To address the degraded prediction accuracy, increased torque ripple, and weakened dynamic response of conventional finite-control-set model predictive control (FCS-MPC) under magnetic saturation, parameter mismatch, and load disturbances in permanent magnet synchronous motors (PMSMs), this paper proposes a hierarchical FCS-MPC framework based on PINN-RLS and virtual-voltage-vector extension, termed HRPV-MPC. Built upon a unified nonlinear motor model, the proposed method integrates PINN-RLS-based online parameter correction, virtual-voltage-vector extension, disturbance-observer-based feedforward compensation, maximum-torque-per-ampere (MTPA) and quadratic-programming (QP) reference reconstruction, and deep-neural-network (DNN)-based torque-ripple compensation into the same closed-loop control framework. Unlike existing studies that usually optimize parameter identification, disturbance compensation, or ripple suppression separately, the proposed method emphasizes their coordinated interaction within the predictive control chain so as to simultaneously improve steady-state precision, disturbance rejection, and dynamic recovery performance. Simulation results show that the proposed HRPV-MPC achieves coordinated improvements in steady-state precision, dynamic response, and disturbance rejection under various operating conditions; compared with baseline FCS-MPC, it exhibits clear advantages in torque-ripple suppression, torque-error reduction, load-disturbance recovery, and speed-tracking performance, thereby validating the effectiveness and superiority of the constructed hierarchical collaborative framework. Full article

To address the bottlenecks of conventional valve-controlled marine steering systems—characterized by high throttling losses, low efficiency, and high leakage risk—as well as the insufficient power density and impact resistance of electro-mechanical actuators (EMAs) for high-load steering of large vessels, this paper proposes and validates a high-performance integrated solution for an electro-hydrostatic actuator (EHA) for ship steering. First, a fifth-order electro–hydraulic–mechanical coupled dynamic model comprising a permanent magnet synchronous motor, hydraulic pump, hydraulic cylinder, and load is established. The validity and applicability boundaries of three simplifying assumptions—neglecting leakage, pipeline pressure losses, and steady-state fluid compressibility effects—are quantitatively analysed, with a total introduced error ≤3%. These assumptions are justified under medium-pressure, short-pipeline, and well-sealed conditions typical of marine EHA systems. Second, a composite control architecture combining outer-loop sliding mode control with inner-loop motor PID dual-loop control is proposed. Parameter tuning is performed using pole placement for the sliding surface and the Ziegler–Nichols critical ratio method for the inner loops, effectively suppressing hydraulic system parameter perturbations and random wave-induced load disturbances. Quantitative comparisons show that the proposed method reduces overshoot by 11.63% and improves sinusoidal tracking accuracy by 90.13% compared to conventional single-loop PID control. An integrated drive-control structure is designed, and a three-phase full-bridge inverter main circuit with wide-voltage input capability—including EMI filtering, soft-start, and LC filtering—is developed to accommodate the ±20% voltage fluctuations typical of ship power grids, thereby enhancing system integration and grid adaptability. Phased bench tests demonstrate that the settling time from no-load start-up to 200 r/min is only 0.01 s. When a sudden 20 N·m load is applied, the speed drop is less than 3%, and the recovery time is less than 0.025 s. The steady-state steering angle error does not exceed 0.12°, the maximum average steering rate reaches 3.33°/s, and the steering response time is within 0.3 s. All core performance indicators exceed the general technical standards for marine steering systems, with a 65.7% improvement in steady-state accuracy and a 62.5% improvement in response speed over conventional PID control. The research findings provide an effective general technical solution and experimental data support for the performance optimization and engineering application of marine EHA systems. Full article

Flat-wire windings have been widely used in high-power-density electric vehicle motors because of their high slot fill factor and high efficiency. However, conventional flat-wire conductors usually have relatively large cross-sectional dimensions, which may lead to significant AC winding losses under high-frequency operation due to the combined effects of the rotor magnetic field and the armature-reaction field. To address this issue, this paper proposes a multilayer thin flat-wire continuous-wave winding and its end-winding transposition method. The parallel multilayer thin flat-wire structure effectively suppresses AC losses by reducing the characteristic dimension of each conductor, while the end-winding transposition method reduces or even eliminates circulating-current losses among parallel strands without compromising slot utilization. An analytical calculation method is established to investigate the AC loss characteristics of the multilayer thin flat-wire winding, and the main influencing factors of winding losses are analyzed. To address the circulating-current loss issue, the loss suppression effect of the transposition method is quantitatively evaluated, and an intermittent transposition method with both effective circulating-current suppression and fewer end-winding crossovers is proposed. Finally, the proposed method is validated by finite-element analysis (FEA) and prototype experiments. The results show that the proposed winding can significantly reduce AC losses over a wide speed range, providing a low loss and manufacturable winding design solution for high-power-density electric vehicle traction motors. Full article

