Search Results (96)

This work studies the impact of different physical and material parameters on the channel resistance, $R_{ch}$, and threshold voltage, $V_{th}$, of nanowire field-effect transistors (NWFETs). In particular, by means of detailed numerical simulations, we investigate the role of the channel length, nanowire diameter, gate oxide thickness, channel-doping concentration, energy bandgap, oxide thickness, and gate oxide permittivity in a wide range of temperatures (200–500 K). Our findings show that optimal values for both $R_{ch}$ and $V_{th}$ are achieved by reducing the nanowire channel length, as well as by increasing the nanowire diameter and doping concentration. Furthermore, NWFETs benefit from using wide-bandgap materials and thinner oxide layers with a higher permittivity. Notably, in short-channel NWFETs operating under ballistic transport, channel resistance remains nearly constant with temperature, governed by quantum conductance and injection statistics rather than temperature-sensitive scattering. These results underscore the complex interplay between material selection, doping levels, and device geometry in shaping the threshold voltage and the channel resistance of NWFETs. Also, they are useful for enhancing the device stability and advancing the design of NWFETs for the next-generation of nanoscale transistors. Full article

This study investigates the morphological evolution of epitaxial indium antimonide (InSb) nanowires (NWs) grown via chemical vapor deposition (CVD). We systematically explored the influence of key growth parameters—temperature (300 °C to 480 °C), source material composition, gold (Au) nanoparticle catalyst size, and growth duration—on the resulting NW morphology, specifically focusing on NW length and tapering. Our findings reveal that the competition between axial and radial growth modes, which are governed by different growth mechanisms, dictates the final nanowire shape. An optimal growth condition was identified that yields straight and minimally tapered InSb NWs. High-resolution transmission electron microscopy (TEM) confirmed that these nanowires grow preferentially along the <110> direction, and electrical characterization via field-effect transistor (NW-FET) measurements showed that they are n-type semiconductors. Full article

In this article, femtosecond laser scanning was used to create heterojunctions between silver nanowire (Ag NW) and graphene oxide (GO), resulting in a mechanical and electrical interconnection. Surface plasmon resonances (SPRs) were generated on the nanowire surface by using femtosecond laser irradiation, producing a periodically excited electric field along the Ag NWs. This electric field then interfered with the femtosecond laser field, creating strong localized heating effects, which melted the Ag NW and GO, leading to mechanical bonding between the two. The formation of these heterostructures was attributed to the transfer of plasmon energy from the Ag NW to the adjacent GO surface. Since the connection efficiency of the nanowires is closely related to the specific location and the polarization direction of the laser, FDTD simulations were conducted to model the electric field distribution on the surface of Ag NW and GO structures under different laser polarization directions, varying the lengths and diameters of the nanowires. Finally, the resistance changes of the printed Ag NW paths on the GO thin film after femtosecond laser irradiation were investigated. It was found that laser bonding could reduce the resistance of the Ag NW-GO heterostructures by two orders of magnitude, further confirming the formation of the junctions. Full article

Copper nanowires (Cu NWs) are considered a promising alternative to indium tin oxide (ITO) and silver nanowires (Ag NWs) due to their excellent electrical conductivity, mechanical properties, abundant reserves, and low cost. They have been widely applied in various optoelectronic devices. In this study, Cu NWs were synthesized using copper chloride (CuCl₂) as the precursor, monoethanolamine (MEA) as the complexing agent, and hydrated hydrazine (N₂H₄) as the reducing agent under strongly alkaline conditions at 60 °C. Notably, this is the first time that MEA has been employed as a complexing agent in this synthesis method for Cu NWs. Through a series of experiments, the optimal conditions for the CuCl₂–MEA–N₂H₄ system in Cu NWs synthesis were determined. This study revealed that the presence of amines plays a crucial role in nanowire formation, as the co-ordination of MEA with copper in this system provides selectivity for the nanowire growth direction. MEA prevents the excessive conversion of Cu(I) complexes into Cu₂O octahedral precipitates and exhibits an adsorption effect during Cu NWs formation. The different adsorption tendencies of MEA at the nanowire ends and lateral surfaces, depending on its concentration, influence the growth of the Cu NWs, as directly reflected by changes in their diameter and length. At an MEA concentration of 210 mM, the synthesized Cu NWs have an average diameter of approximately 101 nm and a length of about 28 μm. To fabricate transparent conductive films, the Cu NW network was transferred onto a polyethylene terephthalate (PET) substrate by applying a pressure of 20 MPa using a tablet press to ensure strong adhesion between the Cu NW-coated mixed cellulose ester (MCE) filter membrane and the PET substrate. Subsequently, the MCE membrane was dissolved by acetone and isopropanol immersion. The resulting Cu NW transparent conductive film exhibited a sheet resistance of 52 Ω sq⁻¹ with an optical transmittance of 86.7%. Full article

