Polyimide (PI), owing to its high heat resistance and low density, is often employed as a substitute for metallic materials in high-temperature environments, such as aircraft engines, bearings, and gears. However, the relatively high friction coefficient of pure PI limits its application under harsh conditions. Therefore, this study synthesized a composite lubricant with binary fillers to improve this performance. This study employed the hydrothermal method to synthesize MoS₂/MXene composite lubricating fillers and systematically investigated the high-temperature tribological properties of PI composites reinforced with these fillers. The results demonstrated that the optimal PI composite containing 5% MoS₂/MXene exhibited a 14 °C increase in initial decomposition temperature compared to pure PI. Additionally, its thermal conductivity was enhanced by 36%, while the hardness (0.398 GPa) and elastic modulus (6.294 GPa) were elevated by 12.4% and 18.6%, respectively, relative to the pure PI. In terms of tribological behavior, all composite formulations displayed typical temperature-dependent friction characteristics. It is worth noting that MXene’s high hardness and thermal conductivity inhibited the occurrence of abrasive wear. At the same time, the substrate was strengthened, and thermal resistance was enhanced, thereby delaying the plastic deformation of the material at high temperatures. Full article

Bioinspired morphing offers a powerful route to higher aerodynamic and hydrodynamic efficiency. Birds reposition feathers, bats extend compliant membrane wings, and fish modulate fin stiffness, tailoring lift, drag, and thrust in real time. To capture these advantages, engineers are developing airfoils, rotor blades, and hydrofoils that actively change shape, reducing drag, improving maneuverability, and harvesting energy from unsteady flows. This review surveys over 296 studies, with primary emphasis on literature published between 2015 and 2025, distilling four biological archetypes—avian wing morphing, bat-wing elasticity, fish-fin compliance, and tubercled marine flippers—and tracing their translation into morphing aircraft, ornithopters, rotorcraft, unmanned aerial vehicles, and tidal or wave-energy converters. We compare experimental demonstrations and numerical simulations, identify consensus performance gains (up to 30% increase in lift-to-drag ratio, 4 dB noise reduction, and 15% boost in propulsive or power-capture efficiency), and analyze materials, actuation, control strategies, certification, and durability as the main barriers to deployment. Advances in multifunctional composites, electroactive polymers, and model-based adaptive control have moved prototypes from laboratory proof-of-concept toward field testing. Continued collaboration among biology, materials science, control engineering, and fluid dynamics is essential to unlock robust, scalable morphing technologies that meet future efficiency and sustainability targets. Full article

Developing control systems for high aspect ratio aircraft can be challenging due to the flexibility of the structure involved in the control loop design. A model-based approach can be straightforward to tune the control system parameters and, to this aim, a reliable aircraft flexible model is mandatory. This paper aims to present the approach pursued to design a control strategy considering the flexible aircraft simulator in the loop. Once the elastic model for the longitudinal dynamics has been set up, genetic algorithms are used to determine-together with a Linear Quadratic Regulator controller—a logic to improve the dynamic behaviour whilst encountering a gust. A relatively low order elastic model is developed for the dynamics in the longitudinal plane, including both rigid body and elastic degrees of freedom defined in a vehicle-fixed reference frame. The rigid body degrees of freedom and the associated states are the same as those of the rigid vehicle, whilst the additional states represent the elastic degrees of freedom. Modal characteristics are calculated from a finite element model of the aircraft using a commercial code, with the weight distribution added as lumped masses on grid points, while the aerodynamic rigid properties are described with a nonlinear database. Using the 2-D strip theory and neglecting the unsteady effects, the aeroelastic stability derivatives, i.e., elastic influence coefficients, are computed to superimpose the elastic effects on the rigid body degrees of freedom and vice versa. The flexible dynamics is compared to the rigid one in order to highlight the relevant changes in the aircraft modes. Following is herein proposed a control strategy combining genetic algorithms and Linear Quadratic Regulator controller to reduce the load factor, also considering the oscillation amplitude due to a deterministic gust encountered in a predefined flight condition. Full article

This study investigates the ground reaction force of lever-spring landing gear (LSLG) equipped with compressible elastomer shock absorbers (ESA) during the landing process. First, a numerical dynamic model of the LSLG was developed in MATLAB/Simulink, revealing that runway roughness exerts a negligible influence on the ground reaction force during landing. The load characteristics established fundamental references for subsequent FEA-based structural design. Furthermore, an FEA model integrating the LSLG and the aircraft was developed with parameters calibrated for elastic units. The multibody dynamics simulation (MBDS) quantified the vertical ground reaction force and the structural stresses of LSLG, demonstrating two critical relationships: (1) the overload coefficient correlated with the sinking velocity yet exhibits no correlation with aircraft mass and (2) the peak of oscillating force attenuated faster with heavier landing weight at higher sinking velocities. A nonlinear multi-variables function was fitted to predict the maximum vertical ground reaction force. Subsequently, experimental validation via a landing gear drop test (LGDT) showed a maximum error of 8.39% between the results of the LGDT and the MBDS, confirming the accuracy of simulation and the fitting surface function for force prediction. The study further validates the feasibility and reliability of using the MBDS to model and study the LSLG with ESAs. Full article

