Search Results (99)

To address the limitations of unsound physical models and the lack of compensation mechanisms in existing multi-degree-of-freedom programmable lighting methods, we proposed a novel multi-degree-of-freedom programmable lighting approach. The maximum deviation of single-wavelength spectral distribution curves before and after compensation was reduced by 2 times, and energy distribution uniformity was improved by 19.42 times. The wavelength scanning, intensity encoding, and broadband target spectral modulation performances were verified. The spectral modulation errors for CIE standard illuminants A and $D_{65}$ were −1.78% and −0.86%, respectively. This research lays the foundation for high-precision optical detection and analysis, enabling applications in biomedical and material fields. Full article

(1) Background: A decrease in corneal hydration during refractive surgery is observed clinically as well as in laboratory settings, but the associated consequences are not yet fully understood. The purpose of this paper is to analyze the impact of the gain of ablation efficiency due to hydration changes during cornea refractive surgery. (2) Methods: We developed a simulation model to evaluate the influence of hydration changes on the ablation algorithms used in laser refractive surgery. The model simulates different physical effects of an entire surgical process, simulating the shot-by-shot ablation process based on a modeled beam profile. The model considers corneal hydration, as well as environmental humidity, along with the laser beam characteristics and ablative spot properties for evaluating any hydration changes and their effect on laser refractive surgery. (3) Results: Using pulse lists collected from actual treatments, we simulated the gain of efficiency during the ablation process. Ablation efficiency is increased due to dehydration effects during laser treatments. Longer treatments suffer larger dehydration effects and are more prone to overcorrections due to gain of efficiency than shorter treatments. (4) Conclusions: The improper use of a model that overestimates or underestimates the effects derived from the hydration dynamics during treatment may result in suboptimal refractive corrections. This model may contribute to improving emmetropization and the correction of ocular aberrations with improved laser parameters that can compensate for the changes in ablation efficiency due to hydration changes in the cornea. Full article

High aspect ratio (HAR) sample-induced aberrations seriously affect the topography measurement for the bottom of the microstructure by coherence scanning interferometry (CSI). Previous research proposed an aberration compensating method using deformable mirrors at the conjugate position of the pupil. However, it failed to compensate for the shift-variant aberrations introduced by the HAR hybrid trench array composed of multiple trenches with different parameters. Here, we propose a computational aberration correction method for measuring the topography of the HAR structure by the particle swarm optimization (PSO) algorithm without constructing a database and prior knowledge, and a phase filter in the spatial frequency domain is constructed to restore interference signals distorted by shift-variant aberrations. Since the aberrations of each sampling point are basically unchanged in the field of view corresponding to a single trench, each trench under test can be considered as a separate isoplanatic region. Therefore, a multi-channel aberration correction scheme utilizing the virtual phase filter based on isoplanatic region segmentation is established for hybrid trench array samples. The PSO algorithm is adopted to derive the optimal Zernike polynomial coefficients representing the filter, in which the interference fringe contrast is taken as the optimization criterion. Additionally, aberrations introduce phase distortion within the 3D transfer function (3D-TF), and the 3D-TF bandwidth remains unchanged. Accordingly, we set the non-zero part of the 3D-TF as a window function to preprocess the interferogram by filtering out the signals outside the window. Finally, experiments are performed in a single trench sample and two hybrid trench array samples with depths ranging from 100 to 300 μm and widths from 10 to 30 μm to verify the effectiveness and accuracy of the proposed method. Full article

Based on the widely used Gullstrand–Le Grand eye model, a scattering individual eye model was constructed with Zemax, which has individual ocular wavefront aberration and the scattering particles distributed in the eye. There are three main steps to build the model. Firstly, the Gullstand-Le Grand eye model was constructed, and converted into a non-sequential model. The axial lengths of all ocular components, and the corneal curvatures were input into the optical model. Secondly, a high-order aspheric surface-Zernike Fringe Sag surface was chosen to fit the wavefront aberrations measured with the ocular wavefront aberrometer. Thirdly, an embedded scattering lens within the crystalline lens was developed, of which parameters of scattering particles can be selected flexibly. The scattering individual eye model can be used to quantitatively investigate interaction between ocular aberrations and scattering light on retina image quality. The results demonstrated that when scattering particles were uniformly distributed across the optical pupil, MTFs at all spatial frequencies decreased proportionally with increasing particle density, independent of aberrations. When scattering particles were located in regions with smaller wavefront aberrations, the combined effect of scattering and aberrations synergistically degraded retinal image quality. In contrast, when particles were concentrated in zones of larger aberrations, the scattered light could partially compensate for the aberrational effects, leading to improved optical performance Full article

