This paper proposes an improved zero-current distortion compensation (IZCDC) method for the Vienna rectifier. The conventional zero-current distortion compensation (ZCDC) method modifies the reference voltages by adding an offset voltage to compensate for the zero-current distortion (ZCD). However, the reference voltages occasionally exceed the linear modulation region by the offset voltage added at the driving start-point of the Vienna rectifier, where the modulation index of phase voltage is relatively large. This causes a hard-start of the Vienna rectifier accompanied by a serious surge and distortion in the phase current. In this paper, the IZCDC method is proposed for achieving the soft-start of the Vienna rectifier. When the overmodulation occurs, the proposed method modifies the conventional offset voltage to the IZCDC component, which is involved in the adjustment of the variance of the phase current, only for a certain phase among the three phases. As the IZCDC component regulates the variance of the phase current to zero, surge and distortion in the phase current can be mitigated. As a result, the Vienna rectifier starts its operation softly while ensuring its normal operation in the transients. The effectiveness of the proposed method is verified through simulations and experimental results. Full article

Regulating LED current and voltage is critical to maintaining a constant luminous flux in AC- or DC-powered LED lighting circuits. Today, users require constant current drivers that can provide a wide range of output voltages to drive different numbers of series-connected LED arrays. This work proposes an LED driver by combining an isolated SEPIC converter operating in the continuous conduction mode (CCM) and a modified Vienna rectifier. The proposed LED driver offers a single-switch control structure by adding a Vienna rectifier to the integrated SEPIC-FLYBACK converter. This driver structure provides many advantages over traditional bridge rectifier structures. The prototype circuit was tested in an 18 W continuous current mode (CCM) to verify its feasibility. As a result of the values obtained from both simulation and prototype circuit models, it has been shown to provide many of the following advantages: 95% high efficiency, high reliability, 4% low total harmonic distortion, 97% high power factor, and 70 V low switching voltage. This work meets class C 3-2 and IEC 61000 standards. Full article

This article aims to shed new light on the work of the humanist and Jewish convert Paulus Weidner (1522–1585) by focusing on his use of postbiblical Jewish sources to defend, illustrate, and spread a non-confessional Christian faith both among Jews and among the divided Christians of the Habsburg Monarchy. As such, Weidner was a major figure of the Christian via media promoted at the Habsburg court in Vienna around the mid-16th century. Yet, he retained, at the same time, a profound originality, for his contribution was largely based on the Mishnah. Indeed, Weidner not only proposed Christian interpretations of the Talmud, which he argued could lead to Christian faith but also claimed that the Pirkei Avot could serve as a source of Christian ethics and, as such, ought be added to the Biblical and classical heritage promoted and revered by scholars of his time. Full article

This work presents the experimental validation of a 40 kW electric vehicle (EV) charger. The proposed system comprises two 20 kW modules connected in parallel at the input and output. Each module has two stages—as a grid converter Vienna Rectifier (VR) was chosen, and as an isolated DC/DC stage, two Series-Resonant Dual-Active-Bridges (SRDABs) in input-series-output-parallel (ISOP) configurations were applied. The AC/DC and DC/DC stages were enclosed in 2U rack standard housing. A bipolar DC-link with ±400 V DC voltage was employed to connect both stages of the charger module while the charger’s output is dedicated to serving 800 V batteries. VRs operated at 66 kHz switching frequency and the SRDABs operated at 100 kHz. The converters used in the charger structure were based on silicon carbide (SiC) power devices. The description and parameters of the built hardware prototypes of both—AC/DC and DC/DC—converters are provided. Moreover, the experimental validation of each stage and the whole charging system, including oscilloscope waveforms and power analyzer measurements at nominal power, are included. Such a configuration enables energy conversion with high efficiency without a negative impact on the grid and high-quality grid waveforms. Full article

Although a switched reluctance generator (SRG) is not the mainstream wind generator, it possesses the application potential and is worth developing for its many structural merits and high developed power ability. This paper presents a wind SRG-based bipolar DC microgrid having grid-connected and plug-in energy supporting functions. First, a surface-mounted permanent magnet synchronous motor (SPMSM)-driven wind turbine emulator (WTE) is established. Next, the wind SRG with an asymmetric bridge converter is developed. Good generating characteristics are obtained through proper designs of power circuit, commutation mechanism, external excitation source, voltage and current controllers. Third, a DC/DC boost interface converter and a bipolar voltage balancer are constructed to establish the 500 V microgrid bipolar DC-bus. To preserve the microgrid power supplying quality, a battery energy storage system (BESS) with bidirectional DC/DC interface converter is equipped. A dump load leg is added across the bus to limit the DC-bus voltage under energy surplus condition. In load side, a three-phase bidirectional load inverter is developed, which can be operated as a single-phase three-wire (1P3W) inverter or a three-phase three-wire (3P3W) inverter. Good sinusoidal voltage waveform and regulation characteristics are obtained using the proportional-resonant (PR) control. The microgrid to load and microgrid to grid operations are conductible. Finally, to further improve the powering reliability of microgrid, a three-phase T-type Vienna switch-mode rectifier (SMR) based plug-in energy supporting scheme is developed. When the microgrid energy shortage occurs, the possible harvested energy can be used to supply the microgrid. Full article

