Air-coupled ultrasonic detection demands high transmission performance from piezoelectric micromachined ultrasonic transducers (PMUTs). However, existing microelectromechanical system (MEMS)-based PMUTs deliver limited output, which compromises measurement accuracy and constrains further development. This work proposes a novel PMUT design with a cantilevered, boundary-suspended diaphragm that relieves residual stress, relaxes edge constraints, increases the mechanical degrees of freedom, and enables larger vibration amplitudes. Additionally, this work develops an accurate air-coupling model to predict device performance and a streamlined micro-nanofabrication process for device realization. Experimental results show that under a 1 Vpp (−5 Voffset) drive, the device achieves a peak acoustic pressure of 4.004 Pa at 69.3 kHz, measured at 10 cm distance in air, corresponding to a maximum sound pressure level of 106.02 dB (re 2 × 10⁻⁵ Pa). Compared to a traditional PMUT at 98.45 dB, this represents a 7.57 dB improvement and, to our knowledge, the highest reported sound pressure level at 10 cm for a single PMUT operating near 70 kHz under a 1 Vpp excitation. These results validate the significant enhancement in transmission performance achieved by the proposed topological structure, offering a solution to overcome the common bottleneck of insufficient output in PMUTs, and indicate strong potential for broader air-coupled sensing applications. Full article

Precision solder deposition for 3D or flexible substrates remains a persistent challenge in electronic packaging. This study introduces a hybrid process that integrates stencil printing with laser-induced forward transfer (LIFT), employing a customized line-scan trajectory to fabricate high-aspect-ratio solder deposits under large-gap, contactless conditions. Solder paste patterns were first printed on a glass carrier and subsequently transferred using pulsed laser scanning, with high-speed imaging employed to resolve the transfer dynamics. Three transfer regimes—stable, unstable, and no transfer—were identified, with the stable regime exhibiting sequential stages governed by vaporization-induced pressure and the viscoelastic response of the solder paste. The initial aspect ratio (AR) was found to critically influence separation behavior, with AR = 0.3 marking the transition between bridging and cantilevered morphologies. Transferred deposits consistently achieved final aspect ratios approaching 0.7; notably, low-AR (<0.15) patterns showed a 2.2-fold height increase. The process maintains a robust energy window (0.937–1.112 J/cm²), offering both mechanistic insight into transfer stability and practical guidance for optimizing solder paste deposition in advanced packaging applications. Full article

The Crested Porcupine Optimizer (CPO), as a newly emerging swarm intelligence algorithm, demonstrates advantages in balancing global exploration and local exploitation but still suffers from limitations in convergence speed and local exploitation precision. To address these issues, this paper proposes an enhanced variant, the Butterfly Search and Triangular Walk Crested Porcupine Optimizer (BTCPO). The method achieves a dynamic balance between exploration and exploitation by combining triangular walk to boost local exploitation and butterfly search to increase global variety. Experimental results on 23 classical benchmark functions and the CEC2021 test suite show that BTCPO outperforms CPO as well as seven state-of-the-art algorithms (DBO, HBA, BKA, HHO, GWO, GOOSE, and SSA). Specifically, BTCPO achieves the best performance on more than 80% of CEC2021 functions, with convergence speed improved by approximately 25% compared to CPO. Furthermore, BTCPO exhibits higher efficiency and usefulness in engineering design problems such as trusses, welded beams, and cantilever beams. These findings demonstrate the theoretical and practical advantages of BTCPO, making it a workable approach to solving difficult optimization problems. Full article

