The advancement of wearable technologies has resulted in significant interest in GNSS-integrated textile antenna development. Although existing literature surveys predominantly concentrate on flexible non-textile antenna systems operating within UHF and 5G frequency spectra, systematic investigations of textile-based antenna configurations in the 1–2 GHz GNSS band have been relatively scarce. Contemporary GNSS textile antenna architectures primarily target GPS frequency coverage, while the global proliferation of BeiDou Navigation Satellite System (BDS) infrastructure necessitates urgent development of BDS-compatible textile antenna solutions. This review methodically examines the structural configurations and radiation characteristics of 1–2 GHz textile antennas, bandwidth enhancement techniques, miniaturization methodologies, and gain optimization approaches, along with material selection criteria and manufacturing processes. Technical challenges persist in simultaneously achieving broadband operation, compact dimensions, and elevated gain performance. Primary manufacturing approaches encompassing laminated fabric assemblies, printed electronics, and embroidered conductive patterns are analyzed, while existing methodologies exhibit limited capacity for seamless garment integration. Despite remarkable progress in conductive material engineering, dielectric property modification studies demonstrate insufficient theoretical depth. Comprehensive mitigation strategies for multifaceted operational environments involving human proximity effects, mechanical deformation, and variable meteorological conditions remain notably underdeveloped. This comprehensive analysis aims to establish a foundational framework for next-generation BDS-oriented textile antenna development. Full article

The last few years have seen the introduction of new technologies in beekeeping, including RFID. Using readers and miniaturized tags, RFID systems work in the UHF frequency band, allowing reading distances to reach tens of centimeters. This work analyzes the propagation inside a full beehive, composed of 10 frames supported by a wooden structure. Each frame contains a layer of beeswax supported by metallic wires. The methodology employed involves measuring Received Signal Strength Indicator (RSSI) values and simulating the environment using CST Studio. The results show that tags located along the frame’s wires have more coverage than tags in the center positions, revealing coupling of the microtag antenna with the wire. Furthermore, obtaining coverage through simulations represents a more restrictive approach than through measurements. Frame selectivity is also observed, as most of the coverage is found within the three frames closest to the reader antenna. This result shows that RFID systems can find application in the identification and location of the queen bee in a hive. Full article

In the context of Doppler radar, studies have examined the changes in the phase shift of the S₂₁ transmission coefficient related to minute movements of the human chest as a response to breathing or heartbeat. Detecting human vital signs remains a challenge, especially when obstacles interfere with the attempt to detect the presence of life. The sensitivity of a measurement system’s perception of vital signs is highly dependent on the monitoring systems and antennas that are used. The current work proposes a computational approach that aims to extract an empirical law of the dependence of the phase shift of the transmission coefficient (S₂₁) on the sensitivity at reception, based upon a set of four parameters. These variables are as follows: (a) the frequency of the continuous wave utilized; (b) the antenna type and its gain/directivity; (c) the electric field strength distribution on the chest surface (and its average value); and (d) the type of material (dielectric properties) impacted by the incident wave. The investigated frequency range is (1–20) GHz, while the simulations are generated using a doublet of dipole or gain-convenient identical Yagi antennas. The chest surface is represented by a planar rectangle that moves along a path of only 3 mm, with a step of 0.3 mm, mimicking respiration movement. The antenna–target system is modeled in the computational space in each new situation considered. The statistics illustrate the multiple regression function, empirically extracted. This enables the subsequent building of a continuous-wave bio-radar Doppler system with controlled and improved sensitivity. Full article

