Search Results (13)

Airborne array synthetic aperture radar (SAR) can achieve three-dimensional (3D) imaging of the observed scene in a single flight. Nevertheless, the imaging process of airborne array SAR is subject to various parameter errors due to unstable factors. Such errors degrade the quality of 3D imaging, particularly for the elevation imaging results, which necessitates the employment of super-resolution algorithms. The most significant error parameters include the amplitude and phase imbalances between multiple channels, as well as the phase-center positions of each channel. Owing to the coupled nature of these parameter errors, the calibration accuracy for each parameter independently is relatively sub-par, while super-resolution algorithms have strict demands for parameter precision. Addressing these challenges, this article proposes a multi-parameter calibration method for airborne array SAR based on the Newton method and the genetic algorithm. Initially, a least squares model for multi-parameter calibration is established, followed by leveraging the global optimization characteristics of genetic algorithms and the rapid convergence property of the Newton method. The genetic algorithm is utilized to locate a sub-optimal solution in proximity to the optimal one, subsequently converging swiftly to the optimal solution via the Newton method, which incorporates second-order information. This approach averts the pitfalls of local convergence due to large initial value errors, thereby enhancing the algorithm’s robustness. The proposed method effectively enhances the precision of multi-parameter calibration, which is of significant importance in ensuring the quality of 3D imaging of airborne array SAR. Full article

A convective cell storm containing two differential reflectivity (Z_DR) columns was observed with a dual-polarization phased-array radar (X-PAR) in Xixian County. Since a Z_DR column is believed to correspond to a strong updraft and a single convective cell is considered to have a simple dynamic structure with one updraft core, how these two Z_DR columns form and coexist is the focus of this study. The dynamic and microphysical structures around the two Z_DR columns are studied under the mutual confirmation of the X-PAR observations and a cloud model simulation. The main Z_DR column forms and maintains in an updraft whose bottom corresponds to a convergence of low-level and mid-level flow; it lasts from the early stages to the later stages. The secondary Z_DR column emerges at the rear of the horizontal reflectivity (Z_H) core relative to the moving direction of the cell; it forms in the middle stages and lasts for a shorter period, and its formation is under an air lifting forced by the divergent outflow of precipitation. Therefore, the secondary Z_DR column is only a by-product in the middle stages of the convection rather than an indicator of a new or enhanced convection. Full article

With the increasing use of the strategy and group target attack method in the modern battlefield, multi-target inverse synthetic aperture radar (ISAR) imaging simultaneously with high efficiency draws more and more attention, which gives a promising prospect for aerospace target detection and recognition in the multi-target scenario. To overcome the shortcomings of traditional multi-target imaging with one beam at one pulse repetition time (PRT) based on phase array radar (PAR), this paper proposes a novel multi-target imaging waveform design method based on the newly full digital array radar (DAR). Firstly, we propose using radar waveform diversity with 2D orthogonality to realize multi-target ISAR imaging with high imaging quality and efficiency. Then, to meet the constant modulus requirement for maximizing the transmitting power, orthogonal frequency division multiplexing (OFDM) chirp theory is proposed to directly generate the transmit waveform instead of the traditional optimization method with the nonconvex problem for waveform design. Based on time-variant weighted and time diversity technology, a of group transmit waveforms is designed, which can form multiple beams simultaneously and make the signals arriving at different targets approximately orthogonal. Finally, simulations and experiments are carried out to demonstrate the effectiveness of the proposed method. Full article

The consumption of phased array radar (PAR) resources affects the accuracy of its multi-target searching and tracking abilities. The jamming methods aimed at PAR involve deceptive jamming and comprehensive jamming strategies, but have the disadvantages of high cost and complexity. Given this context, this paper proposes a PAR resource consumption method based on phase-switched screen (PSS), and derives a relationship between the targets and the evaluation indicators. By implementing periodic modulation of PSS, a controlled number of deceptive multiple false targets can be generated, thereby enticing the radar system to engage in activities such as searching and tracking targets. When the quantity of false targets is increased, the number of beam requests becomes five times higher than compared to the scenario without false targets. This has also led the margin of time resources to exceed 50%, successfully achieving the objective of consuming radar resources. Furthermore, this method offers straightforward manipulation, flexibility, and the potential to significantly consume radar resources. The efficacy of the proposed method is confirmed with the simulation outcomes. Full article

Polarimetric phased array radar (PAR) can achieve high temporal resolutions for improved meteorological observations with digital beamforming (DBF). The Fourier method performs DBF deterministically, and produces antenna radiation patterns with fixed sidelobe levels and angular resolution by pre-computing the beamforming weights based on the geometry of receivers. In contrast, the Capon method performs DBF adaptively in response to the changing environment by computing the beamforming weights from the received signals at multiple channels. However, it becomes computationally expensive as the number of receivers grows. This paper presents computationally efficient adaptive beamforming with an application of convolutional neural networks, named ABCNN. ABCNN is trained with the phase and amplitude of complex-valued time-series IQ signals and the Capon beamforming weights as input and output. ABCNN is tested and evaluated using simulated time-series data from both point targets and weather scatterers for a planar of fully digital PAR architecture. The preliminary results show that ABCNN lowers computation time by a factor of three, compared to the Capon method, for a phased array antenna with 1024 elements, while mitigating the contamination from sidelobes by placing nulls at the location of the clutter. Furthermore, ABCNN produces antenna patterns similar to those from the Capon method, which shows that it has successfully learned the data. Full article