This study aims to analyze the wind-induced effects and vibration control of a long-span cable-stayed bridge with a steel truss girder under strong marine wind conditions during its maximum single-cantilever state. During the cantilever construction stage of cable-stayed bridges, the reduction in structural stiffness and damping may lead to excessive wind-induced responses, affecting construction accuracy and safety. Focusing on a newly constructed sea-crossing railway cable-stayed bridge with a steel truss girder and a main span of 364 m, this research utilizes field-measured data and finite element simulations to analyze the buffeting responses of the bridge in the maximum single-cantilever state during construction. The vibration suppression effects of different wind-resistant measures are compared, and we propose an economical and efficient vibration mitigation solution. The results indicate that using the turbulent field parameters and unit aerodynamic admittance function recommended in JTG/T 3360-01—2018 Wind-resistant Design Specification for Highway Bridges leads to conservative in predictions regarding the buffeting responses, and this approach can be used in the preliminary design of large-span bridges. The measured turbulent field parameters can effectively estimate the bridge buffeting responses, especially in the transverse direction. Measuring wind speeds at the bridge site is crucial for the rational design and construction of cable-stayed bridges in strong marine wind environments. The effectiveness of vibration reduction decreases in the order of temporary piers, inclined struts, tuned mass dampers, and wind-resistant cables. The inclined strut scheme achieved vibration reductions of 84.45% in the transverse direction and 68.17% in the vertical direction, slightly lower than those of the auxiliary pier scheme (89.04% and 85.47%). However, the installation of temporary piers during the construction of a sea-crossing bridge would significantly increase construction costs, whereas the inclined strut scheme requires only temporary steel structures near the main tower and piers without substantially increasing the construction workload. Therefore, the inclined strut scheme is recommended as an effective and economical vibration control measure for large-span sea-crossing cable-stayed bridges. Full article

In this study, an innovative measurement method integrating lateral confocal technology and composite motion control is proposed to address the physical space constraints and data processing problems in the detection of the shape and position errors in deep holes with large aspect ratios and small diameters. By designing a lateral confocal displacement sensor and a cantilever measuring device, we break through the spatial constraints of $\mathrm{\varnothing }6 \mathrm{m}\mathrm{m}$ deep-hole inspection and solve the problems of rigidity and surface damage in the traditional contact probe. We constructed an axis-rotation coordinated motion control model and found that the measuring points were densely arranged in a helical trajectory along the inner wall of the hole. We developed the “virtual slicing–B-spline reconstruction” algorithm and used the adaptive motion control algorithm to achieve a more efficient measurement of the hole. The innovative “virtual slicing–B-spline reconstruction” algorithm, using adaptive grouping, dynamic slicing, and a fourth-order B-spline-fitting hierarchical processing framework, reached a straightness error assessment result of the $1 \mathsf{\mu }\mathrm{m}$ order. Experiments show that, under $0.5 \mathrm{m}\mathrm{m}∕\mathrm{s}$ feed rate and $12 \mathrm{r}\mathrm{m}\mathrm{p}$ rotational speed, the standard deviation of straightness is ≤$0.0008 \mathrm{m}\mathrm{m}$ and the standard deviation of cylindricity is ≤$0.0064 \mathrm{m}\mathrm{m}$; compared to the CMM (coordinate measuring machine) measurement results, the cylindricity and straightness evaluation errors obtained by the new measurement method are reduced by $4.6\%$ and $4.5\%$, respectively. It provides a technical solution that improves both accuracy and efficiency for the precision inspection of small-diameter deep holes. Full article

This paper presents a novel Ripple Evolution Optimizer (REO) that incorporates adaptive and diversified movement—a population-based metaheuristic that turns a coastal-dynamics metaphor into principled search operators. REO augments a JADE-style current-to-p-best/1 core with jDE self-adaptation and three complementary motions: (i) a rank-aware that pulls candidates toward the best, (ii) a time-increasing that aligns agents with an elite mean, and (iii) a scale-aware sinusoidal that lead solutions with a decaying envelope; rare Lévy-flight kicks enable long escapes. A reflection/clamp rule preserves step direction while enforcing bound feasibility. On the CEC2022 single-objective suite (12 functions spanning unimodal, rotated multimodal, hybrid, and composition categories), REO attains 10 wins and 2 ties, never ranking below first among 34 state-of-the-art compared optimizers, with rapid early descent and stable late refinement. Population-size studies reveal predictable robustness gains for larger N. On constrained engineering designs, REO achieves outperforming results on Welded Beam, Spring Design, Three-Bar Truss, Cantilever Stepped Beam, and 10-Bar Planar Truss. Altogether, REO couples adaptive guidance with diversified perturbations in a compact, transparent optimizer that is competitive on rugged benchmarks and transfers effectively to real engineering problems. Full article

