Search Results (61)

A pulse generator capable of outputting quasi-square-wave pulses at the hundred-nanosecond scale is designed. With the development of high-power microwaves, the pulse flat-top is required to be more and more stable. However, at the hundred-nanosecond scale, an equal-value pulse-forming network is prone to being affected by stray parameters in the output waveform. To meet this requirement, a Marx generator and an anti-resonant network is used as the pulse boosting component and the pulse modulation component, respectively. Taking advantage of the anti-resonant network’s fewer sections and good modulation effect, the output waveform of the Marx generator is improved. The modulation ability of two-section and three-section modulation networks on waveforms, the output characteristics of two-section modulation networks, and the effect of stray parameters on the modulation network are explored. The experimental results show that both networks were able to achieve a quasi-square waveform of 100 kV on a 50 Ω load. Compared to the two-section network (165 ns pulse width, 41 ns rise time, 54.54% waveform flatness), the proposed three-section network achieves a pulse width of 185 ns with faster rise time (25 ns) and better waveform flatness (63.78%). Both topologies generate 100 kV quasi-square pulses on 50 Ω loads, with the three-section design demonstrating superior waveform control. In the repetition experiment, the pulse power source achieved stable operation at a repetition frequency of 20 Hz, and a quasi-square waveform with an output voltage of 100 kV was obtained. Finally, compared with previous studies, the modulated Marx generator based on an anti-resonant network has better waveform modulation effect and fewer network sections when generating a Square wave pulse of 100–200 ns. Full article

This study presents the successful fabrication of lead zirconate titanate (PZT) thin films on silicon (Si) substrates using a hybrid deposition method combining spin-coating and RF sputtering techniques. Initially, a PZT layer was deposited through four successive spin-coating cycles, followed by an additional layer formed via RF sputtering. The resulting multilayer structure was annealed at ${700 }^{°}$C for 2 h to improve crystallinity. Comprehensive material characterization was conducted using XRD, SEM, cross-sectional SEM, EDX, and UV–VIS absorbance spectroscopy. The analyses confirmed the formation of a well-crystallized perovskite phase, a uniform surface morphology, and an optical band gap of approximately 3.55 eV, supporting its suitability for sensing applications. Building upon these findings, a multilayer PZT-based touch sensor was fabricated and electrically characterized. Low-frequency I–V measurements demonstrated consistent and repeatable polarization behavior under cyclic loading conditions. In addition, $\left|Z\right|$–f measurements were performed to assess the sensor’s dynamic electrical behavior. Although expected dielectric responses were observed, the absence of distinct anti-resonance peaks suggested non-idealities linked to ${\mathrm{Ag}}^{+}$ ion diffusion from the electrode layers. To account for these effects, the classical Butterworth–Van Dyke (BVD) equivalent circuit model was extended with additional inductive and resistive components representing parasitic pathways. This modified model provided excellent agreement with the measured impedance and phase data, offering deeper insight into the interplay between material degradation and electrical performance. Overall, the developed sensor structure exhibits strong potential for use in piezoelectric sensing applications, particularly for tactile and pressure-based interfaces. Full article

In the continuous drilling process of oil wells, to achieve the efficient screening of drilling fluids by the vibrating screen while ensuring the safety of the screening operation, an anti-resonance system driven by two exciters with triple-frequency (denoted as 3:1 frequency ratio) is proposed. Initially, differential motion equations are formulated utilizing Lagrange’s equation, followed by the definition of vibration isolation coefficients adopting ratios. Triple-frequency synchronization and stability criterion between two eccentric blocks are subsequently elucidated via the asymptotic method and Routh–Hurwitz criterion. Concurrently, the effects of structural parameters on vibration isolation capacity, steady-state trajectory, and the triple-frequency synchronization phase are investigated through numerical computation. Ultimately, the reliability of the theoretical study is corroborated by simulation analysis. Results indicate that under the allowable system parameters for the practical project, the amplitude of the vibration body can exceed three times that of the isolation body; the two solutions of the stable phase difference (SPD) are different by π, one of which is stable and the other is unstable, and the stability of phase difference is determined by the sign of the stability coefficient. This work is useful for developing new vibrating screens and other multi-frequency vibration machines. Full article

