Search Results (45)

With the aim of addressing the problem of spot drift caused by laser transmission in atmospheric turbulence, the effects of different weather conditions such as sunny, cloudy, rainy and sandstorm conditions on spot drift were measured at 0.42 km, 2 km and 10 km transmission distances, and the correction performance of a fast-steering mirror (FSM) was evaluated. The results show that under weak-turbulence conditions such as sunny, cloudy and short-distance conditions, the mean and variance of spot drift are relatively small, and the disturbance is dominated by low frequency. The FSM achieves more effective correction, significantly reduces the drift amplitude and improves the system stability. Under strong-turbulence conditions such as rainy days, dust storms and long distances, the mean and variance of drift increase significantly, and the spot disturbance frequency is higher. The response ability of the FSM to high-frequency disturbance is limited, and the correction effect decreases. In general, the FSM is more suitable for low-intensity disturbance scenarios, and its correction performance has certain limitations under strong-disturbance and long-distance conditions. Full article

Fast steering mirrors (FSMs), actuated by piezoelectric ceramics, play pivotal roles in satellite laser communication, distinguished by their high bandwidth and fast responsiveness, thereby facilitating the precise pointing and robust tracking of laser beams. However, the dynamic performance of FSMs is notably impaired by the hysteresis nonlinearity inherent in piezoelectric ceramics. Under dynamic conditions, rate-dependent hysteresis models and Hammerstein models are predominantly employed to characterize hysteresis nonlinearity. By combining the advantages of these two models, a hysteresis model termed modified Hammerstein-like (MHL) model is proposed. This model integrates an input time delay, a rate-dependent hysteresis term, and a linear dynamic term in a cascaded structure, effectively capturing the dynamic characteristics of hysteresis systems across a broad frequency range. Additionally, a composite control strategy is tailored for the MHL model which consists of a feedforward compensator based on a rate-dependent hysteresis inverse model and a proportional–integral (PI) controller for closed-loop regulation. Experimental results demonstrate the effectiveness of the proposed modeling and composite control methods. Full article

The Risley prism system offers advantages such as compact structure and excellent dynamic performance, making it suitable for installation on static and motion platforms for target acquisition, aiming, and tracking. This paper presents a strapdown line-of-sight (LOS) stabilization method for the Risley prism system on motion platforms. The method establishes the coordinate transformation between the Risley prism and the motion platform. Real-time platform attitude angles from an inertial measurement unit (IMU) are used to compute the direction cosine matrix, which, combined with the coordinate transformation, determines the target’s actual guided position in the Risley prism’s coordinate. The Risley prism’s rotational angles are then calculated based on the target’s actual guided position to ensure LOS stability and capture the target. After LOS stabilization, an image-based closed-loop tracking cascade control system that integrates a Risley prism and a fast steering mirror with a single image detector (IBCLTCR-F), is used to enable fast and high-precision target tracking. Experimental results demonstrate that the proposed method achieves disturbance rejection of −32.8 dB, −28.8 dB, and −17.3 dB for platform disturbances at 0.05 Hz, 0.2 Hz, and 0.5 Hz, respectively. Furthermore, compared to the Risley prism system, the IBCLTCR-F system improves the dynamic response capability of target tracking in the nonlinear region by a factor of 10 and reduces the tracking error by 70%. Full article

Piezo-driven fast steering mirrors (PFSMs) are widely employed in high-precision beam steering and accurate tracking applications. However, the inherent hysteresis nonlinearity of piezoelectric actuators significantly degrades tracking accuracy. To address the challenges posed by dynamic hysteresis nonlinearity, this study proposes an improved non-singular fast terminal sliding mode control strategy. The proposed method integrates a non-singular fast terminal sliding surface and introduces an adaptive function in the reaching law to enhance response speed and improve control robustness. Additionally, the strategy incorporates an extended state observer (ESO) and an inverse model-based feedforward compensation mechanism. Specifically, the feedforward compensation based on the inverse model aims to offset hysteresis effects, while the ESO provides a real-time estimation of the total system disturbance to mitigate the impact of external disturbances and unmodeled hysteresis. Experimental results demonstrate that the proposed method effectively compensates for the hysteresis nonlinearity of PFSMs, improves disturbance rejection performance, and enhances position control accuracy. Full article

With the advancement of space exploration and optical communication toward deep space, the high-precision evaluation and image stabilization of space optical payloads under micro-vibration have become increasingly critical. To address these challenges and ensure sub-micro-radian pointing accuracy for high-precision space optical payloads (HPSOPs), this paper proposes a high-precision micro-vibration testing scheme and a two-stage image stabilization system. The micro-vibration testing scheme is based on an automated quasi-zero stiffness suspension device (AQZSSD), which enhances testing sensitivity and environmental disturbance resistance, ensuring the accuracy of the results. The two-stage image stabilization system integrates three bipod vibration isolation legs (BVILs) and a decoupled fast steering mirror (FSM), extending control bandwidth and achieving comprehensive vibration suppression. Micro-vibration testing and image stabilization experiments were conducted under disturbances from multiple vibration sources. Experimental results demonstrate that the AQZSSD introduces disturbances below 0.4 Hz, confirming its quasi-zero stiffness characteristics in alignment with theoretical predictions. Furthermore, the line-of-sight (LOS) jitter root mean square (RMS) value is reduced from 1.253 μrad to 0.276 μrad, achieving sub-micro-radian stability. Additionally, due to the coupling effect of the micro-vibration response, the collaborative testing results were found to be lower than the linear superposition of individual sources. This work offers critical theoretical and technical support for the development of HPSOPs, with potential applications in future space missions and advanced optical technologies. Full article

