Magnetorheological elastomers (MREs) have recently attracted significant attention for the development of adaptive vibration isolators and absorbers. Their ability to tune mechanical properties in response to external excitations makes them promising candidates for semi-active control applications. In this study, the Generalized Maxwell model with three Maxwell branches is employed to predict variations in storage and loss moduli of isotropic MREs operating in shear mode under varying excitation frequencies and magnetic flux densities. A practical semi-active MRE-based seat vibration isolator is proposed, and a multidisciplinary design optimization problem is subsequently formulated to determine the optimal geometrical parameters of the isolator. The objective is to maximize the frequency bandwidth while satisfying constraints on weight, material magnetic saturation, and total volume. The optimization results demonstrate that the proposed adaptive isolator can achieve a significant relative increase in its natural frequency by adjusting the applied magnetic flux density, while maintaining a practical total mass. A post-optimality analysis is also conducted to investigate the influence of the upper bound on the isolator’s mass. The findings reveal a nonlinear relationship between the optimal frequency ratio and the total mass of the isolator. Finally, closed-loop control strategies based on on–off skyhook and PID control are implemented and compared to evaluate the capability of the proposed adaptive isolator to mitigate vibration and shock under varying disturbances. Full article

Continuous impact vibrations caused by uneven road surfaces (such as speed bumps) can significantly reduce the trajectory tracking accuracy of mobile manipulator. This study proposes for the first time an integrated framework combining a semi-active magnetorheological elastomer (MRE) intelligent isolation system with an active trajectory tracking controller to improve the operational accuracy of mobile manipulator under continuous impact excitation, and numerically evaluates the effect of the MRE isolation system. The working principle and design method of the MRE isolation system for mobile manipulators are described, and a multi-layer MRE isolator is fabricated and experimentally characterized. A semi-active control strategy is developed to adaptively adjust the stiffness and damping of the isolator based on continuous impact input. To further compensate for residual disturbances transmitted through the isolator, an enhanced computational torque control (CTC) and proportional-derivative (PD) controller with predefined-time disturbance observer (DOB) is designed for the mobile manipulator. This ensures that the disturbance estimate converges within a predefined time window, thereby improving the robustness of the closed-loop system. By constructing a comprehensive multibody dynamics model coupling the vehicle, the MRE isolator, and the manipulator, vibration transmission is analyzed and trajectory tracking performance is evaluated. Simulation results under continuous road impact excitation demonstrate that the proposed semi-active MRE intelligent isolation system can significantly suppress base vibration and greatly improve the trajectory tracking accuracy of the mobile manipulator end-effector and its joints. This study proves the feasibility of the semi-active MRE isolation system in the trajectory tracking application of mobile manipulator and provides a new approach for the collaborative design of intelligent vibration isolation and control strategies for mobile robot systems operating in harsh and frequently impacted environments. Full article

Magnetorheological elastomers (MREs) have attracted considerable attention in high-precision sensing and intelligent control due to their responsive sensitivity. The magnetostrictive properties of MREs excited by magneto-mechanical coupling at the mesoscopic scale show broad application potential but have not yet been fully elucidated. In this study, the magnetostrictive properties were investigated at the mesoscopic scale through theoretical modeling, numerical simulation and experimental research. A correction factor was introduced to address the limitations of conventional magnetic dipole theory under near-field conditions, thereby providing a rational theoretical explanation of magnetostrictive behavior. Visualization analysis was performed using the finite element method (FEM). Subsequently, MREs were prepared under various solidified magnetic fields, and their performance was validated through scanning electron microscopy (SEM) and a laser displacement sensor. The results demonstrated that magnetostriction is determined by the relative angle between the particle chain and the magnetic field direction. The linearity of the particle chain was found to be positively correlated with magnetostriction. The maximum theoretical and experimental magnetostrictive elongations reached 0.9% and 0.565%, respectively, while the maximum theoretical and experimental magnetostrictive compression reached 2.77% and 1.81%, respectively. This work provides significant scientific insights into the magneto-mechanical energy conversion mechanism and contributes to the development of magnetostrictive instruments. Full article