Emerging electric vehicle (EV) technology requires high-voltage energy storage systems, efficient electric motors, electrified power trains, and power converters. If we consider forecasts for EV demand and driving applications, this article comprehensively reviewed power converter topologies, control schemes, output power, reliability, losses, switching frequency, operations, charging systems, advantages, and disadvantages. This article is intended to help engineers and researchers forecast typical recharging/discharging durations, the lifetime of energy storage with the help of control systems and machine learning, and the performance probability of using AlGaN/GaN heterojunction-based high-electron-mobility transistors (HEMTs) in EV systems. The analysis of this extensive review paper suggests that the Vienna rectifier provides significant performance among all AC–DC rectifier converters. Moreover, the multi-device interleaved DC–DC boost converter is best suited for the DC–DC conversion stage. Among DC–AC converters, the third harmonic injected seven-level inverter is found to be one of the best in EV driving. Furthermore, the utilization of multi-level inverters can terminate the requirement of the intermediate DC–DC converter. In addition, the current status, opportunities, challenges, and applications of wireless power transfer in hybrid and all-electric vehicles were also discussed in this paper. Moreover, the adoption of wide bandgap semiconductors was considered. Because of their higher power density, breakdown voltage, and switching frequency characteristics, a light yet efficient power converter design can be achieved for EVs. Finally, the article’s intent was to provide a reference for engineers and researchers in the automobile industry for forecasting calculations. Full article

This work considers the enhancement of the thermoelectric figure of merit, ZT, of SrTiO₃ (STO) semiconductors by (La, Dy and N) co-doping. We have focused on SrTiO₃ because it is a semiconductor with a high Seebeck coefficient compared to that of metals. It is expected that SrTiO₃ can provide a high power factor, because the capability of converting heat into electricity is proportional to the Seebeck coefficient squared. This research aims to improve the thermoelectric performance of SrTiO₃ by replacing host atoms by La, Dy and N atoms based on a theoretical approach performed with the Vienna Ab Initio Simulation Package (VASP) code. Here, undoped SrTiO₃, Sr_0.875La_0.125TiO₃, Sr_0.875Dy_0.125TiO₃, SrTiO_2.958N_0.042, Sr_0.750La_0.125Dy_0.125TiO₃ and Sr_0.875La_0.125TiO_2.958N_0.042 are studied to investigate the influence of La, Dy and N doping on the thermoelectric properties of the SrTiO₃ semiconductor. The undoped and La-, Dy- and N-doped STO structures are optimized. Next, the density of states (DOS), band structures, Seebeck coefficient, electrical conductivity per relaxation time, thermal conductivity per relaxation time and figure of merit (ZT) of all the doped systems are studied. From first-principles calculations, STO exhibits a high Seebeck coefficient and high figure of merit. However, metal and nonmetal doping, i.e., (La, N) co-doping, can generate a figure of merit higher than that of undoped STO. Interestingly, La, Dy and N doping can significantly shift the Fermi level and change the DOS of SrTiO₃ around the Fermi level, leading to very different thermoelectric properties than those of undoped SrTiO₃. All doped systems considered here show greater electrical conductivity per relaxation time than undoped STO. In particular, (La, N) co-doped STO exhibits the highest ZT of 0.79 at 300 K, and still a high value of 0.77 at 1000 K, as well as high electrical conductivity per relaxation time. This renders it a viable candidate for high-temperature applications. Full article

