Search Results (9)

Accurate measurement of pipeline flow is of great significance for industrial and environmental monitoring. Traditional intrusive methods have the disadvantages of high cost and damage to pipeline structure, while non-intrusive techniques can circumvent such issues. Although Taylor’s frozen hypothesis has a theoretical advantage in non-intrusive velocity detection, current research focuses on planar flow fields, and its applicability in turbulent circular pipes remains controversial. Moreover, there is no precedent for combining it with distributed acoustic sensing (DAS) technology. This paper constructs a circular pipe turbulence model through large eddy simulation (LES), revealing the spatiotemporal distribution characteristics of turbulent kinetic energy and the energy propagation rules of FK spectra. It proposes a dispersion feature enhancement algorithm based on cross-correlation, which combines a rotatable elliptical template with normalized cross-correlation coefficients to suppress interference from non-target directions. An experimental circulating pipeline DAS measurement system was set up to complete signal denoising and compare two principles of flow velocity verification. The results show that the vortex structure of turbulent flow in circular pipes remains stable in the convection direction, conforming to theoretical premises; the relative error of average flow velocity by this method is ≤3%, with significant improvements in accuracy and stability in high-flow zones. This study provides innovative methods and experimental basis for non-intrusive flow detection using DAS. Full article

Tidal sites can present uneven seabed bathymetry features that induce favourable or adverse pressure gradients and are sources of turbulence, and so are likely to affect the operation, performance, and wake recovery dynamics of deployed tidal-stream turbines. Large-eddy simulations are conducted to analyse the unsteady loading of a tidal turbine subjected to the wake of an upstream turbine that interacts with a two-dimensional ridge located between the two turbines. Relative to an isolated turbine, blade fatigue loading is increased by up to 43% when subject to the wake of a turbine located 8 turbine diameters upstream interacting with a ridge located 2 turbine diameters upstream, whereas for the same spacing, the turbine wake led to a limited 6% reduction in loading and the ridge wake only caused a 79% increase. For larger spacings, the trends were similar, but the magnitude of difference reduced. Predictions of fatigue loads with a blade element momentum model (BEMT) provided a good agreement for flat bed conditions. However, the ridge-induced pressure gradient drives rapid spatial change of coherent flow structures, which limits the applicability of Taylor’s frozen turbulence hypothesis adopted in the BEMT. Reasonable prediction of rotor loading with BEMT was found to be obtained using the turbulent onset flow field at a plane one-diameter upstream of the turbine. This is more accurate than use of the planes at the rotor plane or two-diameters upstream, as coherent structures represent those modified by wake recovery and rotor induction in the approach flow to the turbine. Full article

Large Eddy Simulations (LES) allow the generation of spatio-temporal fields of the refractivity index for various meteorological conditions and provide a unique way to simulate turbulence-distorted phase measurements as those from geodetic sensors. This approach enables a statistical quantification of the von Kármán model’s adequacy in describing the phase spectrum and the assessment of the validity of common assumptions such as isotropy or the Taylor frozen hypothesis. This contribution shows that the outer scale length, defined using the Taylor frozen hypothesis as the saturation frequency of the phase spectrum, can be statistically estimated, along with an error fit factor between the model and its estimation. It is found that this parameter strongly varies with height and meteorological conditions (convective or wind-driven boundary layer). The simulations further highlight the linear dependency with the variance of the turbulent phase fluctuations but no dependency on the local outer scale length as defined by Tatarskii. An application of these results within a geodetic context is proposed, where an understanding and solid estimation of the outer scale length is mandatory in avoiding biased decisions during statistical deformation analysis. The LES presented in this contribution support derivations for an improved stochastic model of terrestrial laser scanners. Full article

Wind loads have become one of the key influencing factors for the running safety of vehicles and comfort of passengers. The investigation of the wind speed spectrum characteristics of a moving vehicle under turbulent crosswinds is of great importance. Expressions of the wind speed spectrum of a moving vehicle were obtained from the von Kármán spectrum, based on Taylor’s frozen flow hypothesis. The influencing factors, including the ratio of the vehicle speed to the wind speed and wind yaw angles, were analyzed. The change rules of the wind speed spectrum peak and its corresponding frequency were also studied. The results show that the wind speed spectrum peak values of the moving vehicle were larger than those of the static vehicle. The wind speed spectrum peak values corresponding to the moving vehicle were first increased and then decreased, as the wind yaw angles increased. Some of the frequencies corresponding to the longitudinal wind speed spectrum values of the moving vehicle were smaller than those of the static vehicle. Therefore, the energy had been transferred to the lower frequency. For the moving vehicle, the frequency values corresponding to the longitudinal wind speed spectrum peak were first increased and then decreased, as the ratio of the vehicle speed to the wind speed and the wind yaw angle increased. Full article