Soft robotics focuses on the imitation of the work of living organisms and mostly utilizes soft deformable materials for actuation or object manipulation tasks. Soft robots or grippers can be used for tasks which are beyond the reach of conventional rigid body ones. Recently, soft flexible robotic grippers have attracted research and engineering interest. A variety of materials and actuation technologies incl. magnetorheological (MR) materials have been used for developing grippers for grasping and object manipulation purposes. In this proof-of-concept study, the authors propose a magnetorheological elastomer (MRE) based gripper concept that deforms when subjected to magnetic field, thus adapting to objects of various shapes and sizes. With the prototype, a reduction in the closing area by a factor of four was achieved. To realize the assumed goals, a prototype of the gripper was designed, built, and tested, and its behaviour was evaluated, focusing on its adaptability and identification of the opening/closing current levels. Moreover, a contactless CV (computer vision)-based method was developed for the purpose of assessment of the prototype’s operation. The experiments involved the handling of cylindrical and cubic objects, respectively. The experimental results indicate that the operation is repeatable, and with no visible degradation of the flexible casing. Full article

Magnetorheological elastomers (MREs) are composed of soft silicone rubber, carbonyl iron particles (CIPs), and various additives. This study designs and fabricates a novel hybrid-mode MRE isolator that can operate in both compression and shear modes simultaneously. Experimental and modeling investigations are conducted to examine the dynamic mechanical properties of the hybrid-mode MRE isolator under varying excitation frequencies, displacement amplitudes, and magnetic field strengths. The equivalent stiffness, energy dissipation, and equivalent damping of the MRE isolator are determined. Experimental results reveal that the hybrid-mode MRE isolator exhibits a pronounced MR effect by utilizing a hybrid magnetic field generation system, with all three parameters significantly increasing as the magnetic field strength increases. However, as the excitation frequency increases, the equivalent stiffness and energy dissipation increase, while the equivalent damping decreases. Based on the experimental findings, a compression–shear hybrid fractional-derivative parametric (CSHF) model is proposed to describe the impact of different operating conditions on the dynamic viscoelastic properties of the MRE isolator. A comparative analysis of the experimental results and model predictions indicates that the proposed mechanical model can accurately describe the dynamic mechanical characteristics of the hybrid-mode MRE isolator. Full article

Magnetorheological elastomers (MREs) are a type of smart materials formed by dispersing magneto-responsive micron particles in an elastic polymer matrix. They hold significant potential for various applications due to their tunable stiffness, capability to carry out non-contact actuation, and rapid responsiveness to magnetic fields. However, weak interfacial interactions and poor dispersion of magnetic particles within the polymer matrix often lead to diminished magnetorheological (MR) performance. In this study, carbonyl iron powder (CIP) was chemically modified via polydopamine (PDA) deposition followed by grafting with isobutyl (trimethoxy)silane (IBTMO) to enhance its compatibility with a silicone-based matrix. The resulting anisotropic MREs fabricated using the dual-modified CIP exhibited a reduced elastic modulus, enhanced elongation, a large magnetically induced bending angle of 38°, and a notably improved MR effect of 246.8%. Furthermore, a magnetic soft actuator was designed based on the anisotropic dual-modified CIP-based MRE. When used as flippers for a duck model, the actuator successfully propelled a load approximately 76.8 times its own weight at a speed of 3.48 mm/s, thereby demonstrating promising potential for applications requiring load-bearing actuation. Full article

Magnetorheological fluids (MRFs) and elastomers (MREs) are two types of smart materials that exhibit modifiable rheological properties in response to an applied magnetic field. Although they share a similarity in their magnetorheological response, these two materials differ in their nature, structure, and mechanical behavior when exposed to a magnetic field. They also have distinct application differences due to their specific rheological properties. These fundamental differences therefore influence their properties and applications in various industrial fields. This review provides a synthesis of the distinct characteristics of MRFs and MREs. The differences in their composition, rheological behavior, mechanical properties, and respective applications are summarized and highlighted. This analysis will enable a comprehensive understanding of these differences, thereby allowing for the appropriate selection of the material based on the specific requirements of a given application and fostering the development of new applications utilizing these MR materials. Full article

Traditional magnetorheological elastomers (MREs) often suffer from limited modulus tunability and insufficient energy dissipation, which restrict their applications. This study prepared a novel composite material by an MR gel (MRG) embedded within the MRE, called the MRE encapsulating MRG, to synergistically enhance these properties. Annular and radial MRE encapsulating MRG configurations were fabricated using 3D-printed molds, and their dynamic mechanical performance was characterized under varying magnetic fields (0–1 T) via a rheometer. The results revealed that the composite materials demonstrated significantly improved magnetic-induced modulus and magnetorheological (MR) effects compared to conventional MREs. Specifically, the annular MRE encapsulating MRG exhibited a 238.47% increase in the MR effect and a 51.35% enhancement in the magnetic-induced modulus compared to traditional MREs. Correspondingly, the radial configuration showed respective improvements of 168.19% and 27.03%. Furthermore, both the annular and radial composites displayed superior energy dissipation capabilities, with loss factors 2.68 and 2.03 times greater than those of pure MREs, respectively. Dynamic response tests indicated that composite materials, particularly the annular MRE encapsulating MRG, achieve faster response times. These advancements highlight the composite’s potential for high-precision damping systems, vibration isolation, and adaptive control applications. Full article

