Dynamic Line Rating (DLR) is increasingly important for maximizing capacity of existing overhead transmission lines. Conventional thermal rating methods, such as IEEE 738 and model conductors as single, isothermal cylinders and offer limited guidance for multi-conductor bundles, not fully capturing the complex aerodynamic and thermal interactions present in high-voltage networks. This study addresses these limitations by presenting a high-fidelity, two-dimensional coupled thermal-fluid model developed in COMSOL Multiphysics 4.3b. Single and bundled configurations (two-conductor, three-conductor and four-conductor) are analyzed under steady-state conditions using the Shear Stress Transport (SST) turbulence model, accounting for sub-conductor spacing, wind speed, and interactions between temperature distribution and airflow. Simulation results are compared with ampacity calculations from relevant standards to evaluate limitations of simplified models. Results show that leeward conductors reach temperatures up to ~4 °C higher than windward conductors, forming the thermal bottleneck, with peak temperatures of ~103.3 °C versus ~99 °C for single conductors. For bundled conductors, the current required to keep the maximum temperature at 100 °C was calculated, and this value was found to be approximately 3% lower than the current predicted by IEEE 738. The study emphasizes the importance of multiphysics, position-aware simulations to prevent overloading and optimize transmission line utilization. Full article

The status of an optic–electric composite high-voltage submarine cable (referred to as submarine cable) can be monitored based on optical fiber-distributed sensing technology, and at the same time, no additional sensor is needed in the monitoring system. Currently, this technology is widely used in submarine cable monitoring systems. To estimate the temperatures of conductor and XLPE (cross-linked polyethylene) insulation of the submarine cable based on the ambient temperature and optical fiber temperature, the thermoelectric coupling field model of the 110 kV single-core submarine cable is established and validated. The thermoelectric coupling field models of the submarine cable with different values of ambient temperature and ampacity are built, and the influence of ambient temperature and ampacity on the temperatures of conductor, insulation and optical fiber is investigated. Furthermore, the relationship between the temperatures of the conductor and insulation and the ambient temperature and optical fiber temperature is obtained. Then, estimation formulas for temperatures of conductor and insulation of submarine cable according to ambient temperature and optical fiber temperature are obtained and preliminarily validated. This work lays the foundation for condition evaluation of the submarine cable insulation, life expectancy and maximum allowable ampacity estimation. Full article

Determining reliable cable ampacities for marine High Voltage Cables is currently the subject of significant industry and academic reassessment in order to optimize (maximizing load while maintaining safe operating temperatures) design and reduce costs. Ampacity models can be elaborate, and inaccuracies are increasingly predicated on the uncertainty in environmental inputs. A stark example is the role of ambient temperature at cable depth, which, due to the scale of cables and the inaccessibility of the seafloor, is commonly estimated at 15 °C. Oceanographic models incorporating ocean bottom temperature are increasingly available, and they achieve coverage and spatiotemporal resolutions for cable applications without the requirement for project specific measurements. Here, a rudimental validation of the AMM15 and AMM7 mean monthly ocean bottom temperature models for the NW European Shelf indicates encouraging accuracies (MBE ≤ 1.48 °C; RMSE ≤ 2.2 °C). A series of cable case studies are used to demonstrate that cable ratings can change between −4.1% and +7.8% relative to ratings based on a common static (15 °C) ambient temperature value. Consideration of such variations can result in both significant ratings (and hence capital expenditure and operating costs) gains and/or the avoidance of cable overheating. Consequently, validated modelled ocean bottom temperatures are deemed sufficiently accurate, providing incomparable coverage and spatiotemporal resolutions of the whole annual temperature signal, thereby facilitating much more robust ambient temperatures and drastically improving ampacity estimates. Full article

The purpose of this research is to correctly model steady-state heat transfer in and around rectangular bus bars installed horizontally in an indoor environment and to estimate the corresponding ampacities, considering the effects of horizontal transverse vibrations caused by electromagnetic forces. This thermo-electro-magneto-mechanical problem is solved analytically using correlations determined experimentally by other researchers, while the accuracy of the obtained results is verified numerically using the finite element method (FEM). The novelties of the developed model are as follows. First, modeling the effects of horizontal transverse vibrations on free convection from the top and bottom surfaces of rectangular bus bars via forced convection for different characteristic lengths. Second, modeling the effects of vibration amplitudes and vibration frequencies on the bus bar ampacity. Third, introducing the existing vibration classes (A, B, and C) into the analytical and FEM-based thermal analyses. The results show that with an increase either in the vibration amplitude or the vibration frequency, there is a greater convection-based dissipation of heat from the bus bars and an increase in their ampacity. Finally, for the standard vibration classes, it is found that the effect of horizontal transverse vibrations on the ampacity can be up to 41.99% for Class C. Full article