This paper proposes a portable 11 kW off-board charger for electric vehicles. In the ac/dc stage, a three-phase power factor correction (PFC) in Vienna topology is chosen. The loss and volume of the PFC inductance are calculated over a wide range of parameters and optimized with regard to design, winding, and core material. A three-phase LLC resonant converter operating at 1 MHz is chosen for the galvanically isolated dc/dc stage. A parametrizable loss model of the high-frequency transformer and the resonance inductor is developed to minimize volume, weight, and losses. With the help of an automated algorithm using these loss models, the inductive components are optimized in terms of winding specification, magnetic material, and core geometry, verified by finite element analysis and measurements. For the ac/dc stage, 900 V SiC devices are adopted, and 1200 V SiC devices are used in the primary and secondary sides of the dc/dc stage. A variable dc-link voltage is utilized to adjust the charging profile and to operate the LLC resonant converter at the most efficient point near the series resonance frequency. A mechatronically integrated portable air-cooled off-board charger prototype with 11 kW, three-phase 400 V_AC input, and 620–850 V_DC output is realized and tested. The prototype demonstrates a power density of 2.3 kW/liter (37.7 W/in³), a peak efficiency of 96%, and 95.8% efficiency over the defined battery voltage range. Full article

Vienna converters have several advantages, including low construction costs, improved total harmonics, and considerable reliability. Generally, they are used in applications with a high switching frequency, particularly in telecommunications, and their use in power generation systems is recent but promising. They can be an interesting solution for medium and large wind power systems as they have the advantage of a high power density compared to traditional two-level converters. In this paper, a wind energy production system based on a Vienna rectifier and the permanent magnet synchronous generator (PMSG) is proposed. The main objective of this work is to evaluate the performance of the vector control strategy of the PMSG associated with the Vienna rectifier considering the real conditions of wind power systems. The feasibility and effectiveness of the proposed control strategy are evaluated through the simulations in MATLAB/Simulink and experimental tests based on a laboratory prototype. The outcomes present interesting performances in terms of dynamics and stability. Full article

Two of the main challenges of recent electric vehicles (EVs) are the charging time and high initial cost. To solve the problem associated with long charging time, the car manufacturers are moving from 400 V battery EV (BEV) to 800 V BEV, which enables the utilization of multi-level converters in EV applications. This paper presents a power conversion system consisting of a Vienna rectifier and a two/three level hybrid inverter as a machine-side inverter to drive a permanent-magnet synchronous motor (PMSM). The Vienna rectifier improves the quality of the grid-side current and provides a regulated DC-link voltage. The proposed inverter, known as a 10-switch inverter, offers high output current quality with a lower number of active switches, making it compact and cost-effective. The field-oriented control (FOC), along with the SPWM modulation, is implemented to control the system. A reliable and cost-effective PMSM drive system demands sensorless control; therefore, a sliding mode observer (SMO) is used to estimate the rotor position and velocity. The accuracy of the proposed system was proved through the simulation results from MATLAB/Simulink. Full article

Internet of things (IoT) is playing a major role in smart cities to make a digital environment. Traffic congestion is a serious road issue because of an increasing number of vehicles in urban areas. Some crucial traffic problems include accidents and traffic jams that cause waste of fuel, health diseases, and a waste of time. Present traffic signaling systems are not efficient in resolving congestion problems because of the lack of traffic signals. Nowadays, traffic signaling systems are modeled with fixed time intervals in which no proper mechanism for emergency vehicles is available. Such traffic mechanisms failed to deal with traffic problems effectively. The major objective is to establish a robust traffic monitoring and signaling system that improves signal efficiency by providing a responsive scheme; appropriate routes; a mechanism for emergency vehicles and pedestrians in real-time using Vienna Development Method Specification Language (VDM-SL) formal method and graph theory. A formal model is constructed by considering objects, such as wireless sensors and cameras that are used for collecting information. Graph theory is used to represent the network and find appropriate routes. Unified Modeling Language is used to design the system requirements. The graph-based framework is converted into a formal model by using VDM-SL. The model has been validated and analyzed using many facilities available in the VDM-SL toolbox. Full article

This article investigates the potential of selected urban typologies in Vienna to reach the state of Positive Energy Districts (PED) by achieving a positive annual energy balance. It follows the EU initiative for implementing at least 100 PED in Europe by 2025. Four urban typologies have been assessed using the bottom-up energy modelling tool MAPED that enables a simplified energy demand-supply analysis at the district scale. Considering relevant urban typologies in different construction periods, the analysis focused on converting the allocated building stocks into PED by employing comprehensive thermal refurbishment and energy efficiency measures, electrification of end-uses and fuel switching, exploitation of local renewable energy potential, and flexible interaction with the regional energy system. The results reveal that a detached housing district can achieve a positive annual energy balance (for heat and power) of 110% due to the fact that there are sufficient surfaces (roofs, facades, open land) available for the production of local renewable energy, whereas the remaining typologies fail to achieve the criteria with an annual balance ranking between 61% and 97%, showing additional margins for improvement to meet the PED conditions. The presented concept offers a practical approach to investigate the PED suitability of urban typologies. It will help the Austrian Ministry for Climate Action and Environment to identify appropriate strategies for the refurbishment of existing urban areas towards the PED standard. Full article