High-voltage direct-current (HVdc) transmission lines are gaining more attention as an integral part of modern power system networks. Monitoring the dc current is important for metering and the development of dynamic line rating control schemes. However, this has been a challenging task, and there is a need for wireless sensing methods with high accuracy and a dynamic range. Conventional methods require direct contact with the high-voltage conductors and utilize bulky and complex equipment. In this paper, an ultra-high-frequency (UHF) radio frequency identification (RFID)-based sensor is introduced for the monitoring of the dc current of an HVdc transmission line. The sensor is composed of a passive RFID tag with a custom-designed antenna, integrated with a Hall effect magnetic field device and an RF power harvesting unit. The dc current is measured by monitoring the dc magnetic field around the conductor using the Hall effect device. The internal memory of the RFID tag is encoded with the magnetic field data. The entire RFID sensor can be wirelessly powered and interrogated using a conventional RFID reader. The advantage of this approach is that the sensor does not require batteries and does not need additional maintenance during its lifetime. This is an important feature in a high-voltage environment where any maintenance requires either an outage or special equipment. In this paper, the detailed design of the RFID sensor is presented, including the antenna design and measurements for both the RFID tag and the RF harvesting section, the microcontroller interfacing design and testing, the magnetic field sensor calibration, and the RF power harvesting section. The UHF RFID-based magnetic field sensor was fabricated and tested using a laboratory experimental setup. In the experiment, a 40 mm-diameter-aluminum conductor, typically used in 500 kV HVdc transmission lines carrying a dc current of up to 1200 A, was used to conduct dc current tests for the fabricated sensor. The sensor was placed near the conductor such that the Hall effect device was close to the surface of the conductor, and readings were acquired by the RFID reader. The sensitivity of the entire RFID sensor was 30 mV/mT, with linear behavior over a magnetic flux density range from 0 mT to $4.5$ mT. Full article

In this paper, a conformal UHF antenna with a wide-angle radar cross section (RCS) reduction capability is proposed. The radiator of the design is a planar monopole antenna. Since the large physical size of the antenna in UHF band can generate a scatter beam with a large RCS in the high operating frequency of radars and other sensing applications, i.e., the X band, two types of ITO (Indium Tin Oxide) meta-absorber are proposed and loaded onto the monopole antenna to suppress the scatter. For the incident beam around the direction orthogonal to the radiator plane, the periodical meta-absorber can realize around a 20 dB RCS reduction in the X band. The incident wave around the parallel direction of the radiator is absorbed by the taper meta-absorber, which can greatly suppress the surface and then reduce the RCS in the horizontal plane. The combined effect means the antenna can achieve a wide-angle RCS reduction. It should be noted that the antenna can still produce a high-efficiency omnidirectional beam after the lossy meta-absorber is loaded. In our opinion, the advantages of the proposed antenna design, including good radiation performance in UHF band and high RCS reduction in X band, make it a suitable candidate for airborne and drone applications. Full article

The aim of the research is to investigate the impact of laser operation parameters on the LIG (laser-induced graphene) process. It focuses on evaluating the feasibility of using the induced conductive layers to create antenna circuits that are dedicated to radio-frequency identification (RFID) technology. Given the specific design of textile RFIDtex transponders, applying the LIG technique to fabricate antenna modules on a flexible substrate (e.g., Kapton) opens new possibilities for integrating RFID labels with modern materials and products. The paper analyses the efficiency of energy and data transmission in the proposed innovative UHF RFID_LIG tags. The signal strength, read range, and effectiveness are estimated in the experimental setup, providing key insights into the performance of the devices. Based on the obtained results, it can be concluded that changes in laser cutting parameters, the size of the induced graphene layer, and the method of fixing the Kapton substrate significantly affect the quality of the cutting/engraving components and the conductivity of burned paths. However, these changes do not directly affect the correct operation of the RFID_LIG transponders, owing to the fact that these structures are resistant to external impacts. Nevertheless, an increased range of data readout from the RFID_LIG tags can be achieved by using graphene paths with higher conductivity. The obtained results confirm the validity of the proposed concept and provide a foundation for further research on adapting the LIG method to automated logistics, ultimately leading to the development of more versatile and innovative solutions for identification processes. Full article

An ultra-high-frequency (UHF) deployable conical log spiral antenna’s design and experimental test results are presented. The antenna is a spring constructed from a carbon-fiber-infused epoxy matrix. The spring design simplified the spacecraft deployment mechanism, and the use of composite materials allowed for the integration of radiating elements into the spring structure. A Chebyshev transformer at the base of the antenna is used to match the incoming transmission line impedance to a 95 $\mathrm{\Omega }$ coaxial cable. The 95 $\mathrm{\Omega }$ coaxial, which is the balun and the radiating element, is embedded into the antenna structure. The antenna is fed at the cone’s base without requiring a ground plane whilst maintaining radiation in the cone’s apex-pointing direction. This facilitated an uncomplicated deployment mechanism. Prototypes have been manufactured for 500 to 1500 MHz designs. Antenna measurements show a realized gain of between approximately 3 to 6 dBi from 500 to 1500 MHz. Full article

