Search Results (41)

In inertial confinement fusion (ICF) laser drivers, large-aperture high-intensity third-harmonic (3ω, central wavelength 351 nm) laser pulses passing through KDP crystals (potassium dihydrogen phosphate) can produce strong transverse stimulated Raman scattering (TSRS). TSRS not only depletes the energy of the 3ω laser beam but also damages the KDP crystal, thus significantly limiting the enhancement of ICF laser driver capabilities. Therefore, effectively suppressing TSRS in KDP crystals is a critical issue in the design and construction of ICF laser driver systems. This paper first proposes that SSD has the ability to suppress TSRS through theoretical analysis of the characteristics of SSD beams. Secondly, through numerical simulations, it presents the influence of variations in three key parameters—modulation amplitude, modulation frequency, and grating dispersion coefficient—on the TSRS gain. The results show that the Stokes gain decreases with increasing modulation amplitude and modulation frequency; specifically, the suppression capability of SSD for TSRS gradually strengthens as modulation bandwidth increases. In addition, previous reports have demonstrated that SSD can significantly suppress stimulated rotational Raman scattering (SRRS) in air, which highlights the potential value of applying SSD in large laser facilities such as ICF driver systems. Full article

The results of precise measurements of the temperature dependencies of quadratic electro-optic coefficients, namely $g_{1111}-g_{1122}$ and $n_{\mathrm{o}}^3{g}_{1111}-n_{\mathrm{e}}^3{g}_{3311}$, in KH₂PO₄ (KDP) and KD₂PO₄ (DKDP) crystals at a wavelength of 632.8 nm are presented. We consider electro-optic coefficients describing changes in the optical impenetrability tensor resulting from an applied electric field, as well as intrinsic electro-optic coefficients defined in terms of induced polarization. The results show significant differences in the values of the analogous coefficients for the KDP and DKDP crystals and their temperature dependencies. Therefore, the quadratic electro-optic effect in KDP-type crystals cannot be easily described based solely on the contribution of PO₄ tetrahedra, as assumed in current models of the linear effect. Moreover, the values of the intrinsic coefficients in the KDP and DKDP crystals differ even more than the corresponding usual electro-optic coefficients, which contradicts the conventional belief in their lower variability. Full article

Potassium dihydrogen phosphate (KDP) crystals, vital for high-power laser systems, pose significant machining challenges due to their brittleness, low hardness, and hygroscopic properties. Achieving crack-free, high-precision surfaces is essential but complex. Single-point diamond fly-cutting (SPDF) is the primary method, yet it exposes tools to high mechanical stress and heat, accelerating wear. In dry cutting, worn tools develop adhesive layers that detach, causing scratches and degrading surface quality. Traditional wet cutting improves surface finish but leaves residual fluids that contaminate the surface with metal ions, leading to optical degradation and fogging. To address these issues, this study explores mixed-fat-based minimum quantity lubrication (MQL) as a sustainable alternative, comparing two lubricants: biodegradable-base mixed ester lubrication (BBMEL) and hydrocarbon-based synthetic lubricant (HCBSL). A comprehensive evaluation method was developed to analyze surface roughness, tool wear, and subsurface damage under dry cutting, MQL-BBMEL, and MQL-HCBSL conditions. Experimental results show that MQL-BBMEL significantly enhances machining performance, reducing average surface roughness by 27.77% (Sa) and 44.77% (Sq) and decreasing tool wear by 25.16% compared to dry cutting, outperforming MQL-HCBSL. This improvement is attributed to BBMEL’s lower viscosity and higher proportion of polar functional groups, which form stable lubricating films, minimizing friction and thermal effects. Structural analyses confirm that MQL-BBMEL prevents KDP crystal deliquescence and surface fogging. These findings establish MQL-BBMEL as an eco-friendly, high-performance solution for machining brittle optical materials, offering significant advancements in precision machining for high-power laser systems. Full article

Intentionally adding select ions such as Al³⁺ could be helpful in controlling the crystal habit of KDP crystal for high yield of optics. The study of how Al³⁺ ions affect crystal quality can provide a basis for selecting an appropriate doping level without negatively affecting the optical properties of crystals. Here, the influence of Al³⁺ ions on the crystal structure and properties of KDP crystals have been investigated by using first-principles calculations. Theoretical calculations show that Al³⁺ ions mainly replace K sites in KDP crystals and could complex with intrinsic V_H⁻ point defects to form Al_K²⁺ + 2V_H⁻ cluster defects. The linear absorption spectra indicate that the presence of Al³⁺ ions has minimal impact on the linear absorption of KDP crystals, aligning well with the experimental findings. And Al³⁺ ions could cause a slight shortening of the band gap of KDP crystals. However, these ions could bring significant deformations of O-H bonds. As the concentration of Al³⁺ ions increase, more O-H bonds linking to PO₄ groups are distorted in KDP crystals. As a result, the structural instability could be fast enhanced with increasing the defect concentration. Therefore, high concentrations of Al³⁺ ions could cause the instability of the crystal structure, which finally affects the laser-induced damage resistance of the KDP crystals. This manuscript contributes to a more comprehensive understanding of the physical mechanisms by which different impurity ions affect the optical properties of KDP crystals. Full article

