are verified by experiments. Based on a 14-power module input parallel output series connection, a ±30 kV/1 MW PV DC/DC converter is developed, a ±30 kV PV HVDC collection and grid-connection demonstration system is established, and the experimental test is completed to realize the stable operation of the system. Full article

As the size and distance from shore of new offshore wind power plants (OWPPs) increase, connection to shore using high-voltage (HV) direct-current (DC) technology becomes more cost-effective. Currently, every offshore wind power plant has a collection system based on medium-voltage alternating-current technology. Such systems rely on heavy and bulky low-frequency (i.e., 50 or 60 Hz) transformers: a drawback offshore, where equipment weight and space are restricted. Consequently, there is growing interest in medium-voltage direct-current collection systems, in which low-frequency transformers are replaced with DC/DC converters equipped with lighter and smaller medium-frequency transformers. However, the deployment of all-DC OWPPs still faces several challenges. Based on a very comprehensive and critical literature review, three of them are identified and discussed in this paper. The first challenge is the technological gap at component level. In this work, the DC/DC converter topologies most suitable for application to OWPPs are described and compared. The second challenge is the controllability of DC collection systems. Parallel, series and hybrid DC collection system layouts are presented and discussed. The third challenge is the compliance of all-DC OWPPs with current requirements for their connection to the onshore grids. The three challenges are discussed to highlight current research gaps and potential future directions. Full article

A diode rectifier-modular multilevel converter AC/DC hub (DR-MMC Hub) is proposed to integrate offshore wind power to the onshore DC network and offshore production platforms (e.g., oil/gas and hydrogen production plants) with different DC voltage levels. The DR and MMCs are connected in parallel at the offshore AC collection network to integrate offshore wind power, and in series at the DC terminals of the offshore production platform and the onshore DC network. Compared with conventional parallel-connected DR-MMC HVDC systems, the proposed DR-MMC hub reduces the required MMC converter rating, leading to lower investment cost and power loss. System control of the DR-MMC AC/DC hub is designed based on the operation requirements of the offshore production platform, considering different control modes (power control or DC voltage control). System behaviors and requirements during AC and DC faults are investigated, and hybrid MMCs with half-bridge and full-bridge sub-modules (HBSMs and FBSMs) are used for safe operation during DC faults. Simulation results based on PSCAD/EMTDC validate the operation of the DR-MMC hub. Full article

Series–parallel module technology can meet a DC converter’s requirements of high-power, large-capacity, and high step-up ratio in photovoltaic a DC boost collection system. However, the cascaded structure has the problem of voltage and current sharing between modules, and due to the duty cycle limitation of converters, the combined converters in the PV-converter unit have an unbalanced voltage, which may also exceed the voltage range under partial shading conditions (PSCs). First, aiming at the problems of voltage sharing, current sharing, and low modularity in the combined converter, this paper proposes a distributed control strategy. Then, by adopting a coordinated control strategy based on the sub-module cutting in and out, the problem that the combined converter cannot normally boost under PSCs was solved. The paper not only takes the advantages of the cascade structure of the combined converter to increase the power and voltage, but also improves its modularity to solve the problem of abnormal operation under uneven irradiation. This dramatically improves the adaptability of combined converters in a photovoltaic DC collection system. Finally, a small power experiment was carried out, where the experimental results verified the effectiveness of the control strategy. Full article
