To address the inefficiencies of traditional numerical simulations and the high cost of experimental validation in the aerodynamic–stealth integrated design of S-shaped inlets for aero-engines, this study proposes a novel parameter prediction model based on a fuzzy C-means (FCM) clustering and nonlinear dynamic adaptive particle swarm optimization-enhanced radial basis function neural network (NDAPSO-RBFNN). The FCM algorithm is applied to reduce the feature dimensionality of aerodynamic parameters and determine the optimal hidden layer structure of the RBF network using clustering validity indices. Meanwhile, the NDAPSO algorithm introduces a three-stage adaptive inertia weight mechanism to balance global exploration and local exploitation effectively. Simulation results demonstrate that the proposed model significantly improves training efficiency and generalization capability. Specifically, the model achieves a root mean square error (RMSE) of $3.81\times {10}^{-8}$ on the training set and $8.26\times {10}^{-8}$ on the test set, demonstrating robust predictive accuracy. Furthermore, $98.3\%$ of the predicted values fall within the $y=x\pm 3\beta$ confidence interval ($\beta =1.2\times {10}^{-7}$). Compared with traditional PSO-RBF models, the number of iterations of NDAPSO-RBF network is lower, the single prediction time of NDAPSO-RBF network is shorter, and the number of calls to the standard deviation of the NDAPSO-RBF network is lower. These results indicate that the proposed model not only provides a reliable and efficient surrogate modeling method for complex inlet flow fields but also offers a promising approach for real-time multi-objective aerodynamic–stealth optimization in aerospace applications. Full article

Aircraft, as electromagnetically complex targets, have radar cross-sections (RCSs) that are influenced by various factors, with the inlet duct being a critical component that often serves as a primary source of electromagnetic scattering, significantly impacting the scattering characteristics. In light of the conflict between aerodynamic performance and electromagnetic characteristics in the design of aircraft engine inlet grilles, this paper proposes a metasurface radar-absorbing inlet grille (RIG) solution based on a NACA symmetric airfoil. The RIG adopts a sandwich structure consisting of a polyethylene terephthalate (PET) dielectric substrate, a copper zigzag metal strip array, and an indium tin oxide (ITO) resistive film. By leveraging the principles of surface plasmon polaritons, electromagnetic wave absorption can be achieved. To enhance the design efficiency, a multi-objective Bayesian optimization framework driven by the expected hypervolume improvement (EHVI) is constructed. The results show that, compared with a conventional rectangular cross-section grille, an airfoil-shaped grille under the same constraints will reduce both aerodynamic losses and the absorption bandwidth. After 100-step EHVI–Bayesian optimization, the optimized balanced model attains a 57.79% reduction in aerodynamic loss relative to the rectangular-shaped grille, while its absorption bandwidth increases by 111.99%. The RCS exhibits a reduction of over 8.77 dBsm in the high-frequency band. These results confirm that the proposed optimization design process can effectively balance the conflict between aerodynamic performance and stealth performance for RIGs, reducing the signal strength of aircraft engine inlets. Full article

Flying wing Unmanned Aerial Vehicles (UAVs) are an interesting flight configuration, considering its benefits over aerodynamic, structural and added stealth aspects. The existing configurations are thoroughly studied from the literature survey and useful observations with respect to design and analysis are obtained. The proposed design method includes distinct calculations of the UAV and modelling using 3D experience. The created innovative models are simulated with the help of computational fluid dynamics techniques in ANSYS Fluent to obtain the aerodynamic parameters such as forces, pressure and velocity. The optimization process continues to add more desired modifications to the model, to finalize the best design of flying wing frame for the chosen application and mission profile. In total, nine models are developed starting with the base model, then leading to the conventional, advanced and nature inspired configurations such as the falcon and dragonfly models, as it has an added advantage of producing high maneuverability and lift. Following this, fluid structure interaction analysis has been performed for the best performing configurations, resulting in the determination of variations in the structural behavior with the imposition of advanced composite materials, namely, boron, Kevlar, glass and carbon fiber-reinforced polymers. In addition to this, a hybrid material is designed by combining two composites that resulted in superior material performance when imposed. Control dynamic study is performed for the maneuvers planned as per mission profile, to ensure stability during flight. All the resulting parameters obtained are compared with one another to choose the best frame of the flying wing body, along with the optimum material to be utilized for future analysis and development. Full article