In this paper, we investigate the theory of energy distribution when divergent light undergoes harmonic conversion in KDP crystals, and based on this theory, we design and construct a precision measuring instrument for the detuning angle of (KDP) Crystals (MIDC). The device can obtain the detuning angle of the crystal by a single measurement with an average measurement error of 72.78 urad. At the same time, it also has the function of scanning the full aperture of the crystals. Using the MIDC, it is possible to quickly measure the KDP crystal at a single point and quickly scan the crystal detuning angle at full aperture. In addition, we conduct a theoretical study on the variation of detuning angle caused by gravity-influencing factors under online conditions, propose an optimization formula for the offline measurement results of detuning angle, and calculate the optimized values of detuning angle for two kinds of crystals under 45° online conditions. We finally study the error source of the MIDC device, analyze the trend of the influence of positioning errors of the crystal and optical elements on the detuning angle measurement results, and provide theoretical support for the error monitoring and correction of MIDC. Full article

The structure of an aqueous solution of potassium dihydrogen phosphate (KH₂PO₄, KDP) was studied by small-angle X-ray scattering (SAXS) and molecular dynamics (MD). According to SAXS data, the octameric species (KH₂PO₄)₈ are formed in solution in addition to K⁺, (H₂PO₄)⁻, and KH₂PO₄, while the presence of other types of oligomers is not observed. When the temperature drops below the saturation temperature (~60 °C), the volume fraction of octamers increases sharply, reaching 50% at 4 °C. The results of MD calculations of the temporal stability relationships of dimers (KH₂PO₄)₂, tetramers (KH₂PO₄)₄, and octamers (KH₂PO₄)₈ show that the dimers and tetramers disintegrate rapidly (50–100 ps), while the octamers remain stable. A comparative analysis of the bonds between the octamers and the KDP crystal lattice was carried out when the octamer was inserted during crystal growth in the directions [001] and [100]. The possible relationship of the obtained results with the changes in the anisotropy of growth rates (habitus) of KDP crystals at different degrees of supersaturation is discussed. Full article

The focus of this study was to examine antisolvent effects, which hold significance in particulate processes, such as crystallization and precipitation. In the first section, an experimental investigation revealed that C₁–C₄ primary alcohols significantly reduced the solubility of potassium dihydrogen phosphate (KDP) in water. The solid–liquid equilibria of KDP solutions were determined using an innovative polythermal method, demonstrating time and labor efficiency compared to the traditional isothermal method while maintaining solubility determination quality. This achievement established an efficient tool for high-throughput solvent screening, a crucial aspect of particulate process development. In addition to the experimental approach, in the second part, the influence of these alcohols on KDP solubility was analyzed using the eNRTL thermodynamics model. The model’s estimated parameters confirmed that the addition of these alcohols induced strong non-ideal behavior in the solutions, altered interactions between solute species and solvent components, and reduced KDP solubility. Under the effects of these alcohols, KDP solubility generally increased with the length of the alkyl chain in the added alcohols, although methanol deviated from this observation. Furthermore, the present work also discussed the limitation of the well-known Bromley’s equation, particularly when applied for KDP in alcohol–water mixed solvents. Consequently, binary and ternary systems consisting of KDP, water, and C₁–C₄ primary alcohols were successfully modeled using eNRTL. Furthermore, it was determined that the obtained model was insufficient for quaternary systems with a higher alcohol content, particularly when high-order interactions were neglected as in the cases of binary and ternary systems. In short, these investigated alcohols have potential for future applications in the design of particulate processes, with a particular emphasis on antisolvent crystallization. Full article

Potassium dihydrogen phosphate (KDP) has garnered considerable attention due to its diverse applications across various scientific and engineering domains. Although promising machining performance enhancements have been achieved in ultra-precision diamond cutting, the brittle–ductile transition (BDT) depth for KDP crystals is essentially at the nanometer range and limits the further improvement of machining efficiency. In this paper, a novel ultra-precision diamond cutting process based on tool trapezoidal modulation is proposed for the first time to investigate the BDT characteristics of KDP crystals. By intentionally designing the tool modulation locus, the uncut chip thickness and cutting direction in the cutting duty cycle are kept constant, which provides a new strategy for probing the BDT mechanism and enhancing the machining performance. The BDT depth is significantly increased compared to the conventional ultra-precision diamond cutting owing to its unique modulation machining advantages. The significance of this paper lies not only in the improvement of the machining efficiency of KDP crystals through the proposed modulation cutting process, but also in the possibility of extending the relevant research methods and conclusions to the machining performance enhancement of other brittle optical crystals. Full article