This study proposes the design of a hybrid reluctance-actuated fast steering mirror (HRAFSM) using Maxwell’s electromagnetic normal stress principle. Strain gauges were attached to the flexible supports as sensors for measuring the rotation angles. According to Maxwell’s stress tensor theory and the theory of vibration mechanics, we obtained the dynamic equation of the HRAFSM in the uniaxial direction to investigate the relationship between the input current and the output angle of the entire system. Further, we propose a control algorithm combining proportional-integral-derivative (PID) and adaptive inverse control (AIC) to achieve high-precision control. We established an experimental system for testing and validation of the control method. The experimental results showed that the designed HRAFSM can achieve the expected rotation angle of ±1.5 mrad, and revealed a linear relationship between the rotation angle of the two axes and their corresponding strain voltages. The effectiveness of the designed controller was verified, and the amplitude tracking errors of the x- and y-axes were 0.1% and 0.14%, respectively. Full article

There is an increasing number of spacecrafts in orbit, and the collision impact of high-speed moving targets, such as space debris, can cause fatal damage to these spacecrafts. It has become increasingly important to rapidly and accurately locate high-speed moving targets in space. In this study, we designed a visible-light telephoto camera for observing high-speed moving targets and a laser rangefinder for measuring the precise distance of these targets, and we proposed a method of using fast steering mirror deflection to quickly direct the emitted laser towards such targets and measure the distance. Based on the principle of photographic imaging and the precise distance of targets, a collinear equation and a spatial target location model based on the internal and external orientation elements of the camera and the target distance were established, and the principle of target location and the method for calculating target point coordinates were determined. We analyzed the composition of target point location error and derived an equation for calculating such errors. Based on the actual values of various error components and the error synthesis theory, the accuracy of target location was calculated to be 26.5 m when the target distance is 30 km (the relative velocity is 8 km/s and the velocity component perpendicular to the camera’s optical axis is less than 3.75 km/s). This study provides a theoretical basis and a method for solving the practical needs of quickly locating high-speed moving targets in space and proposes specific measures to improve target location accuracy. Full article

We present the generalised design of low-complexity, small-aperture optical terminals intended for kilometre-scale, terrestrial, free-space laser links between fixed and dynamic targets. The design features single-mode fibre coupling of the free-space beam, assisted by a fast-steering, tip/tilt mirror that enables first-order turbulence suppression and fine target tracking. The total power throughput over the free-space link and the scintillation index in fibre are optimised. The optimal tip/tilt correction bandwidth and range, aperture size, and focal length for a given link are derived using analytical atmospheric turbulence modelling and numerical simulations. Full article

This paper presents an innovative piezo-actuated fast-steering mirror (FSM) that integrates control design and system operation to improve the tracking performance of laser beam steering (LBS) systems. The proposed piezoelectric FSM is centered on two pairs of stacked actuators functioning in the tip-tilt direction via novel flexible hinges with strain-gauge sensors for position measurement. The suggested flexible hinge scheme allows the first fundamental resonance mode with the optical mirror to exceed 400 Hz while achieving an actuation range of ±5 mrad. Thus, the design offers a wider mechanical actuation range than conventional piezoelectric FSMs. Moreover, LBS systems that use fast-steering motion controllers should be robust against dynamic disturbances, such as periodic external vibrations. Such disturbances, inherently associated with the operating conditions for LBS systems, typically reduce the stability of the tip-tilt motion. To attenuate the effects of such disturbances, a high-precision control system is necessary for the tip-tilt motion. Therefore, a control method integrating a proportional–integral controller with an adaptive feedforward control (AFC) algorithm is outlined to enhance tip-tilt tracking performance during high-speed scanning, compared with conventional LBS systems. Based on experimental findings, the AFC algorithm boosted control performance under dynamic disturbances, such as sinusoidal vibrations with multiple frequencies. Full article

Fast steering mirrors (FSMs) designed by the micro-electro-mechanical system (MEMS) technology are significantly smaller in volume and mass, offering distinct advantages. To improve their performance in the open-loop control mode, this study introduces a control algorithm and evaluates its performance on an electromagnetic-driven MEMS-FSM. The algorithm employs a method to shape the input signal by fitting the system’s transfer function and modifying the step response. This shaped signal is then applied to the system to minimize overshoot, reduce settling time, and improve working bandwidth, thereby enabling faster angular adjustments and improving the stability of the FSM. The experimental results demonstrate an 85.65% reduction in overshoot and a decrease in settling time from 84 ms to 0.4 ms. Consequently, the working bandwidth of the FSM system increases to 2500 Hz, demonstrating the effectiveness of the algorithm in enhancing MEMS-FSM’s performance. Full article