The rescaling of rainfall requires measurements of rainfall rates over many dimensions. This paper develops one approach using 10 m vertical spatial observations of the Doppler spectra of falling rain every 10 s over intervals varying from 15 up to 41 min in two different locations and in two different years using two different micro-rain radars (MRR). The transformation of the temporal domain into spatial observations uses the Taylor “frozen” turbulence hypothesis to estimate an average advection speed over an entire observation interval. Thus, when no other advection estimates are possible, this paper offers a new approach for estimating the appropriate frozen turbulence advection speed by minimizing power spectral differences between the ensemble of purely spatial radial power spectra observed at all times in the vertical and those using the ensemble of temporal spectra at all heights to yield statistically reliable scaling relations. Thus, it is likely that MRR and other vertically pointing Doppler radars may often help to obviate the need for expensive and immobile large networks of instruments in order to determine such scaling relations but not the need of those radars for surveillance. Full article

The paper introduces an algorithm to generate a three-variate four-dimensional wind turbulence field suited for yawed wind dynamic load simulation. At large yaw angles, a relaxation of Taylor’s hypothesis of frozen turbulence becomes relevant as well as the flow phase lag in the along-wind direction, which modulates the real and imaginary parts of the coherence. To capture such a general wind action on a structure, a modified spectral representation method is used where the coherence of turbulence is described as a complex-valued function. The one-point and two-point co-spectra are implemented in the simulation setup using a square-root-free Cholesky decomposition of the spectral matrix. The numerical procedure is illustrated based on turbulence characteristics derived from data collected during storm Aina (2017) on the Norwegian coast by three-dimensional sonic anemometers. During this event, a remarkable 3-hour stationary time series with a mean wind speed of 24 m s${}^{-1}$ at a height of 49 m above ground was recorded. Since no computational grid is needed, the velocity fluctuations with representative spatio-temporal characteristics can be directly simulated on structural elements of slender structures. Such an algorithm may be essential for the design of super-long span bridges in coastal areas. Full article

Wind profile observations are used to estimate turbulent mixing in the atmospheric boundary layer from 1 m up to 300 m height in two locations of pine forests characteristic of the southeast US region, and to 30 m height at one location in the northeast. Basic turbulence characteristics of the boundary layers above and within the canopy were measured near prescribed fires for time periods spanning the burns. Together with theoretical models for the mean horizontal velocity and empirical relations between mean flow and variance, we derive the lateral diffusivity using Taylor’s frozen turbulence hypothesis in the thin surface-fuel layer. This parameter is used in a simple 1D model to predict the spread of surface fires in different wind conditions. Initial assessments of sensitivity of the fire spread rates to the lateral diffusivity are made. The lateral diffusivity with and without fire-induced wind is estimated and associated fire spread rates are explored. Our results support the conceptual framework that eddy dynamics in the fuel layer is set by larger eddies developed in the canopy layer aloft. The presence of fire modifies the wind, hence spread rate, depending on the fire intensity. Full article

Many studies based on single-point measurement data have demonstrated the impressive ability of wavelet coherency analysis to catch the coherent structures in the wall-bounded flows; however, the question of how the events found by the wavelet coherency analysis relate to the features of the coherent structures remains open. Time series of velocity fields in x–y plane of the steady open channel flow was obtained from a time-resolved particle imaging velocimetry system. The local wavelet spectrum found shows that one of the main energetic scales in open channel flows is 3h motions. The wavelet coherent coefficients of u and v series from the same measurement points successfully detected the occurrence and the scale of these 3h motions, and the phase angle indicates their inside velocity structure is organized by the Q2 and Q4 events. The wavelet coherency analysis between different measurement points further reveals the incline feature of the 3h scale motions. All the features of this 3h motion found by the wavelet coherency analysis coincide well with the flow field that is created by the passing of hairpin packets. Full article

Wind gusts on a scale from 100 m to 1000 m are studied due to their significant influence on wind turbine performance. A detecting and tracking algorithm is proposed to extract gusts from a wind field and track their movement. The algorithm utilizes the “peak over threshold method,” Moore-Neighbor tracing algorithm, and Taylor’s frozen turbulence hypothesis. The algorithm was implemented for a three-hour, two-dimensional wind field retrieved from the measurements of a coherent Doppler lidar. The Gaussian shape distribution of the gust spanwise deviation from the streamline was demonstrated. Size dependency of gust deviations is discussed, and an empirical power function is derived. A prediction model estimating the impact of gusts with respect to arrival time and the probability of arrival locations is introduced, in which the Gaussian plume model and random walk theory including size dependency are applied. The prediction model was tested and the results reveal that the prediction model can represent the spanwise deviation of the gusts and capture the effect of gust size. The prediction model was applied to a virtual wind turbine array, and estimates are given for which wind turbines would be impacted. Full article
