Search Results (11)

The on-orbit geometric calibration accuracy of high-resolution space cameras directly affects the application value of Earth observation data. Conventional on-orbit geometric calibration methods primarily rely on ground calibration fields, making it difficult to simultaneously achieve high precision and real-time monitoring. To address this limitation, we, in collaboration with Tsinghua University, propose a high-precision, real-time, on-orbit geometric calibration system based on active optical monitoring. The proposed system employs reference lasers to integrate the space camera and the star tracker into a unified optical system, enabling real-time monitoring and correction of the camera’s exterior orientation parameters. However, during on-orbit operation, the space camera is subjected to a complex thermal environment, which induces thermal deformation of optical elements and their supporting structures, thereby degrading the measurement accuracy of the geometric calibration system. To address this issue, this article analyzes the impact of temperature fluctuations on the focal plane, the reference laser unit, and the laser relay folding unit and proposes athermalization design optimization schemes. Through the implementation of a thermal-compensated design for the collimation optical system, the pointing stability and divergence angle control of the reference laser are effectively enhanced. To address the thermal sensitivity of the laser relay folding unit, a right-angle cone mirror scheme is proposed, and its structural materials are optimized through thermo–mechanical–optical coupling analysis. Finite element analysis is conducted to evaluate the thermal stability of the on-orbit geometric calibration system, and the impact of temperature variations on measurement accuracy is quantified using an optical error assessment method. The results show that, under temperature fluctuations of 5 °C for the focal plane and the reference laser unit, 1 °C for the laser relay folding unit, and 2 °C for the star tracker, the maximum deviation of the system’s measurement reference does not exceed 0.57″ (3σ). This enables long-term, stable, high-precision monitoring of exterior orientation parameter variations and improves image positioning accuracy. Full article

This paper is about the design and fabrication of infrared lenses, which are the core components of thermal imaging cameras to be mounted on vehicles. To produce an athermalized optical system, chalcogenide glass (As₄₀Se₆₀) with a lower thermo-optic coefficient (dn/dT) than germanium was adopted as a lens material, and each lens was designed so that defocus occurs in opposite directions depending on temperature. The designed lens was fabricated using a compression molding method, and the molded lenses showed less than 1.5 μm of form error (PV) using a mold iteration process. Through evaluations of MTF and thermal images obtained from the lens module, it was judged that this optical design process is obtainable. Full article

In the athermal and apochromatic design of optical systems, the distribution of lens’ optical powers and the selection of optical glass and structural materials are crucial. In this paper, an athermal and apochromatic design method is proposed for optical systems with a long focal length, large relative aperture, and wide spectrum. Firstly, a complex optical system composed of multiple lenses is equivalent to a two-component, single-lens system consisting of a replacement and an equivalent lens group. The optical glass for the replacement lens group is selected based on weight and the principle of material replacement in the 3D glass diagram, thus achieving an athermal and apochromatic design. Secondly, an athermal and apochromatic optical system with a focal length of 130 mm, an F-number of 2.0, a spectral range of 480 nm~800 nm, a field of view angle of 22°, and an operating temperature of −40 °C~+60 °C is designed. The modulation transfer function (MTF) at each field of view is greater than 0.6 at 50 lp/mm in the −40 °C~+60 °C temperature range, and the secondary spectrum aberration is 0.0056 mm, which is within the focal depth range of the optical system. Full article