To address the challenge of evaluating a radar cross-section (RCS) for a non-cooperative aircraft with limited aerodynamic shape information, this paper presents a multi-source, data-driven inverse reconstruction method. This approach integrates data fusion techniques to facilitate an initial shape reconstruction, followed by an iterative optimization process that utilizes computational fluid dynamics (CFD) to enhance the shape, accounting for the aerodynamic performance. Additionally, an inverse deduction analysis is effectively employed to ascertain the characteristics of the power system, leading to the design of a double S-curved tail nozzle layout with stealth capabilities. An aerodynamic analysis demonstrates that at Mach 0.6, the lift-to-drag ratio peaks at 27.3 for the attack angle of 4°, after which it declines as the angle increases. At higher angles of attack, complex flow separation occurs and expands with the increasing angle. The electromagnetic simulation results indicate that under vertical polarization, the omnidirectional RCS reaches its peak as the incident angle is deflected downward by 10° and reduces with the growth of the angle, demonstrating angular robustness. Conversely, under horizontal polarization, the RCS is more sensitive to edge-induced rounding. The findings illustrate that this methodology enables accurate shape modeling for non-cooperative targets, thereby providing a fairly solid basis for stealth performance evaluation and the assessment of surprise effectiveness. Full article

The design of the flying wing airfoil must consider aerodynamic stealth and trim requirements, with their coupling exacerbating the complexity of the design problem by introducing multiple local minimum points in design space. In addition, it would need a broad space with high dimensionality to obtain the ideal result, and expansion of design space could lead to more local minimum points, causing significant challenges to traditional optimization design methods. A Two-Stage Global–Local Constrained Optimization Method (TGLCOM) was proposed to address these issues. The parametric space was divided into a large-scale global space and a high-dimensional local space. A surrogate-based global constrained optimization method was applied in the large-scale global space, followed by a gradient-based algorithm in the high-dimensional local space to refine the design and obtain the global optima. The efficiency and robustness of the proposed TGLCOM were verified through the airfoil and flying wing layout aero/stealth design. The results indicated a minor conflict between the RCS drag and pitch moment performance. Moreover, the stealth design of the airfoil improved the stealth performance of the flying wing layout in both the yaw and pitch directions. Full article

The conceptual design of unmanned aerial vehicles (UAVs) presents significant multidisciplinary challenges requiring the optimization of aerodynamic and structural performance, stealth, and propulsion efficiency. This work addresses these challenges by integrating deep neural networks with a multiobjective genetic algorithm to optimize UAV configurations. The proposed framework enables a comprehensive evaluation of design alternatives by estimating key performance metrics required for different operational requirements. The design process resulted in a significant improvement in computational time over traditional methods by more than three orders of magnitude. The findings illustrate the framework’s capability to optimize UAV designs for a variety of mission scenarios, including specialized tasks such as intelligence, surveillance, and reconnaissance (ISR), combat air patrol (CAP), and Suppression of Enemy Air Defenses (SEAD). This flexibility and adaptability was demonstrated through a case study, showcasing the method’s effectiveness in tailoring UAV configurations to meet specific operational requirements while balancing trade-offs between aerodynamic efficiency, stealth, and structural weight. Additionally, these results underscore the transformative impact of integrating AI into the early stages of the design process, facilitating rapid prototyping and innovation in aerospace engineering. Consequently, the current work demonstrates the potential of AI-driven optimization to revolutionize UAV design by providing a robust and effective tool for solving complex engineering problems. Full article

Modern fighter aircraft increasingly need to conjugate aerodynamic performance and low observability. In this paper, we showcase a methodology for a gradient-based bidisciplinary aero-stealth optimization. The shape of the aircraft is parameterized with the help of a CAD modeler, and we optimize it with the SLSQP algorithm. The drag, computed with the help of a RANS method, is used as the aerodynamic criterion. For the stealth criterion, a function is derived from the radar cross-section in a given cone of directions and weighed with a function whose goal is to cancel the electromagnetic intensity in a given direction. Stealth is achieved passively by scattering back the electromagnetic energy away from the radar antenna, and no energy is absorbed by the aircraft, which is considered as a perfect conductor. A Pareto front is identified by varying the weights of the aerodynamic and stealth criteria. The Pareto front allows for an easy identification of the CAD model corresponding to a chosen aero-stealth trade-off. Full article