To address the issues of sluggish dynamic response, significant steady-state fluctuations, and poor disturbance rejection associated with traditional proportional–integral (PI) and conventional speed control methods, a novel sensorless sliding-mode speed control strategy for permanent magnet synchronous motors (PMSMs) based on the super-twisting algorithm (STA) is proposed. First, an advanced sliding-mode speed controller is designed by integrating an integral nonsingular fast terminal sliding-mode surface with the STA, thereby enhancing the dynamic response and transient stability of the PMSM under speed variations. Subsequently, to mitigate inherent sliding-mode chattering, a novel load torque observer is developed. This observer continuously feeds forward real-time load estimates to the speed controller, which substantially improves the system’s robustness against external disturbances. Furthermore, to eliminate the reliance on mechanical sensors and ensure reliable operation across diverse scenarios, an improved sliding-mode observer (SMO) incorporating the STA is utilized to achieve more precise rotor position and speed estimation. Finally, an experimental platform is established to conduct comprehensive variable-speed and variable-load tests on the PMSM. Experimental results demonstrate that the proposed method improves the dynamic response and disturbance immunity of the PMSM by 58.33% and 71.75%, respectively, while reducing steady-state fluctuations by 33.33%. These results demonstrate the effectiveness of the proposed sensorless sliding-mode control strategy and show improved speed regulation performance for PMSM drives. Full article

In electric vehicle thermal management systems, direct measurement of the internal motor temperature is difficult. Therefore, the coolant pressure drop is an important indicator for estimating the motor thermal state. However, manufacturing and operating uncertainties in water-cooled interior permanent magnet synchronous motors (IPMSMs) can cause variability in cooling performance and pressure drop, requiring a reliability-based design approach. In this study, reliability-based design optimization (RBDO) is performed by considering manufacturing tolerances in the cooling channels and uncertainty in the inlet coolant flow rate. Based on coupled electromagnetic–thermal–fluid analysis and Kriging surrogate models, RBDO is applied to minimize the maximum temperature while satisfying the allowable pressure-drop limit at a target reliability level. The proposed RBDO improves the probability of satisfying the pressure-drop constraint from 54.1% in the baseline design to 99.9%, while increasing the mean maximum temperature by only 0.17 K. These results indicate that RBDO can improve the reliability of the pressure-drop constraint in IPMSM water-cooling systems under practical manufacturing and operating uncertainties, with only a limited change in thermal performance. Full article

Traditional permanent magnet synchronous motor (PMSM) control systems rely on mechanical position sensors for high-precision rotor position and speed information, which increases hardware complexity, raises system cost, reduces reliability, and limits adaptability to harsh environments. To overcome the above limitations, this paper proposes a novel high-performance sensorless speed control strategy for PMSMs, which is constructed based on a non-singular terminal sliding mode observer (NTSMO) and a non-singular terminal sliding mode controller (NTSMC). First, an improved fast power reaching law (IFPRL) is proposed, which consists of a variable exponential reaching term and a power reaching term. Specifically, the gain of the exponential reaching term is dynamically adjusted by the absolute value of the sliding mode switching function, enabling the reaching law to operate in two different modes throughout the entire convergence process of the system state. Moreover, the introduction of scaling coefficient c compensates for the performance degradation caused by variations in the range of sliding mode surfaces (SMSs) in different systems. The proposed IFPRL not only effectively mitigates the inherent chattering issue, it also expedites the rate at which the system state converges to its SMS. On this basis, both the NTSMO for rotor position observation and the NTSMC for speed closed-loop control are designed by embedding the proposed IFPRL into the framework of non-singular terminal sliding mode control theory. Finally, the effectiveness of the proposed method is validated through numerical simulations and experimental tests. Experimental results demonstrate that the proposed IFPRL-based NTSMC + NTSMO scheme reduces the root mean square error (RMSE) of speed control by 2.7% relative to the traditional SMC + SMO method. The proposed method realizes reliable sensorless speed control for PMSMs and exhibits superior dynamic response, higher control accuracy, and stronger robustness against disturbances. Full article