In the high-precision optoelectronic tracking system (OTS) based on a charge-coupled device (CCD), the boresight error extracted from the tracking image contains an undeniable delay, which directly limits the control bandwidth of visual tracking. High bandwidth means high response speed and tracking accuracy. Generally, a model-based delay compensation control method called the Smith predictor is utilized to separate time delay from the closed loop to promote the control bandwidth. However, due to the existence of errors between the established model and the real object, the improvement in the bandwidth is still limited to ensure system stability, resulting in insufficient tracking performance. In this paper, to solve the problem, a Smith predictor modified with pseudo feedforward control for the OTS is proposed. The experimental results demonstrate that the proposed method achieves significant improvements in tracking performance, reducing the maximum residual error at 1 Hz from 365 arcseconds (using the classic Smith predictor) to 283 arcseconds, a 22.5% improvement. Across the main frequency band (0.2 Hz to 2 Hz), the residual errors were consistently lower using the proposed method. Full article

This study presents an effective control algorithm to improve the robustness of fast steering mirror (FSM)-based laser-beam steering systems against dynamic disturbances, such as repetitive disturbances resulting from operating conditions. A stable control system must be able to maintain the required high-precision control, even when dynamic disturbances affect the FSM system. In this study, an improved control method is proposed using an internal model principle (IMP)-based nonlinear controller with a disturbance observer (DOB) for the FSM system. This IMP-based controller with DOB can attenuate the residual control-error signal under dynamic disturbance conditions. Full article

This paper presents an approach for improving the robustness of tip-tilt controllers for fast-steering mirror (FSM)-based laser beam steering (LBS) systems in the presence of dynamic disturbances such as external shocks. To this end, we propose the addition of a disturbance observer (DOB)-based anti-shock controller in parallel to the original linear servo control loop to improve its control performance in the presence of external shocks. To increase the tip-tilt control performance against external shocks, the DOB-based control method, which is an improved control method for eliminating nonperiodic disturbances, is implemented in the original tip-tilt control system. The results indicate that the control error of the DOB-based anti-shock controller decreased, resulting in an efficient improvement in its disturbance-rejection performance. Full article

In this study, a tracking and pointing control system with a dual-FSM (fast steering mirror) two-dimensional flexible turntable composite axis is proposed. It is applied to the target-tracking accuracy control in a GI LiDAR (ghost imaging LiDAR) system. Ghost imaging is a multi-measurement imaging method; the dual-FSM GI LiDAR tracking and pointing imaging control system proposed in this study mainly solves the problems of the high-resolution remote sensing imaging of high-speed moving targets and various nonlinear disturbances when this technology is transformed into practical applications. Addressing the detrimental effects of nonlinear disturbances originating from internal flexible mechanisms and assorted external environmental factors on motion control’s velocity, stability, and tracking accuracy, a nonlinear active disturbance rejection control (NLADRC) method based on artificial neural networks is advanced. Additionally, to overcome the limitations imposed by receiving aperture constraints in GI LiDAR systems, a novel optical path design for the dual-FSM GI LiDAR tracking and imaging system is put forth. The implementation of the described methodologies culminated in the development of a dual-FSM GI LiDAR tracking and imaging system, which, upon thorough experimental validation, demonstrated significant improvements. Notably, it achieved an improvement in the coarse tracking accuracy from 193.29 μrad (3σ) to 87.21 μrad (3σ) and enhanced the tracking accuracy from 10.1 μrad (σ) to 1.5 μrad (σ) under specified operational parameters. Furthermore, the method notably diminished the overshoot during the target capture process from 28.85% to 12.8%, concurrently facilitating clear recognition of the target contour. This research contributes significantly to the advancement of GI LiDAR technology for practical application, showcasing the potential of the proposed control and design strategies in enhancing system performance in the face of complex disturbances. Full article

Precision beam pointing plays a critical role in free-space optical communications terminals in uplink, downlink and inter-satellite link scenarios. Among the various methods of beam steering, the use of fast steering mirrors (FSM) is widely adopted, with many commercial solutions employing diverse technologies, particularly focusing on small, high-bandwidth mirrors. This paper introduces a method using lightweight, commercial off-the-shelf components to construct a custom closed-loop steering mirror platform, suitable for mirror apertures exceeding 100 mm. The approach involves integrating optical encoders into two off-the-shelf open-loop actuators. These encoders read the signal reflected on purposefully diamond-machined knurled screw knobs, providing maximum contrast between light and dark lines. The resulting steering mirror has the potential to complement or replace FSM in applications requiring a larger stroke, at the expense of motion speed. In the presented setup, the mirror tilt resolution achieved based on the encoder closed-loop signal feedback is 45 $\mathsf{\mu }$rad, with a mean slew rate of 1.5 mrad/s. Importantly, the steering assembly is self-locking, requiring no power to maintain a steady pointing angle. Using the mirror to actively correct for a constantly moving incoming beam, a 5-fold increase in concentration of the beam spot on the center of the detector was obtained compared to a fixed position mirror, demonstrating the mirrors ability to correct for satellite platform jitter and drift. Full article