Global warming reduces the thickness and duration of seasonal lake ice, increasing the risk of ice cover failure. To investigate the bending behavior of ice cover, six groups of full-scale cantilever beam tests were conducted on a brackish water lake during the winter of 2023–2024, covering the following three ice periods: growth, stable, and melt. A total of 16 upward-loaded beams and 24 downward-loaded beams were tested. The results showed that the flexural strength of brackish ice was 374.21 ± 99.93 kPa, and the effective elastic modulus was 2.77 ± 0.93 GPa. The square root of bulk porosity, fitted with an exponential function, is the optimal predictor of flexural performance. Both flexural strength and effective elastic modulus systematically decreased with increasing porosity, and empirical regression formulas were established. On average, downward-loaded flexural strength was approximately 17.3% to 38.8% higher than upward-loaded strength, whereas elastic modulus showed no significant difference between the two loading directions. Flexural mechanical properties during the melt period reduced significantly, with a strength and modulus about 33.0% to 61.1% lower than those in the growth and stable periods. Comparisons with existing datasets demonstrate that the mechanical properties of brackish ice are lower than those of freshwater ice but higher than those of sea ice. This study provides new in situ data on the full-scale flexural mechanical properties of brackish ice and offers an important basis for assessing ice loads in lakes and estuarine environments under climate change. Full article

Multi-slice mining of the 70 m ultra-thick coal seam in East Junggar coalfield, China is marked by large-scale mining space expansion and frequent stress disturbances. To address those, this study uses theoretical analysis, physical simulation, and numerical simulation to explore the evolution of an overburden bearing structure and the control of strata behavior in multi-slice mining. The results (1) clarify the overburden fracture-hinging characteristics: fractured blocks in lower hard strata form beam-type hinges (early stage), the lower hinged structure weakens and the beam-type hinge structure moves upward in steps (middle stage), the continuous increase in the mined-out space leads to the transverse O-X fracture of far-stope rock strata, and broken rock blocks are extruded into shells (late stage); this study also proposes an identification method for the morphology of roof bearing structures (including beam structure, higher beam structure, and arch structure); (2) define the support-controlled strata range and load calculation method at different stages, and show that the support load “increases slowly under the near-stope roof bearing structure and tends to stabilize under the far-stope roof bearing structure” as the roof bearing structure moves upward; and (3) guided by the aims of avoiding cantilever beams and ensuring near-stope roof stability, lead us to propose the following measures: pre-splitting main roof (early stage); short working faces with reduced layered thickness and rapid advance (late stage); and goaf/separation grouting (whole process). The maximum support load drops from 20,017.5 kN to 16,192.5 kN, enabling lightweight support selection. This study provides theoretical guidance for support selection and roof control in the multi-slice mining of ultra-thick coal seams. Full article

In this paper, synchronous mechanical and optical measurements are proposed using the dual cantilever mode of dynamic mechanical analysis (DMA). It was demonstrated that this mode enables the detection of phase transitions in both the core and cladding materials of polymer optical fibers (POFs), with corresponding changes in optical signal intensity observed across different light wavelengths. In dual cantilever mode DMA, an increase in optical transmission was recorded between the two detected glass transition temperatures. The initial increase in transmission is attributed to cladding softening and the consequent reduction in internal stresses in the POF, while the maximum in optical transmission coincides with the beginning of the phase transition in the core material. To compare and interpret the optical and thermo-mechanical results, Differential scanning calorimetry (DSC) and Fourier transform infrared (FTIR) measurements were carried out on POF pieces, as well as separately on the core and cladding materials. This integrated technique yields quantitative data on a material’s viscoelasticity and light-transmission changes, making it valuable for quality control and for predicting the long-term behavior of advanced POFs in various applications. Full article