Atmospheric turbulence introduces distortions to the wavefront of propagating optical radiation. It causes image resolution degradation in astronomical telescopes and significantly reduces the power density of radiation on the target in focusing applications. The impact of turbulence fluctuations on the wavefront can be investigated under laboratory conditions using either a fan heater (roughly tuned), a phase plate, or a deformable mirror (finely tuned) as a turbulence-generation device and a wavefront sensor as a wavefront-distortion measurement device. We designed and developed a software simulator and an experimental setup for the reconstruction of atmospheric turbulence-phase fluctuations as well as an adaptive optical system for the compensation of induced aberrations. Both systems use two 60 mm, 92-channel, bimorph deformable mirrors and two tip-tilt correctors. The wavefront is measured using a high-speed Shack–Hartmann wavefront sensor based on an industrial CMOS camera. The system was able to achieve a 500 Hz correction frame rate, and the amplitude of aberrations decreased from 2.6 μm to 0.3 μm during the correction procedure. The use of the tip-tilt corrector allowed a decrease in the focal spot centroid jitter range of 2–3 times from ±26.5 μm and ±24 μm up to ±11.5 μm and ±5.5 μm. Full article

System architecture was developed to solve the issues of short pupil distance and mismatch between the simulated wavelength range and the sensor in the simulator of small targets in space. The system consists of Liquid Crystal on Silicon (LCOS), a Polarizing Beam Splitter (PBS), a dual free-form surface-illumination system, and a long-exit-pupil-distance projection system. The innovatively designed long exit pupil distance projection system can achieve an exit pupil distance of 1250 mm, covering the visible and near-infrared bands from 400 to 950 nm. The dual free-form surface-illumination system reaches a divergence angle of ±4.3° and an illumination non-uniformity of 4.7%. Experimental validation shows that the system’s star position error is better than −3.94″, and the angular distance error between stars does not exceed −7.69″. The radiation simulation accuracy for stars ranging from magnitude 3 to 6 is between −0.049 and 0.085 magnitudes, demonstrating high-precision simulation capabilities for both geometric and radiation characteristics. The research results set a critical theoretical foundation for the development of high-fidelity space target simulators, and the proposed dual free-form surface-design method and wide-spectrum aberration compensation technology provide a new paradigm for precision optical system design. Full article

Conventional metalenses struggle with chromatic aberration and narrow field of view (FOV), making it challenging to meet the dispersion requirements for large apertures and compensate off-axis aberrations for wide FOV. Here, we demonstrate a hybrid metalens module consisting of five refractive plastic lenses and a polarization-insensitive metalens to achieve broadband achromatic imaging within 400–700 nm and a wide FOV up to 100°. The system exhibits negligible variation in focal length (~1.2%) across the visible range (460–656 nm) and consistently achieves modulation transfer function (MTF) values > 0.2 at 167 lp/mm across all wavelengths and incident angles. We also demonstrate integrated lens modules that capture high-quality images from distances ranging between 0.5 and 4 m without post-processing, showcasing its potential for compact, wide-angle optical systems. Full article

We present a single-capture multimodal bright-field (BF) and quantitative phase imaging (QPI) approach that enables the analysis of large, connected, or extended samples, such as confluent cell layers or tissue sections. The proposed imaging concept integrates a fiber-optic Mach–Zehnder interferometer-based off-axis digital holographic microscopy (DHM) with an inverted commercial optical BF microscope. Utilizing 8-bit grayscale dynamic range multiplexing, we simultaneously capture both BF images and digital holograms, which are then demultiplexed numerically via Fourier filtering, phase aberration compensation, and weighted image subtraction procedures. Compared to previous BF-DHM systems, our system avoids synchronization challenges caused by multiple image recording devices, improves acquisition speed, and enhances versatility for fast imaging of large, connected, and rapidly moving samples. Initially, we perform a systematic characterization of the system’s multimodal imaging performance by optimizing numerical as well as coherent and incoherent illumination parameters. Subsequently, the application capabilities are evaluated by multimodal imaging of living cells. The results highlight the potential of single-capture BF-DHM for fast biomedical imaging. Full article