With an ultrahigh aspect ratio and a similar chemical composition to the biomineral in bone and tooth, ultralong hydroxyapatite nanowires (UHAPNWs) exhibit a meritorious combination of high flexibility, excellent mechanical performance, high biocompatibility, and bioactivity. Despite these exciting merits, the rapid and green synthesis of UHAPNWs remains challenging. In this work, we have developed an environment-friendly, rapid, and highly efficient synthesis of ultrathin UHAPNWs by the microwave-assisted calcium oleate precursor hydrothermal method using biogenic creatine phosphate as the bio-phosphorus source. Owing to the controllable hydrolysis of bio-phosphorus-containing creatine phosphate and the highly efficient heating of microwave irradiation, ultrathin UHAPNWs with a homogeneous morphology of several nanometers in diameter (single nanowire), several hundred micrometers in length, and ultrahigh aspect ratios (>10,000) can be rapidly synthesized within 60 min. This effectively shortens the synthesis time by about two orders of magnitude compared with the traditional hydrothermal method. Furthermore, ultrathin UHAPNWs are decorated in situ with bioactive creatine and self-assembled into nanowire bundles along their longitudinal direction at the nanoscale. In addition, ultrathin UHAPNWs exhibit a relatively high specific surface area of 84.30 m² g^–1 and high ibuprofen drug loading capacity. The flexible bio-paper constructed from interwoven ibuprofen-loaded ultrathin UHAPNWs can sustainably deliver ibuprofen in phosphate-buffered saline, which is promising for various biomedical applications such as tissue regeneration with anti-inflammatory and analgesic functions. Full article

Background: Denture stomatitis is an inflammatory condition involving swelling and redness of the oral mucosa beneath a denture. Among various available treatments, zinc oxide nanoparticles (ZnONPs) and nano-wire nanostructures have been suggested as potential future therapies. However, there is a lack of information in the literature about the effectiveness of ZnONPs regarding microbial adhesion to different denture base resins. Here, we review studies on the effect of ZnONP use on microbial adhesion to denture base resins to answer the following study question: “Does incorporating ZnONPs into denture base resins reduce microbial adhesion?” Methods: Following the Preferred Reporting Items for Systematic Reviews and Meta-Analyses (PRISMA) guidelines, an electronic and manual search ranging from Jan 2000 to May 2024 was performed using PubMed, Web of Science, and Scopus databases to answer the study question. All full-length English-language articles investigating the effects of ZnO nanostructures on Candida albicans adhesion to polymethyl methacrylate (PMMA) denture base resins were included. The extracted data were tabulated for qualitative and quantitative analysis of the included studies. Results: Of the 479 studies reviewed, 7 studies successfully met the eligibility criteria. All included studies utilized PMMA as the denture base material with different polymerization methods. C. albicans was the most extensively studied microbial species, with various count methods used. Six studies concluded a statistically significant impact of ZnONPs on decreasing C. albicans adhesion to the denture base. However, one study reported the opposite. Conclusions: Incorporating ZnONPs into PMMA denture base resin has a positive impact on reducing C. albicans adherence and could be recommended for denture stomatitis treatment. However, further studies are needed to cover the notable gap in data regarding the safety and effectiveness of ZnO nanostructures. Full article

Magnetic skyrmion random switching and structural stability are critical limitations for storage data applications. Enhancing skyrmions’ magnetic properties could improve their thermal structural stability. Hence, micromagnetic calculation was carried out to explore the thermal nucleation and stability of skyrmions in magnetic nanodevices. Different magnetic properties such as uniaxial magnetic anisotropy energy (Ku), saturation magnetization (Ms) and Dzyaloshinskii—Moriya interaction (DMI) were used to assess the thermal stability of skyrmions in magnetic nanowires. For some values of Ms and Ku, the results verified that the skyrmion structure is stable at temperatures above 800 K, which is higher than room temperature. Additionally, manipulating the nanowire geometry was found to have a substantial effect on the thermal structural stability of the skyrmion in storage nanodevices. Increasing the nanowire dimensions, such as length or width, enhanced skyrmions’ structural stability against temperature fluctuations in nanodevices. Furthermore, the random nucleation of the skyrmions due to the device temperature was examined. It was shown that random skyrmion nucleation occurs at temperature values greater than 700 K. These findings make skyrmion devices suitable for storage applications. Full article

