The transition toward more electric aircraft (MEA) and all-electric aircraft (AEA) has driven the adoption of high-voltage DC (HVDC) electrical architectures to meet increasing power demands while reducing weight and enhancing overall efficiency. However, HVDC systems introduce new challenges, particularly concerning insulation reliability and the detection of in-flight series arc faults. This paper presents the design and evaluation of a capacitive sensor specifically developed to detect series arc faults in HVDC electrical systems for aerospace applications. A model of the sensor is proposed and validated through both simulations and experimental measurements using a step response test. The results show excellent agreement between the model and the physical setup. After validating the capacitive coupling value and its response to high-frequency signals, series arcs were generated in the laboratory to evaluate the sensor’s performance under realistic operating conditions, which involve different signal dynamics. The results are highly satisfactory and confirm the feasibility of using capacitive sensing for early arc detection, particularly aligned with the stringent requirements of more electric aircraft (MEA) and all-electric aircraft (AEA). The proposed sensor thus enables non-intrusive detection of series arc faults in compact, lightweight, and safety-critical environments. Full article

Celestial navigation is rarely seen in modern Uncrewed Aerial Vehicles (UAVs). The size and weight of a stabilized imaging system, and the lack of precision, tend to be at odds with the operational requirements of the aircraft. Nonetheless, celestial navigation is one of the few non-emissive modalities that enables global navigation over the ocean at night in Global Navigation Satellite System (GNSS) denied environments. This study demonstrates a modular, low cost, lightweight strapdown celestial navigation solution that is utilized in conjunction with Ardupilot running on a Cube Orange to produce position estimates to within 4 km. By performing an orbit through a full rotation of compass heading and averaging the position output, we demonstrate that the biases present in a strapdown imaging system can be nullified to drastically improve the position estimate. Furthermore, an iterative method is presented which enables the geometric alignment of the camera with the Attitude and Heading Reference System (AHRS) in-flight without an external position input. The algorithm is tested using real flight data captured from a fixed wing aircraft. The results from this study offer promise for the application of low cost celestial navigation as a redundant navigation modality in affordable, lightweight drones. Full article

In-flight alignment is a critical milestone for inertial navigation system/global navigation satellite system (INS/GNSS) applications in unmanned aerial vehicles (UAVs). The traditional position integration formula for in-flight coarse alignment requires the GNSS velocity data to be valid throughout the alignment period, which greatly limits the engineering applicability of the method. In this paper, a new robust position integration optimization-based alignment (OBA) method for in-flight coarse alignment is presented to solve the problem of in-flight alignment under a prolonged ineffective GNSS. In this methodology, to achieve a higher alignment accuracy in case the GNSS is not effective throughout the alignment period, the integration of GNSS velocity into the local-level navigation frame is replaced by the GNSS position in the Earth-centered, Earth-fixed frame, which avoids the need for complete GNSS velocity data. The simulation and flight test results show that the new robust position integration method proposed in this paper achieves higher stability and robustness than the conventional position integration OBA method and can achieve an alignment accuracy of 0.2° even when the GNSS is partially time-invalidated. Thus, this greatly extends the application of the OBA method for in-flight alignment. Full article

This paper presents the Vertidrome Airside Level of Service (VALoS) framework, a novel performance metric designed to evaluate airside traffic flow operations at vertidromes in the context of Urban Air Mobility (UAM). As the UAM industry rapidly evolves, the need for a comprehensive evaluation framework becomes increasingly important. The VALoS framework provides a performance-based approach to evaluating vertidrome traffic flow performance, considering metrics like average passenger delay, air taxi in-flight delay, and vertidrome punctuality. Unlike existing Level of Service approaches, the VALoS framework unifies the requirements of various stakeholders, the passenger, the air taxi operator, and the vertidrome operator each with their own performance metric and target. It provides a multi-faceted approach covering airside air and ground traffic flows, arrivals and departures, and performance changes during strategic planning and tactical execution phases. The VALoS is evaluated at 15-min intervals while considering changing stakeholder performance targets and operational uncertainties. For the reference use case, the study demonstrates the significant impact of short-term disruptions, while stochastic deviations can be neglected. Higher traffic volumes due to changing demand/capacity ratios result in higher VALoS variability. The VALoS framework, together with a fast-time simulation, provides a versatile method for exploring future vertidrome traffic flows and supporting strategic vertidrome airside planning and integration. This integrated approach is essential for the evolving UAM vertidrome industry; aligning the interests of different stakeholders and promoting sustainable and efficient vertidrome planning and operation. Full article