In this paper, an all-fiber light-induced thermoelastic spectroscopy (LITES) sensor based on hollow-core anti-resonant fiber (HC-ARF) and self-designed low-frequency quartz tuning fork (QTF) is reported for the first time. By utilizing HC-ARF as both the transmission medium and gas chamber, the laser tail fiber was spatially coupled with the HC-ARF, and the end of the HC-ARF was directly guided onto the QTF surface, resulting in an all-fiber structure. This design eliminated the need for lens combinations, thereby enhancing system stability and reducing cost and size. Additionally, a self-designed rectangular-tip QTF with a low resonant frequency of 8.69 kHz was employed to improve the sensor’s detection performance. Acetylene (C₂H₂), with an absorption line at 6534.37 cm⁻¹ (1.53 μm), was chosen as the target gas. Experimental results clearly demonstrated that the detection performance of the rectangular-tip QTF system was 2.9-fold higher than that of a standard commercial QTF system. Moreover, it exhibited an outstanding linear response to varying C₂H₂ concentrations, indicating its high sensitivity and reliability in detecting C₂H₂. The Allan deviation analysis was used to assess the system’s stability, and the results indicated that the system exhibits excellent long-term stability. Full article

Non-uniform composite structures for transducers exhibit considerable potential in enhancing impedance matching and efficiency. Here, a functionally graded material composite spherical piezoelectric transducer (FGM-cSPT) is proposed, and a three-port electromechanical equivalent circuit model is established. The correctness of the theoretical model is verified using the finite element method and experiment. Based on the theoretical model, the effects of the non-uniform coefficient and the geometric dimension of FGM-cSPT on the electromechanical vibration characteristics (resonance frequency, anti-resonance frequency, and effective electromechanical coupling coefficient) of the transducer are analyzed. The results show that the non-uniform coefficient and geometric dimension can effectively regulate the vibration characteristics of the FGM-cSPT, which can be used to guide engineering design. Our methodology will offer possibilities for designing FGM-cSPTs and may promote applications in various fields, such as marine exploitation, structural health detection, and energy collection. Full article

In the last decade, substantial progress has been made to improve the performance of optical gyroscopes for inertial navigation applications in terms of critical parameters such as bias stability, scale factor stability, and angular random walk (ARW). Specifically, resonant fiber optic gyroscopes (RFOGs) have emerged as a viable alternative to widely popular interferometric fiber optic gyroscopes (IFOGs). In a conventional RFOG, a single-wavelength laser source is used to generate counter-propagating waves in a ring resonator, for which the phase difference is measured in terms of the resonant frequency shift to obtain the rotation rate. However, the primary limitation of RFOG performance is the bias drift, which can be attributed to nonreciprocal effects such as Rayleigh backscattering, back-reflections, polarization instabilities, Kerr nonlinearity, and environmental fluctuations. In this paper, we review the challenges and opportunities of achieving performance enhancement in RFOGs. Full article

This paper presents a theoretical framework to enhance the prediction of dynamic responses in complex mechanical systems, such as vehicle structures, by incorporating both translational and rotational degrees of freedom. Traditional receptance coupling methods often neglect rotational effects, leading to significant inaccuracies at higher frequencies. Additionally, approaches that implicitly include full dynamics frequently result in redundancy of generalized coordinates, especially at connection points. To address these limitations, the generalized receptance coupling method using Frequency-Based Substructuring is extended to explicitly account for rotational dynamics resulting in a refined GRCFBS approach. This extension enhances both the understanding and prediction of system responses, which are represented through the receptance matrix or Frequency Response Function. Building on Jetmundsen’s foundational work, the proposed framework introduces a practical, generalized formulation that explicitly incorporates full translational and rotational dynamics at each substructure node. This explicit definition provides deeper insights into system behavior, particularly for complex interactions between substructures under weak and strong coupling scenarios at interface points. The Euler–Bernoulli beam theory is employed to model rotational behavior at critical points, yielding reduced-order and explicit receptance matrices for substructures in the coupling process. The methodology’s accuracy and applicability in capturing resonance and anti-resonance modes are validated through two case studies: the coupling of two flexible subsystems and the integration of flexible and rigid components. Results are benchmarked against numerical finite element analysis, and all limitations and potential improvements are discussed. By directly incorporating rotational dynamics directly, this approach enables more reliable dynamic response predictions under multi-directional loading conditions, particularly for vehicle and machinery system design. The GRCFBS method offers a versatile and reliable tool for dynamic system analysis, with significant potential for vibration analysis over a broad frequency range. Full article