Background and Objectives: This study aimed to evaluate the biomechanical behavior of three-unit implant-supported prostheses with different bridge configurations (mesial cantilever, distal cantilever, and pontic) and two types of retention in the atrophic posterior maxilla, through three-dimensional finite element analysis (3D FEA). The focus was on stress distribution in short implants used in pontic and mesial cantilever designs. Materials and Methods: Six 3D finite element models were developed to represent various prosthetic designs and retention mechanisms in a maxillary segment including the first premolar, second premolar, and first molar regions. Type III bone with 8 mm vertical height simulated an atrophic maxilla. Standard implants were placed in premolar areas and short implants in molar regions. A 100 N oblique load at 45° was applied to each unit to simulate masticatory function. Stress distribution was assessed using von Mises and principal stress criteria. Results: The highest implant and crown stress occurred in the cement-retained distal cantilever (100.14 MPa and 329.95 MPa, respectively), while the lowest values were found in the screw-retained pontic model (44.74 MPa and 81.23 MPa). Mesial cantilevers showed intermediate stress levels. Screw-retained designs generally generated lower stresses within implants than cement-retained ones. In cortical bone, stress ranged from 10.25 MPa in the cement-retained distal cantilever to 4.22 MPa in the screw-retained pontic, while trabecular bone showed maximum stress of 1.69 MPa and 0.82 MPa, respectively. Conclusions: Prosthetic design and retention type significantly influenced biomechanical performance. Screw-retained pontic prostheses with short implants in the molar region provided the most favorable stress distribution. When cantilevers are required, mesial extensions are biomechanically more advantageous than distal ones. Short implants can thus be safely used in the posterior maxilla when accompanied by proper prosthetic design and retention type. Full article

The material point method (MPM) has shown significant potential for simulating problems involving large deformations. However, many implicit MPM formulations based on the traditional Updated Lagrangian (UL) scheme still face challenges in terms of computational stability. In this study, we propose a novel Lagrangian equilibrium formulation for an implicit MPM that is tailored to large-deformation problems. (1) The previously converged state is utilized to simplify stiffness matrix computations, thereby improving the stability of the algorithm. (2) The framework supports a variety of high-order interpolation functions, which effectively mitigate numerical artifacts such as cell-crossing errors. (3) The B-bar technique is further incorporated to suppress spurious stress oscillations in the incompressible limit. The proposed method is validated through two classical benchmark tests, the simple shear of a single element and the cantilever beam problem, by comparing the simulation results with analytical solutions and alternative numerical approaches. Finally, its capability is demonstrated in slope stability and strip footing analyses, confirming the superior accuracy, stability, and robustness of the method for large-deformation elastoplastic problems. Full article

This study introduces the Graph-Structured Physics-Informed DeepONet (GS-PI-DeepONet), a novel neural network framework designed to address the challenges of solving parametric Partial Differential Equations (PDEs) in structural analysis, particularly for problems with complex geometries and dynamic boundary conditions. By integrating Graph Neural Networks (GNNs), Deep Operator Networks (DeepONets), and Physics-Informed Neural Networks (PINNs), the proposed method employs graph-structured representations to model unstructured Finite Element (FE) meshes. In this framework, nodes encode physical quantities such as displacements and loads, while edges represent geometric or topological relationships. The framework embeds PDE constraints as soft penalties within the loss function, ensuring adherence to physical laws while reducing reliance on large datasets. Extensive experiments have demonstrated the GS-PI-DeepONet’s superiority over traditional Finite Element Methods (FEMs) and standard DeepONets. For benchmark problems, including cantilever beam bending and Hertz contact, the model achieves high accuracy. In practical applications, such as stiffness analysis of a recliner mechanism and strength analysis of a support bracket, the framework achieves a 7–8 speed-up compared to FEMs, while maintaining fidelity comparable to FEM, with R² values reaching up to 0.9999 for displacement fields. Consequently, the GS-PI-DeepONet offers a resolution-independent, data-efficient, and physics-consistent approach for real-time simulations, making it ideal for rapid parameter sweeps and design optimizations in engineering applications. Full article