Traditional elastic correction methods fail to address the significant aeroelastic interactions arising from unsteady flow fields and structural deformations during aggressive maneuvers. To resolve this, a numerical method is developed by solving unsteady aerodynamic equations coupled with a rigid–flexible dynamics equations derived from Lagrangian mechanics in quasi-coordinates. Validation via a flexible pendulum test and AGARD445.6 wing flutter simulations demonstrates excellent agreement with experimental data, confirming the method’s accuracy. Application to a slender air-to-air missile reveals that reducing structural stiffness can destabilize the aircraft, transitioning it from stable to unstable states during forced pitching motions. Studies on longitudinal flight under preset rudder deflection control indicate that the aeroelastic effect increases both the amplitude and period of pitch angles, ultimately resulting in larger equilibrium angles compared to a rigid-body model. The free-flight simulations highlight trajectory deviations due to deformation-induced aerodynamic forces, which emphasizes the necessity of multidisciplinary coupling analysis. The numerical results show that the proposed CFD/CSD-based coupling methodology offers a robust aeroelastic effect analysis tool for flexible flight vehicles during aggressive maneuvers. Full article

This paper presents a rigid–elastic coupling dynamic model for a morphing aircraft with variable-sweep wings, developed using Kane’s method. The model accurately captures the interactions between flight dynamics and structural dynamics during morphing. To fully account for the coupling effects, we derive a morphing aircraft model consisting of a rigid fuselage and two elastic wings. Each wing is modeled as a straight beam undergoing small elastic deformations while experiencing large overall motions following the fuselage in space, along with variable-sweep rotations relative to the fuselage. These factors introduce uncertainties into the flight dynamics. To quantify the uncertainties caused by wing rotation, additional morphing forces and moments are introduced to describe morphing-induced uncertainties, while additional elastic forces and moments are defined to account for uncertainties arising from wing deformations. Numerical simulations are conducted across different models and morphing rates to analyze the dynamic characteristics. The results reveal that the elastic deformations of morphing wings significantly influence pitch angles, pitch rates, and wing vibrations, particularly during large-sweep transitions exceeding 45°. Additionally, slow morphing rates below 5°/s induce significant transient uncertainties due to elastic vibrations. These findings establish a quantitative relationship between morphing rate, vibration characteristics, and model uncertainties, providing valuable insights for trajectory tracking and attitude control in morphing aircraft. Full article

In the framework of lightweight aircraft preliminary design and optimisation, different computational approaches are formulated and assessed for the large-amplitude static aeroelastic response of very-flexible slender thin wings in subsonic incompressible flow at low speed. Starting from either a continuous or a discrete model, either numerical or semi-analytical solutions are derived and compared for several combinations of flow speed and angle of attack. Exploiting the Euler–Bernoulli beam idealisation for the wing structure and its local deformation, non-linear and quasi-linear models are presented where the elastic axis is inextensible and its global displacement is geometrically nonlinear; to this purpose, Hencky’s model is also adopted. Employing modified strip theory for the airload, reduced-order conceptual assessments and parametric evaluations are possible, and the results are shown for the Pazy wing which exhibit excellent agreement with nonlinear higher-fidelity simulations in the literature. Both closed-loop and open-loop solutions are then provided, with the latter being readily resumed from the former in the low-speed limit far away from static aeroelastic divergence. In conclusion, the novel approaches hereby explored demonstrate overall consistency while offering both theoretical insights and practical recommendations for their trust region, especially in terms of the impact and importance of the linear and nonlinear features as well as their effects. Full article