The <100> oriented single-crystalline Zirconium Carbide (ZrC) nanowires were controllably synthesized on a graphite substrate by chemical vapor deposition (CVD) with optimized growth parameters involving Zirconium tetrachloride (ZrCl₄), flow of methane (CH₄), and growth temperature. The length of nanowires is above 10 µm while the diameter is smaller than 100 nm. A single ZrC nanowire was picked up and fixed on a tungsten tip for field emission measurement. After surface pretreatments, a sharpened and cleaned ZrC nanowire emitter showed a high emission current density of 1.1 × 10¹⁰ A m⁻² at a low turn-on voltage of 440 V. The field emission is stable for 150 min with a fluctuation of 1.77%. This work provides an effective method for synthesizing and stabilizing single-crystalline ZrC nanowire emitters as an electron source for electron-beam applications. Full article

In this study, we investigate the thermal pinning and depinning behaviors of vortex domain walls (VDWs) in constricted magnetic nanowires, with a focus on potential applications in storage memory nanodevices. Using micromagnetic simulations and spin transfer torque, we examine the impacts of device temperature on VDW transformation into a transverse domain wall (TDW), mobility, and thermal strength pinning at the constricted area. We explore how thermal fluctuations influence the stability and mobility of domain walls within stepped nanowires. The thermal structural stability of VDWs and their pinning were investigated considering the effects of the stepped area depth (d) and its length (λ). Our findings indicate that the thermal stability of VDWs in magnetic stepped nanowires increases with decreasing the depth of the stepped area (d) and increasing nanowire thickness (th). For th ≥ 50 nm, the stability is maintained at temperatures ≥ 1200 K. In the stepped area, VDW thermal pinning strength increases with increasing d and decreasing λ. For values of d ≥ 100 nm, VDWs depin from the stepped area at temperatures ≥ 1000 K. Our results reveal that thermal effects significantly influence the pinning strength at constricted sites, impacting the overall performance and reliability of magnetic memory devices. These insights are crucial for optimizing the design and functionality of next-generation nanodevices. The stepped design offers numerous advantages, including simple fabrication using a single electron beam lithography exposure step on the resist. Additionally, adjusting λ and d allows for precise control over the pinning strength by modifying the dimensions of the stepped areas. Full article

Silver nanowires (AgNWs) are one kind of nanomaterials for various applications such as solar panel cells and biosensors. However, the morphology of AgNWs, particularly their length and diameter, plays a critical role in determining the efficiency of energy storage systems and the transmittance of biosensors. Thus, it is imperative to study synthesis strategy for morphology control. This study focuses on synthesizing AgNWs through the solvothermal approach and aims to understand the individual and combined effects of three nucleants, NaCl, Fe(NO₃)₃ and NaBr, on the morphology of AgNWs. Using a modified successive multistep growth (SMG) approach and fine-tuning the nucleant concentrations, this study synthesized AgNWs with controllable aspect ratios, while minimizing the presence of undesirable byproducts like nanoparticles. Our results demonstrated the successful synthesis of AgNWs with favorable morphologies, including lengths of approximately 180 µm and diameters of 40 nm, thus resulting in aspect ratios of 4500. In addition, to assess the quality of the synthesized AgNWs, this work developed computational tools that uses MATLAB to automate the analysis of scanning electron microscope (SEM) images for detecting silver nanoparticles. This automated approach provides a quantitative analysis tool for material characterization and holds the promise for long-term evaluation of diverse AgNW samples, thereby paving the way for advancements in their synthesis and application. Overall, this study demonstrates the significance of morphology control in AgNW synthesis and presents a robust framework for material characterization and quality analysis. Full article

A kind of surface plasmon waveguide composed of two nested cylindrical dielectric parallel nanowire pairs coated with graphene was designed and studied. The dependence of the mode characteristics and the normalized gradient force of the lowest two modes supported by the waveguide on the parameters involved were analyzed by using the multipole method. To ensure rigor, the finite element method was employed to verify the accuracy of the multipole method, thus confirming its results. The results show that the multipole method is a powerful tool for handling this type of waveguide. The real part of the effective refractive index, the propagation length, the figure of merit, and the normalized gradient force can be significantly affected by the operating wavelength, the Fermi energy of graphene, the waveguide geometric parameters, and the refractive index of the inner dielectric nanowire. Due to the employment of nested dielectric nanowire pairs coated with graphene, this waveguide structure exhibits significant gradient force that surpasses 100 nN·μm⁻¹·mW⁻¹. The observed phenomena can be attributed to the interaction of the field with graphene. This waveguide holds promising potential for applications in micro/nano integration, optical tweezers, and sensing technologies. Full article