The quantum statistical properties of the proton subsystem in hydrogen-bonded crystals (HBC) are investigated. Based on the non-stationary Liouville operator equation (taking into account a number of assumptions established in the experiment), a quantum kinetic equation is constructed for the ensemble of non-interacting protons (an ideal proton gas) moving in the crystal potential image perturbed by the external electric field. The balanced density matrix for the unperturbed proton subsystem is constructed using the quantum canonical Gibbs distribution, and the non-balanced density matrix is calculated from the solutions of the nonlinear quantum kinetic equation by methods in linear approximation of perturbation theory for the blocking electrode model. Full quantum mechanical averaging of the polarization operator makes it possible to study the theoretical frequency-temperature spectra of the complex dielectric permittivity (CDP) calculated using quantum relaxation parameters that differ significantly from their semiclassical counterparts. A scheme is presented for an analytical study of the dielectric loss tangent in the region of quantum nonlinear relaxation in HBC. The results obtained in the given paper are of scientific interest in developing the theoretical foundations of proton conduction processes in energy-independent memory elements (with anomalously high residual polarization) based on thin films of ferroelectric materials in the ultralow temperature range (1–10 K). The theoretical results obtained have a direct application to the study of the tunneling mechanisms of spontaneous polarization in ferroelectric HBC with a rectangular hysteresis loop, in particular in crystals of potassium dideutrophosphate (KDP), widely used in nonlinear optics and laser technology. The quantum properties of proton relaxation in HBC can be applied in the future to the study of solid-state electrolytes with high proton conductivity for hydrogen energy, capacitor technology (superionics, varicodes), and elements of MIS and MSM structures in the development of resonant tunnel diodes for microelectronics and computer technology. Full article

Using the quasi-classical kinetic theory of dielectric relaxation, in addition to existing methods, fundamental mathematical expressions are built, which make it possible to more strictly consider the effects of the main charge carriers’ (protons’) tunneling on the numerical values of the molecular parameters (activation energy, equilibrium concentration) of protons in HBC. The formulas for calculating the statistically averaged non-stationary quantum transparency of a parabolic potential barrier for protons have been modernized by more stringent consideration of the effects of corrections caused by an external electric field. For the model of a double-symmetric potential well, a generalized nonlinear solution of the quasi-classical kinetic equation of dielectric relaxation in HBC was built. The phenomenological Bucci-Rive formula for thermally stimulated depolarization current density (TSDC) was first investigated, taking into account quantum transparency, for the case of a parabolic potential barrier. The choice of the parabolic shape of the potential barrier allowed, at a theoretical level, for the mathematical model of relaxation polarization to be brought closer to the conditions of the real spatial structure of the crystal potential field, in comparison with the rectangular potential barrier model. It has been found that quantum effects due to proton tunnel transitions significantly affect the mechanism of thermally stimulated depolarization currents in HBC, over a wide temperature range (50–550 K) and external field parameters (0.1–1 MV/m). Generalized solutions of the nonlinear kinetic equation, recorded considering the effects of field parameters on proton tunnel transitions, made it possible to significantly approximate the theoretical values of activation energies, equilibrium concentrations of protons and amplitudes of the theoretical maxima of the current density of thermally stimulated depolarization, according to their experimental values in the field of low-temperature (50–100 K) and high-temperature (350–550 K) maxima of TSDC density in HBC. For the first time, precision measurements of TSDC temperature spectra were carried out for chalcanthite crystals. The effects of alloying impurities concentrations and crystal calcination temperatures on the parameters of experimental maxima in the TSDC spectrum of chalcanthite were established. A physical mechanism of the quantum tunnel motion of protons in HBC with a complex crystal structure (crystalline hydrates, layered silicates, ferroelectric HBC (KDP, DKDP)) is described. The patterns found in this article indicate a fairly high degree of applied scientific significance for the obtained theoretical results, allowing for the further development of electrophysics and optoelectronics of heterogeneous structures (MIS, MSM) based on proton semiconductors and dielectrics (PSD) and their composites. Full article

The application range of potassium dihydrogen phosphate (KDP) crystals can be expanded by enhancing their surface quality properties. Therefore, a method for controlling the surface-temperature field of various materials was developed to expand the plastic zone to overcome the difficulty in processing KDP crystals. The ductile/brittle transition depth of the KDP crystals was determined using a 38 nm nanoindentation experiment. The nanoscratch experiment revealed the rules of how the transformation depth of the KDP crystals changes with temperatures, and the effect of temperature on the microstructure of the KDP crystals was studied. Finally, KDP crystal surfaces were processed using a UPDFC machine at elevated temperatures. According to our experiments, the surface roughness of the KDP crystal reached 5.275 nm as temperature increased, thus enhancing its surface quality. This method could be applied to other brittle materials. Full article