The hybrid laser inertial navigation system (INS) is increasingly vital for high precision under high-dynamic, long-duration conditions, especially in complex aircraft environments. Key components like the base, platform, and inner/outer frames significantly impact system accuracy and stability through thseir static and dynamic characteristics. This study focuses on minimizing deviations in the INS body coordinate system caused by elastic deformation under high overload by developing a mechanical simulation model of a rotational modulation structure and a structural model of the outer frame assembly. A reliability analysis model is established, considering both functional and structural strength failures. To address uncertainties from manufacturing, technical conditions, material selection, and assembly errors, a global sensitivity analysis based on Bayesian inference evaluates parameter contributions to functional failure probability, using a sample size of N1 = 5 × 10⁵. Additionally, uncertainty analysis via Sobol sequence sampling (N2 = 10,000) examines the impact of mean design parameter variations on failure probability for ZL107 and SiCp/Al aluminum matrix composite frames. Experimental verification concludes the study. The results indicate that the SiCp/Al composite material demonstrates superior mechanical performance compared to traditional materials such as the ZL107 aluminum alloy. The uncertainties in the inner frame thickness, inner frame material strength, and outer frame thickness have the most significant impact on the probability of functional failure in the hybrid INS, with sensitivity indices of ${\delta }_6^{P\left\{F\right\}}$ = 0.01657, ${\delta }_2^{P\left\{F\right\}}$ = 0.00873, and ${\delta }_4^{P\left\{F\right\}}$ = 0.00818, respectively. The mechanical properties of the outer frame structure made from SiCp/Al are significantly enhanced, with failure probabilities across three failure modes markedly lower than those of the ZL107 frame, indicating high reliability. In an impact test conducted on the product, the laser gyroscope worked normally, the hybrid laser system function was normal, and the platform angular velocity change corresponding to each impact direction was less than 12 ″/s. The maximum angle change of the inner and outer frames was 0.107°, indicating that the system structure can withstand large overloads and multiple levels of mechanical environments and has good environmental adaptability and reliability. This analytical approach provides a valuable method for reliability evaluation and design of new hybrid INS structures. More importantly, it provides insights into the influence of design parameter uncertainties on navigation accuracy, offering critical support for the advancement of inertial technology. Full article

The thermomechanical effects on aircraft structures in flight are compared between fair weather and a lightning storm based on a model problem, namely, equations of anisothermal unsteady piezoelectromagnetism are solved in the particular case of a parallel-sided slab assuming (i) steady conditions and spatial dependence only on the coordinate orthogonal to the slab; (ii) the displacement vector orthogonal to the slab; (iii) the magnetic field orthogonal to the electric field, with both in the plane parallel to the sides of the slab. The exact analytical solution is obtained in the linear approximation for the displacement vector, electric and magnetic fields and temperature as function of the coordinate normal to the slab, taking into account heating by the Joule effect of Ohmic electric currents and Fourier thermal conduction. These specify the strain and stress tensors, the electric current and the heat flux. The material properties involved include the mass density, dielectric permittivity, magnetic permeability, elastic stiffness tensor, electromagnetic coupling and thermal stress tensors, pyroelectric and pyromagnetic vectors and piezoelectric and piezomagnetic tensors. The analytic results of the theory are simplified assuming (i) isotropic material properties; (ii) a steady state independent of time. The profiles as a function of the coordinate normal to the slab of the electric and magnetic fields, temperature and heat flux and displacement, strain and stress are obtained in these conditions. Full article

This work presents a suggested analytical solution for a forced vibration of an aircraft sandwich plate with a honeycomb core under transient load. The differential equation of motion is first derived and then solved by using the separation of variables method. The plate’s transient response and maximum transient deflection are studied with various design parameters. First, the analytical results are figured out using the honeycomb structure’s mechanical properties, such as its density, Poisson’s ratio, modulus of elasticity, and modulus of rigidity. Next, the effect of the honeycomb structural properties on the transient response and the maximum transient deflection is determined. Then, the cell size, core height, and cell wall thickness are selected as the honeycomb structural parameters. The ANSYS 19.2 software package is utilized to perform the finite element simulation for the sandwich panel with the honeycomb core. This study conducted modal and transient response analyses to derive the numerical transient response and maximum transient deflection. The results demonstrate a strong concordance between the analytical and numerical results with a 95% conformity rate. Moreover, the results demonstrate an inverse relationship between the transient response and both the core height and cell wall thickness, while it is directly proportional to the cell size. This relationship is derived from the theoretical equations and further validated through numerical simulations, showing strong agreement between analytical and computational results. Full article

Despite the impressive properties of additively manufactured products, their inherent anisotropy is a crucial challenge for polymeric parts made via fused filament fabrication (FFF). This study compared the tensile, thermophysical, smoke density, and toxicity characteristics of Ultem 9085 (a blend of polyetherimide and polycarbonate) for samples printed in various orientations (X, Y, and Z). The results revealed that mechanical properties, such as elastic modulus and tensile strength, significantly differed from the Z printing orientation, particularly in the X and Y printing layer orientations. Thermomechanical analysis revealed that Ultem 9085 had high anisotropic effects in the coefficient of thermal expansion, indicating superior thermal properties along the printing orientation. The smoke density and toxicity test results proved that Ultem 9085 complies with aviation safety standards. Smoke density tests showed that all samples, regardless of print orientation or thickness, stayed well below the regulatory limit, making them suitable for aircraft interiors. Full article

