Pile splicing is generally considered in construction because of transportation limits, length requirements, construction means and methods, and strength capacity. A major challenge in the use of precast prestressed UHPC piles is the lack of efficient and effective splicing solutions. To address the problem, this study evaluated different pile splicing methods for UHPC H-piles and their constructability. The analysis and design for strength capacity and detailing presented here are based on relevant established guidelines and design codes for UHPC. This study assessed two pile splicing methods: epoxy-bonded dowels and near-surface mounted bars (NSMBs). The analysis demonstrated that the epoxy-bonded dowel method provides a moment capacity that is 127% of the pile moment capacity in the strong direction and 139% of the pile moment capacity in the weak direction. In comparison, the NSMB method achieved 121% in the strong direction and 106% in the weak direction. Both methods developed the established strength capacity requirements. The constructability of both pile splicing options was evaluated to provide practical guidelines for their preparation in preplanned and unplanned situations. The results reported are for 18-inch UHPC H-piles; however, the construction and analytical approach applies to other pile sizes as well. The pile splicing options developed are recommended for further experimental investigations. Full article

A new type of precast pile, namely steel strand square piles with reinforcement (PRS), is proposed in present study, which uses steel strand as a prestressed reinforcement and is equipped with hot-rolled reinforcement. Two kinds of full-scale pile specimens with different reinforcement were constructed to study the bending performance by the full-scale tests. The finite element model was also performed to study the differences in bending resistance, deformation capacity, crack resistance, and failure mode because of the reinforcement ratio. The results show that the steel strand in the pile was not pulled off, and the concrete in the compression zone was crushed. The finite element analysis results are close to the results of the full-scale test of the piles, which can simulate the flexural performance of the pile well. The experimental results were closer to the theoretical calculation of the cracking moment. The ultimate bending moment value is about 25% more than the theoretical value. The parametric analysis shows that for the PRS with 0.27% prestressed reinforcement, the best bending performance is achieved with 0.64% non-prestressed reinforcement. For the PRS with 0.64% of non-prestressed reinforcement, the best bending performance is achieved with 0.37% of prestressed reinforcement. Full article

Prestressed, precast concrete piles using High-Strength Steel Strands (PPCPs using HSSS) are a new type of precast pile. Compared with prestressed high-strength concrete (PHC) piles, the adoption of ultra-high-strength concrete and HSSS not only improves the load-bearing capacity, but also enhances the ductility of precast piles. The engineering application of PPCPs using HSSS requires not only a high bearing capacity of the pile segments, but also reliable splicing to ensure cooperation between pile segments. Based on the characteristics of strand anchorage plates, this paper proposes a new combination splice using the clamp ring and welding (Combination Splice). The theoretical analysis and design method of this Combination Splice is introduced. This research gives a thorough investigation into the flexural performance of PPCPs using HSSS with the Combination Splice. The flexural tests of PPCPs using HSSS with the Combination Splice were firstly conducted on eight full-scale pile specimens with three different pile diameters and four different steel reinforcement ratios. The flexural performances are evaluated in terms of crack resistance, flexural capacities, crack distribution, as well as strain development. The results indicate that the Combination Splice remain safe and intact when the piles reach the ultimate bending capacity. The ultimate bending moment of tested specimens with the Combination Splice is, on average, 10% larger than that of specimens using a theoretical formula. In light of the experimental data, a finite element analysis (FEA) model has been created to simulate the flexural performance of the piles with the Combination Splice. The FEA results show that the load–displacement curves and crack distribution regions are in good agreement with the experimental findings, which verifies the reliability and accuracy of the FEA model. The parameter analysis investigates the effects of the assembly gap and clamp ring corrosion on the flexural performance of PPCPs using HSSS. The results show that assembly gaps have a greater influence on the flexural capacity and deformation, while the influence of the clamp ring corrosion is negligible, indicating that the Combination Splice has certain advantages in terms of durability. Full article

This research optimizes the environmental impact of a conventional building foundation in Northern Europe while considering the economic cost. The foundation is composed of piles and ground beams. Calculations are performed following relevant building Eurocodes and using life cycle assessment methodology. Concrete and steel accounted for the majority of the environmental impact of foundation alternatives; in particular, steel on piles has a significant influence. Selecting small sections of precast piles or low-reinforcement vibro-piles instead of continuous-flight auger piles can reduce the environmental impacts and economic costs of a foundation by 55% and 40%, respectively. However, using precast beams rather than building them on site can increase the global warming potential (GWP) by up to 10%. Increasing the concrete strength in vibro-piles can reduce the eco-costs, ReCiPe indicator, and cumulated energy demand (CED) by up to 30%; the GWP by 25%; and the economic costs by up to 15%. Designing three piles instead of four piles per beam reduces the eco-costs and ReCiPe by 20–30%, the GWP by 15–20%, the CED by 15–25%, and the costs by 12%. A Pareto analysis was used to select the best foundation alternatives in terms of the combination of costs and eco-burdens, which are those with vibro-piles with higher concrete strengths (low reinforcement), cast in situ or prefabricated beams and four piles per beam. Full article

Mechanical performance monitoring of civil infrastructure using fiber Bragg grating (FBG) sensors has received significant public attention in recent years. However, there is currently little research on the mechanical performance monitoring of piles used in high-piled wharfs in coastal ports during pile driving using the FBG sensor technique. Based on the properties of precast prestressed concrete piles used in high-piled wharfs in coastal ports and servicing seawater environments, and the benefits of FBG sensors, the mechanical performance monitoring for precast prestressed concrete piles used in a newly-built high-piled wharf in the Tianjin Port of China is devised and deployed with the FBG sensor technique. To conduct performance monitoring of the precast prestressed concrete pile, a state-of-the-art FBG strain sensor, which is less thermosensitive and does not require temperature compensation, was used to monitor the strain status of different locations of the pile. In one pile, three of this kind of strain sensor were set near the head, middle and tip of the pile, and one FBG angle sensor was set near the head of the pile to measure the dip angle of the pile. During the testing, data were recorded for all of the details of the pile driving process. According to the data analysis, it is clear that the compressive strain at the middle of the pile during driving is larger than that near the head and tip of the pile. Therefore, the middle of the prestressed concrete pile is the key location that should be preferentially monitored during pile driving. Meanwhile, when the hammer impacts the pile continuously, the obvious tension strain at the tip of the pile increases and the maximum dynamic tension strain reaches 56 με, which approaches the tension ultimate strain. This occurs because the frictional resistance of soil is small in the middle of the pile when the tip meets the significant supporting soil layer. This study can provide a reference for the mechanical performance monitoring deployment of precast prestressed concrete piles used in high-piled wharf structures in coastal ports. Full article
