High-speed trains have revolutionized modern transportation with their exceptional speeds, yet the essence of this technological breakthrough resides in the train’s wheels. These components are engineered to endure extreme mechanical stresses while ensuring high safety and reliability. In this paper, we selected the rim and web as representative components of the wheel and conducted a comprehensive and systematic study on their microstructure and mechanical properties. The wheels are typically produced through integral forging. To improve the mechanical performance of the wheel/rail contact surface (i.e., the tread), the rim is subjected to surface quenching or other heat treatments. This endows the rim with strength and hardness second only to the tread and lowers its ductility. This results in a more isotropic structure with improved fatigue resistance in low-cycle and high-cycle regimes under rotating bending. The web connects the wheel axle to the rim and retains the microstructure formed during the forging process. Its strength is lower than that of the rim, while its ductility is slightly better. The web satisfies current property standards, although the microstructure suggests further optimization may be achievable through heat treatment refinement. Full article

Bore deterioration phenomena, such as surface ablation, wear, aluminum deposition, and structural bending, severely restrict the service life and performance of electromagnetic launchers. Efficient bore inspection is necessary to study the deterioration mechanism, guide design, and health management. In this paper, an inspection system for electromagnetic launchers is presented which utilizes structured light scanning, time-of-flight, and laser alignment methods to acquire bore laser point clouds, and ultimately extracts the surface deformation of rails and insulators, as well as the straightness of the bore, through the registration of point cloud data. First, the system composition and detection principles are introduced. Second, the impacts of the detection device’s attitude deflection are analyzed. Next, focusing on the key registration issue of laser point clouds, a coarse registration method is proposed which utilizes the arc features of the rail by combining circle and parabola equations, thereby maximizing registration efficiency. Finally, the trimmed iterative closest-point (TrICP) algorithm is employed for fine registration to handle non-axisymmetric bore deformations. The experimental results show that the proposed method can detect bore surface deformation and straightness efficiently and precisely. Full article

In the realm of road–rail dual-use bridges, conducting accurate vehicle–bridge coupling analysis is crucial, as the combined effects of road traffic and rail transit induce complex dynamic challenges. This study investigates a road–rail dual-use network arch bridge, highlighting the dynamic effects induced by light rail loadings. By employing a noniterative vehicle–bridge coupling analysis method, the dynamic responses of hangers caused by vehicular and light rail loads are effectively captured. Additionally, this study explores the influence of various parameters, including vehicle types, driving lanes, and road surface roughness on the responses of hangers positioned at different locations along the bridge. The findings reveal that light rail induces significantly larger dynamic effects compared to motor vehicles. When the light rail operates closer to the hanger, the responses of hangers are more pronounced. Furthermore, different road surface roughness level notably affects the amplitude of axial stress and bending moment fluctuations. Poorer road conditions amplify these dynamic effects, leading to increased stress variations. These insights underscore the necessity of integrating considerations for both road and rail traffic in the structural analysis and design of network arch bridges to ensure their reliability and serviceability. Full article

The paper highlights the results of determining the strength of the brake pad of a freight wagon under uneven loading in operation. The main reasons for the uneven loading on the pad have been found. A mathematical tool for determining the strength of the pad unevenly loaded has been proposed. In the study, the pad is considered to be a rod system loaded with concentrated forces and bending moments. Sensors have been used in order to detect the load state of the brake pads. These sensors have been defined in the simulation software, and they have been placed on the working surface of the pad in the area of its interaction with the wheel. The operation of these sensors was simulated in the simulation software package. The results of the calculation have shown that the stresses in the pad are about 21.1 MPa; thus, they exceed the permissible values by 29%. Therefore, considering the uneven loading of the pad in operation, the strength of the pad is not ensured. To test the obtained results, the strength of the pad was determined using the finite element method. The Coulomb criterion was used for the calculation. It was found that the maximum stresses in the pad were about 19 MPa. These stresses were 21% higher than permissible values and occurred in the back of the pad. The study has proven that the uneven loading on the brake pad in operation can cause their destruction during braking. This may also cause traffic accidents with freight trains during their movement. The results of this study will contribute to the theoretical developments and recommendations aimed at improving the brake system of a freight wagon and rail traffic safety. It is considered that the tensometric sensors will be applied in future experimental tests for comparison and verification of the achieved results from the simulation computations. Full article