The micro-defects on KH₂PO₄ (KDP) optic surfaces are mainly repaired by the micro-milling technique, while it is very easy to introduce brittle cracks on repaired surfaces, as KDP is soft and brittle. To estimate machined surface morphologies, the conventional method is surface roughness, but it fails to distinguish ductile-regime machining from brittle-regime machining directly. To achieve this objective, it is of great significance to explore new evaluation methods to further characterize machined surface morphologies. In this study, the fractal dimension (F_D) was introduced to characterize the surface morphologies of soft-brittle KDP crystals machined by micro bell-end milling. The 3D and 2D fractal dimensions of the machined surfaces and their typical cross-sectional contours have been calculated, respectively, based on Box-counting methods, and were further discussed comprehensively by combining the analysis of surface quality and textures. The 3D F_D is identified to have a negative correlation with surface roughness (S_a and S_q), meaning the worse the surface quality the smaller the F_D. The circumferential 2D F_D could quantitively characterize the anisotropy of micro-milled surfaces, which could not be analyzed by surface roughness. Normally, there is obvious symmetry of 2D F_D and anisotropy on the micro ball-end milled surfaces generated by ductile-regime machining. However, once the 2D F_D is distributed asymmetrically and the anisotropy becomes weaker, the assessed surface contours would be occupied by brittle cracks and fractures, and corresponding machining processes will be in a brittle regime. This fractal analysis would facilitate the accurate and efficient evaluation of the repaired KDP optics by micro-milling. Full article

A quaternary metal chalcogenide, namely K₂CdGe₃S₈ (I), is obtained through a high-temperature solid-state approach. Compound I crystallizes with the non-centrosymmetric space group P2₁2₁2₁. It features a 2D layer structure with [CdGe₃S₈] layers consisting of tetrahedral GeS₄ and CdS₄ units, and counter K⁺ embedded between the layers. The compound exhibits a powder second-harmonic generation (SHG) response of ~0.1 times that of KH₂PO₄ (KDP) with phase-matchable character at the laser wavelength of 1064 nm. Remarkably, it has a wide band gap (3.20 eV), which corresponds to a favorable high laser-induced damage threshold of 6.7 times that of AgGaS₂. In addition, the calculated birefringence (Δn) is 0.039 at the wavelength of 1064 nm, which satisfies the Δn criteria for a promising infrared NLO material. Full article

Elementary building blocks for the growth of KDP crystals were established. The solution of potassium dihydrogen phosphate (KH2PO4–KDP) has been experimentally studied by the small-angle X-ray scattering (SAXS) method. The analysis of SAXS data in the temperature range of 2.5–90 °C using a set of models of 3D fragments of the crystal structure showed that the saturated solution contains above K⁺, H₂PO₄⁻ and KH₂PO₄ monomers, as well as mainly octamers. The 3D model of the octamer isolated from the crystal structure has dimensions of 17.443 Å along the [001] axis and 5.963 Å along the [100] and [010] axes. As the temperature is decreased, starting from the saturation temperature of the solution, the volume fraction of octamers sharply increases while the volume fraction of monomers decreases. The results indicate that the monomers and octamers represent major components in the solution with the presence of minor populations of other oligomers. The significant dominance of octamers in the supersaturated solution indicates that they are elementary building blocks for the growth of KDP crystals of tetragonal modification. Full article

Surface defects are usually associated with the formation of other forms of expansion defects in crystals, which have an impact on the crystals’ growth quality and optical properties. Thereby, the structure, stability, and electronic structure of the hydrogen and oxygen vacancy defects (V_H and V_O) on the (100) and (101) growth surfaces of KDP crystals were studied by using density functional theory. The effects of acidic and alkaline environments on the structure and properties of surface defects were also discussed. It has been found that the considered vacancy defects have different properties on the (100) and (101) surfaces, especially those that have been reported in the bulk KDP crystals. The (100) surface has a strong tolerance for surface V_H and V_O defects, while the V_O defect causes a large lattice relaxation on the (101) surface and introduces a deep defect level in the band gap, which damages the optical properties of KDP crystals. In addition, the results show that the acidic environment is conducive to the repair of the V_H defects on the surface and can eliminate the defect states introduced by the surface V_O defects, which is conducive to improving the quality of the crystal surface and reducing the defect density. Our study opens up a new way to understand the structure and properties of surface defects in KDP crystals, which are different from the bulk phase, and also provides a theoretical basis for experimentally regulating the surface defects in KDP crystals through an acidic environment. Full article