The airfoil is the foundation of an aircraft, and its characteristics have a significant impact on those of the aircraft. Conventional airfoil design mainly focuses on improving aerodynamic performance, while flying wing airfoil designs should also consider layout stability and stealth performance. The design requirements for an airfoil vary with its position on the flying wing layout aircraft based on corresponding spanwise flow field characteristics. By analyzing the spanwise flow characteristics of the flying wing, partition design models for flying wing airfoils were established in this study, and a series of flying wing airfoil designs that consider aerodynamics and aerodynamic/stealth were implemented. Then, the designed airfoils were configured on a three-dimensional X-47B layout for testing and verification. The results showed that the aerodynamic design and the aerodynamic/stealth design exhibited significant improvements in terms for aerodynamic and longitudinal trimming characteristics. However, the cruise drag performance of the aerodynamic/stealth design was slightly worse than that of the aerodynamic design, although the longitudinal moment trimming characteristics were basically the same. The stealth characteristics of the aerodynamic/stealth design had significant advantages, indicating that there were weak contradictions between the aerodynamic, stealth, and trimming requirements in the design of the flying wing. Full article

Aerodynamic/stealth optimization is a key issue during the design of a stealth UAV. Balancing the weight of different incident angles of the RCS and combining stealth characteristics with aerodynamic characteristics are hotspots of aerodynamic/stealth optimization. To address this issue, this paper introduces a radar detection probability model to solve the weight balance problem of incident angles of the RCS and a penetration efficiency model to transfer the multi-object optimization into single-objective optimization. In this paper, a parameterized model of a flying-wing UAV is selected as the research object. A gradient-free optimization algorithm based on the genetic algorithm is used for maximizing efficiency. The optimization model balances the influence of the RCS mean value and RCS peak value on stealth performance. Moreover, the model achieves an optimal entire life cycle penetration efficiency coefficient by balancing aerodynamic and stealth optimization. The results show that the optimized model improves the penetration efficiency coefficient by 13.84% and increases maximum flight sorties by 1.8%. These results prove that the model has a reasonable combination of aerodynamic and stealth optimization for UAVs undertaking penetration missions. Full article

Intake is not only the main air supply component of an aircraft, but also one of the forward radar scattering sources. The aerodynamic and stealth performance of intake is critical to the serviceability of advanced fighter aircrafts. The effects of baffle boards with different configurations on the performance of the caret intake with a double S-duct diffuser are presented in this article. The multi-level fast multipole method (MLFMM) and the SST k-ω turbulence model were respectively used to calculate the surface current and the flow field. It was found that the average RCS value of intake can be effectively reduced by installing the baffle board with vertical orientation in the front diffuser, with the DC60 value and the loss of outlet total pressure both increased slightly. The boundary layer separation and the RCS characteristics of intake were closely related to the configuration of the corrugated baffle board. Compared with the traditional curved board, by installing the corrugated board with optimized corrugation number and shape, the stealth performance of intake can be further improved, and the loss of aerodynamic performance can be also reduced. Full article

The use of traditional optimization methods in engineering design problems, specifically in aerodynamic and infrared stealth optimization for engine nozzles, requires a large number of objective function evaluations, therefore introducing a considerable challenge in terms of time constraints. In this paper, this limitation is addressed by using a sample-efficient multi-objective Bayesian optimization that takes Kriging as a surrogate model and Expected Hypervolume Improvement as the infill criterion. Using this approach, the probabilistic model is continuously established and updated, and the approximate Pareto front is obtained at a relatively small computational budget. The objective of this work is to evaluate the applicability of employing a multi-objective Bayesian optimization framework for the aerodynamic-infrared shape optimization of an elliptical double serpentine nozzle at 6 km flight condition, where the objective functions are evaluated by means of high-fidelity computational fluid dynamics and reversed Monte Carlo ray tracing simulations. We achieve good results in both infrared radiation signature reduction and aerodynamic performance improvement with a reasonable number of evaluations, indicating that the proposed method is effective and efficient for tackling the computationally intensive optimization challenges in the aircraft design. Full article

