The classical pre-stack seismic inversion technique uses the Zoeppritz equation and its simplified versions to calculate the PP and PS reflection coefficients at different incidence angles, aiding in inverting the subsurface velocity and density parameters. Despite its widespread application, the amplitude variation with angle (AVA) inversion based on the Zoeppritz equation has limitations regarding the accuracy. The AVA neglects transmission losses and the effects of multiple reflections during seismic wave propagation, resulting in reduced resolution. In contrast, the propagation matrix theory offers a comprehensive range of reflection coefficients for P- and S-waves in multilayered media at arbitrary incidence angles, thereby theoretically enhancing the inversion accuracy. However, the seismic responses obtained using this method exist in the slowness–frequency domain and require constant slowness for consistency along a profile. This assumption is violated when variations in the P-wave velocity occur within the subsurface, affecting the incidence angle of propagating seismic waves. This study modifies the propagation matrix theory to compute AVA seismic responses and applies it to pre-stack multiparameter inversion. The effectiveness of the modified method was validated by deriving theoretical AVA seismic responses and comparing them to solutions from a typical layered media model. The modified theory was also employed for seismic pre-stack inversion. Numerical simulations and field data tests demonstrated that the new propagation matrix method offers a high accuracy and stability. Full article

Channel wave seismic activity often occurs with thin and medium-thick coal seams being the main target layer. To address the problem of channel wave applicability detection in extremely thick coal seams, the propagation and identification characteristics of channel waves remain the focus of research. Therefore, this paper takes the in-seam wave exploration of a 27 m extremely thick coal seam as an example and uses the staggered mesh finite difference method to construct a three-dimensional medium model for numerical simulation. An analysis of the physical parameters of coal and rock, along with the dispersion characteristics of channel waves in extra-thick coal seams, is utilized, through the Zoeppritz equation and the total reflection propagation method, to calculate the imaging. We found the following: (1) The dispersion areas and weak dispersion areas along the detection direction are extremely thick coal seams. (2) There are apparent channel waves in extra-thick coal seams, with a waveform similar to body waves; the length of the wave train is shorter than that of the conventional channel wave, and the arrival time can be estimated accurately. The amplitude of the apparent channel wave is affected by the degree of dispersion, with lower attenuation and higher resolution. The characteristic of total reflection in extremely thick coal seams is that the incident angle is equal to the critical angle, and the dispersion characteristics are weak. (3) The channel waves with weak dispersion characteristics in extra-thick coal seams are mainly Love-type waves. Full article

The high-resolution seismic characterization of gas hydrate reservoirs plays an important role in the detection and exploration of gas hydrate. The conventional AVO (amplitude variation with offset) method is based on a linearized Zoeppritz equation and utilizes only the reflected wave for inversion. This reduces the accuracy and resolution of the inversion properties and results in incorrect reservoir interpretation. We have studied a high-resolution wave-equation-based inversion method for gas hydrate reservoirs. The inversion depends on the scattering integral wave equation that describes a nonlinear relationship between the seismic wavefield and the elastic properties of the subsurface medium. In addition to the reflected wave, it considers more wavefields including the multiple scattering and transmission during inversion to improve the subsurface illumination, so as to enhance the accuracy and resolution of the inversion properties. The results of synthetic data from Pearl River Mouth Basin, South China Sea, demonstrate the validity and advantages of the wave-equation-based inversion method. It can effectively improve the resolution of inversion results compared to the conventional AVO method. In addition, it has good performance in the presence of noise, which makes it a promising method for field data. Full article

