The bond between steel bars and concrete is a fundamental aspect of reinforced concrete, ensuring the efficient transfer of forces between the two materials and guaranteeing their compatibility and composite action. The conventional equation for calculating bond stress does not account for slip effects. However, significant slip can lead to considerable errors, which are disadvantageous when analyzing bond performance using finite element methods. To address this issue, this study proposed a modified bond stress calculation model, whose reliability was systematically validated through pull-out tests and comparative analysis with a CEB-FIP model. The experimental program employed a universal testing machine for load application, with a static strain measurement system continuously monitoring stress–strain data throughout the loading process. The experimental results indicated that the failure process of the specimens could be categorized into the following, four distinct stages: micro-slip stage, slip stage, descent stage, and residual stage. The discrepancy between bond stresses calculated by the modified and conventional equations increased with the increasing relative slip, reaching its maximum value in the residual stage. A comparative analysis of 23 groups of experimental data from the literature was performed, revealing that the difference in bonding stress reached a maximum of 20.45% in the residual stage, with a standard deviation (S) of 0.006 and a coefficient of variation (C_v) of 0.321, reflecting small fluctuations but large dispersion. In contrast, the S of the residual bonding stress was 0.016, and the C_v was 0.080, showing lower dispersion but greater volatility. Further comparison with the CEB-FIP model confirmed the superior applicability and computational accuracy of the proposed modified model. Therefore, the modified equation should be utilized for calculating bond stress when significant slip occurs, particularly during the residual stage. Full article

The slip mechanism between the chunk and wafer during high-speed dynamic scanning of the extreme ultraviolet lithography (EUV) motion stage remains unclear. Considering real-machined roughness, molecular dynamics (MD) simulations were performed to investigate the nanotribological behavior of 6H-SiC sliders on single-crystal silicon substrates. The effects of sinusoidal asperity parameters and normal loads on wear and slip were systematically analyzed. Results indicate that, for friction between sinusoidal asperities and ideal flat surfaces, the amplitude of surface parameters exhibits negligible influence on friction. In contrast, reduced normal loads and lower periods significantly increase both friction force and coefficient of friction (COF). Full article

The safe and efficient torque transmission of wet disk clutch systems requires high coefficients of friction. To achieve good controllability and high comfort, a positive slope of the coefficient of friction over sliding velocity is ensured by a reasonable formulation of the lubricant and choice of the friction pairing. This results in low transmittable torque at low sliding velocities. Thus, the occurrence of unwanted micro-slip in dynamic operation modes must be considered for the design of safety-relevant clutch systems. This work presents a methodology for the holistic measurement of the friction behavior of wet disk clutches. It is suitable for numerous applications and supports a sound understanding of frictional properties in the range of sliding velocities occurring in brake shifts through forced slip operation down to static torque transmission. The experimental determination of the holistic friction behavior is crucial for developing optimized design guidelines for modern clutch systems. Full article

Contacts and joints in structures, mechanisms, and dynamic systems often exhibit high localized interface shear at their edges, leading to edge microslip and fretting wear and fatigue. This introduces complexity, nonlinearity, and multiscale friction phenomena. This paper presents a novel approach to address this issue by introducing geometrical changes near contact edges. Two-dimensional contact models are developed and analyzed using asymptotic, closed-form, and numerical methods to study the effect of edge changes on pressure and shear traction. The results show that geometric changes near contact edges can effectively reduce contact edge shear, thereby inhibiting edge microslip and the resulting fretting wear and fatigue in contacts that occur under dynamic conditions. This approach has implications for reduced complexity in contacts and joints for improved capability in modeling, analysis, and measurement characterization. Full article