Optical aberrations represent a critical issue for gravitational wave interferometers, as they impact the stability and controllability of the experiment. In the next generation of detectors, the circulating power in the cavity arms is expected to increase by up to a factor of 20 compared to current ones. This significant increase makes the mitigation of power-dependent optical aberrations extremely challenging. In this paper, we describe the problem of absorption in the optics and its role in generating some of the most important wavefront distortions, along with the present compensation strategy. To meet the new stringent requirements, new technologies must be designed, and existing ones upgraded. We present a review of the strategies and concepts in the field of aberration control in gravitational wave detectors and discuss the challenges for future detectors like the high-power operation of the Einstein Telescope. Full article

The deformation of the image plane due to gravity, clamping forces, and surface shape errors can significantly impact the exposure accuracy and imaging quality of the doubly telecentric projection optical system. To address the issues of resolution and image quality degradation resulting from non-conjugate image planes, this paper proposes a high-precision method for compensating image plane deformation using a dual-prism approach, establishes an analytical compensation model, and the theoretical derivation and quantification of the effects of compensation devices on image plane defocus, tilt, and aberration are provided. Compared to traditional simulation methods, the proposed approach offers a more predictable and precise compensation framework. The optimized design of the dual-prism compensation device has been validated through simulations, demonstrating the ability to control image plane deformation within 3.011 µm, which is smaller than the system’s depth of focus. The results indicate that this method significantly enhances the imaging accuracy of doubly telecentric projection optical systems and presents a novel theoretical tool for optimizing the design of optical compensation devices, thereby advancing the development of high-precision optical compensation technologies. Full article

A photovoltaic-thermal side-absorption concentrated module (PT-SACM) based on spectrum division for photovoltaic-thermal hybrid applications is carried out. In order to reduce the absorption by materials and the axial-chromatic aberration caused by the transmissive optical system and to improve the performance of the entire system, a reflective system, the parabolic mirror array, fabricated by the ultra-precision diamond turning technology, is proposed herein. For the purposes of spectrum division, thinner volume, lightweight, and wide acceptance angle, the proposed module is designed with a diffraction optical element (DOE), a light-guide plate with a micro-structure array and a parabolic mirror array. Among them, the DOE can separate the solar spectrum into the visible band, which is converted to electrical energy via photovoltaics, and the infrared band, whose thermal energy is collected. Experimental measurements show that the overall optical efficiency of the entire system reached 38.32%, while a deviation percentage of 3.5% is calculated based on the simulation. The system has successfully demonstrated the separation of visible and infrared bands of the solar spectrum. Meanwhile, the lateral displacement between the micro-structures of the light-guide plate and the focus of the parabolic mirror array can be used to compensate for the angular deviation of the sun incidence, thereby achieving wide-angle acceptance via the proposed solar concentration system. Full article

Metalenses have excellent modulation capabilities in terms of phase, amplitude, and polarization of light, significantly reducing the size and complexity of imaging systems, and showing great application prospects. However, like traditional optical meta-atoms, ordinary metalenses suffer from a significant chromatic aberration problem because it is difficult to design the phase distribution for different wavelengths on a single-layer metalens. To address this, various methods for correcting chromatic aberration in metalenses have been proposed and demonstrated, such as spatial multiplexing, material hybridization, and increasing the cross-sectional diversity of metalens meta-atoms. In this paper, a novel design method is used, which expands the parameter space by increasing the cross-sectional diversity of the metalens meta-atoms to provide the phase required for focusing different wavelengths, combined with particle swarm optimization for phase compensation. The multi-level metalens designed by this method achieves a constant and approximate focal length in the visible wavelength range of λ = 450–650 nm, with a polarization-independent absolute focusing efficiency of about 17%, and a numerical aperture (NA) of 0.31 for a lens diameter of 100 μm. This improves the imaging quality. Full article