In the overall design process of the turbofan engine, it has become crucial to address the challenge of selecting design parameters that not only meet the flight thrust demand but also enhance engine economy. As the demand for stealth performance in future fighter aircraft increases, it becomes imperative to consider infrared stealth indicators during the design process. The adaptive cycle engine possesses an adjustable thermal cycle, necessitating careful attention to the selection of design parameters to fulfill the requirements. Therefore, this paper proposes a multi-objective optimization design method for the adaptive cycle engine that integrates infrared stealth technology. Initially, the parameter cycle model of the adaptive cycle engine is established based on the principles of aerodynamic and thermodynamic calculations. Subsequently, the model incorporates a serpentine two-dimensional (2-D) exhaust system to achieve infrared suppression. Meanwhile, a method for predicting the infrared characteristics is proposed to calculate the infrared radiation intensity of the engine exhaust system. Finally, the sequential quadratic programming algorithm is applied to comprehensively optimize the engine’s performance. The simulation results reveal that the multi-objective optimization design can effectively select appropriate design parameters to im-prove the engine, thereby reducing fuel consumption while meeting thrust requirements. This approach combines the consideration of infrared stealth technology with the optimization of engine performance, thus contributing to the development of advanced adaptive cycle engines. Full article

Quantum radar is a novel detection method that combines radar and quantum technologies. It exceeds the detection threshold and poses a threat to conventional stealth targets. This work aims to derive the expression of the quantum radar cross-section of a new complex target. The calculation formula of QRCS was derived after introducing the relative photon parameters and vector dot product. Subsequently, a comprehensive optimization model of quantum stealth and lift–drag ratio based on a genetic algorithm was proposed for the waverider warhead. During the optimization process, we proposed an optimization method with the objective function of the QRCS pioneering design value and achieved better outcomes than the optimization method using the average value in terms of QRCS performance and lift–drag ratio in the important azimuths of the waverider. By changing the design variables of the waverider warhead and using this new optimization method, the QRCS of the waverider in the forward and lateral angles were minimized, remarkably improving the aerodynamic performance of the waverider. Similarly, the optimization results show that the proposed design value optimization method is feasible. Full article

To study the influence of the tilt-back design of a vertical tail on its aerodynamic stealth characteristics, an optimization method based on a quantitative weight coefficient and a two-particle search algorithm is presented. When the aerodynamic performance of the vertical tail is optimized separately, the reduction in the drag index is obvious, and the optimal solution appears at the boundary of the backward-tilt range. The optimal solution of separate stealth optimization is different from that of separate aerodynamic optimization within the given range of tilt back. The two-particle search algorithm can provide an optimal solution for comprehensive performance optimization under different weight coefficient distributions, where the fitness index, aerodynamic index, and radar cross-section index are all significantly reduced. The presented optimization method is effective for optimizing the aerodynamic stealth performance of the vertical tail. Full article

An ultra wideband (UWB) radar cross-section (RCS) reduction metasurface has received attention in recent years. However, the majority of the research has concentrated on the physics and design of planar surfaces, which do not meet the standards of modern aerodynamics and aesthetics. In this paper, we offer a sophisticated strategy for designing a metasurface that can conform to the shape of any object, even those of moderate curvature, and can also achieve UWB RCS reduction by combining absorption, polarization conversion, and diffusion mechanisms. Firstly, an absorbing-polarization converter is designed, composed of a square patch with a truncated diagonal strip and ring. A thin Rogers RT/Duroid 5880 dielectric substrate layer is used in the structure, which is also appropriate for conformal conditions. The substrate layer and the ground plane are separated by an air gap to enhance the polarization conversion bandwidth (PCBW). For normal incident electromagnetic (EM) waves, the PCBW ranges from 10.8 to 31.3 GHz with polarization conversion ratio (PCR) values greater than 0.9 dB. Up to a 45${}^{\circ }$ oblique incidence angle over the aforementioned band, the PCR efficiency is well maintained. Then, the optimized coding metasurface is formed by the Pancharatnam–Berry (PB) phase, consisting of meta-atoms “0” and “1” of the same size but different orientations, to realize the concept of cross-polarization diffusion. A theoretical investigation has been performed to analyze the RCS reduction performance of planar as well as conformal cylindrical surfaces. The results show that more than 10 dB of RCS reduction is experienced over UWB (10.8–31.3 GHz) for planar metasurfaces under linearly and circularly polarized incidence waves. Furthermore, the RCS reduction for cylindrical surfaces can be achieved in a similar frequency band above 10 dB up to an angle of 90${}^{\circ }$. It can be deduced that our proposed flexible metasurface can be used as an absorber or a polarization converter and provide broadband RCS reduction, which is essential for multi-function and conformal stealth applications. Full article