In industrial applications such as in situ leaching and uranium mining, permanent magnet synchronous motors (PMSMs) for submersible pumps are frequently connected to frequency converters via long cables. During this long-distance transmission, traveling wave reflections induced by high-frequency pulse width modulation (PWM) generate severe transient overvoltages that threaten motor insulation. Because installation space at deep-well motor terminals is severely restricted, overvoltage suppression must be implemented at the inverter output. Here, the parameter design and optimization of a passive LC filter specifically developed for 250 Hz high-frequency PMSMs are presented. The optimal inductance and capacitance parameters were determined by balancing multiple operational constraints, including fundamental voltage drop, high-frequency harmonic attenuation, and the avoidance of low-order harmonic resonance. Furthermore, the anti-saturation performance of the magnetic core material, evaluated thermal characteristics through electromagnetic-thermal co-simulation, and analyzed the risk of self-excited oscillation between the filter capacitors and the motor was analyzed. Finally, hardware experiments conducted on a 20 m cable test bench validate that the designed LC filter effectively mitigates terminal overvoltage. The peak terminal voltage was reduced from 900 V to 505 V, and total harmonic distortion (THD) was limited to below 5%. This design provides a highly reliable, space-efficient solution for overvoltage suppression in high-speed, long-cable motor drive systems. Full article

Conventional model predictive control (MPC) is highly vulnerable to motor parameter variations. Meanwhile, existing parameter-based MPC schemes are often constrained by the accuracy of model reconstruction. To overcome these limitations, this article proposes a model-free predictive control (MFPC) strategy based on a fuzzy approximation method for a permanent magnet synchronous motor (PMSM). Leveraging the exceptional nonlinear mapping capability of fuzzy approximation, the proposed strategy approximates the autoregressive term within a structurally simple first-order autoregressive model with exogenous input (ARX). This significantly enhances model reconstruction accuracy. Furthermore, discrete-time Lyapunov stability analysis rigorously demonstrates that the estimation errors of the internal states under the proposed control scheme are uniformly ultimately bounded (UUB). Finally, experimental results reveal that the proposed MFPC strategy achieves superior steady-state current quality while ensuring excellent dynamic performance, effectively validating the advantages of the proposed method. Full article

This paper addresses a specific dynamic limitation in conventional adaptive super-twisting sliding mode control (ASTSMC) for permanent-magnet synchronous motor (PMSM) speed regulation: the reactive lag of gain adaptation. In standard ASTSMC, controller gains are adjusted based solely on the sliding variable, which grows only after a disturbance has already induced a tracking error. This reactive behavior may produce a non-negligible transient speed droop during abrupt load variations. To alleviate this limitation, a proactive gain-scheduled ASTSMC (PDG-ASTSMC) strategy is proposed. A second-order nonlinear extended state observer (NESO) is employed to estimate the lumped disturbance and to extract its time derivative ${\dot{\widehat{d}}}_l$. This disturbance-derivative signal is incorporated into the gain adaptation law to increase the controller gains during the incipient phase of a load change, before significant speed error accumulates. Stability analysis based on a composite Lyapunov function establishes uniformly ultimately bounded convergence of the closed-loop system, and a quantitative relationship between the proactive index and transient droop reduction is derived. Experimental validation on a 1.42 kW PMSM platform shows that, compared with conventional reactive ASTSMC, the proposed PDG-ASTSMC reduces transient speed droop by over 17% (from 10.5 rpm to 8.7 rpm) and shortens load recovery time by approximately 69% (from 140 ms to 44 ms), without increasing steady-state chattering or current ripple. Full article