Due to its high section use rate and minimal environmental impact, pipe jacking technology is frequently utilized in the building of urban rail transit and other municipal projects. This paper develops a three-dimensional numerical model for the gradual construction of rectangular pipe jacking based on the quasi-rectangular pipe jacking metro station project on Shanghai Line 14 and examines the interaction between the subsequent construction of double line pipe jacking and pile foundation. To analyze the deformation pattern of the tunnel section and the ground surface during the construction period and to confirm the applicability and accuracy of the model, the simulation results are compared with the monitoring data. The findings demonstrate that although the bending moment of the pipe jacking section is distributed as a “butterfly” under the influence of the viaduct piles, the maximum positive and negative bending moments as well as the lateral and vertical radial deformations of the pipe section cross-section are all somewhat diminished. The ground surface settlement curve in the vicinity of the bearing platform exhibits a more pronounced non-uniform settlement when the two pipe jackings pass through the pile foundation in close proximity, one after the other. The largest horizontal displacement of the pile foundation is found inside the jacking pipe tunnel at a depth of roughly 17 m below ground, where pipe jacking II has a greater influence on the lateral displacement of the pile foundation than pipe jacking I. The study’s findings line up with the monitoring data, which can serve as a guide and aid in the development of initiatives of a similar nature. Full article

In this study, field measurements of the bending moments of prestressed concrete (PC) sleepers installed on commercial lines were obtained, and numerical analyses to identify the effects of different parameters on their bending moments were conducted. The bending load capacities of aged PC sleepers collected from commercial lines via bending tests were also determined. According to the field measurement results of the wheel loads and bending moments of the PC sleepers, the measured values were smaller than the design values. In addition, neither the wheel load nor the bending moment depended on train speed. The numerical analysis results indicate that the positive bending moment at the rail seat section is unlikely to exceed the design decompression moment (DDM). However, the negative bending moment at the center section may exceed the DDM if center support is provided with a reduced spring constant under the rail (the “hanging” rail seat section). In addition, the bending moment increased with the rail surface roughness, so the rail should be kept smooth. Moreover, the results of the JIS E 1201 bending tests on the aged PC sleepers showed that the crack generation load and ultimate load decreased gradually with increases in age and passing tonnage. However, all samples satisfied the JIS standard values. Furthermore, the bending moments generated in the PC sleepers during train passage were considerably smaller than the crack generation load and ultimate load during the bending test. Thus, Japanese PC sleepers aged more than 50 years currently satisfy the standard flexural fracture values specified by the JIS, and safety is not immediately compromised. Full article

In order to find out the influence of subgrade frost heave on the deformation of track structure and track irregularity of high-speed railways, a nonlinear damage finite element model for China Railway Track System III (CRTSIII) slab track subgrade was established based on the constitutive theory of concrete plastic damage. The analysis of track structure deformation under different subgrade frost heave conditions was focused on, and amplitude the limit of subgrade frost heave was put forward according to the characteristics of interlayer seams. This work is expected to provide guidance for design and construction. Subgrade frost heave was found to cause cosine-type irregularities of rails and the interlayer seams in the track structure, and the displacement in lower foundation mapping to rail surfaces increased. When frost heave occured in the middle part of the track slab, it caused the greatest amount of track irregularity, resulting in a longer and higher seam. Along with the increase in frost heave amplitude, the length of the seam increased linearly whilst its height increased nonlinearly. When the frost heave amplitude reached 35 mm, cracks appeared along the transverse direction of the upper concrete surface on the base plate due to plastic damage; consequently, the base plate started to bend, which reduced interlayer seams. Based on the critical value of track structures’ interlayer seams under different frost heave conditions, four control limits of subgrade frost heave at different levels of frost heave amplitude/wavelength were obtained. Full article

Dynamic response of a bridge–embankment transition is determined by, and therefore an indicator of, the coupled train–track–subgrade system. This study aims to investigate the approach of coupling the train–track–subgrade system to determine the dynamic response of the transition. The coupled system is established numerically based on the weak energy variation, the overall Lagrange format of D’Alembert’s principle and dynamics of the multi-rigid body, which is verified by in-site measurements. With this model, the influence of rail bending, differential settlement and other factors on the dynamic performance of the transition system is analyzed. The results show that when the train driving speed is 350 km/h, basic requirements should be satisfied. These requirements include that the irregularity bending of the bridge–embankment transition section should be less than 1/1000, the rigidity ratio should be controlled within 1:6, and the length of the transition section should be more than 25 m. In addition, the differential settlement should not exceed 5 mm. Among these factors, the differential settlement and the bending of the rail surface are the main ones to cause the severe dynamic irregularity of the transition section. Our analysis also indicates a requirement to strengthen the 18 m and 25–30 m distance from the abutment tail and the bed structure. Full article