The CSES high precision magnetometer (HPM), consisting of two fluxgate magnetometers (FGM) and one coupled dark state magnetometer (CDSM), has worked successfully for more than 5 years providing continuous magnetic field measurements since the launch of the CSES in February 2018. After rechecking almost every year’s data, it has become possible to make an improvement to the in-flight intrinsic calibration (to estimate offsets, scale values and non-orthogonality) and alignment (to estimate three Euler angles for the rotation between the orthogonalized sensor coordinates and the coordinate system of the star tracker) of the FGM. The following efforts have been made to achieve this goal: For the sensor calibration, FGM sensor temperature corrections on offsets and scale values have been taken into account to remove seasonal effects. Based on these results, Euler angles have been estimated along with global geomagnetic field modeling to improve the alignment of the FGM sensor. With this, a latitudinal effect in the east component of the originally calibrated data could be reduced. Furthermore, it has become possible to prolong the updating period of all calibration parameters from daily to 10 days, without the separation of dayside and nightside data. The new algorithms optimize routine HPM data processing efficiency and data quality. Full article

Alignment technology plays an important role in navigation, and is used extensively throughout military and civilian applications. However, the existing in-flight alignment methods cannot be applied to the low-cost based strap-down inertial navigation system/global positioning system integrated navigation system, used in short-endurance and high-speed rotation flight bodies, since they cannot quickly obtain alignment results to meet the accuracy requirements of a flight body with special movement characteristics of short-endurance and high-speed rotation. In this paper, in order to solve this challenging problem of alignment for flight body with short-endurance and high-speed rotation, a fast in-flight alignment method based on the Lie group is proposed. First, an in-flight alignment model based on vector observations was established by using the Lie group. Second, addressing the problem that the alignment accuracy is greatly affected by the low-cost inertial sensor bias, an improved unscented Kalman filter was constructed in the Lie group on the basis of fully considering the characteristics of the system equations to estimate and feedback the correlated errors. Finally, a trajectory simulation of high-speed flight body and field semi-physical test was carried out to evaluate the proposed method. Evaluation of the system performance in comparison with existing state-of-the-art methods indicated that the proposed in-flight alignment method has better alignment accuracy and faster alignment velocity for a low-cost strap-down inertial navigation system/global positioning system integrated navigation system. Full article

As a common integrated navigation system, the strapdown inertial navigation system (SINS)/global positioning system (GPS) can estimate velocity and position errors well. Many auxiliary attitude measurement systems can be used to improve the accuracy of attitude angle errors. In this paper, the in-flight alignment problem of the integrated SINS/GPS/Polarization/Geomagnetic navigation system is discussed. Firstly, the SINS/Geomagnetic subsystem is constructed to improve the estimation accuracy of horizontal attitude angles. Secondly, the polarization sensor is used to improve the estimation accuracy of heading angle. Then, a federal unscented Kalman filter (FUKF) with non-reset structure is applied to fuse the navigation data. Finally, simulation results for the integrated navigation system are provided based on experimental data. It can be shown that the proposed approach can improve not only the speed and position, but also the attitude error effectively. Full article

With the emergence of numerous low Earth orbit (LEO) satellite constellations such as Iridium-Next, Globalstar, Orbcomm, Starlink, and OneWeb, the idea of considering their downlink signals as a source of pseudorange and pseudorange rate measurements has become incredibly attractive to the community. LEO satellites could be a reliable alternative for environments or situations in which the global navigation satellite system (GNSS) is blocked or inaccessible. In this article, we present a novel in-flight alignment method for a strapdown inertial navigation system (SINS) using Doppler shift measurements obtained from single or multi-constellation LEO satellites and a rotation technique applied on the inertial measurement unit (IMU). Firstly, a regular Doppler positioning algorithm based on the extended Kalman filter (EKF) calculates states of the receiver. This system is considered as a slave block. In parallel, a master INS estimates the position, velocity, and attitude of the system. Secondly, the linearized state space model of the INS errors is formulated. The alignment model accounts for obtaining the errors of the INS by a Kalman filter. The measurements of this system are the difference in the outputs from the master and slave systems. Thirdly, as the observability rank of the system is not sufficient for estimating all the parameters, a discrete dual-axis IMU rotation sequence was simulated. By increasing the observability rank of the system, all the states were estimated. Two experiments were performed with different overhead satellites and numbers of constellations: one for a ground vehicle and another for a small flight vehicle. Finally, the results showed a significant improvement compared to stand-alone INS and the regular Doppler positioning method. The error of the ground test reached around 26 m. This error for the flight test was demonstrated in different time intervals from the starting point of the trajectory. The proposed method showed a 180% accuracy improvement compared to the Doppler positioning method for up to 4.5 min after blocking the GNSS. Full article