The macroscopic magnetic properties of magnetorheological elastomers (MREs) are influenced by their microstructure, yet limited investigations has been conducted on this subject to date. In this paper, a microstructure-based model is proposed to investigate the magnetization response of MREs. The dipole theory is employed to compute the local magnetic field, and a fitting equation derived from finite element analysis is used to correct the magnetic field. The Fröhlich–Kennelly equation is applied to describe the nonlinear magnetic properties of the particle material. Based on experimental observations, a body-centered tetragonal (BCT) model is established to describe the magnetization properties of anisotropic MREs. The proposed model is validated by comparison with experimental data and can be utilized to predict the effective susceptibility of MREs. The effects of particle volume fraction, the direction of the external magnetic field, and the shape of the MRE samples can also be analyzed using this model. Full article

Rotary drilling systems with PDC bits, commonly used for drilling deep wells in the production and exploration of oil and natural gas, frequently encounter severe vibrations. These vibrations can cause significant damage to the drilling system, particularly its downhole components, leading to drilling performance inefficiencies, notably reducing the rate of penetration and incurring high costs. This paper presents a parametric study on a proposed new axial semi-active tool designed to mitigate these unwanted vibrations. The tool, an axial absorber with tunable stiffness and damping coefficients over a wide range, composed of a hybrid magnetorheological elastomer-fluid (MRE-F), is installed above the PDC bit. In this study, the lumped parameter model considering axial and torsional vibrations is followed to assess the effectiveness of including the proposed absorber in the drill-string system’s behavior and to estimate the optimal coefficient values for achieving high-efficiency drilling. The drilling system response shown in this study indicates that, with optimal axial absorber coefficient values, the bit dynamically stabilizes, and unwanted vibrations are minimized, effectively eliminating the occurrence of bit-bounce and stick–slip, even when operating at critical frequencies. The proposed semi-active control tool has been proven to significantly reduce maintenance time, reduce the costs associated with severe vibrations, extend the lifespan of bottom-hole assembly components, and achieve smoother drilling with a simple addition to the drilling system. Full article

Rubber materials can endure substantial deformation while avoiding permanent damage or rupture, making them highly suitable for applications in the automotive industry and other sectors, particularly for noise and vibration reduction. However, rubber experiences degradation over time as defects or cracks appear and propagate under fluctuating loads. Therefore, it is of critical importance to prevent the failure of rubber components during service. As highlighted in prior literature surveys by Tee et al. in 2018, Mars and Fatemi in 2002 and 2004, significant research has focused on the mechanics and analysis of rubber fatigue. This body of work has grown rapidly and continues to evolve. Therefore, this study aims to compile and analyze the vast body of recent research on rubber fatigue conducted over the last decade, supplementing the reviews by Tee et al. in 2018, Mars and Fatemi in 2002 and 2004. The gathered studies were analyzed to identify current trends and emerging research gaps in the fatigue study of rubber, including advanced composite rubber materials such as magnetorheological elastomers (MREs). This review emphasizes the analysis techniques and fatigue experiments available for fatigue life prediction in rubber materials, while illustrating their practical applications in engineering analyses through specific examples. Full article

Magnetorheological elastomers (MREs) are smart composite materials with tunable mechanical properties by ferromagnetic particle interactions. This study applied the microstructure-based dipole and Maxwell methods to evaluate the magneto-mechanical coupling and magnetostrictive responses of MREs, focusing on various particle distributions. The finite element modeling of representative volume elements with fixed volume fractions revealed that the straight chain microstructure exhibits the most significant magnetostrictive effect due to its low initial shear stiffness and significant magnetic force contributions. For particle separations exceeding three radii, the dipole and Maxwell methods yield consistent results for vertically or horizontally aligned particles. For particle separations greater than three radii, the dipole and Maxwell methods produce consistent results for vertically and horizontally aligned particles. However, discrepancies emerge for angled configurations and complex microstructures, with the largest deviation observed in the hexagonal particle distribution, where the two methods differ by approximately 27%. These findings highlight the importance of selecting appropriate modeling methods for optimizing MRE performance. Since anisotropic MREs with straight-chain alignments are the most widely used, our results confirm that the dipole method offers an efficient alternative to the Maxwell method for simulating these structures. Full article