The hybrid three-phase rectifiers (HTR) consist of parallel associations of two rectifiers (rectifier 1 and rectifier 2), each one of them with a distinct operation, while the sum of their input currents forms a sinusoidal or multilevel waveform. In general, rectifier 1 is a GRAETZ (full bridge) (can be combined with a BOOST converter) and rectifier 2 is combined with a DC-DC converter. In this HTR contest, this paper is intended to answer some important questions about those hybrid rectifiers. To obtain the correct answers, the study is conducted as an analysis of a systematic literature review. Thus, a search was carried out in the databases, mostly IEEE and IET, and 34 papers were selected as the best corresponding to the HTR theme. It is observed that the preferred form of power distribution in unidirectional hybrid three-phase rectifiers (UHTR) is $55\%P_o$ (rectifier 1) and $45\%P_o$ (rectifier 2). For the bidirectional hybrid three-phase rectifiers (BHTR), rectifier 1 preferably takes $90\%\mathrm{of}{P}_o$ and $10\%\mathrm{of}{P}_o$ is processed by rectifier 2. It is also observed that the UHTR that employ the single-ended primary-inductor converter (SEPIC) or VIENNA converter topologies in rectifier 2 can present sinusoidal input currents with low total harmonic distortion (THD) and high Power Factor (PF), even successfully complying with the international standards. The same can be said about the rectifier that employs a pulse-width (PWM) converter of BOOST topology in rectifier 2. In short, the HTR are interesting because they allow using the GRAETZ full bridge topology in rectifier 1, thus taking advantage of its characteristics, being simple, robust, and reliable. At the same time, the advantages of rectifier 2, i.e., high PF and low THD, are well used. In addition, this article also points out the future direction of research that is still unexplored in the literature, thus giving opportunities for future innovation. Full article

The rapid development of electric vehicle ultra-fast battery chargers is increasingly demanding higher efficiency and power density. In particular, a proper control of the grid-connected active front–end can ensure minimum passive component size (i.e., limiting design oversizing) and reduce the overall converter losses. Moreover, fast control dynamics and strong disturbance rejection capability are often required by the subsequent DC/DC stage, which may act as a fast-varying and/or unbalanced load. Therefore, this paper proposes the design, tuning and implementation of a complete digital multi-loop control strategy for a three-level unidirectional T-type rectifier, intended for EV ultra-fast battery charging. First, an overview of the operational basics of three-level rectifiers is presented and the state-space model of the considered system is derived. A detailed analysis of the mid-point current generation process is also provided, as this aspect is widely overlooked in the literature. In particular, the converter operation under unbalanced split DC-link loads is analyzed and the converter mid-point current limits are analytically identified. Four controllers (i.e., dq-currents, DC-link voltage and DC-link mid-point voltage balancing loops) are designed and their tuning is described step-by-step, taking into account the delays and the discretization introduced by the digital control implementation. Finally, the proposed multi-loop controller design procedure is validated on a 30 kW, 20 kHz T-type rectifier prototype. The control strategy is implemented on a single general purpose microcontroller unit and the performances of all control loops are successfully verified experimentally, simultaneously achieving low input current zero-crossing distortion, high step response and disturbance rejection dynamics, and stable steady-state operation under unbalanced split DC-link loading. Full article

The balance control of neutral-point voltage (NPV) is important in the three-level converter. In this paper, this problem is studied by taking the VIENNA circuit as an example. The deviation of NPV is essentially caused by mismatch between the charging and discharging time of two series capacitors by the neutral-point current flowing into or out of the DC side. The unbalanced NPV will lead to unbalanced voltage stress of two capacitors and power switches and may cause overvoltage damage to both and also increase the total harmonic distortion (THD) and harmonic components in the AC current. In this paper, by analyzing the role and effect of a small-voltage vector on NPV, a control strategy based on the selection method of dynamical adjustment for a small vector is proposed. By judging the fluctuation of NPV, different small vectors are dynamically selected to act to adjust the NPV. For verification, the proposed strategy is compared with the traditional zero-sequence voltage injection (ZSV-J) method through simulation and experiment. Compared with ZSV-J, the THD of AC current is decreased by about 27.2%, the efficiency is increased by about 1.66%, and the adjustment speed of NPV is increased by about 50%. Therefore, the feasibility and advantages of the strategy are verified. Full article