The optimization-based alignment (OBA) methods, which are implemented by the optimal attitude estimation using vector observations—also called double-vectors—have proven to be effective at solving the in-flight alignment (IFA) problem. However, the traditional OBA methods are not applicable for the low-cost strap-down inertial navigation system (SINS) since the error of double-vectors will be accumulated over time due to the substantial drift of micro-electronic- mechanical system (MEMS) gyroscope. Moreover, the existing optimal estimation method is subject to a large computation burden, which results in a low alignment speed. To address these issues, in this article we propose a new fast IFA method based on modified double-vectors construction and the gradient descent method. To be specific, the modified construction method is implemented by reducing the integration interval and identifying the gyroscope bias during the construction procedure, which improves the accuracy of double-vectors and IFA; the gradient descent scheme is adopted to estimate the optimal attitude of alignment without complex matrix operation, which results in the improvement of alignment speed. The effect of different sizes of mini-batch on the performance of the gradient descent method is also discussed. Extensive simulations and vehicle experiments demonstrate that the proposed method has better accuracy and faster alignment speed than the related traditional methods for the low-cost SINS/global positioning system (GPS) integrated navigation system Full article

The MinION sequencer has made in situ sequencing feasible in remote locations. Following our initial demonstration of its high performance off planet with Earth-prepared samples, we developed and tested an end-to-end, sample-to-sequencer process that could be conducted entirely aboard the International Space Station (ISS). Initial experiments demonstrated the process with a microbial mock community standard. The DNA was successfully amplified, primers were degraded, and libraries prepared and sequenced. The median percent identities for both datasets were 84%, as assessed from alignment of the mock community. The ability to correctly identify the organisms in the mock community standard was comparable for the sequencing data obtained in flight and on the ground. To validate the process on microbes collected from and cultured aboard the ISS, bacterial cells were selected from a NASA Environmental Health Systems Surface Sample Kit contact slide. The locations of bacterial colonies chosen for identification were labeled, and a small number of cells were directly added as input into the sequencing workflow. Prepared DNA was sequenced, and the data were downlinked to Earth. Return of the contact slide to the ground allowed for standard laboratory processing for bacterial identification. The identifications obtained aboard the ISS, Staphylococcus hominis and Staphylococcus capitis, matched those determined on the ground down to the species level. This marks the first ever identification of microbes entirely off Earth, and this validated process could be used for in-flight microbial identification, diagnosis of infectious disease in a crewmember, and as a research platform for investigators around the world. Full article

A slalom and alignment tracking manoeuvre was developed for multi-directional handling qualities analysis of large transport aircraft in simulation environments. The manoeuvre is defined and scaled as a function of aircraft characteristics, flight conditions using a simple set of mathematical models. Throughout the manoeuvre, the trajectory and overall performances are monitored at a set of gross position and alignment control checkpoints methodically distributed and sized to buoy the task and allow handling qualities analysis based on Cooper Harper Ratings and quantitative data analysis. Initial tests have shown that the manoeuvre sizing method led to feasible manoeuvres at multiple points of the flight envelope of a large civil transport aircraft. The manoeuvre capability to highlight desirable and undesirable handling qualities was also highlighted based on the initial findings for a couple of commercial large transport aircraft, a high aspect ratio wing and in-flight folding wingtip aircraft concepts. The relevance and applicability of the manoeuvre for multi-directional studies are discussed and compared against a more conventional offset landing manoeuvre. Finally, the potential use of the manoeuvre for different aircraft type and test flight is also suggested based on augmented reality technology. Full article

In order to guarantee the stable flight of a guided projectile, it is difficult to realize in-flight alignment for the micro inertial navigation system (MINS) during its short flight time. In this paper, a method based on changing acceleration using exponential function is proposed. First, double-vector observations were derived. Then the initial attitude for the guided projectiles was estimated by the regressive quaternion estimation (QUEST) algorithm. Further, the estimated errors were analyzed, and the reason for using the changing acceleration for the in-flight alignment was explained. A simulation and semi-physical experiment was performed to show the effectiveness of the proposed method. The results showed that the initial attitude error for the rolling angle was about 0.35°, the pitch angle was about 0.1° and the heading angle was about 0.6°, in which the initial shooting angle was between 15° and 55°. In future studies, the field experiments will be carried out to test the stability of the proposed in-flight alignment for guided projectiles. Full article

This paper presents an innovative method for estimating the attitude of airborne electro-optical cameras with respect to the onboard autonomous navigation unit. The procedure is based on the use of attitude measurements under static conditions taken by an inertial unit and carrier-phase differential Global Positioning System to obtain accurate camera position estimates in the aircraft body reference frame, while image analysis allows line-of-sight unit vectors in the camera based reference frame to be computed. The method has been applied to the alignment of the visible and infrared cameras installed onboard the experimental aircraft of the Italian Aerospace Research Center and adopted for in-flight obstacle detection and collision avoidance. Results show an angular uncertainty on the order of 0.1° (rms). Full article