The pathogenic mechanisms of severe aplastic anemia (SAA) in children are not completely elucidated. The insufficiency of the bone marrow microenvironment, in which mesenchymal stem cells (MSCs) are an important element, can be a potential factor associated with hematopoietic impairment in SAA. In the present study, we compared bone marrow MSCs from five children with SAA and five controls. We found a higher intensity of senescence-associated β-galactosidase activity in SAA MSCs, indicating the increased senescence in these cells. Further RNA sequencing analysis identified a distinctive profile of transcriptomes in SAA MSCs. After conducting a survey of the differentially expressed genes, we found that the up-regulated expression of TXNIP may compromise the proliferative potential of MSCs and probably relate to the pathogenesis of SAA. These results were validated by qPCR. To explore the molecular mechanism involving aberrant TXNIP regulation in SAA MSCs, the expression levels of IGF-1 and IGFBP-1 were measured. A significant increase in IGFBP-1 expression was noted in SAA MSCs despite the wide range of IGF-1 expressions. Accordingly, we postulated a novel pathogenic mechanism of SAA: a compensated increase in the expression of IGF-1 in MSCs to down-regulate TXNIP expression in the face of SAA, which is offset by the up-regulated expression of IGFBP-1. Full article

Free Space Optical (FSO) communication is extensively utilized in the telecommunication industry for both ground and space wireless links, as well as last-mile applications, as a result of its lesser Bit Error Rate (BER), free spectrum, and easy relocation. However, atmospheric turbulence, also known as Wavefront Aberration (WA), is considered a serious issue because it causes higher BER and affects coupling efficiency. In order to address this issue, a Sensor-Less Adaptive Optics (SLAO) system is developed for FSO to enhance performance. In this research, the compensation of WA in SLAO is obtained by proposing the Brownian motion and Directional mutation scheme-based Coati Optimization Algorithm, BDCOA. Here, the BDCOA is developed to search for an optimum control signal value of actuators in Deformable Mirror (DM). The incorporated Brownian motion and directional mutation are used to avoid the local optimum issue and enhance search space efficiency while searching for the control signal. Therefore, the dynamic control signal optimization for DM using BDCOA helps to enhance the coupling efficiency. Thus, the WAs are compensated for and optical signal concentration is enhanced in FSO. The metrics used for analyzing the BDCOA are Root Mean Square (RMS), BER, coupling efficiency, and Strehl Ratio (SR). The existing methods, such as Simulated Annealing (SA) and Stochastic Parallel Gradient Descent (SPGD), Advanced Multi-Feedback SPGD (AMFSPGD), and Oppositional-Breeding Artificial Fish Swarm (OBAFS), are used for evaluating the performance of BDCOA. The RMS of BDCOA for iterations 500 is 0.12, which is less than that of the SA-SPGD and OBAFS. Full article

The optical remote sensors carried by the Jilin-1 KF02 series satellites have an imaging resolution better than 0.5 m and a width of 150 km. There are radiometric problems, such as stripe noise, vignetting, and inter-slice chromatic aberration, in their raw images. In this paper, a relative radiometric correction method based on temperature normalization is proposed for the response characteristics of sensors and the structural characteristics of optical splicing of Jilin-1 KF02 series satellites cameras. Firstly, a model of temperature effect on sensor output is established to correct the variation of sensor response output digital number (DN) caused by temperature variation during imaging process, and the image is normalized to a uniform temperature reference. Then, the horizontal stripe noise of the image is eliminated by using the sensor scan line and dark pixel information, and the vertical stripe noise of the image is eliminated by using the method of on-orbit histogram statistics. Finally, the method of superposition compensation is used to correct the vignetting area at the edge of the image due to the lack of energy information received by the sensor so as to ensure the consistency of the image in color and image quality. The proposed method is verified by Jilin-1 KF02A on-orbit images. Experimental results show that the image response is uniform, the color is consistent, the average Streak Metrics (SM) is better than 0.1%, Root-Mean-Square Deviation of the Mean Line (RA) and Generalized Noise (GN) are better than 2%, Relative Average Spectral Error (RASE) and Relative Average Spectral Error (ERGAS) are greatly improved, which are better than 5% and 13, respectively, and the relative radiation quality is obviously improved after relative radiation correction. Full article
