Compliance control strategies have been utilised for the ultraprecision polishing process for many years. Most researchers execute active compliance control strategies by employing impedance control law on a robot development platform. However, these methods are limited by the load capacity, positioning accuracy, and repeatability of polishing mechanisms. Moreover, a sophisticated actuator mounted at the end of the end-effector of robots is difficult to maintain in the polishing scenario. In contrast, a hybrid mechanism for polishing that possesses the advantages of serial and parallel mechanisms can mitigate the above problems, especially when an active compliance control strategy is employed. In this research, a high-frequency-impedance robust force control strategy is proposed. It outputs a position adjustment value directly according to a contact pressure adjustment value. An open architecture control system with customised software is developed to respond to external interrupts during the polishing procedure, implementing the active compliance control strategy on a hybrid mechanism. Through this method, the hybrid mechanism can adapt to the external environment with a given contact pressure automatically instead of relying on estimating the environment stiffness. Experimental results show that the proposed strategy adapts the unknown freeform surface without overshooting and improves the surface quality. The average surface roughness value decreases from 0.057 um to 0.027 um. Full article

The inability to converge at the edge of a workpiece during polishing affects the edge profile accuracy and surface quality of the workpiece. In this study, a bias trajectory generation method based on the lifting bonnet method that can maintain the morphology of polished edges is presented. Firstly, by establishing the polishing parameters and the decreasing rule in line with the principles of the lifting bonnet method, we obtained the residual height spacing, the radius of the polishing area, the centre offset position, and the pressing depth for each offset trajectory. Subsequently, the modified bias trajectory algorithm correction coefficients were obtained by fitting the edge trajectories using cubic Bessel curves, which were multiplied with the bias amount to obtain the final modified bias trajectory. Finally, an experiment was designed to compare the edge effect of the modified bias trajectory with the traditional grating trajectory. The experimental findings indicate that the reduction in edge collapse following the implementation of the modified offset trajectory was 1.30 μm. In contrast, the edge collapse after polishing with the traditional grating trajectory amounted to 98.67 μm. Moreover, the edge collapse ensuing traditional polishing trajectory was 75.9 times more pronounced than that observed after using the modified offset trajectory. It is shown that the modified bias trajectory method can not only maintain the original edge morphology of the workpiece but can also promote the convergence of the edge effect to a certain extent. Full article

In order to meet the manufacturing requirements of modern space remote sensors for high-precision freeform optical parts, the grinding technology and its application were studied. The objective of this paper was to improve the application effect of traditional grinding technology in the processing of hard and brittle materials, and then apply it in specific fields. Therefore, the influence of key process factors such as cutting speed and removal depth on subsurface damage (SSD) was studied based on orthogonal experiments, and an improved grinding technology characterized by low SSD and high surface shape accuracy was formed. Then, the effect of this grinding technology was further verified by the high-precision manufacturing of freeform surfaces. A surface of a 130 mm diameter freeform surface was machined by improved grinding technology and combined polishing technology, the final root mean square of surface shape reached 12.1 nm. The improved grinding technology can reduce SSD from 20 μm to 10 μm, and improve the manufacturing efficiency of freeform surfaces above 30% when the cut speed is 20 m/s and the remove depth is 10 μm. The proposed technology can be applied to the extreme manufacturing of hard and brittle materials. Full article

Roughness down to atomic and close-to-atomic scale is receiving an increasing attention in recent studies of manufacturing development, which can be realized by high-precision polishing processes. This review presents polishing approaches at atomic and close-to-atomic scale on planar and curved surfaces, including chemical mechanical polishing, plasma-assisted polishing, catalyst-referred etching, bonnet polishing, elastic emission machining, ion beam figuring, magnetorheological finishing, and fluid jet polishing. These polishing approaches are discussed in detail in terms of removal mechanisms, polishing systems, and industrial applications. The authors also offer perspectives for future studies to address existing and potential challenges and promote technological progress. Full article

Ultraprecision freeform polishing using a bonnet or a felt ball mounted on a polishing head plays an important role in the mold and lens production industries. The volumetric wear of a bonnet or a felt polishing ball is still a problem to be solved. The objective of this study was to develop an ultrasonic-vibration-assisted ball polishing process on a CNC machining center to improve the surface roughness of a STAVAX mold steel and to reduce the volumetric wear of the polishing ball. The optimal combination of the ultrasonic-vibration-assisted ball polishing parameters for a plane surface was determined by conducting the Taguchi L18 matrix experiments, ANOVA analysis, and verification experiments. The surface roughness of the polished specimens was improved from the burnished surface roughness of Ra 0.122 μm to Ra 0.022 μm. In applying the optimal plane surface ball burnishing and vibration-assisted spherical polishing parameters sequentially to a fine-milled and burnished aspherical lens surface carrier on a five-axis machining center, the surface roughness of Ra 0.014 μm was obtainable. The improvement in the volumetric wear of the polishing ball was about 62% using the vibration-assisted polishing process compared with the nonvibrated polishing process. Full article