Here, we report a numerical study of supercontinuum generation in an antiresonant optical fiber with a hollow core filled with a mixture of deuterium (D₂) and hydrogen (H₂). For 1 ps pulses at a wavelength of 1.03 μm with different chirp values, we demonstrate a possibility of obtaining a mid-IR coherent supercontinuum with a spectral width of 2300 nm, initiated by cascade processes at resonance frequencies of vibrational and rotational levels of D₂ and H₂. We show that an increase in the chirped pulse duration to 25 ps while maintaining the energy and spectral width allows increasing the quantum conversion efficiency in the mid-IR from 10 to 50% and expanding the range of optimal fiber lengths at which a high degree of supercontinuum coherence is achieved. Full article

Assessment of the influence of vibration isolator parameters on the distribution of the system’s natural frequencies is a significant task in the design of vibration isolation systems. The root method was used to determine the natural frequencies of the controlled vibration isolator. For a certain feedback structure of a controlled electrodynamic type vibration isolator, the need for a consistent selection of parameters has been justified. A mathematical solution has been proposed for the approximate determination of the roots of the characteristic equation of the controlled vibration isolator, which enables the analytical assessment of the influence of the vibration isolator parameters on the distribution of its natural frequencies. The research has been conducted in relative parameters, which makes it possible to generalize the results. The specificity of the inertial dynamic vibration isolator, which in some cases is associated with the implementation of anti-resonance conditions, can lead to the fact that resonant frequencies can occur on both sides of the tuning frequency of the vibration isolator. The use of an elastic suspension on flat springs to protect navigation equipment from vibration allows reduction in the intensity of translational vibration, while not changing the orientation of the device relative to the Earth. The implementation of an elastic suspension according to the scheme of the inverted pendulum allows an increase in the effectiveness of vibration isolation, under the conditions of a controlled change of the vibration isolator parameters and due to the use of feedback. The results of this research can be used in precision systems, such as vibration isolators, laser processing equipment, ultraprecision measurements or medical devices. Full article

This research investigates how slitted beams fitted with piezoelectric transducers (PZTs) behave when generating energy from environmental vibrations. By changing slit widths, slit lengths, and tip masses, we investigated the frequency response of these beams using analytical methods and finite element analysis (FEA). The obtained results demonstrate that resonance peaks are brought closer together, and coupling between vibrational modes is enhanced by larger slit spacing, whether or not anti-resonance dips are present, though the magnitudes of these peaks are affected by the width of the slits. The possibility of energy harvesting can be enhanced when resonance peaks are shifted and amplified by heavier tip masses. The FEA results support the analytical model, showing other characteristics such as sharp dips or anti-resonance troughs. This work provides valuable information for future design improvements by highlighting the significance of optimizing slit parameters and tip masses to enhance the efficiency of piezoelectric energy harvesters. This study demonstrates the benefits of using slitted beams with piezoelectric energy harvesting and provides recommendations for their efficient design. Full article

Passive vibration isolation techniques with low-frequency characteristics have been a hot topic in the aerospace field. A hydraulic inertial vibration isolator is a highly effective type of isolator for controlling low-frequency vibrations. It typically consists of a main spring, a minor spring, an inertial mass, and a fluid domain. Due to its multi-domain nature, analyzing the isolation mechanism of this type of isolator is challenging. The bond graph method is employed to establish the dynamic model of the isolator. Subsequently, the state equations of the isolator are derived, and the energy equations of both the mechanical and the fluid parts of the isolator are obtained. Based on this, the energy transfer characteristics between the mechanical and fluid domains inside the isolator under external excitation are discussed. The time-domain response of the forces transmitted to the foundation is analyzed. It is shown that the anti-resonance frequency occurs when the forces transmitted to the foundation generated by the main spring and the fluid pressure are equal to that of the minor spring. To verify the proposed method’s correctness, a prototype of the isolator is designed and a carefully designed experiment is conducted. The acceleration transmissibility of the isolator is used to conduct a comparative study. The results show that the theoretical results are in good agreement with the experimental results. To depict the dynamic characteristics of the isolator under large amplitude vibration, the nonlinear dynamic model of the isolator is developed, and the corresponding force transmissibility of the isolator is formulated. The energy flow between the mechanical and the fluid domains under this condition is also analyzed. The results indicate that the energy flow responses exhibit a similar change tendency to the force transmissibility. However, the peak of the energy ratio between the mechanical subsystem and the fluid is the same as the linear condition, suggesting that this value is determined by the amplification ratio of the isolator. This research provides enhanced physical insight to understand the dynamic characteristics of this type of isolator and will help to shorten the design cycle of the isolator. Full article