This paper presents a real-time remote water level monitoring system based on dense wavelength division multiplexing (DWDM)-passive optical fiber sensor (OFS) network for the application of the Internet of Things (IoT). This network employs a broadband light source based on amplified spontaneous emission (ASE) as a seed light. This ASE light is spectrum-sliced by an athermal type arrayed waveguide grating (200 GHz × 16 channel), then distributed towards multiple sensing units (SU). Here, 16 SUs are installed vertically at the specified height in the water pool according to the design specification (i.e., spatial resolution). Then, each SU reflects an optical spectrum having a different reflection coefficient depending on the surrounding medium (e.g., air or water). By measuring these reflected optical spectra with an optical spectrum analyzer, the water level can be easily recognized in real time. However, as the sensing distance increases, system performance is severely degraded due to the Rayleigh Back-Scattering of the ASE light. As a result, the remote sensing capability is limited at a short distance (i.e., <10 km). To overcome this limitation, we propose a simple signal processing technique based on feature extraction of received optical spectra, which includes embedding a peak detection algorithm with a signal validation check. For the specific, the proposed signal processing performs the peak power detection, signal quality monitoring, and determination/display of the actual water level through three function modules, i.e., data save/load module, signal processing module, and Human–Machine Interface display module. In particular, the signal quality of the remote sensing network can be easily monitored through several factors, such as the number of spectral peaks, the wavelength spacing between neighboring peaks and the pattern of detected peak power. Moreover, by using this validation check algorithm, it is also possible to diagnose various error types (such as peak detection error, loss of data and so on) according to the pattern of measured optical spectra. As a result, the IoT sensor network can recognize 17 different level statuses for the water level measurement from a distance of about 25 km away without active devices such as optical amplifiers (i.e., passive remote sensing). Full article

The remote sensing imaging requirements of aerial cameras require their optical system to have wide temperature adaptability. Based on the optical passive athermal technology, the expression of thermal power offset of a single lens in the catadioptric optical system is first derived, and then a mathematical model for efficient optimization of materials is established; finally, the mechanical material combination (mirror and housing material) is optimized according to the comprehensive weight of offset with temperature change and the position change of the equivalent single lens, and achieve optimization of the lens material on an athermal map. In order to verify the effectiveness of the method, an example of a catadioptric aerial optical system with a focal length of 350 mm is designed. The results show that in the temperature range of −40 °C to 60 °C, the diffraction-limited MTF of the designed optical system is 0.59 (at 68 lp/mm), the MTF of each field of view is greater than 0.39, and the thermal defocus is less than 0.004 mm, which is within one time of the focal depth, indicating that the imaging quality of the optical system basically does not change with temperature, meeting the stringent application requirements of the aerial camera. Full article

This research work conducted a design and simulation of an ultra-low power all-optically tuned nonlinear ring resonator-based add-drop filter. The purpose of this study is to investigate a CMOS-compatible nonlinear material system for an optical filter with temperature resilience, polarization insensitivity, and fast and energy-efficient tunability. The all-optical tunability was achieved using an optical pump that photo-excites the high nonlinear Kerr effect in the device material system. A three-dimensional multiphysics approach was used, combining the electromagnetics and thermo-structural effects in the filter. Hybrid graphene on an ultra-rich silicon nitride ring resonator-based filter enabled the realization of an ultra-high tuning efficiency (0.275 nm/mW for TE mode and 0.253 nm/mW for TM mode) on a range of 1.55 nm and thermal stability of 0.11 pm/K. This work contributed to the existing literature by proposing (1) the integration of a high Kerr effect layer on a low loss, high index contrast, and two-photon absorption-free core material with an athermal cladding material system and (2) the use of a cross-section shape insensitive to polarization. Moreover, the tuning mechanism contributed to the realization of an all-optical on-chip integrable filter for Dense Wavelength Division Multiplexing systems in the less occupied L band. Full article

The use of airborne-mapping technology plays a key role in the acquisition of large-scale basic geographic data information, especially in various important civil/military-mapping missions. However, most airborne-mapping cameras are limited by parameters, such as the flight altitude, working-environment temperature, and so on. To solve this problem, in this paper, we designed a panchromatic wide-spectrum optical system with a focusing function. Based on the catadioptric optical structure, the optical system approached a telecentric optical structure. Sharp images at different object distances could be acquired by micro-moving the focusing lens. At the same time, an optical passive compensation method was adopted to realize an athermalization design in the range of −40–60 °C. According to the design parameters of the optical system, we analyzed the influence of system focusing on mapping accuracy during the focusing process of the airborne-mapping camera. In the laboratory, the camera calibration and imaging experiments were performed at different focusing positions. The results show that the experimental data are consistent with the analysis results. Due to the limited experiment conditions, only a single flight experiment was performed. The results show that the airborne-mapping camera can achieve 1:5000 scale-imaging accuracy. Flight experiments for different flight altitudes are being planned, and the relevant experimental data will be released in the future. In conclusion, the airborne-mapping camera is expected to be applied in various high-precision scale-mapping fields. Full article