High-speed permanent magnet synchronous motors (PMSMs) used in electric pump-fed liquid rocket engines require stator shielding sleeves to prevent corrosive propellants from causing harm under cyclic pressure. However, metallic sleeves suffer significant losses due to eddy currents. Conversely, pure carbon fiber reinforced polymer (CFRP) sleeves have failed when exposed to 98% H₂O₂. Micro-CT analysis of a failed pump sleeve reveals a four-stage failure mechanism. Manufacturing defects caused matrix cracking, which propagated under pressure and thermal cycling. This progression resulted in the formation of through-thickness leakage paths, which ultimately triggered catalytic decomposition and explosion. To address these issues, an improved dual-layer sleeve is proposed, featuring a 2.5 mm PEEK 450G liner and a 2.0 mm T700S/epoxy CFRP overwrap. Finite Element Analysis (FEA) indicates peak von-Mises stresses of 86.25 MPa and 112.16 MPa, yielding Tsai–Wu safety factors of 2.9 and 1.7. Furthermore, various tests, including immersion, fatigue, burst, hydraulic, and thermal evaluations, demonstrate a burst margin of 2.37× at 7.12 MPa, with only 0.19% increase in mass. This design effectively eliminates leakage pathways while preserving zero eddy-current loss and ensuring a low weight. Full article

High-performance control of surface-mounted permanent magnet synchronous motors (SPMSMs) is critical for unmanned aerial vehicle (UAV) rotor servo systems, which demand fast dynamic response, high steady-state accuracy, and strong robustness against complex disturbances. However, conventional sliding mode control (SMC) methods often suffer from inherent issues like integral windup, persistent chattering, and sensitivity to parameter variations, limiting their effectiveness in such challenging applications. To address these limitations, this paper proposes a novel composite control strategy. The method integrates an improved terminal integral sliding mode controller (ITISMC) with an adaptive super-twisting reaching law (ADSTA) and a terminal integral sliding mode observer (TISMO). The key innovations include: (1) a redesigned sliding surface incorporating a smooth nonlinear function to suppress chattering and a variable-gain integral term to mitigate integral windup; (2) an adaptive reaching law that dynamically adjusts its gains based on the system state to balance convergence speed and chattering suppression; and (3) a disturbance observer that provides real-time estimation and feedforward compensation of total disturbances, significantly enhancing robustness. The proposed ITISMC-ADSTA-TISMO strategy was implemented and validated on a TMS320F28379D DSP-based experimental platform. Comparative results demonstrate its superiority over benchmark methods (e.g., SMC-STA). Key achievements include a rapid no-load startup time of 0.45 s, high steady-state precision with speed fluctuations suppressed to only 3 rpm, and superior disturbance rejection capability under sudden load changes, sinusoidal disturbances, and parameter perturbations. The method also yields favorable q-axis current response. These results confirm that the proposed strategy offers a high-performance, practical solution for advanced UAV servo control systems. Full article

This paper presents a robust fault-tolerant control (FTC) strategy for a multiphase PMSM-based propulsion system. The proposed approach combines an innovative super-twisting sliding mode controller (IST SMC) with a fault-tolerant model of the machine when an open-circuit fault occurs. The electrical propulsion system mainly has a two-line structure with a single DC source, a five-leg inverter and a Five-Phase Permanent Magnet Synchronous Motors (5-Φ PMSM), suitable for marine propulsion applications. Two main scenarios are investigated in this work. Firstly, if an open-phase fault occurs in one of the two 5-Φ PMSMs, a reconfiguration step of the machine control is applied in order to improve the performance of the propulsion system and to ensure the continuity of operation. Then, if the fault occurs in one of the two inverters, the faulty one is removed and the electrical series connection is made between the two machines, where they are powered by a single five-arm inverter, thus ensuring the continuity of operation of the system. Considering these two scenarios, a comparative analysis is made between the IST SMC and the classical PI controllers in terms of robustness to uncertainties, external disturbances and tracking accuracy for healthy and faulty operation modes, and during transient states. Full article