In 2019–2020, an array weather radar (AWR) network consisting of seven X-band phased-array radars (PARs), with a detection spatial resolution of 30 m and a temporal resolution of 30 s, was built in the city of Foshan in China’s Guangdong Province. The detection time deviation in the same space is within 5 s. Through variational data assimilation, the three-dimensional wind field inside the storm can be obtained. This study selected instances of hail, thunderstorms, strong winds, and short-duration heavy precipitation in 2020 to conduct a detailed analysis. The results show the following: (1) The fine detection ability enables phased-array radars to detect the complete evolution process of convective storms, including development, strengthening, and weakening, providing a useful reference for judging the future variation trends of convective storms. (2) Through evolutionary analysis of the three-dimensional wind field, the dynamic mechanisms of storm strengthening and weakening could be obtained, which could serve as a reference to predict the development of storms. The gust wind index and convection index calculated based on the three-dimensional wind field could provide advanced warning for nowcasting. When the gust wind index was greater than 263, the probability of gale-force wind (above 17.0 m/s) was determined to be high. Moreover, the warning could be provided 10–20 min in advance. A convection index greater than 35 and the presence of concentrated contour lines were found to be conducive to the strengthening and formation of a convection, and the warning could be provided 20 min in advance. These results show that the application of PAR can provide important technical support for nowcasting severe convective weather. Full article

The differential propagation phase (Φ_DP) of X-band dual-polarization weather radar (including X-band dual-polarization phased-array weather radar, X-PAR) is important for estimating precipitation and classifying hydrometeors. However, the measured differential propagation phase contains the backscatter differential phase (δ), which poses difficulties for the application of the differential propagation phase from X-band radars. This paper presents the following: (1) the simulation and characteristics analysis of the backscatter differential phase based on disdrometer DSD (raindrop size distribution) measurement data; (2) an improved method of the specific differential propagation phase (K_DP) estimation based on linear programming and backscatter differential phase elimination; (3) the effect of backscatter differential phase elimination on the specific differential propagation phase estimation of X-PAR. The results show the following: (1) For X-band weather radar, the raindrop equivalent diameters D > 2 mm may cause a backscatter differential phase between 0 and 20°; in particular, the backscatter differential phase varies sharply with raindrop size between 3.2 and 4.5 mm. (2) Using linear programming or smoothing filters to process the differential propagation phase could suppress the backscatter differential phase, but it is hard to completely eliminate the effect of the backscatter differential phase. (3) Backscatter differential phase correction may improve the calculation accuracy of the specific differential propagation phase, and the optimization was verified by the improved self-consistency of polarimetric variables, correlation between specific differential propagation phase estimations from S- and X-band radar and the accuracy of quantitative precipitation estimation. The X-PAR deployed in Shenzhen showed good observation performance and the potential to be used in radar mosaics with S-band weather radar. Full article

X-band dual-polarization phased-array weather radars (X-PARs) have been used in South China extensively. Eliminating the attenuation and system bias of X-band radar data is the key to utilizing the advantage of X-PAR networks. In this paper, the disdrometer raindrop-size distribution (DSD) measurements are used to calculate the radar polarimetric variables and analyze the characteristics of precipitation attenuation. Furthermore, based on the network of S-band dual-polarization Doppler weather radar (S-POL) and X-PARs, an attenuation-correction method for X-PAR reflectivity is proposed with S-POL constraints in view of the radar-mosaic requirements of a multi-radar network. Linear programming is used to calculate the attenuation-correction parameters of different rainfall areas, which realizes the attenuation correction for X-PAR. The results show that the attenuation-correction parameters simulated based on the disdrometer DSD vary with different precipitation classification; the attenuation-corrected reflectivity of X-PARs is consistent with S-POL and can realize a more precise observation of the evolution of the convective system. Compared with previous attenuation-correction methods with constant correction parameters, the improved method can reduce the deviation between X-PAR reflectivity and that of S-POL in heavy rainfall areas and areas of strong attenuation. The method proposed in this paper is stable and effective. After effective quality control, it is found that the X-PAR network deployed in South China observes data accurately and is consistent with S-POL; thus, it is expected to achieve high temporal–spatial resolution within a radar mosaic. Full article