The special dispersion and temperature characteristics of diffractive optical element (DOE) make them widely used in optical systems that require both athermalization and achromatic aberrations designs. The multi-layer DOE (MLDOE) can improve the diffraction efficiency of the overall broad waveband, but its diffraction efficiency decreases with changes in ambient temperature. When the ambient temperature changes, the micro-structure heights of MLDOE and the refractive index of the substrate materials change, ultimately affecting its diffraction efficiency, and, further, the optical transform function (OTF). In this paper, the influence of ambient temperature on the diffraction efficiency of MLDOE in a dual-infrared waveband is proposed and discussed, the diffraction efficiency of MLDOE caused by ambient temperature is derived, and a computational imaging method that combines optical design and image restoration is proposed. Finally, a dual-infrared waveband infrared optical system with athermalization and achromatic aberrations corrected based on computational imaging method is designed. Results show that this method can effectively reduce the diffraction efficiency of MLDOE by ambient temperature and improve the imaging quality of hybrid optical systems. Full article

Superresolution (SR) imaging technology based on compression coding has always been considered as the key to break through the geometric resolution of the detector. In addition to factors such as the reconstruction algorithm and mounting platform vibrations, the impact of inherent errors in the optical system itself on the reconstruction results of SR imaging is also obvious. To address this issue, a study on the design of the SR optical system and the influence of optical alignment errors on SR imaging was conducted. The design of the SR optical system based on digital micro-mirror device (DMD) for long-wave infrared wavelength was completed, and an athermal analysis of the system was carried out. The design results showed that the SR optical system has good imaging quality in the operating temperature range. The imaging model of the DMD SR imaging optical system is established according to the designed SR optical system. We investigated the influence of various alignment errors, including decenter, tilt, lens interval error and defocus, on the imaging properties of the SR optical system. Various random combinations of alignment errors were introduced into the optical system, respectively, and the SR reconstructed image quality of the imaging system was analyzed using the inverse sensitivity method to obtain the tolerance limits when the system was assembled. Finally, the effectiveness of the method to obtain the alignment tolerance limit of the compression coding SR imaging optical system was verified through a desktop demonstration experiment. Full article

High-quality cameras are fundamental sensors in assisted and autonomous driving. In particular, long-range forward-facing cameras can provide vital information about the road ahead, including detection and recognition of objects and early hazard warning. These automotive cameras should provide high-resolution images consistently under extreme operating conditions of the car for robust operation. This paper aims to introduce the design of fixed-focus, passively athermalized lenses for next-generation automotive cameras. After introducing an overview of essential and desirable features of automotive cameras and state-of-the-art, based on these features, two different camera designs that can achieve traffic sign recognition at 200 m distance are presented. These lenses are designed from scratch, with a unique design approach that starts with a graphical lens material selection tool and arrives at an optimized design with optical design software. Optical system analyses are performed to evaluate the lens designs. The lenses are shown to accomplish high contrast from $-40$ °C to 100 °C and allow for a $4\times$ increase in resolution of automotive cameras. Full article

The instability of the principal distance of the nighttime light remote-sensing camera of the Luojia 1-01 satellite directly affects the geometric accuracy of images, consequently affecting the results of analysis of nighttime light remote-sensing data. Based on the theory of optical passive athermal design, a mathematical model of optical-passive athermal design for principal distance stabilization is established. Positive and negative lenses of different materials and the mechanical structures of different materials are matched to optimize the optical system. According to the index requirements of the Luojia 1-01 camera, an image-telecentric optical system was designed under the guidance of the established mathematical model. In the temperature range of −20 °C to +60 °C, the principal distance of the system changes from −0.01 μm to +0.28 μm. After on-orbit testing, the geometric accuracy of the designed nighttime light remote-sensing camera is better than 0.20 pixels and less than index requirement of 0.3 pixels, which indicating that the principal distance maintains good stability on-orbit and meets the application requirements of nighttime light remote sensing. Full article