In order to study the bond performance between desert sands engineered cementitious composites (DS-ECC) and corrosion steel bars, seven groups of specimens were designed and manufactured. Through the center pull-out test, the effects of different types of desert sands, the rate of corrosion (0, 5, 10 and 15%), and the anchorage length of steel bars (5d and 8d) on the bonding properties of DS-ECC and corrosion steel bars were studied. Moreover, a de-rusting agent was used to remove the corrosion, and three groups of specimens were pulled out from the center of the de-rusted steel bars. The results showed that both Tengger DS-ECC and Mu Us DS-ECC have good bond properties with corrosion steel bars. The bond stress slip curves between DS-ECC and corrosion steel bars can be divided into four stages: the micro-slip, slip stage, failure stage and residual stage. The bond stress slip curves between DS-ECC and de-rusted steel bars can be divided into the micro-slip stage, failure stage and residual stage, and splitting and pulling-out failure occurs in DS-ECC specimens. The ultimate bond strength is the highest when the corrosion rate is 5%. The bond toughness index is positively correlated with the anchorage length of steel bars, and negatively correlated with the corrosion rate of steel bars. According to the test results, the bond–slip mathematical relationship is established. Full article

In high production gas wells, premium connections are subject to alternating loads and vibration excitation due to the change of fluid pressure exerted on the tubing string. The energy dissipation on the sealing surface of premium connections affects the sealing performance of premium connections. The present study proposes a new energy dissipation analysis method for the sealing performance of premium connections using a microslip shear layer mode, a novel technique to overcome and improve the limitations of existing analysis method of premium connections. In this paper, based on a microslip shear layer model, a vibration equilibrium equation of premium connection was established with the constraints of the taper of the sealing surface, the thread, and the torque shoulder. Then, the control equilibrium equations of the stick and microslip were derived, and the critical microslip tangential force and force–displacement hysteresis curves under different interface parameters were obtained by solving the equilibrium equations. The influence of different interface parameters on the energy dissipation of premium connection was discussed by using a standardized regression coefficient method. It was found that the friction coefficient influenced both the minimum and maximum microslip tangential forces, while the shear layer stiffness influenced only the minimum microslip tangential force. The greater the stiffness of the shear layer, the smaller the minimum microslip tangential force and the relative displacement of the contact surface, which made it easier to generate energy dissipation. The influence of the friction coefficient on energy dissipation was much greater than the stiffness of the shear layer. There was positive correlation between the friction coefficient and energy dissipation. While, there was a negative correlation between the stiffness of shear layer and energy dissipation. The results can provide a theoretical guide for micro sealing failure mechanism of premium connections under dynamic loads and expand the analysis method of metal seals. Full article

The accumulation of tangential small slips at contact interfaces may occur in mechanical assemblies when subjected to cyclic loadings, and cause failure of parts. However, the slip is difficult to measure directly. In this paper, a self-powered displacement sensor based on triboelectric nanogenerator (TENG) is fabricated, which is used to measure the microslip of the specimen in the designed test bench. When the specimen slips under the cyclic tangential load with a frequency of 10 Hz, the resulted average slip displacement of the specimen under a single load cycle is 9.01 μm, which is measured by the Keithley DAQ 6510 multimeter (Tektronix, Shanghai, China). This value is close to that measured by the Keithley 6514 electrometer. In addition, adding a ${\mathrm{BaTiO}}_3$ thin film with a thickness of 100 nm between the Kapton triboelectric layer and the Cu electrode, the output voltage of the sensor is increased by 51.5%. Thus, the sensitivity of the self-powered sensor is improved effectively. Full article

Fretting fatigue is a fatigue damage process that occurs when two surfaces in contact with each other are subjected to relative micro-slip, causing a reduced fatigue life with respect to the plain fatigue case. Fretting has now been studied deeply for over 50 years, but still no univocal design approach has been universally accepted. This review presents a literature study that involves the three main types of mechanical joint affected by fretting fatigue (press-fitted shaft hub joints, dovetail joints, and bolted joints) aiming at giving insight into the progress made in terms of design guidelines for engineers. Full article