Electricity demand has surged over the last several years and will persist in the future. Increased transmission loads cause transmission lines to operate much closer to their security limits, leading to thermal and mechanical stress and thus affecting the transmission reliability and thermal aging. Accordingly, monitoring the conductor temperature over time is critical to identifying power transmission networks that may need extra attention and perhaps maintenance. This paper presents a fuzzy thermal aging model for transmission lines equipped with a fuzzy dynamic thermal rating system based on the IEEE 738 standard. In this framework, the ampacity of the transmission line was calculated. The conductor temperature was computed with the back-calculation method by considering the fully loaded transmission line. The estimated conductor temperature was employed to determine the corresponding conductor fuzzy loss of tensile strength, i.e., the fuzzy annealing degree of the conductor based on the Harvey model. Additionally, a tensile strength loss cost profile is provided. Simulation and numerical results indicate that the proposed framework is robust against various operating conditions of the parameters considered in the study and provides crucial information for managing transmission assets and transmission network operation. Full article

The transfer capabilities of High-Voltage Overhead Lines (HV OHLs) are often limited by the critical power line temperature that depends on the magnitude of the transferred current and the ambient conditions, i.e., ambient temperature, wind, etc. To utilize existing power lines more effectively (with a view to progressive decarbonization) and more safely with respect to the critical power line temperatures, this paper proposes a Dynamic Thermal Rating (DTR) approach using IoT sensors installed on some HV OHLs located in different Italian geographical locations. The goal is to estimate the OHL conductor temperature and ampacity, using a data-driven thermo-mechanical model with the Bayesian probability approach, in order to improve the confidence interval of the results. This work highlights that it could be possible to estimate a space-time distribution of temperature for each OHL and an increase in the actual current threshold values for optimizing OHL ampacity. The proposed model is validated using the Monte Carlo method. Full article

This paper investigates the maximum photovoltaic (PV) penetration limits on both overhead lines and underground cables medium voltage radial distribution system. The maximum PV penetration limit is estimated considering both bus voltage limit (1.05 p.u.) and feeder current ampacity (1 p.u.). All factors affect the max PV penetration limit are investigated in detail. Substation voltage, load percentage, load power factor, and power system frequency (50 Hz or 60 Hz) are analyzed. The maximum PV penetration limit associated with overhead lines is usually higher than the value associated with the underground cables for high substation voltage (substation voltage = 1.05 and 1.04 p.u.). The maximum PV penetration limit decreases dramatically with low load percentage for both feeder types but still the overhead lines accept PV plant higher than the underground cables. Conversely, the maximum PV penetration increases with load power factor decreasing and the overhead lines capability for hosting PV plant remains higher than the capability of the underground cables. This paper proved that the capability of the 60-Hz power system for hosting the PV plant is higher than the capability of 50 Hz power system. MATLAB software has been employed to obtain all results in this paper. The Newton-Raphson iterative method was the used method to solve the power flow of the investigated systems. Full article

Integration of a large number of renewable systems produces line congestions, resulting in a problem for distribution companies, since the lines are not capable of transporting all the energy that is generated. Both environmental and economic constraints do not allow the building new lines to manage the energy from renewable sources, so the efforts have to focus on the existing facilities. Dynamic Rating Management (DRM) of power lines is one of the best options to achieve an increase in the capacity of the lines. The practical application of DRM, based on standards IEEE (Std.738, 2012) and CIGRE TB601 (Technical Brochure 601, 2014) , allows to find several deficiencies related to errors in estimations. These errors encourage the design of a procedure to obtain high accuracy ampacity values. In the case of this paper, two methodologies have been tested to reduce estimation errors. Both methodologies use the variation of the weather inputs. It is demonstrated that a reduction of the conductor temperature calculation error has been achieved and, consequently, a reduction of ampacity error. Full article

This paper verifies the fluctuation on thermal parameters and ampacity of the high-voltage cross-linked polyethylene (XLPE) cables with different insulation conditions and describes the results of a thermal aging experiment on the XLPE insulation with different operating years in different laying modes guided by Comsol Multiphysics modeling software. The thermal parameters of the cables applied on the models are detected by thermal parameter detection control platform and differential scanning calorimetry (DSC) measurement to assure the effectivity of the simulation. Several diagnostic measurements including Fourier infrared spectroscopy (FTIR), DSC, X-ray diffraction (XRD), and breakdown field strength were conducted on the treated and untreated specimens in order to reveal the changes of properties and the relationship between the thermal effect and the cable ampacity. Moreover, a new estimation on cable ampacity from the perspective on XLPE insulation itself has been proposed in this paper, which is also a possible way to judge the insulation condition of the cable with specific aging degree in specific laying mode for a period of time. Full article