Piezoelectric composites, which consist of piezoelectric materials and polymers, are widely employed in various applications such as underwater sonar transducers and medical diagnostic ultrasonic transducers. Acoustic transducers based on piezoelectric composites can have high sensitivity with broad bandwidth. In recent studies, it is demonstrated that 2-2 composites based on single crystals provide further increased sensitivity and wide bandwidth. In order to utilize a 2-2 composite in acoustic sensors, it is required to demonstrate the full material coefficients of the 2-2 composite. In this study, we investigated an analytic solution for determining equivalent material coefficients of a 2-2 composite. Impedance spectrums of the single-phase resonators with equivalent material coefficients and 2-2 composite resonators were compared by the finite element method in order to verify the analytic solutions. Furthermore, the equivalent material coefficients derived from the analytic solution were also verified by comparing the measured and the simulated impedance spectrums. The difference in resonance and anti-resonance frequencies between the measured and simulated impedance spectrums was around 0.5% and 1.2%. By utilizing the analytic solutions in this study, it is possible to accurately derive full equivalent material coefficients of a 2-2 composite, which are essential for the development of acoustic sensors. Full article

A new type of anti-resonant hollow-core fiber for terahertz waveguides is proposed. By introducing central support pillars and an elliptical structure, the fiber achieves high birefringence while maintaining low confinement loss and low material absorption loss. The fiber structure is optimized through simulation using the finite element method. The optimized fiber exhibits a birefringence of up to 1.22 × 10⁻² at a frequency of 1 THz, with a confinement loss of 8.34 × 10⁻⁶ dB/cm and a material absorption loss of 7.17 × 10⁻³ dB/cm. Furthermore, when the bending radius of the fiber is greater than 12 cm, the bending loss of the anti-resonant optical fiber at 1 THz is less than 1.36 × 10⁻⁴ dB/cm, demonstrating good bending resistance and high practical value. It is expected to play a significant role in optical communication systems. Full article

A typical piezoelectric energy harvester is a bimorph cantilever with two layers of piezoelectric material on both sides of a flexible substrate. Piezoelectric layers of lead-based materials, typically lead zirconate titanate, have been mainly used due to their outstanding piezoelectric properties. However, due to lead toxicity and environmental problems, there is a need to replace them with environmentally benign materials. Here, our main efforts were focused on the preparation of hafnium-doped barium titanate (BaHf_xTi_1−xO₃; BHT) sol–gel materials. The original process developed makes it possible to obtain a highly concentrated sol without strong organic complexing agents. Sol aging and concentration can be controlled to obtain a time-stable sol for a few months at room temperature, with desired viscosity and colloidal sizes. Densified bulk materials obtained from this optimized sol are compared with a solid-state synthesis, and both show good electromechanical properties: their thickness coupling factor k_t values are around 53% and 47%, respectively, and their converse piezoelectric coefficient $d_{33}^{\ast }$ values are around 420 and 330 pm/V, respectively. According to the electromechanical properties, the theoretical behavior in a bimorph configuration can be simulated to predict the resonance and anti-resonance frequencies and the corresponding output power values to help to design the final device. In the present case, the bimorph configuration based on BHT sol–gel material is designed to harvest ambient vibrations at low frequency (<200 Hz). It gives a maximum normalized volumetric power density of 0.03 µW/mm³/Hz/g² at 154 Hz under an acceleration of 0.05 m/s². Full article

Electrical drive systems are commonly applied for the mechanisms of precise movement, where having a high-quality position and high-quality speed control is especially valuable. Very often, the mechanical part of these systems reveals resonant properties that are related to the limited stiffness of the interconnection between subsequent parts of the mechanism. In most cases, this sort of system may be described as a model of several linked masses. If only the structure of the mechanical part is known and the corresponding parameters are constant and identified, the demanded control quality may be obtained using a properly tuned ADRC or PID controller equipped with appropriate anti-resonance filtration. However, if the parameters of the mechanical part are variant, adaptive control may be considered as a solution. In this paper, artificial neural network (ANN) is considered to be a speed controller and its training method assures adaptation to the unknown mechanical parameters. The paper is particularly focused on a three-mass system, which possesses, due to its structure, two resonant frequencies. The unique property of the analyzed system is the application of drive units at both ends of the system, so that the controller has the ability to influence the resonant system from both sides. The coordination of the drive unit is performed by the aforementioned ANN, from which two outputs affect the drive units independently. The derivation of the mathematical model is followed by its implementation in a computer simulation and finally the evaluation in a dedicated laboratory setup, the construction of which is also presented in the paper. Full article
