This paper presents the reliability assessment of an IoT-based sensor node designed for detecting combustible gas leaks in residential environments. Building on a previously published design that integrates low-power micromachined (Micro-Electro-Mechanical Systems, MEMS) pellistors and electrochemical Volatile Organic Compounds (VOC) sensors, this study evaluates the node’s long-term robustness and stability under both realistic and accelerated operating conditions. The system employs a dual-sensor strategy in which the VOC sensor acts as a sentinel, activating the pellistor only when necessary, thereby optimizing power consumption and extending battery life. BLE and LoRa communication capabilities support flexible deployment and real-time data transmission. To ensure suitability for safety-critical applications, we conducted comprehensive reliability testing, including accelerated life tests and environmental stress testing in compliance with IEC 60068 standards. The results confirm the system’s ability to maintain consistent performance and data integrity under thermal, mechanical, and chemical stress, demonstrating its robustness for prolonged operation in demanding environments. Overall, this work underscores the importance of rigorous reliability validation for IoT-based safety devices and positions the proposed solution as a significant step toward enhancing residential gas safety, with potential applications in broader industrial monitoring scenarios. Full article

To meet today’s requirements, new active catalysts with reduced noble metal content are needed for hydrogen sensing. A palladium-functionalized nanostructured Ni_0.5Co_2.5O₄ catalyst with a total Pd content of 4.2 wt% was synthesized by coprecipitation to obtain catalysts with an advantageous sheet-like morphology and surface defects. Due to the synthesis method and the reducible nature of Ni_0.5Co_2.5O₄ enabling strong metal-metal oxide interactions, the palladium was highly distributed over the metal oxide surface, as determined using scanning transmission electron microscopy and energy-dispersive X-ray investigations. The catalyst tested in planar pellistor sensors showed high sensitivity to hydrogen in the concentration range below the lower flammability limit (LFL). At 400 °C and in dry air, a sensor response of 109 mV/10,000 ppm hydrogen (25% of LFL) was achieved. The sensor signal was 4.6-times higher than the signal of pristine Ni_0.5Co_2.5O₄ (24.6 mV/10,000 ppm). Under humid conditions, the sensor responses were reduced by ~10% for Pd-functionalized Ni_0.5Co_2.5O₄ and by ~27% for Ni_0.5Co_2.5O₄. The different cross-sensitivities of both catalysts to water are attributed to different activation mechanisms of hydrogen. The combination of high sensor sensitivity to hydrogen and high signal stability over time, as well as low cross-sensitivity to humidity, make the catalyst promising for further development steps. Full article

This is the fourth part of a study presenting a miniature, combustion-type gas sensor (dubbed GMOS) based on a novel thermal sensor (dubbed TMOS). The TMOS is a micromachined CMOS-SOI transistor, which acts as the sensing element and is integrated with a catalytic reaction plate, where ignition of the gas takes place. The GMOS measures the temperature change due to a combustion exothermic reaction. The controlling parameters of the sensor are the ignition temperature applied to the catalytic layer and the increased temperature of the hotplate due to the released power of the combustion reaction. The solid-state device applies electrical parameters, which are related to the thermal parameters. The heating is applied by Joule heating with a resistor underneath the catalytic layer while the signal is monitored by the change in voltage of the TMOS sensor. Voltage, like temperature, is an intensive parameter, and one always measures changes in such parameters relative to a reference point. The reference point for both parameters (temperature and voltage) is the blind sensor, without any catalytic layer and hence where no reaction takes place. The present paper focuses on the study of the effect of humidity upon performance. In real life, the sensors are exposed to environmental parameters, where humidity plays a significant role. Humidity is high in storage rooms of fruits and vegetables, in refrigerators, in silos, in fields as well as in homes and cars. This study is significant and innovative since it extends our understanding of the performance of the GMOS, as well as pellistor sensors in general, in the presence of humidity. The three main challenges in simulating the performance are (i) how to define the operating temperature based on the input parameters of the heater voltage in the presence of humidity; (ii) how to measure the dynamics of the temperature increase during cyclic operation at a given duty cycle; and (iii) how to model the correlation between the operating temperature and the sensing response in the presence of humidity. Due to the complexity of the 3D analysis of packaged GMOS, and the many aspects of humidity simultanoesuly affecting performane, advanced simulation software is applied, incorporating computational fluid dynamics (CFD). The simulation and experimental data of this study show that the GMOS sensor can operate in the presence of high humidity. Full article

It is shown that the operating temperature of pellistors for the detection of methane can be reduced to 300 °C by using Au–Pd nanoparticles on mesoporous cobalt oxide (Au–Pd@meso-Co₃O₄). The aim is to reduce possible catalyst poisoning that occurs during the high-temperature operation of conventional Pd-based pellistors, which are usually operated at 450 °C or higher. The individual role of Au–Pd as well as Co₃O₄ in terms of their catalytic activity has been investigated. Above 300 °C, Au–Pd bimetallic particles are mainly responsible for the catalytic combustion of methane. However, below 300 °C, only the Co₃O₄ has a catalytic effect. In contrast to methane, the sensor response and the temperature increase of the sensor under propane exposure is much larger than for methane due to the larger heat of combustion of propane. Due to its lower activation energy requirement, propane exhibits a higher propensity for oxidation compared to methane. As a result, the detection of propane can be achieved at even lower temperatures due to its enhanced reactivity. Full article