In this paper, a two-step tuning strategy of a finite element (FE) model of a bridge with pot bearings exposed to mining-triggered tremors of various intensities is proposed. In the study, a reinforced concrete bridge 160 m long is considered. Once the modal identification of the bridge was experimentally carried out based on low-energy ambient vibrations, the FE model was tuned by replacing the free-bearing sliding with a Coulomb friction-regularized model. This model of friction split the tangential relative displacement rates between contacting surfaces into a reversible elastic part and irreversible sliding. The elastic microslip (spring-like behavior) prior to macrosliding can be explained by the deformation of asperities (roughness of contacting surfaces on the microscopic scale). The proposed model allows for accurate sliding bearing performance simulation under both low-energy and high-energy mining-induced tremors. In the first step of the FE model tuning strategy, the elastic microslip constant was experimentally estimated based on the modal identification. In the second step, the macro-sliding friction parameter was implemented to address the realistic behavior of the bridge under mining-induced shocks. Finally, the dynamic responses of the bridge to mining-triggered tremors of various intensities were calculated and assessed using the untuned and tuned FE models. The analysis proved that the untuned model was not suitable for dynamic bridge assessment in the case of low-intensity tremors. The stresses obtained for this model turned out to be strongly underestimated. For shocks of higher intensity, frictionless sliding at the bearings gives a relatively good global estimation of the structure performance but undervalues its local response. The analysis also reveals that the tuned Coulomb friction-regularized model allows for the accurate simulation of sliding bearings under both low and high-energy mining-induced tremors. Full article

During the bearing service, a series of microstructural evolutions will arise inside the material, such as the appearance of feature microstructures. The essential reason for the microstructural evolution is the cumulative effect of cyclic stress. The Hertz Contact formula is usually adopted to calculate the internal stress, and there is a correlation between the shape and distribution of the feature microstructure and the stress distribution. But it is insufficient to explain the relationship between the morphology of feature microstructures and the rolling direction, such as specific angles in butterfly and white etching bands. The rolling phenomenon will cause the asymmetry of stress distribution in the material, which is the source of the rolling friction coefficient. Moreover, slipping or microslip will produce additional stress components, which also cause the asymmetry of the stress field. However, there is no experimental or theoretical explanation for the relationship between the asymmetry of the stress field and the feature microstructure. According to the current theory, the appearance of feature microstructures is caused by stress with or without rolling. Therefore, it is of great significance to study the formation mechanism: whether feature microstructures will appear in the uniaxial cyclic compression stress field without rolling. In this paper, uniaxial cyclic compressive stress was loaded into a plate-ball system and a cylinder system. The characteristics of microstructural change of bearing steel (GCr15) were studied. It was found that the hardness of the material increased after the cyclic compressive load, and the inclusions interacted with the matrix material. In the local microregion a white etching area was found, although the scale is very small. No large-scale feature microstructures appeared. Other phenomena in the experiment are also described and analyzed. For example, the production of oil film in the contact area and the changing law of alternating load. Full article

Wire ropes undergo a fretting fatigue condition when subjected to axial and bending loads. The fretting behavior of wires are classified as line contact and trellis point of contact. The experimental study on the fatigue of wire ropes indicates that most of the failure occurs due to high localized stresses at trellis point of contact. A continuum damage mechanics approach was previously proposed to estimate the fatigue life estimation of wire ropes. The approach majorly depends on the high value of localized stresses as well as the micro-slippage occurs at the contact region. Finite element approach has been used to study radial and axial distribution of stresses and displacement in order to clearly understand the evolution of stresses and existence of relative displacements between neighboring wires under various loading and frictional conditions. The relative movements of contacting wires are more when friction is not considered. In the presence of friction, the relative movement occurs at the boundaries of the contact region. The location of microslip in the presence of friction is backed by the experimental observation stating the crack is initiated at or the outer boundary of the contact spot. The existence of slip is due to different displacement of outer and central wires. Full article

This article reviews fretting wear damage in industries and in the contact mechanics of coated systems. Micro-slip motion resulting in fretting damage is discussed along with major experimental factors. The experimental factors, including normal force, relative displacement, frequency and medium influence are directly compared. Industrial solutions to reduce fretting damages are then discussed. The contact mechanics of a coated system are reviewed to quantify stress states in a coating layer and the substrate. Finally, a literature review on simulation for fretting is carried out. This review study provides useful methods and practical solutions to minimize fretting wear damage. Full article