Analysis of amplitudes of transmitted waves (TAVO) is an extension of the conventional AVO analysis using amplitudes of reflected waves. In this study, we introduce the common transmission point (CTP) gather, which is a new domain that is convenient for TAVO analysis. A CTP gather is formed by binning traces that have the same transmission point across a layer interface. We use the proposed domain to invert the ratios $\frac{\mathsf{\Delta }\mathsf{\alpha }}{\mathsf{\alpha }}$, $\frac{\mathsf{\Delta }\mathsf{\rho }}{\mathsf{\rho }}$, $\frac{\mathsf{\Delta }\mathsf{\beta }}{\mathsf{\beta }}$, and $\frac{\mathsf{\beta }}{\mathsf{\alpha }}$ in a model consisting of a gas channel nestled within an oil reservoir. The TAVO equations are fitted to amplitudes calculated by Zoeppritz equations within CTPs inside and outside the channel. Within each CTP gather, we use all traces with incidence angles less than 90% of the critical angle (if any) as TAVO approximations break down beyond this point. The proposed CTP TAVO analysis method estimated $\frac{\mathsf{\Delta }\mathsf{\alpha }}{\mathsf{\alpha }}$, $\frac{\mathsf{\Delta }\mathsf{\rho }}{\mathsf{\rho }}$, $\frac{\mathsf{\Delta }\mathsf{\beta }}{\mathsf{\beta }}$, and $\frac{\mathsf{\beta }}{\mathsf{\alpha }}$ in the gas channel within 1% of their corresponding true values. Full article

“Thin-bed” reservoirs have become important targets of seismic exploration and exploitation. However, traditional amplitude versus offset/amplitude versus angle (AVO/AVA) technologies, for example, those based on Zoeppritz equations and their approximations for a single interface, are not sufficiently accurate for thin-bed stratigraphy. Analytic solutions of thin-bed reflectivity may become practical for thin-bed AVO analysis and inversion. Therefore, a linear analytic approximation of thin-bed P-wave reflectivity is developed under small-incidence and thin-bed assumptions. Numerical simulations show that the amplitude approximation errors are usually smaller than 10% for incidence angles less than 20 degrees, and the thin-bed thicknesses are less than one-tenth of the P-wave wavelength. Based on the least-squares approach, the inversion strategy is proposed using the approximate formula. A synthetic data test shows that the proposed inversion method can produce more accurate thin-bed properties than that based on the Zoeppritz equations, which reveals the potential of the inversion method based on the linear analytic approximate formula in the fine characterization of thin reservoirs. Full article

Pore-fluid identification is one of the key technologies in seismic exploration. Fluid indicators play important roles in pore-fluid identification. For sandstone reservoirs, the effective pore-fluid bulk modulus is more susceptible to pore-fluid than other fluid indicators. AVO (amplitude variation with offset) inversion is an effective way to obtain fluid indicators from seismic data directly. Nevertheless, current methods lack a high-order AVO equation for a direct, effective pore-fluid bulk modulus inversion. Therefore, based on the Zoeppritz equations and Biot–Gassmann theory, we derived a high-order P-wave AVO approximation for an effective pore-fluid bulk modulus. Series reversion and Bayesian theory were introduced to establish a direct non-linear P-wave AVO inversion method. By adopting this method, the effective pore-fluid bulk modulus, porosity, and density can be inverted directly from seismic data. Numerical simulation results demonstrate the precision of our proposed method. Model and field data evaluations show that our method is stable and feasible. Full article

Seismic velocities are related to the solid matrices and the pore fluids. The bulk and shear moduli of dry rock are the primary parameters to characterize solid matrices. Amplitude variation with offset (AVO) or amplitude variation with incidence angle (AVA) is the most used inversion method to discriminate lithology in hydrocarbon reservoirs. The bulk and shear moduli of dry rock, however, cannot be inverted directly using seismic data and the conventional AVO/AVA inversions. The most important step to accurately invert these dry rock parameters is to derive the Jacobian matrix. The combination of exact Zoeppritz and Biot–Gassmann equations makes it possible to directly calculate the partial derivatives of seismic reflectivities (PP-and PS-waves) with respect to dry rock moduli. During this research, we successfully derive the accurate partial derivatives of the exact Zoeppritz equations with respect to bulk and shear moduli of dry rock. The characteristics of these partial derivatives are investigated in the numerical examples. Additionally, we compare the partial derivatives using this proposed algorithm with the classical Shuey and Aki–Richards approximations. The results show that this derived Jacobian matrix is more accurate and versatile. It can be used further in the conventional AVO/AVA inversions to invert bulk and shear moduli of dry rock directly. Full article