Tungsten carbide (WC) has the characteristics of high hardness, high strength, corrosion resistance, wear resistance and excellent fracture toughness. Accordingly, it has been commonly used as the material for cutting tools and molds in glass-forming techniques. To obtain ultra-smooth surfaces, fine polishing of WC is indispensable. However, the efficiency of WC polishing is low using the existing polishing methods, and the mechanism behind the polishing process requires further investigation. Specifically, the effect of the binder in WC polishing is not clear since there are different kinds of WC with various weight percentages of the binder. In this paper, we present the findings of a study on the polishing performance of two kinds of WC material, with and without the binder, using a semi-rigid (SR) bonnet polishing tool. A series of experiments were performed on a 6-DOF robotic polishing instrument to investigate the material-removal characteristics, surface integrity and sub-surface damage after polishing. The results demonstrate that the SR bonnet polishing tool successfully reduced the surface roughness of WC with and without the binder to the nanometric level, though the lowest surface roughness was obtained on binder-less WC. No obvious sub-surface damage was observed under SEM inspection, while the processing efficiency was greatly improved owing to the high material removal rate of the tool. Based on our analysis of key polishing parameters and corresponding surface integrities, the effect of the binder on the polishing performance is explained, which offers excellent guidance for WC polishing. Full article

Ti6Al4V alloy has been widely used in many fields, such as aerospace and medicine, due to its excellent biocompatibility and mechanical properties. Most high-performance components made of Ti6Al4V alloy usually need to be polished to produce their specific functional requirements. However, due to the material properties of Ti6Al4V, its polishing process still requires significant development. Therefore, this study aimed to investigate the performance of polishing Ti6Al4V by using tools with different rigidities. Two kinds of bonnet tool were used, namely a pure rubber (PR) bonnet and a semirigid (SR) bonnet. The characterization of material removal and surface integrity after polishing was conducted through a series of experiments on a 6-DOF robotic polishing device. The results demonstrate that both bonnet tools successfully produce nanometric level surface roughness. Moreover, the material removal rate of the SR bonnet tool is significantly higher than that of the PR bonnet, which is consistent with the material removal characteristics of glass polishing in previous research. In addition, the presented analysis on key polishing parameters and surface integrity lays the theoretical foundation for the polishing process of titanium alloy in different application fields. Full article

The material removal depth in the pre-polishing stage of the precision optics is usually tens of microns to remove the subsurface damage and grinding marks left by the previous grinding process. This processing of the upstand edge takes a large part of the time at this stage. The purpose of this paper is to develop a method that can reduce the edge effect and largely shorten the processing time of the pre-polishing stage adopting the semirigid (SR) bonnet. The generation of the edge effect is presented based on the finite element analysis of the contact pressure at the edge zone firstly. Then, some experimentations on the edge effect are conducted, and the results proved that the SR bonnet tool can overhang the workpiece edge in the pre-polishing stage to reduce the width and height of the upstand edge to largely shorten the subsequent processing time of it. In addition, there exists a perfect overhang ratio, which generates the upstand edge with the smallest width and height, with no damage to the bonnet tool in the meantime. In addition, one combination of the pre-polishing parameters is concluded according to this method, which can be safely adopted in practical process. Full article

The increasing demand for precision optical components invokes the requirement of advanced fabrication techniques with high efficiency. Atmospheric pressure plasma processing (APPP), based on chemical etching, has a high material removal rate and a Gaussian-shaped influence function, which is suitable to generate complex structures and correct form errors. Because of the pure chemical etching, an optically smooth surface cannot be achieved using only APPP. Thus, bonnet polishing (BP) with a flexible membrane tool, also delivering a Gaussian influence-function, is introduced to smooth the surface after APPP. In this paper, the surface texture evolution in the combined process of APPP and BP is studied. The etched texture with increased removal depth of APPP is presented and analyzed. Subsequently, the processed substrates are smoothed by BP. The texture smoothing and the roughness improvement is investigated in detail. The experimental results show that the APPP etched pits coalesce with each other and transform into irregular convex-concave structures, with roughness degraded to about 25 nm arithmetical mean deviation (Ra). The APPP etched texture can be successfully smoothed to 1.5 nm Ra, with 0.2–1 μm material removal of BP. Full article