High activity of a catalyst and its thermal stability over a lifetime are essential for catalytic applications, including catalytic gas sensors. Highly porous materials are attractive to support metal catalysts because they can carry a large quantity of well-dispersed metal nanoparticles, which are well-accessible for reactants. The present work investigates the long-term stability of mesoporous Co₃O₄-supported Au–Pd catalyst (Au–Pd@meso-Co₃O₄), with a metal loading of 7.5 wt% and catalytically active mesoporous Co₃O₄ (meso-Co₃O₄) for use in catalytic gas sensors. Both catalysts were characterized concerning their sensor response towards different concentrations of methane and propane (0.05–1%) at operating temperatures ranging from 200 °C to 400 °C for a duration of 400 h. The initially high sensor response of Au–Pd@meso-Co₃O₄ to methane and propane decreased significantly after a long-term operation, while the sensor response of meso-Co₃O₄ without metallic catalyst was less affected. Electron microscopy studies revealed that the hollow mesoporous structure of the Co₃O₄ support is lost in the presence of Au–Pd particles. Additionally, Ostwald ripening of Au–Pd nanoparticles was observed. The morphology of pure meso-Co₃O₄ was less altered. The low thermodynamical stability of mesoporous structure and low phase transformation temperature of Co₃O₄, as well as high metal loading, are parameters influencing the accelerated sintering and deactivation of Au–Pd@meso-Co₃O₄ catalyst. Despite its high catalytic activity, Au–Pd@meso-Co₃O₄ is not long-term stable at increased operating temperatures and is thus not well-suited for gas sensors. Full article

The need to achieve digital gas sensing technology, namely, a technology to sense and transmit gas-enabled digital media, has been recognized as highly challenging. This challenge has motivated the authors to focus on complementary metal oxide semiconductor silicon on insulator micro electro-mechanical system (CMOS-SOI-MEMS) technologies, and the result is a new pellistor-like sensor, dubbed GMOS, with integrated signal processing. In this study, we describe the performance of such sensors for the selective detection of mixtures of gases. The novel key ideas of this study are: (i) the use of the GMOS for gas sensing; (ii) applying the Kalman filter to improve the signal-to-noise ratio; (iii) adding artificial intelligence (AI) with tiny edge approach. Full article

This is the third part of the paper presenting a miniature, combustion-type gas sensor (dubbed GMOS) based on a novel thermal sensor (dubbed TMOS). The TMOS is a micromachined CMOS-SOI transistor, which acts as the sensing element and is integrated with a catalytic reaction plate, where ignition of the gas takes place. The first part was focused on the chemical and technological aspects of the sensor. In Part 2, the emphasis was on the physical aspects of the reaction micro-hot plate on which the catalytic layer is deposited. The present study focuses on applying several advanced simulation tools, which extend our understanding of the GMOS performance, as well as pellistor sensors in general. The three main challenges in simulating the performance are: (i) how to define the operating temperature based on the input parameters; (ii) how to measure the dynamics of the temperature increase during cyclic operation at a given duty cycle; (iii) how to model the correlation between the operating temperature and the sensing response. The simulated and analytical models and measured results are shown to be in good agreement. Full article

Pd deposited on CeO_x-MnO_x/La-Al₂O₃ has been prepared as a sensitive material for methane (CH₄) detection. The effect of different amounts (1.25%, 2.5% and 5%) of Pd loading has been investigated. The as prepared materials were deposited on Pt microcoils using a drop-coating method, as a way of developing pellistors operated using a Wheatstone bridge configuration. By spanning the operating temperature range between 300 °C and 550 °C, we established the linearity region as well as the maximum sensitivity towards 4900 ppm of CH₄. By making use of the sigmoid dependence of the output voltage signal from the Wheatstone bridge, the gas surface reaction and diffusion phenomena have been decoupled. The pellistor with 5% Pd deposited on CeO_x-MnO_x/La-Al₂O₃ exhibited the highest selective-sensitivity in the benefit of CH₄ detection against threshold limits of carbon monoxide (CO), sulfur dioxide (SO₂) and hydrogen sulfide (H₂S). Accordingly, adjusting the percent of Pd makes the preparation strategies of pellistors good candidates towards CH₄ detection. Full article

Catalytic gas sensors are widely used for measuring concentrations of combustible gases to prevent explosive accidents in industrial and domestic environments. The typical structure of the sensitive element of the sensor consists of carrier and catalyst materials, which are in and around a platinum coil. However, the size of the platinum coil is micron-grade and typically has a cylindrical shape. It is extremely difficult to control the amount of carrier and catalyst materials and to fulfill the inner cavity of the coil, which adds to the irreproducibility and uncertainty of the sensor performance. To solve this problem, this paper presents a new method which uses a drop-on-demand droplet generator to add the carrier and catalytic materials into the platinum coil and fabricate the micropellistor. The materials in this article include finely dispersed Al₂O₃ suspension and platinum palladium (Pd-Pt) catalyst. The size of the micropellistor with carrier material can be controlled by the number of the suspension droplets, while the amount of Pd-Pt catalyst can be controlled by the number of catalyst droplets. A bridge circuit is used to obtain the output signal of the gas sensors. The original signals of the micropellistor at 140 mV and 80 mV remain after aging treatment. The sensitivity and power consumption of the pellistor are 32 mV/% CH₄ and 120 mW, respectively. Full article

The paper presents principle of operation and design of the most popular chemical sensors for measurement of volatile organic compounds (VOCs) in outdoor and indoor air. It describes the sensors for evaluation of explosion risk including pellistors and IR-absorption sensors as well as the sensors for detection of toxic compounds such as electrochemical (amperometric), photoionization and semiconductor with solid electrolyte ones. Commercially available sensors for detection of VOCs and their metrological parameters—measurement range, limit of detection, measurement resolution, sensitivity and response time—were presented. Moreover, development trends and prospects of improvement of the metrological parameters of these sensors were highlighted. Full article