Due to the challenges in antenna installation and detection performance caused by metal obstruction along the propagation path at a Gas-Insulated Switchgear (GIS) cable terminal, as well as the adverse effects of environmental interference on the detection of partial discharge (PD) by existing flexible antennas, this paper proposes a directional flexible antenna design to mitigate these issues and improve detection performance. The proposed design employs a coplanar waveguide (CPW)-fed monopole antenna structure, where the grounding plane is extended to the back of the antenna to enhance directional reception. The designed flexible antenna measures 88.5 × 70 × 20 mm, and its low-profile design allows it to be easily mounted on the outer wall of the epoxy sleeve at the GIS cable terminal. The measurement results show that the flexible antenna has a Voltage Standing Wave Ratio (VSWR) of less than 2 in the 0.541–3 GHz frequency range. It also maintains stable impedance characteristics across various bending radii, with an average effective height of 10.79 mm in the 0.3–1.5 GHz frequency range. A GIS cable terminal PD experimental platform was established, and the experimental results demonstrate that the bending has minimal impact on the detection performance of the flexible antenna, which can cover the detection range of the GIS cable terminal; metal obstruction significantly impacts the PD signal amplitude, and the designed flexible antenna is suitable for detecting PDs in confined spaces with metal obstruction. Full article

An S-band antenna has been designed, developed, measured, space-qualified, and integrated into the INTA ANSER satellite constellation and the future ANSER-AT mission. This antenna will be part of the space-to-ground communication link for the constellation, which consists of one Leader and two Followers. The novel antenna, mounted on the Leader, has been designed and manufactured with materials and processes specifically tested for space. It features dual circular polarization over a wide band without requiring a phase-shifting network, making it very compact and straightforward. Additionally, its gain patterns are highly stable within the desired band, improving its link capacity compared to the UHF monopole alternative used in the previous Leader. Currently, the antenna has been qualified and installed on INTA’s Leader-S, set to launch in January 2025, as well as on the future ANSER-AT mission. Full article

The literature reports highlight the transmission field (B₁⁺) uniformity and efficiency constraints of cardiac magnetic resonance imaging (MRI) at ultrahigh magnetic fields (UHF). This simulation study proposes a 3D Metamaterial (MM) to address these challenges. The study proposes a 3D MM consisting of unit cells (UC) with split ring resonator (SRR) layers immersed in dielectric material glycerol. Implementing the proposed MM design aims to reduce the effective thickness and weight of the dielectric material while shaping B₁⁺ and improving the penetration depth. The latter is dictated by the chosen array size, where small local UC arrays can focus B₁⁺ and larger UC arrays can increase the field of view, at the cost of a lower penetration depth. Designing RF antennas that can effectively transmit at 21.0 T while maintaining patient safety and comfort is challenging. Using Self-Grounded Bow-Tie (SGBT) antennas in conjunction with the proposed MM demonstrated enhanced B₁⁺ efficiency and uniformity across the human heart without signal voids. The study employed dynamic parallel transmission with tailored kT points to homogenize the 3D flip angle over the whole heart. This proof-of-concept study provides the technical foundation for human cardiac MRI at 21.0 T. Such numerical simulations are mandatory precursors for the realization of whole-body human UHF MR instruments. Full article