In this study, the quantitative precipitation estimation (QPE) capability of three X-band dual-polarization phased array radars (PAR) in Guangzhou, South China, was demonstrated, with an S-band operational dual-polarization radar as the benchmark. Rainfall rate (R) estimators based on the specific differential phase (K_DP) for summer precipitation for both X-band and S-band radars were derived from the raindrop size distributions (DSDs) observed by a 2-dimensional video disdrometer (2DVD) in South China. Rainfall estimates from the radars were evaluated with gauge observations in three events, including pre-summer rainfall, typhoon precipitation, and local severe convective precipitation. Observational results showed that radar echoes from the X-band PARs suffered much more severely from attenuation than those from the S-band radar. Compared to S-band observations, the X-band echoes can disappear when the signal-to-noise ratio drops to a certain level due to severe attenuation, resulting in different estimated rainfall areas for X- and S-band radars. The attenuation corrected by K_DP had good consistency with S-band observations, but the accuracy of attenuation correction was affected by DSD uncertainty and may vary in different types of precipitation. The QPE results demonstrated that the R(K_DP) estimator produced better rainfall accumulations from the X-band PAR observations compared to the S-band observations. For both the X-band and S-band radars, the estimates of hourly accumulated rainfall became more accurate in heavier rainfall, due to the decreases of both the DSD uncertainty and the impact of measurement errors. In the heavy precipitation area, the estimation accuracy of the X-band radar was high, and the overestimation of the S-band radar was obvious. Through the analysis of the Z_H-Z_DR distribution in the three weather events, it was found that the X-band PAR with the capability of high spatiotemporal observations can capture minute-level changes in the microphysical characteristics, which help improve the estimation accuracy of ground rainfall. Full article

A novel power amplifier unit for a phased array radar with 2 × 2 output ports for a vacuum electron device is proposed. Double parallel connecting microstrip meander-lines are employed as the slow-wave circuits of a large power traveling wave tube operate in a Ka-band. The high frequency characteristics, the transmission characteristics, and the beam–wave interaction processes for this amplifier are simulated and optimized. For each output port of one channel, the simulation results reveal that the output power, saturated gain, and 3-dB bandwidth can reach 566 W, 27.5 dB, and 7 GHz, respectively. Additionally, the amplified signals of four output ports have favorable phase congruency. After fabrication and assembly, transmission tests for the 80-period model are performed preliminarily. The tested “cold” S-parameters match well with the simulated values. This type of integratable amplifier combined with a vacuum device has broad application prospects in the field of high power and broad bandwidth on a millimeter wave phased array radar. Full article

This paper presents the concept of a passive bistatic radar (PBR) system using existing phased array radar (PAR) as the source of illumination. Different from PBR based on common civil illuminators of opportunity, we develop an experimental PBR system using an high-power air surveillance PAR with abundant signal modulation forms as the transmitter. After the introduction of the PBR system and PAR signals, it can be concluded that the agility of the waveform parameters of PAR signal brings two problems to the signal processing of the PBR systems, which are not discussed in conventional PBR systems. The first problem is the time and frequency synchronization of the system, so we propose a direct wave parameter estimation method based on template matching to estimate the parameters of the transmitted signal in real time to achieve time and frequency synchronization of the system. The second problem is the coherent integration for moving target detection and weak target detection, so we propose a coherent integration method based on Radon–Nonuniform Fast Fourier Transform (Radon-NUFFT) to deal with the problems introduced by the agile waveform parameters. Preliminary results from the field experiment demonstrate the feasibility of the PBR system based on PAR signals, and the effectiveness of the proposed methods is verified. Full article

The cross-range resolution of forward-looking phase array radar (PAR) is limited by the effective antenna beamwidth since the azimuth echo is the convolution of antenna pattern and targets’ backscattering coefficients. Therefore, deconvolution algorithms are proposed to improve the imaging resolution under the limited antenna beamwidth. However, as a typical inverse problem, deconvolution is essentially a highly ill-posed problem which is sensitive to noise and cannot ensure a reliable and robust estimation. In this paper, multi-channel deconvolution is proposed for improving the performance of deconvolution, which intends to considerably alleviate the ill-posed problem of single-channel deconvolution. To depict the performance improvement obtained by multi-channel more effectively, evaluation parameters are generalized to characterize the angular spectrum of antenna pattern or singular value distribution of observation matrix, which are conducted to compare different deconvolution systems. Here we present two multi-channel deconvolution algorithms which improve upon the traditional deconvolution algorithms via combining with multi-channel technique. Extensive simulations and experimental results based on real data are presented to verify the effectiveness of the proposed imaging methods. Full article

In launching operations, Rocket Tracking Systems (RTS) process the trajectory data obtained by radar sensors. In order to improve functionality and maintenance, radars can be upgraded by replacing antennas with parabolic reflectors (PRs) with phased arrays (PAs). These arrays enable the electronic control of the radiation pattern by adjusting the signal supplied to each radiating element. However, in projects of phased array radars (PARs), the modeling of the problem is subject to various combinations of excitation signals producing a complex optimization problem. In this case, it is possible to calculate the problem solutions with optimization methods such as genetic algorithms (GAs). For this, the Genetic Algorithm with Maximum-Minimum Crossover (GA-MMC) method was developed to control the radiation pattern of PAs. The GA-MMC uses a reconfigurable algorithm with multiple objectives, differentiated coding and a new crossover genetic operator. This operator has a different approach from the conventional one, because it performs the crossover of the fittest individuals with the least fit individuals in order to enhance the genetic diversity. Thus, GA-MMC was successful in more than 90% of the tests for each application, increased the fitness of the final population by more than 20% and reduced the premature convergence. Full article