Polypyrrole (PPy)-capped silver nanowire (Ag NW) nanomaterials (core–shell rod-shaped Ag NW@PPy) were synthesized using a one-port suspension polymerization technique. The thickness of the PPy layer on the 50 nm thickness/15 μm length Ag NW was effectively controlled to 10, 40, 50, and 60 nm. Thin films cast from one-dimensional conductive Ag NW@PPy formed a three-dimensional (3D) conductive porous network structure and provided excellent electrochemical performance. The 3D Ag NW@PPy network can significantly reduce the internal resistance of the electrode and maintain structural stability. As a result, a high specific capacitance of 625 F/g at a scan rate of 1 mV/s was obtained from the 3D porous Ag NW@PPy composite film. The cycling performance over a long period exceeding 10,000 cycles was also evaluated. We expect that our core–shell-structured Ag NW@PPy composites and their 3D porous structure network films can be applied as electrochemical materials for the design and manufacturing of supercapacitors and other energy storage devices. Full article

In this study, we investigated the influence of quasi-one-dimensional (Quasi-1D) characteristics on the source and drain contact resistances within vertical nanowire (NW) field-effect transistors (FETs) of diminutive diameter. The top contact of the NW is segregated into two distinct regions: the first encompassing the upper surface, designated as the axial contact, and the second encircling the side surface, known as the radial contact, which is formed during the top-contact metal deposition process. Quantum confinement effects, prominent within Quasi-1D NWs, exert significant constraints on radial transport, consequently inducing a noticeable impact on contact resistance. Notably, in the radial direction, electron tunneling occurs only through quantized, discrete energy levels. Conversely, along the axial direction, electron tunneling freely traverses continuous energy levels. In a meticulous numerical analysis, these disparities in transport mechanisms unveiled that NWs with diameters below 30 nm exhibit a markedly higher radial contact resistance compared to their axial counterparts. Furthermore, an increase in the overlap length (less than 5 nm) contributes to a modest reduction in radial resistance; however, it remains consistently higher than the axial contact resistance. Full article

ZnO nanowire is a promising candidate for large-area gated field emitter arrays. How to improve its temporal response is one of the key problems to be solved for applications. In this work, a device model for a gated ZnO nanowire field emitter with consideration of charging and self-heating effect has been established to investigate its temporal response. It is found that while the charging effect is responsible for the delay at the beginning of the pulse, the self-heating effect which induces delay due to the thermal conduction process can shorten the charging time because of its lowering of nanowire resistance. The response time can be minimized when these two effects are balanced at an optimal field which is below the critical field for thermal runaway. We further investigate the optimal response time of a nanowire with the same resistance but a different length, radius, and electrical properties. The results imply that a lower heat capacity and higher critical temperature for thermal runaway are in favor of a shorter response time, which must be taken into account in the reduction in nanowire resistance for improving response speed. All the above should be useful for the device design of a fast-response gated ZnO nanowire field emitter array. Full article

P-nitroaniline (PNA) is an aniline compound with high toxicity and can cause serious harm to aquatic animals and plants. Multiwalled carbon nanotubes (MWCNTs) are a multifunctional carbon-based material that can be applied in energy storage and biochemistry applications and semiconductors as well as for various environmental purposes. In the present study, MWCNTs (CO₂–MWCNTs and KOH–MWCNTs) were obtained through CO₂ and KOH activation. ACID–MWCNTs were obtained through surface treatment with an H₂SO₄–HNO₃ mixture. Herein, we report, for the first time, the various MWCNTs that were employed as nanoadsorbents to remove PNA from aqueous solution. The MWCNTs had nanowire-like features and different tube lengths. The nanotubular structures were not destroyed after being activated. The KOH–MWCNTs, CO₂–MWCNTs, and ACID–MWCNTs had surface areas of 487, 484, and 80 m²/g, respectively, and pore volumes of 1.432, 1.321, and 0.871 cm³/g, respectively. The activated MWCNTs contained C–O functional groups, which facilitate PNA adsorption. To determine the maximum adsorption capacity of the MWCNTs, the influences of several adsorption factors—contact time, solution pH, stirring speed, and amount of adsorbent—on PNA adsorption were investigated. The KOH–MWCNTs had the highest adsorption capacity, followed by the CO₂–MWCNTs, pristine MWCNTs, and ACID–MWCNTs. The KOH–MWCNTs exhibited rapid PNA adsorption (>85% within the first 5 min) and high adsorption capacity (171.3 mg/g). Adsorption isotherms and kinetics models were employed to investigate the adsorption mechanism. The results of reutilization experiments revealed that the MWCNTs retained high adsorption capacity after five cycles. The surface-activated and modified MWCNTs synthesized in this study can effectively remove hazardous pollutants from wastewater and may have additional uses. Full article