In radio frequency identification (RFID), differences in spectrum policies and tag misreading in different countries are the two main issues that limit its application. To solve these problems, this article proposes a composite right/left-handed transmission line (CRLH-TL)-based reconfigurable antenna for ultra-high frequency near-field and far-field RFID reader applications. The CRLH-TL is achieved using a periodically capacitive gap-loaded parallel plate line. By deploying the CRLH-TL operating at zeroth-order resonance, a loop antenna with in-phase radiating current is obtained, which contributes to a strong and uniform H-field and a horizontally polarized omnidirectional radiation pattern. By introducing additional tunable components, frequency and reading range reconfigurabilities are enabled. The frequency tuning range is from 833 MHz to 979 MHz, which covers the worldwide UHF RFID band. Moreover, each operation mode has a narrow frequency band, which means it can operate without violating different countries’ radio frequency policy and reduce the design difficulty of designing multiple versions of a reader. Both the near-field interrogation zone and maximum far-field reading distance of the antenna are adjustable. The near-field interrogation zone is 400 mm × 400 mm × 50 mm and can be further confined. The tuning range for far-field reading distance is from 2.71 m to 0.35 m. Full article

The production of consumer electronics using electrically conductive materials is a dynamically developing sector of the economy. E-textiles (electronic textiles) are also used in radio frequency identification technology, mainly in the production of tag antennas. For economic reasons, it is important that the finished product is universal, although frequencies in radio systems have different values in different regions of the world. Therefore, the antenna bandwidth must be sufficiently wide so that the read range of the tag is maximally large for all frequencies of the specified band. The bandwidth of an antenna depends on its type and geometric dimensions, but this parameter can also be influenced by the way a given type of antenna is made. The authors prepared samples of embroidered RFID tag antennas for the UHF band using various types of embroidery. Then, its impedance and the read range of the tag were examined in order to determine the exact influence of the type of embroidery on the parameter of interest (antenna bandwidth). The results obtained during the research indicate the influence of different embroidery styles is present; however, that influence is not significant. Full article

A broadband and compact planar UHF antenna is presented for use in MIMO Digital TV indoor applications. The choice of the element and its physical implementation is oriented towards a low-profile, low-cost, and single-layer deployment. Since it is intended to be used in a 2 × 1 MIMO array, two antennas were constructed and tested to minimize their coupling to provide larger MIMO gains. Regarding the excitation, two different structures were evaluated to observe their impact on the final impedance profile. The option of an infinite balun provided a 62% fractional bandwidth (394 MHz to 747 MHz), covering the desired band and with good isolation levels when analyzed in the array. Results regarding MIMO parameters are provided herein, such as Envelope Correlation Coefficient and Total Active Reflection Coefficient, proving the potential of the proposed antenna array to be used in MIMO Digital TV applications in covering the UHF band. Full article

A compact VHF/UHF ultrawideband discone antenna with consistent patterns is proposed in this article. The proposed antenna consists of a disk, a modified cone, an inverted cone, four shorting probes, and two sleeves. To improve the radiation angular distortion at high frequencies, two sleeves are inserted into the discone antenna. Higher-order modes are suppressed, and ultrawideband consistent patterns are obtained without antenna size increasing. An inverted cone and four shorting probes are introduced to achieve broadband and profile reduction. An antenna prototype is fabricated and measured. The proposed antenna possesses consistent patterns in a 11.36:1 bandwidth. The pattern nulls is improved by 26.1 dB. The antenna occupies a cylindrical volume of 0.227 ${\lambda }_0$ (D) and 0.096 ${\lambda }_0$ (H). It is a competitive candidate for future in-vehicle communication systems. Full article

In this paper, some of the basic information on Ground-Penetrating Radar (GPR), its applications (especially in the field of civil engineering) and limitations are presented. As a non-destructive technique, GPR is a powerful tool for the investigation of structures and structural members, roads, geological layers, archaeological sites and many more. The technology is based on electromagnetic radiation in the UHF/VHF range (10 MHz to 3 GHz). The choice of the frequency depends on the intended use, depth and size of the target and medium where the target is located. Joined with other testing methods (ultrasound method, dynamic methods with forced or ambient vibrations, electrical conductivity testing, etc.), GPR can provide a deep insight into the investigated object. However, like many other non-destructive methods, the choice of input parameters may affect the results. In this regard, a case study presented in this paper demonstrates not only different applications of GPR in civil engineering but also the determination (calibration) of one of those input parameters: the dielectric constant of glued laminated timber. The challenge here was not only to investigate the influence of the direction of measurements with regards to the direction of the fibers but also to acknowledge the contribution of the test antenna used during testing and dielectric constant calibration. Full article