To study the bearing capacity of large width-to-height ratio (LWHR) wind power spread foundations on onshore sandy soils, this study takes a 2 MW unit foundation of a specific wind farm as the object, conducts its sustainable design optimization, structural design and bearing capacity analysis, and explores internal force variation patterns of the structure and foundation. First, it investigates interactions among foundation soil stiffness, foundation deformation, and width-to-height ratio, and proposes the ratio can be slightly over 2.5 under specific geological conditions. Then, it verifies the foundation’s design and bearing capacity via code-based methods and uses ABAQUS to build an integrated finite element model (foundation, reinforcement, foundation ring, soil) for analyzing the mechanical behavior of the overall structure and key components. Finally, it focuses on bending moments of the foundation’s top/bottom slab reinforcement and reaction force distribution, and compares results from code formulas, commercial software, and finite element analysis. The results show that foundation deformation relates to the outer cantilever’s width-to-height ratio, reaction force magnitude, and soil stiffness. Soil stiffness impacts the linear distribution of reaction forces more significantly than the ratio—when soil stiffness is smaller, reaction forces still meet the linear assumption even if the ratio exceeds 2.5 within a range; when larger, they differ greatly. Under specific sandy soils (bearing stratum capacity < 300 kPa), the LWHR foundation meets wind turbine requirements, and its foundation ring’s punching shear resistance complies with standards (considering uplift-resistant reinforcement). For coarse sand bearing strata, the foundation’s bottom pressure follows linear distribution per code, and code formulas apply. However, the LWHR scheme is not fully suitable for complex geology or other foundation types, whose applicability needs comprehensive analysis. Full article

The proliferation of wireless sensor networks in industrial Internet of Things (IIoT) applications demands sustainable power solutions that eliminate battery replacement requirements while maintaining operational reliability in varying vibration environments. This paper presents a frequency-tunable magnetoelectric (ME) energy harvester that addresses the fundamental challenge of frequency mismatch between ambient industrial vibrations and harvester resonance through position-dependent magnetic force manipulation. The proposed system employs a Terfenol-D/PMNT/Terfenol-D sandwich transducer mounted on a cantilever beam within an adjustable magnetic circuit, enabling continuous frequency tuning through air gap modification for different magnetic field configurations. A comprehensive theoretical framework incorporating position-dependent magnetic forces was developed to predict the system behavior. Additionally, Multi-walled carbon nanotube (MWCNT)-enhanced epoxy bonding layers with 2 wt.% concentration were analyzed and demonstrated six-fold power improvement over conventional epoxy. The experimental validation shows frequency tuning from 40 Hz to 65 Hz through air gap adjustment of only 1 mm, corresponds to a 62.5% tuning range. Further experimental investigation proves a ten-fold power output improvement up to 2 mW by employing a four-magnet circuit design compared to the two-magnet configuration through specific adjustment of the air gap width. Full article

This study systematically evaluates the mode-I (opening) and mode-II (shearing) interlaminar strength and fracture toughness of four co-cured fiber–metal laminates (FMLs): AL–CF (aluminum–carbon fiber fabric), AL–GF (aluminum–glass fiber fabric), AL–HC (aluminum–carbon/glass hybrid fabric), and AL–HG (aluminum–glass/carbon hybrid fabric). Epoxy adhesive films were interleaved between metal and composite plies to enhance interfacial bonding. Mode-I interlaminar tensile strength (ILTS) and mode-II interlaminar shear strength (ILSS) were measured using curved beam and short beam tests, respectively, while mode-I and mode-II fracture toughness ($G_{Ic}$ and $G_{IIc}$) were obtained from double cantilever beam (DCB) and end-notched flexure (ENF) tests. Across laminates, interlaminar tensile strength (ILTS) values lie in a narrow band of 31.6–31.8 MPa and interlaminar shear strength (ILSS) values in 41.0–41.9 MPa. The mode-I initiation ($G_{Ic,init}$) and propagation ($G_{Ic, prop}$) toughnesses are 0.44–0.56 kJ/m² and 0.54–0.64 kJ/m², respectively, and the mode-II toughness ($G_{IIc}$) is 0.65–0.79 kJ/m². Scanning electron microscopy reveals that interlaminar failure localizes predominantly at the metal–adhesive interface, displaying river-line features under mode-I and hackle patterns under mode-II, whereas the adhesive–composite interface remains intact. Collectively, the results indicate that, under the present processing and test conditions, interlaminar strength and toughness are governed by the metal–adhesive interface rather than the composite reinforcement type, providing a consistent strength–toughness baseline for model calibration and interfacial design. Full article