In order to meet the dual requirements of hydraulic dynamic sealing to ensure a reduction in friction, this study prepared polyurethane-based magnetorheological elastomers (MREs). The compression performance of isotropic and anisotropic samples under a magnetic field was tested in samples containing carbonyl iron powder (CIP) particles with different volume contents and particle sizes. The compression performance of isotropic and anisotropic samples under the magnetic field was tested under static loading, and the friction coefficient changes in isotropic and anisotropic samples under a magnetic field were analyzed by a friction testing machine. The test results show that under static compression load, the contact stress of isotropic and anisotropic specimens increases with the increase in magnetic field strength, and the magnitude of the contact stress changes when the increase in magnetic field strength is proportional to the CIP content and CIP particle size of the specimen. The friction test results of the samples showed that an increase in magnetic field strength, CIP particle diameter, and CIP content reduces the friction coefficient of the CIP particle polyurethane-based magnetorheological elastomer samples, and the variation in the magnetic friction coefficient of anisotropic samples is greater than that of isotropic samples. This research result indicates that utilizing the magneto-mechanical properties of polyurethane-based magnetorheological elastomers can provide an innovative solution to the inherent contradiction between increasing contact stress and avoiding wear in the dynamic sealing of hydraulic systems, which can provide controllable sealing performance for hydraulic dynamic sealing components in specific application scenarios, enabling them to have a better sealing ability while reducing the friction coefficient of the sealing pair. Full article

The application of smart materials in robots has attracted considerable research attention. This study developed an inchworm robot that integrates smart materials and a bionic design, using the unique properties of magnetorheological elastomers (MREs) to improve the performance of robots in complex environments, as well as their adaptability and movement efficiency. This research stems from solving the problem of the insufficient adaptability of traditional bionic robots on different surfaces. A robot that combines an MRE foot, an electromagnetic control system, and a bionic motion mechanism was designed and manufactured. The MRE foot was made from silicone rubber mixed with carbonyl iron particles at a specific ratio. Systematic experiments were conducted on three typical surfaces, PMMA, wood, and copper plates, to test the friction characteristics and motion performance of the robot. On all tested surfaces, the friction force of the MRE foot was reduced significantly after applying a magnetic field. For example, on the PMMA surface, the friction force of the front leg dropped from 2.09 N to 1.90 N, and that of the hind leg decreased from 3.34 N to 1.75 N. The robot movement speed increased by 1.79, 1.76, and 1.13 times on PMMA, wooden, and copper plate surfaces, respectively. The MRE-based intelligent foot design improved the environmental adaptability and movement efficiency of the inchworm robot significantly, providing new ideas for the application of intelligent materials in the field of bionic robots and solutions to movement challenges in complex environments. Full article

Magnetorheological elastomers (MREs) are in demand in the field of high-tech microindustries and nanoindustries such as biomedical applications and soft robotics due to their exquisite magneto-sensitive response. Among various MRE applications, programmable actuators are emerging as promising soft robots because of their combined advantages of excellent flexibility and precise controllability in a magnetic system. Here, we present the development of magnetically programmable soft magnetic microarray actuators through field-induced injection molding using MREs, which consist of styrene-ethylene/butylene styrene (SEBS) elastomer and carbonyl iron powder (CIP). The ratio of the CIP/SEBS matrix was designed to maximize the CIP fraction based on a critical solids loading. Further, as part of the design of the magnetization distribution in micropillar arrays, the magnetorheological response of the molten composites was analyzed using the static and dynamic viscosity results for both the on and off magnetic states, which reflected the particle dipole interaction and subsequent particle alignment during the field-induced injection molding process. To develop a high-aspect-ratio soft magnetic microarray, X-ray lithography was applied to prepare the sacrificial molds with a height-to-width ratio of 10. The alignment of the CIP was designed to achieve a parallel magnetic direction along the micropillar columns, and consequently, the micropillar arrays successfully achieved the uniform and large bending actuation of up to approximately 81° with an applied magnetic field. This study suggests that the injection molding process offers a promising manufacturing approach to build a programmable soft magnetic microarray actuator. Full article