An in-depth analysis was conducted on the dynamic strength design optimization of carbon fiber composite cap cones in aircraft engines subjected to bird body impacts. Initially, the top, 1/4, 1/2, 3/4, and root positions of the cap cone’s generatrix were designated as the impact sites. The analysis of bird impacts revealed that the 1/2 position along the generatrix is the most hazardous impact location. Subsequently, considering the thickness of the composite material cap cone as a variable and accounting for its high-speed rotational state, a bird impact analysis was performed at the most critical impact location. Additionally, a comparative study on the bird impact performance of the composite material cap cone under rotating and non-rotating conditions was conducted. The study indicates that, under identical conditions, the cap cone in rotation experiences more severe damage than in a non-rotating state, necessitating a cone thickness of 7 mm or greater; Subsequently, a bolt strength analysis model was established to thoroughly examine the impact of varying cone side thicknesses on the load applied to connecting bolts, and to assess bolt strength. The findings suggest that excessive bolt loads can also constrain the optimization of the cap cone; hence, finding the optimal balance between bolt quantity and strength is essential in design. Lastly, the study discussed the weakening of local stiffness in the composite material cap cone post-impact, noting a 12% decrease in its elastic mode frequency and the emergence of asymmetric vibration modes. This phenomenon could potentially lead to dynamic unbalanced loads, thus necessitating further evaluation in the optimization process of the cap cone. Full article

Regarding the dynamic magnification effect of structure stiffness on the gust analysis of civil aircraft, the following three methods are presented: rigid modes analysis, secondary processing based on elastic modes, and analysis with enlarged stiffness. These methods provide consistent gust load and address the challenge of extracting internal gust loads of rigid aircraft. The coupling resonant effects of the inertial force, the aerodynamic force, and the gust-induced aerodynamic force at different frequencies are examined. The response of flexible aircraft is nonlinearly related to frequency. It exhibits a significant increase in the inertial force and the aerodynamic force at higher frequencies, while a quasi-rigid response at very low frequencies shows the importance of sufficient analysis time. In addition, compared with rigid aircraft, flexible aircraft experiences a delay in the occurrence of extreme gust loads with the delay interval proportional to the frequency. The maximum gust load of flexible aircraft under a certain range of frequencies exceeds that of rigid aircraft, although this is not necessarily the case at the specific frequency. The dynamic magnification factor is 1.25 for the model in this study, which is almost constant and reaches its maximum value together with the gust loads when the frequency coincides with the frequency of the first bending mode. Full article

This paper focuses on the internal honeycomb structure of flexible skins for morphing aircraft, specifically targeting a unique concave honeycomb structure. By selecting specific honeycomb cells and simplifying their cell walls to beams, the equivalent elastic modulus and shear modulus were derived using the principle of virtual work. The cell was also simplified to an orthotropic plate, and the equivalent bending stiffness was derived using the principle of equivalent deformation energy. Using additive manufacturing methods and photosensitive resin materials, a series of honeycomb structure test pieces were manufactured and subjected to mechanical performance tests. The stress–strain curves and load-deflection curves of the honeycomb structures were obtained, and the equivalent elastic modulus, equivalent shear modulus, and equivalent bending stiffness were calculated from the experimental data. The theoretical values of the equivalent mechanical properties were compared with the experimental values, with errors of 4.38%, 16.67%, and 15.47% for the equivalent elastic modulus, equivalent shear modulus, and equivalent bending stiffness, respectively. Finally, the causes of the errors were analyzed, and this method has significant value for the application of such honeycomb structures. Full article

A thermal protection system is critical for ensuring the safe take-off and return of various aircraft. A key heat-resistant material within this system is the ceramic fiber insulation tile (CFIT), which is a porous three-dimensional network material with density ranges from 0.3 to 0.4 g/cm³ that exhibits complex mechanical behaviors. Due to the complexity of the service environment, experimental methods cannot accurately capture the mechanical behavior of a CFIT. Although simulation-based methods can provide insights, an accurate constitutive model for CFITs has yet to be established. To predict its complex mechanical behavior, an elastic–plastic damage constitutive model was established for CFITs. Based on the Hashin criteria and four fundamental assumptions, a yield rule was modified by introducing a damage factor in the TTT direction. The model was encoded into a user–material subroutine (UAMT) integrated within ABAQUS to capture the mechanical responses under four typical working conditions. The change trend of the simulation curve closely aligned with that of the experiment curve, better characterizing the stress–strain relationship of the CFIT under different working conditions such as compression, tension, and shear and the error was less than 18%. The proposed approach was validated by designing a millimeter-level indentation experiment. The results in this paper demonstrate that the maximum loading depths of the simulation and experiment were consistent, and the relative errors were within 12%, respectively. The research provides a reliable elastic–plastic damage constitutive model to predict the mechanical behavior of CFITs under complex working conditions. Full article