Electric power steering (EPS) motors require low torque ripple, low cogging torque, and smooth torque output to ensure precise control and driving comfort. However, consequent pole permanent magnet synchronous motors (CP-PMSMs), although advantageous in reducing permanent magnet usage, exhibit an imbalanced magnetic flux distribution due to the iron poles, resulting in even-order harmonic components in the back electromotive force (BEMF) and significant torque ripple. In this paper, a rotor pole arrangement for CP-PMSMs is proposed to improve torque characteristics for EPS applications. Symmetric and asymmetric pole arrangements are introduced to modify the magnetic flux distribution and suppress harmonic components generated by the iron poles. In addition, the iron pole arc ratio is selected as a key design variable and analyzed for each model to achieve low torque ripple while maintaining torque performance. The electromagnetic characteristics of the proposed structures are evaluated using finite element analysis under identical operating conditions. The results show that the torque ripple of the proposed models is reduced by approximately 33.3%p and 34.1%p compared with the conventional CP-PMSM, and the cogging torque is also significantly reduced. Although average torque decreases, overall torque characteristics improve due to reduced torque ripple and harmonic components. These results demonstrate that the proposed rotor pole arrangement effectively enhances torque quality in CP-PMSMs without increasing axial length or requiring three-dimensional analysis. Full article

Aiming at the problem that the loss and temperature rise of the pole-suspended rotor low-speed high-torque permanent magnet synchronous motor (LHPMSM) increase in the pursuit of high torque density, and the design cycle is prolonged due to the dependence on thermal post-verification. In this paper, a multi-physics trade-off design method based on weighted heating rate combined with a surrogate model and a multi-objective evolutionary algorithm is proposed. Firstly, the rationality of introducing a weighted heating rate is proved by mathematical proof and thermal network calculation. Secondly, the two-dimensional sensitivity analysis of the key structural parameters of the motor is carried out to identify the most influential structural variables, which are then used to construct a high-precision surrogate model based on gradient boosting regression tree (GBRT). Then, in order to effectively obtain the Pareto solution set of balanced torque performance and heat dissipation performance, the non-dominated sorting genetic algorithm (NSGA-II) is used for multi-objective optimization. Finally, the multi-physical field finite-element simulation verification and a 356kW prototype experimental analysis show that the optimized design significantly improves the torque performance while effectively controlling the temperature rise and realizes the fast compromise design of the multi-physical field of the motor. The effectiveness and advancement of the proposed method to achieve coordinated improvement of high power density and high steady-state thermal margin in motor design are verified. Full article

Interior permanent magnet synchronous motor (IPMSM) has advantages with high power density, wide speed range, small size, and high efficiency, and is widely used in the drive system of electric vehicles. Compared to other types of motors, permanent magnet synchronous motors (PMSMs) have some irreplaceable advantages, but there are also some disadvantages. As a type of PMSM, IPMSMs have problems with large fluctuations in permanent magnet (PM) magnetic field and demagnetization. At present, irreversible demagnetization of PMs is the most serious problem faced by IPMSMs. Once irreversible demagnetization of PMs occurs, it can cause a decrease in the performance of IPMSMs and can even damage the entire drive system. This paper takes an IPMSM with 48 slots, 8 poles, and 66 kW as the research object. Based on the reasons for PM demagnetization, a PM demagnetization model is established to obtain the demagnetization law of PMs. Firstly, the magnetic properties of PM materials were described based on their characteristic curves. The demagnetization mechanism of PMs was analyzed, and the demagnetization process of PMs was studied in combination with the reasons for demagnetization. Secondly, the basic parameters and torque performance of IPMSMs were calculated and analyzed. We analyzed the demagnetization curves of PM materials at different temperatures, calculated the operating points of PMs under various working conditions, and analyzed whether PMs undergo irreversible demagnetization based on the relationship between the operating points of PMs and the knee points of demagnetization curves. A high-fidelity electromagnetic–thermal coupling simulation model has been established, combined with the characteristics of electric vehicle driving conditions, to accurately characterize the temperature rise distribution and electromagnetic parameter changes of IPMSMs under different operating conditions and achieve multi-physics field collaborative analysis. Finally, a finite element model is adopted to simulate uniform and local demagnetization of PMs, and the changing characteristics of motor performance parameters under demagnetization are summarized. Different magnitudes of d-axis reverse current are applied as demagnetization excitation to analyze PM behaviors under various demagnetization degrees. The variations in magnetic flux density, output torque, and no-load back electromotive force (EMF) before and after demagnetization are simulated and analyzed. For the investigated motor and specific magnet grade, this work summarizes the irreversible demagnetization characteristics and corresponding practical judgment references. Full article
